Gosuncn Technology Group GM500U1A Users manual

HARDWARE DEVELOPMENT GUIDE

Version: V1.1

Date: 2018-04-28

LTE Module Series

GM500_U1A

Website: www.gosuncnwelink.com

E-mail: welink@gosuncn.com

GM500_U1A

Hardware Development Guide

Version

Date

Description

1.0

2018-04-18

1st released version

REVISION HISTORY

GM500_U1A

Hardware Development Guide

Abbreviations

Full Name

3GPP

Third Generation Partnership Project

AP

Another name of DTE

CHAP

Challenge Handshake Authentication Protocol

CE

European Conformity

CMOS

Complementary Metal Oxide Semiconductor

DCE

Data Communication Equipment

DL

Downlink

DTE

Data Terminal Equipment

EIA

Electronic Industries Association

EMC

Electromagnetic Compatibility

ESD

Electro-Static discharge

ESR

Equivalent Series Resistance

FDD

Frequency Division Duplex

GPIO

General-purpose I/O

LCC

Leadless Chip Carrier

ABOUT THIS DOCUMENT

A. Application Range

This document is the Product Technical Specification for the GM500_U1A GSM/WCDMA/LTE-FDD module. It defines the high level product features and illustrates the interface for these features. This document is intended to cover the hardware aspects of the product, including electrical and mechanical.

B. Reading Note

The symbols below are the reading notes you should pay attention on:

: WARNING or ATTENTION : NOTE or REMARK

C. Purpose

This document provides the hardware solutions and development fundamentals for a product with the module. By reading this document, the user can have an overall knowledge of the module and a clear understanding of the technical parameters. With this document, the user can successfully fulfill the application and development of wireless Internet product or equipment.

Besides the product features and technical parameters, this document also provides the product reliability tests and related testing standards, RF performance indexes and a guide on the design of user circuits, to provide the user with a complete design reference.

NOTE:

To ensure the module manufacturing and welding quality, do as the chapter 7 of Manufacturing Guide in

this document. The force on the squeegee should be adjusted so as to produce a clean stencil surface on a

single pass and ensure the module soldering quality.

D. Abbreviations

Table below is a list of abbreviations involved in this document, as well as the English full names.

GM500_U1A

Hardware Development Guide

LDO

Low-Dropout

LED

Light Emitting Diode

LTE

Long Term Evolution

ME

Mobile Equipment

MO

Mobile Origination Call

MT

Mobile Termination Call

MSB

Most Significant Bit

PC

Personal Computer

PCB

Printed Circuit Board

PDA

Personal Digital Assistant

PDU

Protocol Data Unit

PAP

Password Authentication Protocol

PPP

Point to Point Protocol

RTC

Real Time Clock

SMS

Short Messaging Service

SMT

Surface Mount Technology

SPI

Serial Peripheral Interface

TBD

To Be Determined

TCP

Transmission Control Protocol

TIS

Total Isotropic Sensitivity

TRP

Total Radiated Power

TVS

Transient Voltage Suppressor

UART

Universal Asynchronous Receiver-Transmitter

UDP

User Datagram Protocol

UL

Up Link

USB

Universal Serial Bus

USIM

Universal Subscriber Identity Module

URC

Unsolicited result code

VIH

Logic High level of input voltage

VIL

Logic Low level of input voltage

VOH

Logic High level of output voltage

VOL

Logic Low level of output voltage

GM500_U1A

Hardware Development Guide

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a

mobile while driving (even with a hands free kit) cause distraction and can lead to an accident. You must

comply with laws and regulations restricting the use of wireless devices while driving.

Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it switched off. The

operation of wireless appliances in an aircraft is forbidden to prevent interference with communication

systems. Consult the airline staff about the use of wireless devices on boarding the aircraft, if your device

offers a Airplane Mode which must be enabled prior to boarding an aircraft.

Switch off your wireless device when in hospitals or clinics or other health care facilities. These

requests are designed to prevent possible interference with sensitive medical equipment.

GSM cellular terminals or mobiles operate over radio frequency signal and cellular network and

cannot be guaranteed to connect in all conditions, for example no mobile fee or an invalid SIM card. While

you are in this condition and need emergent help, please remember using emergency call. In order to make

or receive call, the cellular terminal or mobile must be switched on and in a service area with adequate

cellular signal strength.

Your cellular terminal or mobile contains a transmitter and receiver. When it is on, it receives and

transmits radio frequency energy. RF interference can occur if it is used close to TV set, radio, computer or

other electric equipment.

In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices

such as your phone or other cellular terminals. Areas with potentially explosive atmospheres including

fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air

contains chemicals or particles such as grain, dust or metal powders.

SAFETY INFORMATION

The following safety precautions must be observed during all phases of the operation, such as usage, service or repair of any cellular terminal or mobile incorporating ME3610 module. Manufacturers of the cellular terminal should send the following safety information to users and operating personnel and to incorporate these guidelines into all manuals supplied with the product. If not so, GOSUNCN does not take on any liability for customer failure to comply with these precautions.

GM500_U1A

Hardware Development Guide

CONTENTS

1. Product Overview ....................................................................................................................................................................... 11

1.1. General Description ........................................................................................................................................................................... 11

1.2. Key Features 11

1.3. Function Diagram............................................................................................................................................................................... 12

1.4. Evaluation Board ................................................................................................................................................................................ 13

2. Application Interface ................................................................................................................................................................... 14

2.1. General Description ........................................................................................................................................................................... 14

2.2. Pin Assignment 14

2.3. Pin Description 16

2.4. Power Supply 22

2.4.1. Power Supply Pins ................................................................................................................................................................... 22

2.4.2. Decrease Voltage Drop ............................................................................................................................................................ 22

2.4.3. Reference Circuit of Power Supply .......................................................................................................................................... 22

2.5. Turn on Scenarios .............................................................................................................................................................................. 23

2.6. Turn off Scenarios .............................................................................................................................................................................. 25

2.7. Reset Scenarios 26

2.8. USIM Card Interface........................................................................................................................................................................... 28

2.8.1. Description of PINs .................................................................................................................................................................. 28

2.8.2. Design Considerations for USIM Card Holder .......................................................................................................................... 29

2.9. USB Interface 31

2.10. UART Interface ................................................................................................................................................................................. 33

2.10.1. UART CONNECTION ............................................................................................................................................................... 34

2.10.2. UART LEVEL MATCH .............................................................................................................................................................. 35

2.10.3. Use ic for level switch ............................................................................................................................................................ 40

2.11. Network Status Indication ............................................................................................................................................................... 41

2.12. POWER_ON/OFF Status Indicator ON_STATE .................................................................................................................................. 42

2.13. ADC Interface 43

2.14. WAKEUP_IN Signal ........................................................................................................................................................................... 43

2.15. WAKEUP_OUT Signal ....................................................................................................................................................................... 44

2.16. GPIO Interface 46

3. Antenna Interface ....................................................................................................................................................................... 47

3.1. Pin Definition 47

3.2. Reference Design ............................................................................................................................................................................... 47

3.3. Reference PCB Layout of Antenna ..................................................................................................................................................... 49

3.4. Suggestions for EMC & ESD Design .................................................................................................................................................... 49

3.4.1. EMC Design Requirements ...................................................................................................................................................... 49

3.4.2. ESD Design Requirements ....................................................................................................................................................... 49

3.5. Test Methods for Whole-Set Antenna OTA ....................................................................................................................................... 50

GM500_U1A

Hardware Development Guide

4. Electrical, Reliability and Radio Characteristics ............................................................................................................................ 51

4.1. Absolute Maximum Ratings ............................................................................................................................................................... 51

4.2. Operating Temperature ..................................................................................................................................................................... 51

4.3. Electrostatic Discharge ...................................................................................................................................................................... 51

4.4. GM500_U1A Test ............................................................................................................................................................................... 51

4.4.1. Current Consumption .............................................................................................................................................................. 51

4.4.2. RF Output Power ..................................................................................................................................................................... 52

4.4.3. RF Receiving Sensitivity ........................................................................................................................................................... 52

4.5. GNSS Technical Parameters ............................................................................................................................................................... 52

5. Mechanical Dimensions .............................................................................................................................................................. 53

5.1. Mechanical Dimensions of the Module ............................................................................................................................................. 53

5.2. Footprint of Recommendation .......................................................................................................................................................... 55

6. Related Test & Test Standard ...................................................................................................................................................... 56

6.1. Testing Reference .............................................................................................................................................................................. 56

6.2. Description of Testing Environment .................................................................................................................................................. 56

6.3. Reliability Testing Environment ......................................................................................................................................................... 57

7. SMT Process and Baking Guide .................................................................................................................................................... 58

7.1. Storage Requirements ....................................................................................................................................................................... 58

7.2. Module Plainness Standard ............................................................................................................................................................... 58

7.3. Process Routing Selection .................................................................................................................................................................. 58

7.3.1. Solder Paste Selection ............................................................................................................................................................. 58

