GPC 14 SEER R-410A
Package Air Conditioners
with R-410A
• Refer to Service Manual RS6300011 (Horizontal)
for installation, operation, and troubleshooting information.
• All safety information must be followed as provided in the Service Manual.
• Refer to the appropriate Parts Catalog for part number information.
• Models listed on page 3.
• Models qualify for the 2009 and 2010 Federal Tax Credits for Energy Efficiency**
ALAL
AL
ALAL
**Note that these tax credits are subject to specific requirements set forth in the American Recovery and
Reinvestment Act of 2009 and in the Internal Revenue Code. Goodman recommends that consumers consult
a tax professional if they have questions about the applicability of these credits.
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does not
assume any responsibility for property damage or personal injury due to improper service procedures or
services performed by an unqualified person.
Copyright © 2009 Goodman Manufacturing Company, L.P.
RT6322007r2
August 2009
PRODUCT IDENTIFICATION
Y
A
A
The model and manufacturing number are used for positive identification of component parts used in manufacturing. Please
use these numbers when requesting service or parts information.
GPC1424H
BRAND:
G: Go odm an
Brand
®
PRODUCT
TYPE:
Packag e Un it
PRODUCT
FAMILY:
C: Cooling
PRODUCT
SERIES:
SEER Ratin g
CONFIGURATION:
H: Ho ri zontal
OMINAL
APACIT
4: 24, 000 BTUH
0: 30, 000 BTUH
6: 36, 000 BTUH
2: 42, 000 BTUH
8: 48, 000 BTUH
0: 60, 000 BTUH
41AA
VOLTAGE:
1: 208-230v
1ph/60Hz
REFRIGERANT:
4: R-410A
MAJOR REVISION:
: Initial R elea se
MIN OR REV ISION:
: Init ial Relea s e
WARNING
WARNING
WARNING
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
2
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Goodman will not be responsible
for any injury or property damage
WARNING
WARNING
individuals meeting the requirements of an "entry level
technician" as specified by the Air-Conditioning, Heating,
and Refrigeration Institute (AHRI). Attempting to install
or repair this unit without such background may result
in product damage, personal injury or death.
Installation and repair of this unit
should be performed
ONLY by
WARNING
HIGH VOLTAGE!
PRODUCT IDENTIFICATION
The model and manufacturing number are used for positive identification of component parts used in manufacturing. Please
use these numbers when requesting service or parts information.
GPC1424H41A*
GPC1430H41A*
GPC1436H41A*
GPC1442H41A*
GPC1448H41A*
GPC1460H41A*
Models qualify for the 2009 and 2010 Federal Tax Credits
for Energy Efficiency**
**Note that these tax credits are subject to specific requirements set forth in the American
Recovery and Reinvestment Act of 2009 and in the Internal Revenue Code. Goodman
recommends that consumers consult a tax professional if they have questions about the
applicability of these credits.
WARNING
WARNING
WARNING
WARNING
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
The United States Environmental Protection Agency (“EPA”) has issued various regulations regarding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
WARNING
WARNING
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
To prevent the risk of property
damage, personal injury, or death,
3
PRODUCT DESIGN
GPC Package Cooling Units are designed for outdoor installations only in either residential or light commercial applications.
The connecting ductwork (Supply and Return) can be connected for either horizontal or vertical airflow. In the vertical
application a matching Roof Curb is recommended.
A return air filter must be installed behind the return air grille(s)
or provision must be made for a filter in an accessible location within the return air duct. The minimum filter area should
not be less than those sizes listed in the Specification Section. Under no circumstances should the unit be operated
without return air filters.
A 3/4” PVC pipe is provided for removal of condensate water
from the indoor coil In order to provide proper condensate
flow, a drain trap is supplied and shipped loose inside the
unit for field installation. (Do not reduce the drain line size.)
Refrigerant flow control is achieved by use of restrictor orifices. GPC units use the FasTest Access Fitting System
with a saddle that is either soldered to the suction and liquid
lines or is fastened with a locking nut to the access fitting
box (core) and then screwed into the saddle.
move the core from the saddle until the refrigerant
charge has been removed. Failure to do so could result in property damage or personal injury.
