Typ e
Nominal Dimension
(with Sleeve)
Applications
Nominal Voltage
Capacity
Charging Condition
Fast Charge
Service Life
Continuous
Overcharge
Weight
Internal Resistance
Max. Charging
Voltage
Ambient Temperature
Range
Fast Charge (Charge control required)
1.6
800mA
(1C)
1.5
: Rechargeable Nickel Metal
Hydride Cylindrical Cell
: Φ = 10.5mm
H = 44.5mm
: Recommended discharge current
80 to 2400mA
: 1.2V
: Nominal: 800mAh
Minimum: 780mAh
Typical: 800mAh
When discharged at 160mA to
1.0V at 20℃
: 80mA for 16 hrs at 20℃
: 400mA to 800mA (0.5 to 1C) charge
termination control recommended
control parameters:
-∆V : 0-5mV
**DT/dt
**TCO
**Timer
** for ref. only
: >500 cycles (IEC standard)
: 80mA maximum current for 1 year.
No conspicuous deformation and/or
leakage
: 14.0g
: Average 40mΩ upon fully charged
(Range 20 – 60mΩ) at 1000Hz
: 1.5V at 80mA charging
: Standard Charge : 0 to 45℃
Fast Charging : 10 to 45℃
Discharge : -20 to 50℃
Storage : -20 to 35℃
: 0.8℃/min (0.5 to 0.9C)
0.8 - 1℃/min (1C)
: 45 - 50℃
: 105% nominal input
Model No.:
Low Rate Discharge
1.5
1.4
1.3
1.2
1.1
1
Voltage(V)
0.9
0.8
0.7
0 2 4 6 8 10 12 14
High Rate Discharge
400mA
(0.5C)
GP80AAAHC
Charge:80mA x 16hrs at 20°C
160mA
(0.2C)
Discharge Time (Hrs)
Charge:80mA x 16hrs at 20°C
80mA
(0.1C)
1.4
1.3
Voltage (V)
1.2
1.1
0 20 40 60 80 100 120 140 16
Capacity Input ( % )
400mA
0.5C)
2400mA
(3C)
1600mA
(2C)
800mA
(1C)
The information (subject to change without prior notice) contained in
this document is for reference only and should not be used as a basis
for product guarantee or warranty. For applications other than those
described here, please consult your nearest GP Sales and Marketing
Office or Distributors.
www.gpbatteries.com.hk
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice.
Copyright@GPI International Ltd. – All rights reserved
TRS0253 Rev.05
