Gossen MetraWatt SECULIFE IA Quick Setup Manual

QUICK SETUP

GUIDE

SECULIFE IA

The SECULIFE IA is a high-precision measuring instrument with a measuring angle of 1°. Luminance measurements at distances of 1 meter
to infinity can be performed with the instrument. The SECULIFE IA features mirror reflex optics with a 15° field of view, a sharply marked 1°
measuring circle at the center and a focusing mechanism.

Lens with protective filter or close-up lens and baffle

Focus ring

Eyepiece with cup

USB Connector

Control panel

Battery-compartment

Tripod socket

1

Your SECULIFE IA will be delivered in an aluminum case, including USB-Cable, Battery, GLUX2 Software for Data recording and the Instruction
book.

Tripod socket Close-Up Lens 1 (51 to 100cm) Close-Up Lens 2 (34 to 50cm)

Probe for contact measurement incl. Adapter disc Reflectance standard for indirect illuminance measurement

Carrying strap

2

The display panel and its elements

1 Memory location display
2 Measured value and memory display
3 Unit of measure
4 Symbol for correction factors 1 and 2
5 Difference symbol
6 Ratio symbol
7 Percentage deviation symbol
8 Calculated value, memory group
9 Plus or minus sign for calculated value
10 Low battery warning display
11 USB indicator
12 Measuring function
13 Correction factor function
14 Measured value memory function
15 Ratio function
16 Percentage deviation function
17 Difference function

The SECULIFE IA is equipped with a multiinformation display which can show you various informations. With only five function keys on the
keypad you are able to perform all measurements.

Measuring Key

> Function Key

(A/B - %A - A-B)

Measuring Key

Function Key <
(Lumi –Corr – Mem)

Multifunction Key (MFK)

3