The single phase units use permanent split capacitor (PSC)
design compressors. Starting components are therefore not
required for these units. A low microfarad run capacitor assists the compressor to start and remains in the circuit during operation.
All GPC14 units have X-13 indoor blower motors that are energized by a 24V signal from the thermostat and are constant torque motors with very low power consumption. The X13 features an integral control module.
Air for condensing (cooling cycle) is drawn through the outdoor coil by a propeller fan, and is discharged vertically out
the top of the unit. The outdoor coil is designed for .0 static.
No additional restriction (ductwork) shall be applied.
Conditioned air is drawn through the filter(s), field installed,
across the coil and back into the conditioned space by the
indoor blower.
GPC1424-30H41* use Copeland Reciprocating Compressors.
GPC1436-60H41* use Copeland Scroll Compressors. There
are a number of design characteristics which are different
from the traditional reciprocating compressor.
Do not re-
- Due to their design Scroll Compressors are inherently
more tolerant of liquid refrigerant. NOTE: Even though the
compressor section of a Scroll compressor is more tolerant of liquid refrigerant, continued floodback or flooded
start conditions may wash oil from the bearing surfaces
causing premature bearing failure.
- Scroll Compressors use white oil which is compatible
with 3GS oil which may be used if additional oil is required.
- Operating pressures and amp draws may differ from standard reciprocating compressors. This information may be
found in the "Cooling Performance Data" section.
Location and Clearances
NOTE: To ensure proper condensate drainage, unit must be
installed in a level position.
10"
36"
WALL
UNIT
36"
36"
Outside Slab Installation - Horizontal (H)
Minimum clearances are required to avoid air recirculation and
keep the unit operating at peak efficiency.
4
PRODUCT DESIGN
36"
U
N
I
T
P
L
E
N
U
M
P
L
A
T
F
O
R
M
Rooftop Installation - Horizontal (H)
In installations where the unit is installed above ground level
and not serviceable from the ground (Example: Roof Top installations), the installer must provide service platform for service person with rails or guards in accordance with local codes
or ordinances or in their absence with the latest edition of the
Uniform Mechanical Code Section 305.
NOTE: Unit can also use roof curb.
24"
WARNING
TO PREVENT POSSIBLE PROPERTY DAMAGE, THE
UNIT SHOULD REMAIN IN AN UPRIGHT POSITION
B
R
U
C
DURING ALL RIGGING AND MOVING OPERATIONS.
TO FACILITATE LIFTING AND MOVING IF A CRANE
36"
IS USED, PLACE THE UNIT IN AN ADEQUATE CABLE
SLING.
Refer to Roof Curb Installation Instructions for proper curb
installation. Curbing must be installed in compliance with
the National Roofing Contractors Association Manual.
5
PRODUCT DESIGN
GPC14[24-60]H41A*
HKR ELECTRICAL DATA
Circuit #1 Circuit #2
Model and Heat Kit Usage
GPH1424H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C* 45 / 51 60 / 60 ---- ---- 9.50 / 32,400
GPH1430H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C*
