Gotop VT810 User Manual

GPS Vehicle Tracker

User Manual

VT810

1. Please read this manual carefu lly for correct o peration.

2. You need to ask a professional to install this product in a safe position of your vehicle. Avoid dangerous or
unsuitable positions, otherwise, harm to the driver or passengers may occur.

3. This manual is just for your reference. The contents and operating steps described in this manual may be different
from that of the actual product, please refer to the actual product.

1. Overview

This vehicle tracker is a remote vehicle positioning device consisting of a GPS module and a GSM/GPRS module, which
is featured by compact size, good concealment and high precision. It can provide the GPS satellite positioning
information, and can also provide the positioning information supported by the GSM base station if the GPS satellite
information is unavailable, and the info rmation about the latitude and longitude coordinates can be sent to the system
platform and the preset mobile phone number. You can make us e of these features to locate and manage your v ehicle.

2. Definition

2. Installation of SIM card

There is a SIM card slot on the vehicle tracker. Insert the SIM card into the slot as illustrated

3. Operating environment

Operating temperature

-20---65℃
Humidity 5%---95%
Dimensions (mm) 90x53x21
Average current Less than 80MA ( On Standby)
Weigh 70g
PCBA Size

82×47 mm
Frequency GSM850/900/1800/1900 Mhz
GPS capability Hot start: <1.5s

Warm start: <34s

Cold start: <35s(Autonomous)

Position Accuracy: 3.0 m 2D-RMS ，DGPS: 2.5 m

Velocity Accuracy: 0.1m/s，DGPS:0.05m/s
GPS antenna 25×25×2 Built-in
GSM antenna Built-in
Sensor G-SENSOR
Button Turn On/ Off
Interface 2 pieces 4PIN Connector , 2 pieces 2PIN Connector
MIC External
Relay External
SOS Button External
Power Input voltage 9-57V
Inner Battery

3.7V，350MAH
Speaker NO
Indicator 2 LED
SIM Slot PUSH-PUSH

Note:

• The SIM card shall be GSM card

• Make sure to keep enough money in the SIM card account.

• Make sure the SMS service of the SIM card have been subscribed for. To use the real-time tracking by service
platform and positioning by SMS, the user has to subscribe for the GPRS service.
