Type
Nominal Dimension
(with Sleeve)
Applications
Nominal Voltage
Capacity
Charging Condition
Fast Charge
Service Life
Continuous
Overcharge
Weight
Internal Resistance
Max. Charging
Voltage
Ambient Temperature
Range
Fast Charge (Charge control required)
Voltage (V)
9.6
9
: Rechargeable Nickel Metal
Hydride Cylindrical Cell
: 17.5mm(i) x 26.2mm(w) x 48.5mm(h)
: Recommended discharge current
30 to 900mA
: 7.2V
: Nominal: 300mAh
Minimum: 300mAh
Typical: 320mAh
When discharged at 60mA to
6.0V at 20℃
: 30mA for 16 hrs at 20℃
: 150mA to 300mA (0.5 to 1C) charge
termination control recommended
control parameters:
-∆V : 0-5mV
**DT/dt
**TCO
**Timer
** for ref. only
: >500 cycles (IEC standard)
Up to 1000 cycle (not less than 60% of
nominal at 0.1C charge / 0.2C discharge)
: 30mA maximum current for 1 year.
No conspicuous deformation and/or
leakage
: 48.5g
: Maximum 900mΩ upon fully charged
at 1000Hz
: 9.0V at 30mA charging
: Standard Charge : 0 to 45℃
Fast Charging : 10 to 45℃
Discharge : -20 to 50℃
Storage : -20 to 35℃
: 0.8℃/min (0.5 to 0.9C)
0.8 - 1℃/min (1C)
: 45 - 50℃
: 105% nominal input
300mA
Model No.:
12.7mm
26.20mm
Low Rate Discharge
Voltage (V)
9
8.4
7.8
7.2
6.6
6
5.4
4.8
150mA
0.5C
4.2
02468101214
High Rate Discharge
Voltage (V)
9
8.4
7.8
7.2
8.4
7.8
7.2
150mA
0.5C
6.6
5.4
4.8
6
900mA
(3C)
4.2
6.6
0 10203040506070
0 20 40 60 80 100 120 140 160
Capacity Input (%)
The information (subject to change without prior notice) contained in
this document is for reference only and should not be used as a basis
for product guarantee or warranty. For applications other than those
described here, please consult your nearest GP Sales and Marketing
Office or Distributors.
www.gpbatteries.com.hk
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice.
Copyright@GPI International Ltd. – All rights reserved
GP30R7H
17.5mm
48.50mm
46.40mm
Unit: mm
Charge: 30mA x 16hrs at 20oC
60mA
0.2C
Discharge Time (Hrs)
Charge: 30mA x 16hrs at 20oC
600mA
Discharge Time (Mins)
30mA
(0.1C)
300mA
(1C)
TRS0345 Rev.03