7.3.2. Design of module PAD’s steel mesh opening on main board .................................................................................................. 58

7.3.3. Module Board’s SMT process .................................................................................................................................................. 59

7.3.4. Module Soldering Reflow Curve .............................................................................................................................................. 60

7.3.5. Reflow method ........................................................................................................................................................................ 61

7.3.6. Maintenance of defects .......................................................................................................................................................... 61

7.4. Module’s Baking Requirements ......................................................................................................................................................... 61

7.4.1. Module’s Baking Environment ................................................................................................................................................ 61

7.4.2. Baking device and operation procedure ................................................................................................................................. 62

7.4.3. Module Baking Conditions ...................................................................................................................................................... 62

8. Federal Communication Commission Interference Statement ..................................................................................................... 62

GM500_U1A

Hardware Development Guide

TABLES

Table 1-1 GM500_U1A Supported Band ...................................................................................... 11

Table 1-2 GM500_U1A Key Features .......................................................................................... 11

Table 2-1 IO Parameters Definition .............................................................................................. 16

Table 2-2 Logic levels Description ................................................................................................ 16

Table 2-3 Pin Description ............................................................................................................. 16

Table 2-4 Power Supply ................................ ................................................................ ............... 22

Table 2-5 Definition of POWER_ON ............................................................................................. 24

Table 2-6 Power-on Time ............................................................................................................. 25

Table 2-7 Power-off Time ............................................................................................................. 25

Table 2-8 Pin Definition of the USIM Interface .............................................................................. 28

Table 2-9 Pin Description of Molex USIM Card Holder ................................................................. 30

Table 2-10 Pin Description of Amphenol USIM Card Holder ......................................................... 31

Table 2-11 USB Pin Description ................................................................................................... 32

Table 2-12 Pin Definition of the Main UART Interface .................................................................. 33

Table 2-13 Pin Definition of the Debug UART Interface ................................................................ 34

Table 2-14 Pin Definition of Network Indicator .............................................................................. 42

Table 2-15 Working State of the Network Indicator ...................................................................... 42

Table 2-16 Pin Definition of ON_STATE ....................................................................................... 42

Table 2-17 Pin Definition of the ADC ............................................................................................ 43

Table 2-18 Characteristic of the ADC ........................................................................................... 43

Table 2-19 Pin Definition of WAKEUP_IN .................................................................................... 43

Table 2-20 Pin Definition of WAKEUP_OUT ................................................................................ 45

Table 2-21 Pin Definition of GPIO ................................................................................................ 46

Table 3-1 Pin Definition of Antenna .............................................................................................. 47

Table 4-1 Absolute Maximum Ratings .......................................................................................... 51

Table 4-2 Operating Temperature ................................................................................................ 51

Table 4-3 ESD characteristic ........................................................................................................ 51

Table 4-4 Averaged standby DC power consumption [1] .............................................................. 51

Table 4-5 Averaged working current [1] ........................................................................................ 51

GM500_U1A

Hardware Development Guide

Table 4-6 Averaged working current [2] ........................................................................................ 52

Table 4-7 Conducted RF Output Power........................................................................................ 52

Table 4-8 Conducted RF Receiving Sensitivity Typical Value [1] .................................................. 52

Table 4-9 Conducted RF Receiving Sensitivity Typical Value [2] .................................................. 52

Table 4-10 GNSS Technical Parameters ...................................................................................... 52

Table 6-1 Testing Standard .......................................................................................................... 56

Table 6-2 Testing Environment .................................................................................................... 56

Table 6-3 Testing Instrument & Device......................................................................................... 57

Table 6-4 Reliability Features ....................................................................................................... 57

Table 7-1 Baking parameters ....................................................................................................... 58

Table 7-2 LCC module PAD’s steel mesh opening ................................................................................ 58

GM500_U1A

Hardware Development Guide

FIGURES

Figure 1–1 System Connection Structure ....................................................................................................... 13

Figure 2–1 Pin Assignment ............................................................................................................................. 16

Figure 2–2 The input reference circuit of VBAT ............................................................................................. 22

Figure 2–3 Reference circuit of DC-DC ........................................................................................................... 23

Figure 2–4 Reference circuit of LDO ............................................................................................................... 23

Figure 2–5 Reference circuit of POWER_ON .................................................................................................. 24

Figure 2–6 Timing of Turning on Mode .......................................................................................................... 25

Figure 2–7 Timing of Turning off Mode .......................................................................................................... 26

Figure 2–8 reference circuit to reset module ................................................................................................. 27

Figure 2–9 Timing of Reset Mode .................................................................................................................. 27

Figure 2–10 Reference Circuit of the 8 Pin USIM Card ................................................................................... 29

Figure 2–11 Reference Circuit of the 6 Pin USIM Card ................................................................................... 29

Figure 2–12 Molex 91228 USIM Card Holder ................................................................................................. 30

Figure 2–13 Amphenol C707 10M006 512 2 USIM Card Holder .................................................................... 31

Figure 2–14 Reference Circuit of USB Application ......................................................................................... 32

Figure 2–15 Reference Circuit of USB Communication between module and AP ......................................... 32

Figure 2–16 Reference circuit of USB when USB is not the desired function ................................................ 33

Figure 2–17 Schematic of 8-wire UART Connection....................................................................................... 34

Figure 2–18 Schematic of 3-wire UART Connection....................................................................................... 34

Figure 2–19 Schematic of 4-wire UART Connection....................................................................................... 35

Figure 2–20 Recommended TXD circuit ......................................................................................................... 36

Figure 2–21 Recommended RXD circuit ......................................................................................................... 37

Figure 2–22 Recommended RTS circuit .......................................................................................................... 38

Figure 2–23 Recommended CTS circuit .......................................................................................................... 39

Figure 2–24 Recommended 8-wires UART level switch circuit ...................................................................... 40

Figure 2–25 Recommended 4-wires UART level switch circuit ...................................................................... 41

Figure 2–26 Recommended 2-wires UART level switch circuit ...................................................................... 41

Figure 2–27 The test point of debug UART .................................................................................................... 41

Figure 2–28 Reference Circuit of the Network Indicator ............................................................................... 42

Figure 2–29 WAKEUP_IN input sequence ...................................................................................................... 44

GM500_U1A

Hardware Development Guide

Figure 2–30 Connections of the WAKEUP_IN pin .......................................................................................... 44

Figure 2–31 The output signal of WAKEUP_OUT ........................................................................................... 45

Figure 2–32 Connections of the WAKEUP_OUT pin ....................................................................................... 45

Figure 3–1 Reference Circuit of Antenna Interface ........................................................................................ 48

Figure 3–2 Reference Circuit of GNSS Antenna .............................................................................................. 48

Figure 3–3 The OTA test system of CTIA ........................................................................................................ 50

Figure 5–1 GM500_U1A Top and Side Dimensions ........................................................................................ 53

Figure 5–2 GM500_U1A Bottom Dimensions .............................................................................................. 54

Figure 5–3 Recommended Footprint ............................................................................................................. 55

Figure 7–1 Module Board’s Steel Mesh Diagram ........................................................................................... 59

Figure 7–2 Material Module Pallet ................................................................................................................. 59

Figure 7–3 Tape Reel Dimension .................................................................................................................... 60

Figure 7–4 Module Furnace Temperature Curve Reference Diagram ........................................................... 61

Hardware Development Guide

PID

RF support

RF Band

Transmit Frequency (TX)

Receive Frequency (RX)

GM500_U1A(CAT4)

LTE FDD

B2

1850 to 1910 MHz

1930 to 1990 MHz

B4

1710 to 1755 MHz

2110 to 2155 MHz

B5

824 to 849 MHz

869 to 894 MHz

B12

698 to 716 MHz

728 to 746 MHz

WCDMA

B2

1850 to 1910 MHz

1930 to 1990 MHz

B5

824 to 849 MHz

869 to 894 MHz

GSM

850

824.2 to 848.8MHz

869.2 to 893.8 MHz

1900

1850.2 to 1909.8 MHz

1930.2 to 1989.8MHz

Feature

Description

Physical

Small form factor-30 mm × 30 mm × 2.3mm

LCC with 80 pins

Power Supply

The range of voltage supply is 3.4V-4.2V, typical value is 3.8V

Frequency Bands

U1A

(for America)

LTE FDD: B2,B4 ,B5,B12

WCDMA: B2,B5

Rx Diversity

U1A LTE FDD:B2,B4,B5,B12

WCDMA:B2,B5

Transmission Rate

LTE FDD (CAT4): Max 150Mbps(DL)/Max 50Mbps(UL)

Network Protocols

Support TCP/PPP/UDP/FTP protocols

Support PAP, CHAP protocols used for PPP connection.

USIM Interface

1.8V/3V support

SIM extraction/hot plug detection

Support SIM and USIM

UART Interface

Support two UART interface: main UART interface and debug UART interface

1. PRODUCT OVERVIEW

1.1. GEN ERAL DESCRIPTION

GM500_U1A is a LTE/WCDMA/GSM wireless communication module with LCC interface. It is widely applied to but not limited to the various products and equipment such as laptops, vehicle-mounted terminals, and electric devices, by providing data services.

