0
(
Typ e
Nominal Dimension
(with Sleeve)
Applications
Nominal Voltage
Capacity
Charging Condition
Fast Charge
Service Life
Continuous
Overcharge
Weight
Internal Resistance
Max. Charging
Voltage
Ambient Temperature
Range
Fast Charge (Charge control required)
1.6
750mA
(1C)
1.5
: Rechargeable Nickel Metal
Hydride Cylindrical Cell
: Φ = 10.5mm
H = 44.5mm
: Recommended discharge current
75 to 2250mA
: 1.2V
: Nominal: 750mAh
Minimum: 730mAh
Typical: 750mAh
When discharged at 150mA to
1.0V at 20℃
: 75mA for 16 hrs at 20℃
: 375mA to 750mA (0.5 to 1C) charge
termination control recommended
control parameters:
-∆V : 0-5mV
**DT/dt
**TCO
**Timer
** for ref. only
: >500 cycles (IEC standard)
: 75mA maximum current for 1 year.
No conspicuous deformation and/or
leakage
: 13.0g
: Average 35mΩ upon fully charged
(Range 20 – 40mΩ) at 1000Hz
: 1.5V at 75mA charging
: Standard Charge : 0 to 45℃
Fast Charging : 10 to 45℃
Discharge : -20 to 50℃
Storage : -20 to 35℃
: 0.8℃/min (0.5 to 0.9C)
0.8 - 1℃/min (1C)
: 45 - 50℃
: 105% nominal input
Model No.:
Low Rate Discharge
1.5
1.4
1.3
1.2
1.1
1
Voltage(V)
0.9
0.8
0.7
0 2 4 6 8 10 12 14
High Rate Discharge
375mA
(0.5C)
GP75AAAHC
Charge:75mA x 16hrs at 20°C
150mA
(0.2C)
Discharge Time (Hrs)
Charge:75mA x 16hrs at 20°C
75mA
(0.1C)
1.4
1.3
Voltage (V)
1.2
1.1
0 20 40 60 80 100 120 140 16
Capacity Input ( % )
375mA
0.5C)
2250mA
(3C)
1500mA
(2C)
750mA
(1C)
