0 to 45oC
:
Standard Charging
:
Ambient Temperature
29.5g
:
Weight
No conspicuous deformation and/or leakage
Overcharge
>500 cycles (IEC standard)
:
Service Life
1050mA to 21
0
0mA (0.5 to 1C)
:
Fast Charge
210mA for 1
6
hrs at 20
o
C
:
Charging Condition
when discharged at 420mA to 1.0V at 20
C
Recommended discharge current
:
Applications
Φ =14.5mm
:
Nominal Dimension
Data Sheet Model No.: GP210AAH
___________________________________________________________________________________________________
Capacity input %
Discharge Time (Hrs)
Discharge Time (Mins)
14.5
49.5
+0
Charge: 210mA x 1
6
hrs at 20
o
C
4200mA
2100mA
1050mA
Charge: 210mA x 1
6
hrs at 20
o
C
1050mA
420mA
210mA
6.3(REF.)
(with Sleeve)
Rechargeable Nickel Metal Hydride
:Type
Cylindrical Cell
H =49.5mm
210 to 6300mA
1.2V:Nominal Voltage
Nominal: 2100mAh
:Capacity
Minimum: 2100mAh
Typical: 2150mAh
charge termination control recommended
control parameters:
-∆V : 0 - 5mV
DT/dt : 0.8oC/min (0.5 to 0.9C)
: 0.8 - 1oC/min (1C)
TCO : 45 - 50oC
Timer : 105% nominal input
Up to 1000 cycles (not less than 60% of
nominal at 0.1C charge / 0.2C discharge)
210mA maximum current for 1 year
:Continuous
Fast Charge (Charge control required)
Voltage (V)
1.6
1.5
(1C)
1.4
1.3
(0.5C)
1.2
o
1.1
0 20 40 60 80 100 120 140 160
Low Rate Discharge
Voltage (V)
1.5
1.4
1.3
1.2
1.1
1
0.9
0.8
0.7
(0.5C)
(0.2C)
(0.1C)
0 2 4 6 8 10 12 14
Range
___
Average 24mΩ upon fully charged
:Internal Resistance
(Range 16-30mΩ) at 1000Hz
1.5V at 210mA charging:Max. Charging Voltage
Fast Charging
Discharging
Storage
+0
-1
-1
Unit : mm
10 to 45oC
:
-20 to 50oC
:
-20 to 35oC
:
High Rate Discharge
Voltage (V)
1.5
1.4
1.3
1.2
1.1
1
0.9
0.8
0.7
6300mA
(3C)
(2C)
2100mA
(1C)
0 10 20 30 40 50 60 70
* The information (subject to change without prior
notice) contained in this document is for reference
only and should not be used as a basis for product
guarantee or warranty. For applications other than
those described here, please consult your nearest
GP Sales and Marketing Office or Distributors.
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice. CRS3838 Rev.00