Customer can choose the dedicated type based on the wireless network configuration and using area. The following table shows the entire radio band configuration of GM500_U1A.

Table 1-1 GM500_U1A Supported Band

1.2. KEY FEATURE S

The table below describes the detailed features of the GM500_U1A module.

Table 1-2 GM500_U1A Key Features

Hardware Development Guide

Main UART interface:

Eight lines on main UART interface

Support RTS and CTS hardware flow control

Baud rate can reach up to 921600 bps,115200 bps by default

Used for AT command, data transmission or firmware upgrade

Debug UART interface:

Two lines on debug UART interface, can be used for software debug, firmware upgrade

USB Interface

Compliant with USB 2.0 specification (slave only)

Used for AT command communication, data transmission, software debug and firmware upgrade.

USB Driver

Support Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10,

Windows CE5.0/6.0 and later,

Linux 2.6.20 and later,

Android 2.3 / 4.X/ 5.X

SDIO interface

1.8V support (full speed) 4bits,SDIO compatible to WLAN (802.11)

Antenna Interface

Include main antenna ,diversity antenna and GNSS antenna

Rx-diversity

Support WCDMA/LTE Rx-diversity

AT commands

Compliant with 3GPP TS 27.007,27.005 and GOSUNCN enhanced AT commands

Network Indication

Use LED_MODE to indicate network connectivity status

SMS

Text and PDU mode

Point to point MO and MT

SMS saving/reading to SIM card or module storage

SMS cell broadcast

Temperature Range

Normal operation: -30°C to +75°C

Restricted operation: -40°C~ -30°C and +75°C~ +85°C1)

Storage temperature: -40°C to +85°C

Firmware Upgrade

USB interface or UART interface or OTA(WEFOTA)

1.3. FUN CTION DIAGRAM

The figure below shows a block diagram of the GM500_U1A and illustrates the major functional parts.

 Power management

 Baseband

 Memory

 RF send-receive

 Peripheral interface

--UART interface

--USIM card interface

--USB interface

--SDIO interface

--SPI interface

Hardware Development Guide

Baseband

USB

USIM

UART

I2C

SDIO

SPI

LED

ADC

GPIO

FLASH

&

LPDDR2

Data

Control

Rx&Tx

RF

Transceiver

RF PA

Duplexer

Tx

Rx

MAIN_ANT

80PIN LCC Connector Interface

Rx

GNSS

Rx

DIV_ANT

--I2C interface

--ADC interface

--Status interface (LED)

Figure 1–1 System Connection Structure

1.4. EVA LUATI ON BOA RD

In order to help you to develop applications with GM500_U1A, GOSUNCN supplies an evaluation board (G2000/GE2015), RS-232 to USB cable, USB data cable, power adapter, antenna and other peripherals to control or test the module. For details, please refer to the related document [GE2015 Dev Board User Guide].

Hardware Development Guide

2. APPLICATION INTERFACE

2.1. GEN ERAL DESCRIPTION

GM500_U1A is equipped with an 80-pin 0.72mm pitch SMT pads plus 16-pin ground pads and reserved pads that connect to customer’s cellular application platform. Sub-interface included in these pads is described in detail in the following chapters:

 Pin assignment

 Pin description

 Power supply

 Turn on/off scenarios

 USIM interface

 USB interface

 UART interface

 Network status indication

 ADC interface

 WAKEUP_IN signal

 WAKEUP_OUT signal

 GPIO interface

2.2. PIN AS SIGNMENT

The following figure shows the pin assignment of the GM500_U1A module.

Hardware Development Guide

Type

Description

IO

Bidirectional input/output

DI

Digital input

DO

Digital output

PI

Power input

PO

Power output

AI

Analog input

AO

Analog output

OD

Open drain

Parameter

Min

Max

Unit

VIH

0.65*VDD_IO

VDD_IO+0.3

V

VIL

-0.3

0.35* VDD_IO

V

VOH

VDD_IO-0.45

VDD_IO

V

VOL 0 0.45

V

Power Supply Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

V_BAT

50.51

PI

Power supply for

module

Vmax = 4.2V

Vmin = 3.4V

Vnorm = 3.8V

It must be able to provide sufficient

current in a transmitting burst which

typically rises to 2.0A

VREF_1V8

5

PO

Provide 1.8V for

external circuit

Vnorm = 1.8V

Imax = 300mA

Power supply for external GPIO’S pull

up circuits

PLL_1V8

4

PO

Provide 1.8V for

external circuit

Vnorm = 1.8V

Imax = 20mA

This pin can only be used for WiFi

interface, and can left

unconnected when not used.

GND

3,9,11,20,21,31,36,

46,49,52, 61,63,78,

Ground

NOTE:

Keep all NC pins unconnected.

2.3. PIN DE SCR IPTION

The following table shows the IO Parameters Definition.

Figure 2–1 Pin Assignment

Table 2-1 IO Parameters Definition

The logic levels are described in the following table.

Table 2-2 Logic levels Description

NOTE:

VDD_IO is the voltage level of pins.

The following tables show the GM500_U1A’s pin definition.

Table 2-3 Pin Description

Hardware Development Guide

80,

Turn On/Off Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

POWER_ON

1

DI

Turn on/off module

VIH max = 2.1V

VIH min = 1.17V

VIL max = 0.63V

Pull-up to 0.8V internally, active low

RESET_N

2

DI

Reset module

VIH max = 2.1V

VIH min = 1.17V

VIL max = 0.63V

Active low

Status Indication

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

ON_STATE

69

DO

Module power

on/off status

indicator

VOH min = 1.35V

VOL max = 0.45V

1.8V power domain

LED_MODE

70

DO

Indicate the module

network registration

mode

VOH min = 1.35V

VOL max = 0.45V

1.8V power domain

USB Interface

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

USB_DP

24

IO

USB differential data

bus

Compliant with USB 2.0 standard

specification Require differential

impedance of 90Ω

USB_DM

23

IO USB_VBUS

22

PI

USB power

HSIC Interface

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

USB_STROBE

25

IO

HSIC strobe

InterChip USB(HSIC)

line impedance 50 ohm, isometric

constraint is less than 2 mm, line

length is less than 10 cm

USB_DATA

26

IO

HSIC data

USIM Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

USIM_VCC

40

PO

Power supply for

USIM card

For 1.8V USIM:

Vmax = 1.9V

Vmin = 1.7V

For 3.0V USIM:

Vmax = 3.05V

Vmin = 2.7V

IO max = 50mA

Either 1.8V or 3V is supported by the

module automatically

USIM_DATA

38

IO

Data signal of USIM

card

For 1.8V USIM:

VIL max = 0.63V

VIH min = 1.17V

Pull-up to USIM_VCC with 10k resistor

internally

Hardware Development Guide

VOL max = 0.45V

VOH min = 1.35V

For 3V USIM:

VIL max = 1.05V

VIH min = 1.95V

VOL max = 0.45V

VOH min = 2.6V

USIM_CLK

37

DO

Clock signal of USIM

card

For 1.8V USIM:

VOL max = 0.45V

VOH min = 1.35V

For 3V USIM:

VOL max = 0.45V

VOH min = 2.6V

USIM_RST

39

DO

Reset signal of USIM

card

For 1.8V USIM:

VOL max = 0.45V

VOH min = 1.35V

For 3V USIM:

VOL max = 0.45V

VOH min = 2.6V

USIM_DETECT

41

DI

USIM card input

detection

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain. Active low

If no need of USIM detect, leave this

pin not connected.

ADC Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

ADC1

48

AI

Analog to digital

0.05V to 4.15V

External sensor signal detection

ADC2

47

AI

Analog to digital

0.05V to 4.15V

External sensor signal detection

Main UART Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

UART_TXD

53

DO

Transmit data

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

UART_RXD

54

DI

Receive data

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

UART_RTS

55

DO

Request to send

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

UART_CTS

56

DI

Clear to send

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

Hardware Development Guide

UART_DSR

57

DO

Data set ready

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain.

UART_DTR

58

DI

Data terminal ready

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain.