HKR15*,C* 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPH1436H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C*
HKR15*,C* 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPH1442H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C*
HKR15*,C*
HKR20*,C* 46 / 52 60 / 60 43 / 49 60 / 60 19.50 / 66,500
GPH1448H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C*
HKR15*,C*
HKR20*,C*
GPH1460H41A*
HKR05*,C*
HKR08*,C*
HKR10*,C*
HKR15*,C*
HKR20*,C* 48 / 54 60 / 60 43 / 49 60 / 60 19.50 / 66,500
Minimum Circuit
Ampacity
at 208 / 240V
24 / 27 30 / 30 ---- ---- 4.75 / 16,200
33 / 28 40 / 40 ---- ---- 7.00 / 23,800
24 / 27 30 / 30 ---- ---- 4.75 / 16,200
34 / 39 40 / 40 ---- ---- 7.00 / 23,800
45 / 52 60 / 60 ---- ---- 9.50 / 32,400
24 / 27 30 / 30 ---- ---- 4.75 / 16,200
34 / 39 40 / 40 ---- ---- 7.00 / 23,800
45 / 52 60 / 60 ---- ---- 9.50 / 32,400
25 / 27 30 / 30 ---- ---- 4.75 / 16,200
34 / 39 40 / 40 ---- ---- 7.00 / 23,800
46 / 52 60 / 60 ---- ---- 9.50 / 32,400
46 / 5 2 60 / 60 22 / 25 30 / 3 0 14 .25 / 48,600
25 / 28 30 / 30 ---- ---- 4.75 / 16,200
34 / 40 40 / 40 ---- ---- 7.00 / 23,800
46 / 53 60 / 60 ---- ---- 9.50 / 32,400
46 / 5 2 60 / 60 22 / 25 30 / 3 0 14 .25 / 48,600
46 / 5 2 60 / 60 43 / 49 60 / 6 0 19 .50 / 66,500
26 / 30 30 / 30 ---- ---- 4.75 / 16,200
36 / 40 40 / 40 ---- ---- 7.00 / 23,800
48 / 54 60 / 60 ---- ---- 9.50 / 32,400
48 / 5 4 60 / 60 22 / 25 30 / 3 0 14 .25 / 48,600
Maximum Maximum
Overcurrent Overcurrent
Protection (amps) Protection (a mps)
at 20 8 / 240V at 208 / 240V
Minimum Circuit
Ampacity
at 208 / 240V
kW & BTU
at 240V
Actual
IMPORTANT NOTE: A separate power supply is required for the HKR heater kit.
All wires and overcurrent protection devices are sized for use with electric heaters only and without
WARNING
WARNING
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
6
PRODUCT DIMENSIONS
GPC14[24-60]H41A*
A
14.000
4.512
66.542
14.000
4.500
SUPPLY
B
6.500
14.000
RETURN
BACK VIEW
(DUCT OPENINGS)
34.075
Chassis Model A B
GPC1424 33 30½
Small
GPC1430 33 30½
GPC1436 33 35½
Medium
GPC1442 33 35½
GPC1448 33 38½
Large
GPC1460 33 38½
Dimensions in inches
7
PACKAGE COOLING SPECIFICATIONS
)
GPC1424H41* GPC1430H41* GPC1436H41*
COOLING
CAPACITY
UNIT
ELECTRICAL
SPECIFICATION
COMPRESSOR
CONDENSER
FAN MOTOR
COND E NSE R F AN
CONDENSER
COIL
EVAPORATOR
BLOWER
MOTOR
EVAPORATOR
BLOWER
EVAPORATOR
COIL
GENERAL
INFORMATION
COOLI NG CAPACI TY, BT UH 24, 600 28,400 35,6 00
SE ER / EER 14.5 / 12.1 14. 0 / 12.0 14.0 / 12. 0
VOLTAGE (NAM EPLATE) 208-230/1/60 208-230/1/60 208-230/1/60
AMPS (TOTAL) 10.5 13.1 6 20.06
MINI MUM CIRC UIT AMPACITY 12.5 1 5 .6 2 4 .2
MAXIMUM OVERCURRENT PROTECTION
TYPE RECIP RECIP SCROLL
RA T E D LO AD AM P S 7.9 9. 8 16.7
LO CK ED RO TOR A M PS 41 55 79
HORSEP O WER 1/ 6 1/4 1/4
RPM 815 830 830
FULL LOAD AMPS 1.1 1.5 1.5
LOCKED ROTOR AMPS 1. 7 3.0 3. 0
BLADE DIAMETER (INCHES) / N UMBER OF BLADE S 22 / 3 22 / 3 22 / 3
FACE AREA - SQ. FT. 13.4 13.4 13.4
NUM BE R OF ROWS 1 1 1
FINS PER INCH 2 4 24 24
HORSEPOWER - NO. OF SPEEDS 1/2 - 5 1/2 - 5 1/ 2 - 5
FULL LOAD AMPS 1.5 1.86 1. 86
