(3C)
(1C)
Type
Nominal Dimension
(with Sleeve)
Applications
Nominal Voltage
Capacity
Charging Condition
Fast Charge
Service Life
Continuous
Overcharge
Weight
Internal Resistance
Max. Charging
Voltage
Ambient Temperature
Range
Fast Charge (Charge control required)
Voltage (V)
11.2
170mA
10.5
9.8
9.1
8.4
7.7
0 20 40 60 80 100 120 140 160
: Rechargeable Nickel Metal
Hydride Cylindrical Cell
: 15.7mm(i) x 26.5mm(w) x 48.5mm(h)
: Recommended discharge current
17 to 510mA
: 8.4V
: Nominal: 170mAh
Minimum: 170mAh
Typical: 175mAh
When discharged at 34mA to 7.0V at 20℃
: 17mA for 16 hrs at 20℃
: 85mA to 170mA (0.5 to 1C) charge
termination control recommended
control parameters:
-∆V : 0-5mV
**DT/dt
**TCO
**Timer
** for ref. only
: >500 cycles (IEC standard)
Up to 1000 cycle (not less than 60% of
nominal at 0.1C charge / 0.2C discharge)
: 17mA maximum current for 1 year.
No conspicuous deformation and/or
leakage
: 32.0g
: Maximum 2000mΩ upon fully charged
at 1000Hz
: 10.5V at 17mA charging
: Standard Charge : 0 to 45℃
Fast Charging : 10 to 45℃
Discharge : -20 to 50℃
Storage : -20 to 35℃
: 0.8℃/min (0.5 to 0.9C)
0.8 - 1℃/min (1C)
: 45 - 50℃
: 105% nominal input
85mA
(0.5C)
Capacity Input (%)
Model No.:
12.7mm
26.50mm
15.7mm
48.50mm
46.00mm
Unit: mm
GP17R8H
Low Rate Discharge
Voltage (V)
10.5
9.8
9.1
8.4
7.7
7
6.3
85mA
5.6
(0.5C)
4.9
0 2 4 6 8 10 12 14
Discharge Time (Hrs)
High Rate Discharge
Voltage (V)
10.5
9.8
9.1
8.4
7.7
7
6.3
5.6
4.9
0 10203040506070
510mA
Discharge Time (Mins)
Charge: 17mA x 16hrs at 20oC
34mA
(0.2C)
Charge: 17mA x 16hrs at 20oC
340mA
(2C)
17mA
(0.1C)
170mA
(1C)
The information (subject to change without prior notice) contained in
this document is for reference only and should not be used as a basis
for product guarantee or warranty. For applications other than those
described here, please consult your nearest GP Sales and Marketing
Office or Distributors.
www.gpbatteries.com.hk
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice.
Copyright@GPI International Ltd. – All rights reserved
TRS0204 Rev.12