UART_DCD

59

DO

Data carrier

detection

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

UART_RI

60

DO

Ring indicator

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain, DO not pull-up

external

Debug UART Interface

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

UART_DEBUG_TXD

68

DO

Transmit data

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

UART_DEBUG_RXD

67

DI

Receive data

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

RF Interface

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

MAIN_ANT

62

IO

Main antenna

50Ω impedance

DIV_ANT

79

AI

Diversity antenna

50Ω impedance

GNSS_ANT

10

IO

GNSS antenna

50Ω impedance

I2C Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

I2C_SCL

73

DO

I2C serial clock

VOL max = 0.45V

VOH min = 1.35V

Pull-up to 1.8V through external 2.2K

resistance, active low

I2C_SDA

74

IO

I2C serial data

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

Pull-up to 1.8V through external 2.2K

resistance, active low

SDIO Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

SDIO_CMD

14

IO

Secure digital CMD

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

Pull-up to 1.8V through external 10K

resistance, active low

Hardware Development Guide

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

SDIO_D0

15

IO

Secure digital IO data

bit 0

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

SDIO_D1

16

IO

Secure digital IO data

bit 1

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

SDIO_D2

17

IO

Secure digital IO data

bit 2

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

SDIO_D3

18

IO

Secure digital IO data

bit 3

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

SDIO_CLK

19

DO

Secure digital CLK

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

SDIO Interface Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

SPI_MISO

32

IO

SPI main input slave

output

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

1.8V power domain

SPI_MOSI

33

IO

SPI main output slave

input

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

1.8V power domain

Hardware Development Guide

VIH min = 1.17V

VIH max = 2.1V

SPI_CLK

34

DO

SPI clock

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain

SPI_CS_N

35

DO

SPI segment

VOL max = 0.45V

VOH min = 1.35V

1.8V power domain WiF PINs

WLAN_SLEEP_CLK

6

DO

WLAN sleep clock

VOL max = 0.45V

VOH min = 1.35V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

COEX_UART_TX

7

DO

LTE transmitter sync

for coexistence with

UART

VOL max = 0.45V

VOH min = 1.35V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

COEX_UART_RX

8

DI

LTE receiver sync for

coexistence with

UART

VIL max = 0.63V

VIH min = 1.17V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

When pull-up this pin to 1.8V, the

module will enter emergency

download mode.

WLAN_EN

12

DO

WLAN enable

VOL max = 0.45V

VOH min = 1.35V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

WLAN_3V3_EN

13

DO

WLAN power enable

VOL max = 0.45V

VOH min = 1.35V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

WLAN_SLEEP_CLK

6

DO

WLAN sleep clock

VOL max = 0.45V

VOH min = 1.35V

Only supported by firmware with WiFi.

Other firmware, this pin is NC

Other Pins

Pin Name

Pin NO.

I/O

Description

DC Characteristics

Comment

WAKEUP_IN

72

DI

Sleep mode control,

External device

wakeup module

VIL min = -0.3V

VIL max = 0.45V

VIH min = 1.53V

VIH max = 2.1V

1.8V power domain. Pull-down

internally. Edge-triggered, Rising edge

wake up module; Falling edge modules

can enter sleep

WAKEUP_OUT

71

DO

Output wakeup

signal, wake up the

external devices

VOL max = 0.8V

VOH min = 1.35V

Wakeup external circuits

GPIO

27, 28, 29, 30, 65

IO

General input/output

VOL max = 0.45V

VOH min = 1.35V

VIL min = -0.3V

VIL max = 0.63V

VIH min = 1.17V

VIH max = 2.1V

If unused, keep them floating.

DO not pull-up PIN77 external

NC

66,64,75,76,77,4

5,44,43,42

No connection

NC, there is no connection internal,

please keep them floating .

Hardware Development Guide

Pin Name

Pin NO.

Description

Minimum

Typical

Maximum

Unit

V_BAT

50,51

Power supply for module

3.4

3.8

4.2

V

GND

3, 9, 11, 20, 21, 31, 36, 46,

49, 52, 61, 63, 78, 80,

Ground

- -

2.4. POWER SUPPLY

2.4.1. POWER SUPPLY PINS

The GM500_U1A is supplied through the V_BAT signal with the following characteristics.

Table 2-4 Power Supply

GND signal (Pin No: 3/9/11/20/21/31/36/46/49/52/61/63/78/80) is the power and signal ground of the module, which needs to be connected to the ground on the system board. If the GND signal is not connected completely, the performance of module will be affected.

2.4.2. DECREASE VOLTAGE DROP

The power supply range of the module is 3.4V~ 4.2V. In poor situation of the network is, the antenna will transmit at the maximum power, and the transient maximum peak current can reach as high as 2A. So we recommended to add Energy storage capacitor ( C6: 470μF). Filter capacitor(10µF, 0.1µF, 33pF) need to be added to reduce interference. The capacitors should be placed close to the GM500_U1A’s V_BAT pins. The following figure shows structure of the power supply.

Figure 2–2 The input reference circuit of VBAT

The PCB traces from the V_BAT pins to the power source must be wide enough to ensure that there isn’t too

much voltage drop occurs in the transmitting procedure. The width of V_BAT trace should be no less than 2mm, and the principle of the V_BAT trace is the longer, the wider.

In addition, make the ground plane as complete as possible, and play more holes.

2.4.3. REFERENCE CIRCUIT OF POWER SUPPLY

 Option 1:DC-DC switching

The over-current capability requirement of DC/DC switching power supply needs to be above 2.5A. When the input and output voltage difference is large, you need to select Buck circuit to improve translate efficiency.

Two reference power supply circuit design with DC-DC is shown as figure below:

Hardware Development Guide

Figure 2–3 Reference circuit of DC-DC

 Option 2:LDO

The over-current capability of LDO is above 2.5A. This LDO is apply to this situation: input and output voltage difference is small.

The reference power supply circuit design with LDO is shown as figure below:

Figure 2–4 Reference circuit of LDO

2.5. TURN ON SCE NAR IOS

When MCU can provide high/low level pulse with adjustable length, the reference circuit to turn-on/off module is as shown in the following figure below.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

POWER_ON

1

DI

Turn on/off the module

low active. Pull-up to 0.8V internally

The resistors in Figures below are only the recommended value and they need to adjust according to the actual situation.

Power-on by dynatron, the circuit ① connect ON/OFF to high level to power-on the module, the circuit ② can connect ON/OFF to low level to power-on the module

The table below is the information of power-on/off pin

The power on scenarios is illustrated as the following figure, the module will power on and working when the POWER_ON pin keep in low level for T1, in this process , please ensure VBAT steady.

Figure 2–5 Reference circuit of POWER_ON

Table 2-5 Definition of POWER_ON

Hardware Development Guide

Parameter

Description

Min

Typical

Max

Unit

T1

The period that the Power-on signal for power on operation is kept on the low PWL

0.1

0.2

--

Second

T2

The minimum interval between the POWER_ON and RESET signals if you want to

reset the module after power-on.

10

15

--

Second

Parameter

Description

Min

Typical

Max

Unit

T2

The period that the POWER_ON signal for power off operation is

kept on the low PWL

2.5 3 --

second

T3

The period that the VBAT signal should be kept after power off

operation is down

22

--

second

VBAT

POWER_ON

T1

Ensure VBAT steady

T2

RESET_N

Figure 2–6 Timing of Turning on Mode

Table 2-6 Power-on Time

2.6. TURN OFF SCENARI OS

The module supports two modes to turn off:

Mode 1:

Pull down pin1 (POWER_ON) for 2.5-3s will turn off the module. The power off process will take 22s at least. The reference circuit can refer to the figure 2-5.

Table 2-7 Power-off Time

Hardware Development Guide

VBAT

high level

POWER_ON

Module

Status

Turning offRunning

T2

T3

Power off

Figure 2–7 Timing of Turning off Mode

Mode 2:

Send command of AT+ZTURNOFF, and the power off process will take 15s at least.

Note:when using modules, you need to avoid power off abnormally and frequently, as it will cause several risks

shwon as below:

1. it will damage the flash permanently.

2. it can’t send deregiter message to e-NodeB, and the MMS takes for the module is still registering to network, and it

won’t remind "the user can’t reach" or "the user has turn down" when it’s called(MT).

2.7. RESET SCENA RIOS

When the software stops response, you can pulled down RESET_N pin(pin2) for 1 second to reset the module's system.

When MCU can provide high/low level pulse with 1 second, the reference circuit to reset module is as shown in the following figure below. The resistors in Figures below are only the recommended value and they need to adjust according to the actual situation.

Hardware Development Guide

VBAT

high level

RESET_N

Module

Status

ResettingRunning Running

1s

COM can

send/receive AT

27s

Figure 2–8 reference circuit to reset module

The reset scenario is illustrated as the following figure,

Figure 2–9 Timing of Reset Mode

Mode 2:

Send command of AT+ZRST, and the RESET process until the AT port can communicate will take 27s at least.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

USIM_VCC

40

PO

Power supply for USIM card

Either 1.8V or 3V is supported by the module automatically

USIM_DATA

38

IO

Data signal of USIM card

Pull-up to USIM_VDD with 10k resistor internally

USIM_CLK

37

DO

Clock signal of USIM card

USIM_RST

39

DO

Reset signal of USIM card

USIM_DETECT

41

DI

USIM card hot swap detection pin.

1.8V power domain. The signal is internally pulled up.

Keep USIM_DETECT not connected, if it is not used. When USIM

detect function is enable (send AT command AT+ZSDT=1), and if

it is Low, USIM is present; if it is High, USIM is absent.

GND

36 Ground

2.8. USIM CARD INTE RFACE

2.8.1. DESCRIPTION OF PINS

The USIM card interface circuitry meets ETSI and IMT-2000 SIM interface requirements. Both 1.8V and 3.0V USIM cards are supported.