LOCKED ROTOR AMPS NA NA NA
MOTOR SPEED TAP - COOLING T2 T2 T2
RPM 105010501050
DIAM ETER X WIDT H (INCH ES ) 10 X 8 10 X 8 10 X 8
HI EFFICIENCY COOLING CFM 850 1,050 1,200
5 TON NOM INA L C OOLING C FM NA NA NA
FAN ONLY COOLING CFM 80 0 950 1,1 00
MAX EXTERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5
FACE AREA - SQ. FT. 5.25 4.67 5.2
NUM BE R OF ROWS 3 4 3
FINS PER INCH 1 6 16 14
FILTER SIZE - SQ. FT. * 20 x 20 x 1 20 x 25 x 1 25 x 25 x 1
DRAIN S IZE (I NCHES) 3/4" 3/4" 3/4"
EXP ANS I ON DEV IC E ORI FI CE (0 .0 57 ) ORI F ICE (0 .0 60 ) OR IF ICE (0.065)
REFRIGERANT CHARGE R-410A (Oz.) 83 78 80
POWER SUPPL Y CONDUIT KNOCKOUT SIZE (INCHES
LOW VOLTAGE CONDUIT KNOCKOUT SIZE (INCHES) 1/2 1/2 1/2
SHIPPING WEIGHT LBS. 310 310 370
OPERATING WEIGHT LBS. 300 300 360
(1)
3/4, 1, 1-1/4 3/4, 1, 1- 1/4 3/4, 1, 1-1/4
GPC14[24-36]H41A*
20 25 40
(1)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*
Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
All wires and overcurrent protection devices are sized for use with electric heaters only and without
WARNING
WARNING
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
8
PACKAGE COOLING SPECIFICATIONS
GPC14[42-60]H41*
GPC1442H41* GPC1448H41* GPC1460H41*
COOL ING
CAPACITY
UNIT
ELECTRICAL
SPECIFICATION
COMPRESSOR
CONDENSER
FAN MOTOR
CONDENSER FAN
CONDENSER
COIL
EVAPORATOR
BLOWER
MOTOR
EVAPORATOR
BLOWER
EVAPORATOR
COIL
GENERAL
INFORM ATION
COOLING CAPACITY, BTUH 40,500 46,500 5 7,500
SEER / EER 14.5 / 12.0 14.5 / 12.1 14.2 / 12.0
VOLTAGE (NAMEPLATE) 208-230/1/60 208-230/1/60 208-230/1/60
AMPS (TOT A L) 22.2 24.2 30.7
MINI MU M CIRC UIT AMP A CIT Y 26.6 29.1 37. 3
MAXIMUM OVERCURRENT PROTECTION
TYPE SCROLL SCRO LL SCROLL
RATED LOAD AMPS 17.9 19.9 26.4
LO CK E D ROTOR AMPS 112 109 134
HORSEPOWER 1/4 1/4 1/4
RPM 1075 1075 1075
FULL LOAD AMPS 1.4 1.4 1.4
LOCKED R OTOR AMPS 2.9 2.9 2.9
BLADE DIAMETER (INCHES) / NUMBER OF BLADES 22 / 4 22 / 4 22 / 4
FACE AREA - S Q. FT. 17.0 19.1 19.1
NUMBER OF ROWS 112
FINS PER INCH 24 21 16
HORSEPOWER - NO. OF SPEEDS 1/2 - 5 3/4 - 5 3/4 - 5
FULL LOAD AMPS 2.9 2.9 2.9
LOCKE D ROT OR AMPS NA NA NA
MOTOR SP EED TAP - C OOLING T2 T2 T2
RPM 1050 1050 1050
DIAMETER X WIDTH (INCHES) 10 x 8 10 x 8 11 x 8
HI EFFICIENCY COOLING CFM 1,300 1,600 1,600
5 TON NOMINAL COO LING CFM NA NA 1, 8 00
FAN ON LY CO OLING C F M 1,2 00 1,400 1,600
MAX EXTER NAL STATIC PRESS ("w.c.) 0.5 0 .5 0.5
FACE AREA - SQ. FT. 6.2 6.2 7.0
NUMBER OF ROWS 444
FINS PER INCH 14 14 14
FILT E R SIZE - SQ. F T . * ( 2) 20 x 2 0 x 1 (2) 20 x 20 x 1 ( 2) 20 x 25 x 1
DRAIN SIZE (INCHES) 3/4" 3/4" 3/4"
EXPANSIO N DEVICE ORIFICE (0.072) ORIFICE (0.076) ORIFICE (0.088)
REFRIGE R A NT CH ARGE R- 410A (Oz.) 11 8 123 188
POWER SUPPLY CONDUIT KNOCKOUT SIZE (INCHES) 3/4, 1, 1-1/4 3/4, 1, 1-1/4 3/4, 1, 1-1/4
LOW VOLTAGE CONDUIT KNOCKOUT SIZE (INCHES) 1/2 1/2 1/2
SHI P PING WEI GHT LB S. 370 400 400
OPE RA T I NG WEI GHT LB S. 360 390 390
(1)
40 45 60
(1)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*
Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
All wires and overcurrent protection devices are sized for use with electric heaters only and without
