Espresso Multi Capsule
Machine
USER
MANUAL
Model# GCM-7000
Read this manual thoroughly
before using and save it for
future reference
Model: CG9129-GS
© 2016 Gourmia
www.gourmia.com
The Steelstone Group
Brooklyn, NY
All rights reserved. No portion of this manual may be reproduced by any means
whatsoever without written permission from The Steelstone Group, except for the
inclusion of quotations in a media review.
Although every precaution has been taken in the preparation of this manual, The
Steelstone Group assumes no responsibility for errors or omissions. Nor is any
liability assumed for damages resulting from the use of the information contained
herein. Although every eort has been made to ensure that the information
contained in this manual is complete and accurate, The Steelstone Group is not
engaged in rendering professional advice or services to the individual consumer;
further, The Steelstone Group shall not be held responsible for any loss or damage
allegedly arising from any information or suggestion in this manual.
2
Welcome to the Exciting World of
Fresh Ground Coee from Gourmia
Congratulations on your purchase of the Capsule and Ground Espresso Machine
from Gourmia, exclusively designed for the discerning espresso lover!
If you are one the those people who cherishes, or maybe even worships, a good
fresh ground cup of espresso – that “pick-me-up” goodness when you walk into
the room and the smell of freshly brewed, real, delicious espresso - you’ve made
the right choice.
With your new Gourmia Capsule and Ground Espresso Machine preparing fresh
ground espresso, and exceeding the expectations of your most demanding
coee connoisseurs, is only moments away. Whether you prefer fresh ground,
or the convenience and variety of capsules, we’re condent that you’ll nd your
new compact Espresso Machine from Gourmia easy and fun to use, with the end
results being is a fresh full-bodied espresso experience that you are sure to love
over and over again!
The pages of this manual oer full and comprehensive instructions to guide you
through the functions and features of the Gourmia Coee Grinder. Inside this
guide you will also nd information on its modes of operation, complete stepby-step instructions for the operation, assembly, cleaning, and maintenance of
your appliance.
Please read all safety instructions thoroughly to ensure safe usage at all times.
Thank you for your purchase! We sincerely hope you will enjoy this as well as all
the many innovative products brought to you by our family at Gourmia.
3
IMPORTANT SAFEGUARDS
1. Please read the Manual and safety notes thoroughly before beginning
operation.
2. Keep Coee Machine out of children’s reach.
3. Make sure voltage indicated on the rating plate agrees with that of
the electrical installation.
4. Damaged power cord cannot be used, the machine shall stay away
from heat sources and ammable materials:
5. Do not use the machine outdoors, immersed in liquid or close to heat
IMPORTANT SAFEGUARDS
source.
6. If the power supply cord is damaged, it must be replaced by the
manufacturer or its services agent or a similarly qualied person in
order to avoid a hazard.Please keepthe circuit dry and the use original
accessories.
7. Turn o the power and unplug the power before moving the machine.
8. The original packaging can well protect the coee machine during
the transportation, please retain the packaging box.
9. Proper use and maintenance will extend the life of your coee machine.
10. Do not open any component or cut o the power supply of the
coee machine during operation.
11. If machine does not work properly, contact the distributor. Do not
dismantle the machine or try to x it on you own. Bring the machine
to authorized service center for repair if necessary. The manufacturer
will assume no liability for any damage due to unauthorized servicing.
12. The machine should not be operated by the following people:
Children, people with mental illness, physical defect, or have a lack of
knowlege or experience using this product. Unless the said people
have been supervised or guided by qualied personnel who will take
full responsibility for thier safety during the operation.
FOR HOUSEHOLD USE ONLY
4
TABLE OF CONTENTS
Know Your Espresso Machine .......... 6
Before Using The Coee Grinder ..... 7
Using Your Espresso Machine .......... 8
Settings .........................................9
Trouble Shooting .........................10
Maintenance and Care .................11
TABLE OF CONTENTS
5
KNOW YOUR ESPRESSO MACHINE
CBTL/Cataly, K-fee, Verismo*
* by Starbucks
Drawer Storage
Compartment
Water Tank
KNOW YOUR ESPRESSO MACHINE
ON/OFF Button
Short Cup Button
Long Cup Button
Drawer
Drip Tray
Drawer Storage
Compartment
Cover
Drawer
Drip Tray
Choose the correct drawer
for your capsule brand.
Choice of 4 drawers.
More are available for
your specic sysytem.
6
NC Drawer
Nespresso
CK Drawer
Water Tank
Cover
Water Tank
Water Tank
Heating Stand
KNOW YOUR ESPRESSO MACHINE
Main Power Switch
DGDrawer GC Drawer
Power Cord
Water Tank
Cover
Water Tank
* by Starbucks
Docle Gusto Ground Coee
7
Using Your Gourmia Capsule Espresso Maker
3. The Water Tank should rst be
4. Fill the Water Tank with cool
USING YOUR ESPRESSO MACHINE
5. Cover the Water Tank with its
Main Switch
6. Connect the power plug to the
1. Remove all items from the box
carfully, and inspect to make
sure that there is no damage
to any part.
2. Place the Capsule Espresso
Machine on a dry secure sur-
face near a wall outlet.
cleaned throughly with warm
water, rinsed and dried before
use.
puried water only. Make sure
not to over ll the Water Tank.
lid, and place it rmly on the
Water Tank Heating Stand.
Water Tank
Cover
Water Tank
wall outlet, turn on the power
by pressing the Main Switch on
the bottom of the Water Tank
Heating Stand.