Table 2-8 Pin Definition of the USIM Interface

The following figure shows the reference design of the 8-pin USIM card.

Hardware Development Guide

Figure 2–10 Reference Circuit of the 8 Pin USIM Card

GM500_U1A supports USIM card hot-plugging via the USIM_ DETECT pin. For details, refer to document [AT Command Reference Guide of Module Product GM500_U1A]. If you do not need the USIM card detect function, keep USIM_ DETECT unconnected.

The reference circuit for using a 6-pin USIM card socket is illustrated as the following figure.

Figure 2–11 Reference Circuit of the 6 Pin USIM Card

NOTE:

 R14~R16 and D6 are applied to suppress the EMI spurious transmission and enhance the ESD

protection.D6 should be closed to J4

 The value of C33 should be less than 1uF.

In order to enhance the reliability and availability of the USIM card in customer’s application, please follow the following criterion in the USIM circuit design:

 Keep layout of USIM card as close as possible to the module. Assure the possibility of the length of the trace is less than

50mm.

 Keep USIM card signal away from RF and V_BAT alignment.

 Assure the ground between module and USIM cassette short and wide. Keep the width of ground and USIM_VCC no less

than 0.5mm to maintain the same electric potential. The decouple capacitor of USIM_VCC should be less than 1uF and must be near to USIM cassette.

 To avoid cross-talk between USIM_DATA and USIM_CLK, keep them away with each other and shield them with

surrounded ground.

 In order to offer good ESD protection, it is recommended to add TVS such as WILL (http://www.willsemi.com)

ESDA6V8AV6. The 33Ω resistors should be added in series between the module and the USIM card so as to suppress the

EMI spurious transmission and enhance the ESD protection. Please note that the USIM peripheral circuit should be close to the USIM card socket.

 The pull-up resistor on USIM_DATA line can improve anti-jamming capability when long layout trace and sensitive

occasion is applied.

2.8.2. DESIGN CONSIDERATIONS FOR USIM CARD HOLDER

For 8-pin USIM card holder, it is recommended to use Molex 91228.

Please visit http://www.molex.com for more information.

Hardware Development Guide

Pin Name

Pin NO.

Function

GND 1 Ground

VPP 2 Not connected

DATA I/O

3

USIM card data

CLK 4 USIM card clock

RST 5 USIM card reset

VDD 6 USIM card power supply

DETECT

7

USIM card Detection

NC 8 Not defined, Connect to Ground

Figure 2–12 Molex 91228 USIM Card Holder

Table 2-9 Pin Description of Molex USIM Card Holder

For 6-pin USIM card holder, it is recommended to use Amphenol C707 10M006 512 2.

Please visit http://www.amphenol.com for more information.

Hardware Development Guide

Pin Name

Pin NO.

Function

GND 1 Ground

VPP 2 Not connected

DATA I/O

3

USIM card data

CLK 4 USIM card clock

RST 5 USIM card reset

VDD 6 USIM card power supply

Figure 2–13 Amphenol C707 10M006 512 2 USIM Card Holder

Table 2-10 Pin Description of Amphenol USIM Card Holder

2.9. USB IN TER FACE

GM500_U1A contains one integrated USB transceiver which complies with the USB 2.0 specification and supports high speed (480 Mbps), full speed (12 Mbps) and low speed (1.5 Mbps) mode. The USB interface is primarily used for AT command, data transmission, software debug and firmware upgrade. The following table shows the pin definition of USB interface.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

USB_DP

24

IO

USB differential data bus (positive)

Require differential impedance of 90Ω

USB_DM

23

IO

USB differential data bus (negative)

Require differential impedance of 90Ω

USB_VBUS

22

PI

USB power

USB plug detect

GND

21 Ground

Table 2-11 USB Pin Description

More details about the USB 2.0 specifications, please visit http://www.usb.org/home.

For different use purposes, different designs can be referred to:

 Connect USB interface to USB connector directly. The following figure shows the reference circuit of USB interface

Figure 2–14 Reference Circuit of USB Application

 Reference Circuit of USB Communication between module and AP is the one below. The 0Ω in the figure should be placed

near pin.

Figure 2–15 Reference Circuit of USB Communication between module and AP

 When USB is not the desired function, connect differential signal, power and GND via test points. We recommend to

connect these pins to the standard pin header in order to convenient for debugging and upgrading.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

UART_RI

60

DO

Ring indicator

1.8V power domain

UART_DCD

59

DO

Data carrier detection

1.8V power domain

UART_CTS

56

DI

Clear to send

1.8V power domain

UART_RTS

55

DO

Request to send

1.8V power domain

UART_DTR

58

DI

Data terminal ready

1.8V power domain.

UART_DSR

57

DO

Data set ready

1.8V power domain.

Figure 2–16 Reference circuit of USB when USB is not the desired function

Note: we recommend connecting the USB interface for update and debugging the module.

In order to ensure the USB interface design corresponding with the USB 2.0 specification, please comply with the following principles.

It is important to route the USB signal traces as differential pairs with total grounding. The impedance of USB differential trace is 90ohm.

Pay attention to the influence of junction capacitance of ESD component on USB data lines. Typically, the capacitance value should be less than 3pF.

Do not route signal traces under crystals, oscillators, magnetic devices and RF signal traces. It is important to route the USB differential traces in inner-layer with ground shielding not only upper and lower layer but also right and left side.

Keep the ESD components as closer to the USB connector as possible.

2.10. UART INTERFACE

The module provides two UART interfaces: Main UART Port and Debug UART Port. The Main UART Port can work in full function mode while the Debug UART Port is used for software debugging . The following show the different features.

Main UART interface support 1200 2400 4800 9600 19200 38400 57600 115200 230400 460800 921600 1000000 1500000 2000000 2500000 3000000 3500000bps baud rate, the default is 115200bps, This interface can be used for data transmission; AT communication or firmware upgrade (upgrade is not supported currently).

Debug UART interface supports 115200bps baud rate. It can be used for software debug and firmware upgrade. The module is designed as the DCE (Data Communication Equipment), following the traditional DCE-DTE (Data Terminal Equipment) connection.

The following tables show the pin definition of these two UART interfaces.

Table 2-12 Pin Definition of the Main UART Interface

Hardware Development Guide

UART_TXD

53

DO

Transmit data

1.8V power domain

UART_RXD

54

DI

Receive data

1.8V power domain

Pin Name

Pin NO.

I/O

Description

Comment

UART_DEBUG_TXD

68

DO

Transmit data

1.8V power domain

UART_DEBUG_RXD

67

DI

Receive data

1.8V power domain

TXD1

RXD1

RTS1

CTS1

DTR1

DCD1

RING1

TXD

RXD

RTS

CTS

DTR

DCD

RING

Serial Port

(DCE)

(DTE)

GND GND

TXD

RXD

RTS

CTS

DTR

DCD

RING

Serial Port

(DCE)

(DTE)

GND GND

UART_TXD

UART_RXD

UART_RTS

UART_CTS

UART_DTR

UART_DCD

UART_RI

Table 2-13 Pin Definition of the Debug UART Interface

2.10.1. UART CONNECTION

Three normal connections for UART are shown in the figures below:

1. 8-wires UART connection mode, mainly used for MODEM mode(PPP dialing for example)

2. 3-wire UART connection:

3. 4-wire UART connection, with hardware flow control:

Figure 2–17 Schematic of 8-wire UART Connection

Figure 2–18 Schematic of 3-wire UART Connection

Hardware Development Guide

TXD

RXD

RTS

CTS

DTR

DCD

RING

Serial Port

(DCE)

(DTE)

GND GND

UART_TXD

UART_RXD

UART_RTS

UART_CTS

UART_DTR

UART_DCD

UART_RI

2.10.2. UART LEVEL MATCH

Figure 2–19 Schematic of 4-wire UART Connection

Notice the level match when connect module to external MCU. Level must be less than 3.0V under normal operation, and its default speed rate is 115200 bps.

We recommend to use audion or IC for UART level match circuit. The pictures below are the recommended level switch circuit for TXD, RXD, CTS, RTS. Each pin recommend two kinds of circuit, and you can select any one if necessarily.

Hardware Development Guide

Figure 2–20 Recommended TXD circuit

Hardware Development Guide

Figure 2–21 Recommended RXD circuit

Hardware Development Guide

Figure 2–22 Recommended RTS circuit

Hardware Development Guide

Figure 2–23 Recommended CTS circuit

Hardware Development Guide

2.10.3. USE IC FOR LEVEL SWITCH

Figure 2–24 Recommended 8-wires UART level switch circuit

Hardware Development Guide

Figure 2–25 Recommended 4-wires UART level switch circuit

Figure 2–26 Recommended 2-wires UART level switch circuit

 Debug UART Interface

Debug UART Interface is 2-wires interface, we recommend the use to connect this two pins to test points or jumper header.