WARNING
WARNING
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
9
ACCESSORIES
GPC14[24-60]H41A*
ACCESSORIES - GPC/GPH****H UNITS
Part Number Description
OT18-60A Outdoor Thermostat Kit w/Lockout Stat
OT/EHR18-60 Emergency Heat Relay Kit
HKR Electri c Heat Kit
PCCP101-103 Roof Curb
PCP101-103 Downflow Plenum Kit
PCP101-103R8 Downflow Plenum Kit w/ R-8 Insulation
PCEC101-103 Downflow Economizer for GPC-(H) A/C - To Be Used With PCP101-103
PCEH101-103 Downflow Economizer for GPH-(H) Heat Pump - To Be Used With PCP101-103
PCMD101-103 Manual Damper - To Be Used With PCP101-103
PCMDM101-103 Motorized Damper - To Be Used With PCP101-103
GPHMD101-103 Manual Damper for Horizontal Applications
SQRPCH101 Square to Round Adapters 16"&14"
SQRPCH102-103 Square to Round Adapters 18"&14"
SQ RPC101 Squar e to Round Adapter - For Use With PCCP1 01-103 Curb 16" Rounds
SQRPC102-103 Square to Round Adapter For Use With PCCP101-103 Curb 18" Rounds
PCFR101-103 External Horizontal Filter Rack
PCEF101-103 Elbow & Flashing w/ R-8 Liner
CDK36 Flush Mount Concentric Duct Kit
CDK36515 Flush Mount Concentric Duct Kit w/ Filter
CDK36530 Step Down Concentric Duct Kit
CDK36535 Step Down Concentric Duct Kit w/ Filter
CDK4872 Flush Mount Concentric Duct Kit
CDK4872515 Flush Mount Concentric Duct Kit w/ Filter
CDK4872530 Step D own Concentric Duct Kit
CDK4872535 Step D own Concentric Duct Kit w/ Filter
10
BLOWER PERFORMANCE DATA
Dry Coil Data
GPC14[24-60]H41A*
Model Speed Volts
T1
T2,T3
GPC1424H41**
GPC1430H41**
T4, T5
T1
T2,T3
T4, T5
T1
T2,T3
CFM 934 759 755 638 581 489 - -
230
WATTS957776738390 - -
CFM 990 837 801 744 696 652 601 -
230
WATTS 107 94 105 110 119 133 142 -
CFM 1061 989 947 925 876 - - -
230
WATTS 126 1 34 146 158 169 - - -
CFM 1022 929 894 829 797 748 695 643
230
WATTS 116 114 126 134 144 156 168 173
CFM 1103 1063 1012 962 937 - - -
230
WATTS 142 1 54 165 173 185 - - -
CFM 1285 1240 1202 1163 1124 1076 1046 1003
230
WATTS 205 218 231 244 257 268 280 288
CFM 1234 1111 1071 1024 933 922 - -
230
WATTS 144 1 40 152 164 179 183 - -
CFM 1287 1232 1186 1133 1099 1053 - -
230
WATTS 162 1 75 187 201 213 221 - -
E.S.P (In. of H
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
2
O)
GPC 1436H41**
GPC1442H41**
GPC1448H41**
GPC 1460H41**
T4, T5
T1
T2,T3
T4, T5
T1
T2,T3
T4, T5
T1 , T2, T3
T4, T5
CFM 1381 1325 1277 1233 1181 1144 - -
230
WATTS 195 2 03 217 233 247 258 - -
CFM 1272 1197 1145 1106 1055 998 947 906
230
WATTS 160 168 183 191 211 220 230 243
CFM 1357 1297 1244 1194 1147 1099 1049 1008
230
WATTS 188 202 213 228 245 255 267 284
CFM 1537 1478 1431 1386 1336 1293 1253 1208
230
WATTS 244 258 274 288 303 317 329 341
CFM 1418 1383 1349 1312 1275 1228 1178 1141
230
WATTS 242 258 273 282 299 308 320 338
CFM 1175 1635 1645 1515 1510 1450 1430 1400
230
WATTS 395 420 435 445 455 465 470 475
CFM 1845 1790 1715 1685 1590 1580 1530 1500
230
WATTS 490 505 520 535 550 560 570 575
CFM 1775 1635 1645 1515 1510 1450 1430 1400
230
WATTS 395 420 435 445 455 465 470 475
CFM 2025 1900 1840 1780 1725 1650 1620 1580
230
WATTS 575 595 620 630 645 655 660 670
NOTES :