Once the power has
been turned
on the ON/OFF
button will turn
on red.
7. Press the red
button to turn
the unit on.
The button will begin
ashing blue light.
After ashing
numerous times
all the buttons will
turn Blue - indcating
Standby Mode.
Your Capsule Espresso
Machine is now ready to make
espresso or to be programmed.
(See instructions on next page)
8. Select your desired coee
capsule along with its corresponding drawer. (See chart
on previous page for available
choices.)
9. Place the coee capsule into
the drawer, and slide the drawer
into its slot in the front of the
unit.
10. Place your espresso cup onto
the Drip Tray below the coee
nozzle.
11. Choose the size of drink you
would like.
For a Long (65ml default) cup press the bottom blue button.
For a Short (30 ml default) cup press the middle button.
12. Time and volume may vary
depending on the capsule
brand you choose.
8
Setting the Quantity
1. While each button has a default setting for the amount of coee it will
dispense, you can also adjust its amount to suit your needs.
This can be accomplished while the unit is in standby mode - with ALL
THREE BUTTONS in BLUE.
2. For a small/short setting, press and hold down the Short Cup Button for
as long as you want it dispense coee (from 15 seconds but no longer
than 80 seconds) and then release it. The machine will remember this
setting when this button is used. To change the Long Cup setting simply
repeat the above instructions while holding down the Long Cup Button.
3. To return back to the default setting: Press the both, the Short and Long
Cup buttons at the same time untill they ash 3 times, the buttons will
now return to its default settings.
Setting the Temperature
1. While the unit has a default temperature setting, six more temperature
settings are available. The coee temperature may be increased 4 levels
and decreased 2 levels.
2. TO DECREASE TEMPERATURE LEVEL:
Unit must be in standby mode - with ON/OFF button in RED.
Note: Default level is considered Level 3.
• To decrease temperature by one
level, press the Short Cup Button for
one second - it will ash two times,
indicating that the Short Cup Button
will now dispense at level 2 heat
setting.
(To change back to default setting follow #3 step from above)
• To derease by two levels, press the
Short Cup Button two times it will now ash 1 time, indicating
that the Short Cup Button will now
dispense at level 1 heat setting.
(the lowest)
SETTING YOUR ESPRESSO MACHINE
3. TO INCREASE TEMPERATURE LEVEL:
Unit must be in standby mode - with ON/OFF button in RED.
Note: Default level is considered Level 3.
• To increase temperature by1one
level, press the
Long Cup Button
for one second -
it will ash 1 time,
indicating that the
Long Cup Button
was increased
by one level,
to level 4.
• To increase temperature by two
levels, press the
Long Cup Button
two times -
it will ash 2 times,
indicating that the
Long Cup Button
was increased
by two levels,
to level 5.
• To increase temperature by three
levels, press the
Long Cup Button
three times it will ash 3 times,
indicating that the
Long Cup Button
was increased
by three levels,
to level 6.
• To increase temperature by four
levels, press the
Long Cup Button
four times -
it will ash 4 times,
indicating that the
Long Cup Button
was increased by
4 levels, to level 7.
(the maximum)
9
TROUBLE SHOOTING
Trouble Shooting
NO LIGHT.
Check the power supply, fuse and main switch.
NO COFFEE.
Water tank may be empty?Fill water tank and press the button
Bor C several times to make sure the water tank supply water
smoothly
NOTHING HAPPENS AFTER PRESSING THE BUTTON
Check to make the drawer is in the right position. Pull drawer out
and slide it back in carefully.
The drawer can’t be pulled out
Turn o the machine to release the pressure inside the machine
then try to pull out the drawer again.
Loud noise
Check to see if the water tank is lled and the water inserted well
THE MACHINE TURNS OFF BY ITSELF
If the machine is not used for 25 minutes it will automatically go
into Energey Saving mode to protect the machine.
ALL LIGHTS ARE FLASHING
Switch o the machine for 1 minute and restart it again.
10
Maintenance and Care:
Daily cleaning and important information
1. WATER TANK: Take o the tank, remove rest of the water ,
clean with a soft cloth and rinse with clear water.
2. DRIP TRAY AND DRAWER: remove, remove the water or
coee residue, clean with a soft cloth and clean water.
3. EXTERIOR. Wipe the outer surface with a soft cloth regularly. Keep the appliance clean especially the switches and
plug to ensure safety.
NOTE: NO PARTS OF YOUR ESPRESSO CAPSULE MACHINE
SHOULD BE TO BE WASHED IN A DISHWASHER OR SIMILAR
HOME APPLIANCES.
WARRANTY & SERVICE
This Limited Warranty is for one full year from the date
of purchase. It is applicable to the original purchaser
only and is not transferable to a third party user. Repair
or replacement of defective parts is solely at the seller’s
discretion. In the event that repair isn’t possible, the
seller will replace the product/part. If product repair/
replacement won’t suce, the seller has the option of
refunding the cash value of the product or component
returned.
MAINTENANCE AND CARE
Product defects not covered under the Warranty
provisions include normal wear and damage incurred
from use or accidental negligence, misuse of instruction
specications or repair by unauthorized parties.
The manufacturing company is not liable for any
incidental or consequential damages incurred by such
circumstances.
11
FOR CUSTOMER SERVICE
QUESTIONS OR COMMENTS
VISIT US @ GOURMIA.COM
OR CALL 888.552.0033
Loading...