Figure 2–27 The test point of debug UART

2.11. NET WORK STA TUS INDICATION

The network indication pin LED_MODE can be used to drive a network status indicator LED. The different modes of status indicator flashing indicate different network statuses. The following tables describe pin definition and logic level changes in different network status.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

LED_MODE

70

DO

Indicate the module network registration mode

1.8V power domain

LED Status

Module status

High level, LED on

Module register to network success

Low level, LED off

Module not register to network(module is in flight mode or power off)

Low level 1s(LED off), High level 1s(LED on)

PDP activated, and get the IP address or Socket established

Pin Name

Pin NO.

Description

ON_STATE

69

High level: module power on and ready, it can send/receive AT command.

Low level: module power off/reset state, and can’t send/receive AT command.

Table 2-14 Pin Definition of Network Indicator

Table 2-15 Working State of the Network Indicator

Figure below is the reference circuit design diagram.



NOTE:

The resistors R11, R12 and R7 in Figures below are only the recommended value and they need to adjust according to the actual situation.

Figure 2–28 Reference Circuit of the Network Indicator

2.12. POWER_ON/OFF STA TUS INDICATO R ON_STATE

PIN69（ON_STATE） is used to indicate the status of POWER_ON/OFF

Table 2-16 Pin Definition of ON_STATE

Hardware Development Guide

Pin Name

Pin NO.

Description

ADC1

48

General purpose analog to digital converter.

ADC2

47

General purpose analog to digital converter.

Item

Min

Max

Unit

ADC1 voltage range

0.05

4.15 V ADC2 voltage range

0.05

4.15

V

Pin Name

Pin NO.

I/O

Description

Comment

WAKEUP_IN

72

DI

Input control signal

1.8V power domain. Pull-down internally. Edge-triggered, Rising

edge wake up module; Falling edge modules can enter sleep

The recommend connection mode of this pin are shown as below, you can select one property mode according to you necessary:

Mode 1:this pin is used as GPIO output pin, the MCU can judge the state of module according to the high/low level.

Mode 2:connect this pin to LED to indicate the status of module, the reference circuit you can refer to chapter 2.11.

Mode 3:you can connect this pin to test point when in the development stage.

2.13. ADC INTERFACE

The module provides two ADCs to digitize the analog signal to 10-bit digital data such as battery voltage, temperature and so on. Using AT command "AT+ZADC1?" can read the voltage value on ADC1 pin. Using AT command "AT+ZADC2?" can read the voltage value on ADC2 pin. The read value is expressed in mV. For more details of these AT commands, please refer to document [AT Command Reference Guide of Module Product GM500_U1A].

In order to improve the accuracy of ADC, the trace of ADC should be surrounded by ground.

Table 2-17 Pin Definition of the ADC

The following table describes the characteristic of the ADC function.

Table 2-18 Characteristic of the ADC

2.14. WAKEUP_IN SIGNAL

The module provides an AP control interface for communicating with external Application Processor including WAKEUP_IN. The following table shows the pin definition of AP control interface.

Table 2-19 Pin Definition of WAKEUP_IN

When the module needs to be waken up, input a related signal via WAKEUP-IN. The following figure is the signal waveform:

Hardware Development Guide

WAKEUP_IN：

High

Low

Module state：

Sleep state Operating state

High

Operating state

Figure 2–29 WAKEUP_IN input sequence

2.15. WAKEUP_OUT SIGNAL

Figure 2–30 Connections of the WAKEUP_IN pin

NOTE:

There is Anti-shake design with WAKEUP_IN pin internal, when pull up or down this pin by external

processor, the level must last more than 500ms. WAKEUP_IN Usage scenario you can refer to the

document named GOSUNCN GM500_U1A Module Power Management Design Guide.pdf

The module provides the WAKEUP_OUT pin which is used to wake up the external devices.

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

WAKEUP_OUT

71

DO

Output wakeup signal

1.8V power domain

The pin output a high-level voltage by default. When a

wake-up source (such as new SMS receive, call, network

data ) arrives, the pin output a low-level-voltage pulse

lasting for 1s

Module state：

Operating state

Sleep state

low

High

WAKEUP_OUT：

1s

Table 2-20 Pin Definition of WAKEUP_OUT

For instance, When a wake-up source arrives, the module will output the level shown as the figure below through pin 71.

Figure 2–31 The output signal of WAKEUP_OUT

Figure 2–32 Connections of the WAKEUP_OUT pin

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

GPIO1

27

IO

General input/output

1.8V power domain,

GPIO2

28

IO

General input/output

1.8V power domain

GPIO3

29

IO

General input/output

1.8V power domain

GPIO4

30

IO

General input/output

1.8V power domain

GPIO5

65

IO

General input/output

1.8V power domain

NOTE:

WAKEUP_OUT Usage scenario you can refer to the document named GOSUNCN GM500_U1A Module

Power Management Design Guide.pdf

2.16. GPIO INTERF ACE

Module provides 5 GPIO pins. The direction and output voltage level of the GPIO can be set by AT command "AT+ZGPIO". The input voltage level of the GPIO can also be read by AT command "AT+ZGPIO". For more details of these AT commands, please refer to document [AT Command Reference Guide of Module Product GM500_U1A].

NOTE: All the GPIO pins are pull-down internally and are input pins in default.

Table 2-21 Pin Definition of GPIO

Hardware Development Guide

Pin Name

Pin NO.

I/O

Description

Comment

MAIN_ANT

62

IO

Main antenna

50Ω impedance

DIV_ANT

79

AI

Diversity antenna

50Ω impedance

GNSS_ANT

10

IO

GNSS antenna

50Ω impedance

3. ANTENNA INTERFACE

GM500_U1A antenna interface includes a main antenna, an Rx-diversity antenna and a GNSS antenna to improve receiving performance. The antenna interface has an impedance of 50Ω.

3.1. PIN DE FINITION

The main antenna and Rx-diversity antenna pins definition are shown below.

Table 3-1 Pin Definition of Antenna

3.2. REFERENCE DESI GN

The antenna is a sensitive device and its performance is greatly affected by external environments. The radiation performance of the antenna is affected by the module dimensions, antenna position, occupied space size of the antenna, and the grounding of surrounding components of the antenna. Besides, the fixed assembly of the antenna, the wiring of RF cables on the antenna, and the fixed position of the antenna all affect the radiation performance of the antenna too.

The reference design of main antenna and Rx-diversity antenna is shown as below. It should reserve a double-L-type matching circuit for better RF performance, and place these components as close as possible to the module. The capacitors are not mounted by default.

Hardware Development Guide

C2

L2

L1

C3

VDD

GNSS_ANT

MODULE

R1

L3

C1

Figure 3–1 Reference Circuit of Antenna Interface

The following picture is the reference of GNSS active antenna, VDD is its power, power supply should be designed by actual requirements.

Figure 3–2 Reference Circuit of GNSS Antenna

NOTE:

Hardware Development Guide

Keep a proper distance between main and diversity antenna to improve the receiving sensitivity.

3.3. REFERENCE PCB LAY OUT OF ANTE NNA

Please follow the following criterion in the process of antenna line PCB layout design:

Make sure that the transmission line’s characteristic impedance is 50ohm;

Keep line on the PCB as short as possible, since the antenna line loss shall be less than 0.3 dB;

Line geometry should have uniform characteristics, constant cross section, avoid meanders and abrupt curves;

It is wise to surround the PCB transmission line with ground, avoid having other signal tracks facing directly the antenna line track.

Keep at least one layer of the PCB used only for the ground plane; and use this layer as reference ground plane for the transmission line;

 The ground surrounding the antenna line on PCB has to be strictly connected to the main Ground Plane by means of via

holes (once per 2mm at least), placed close to the ground edges facing line track;

 Place EMI noisy devices as far as possible from modules antenna line;

 Keep the antenna line far away from the module power supply lines;

3.4. SUG GESTIONS FOR EMC & ESD DE SIG N

3.4.1. EMC DESIGN REQUIREMENTS

During the design of the whole device, the user needs to fully consider the EMC problem caused by the signal integrity and power integrity.

During the product design, it is better to separate the module from the mainboard PCB, instead of installing the module on the ground of the mainboard. If they cannot be separated, the module should be far from modules and components that might generate EMI, such as chip and memory, power interface, and data cable interface.

Because the mainboard of PAD, CPE, and Internet laptops does not have a shielding cover, as that of mobile terminals, to shield most circuits to avoid overflow of electromagnetic interference, you can spray conductive paint on the surface on non-antenna areas within the structural components above and below the mainboard, and the conductive paint should be connected to the ground on the mainboard by several points to shield electromagnetic interference.

Besides, data cables of the LCD and the camera might introduce interference signals, which affect the receiving performance of the antenna. Thus, it is necessary to wrap conductive cloth around the two data cables and connected them to the ground.

RF cables of the antenna should be far from modules and components that might generate EMI, such as chip and memory, power interface, and data cable interface. The wiring of RF cables should be close to the ground of the mainboard.

