Data Sheet Model No.: GP220CH
V
Rechargeable Nickel Metal Hydride
(with Sleeve)
Overcharge
Voltage
Temperature Range
+ 0
- 1.5
26.20mm
φ
φφ
φ
+ 0
- 2.0
50.00mm
:Type
Cylindrical Cell
:Nominal Dimension
∅ = 26.2mm
H = 50.0mm
Recommended discharge current
:Application
220mA to 6600mA
1.2V:Nominal Voltage
Minimum : 2150mAh
:Nominal Capacity
Typical : 2200mAh
when discharged at 440mA to 1.0V at
o
20
C
220mA for 16 hrs at 20
:Fast Charge
1100mA (0.5C)
o
C:Charging Condition
with charge termination control.
Recommended control parameter :
0-5mV
-∆V
dT/dt
TCO
Timer
:
o
0.8
:
C/min (0.5C)
:
:
o
45-50
C
105% nominal input
(Secondary)
:Service Life
> 500 cycles (IEC standard)
Up to 1000 cycles (not less than 60% of
nominal at 0.1C charge / 0.2C discharge)
:Continuous
220mA maximum current
No conspicuous deformation and/or
leakage
61.0g:Weight
:Internal Resistance
Average 30mΩ upon fully charged
(Range : 20-40mΩ) at 1000Hz
1.5V at 220mA charging:Max. Charging
:Ambient
Standard Charging
Fast Charging
Discharging
Storage
Storage (1 week)
5.5 - 7.5 mm
φφφφ
Unit : mm
:
:
:
:
:
1.5 MIN
0oC to 40oC
o
10
C to 40oC
o
-20
C to 50oC
o
-20
C to 35oC
o
-20
C to 60oC
Fast Charge (Charge Control required)
oltage (V)
1.6
1.5
1.4
1.3
1.2
1.1
1.0
020406080100120
Capacity Input (%)
Low Rate Discharge
Voltage (V)
1.5
1.4
1.3
1.2
1.1
1
0.9
0.8
1,100mA
(0.5C)
024681012
Charge : 220 mA x 16 hrs at 20
440mA
(0.2C)
Discharge Time (Hrs)
High Rate Discharge
Voltage (V)
1.5
1.4
1.3
1.2
1.1
1
6,600mA
0.9
(3C)
0.8
0 10203040506070
Charge : 220 mA x 16 hrs at 20
4,400mA
(2C)
Discharge Time (Mins)
* The information (subject to change without prior
notice) contained in this document is for reference
only and should not be used as a basis for product
guarantee or warranty. For application other than
those described here, please consult GP Sales and
Marketing Office or Distributors.
1100 mA
(0.5C)
220mA
2,200mA
(1C)
1111
C
(0.1C)
1111
C
140
