Page 1
0
(1C)
(2C)
(3C)
(
Typ e
Nominal Dimension
(with Sleeve)
Applications
Nominal Voltage
Capacity
Charging Condition
Fast Charge
Service Life
Continuous
Overcharge
Weight
Internal Resistance
Max. Charging
Voltage
Ambient Temperature
Range
Fast Charge (Charge control required)
1.6
400mA
(1C)
1.5
: Rechargeable Nickel Metal
Hydride Cylindrical Cell
: Φ = 10.5mm
H = 36.2mm
: Recommended discharge current
40 to 1200mA
: 1.2V
: Nominal: 400mAh
Minimum: 400mAh
Typical: 420mAh
When discharged at 80mA to
1.0V at 20℃
: 40mA for 16 hrs at 20℃
: 200mA to 400mA (0.5 to 1C) charge
termination control recommended
control parameters:
-∆V : 0-5mV
**DT/dt
**TCO
**Timer
** for ref. only
: >500 cycles (IEC standard)
: 40mA maximum current for 1 year.
No conspicuous deformation and/or
leakage
:9.30g
: Average 80mΩ upon fully charged
(Range 70 – 90mΩ) at 1000Hz
: 1.5V at 40mA charging
: Standard Charge : 0 to 45℃
Fast Charging : 10 to 45℃
Discharge : -20 to 50℃
Storage : -20 to 35℃
: 0.8℃/min (0.5 to 0.9C)
0.8 - 1℃/min (1C)
: 45 - 50℃
: 105% nominal input
Model No.:
+0
10.5
-0.7
+0
36.2
-1
Low Rate Discharge
1.5
1.4
1.3
1.2
1.1
1
Voltage(V)
0.9
0.8
0.7
0 2 4 6 8 10 12 14
High Rate Discharge
200mA
(0.5C)
GP40AAAH
4.7 (Ref)
Unit : mm
Charge:40mA x 16hrs at 20°C
80mA
(0.2C)
Discharge Time (Hrs)
Charge:40mA x 16hrs at 20°C
40mA
(0.1C)
1.4
1.3
Voltage (V)
1.2
1.1
0 20 40 60 80 100 120 140 16
Capacity Input ( % )
200mA
0.5C)
1200mA
800mA
400mA
The information (subject to change without prior notice) contained in
this document is for reference only and should not be used as a basis
for product guarantee or warranty. For applications other than those
described here, please consult your nearest GP Sales and Marketing
Office or Distributors.
www.gpbatteries.com.hk
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice.
Copyright@GPI International Ltd. – All rights reserved
TRS0067 Rev.05
