GOTRON ELECTRONIC ARMOR2 Users manual

SHENZHEN GOTRON ELECTRONIC CO.,LTD

ulefone

ulefone Mobile Phone / Armor 2

User Manual

Thank you for choosing the Digital m obile phone.
After reading this guide you will be able to fully master the use of your

phone and appreciate all its functions and ease of use.

The availability of some services and features described in this manual
depends on the network and y our subs cri ptio n. T her ef ore, som e m enu i tems
may not be available in your phone. The shortcuts to menus and features
may also vary from phone to phone.

Our company reserves the right to revise this manual content without
prior notice.

1 / 32

Contents

Keys Description .................................................................................................... 4

Icons Description ................................................................................................... 5

Turn on/off the phone ............................................................................................ 6

Use as USB flash disk .......................................................................................... 6

Wi-Fi ......................................................................................................................... 7

Bluetooth ............................................................................................................... 10

Phone Settings ..................................................................................................... 11

Quick settings ....................................................................................................... 14

Change wallpaper ................................................................................................ 14

Theme and launcher settings ............................................................................ 15

Move/ Uninstall launcher application and view detail .................................... 15

Phone ..................................................................................................................... 15

People .................................................................................................................... 16

2 / 32

Messaging ............................................................................................................. 17

Browser .................................................................................................................. 18

Email ...................................................................................................................... 18

Gallery .................................................................................................................... 19

Clock ...................................................................................................................... 19

Multimedia features ............................................................................................. 19

Personalized applications ................................................................................... 20

Simple Trouble shooti ng ...................................................................................... 20

Important Safety Information ............................................................................. 22

3 / 32

Keys Description

4 / 32

Description

Key

Home ●At any status, press the key to return to the standby

screen.

Power ● Hold down this key to turn your phone off and on.

● Generally, press this key to lock the mobile phone.

Volume ● During the conversation, press the two keys to adjust

the volume.

● While playing an audio file, press the two keys to

adjust the volume.
Menu ●Show options of current menu.
Back ●Return to the previous menu.

Icons Description

Icon state Icon state

Signal strength
No service

3G network hasbeen connected

Roaming
Bluetooth on
Vibrate mode on
Alarm on
Full power
New message
NFC is open

No single

GPRS

4G network has been connected

Airplane mode on
GPS is positioning
Silent mode on
Charging
More notifications
New Email
Missed calls

network has been connected

SIM card not detected

5 / 32

WLAN has been connected

Uploading
App permission
USB connected

Downloading
Headphones are inserted
USB sharing networks on

Turn on/off the phone
Turn on the phone

Long press the Power key to turn on the phone.
Tip: If you turn on the UIM/SIM card lock in Settings ,a PIN code is needed
after boot. As wel l as y ou inp ut the corr ect PI N cod e, the phon e can be used.
You can unlock the lock screen by sliding to either direction in unlock region
after boot.

Turn off the phone

Long press the Power key until phone options pop up,select Power off to
turn off the phone.

Use as USB flash disk

To copy music , photos, and other files from your computer to your
memory card, you must first set up the phone as a card U disk.

6 / 32

Set up the phone as a card U disk
Connected to the computer, select Connected as…, then select USB
storage.

Select USB connected and then select Turn on USB storage to load the
U disk so that you can copy music, photos, and other files from your PC to
your phone’s memory card or built-in memory card.

Note: When operating mobile assistant and other tools on the PC, you

must turn on USB debugging

• In the notification panel you can select to use your phone as a

Camera(PTP), Media device(MT P ), or Ch ar ge only.

Wi-Fi

Wi-Fi offers wireless network access range of 300 feet (100M) . To use
Wi-Fi with your phone, you must connect to a wireless access point or hot
spot.

7 / 32

Note: Availability and coverage of Wi-Fi signals is subject to the number
of devices , infrastructure, and oth er signals penetrate object.

Turn on WI-FI and connect to a wireless network.

1)Press Home> Menu, then select Settings.

2)Click on the Wi-Fi switch button In Wireless & networks to turn on

WLAN. The phone will automatically scan for available wireless networks.

3)Touch the Wi-Fi to enter the WLAN settings. The WLAN network list
displays the network name and security settings (open network or WEP,
WPA / WPA2 encrypted)of the WLAN network found . If you enable the
network notification in W LAN Advanced settings, the phone will remind you
an available open wireless network with a icon appearing in the status bar.

4)Select one WLAN network to connect it. When you select an open
network, the phone will automatically connect to the network. If you choose
the WEP, WPA / WPA2 encrypted network, you must first input the

8 / 32

appropriate password to connect it.

•Note: When the phone is connected to a wireless network, the status
bar displays a Wi-Fi icon and shows the approximate signal strength
(number of strip lights). If you select a wireless network connected, the
name of the WLAN network, status, speed, signal strength, security
information and the IP address is displayed.
If you want to remove the wireless network settings in your phone, select
Forget button. If you want to connect to the network, you must re-input
these settings.

• Note: In addition, the phone can also access to Internet via GPRS. Users
can manually select it in the specific location of Settings> Mobile
networks> Data connection.and select data connection to turn on or of f th e
current SIM card data connecti on.

9 / 32

Bluetooth

1)Select Settings.

2)In the wireless and network, click on the Bluetooth switch to turn on
Bluetooth. When turned on, the Bluetooth icon appears in the status bar.
The phone will automatically scan for Bluetooth devices.

3)Select Bluetooth to enter the Bluetooth settings, turn on Bluetooth or
set your phone to be detected and then the Bluetooth devices found
nearby will be displayed in the list below.

(Click on the name of the local Blu etooth devic e to set the phone t o be
detected by other Bluetooth devices so that other devices within the range
will be able to find the phone.)

•Note: The phone can be detected for longest two minutes. The
countdown time shows under the device .After two minutes the device
reverts to the undetectable state . Bluetooth devices typically require a

10 / 32