During the layout and wiring of peripheral circuits, for the wiring of power and signal cables, keep a distance of 2 times of the line width, so as to effectively reduce the coupling between signals and keep a clean reflux path for the signal.

During the design of peripheral power circuits, the de-coupled capacitor should be placed closed to the module power PIN, the high-frequency high-speed circuit and the sensitive circuit should be placed far away from the border of PCB. They should better be separated during layout, so as to reduce the interference between them and protect the sensitive signal.

For the circuit or device on the side of system board that might interfere with the module, it should be shielded during design.

3.4.2. ESD DESIGN REQUIREMENTS

Module is embedded on the side of system board, so the user needs to make the ESD protection during design. For the key input/output signal interface, such as the (U)SIM card signal interface, the ESD device should be placed closely for protection. Besides, on the side of main board, the user should reasonably design the structure and PCB layout, guarantee that the metallic shielding shell is fully grounded, so as to leave a smooth discharge channel for ESD.

Hardware Development Guide

3.5. TEST METHOD S F OR WHOLE -SE T ANTENNA OTA

Figure below is the diagram of OTA test system of CTIA. The system is mainly composed of test chamber, high-precision positioning system and its controller, Windows based PC running test software and RF test instruments with automatic test program. The main RF instruments are integrated RF test equipment, Spectrum Analyzer, Network Analyzer.

The radio equipments, Relay Switch Unit and PC with automatic test software are communicated via GPIB interface.

Figure 3–3 The OTA test system of CTIA

Hardware Development Guide

Parameter

Min

Max

Unit

V_BAT

3.4

4.2

V

Peak current of V_BAT

0

2

A

Voltage at digital pin

-0.3

2.1

V

Voltage at ADC1

0.05

4.15

V

Voltage at ADC2

0.05

4.15

V

Parameter

Min

Typ.

Max

Unit

Normal Temperature

-30

25

75 ℃ Storage Temperature

-40 / 85 ℃ Extreme Operating Temperature

-40°C~ -30°C

/

+75°C~ +85°C

℃

Tested Points

Contact discharge

Air Discharge

Unit

V_BAT

± 5

± 10

kV

All antenna interfaces

±4

± 8

kV

Other interfaces

± 0.5

± 1

kV

Parameter

Condition

Typical Value

Unit

OFF state

Power down

45

uA

Base Current

Flight Mode[Sleep]

0.9

mA

Parameter

Condition

Typical Value

Unit

4. ELECTRICAL, RELIABILITY AND RADIO CHARACTERISTICS

4.1. ABS OLUTE MA XIMUM RAT INGS

Absolute maximum ratings for power supply and voltage on digital and analog pins of module are listed in the following table:

Table 4-1 Absolute Maximum Ratings

4.2. OPE RATING TEMP ERA TURE

The operating temperature is listed in the following table.

Table 4-2 Operating Temperature

4.3. ELECTROSTAT IC DISCHARGE

The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and packaging procedures must be applied throughout the processing, handling and operation of any application that incorporates the module.

The following table shows the module electrostatics discharge characteristics.

Table 4-3 ESD characteristic

4.4. GM500_U1A TEST

4.4.1. CURRENT CONSUMPTION

The values of current consumption in different operating mode are shown below.

Table 4-4 Averaged standby DC power consumption [1]

Table 4-5 Averaged working current [1]

Hardware Development Guide

Bandwidth

5MHz

10MHz

15MHz

20MHz

LTE

LTE FDD Band 2, Pout=23dBm

575

620

630

mA

LTE FDD Band 4, Pout=23dBm

515

530

550

600

mA

LTE FDD Band 5 ,Pout=23dBm

610

mA

LTE FDD Band 12,Pout=23dBm

620

630

mA

Parameter

Condition

Typical Value

Unit

WCDMA

Band2, Pout=24dBm

532

mA

Band5, Pout=24dBm

526

mA

Frequency

Max

Min

LTE FDD Band 2

23±2.7dBm

-39dBm

LTE FDD Band 4

23 ±2.7dBm

-39dBm

LTE FDD Band 5

23 ±2.7dBm

-39dBm

LTE FDD Band 12

23 ±2.7dBm

-39dBm

WCDMA Band 2

24+1/-3 dBm

-50dBm

WCDMA Band 5

24+1/-3 dBm

-50dBm

Band

5 MHz(dBm)

10 MHz(dBm)

20 MHz(dBm)

LTE FDD Band 2

-98 dBm

-95 dBm

-92 dBm

LTE FDD Band 4

-100 dBm

-97 dBm

-94 dBm

LTE FDD Band 5

-98 dBm

-95 dBm

/

LTE FDD Band 12

-97 dBm

-94 dBm

/

Band

Sensitivity

WCDMA Band 2

-104.7 dBm

WCDMA Band 5

-104.7 dBm

GNSS (GNSS/GLONASS)

Technical specification

GNSS Frequency

1575.42±1.023 MHz

Tracking sensitivity

-156dbm

Cold-start sensitivity

-144dbm

TTFF (Open Sky)

Hot start: 4s

Table 4-6 Averaged working current [2]

4.4.2. RF OUTPUT POWER

The following table shows the RF output power of GM500_U1A module.

Table 4-7 Conducted RF Output Power

4.4.3. RF RECEIVING SENSITIVITY

The following table shows the conducted RF receiving sensitivity typical value of GM500_U1A module.

Table 4-8 Conducted RF Receiving Sensitivity Typical Value [1]

Table 4-9 Conducted RF Receiving Sensitivity Typical Value [2]

4.5. GNSS TECHNICAL PARA METERS

The following table shows the GNSS techinical parameters of GM500_U1A module.

Table 4-10 GNSS Technical Parameters

Hardware Development Guide

Cold start: 32s

Receiver Type

Qualcomm GNSS Gen8C

GNSS L1 Frequency

1575.42MHz

Update rate

2-4 HZ

GNSS (GNSS/GLONASS) data format

NMEA data protocol/GOSUNCN defined at commands

GNSS (GNSS/GLONASS) Current consumption

65mA

GNSS (GNSS/GLONASS) antenna

Passive/Active antenna

5. MECHANICAL DIMENSIONS

This chapter describes the mechanical dimensions of the module. All dimensions are measured in mm.

5.1. MECHANIC AL DIMENSIONS OF THE MODULE

Figure 5–1 GM500_U1A Top and Side Dimensions

Hardware Development Guide

Figure 5–2 GM500_U1A Bottom Dimensions (perspective view)

Note: The diameter of test point is 1mm.

Hardware Development Guide

5.2. FOO TPRIN T OF RECO MME NDATI ON

Figure 5–3 Recommended Footprint (perspective view)

NOTE:

 Keep out the area below the test point (blue area on the above figure) in the host PCB.  In order to maintain the module, keep about 3mm between the module and other components in

the host PCB.

Hardware Development Guide

Test Standard

Document Reference

IEC6006826

Environmental testing-Part2.6: Test FC: Sinusoidal Vibration

IEC60068234

Basic environment testing procedures part2.

IEC60068264

Environmental testing-part2-64: Test FH: vibration, broadband random and guidance.

IEC60068214

Environmental testing-part 2-14: Test N: change of temperature

IEC60068229

Basic environmental testing procedures-part2: Test EB and guidance.

IEC6006822

Environmental testing-part2-2: Test B:dry heat

IEC6006821

Environment testing-part2-1: Test A: cold.

GB/T 15844.2

MS telecommunication RF wireless phone-set environment requirement & experimental method – part 4: Strict level of

experimental condition

GB/T 2423.17

Basic environment experiment of electronic products-Experiment Ka: Salt mist experiment method

GB/T 2423.5

Basic environment experiment of electronic products-Part2: Experiment method Try Ea & Introduction: Shock

GB/T 2423.11

Basic environment experiment of electronic products-Part2: Experiment method Try Fd: Broad frequency band random vibration

(General requirement)

TIA/EIA 603 3.3.5

TIA Standard-part3-5:Shock Stability

Working Condition

Min Temperature

Max Temperature

Remark

6. RELATED TEST & TEST STANDARD

6.1. TESTING REFERENCE

The related tests of MODULE comply with the IEC standard, including the equipment running under high/low temperature, storage under high/low temperature, temperature shock and EMC. Table 6-1 is the list of testing standard, which includes the related testing standards for MODULE.

Table 6-1 Testing Standard

NOTE:

 IEC: International Electro technical Commission;  GB/T: Recommended national standard

6.2. DESCRIPT ION OF TE STING ENVIR ONM ENT

The working temperature range of MODULE is divided into the normal working temperature range and the extreme working temperature range. Under the normal working temperature range, the testing result of RF complies with the requirements of 3GPP specifications, and its function is normal. Under the extreme temperature range, the RF index basically complies with the 3GPP specifications, and the quality of data communication is affected to a certain extent, but its normal function is not affected. MODULE has passed the EMC test. Table 6-2 is the requirement for the testing environment, and Table 6-3 lists out the instruments and devices that might be used during the test.

WARNING:

Table 6-2 lists the extreme working conditions for the Module. Using the Module beyond these conditions

may result in permanent damage to the module.

Table 6-2 Testing Environment

Hardware Development Guide

Normal working condition

-30°C

75°C

All the indexes are good.

Extreme working condition

-40~ -30°C

75~85°C

Some indexes become poorer.

Storage

-40°C

85°C

Storage environment of module

Testing Item

Instrument & Device

RF test

Comprehensive testing device

RF cable

Tower antenna

Microwave darkroom

High/Low-temperature running & storage test

High/Low-temperature experimental box

Temperature shock test

Temperature shock experimental box

Vibration test

Vibration console

Test Item

Test Condition

Test Standard

Random vibration

Frequency range: 5-20Hz, PSD: 1.0m2/s3

Frequency range: 20-200Hz, -3dB/oct

3 axis, 1 hour for each axis

IEC 68-2-6

Temperature shock

Low temperature: -40°C ± 2°C

High temperature: +80°C ± 2°C

Temperature changing period: less than 30s

Test duration: 2 hours

Cycle: 10

IEC 68-2-14 Na

High-temperature running

Normal high temperature: 75 °C

Extreme high temperature: 85°C

Duration: 24 hours

GOSUNCN standard

Low-temperature running

Normal low temperature: -30°C

Extreme low temperature: -40°C

Duration: 24 hours

GOSUNCN standard

High temperature & high humidity

Temperature: +60°C

Humidity: 95%

Duration: 48 hours

GOSUNCN standard

High temperature storage

Temperature: 85°C

Duration: 24 hours

IEC 68-2-1 Ab

Low temperature storage

Temperature: -40°C Duration: 24 hours

IEC 68-2-2 Bb

Table 6-3 Testing Instrument & Device

6.3. RELIA BILITY TE STING ENVIRONMENT

The reliability test includes the vibration test, high/low-temperature running, high/low-temperature storage and temperature shock experiment test. Refer to Table 6-4 for the specific parameters.

Table 6-4 Reliability Features

Hardware Development Guide

Temperature

Baking conditions

Baking time

Remarks

125± 5℃

Moisture: ≤60%RH

8 hours

The accumulated baking time must be less than 96 hours

45± 5℃

Moisture: ≤5%RH

192 hours

Module PAD GAP (G)=Center Distance (e)－PAD width (X)

Steel mesh opening

7. SMT PROCESS AND BAKING GUIDE

This chapter describes module’s storage, PAD design, SMT process parameters, baking requirements, etc., and it is applicable

for the process guide to second-level assembly of LCC encapsulation module.

7.1. STORAGE REQUIREMENTS

Storage conditions: temperature<40℃, relative humidity<90% (RH), 12 months weld ability guaranteed under this circumstances of excellent sealing package.

The Moisture sensitivity level for all modules is level 3 (Conforming to IPC/JEDEC J-STD-020). After opening the package, mount within 168 hours under the environment conditions of temperature<30℃, relative humidity<60% (RH). If it doesn’t meet the above

requirements, perform the baking process. See the baking parameters in Table below:

Table 7-1 Baking parameters

The product’s transportation, storage and processing must conform to IPC/JEDEC J-STD-033

When in the process of PAD designing of module, refer to IPC-SM-782A and the chapter 6.2 below.

7.2. MODULE PLAI NNESS STANDARD

Plainness of the module is required to be less than 0.15mm.

Measurement method: put the module on the marble plane, use the feeler gage to measure the gap width at the position of maximum warp, and do not exert force on the module during the measurement.

7.3. PROCESS ROU TIN G SELECTION

The modules are manufactured with the lead-free process and meet the ROHS requirements, therefore it’s recommended to follow the lead-free manufacturing process upon the selection of process routing for module board and main board.

7.3.1. SOLDER PASTE SELECTION

The solder pastes with metal particle TYPE3 and TYPE4 can fulfill the welding requirements. It is accordingly recommended to use the no-clean solder paste. If the solder paste which needs cleaning is used, we cannot guarantee the components on the module board could withstand the washing of the cleaning solvents. This might cause the functional problems of such components and affect the appearance of the module. During the printing process, make sure the solder paste’s thickness at the position of module’s PAD is within 0.18mm~0.20mm.

7.3.2. DESIGN OF MODULE PAD’S STEEL MESH OPENING ON MAIN BOARD

The thickness of the steel mesh on main board is selected according to the encapsulation type of components on the main board. Pay attention to the following requirements:

Make sure to design the module PAD on main board according to chapter 5.

The thickness of steel mesh is 0.15mm or 0.18mm, but the thickness at the position of module pad can be increased to

0.18~0.20mm or the thickness of steel mesh is directly 0.18mm~0.20mm on main board.

Requirements on the thickness of solder paste: control the thickness between 0.18mm and 0.20mm.

See the LCC module PAD’s steel mesh opening in the following table:

Table 7-2 LCC module PAD’s steel mesh opening

Hardware Development Guide

G≥0.5mm

Drill holes at 100% scale in

the direction of width;

extend 0.3mm outward in

the direction of length

G＜0.5mm

Contract 0.05~0.1mm in the

direction of width;

Contract 0.05~0.1mm inward

in the direction of length,

extend 0.5mm outward in

the direction of length.

0.1mm

0.5mm

0.1mm

Steel

mesh

Module PAD on PCB

7.3.3. MODULE BOARD’S SMT PROCESS

1） SMT Tape Reel:

The tape reels, which are suitable for SMT, have been made for most GOSUNCN modules. If the module has provided the tape reel itself and meets the SMT requirements, customers can directly use it for module SMT.

Figure7-2 is just for reference, it doesn’t represent the actual Material Module Tape Reel.

Otherwise, customers need make a loading tool similar to the tape reel. Customers can take out the module from the packaging box, put them into the tape according to the sequence and direction, and then start SMT.

2） Tape Reel Dimension (unit: mm):

Figure 7–1 Module Board’s Steel Mesh Diagram

Figure 7–2 Material Module Pallet

NOTE:

Hardware Development Guide

The following picuture is the tape reel specific dimension for your reference:

A: Whole dimension:

B: Detailed dimension:

Figure 7–3 Tape Reel Dimension

3） Mounting Pressure:

In order to ensure a good contact between the module and the solder paste on main board, the pressure of placing the module board on main board should be 2-5N according to our experiences. Different modules have different numbers of pads, therefore the pressure selected are different. Customers can select proper pressure based on their own situations to suppress the module paste as little as possible, in order to avoid the surface tension of the solder paste melts too much to drag the module during reflow.

7.3.4. MODULE SOLDERING REFLOW CURVE

Module soldering furnace temperature curve is:

 Peak value: 245+0/-5℃

 ≥217℃: 30～～60S

 150～200℃: 60～～120S

 Temperature rise slope: <3℃/S

Hardware Development Guide

 Temperature drop rate: －2～－4℃/S

NOTE:

The test board of furnace temperature must be the main board with the module board mounted on, and

there must be testing points at the position of module board.

Figure 7–4 Module Furnace Temperature Curve Reference Diagram

7.3.5. REFLOW METHOD

If the main board used by customers is a double-sided board, it is recommended to mount the module board at the second time. In addition, it is preferable for the main board to reflow on the mesh belt when mounting at the first time and the second time. If such failure is caused by any special reason, the fixture should be also used to make such main board reflow on the track so as to avoid the deformation of PCB during the reflow process.

7.3.6. MAINTENANCE OF DEFECTS

If poor welding occurs to the module board and main board, e.g., pseudo soldering of the module board and main board, the welder can directly use the soldering iron to repair welding according to the factory’s normal welding parameters.

7.4. MODULE’S BAKING REQUIREMENT S

The module must be baked prior to the second reflow.

7.4.1. MODULE’S BAKING ENVIRONMENT

The operators must wear dust-free finger cots and anti-static wrist strap under the lead-free and good static-resistant environment. Refer to the following environment requirements:

Hardware Development Guide

WARNING:

The product’s transportation, storage and processing must conform to IPC/JEDEC J-STD-033.

7.4.2. BAKING DEVICE AND OPERATION PROCEDURE

Baking device: Any oven where the temperature can rise up to 125°C or above.

Precautions regarding baking: during the baking process, the modules should be put in the high-temperature resistant pallet

flatly and slightly to avoid the collisions and frictions between the modules. During the baking process, do not overlay the modules directly because it might cause damage to the module’s chipset.

7.4.3. MODULE BAKING CONDITIONS

See the baking parameters in Table 7-1.

8. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

This device is intended only for OEM integrators under the following conditions:

1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and the maximum antenna gain allowed for use with this device is 4.8 dBi.

2) The transmitter module may not be co-located with any other transmitter or antenna.

Hardware Development Guide

As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed

IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.

End Product Labeling

This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: 2APNR-GM500U1A”. The grantee's FCC ID can be used only when all FCC compliance requirements are met.

Manual Information To the End User

The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.

Gosuncn Technology Group GM500U1A Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