1. Data shown is dr y coil. Wet coil pres sure drop is approx.
2. 0.1" H
3. Data shown does not include fi l ter pr ess ure drop, approx. 0.08” H
4. Redu ce ai rflow by 2% fo r 208V operation.
O, for 2 row indoor c oil; 0.2” H2O, for 3 row in door coil; and 0.3” H2O, for 4 row indoor coil.
2
O.
2
11
BLOWER PERFORMANCE DATA
÷ CFM
130 140 150
FORMULAS
BTU OUTPUT = CFM x 1.08 x RISE
1.08
BTU OUTPUT
RISE =
100
2400 CFM
2200
2000
1800
1600
1400
1200
1100
1000
900
800
OUTPUT BTU/HR x 1000
12
BTU OUTPUT vs TEMPERATURE RISE CHART
700
600 CFM
30 40 50 60 70 80 90 110 120
100
90
80
70
60
50
40
30
20
10
TEMPERATURE RISE
COOLING PERFORMANCE DA TA GPC1424H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
15 11 20 18 15 10 19 17 14 10
8.7 9.1 8.8 9.0 9.3 9.6 9.3 9.5 9.8 10.2
389 406 386 415 438 457 426 458 484 505
151 160 136 145 158 168 141 150 163 174
2.04 2.11 2.01 2.06 2.13 2.20 2.08 2.13 2.20 2.28
25.4 27.3 21.7 22.3 24.1 25.9 20 .1 20.7 22.4 24.0
0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
19
8.5
369
138
1.97
23.5
0.83
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
16 11 21 19 16 11 19 18 15 10
8.7 9.0 8.7 8.9 9.2 9.5 9.2 9.4 9.7 10.1
386 402 382 411 434 452 422 454 479 500
149 159 135 143 156 166 139 148 162 172
2.02 2.09 1.99 2.04 2.11 2.18 2.06 2.11 2.19 2.26
24.7 26.5 21.0 21.7 23.4 25.2 19 .5 20.1 21.7 23.3
0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40
19
8.4
365
137
1.95
22.8
0.79
16 11 21 20 16 11 20 18 15 10
8.4 8.7 8.5 8.7 9.0 9.3 9.0 9.2 9.5 9.8
374 390 370 398 421 439 409 440 465 485
145 154 131 139 152 161 135 144 157 167
1.97 2.03 1.94 1.98 2.05 2.12 2.01 2.06 2.13 2.20
22.8 24.4 19.4 20.0 21.6 23.2 18 .0 18.5 20.0 21.5
0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
20
8.2
354
133
1.90
21.0
0.76
65 75 85 95 105 115
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
MBh 24.1 25.0 27.4 - 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.3 22.1 24.2 - 19.7 20.5 22.4 -
Design Subcooling, 9 ± 2°F @ the l iquid access fitting connection AHRI 95 test conditions. Design Superheat 5 ± 2°F @ the compressor suction access fi tt ing co n n ection .
MODE L: GPC 1424H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T 171511 - 171511 - 171511 - 18 15 12 - 171511 - 161411 -
AMPS 6.6 6.8 7.0 - 7.1 7.3 7.5 - 7.7 7.9 8.1 - 8.2 8.4 8.7 - 8.7 8.9 9.2 - 9.2 9.4 9.7 -
HI PR 233 251 265 - 262 282 298 - 298 321 338 - 339 365 386 - 38 2 411 4 34 - 422 454 479 -
955 KW 1.57 1.60 1.66 - 1.70 1.73 1.79 - 1.81 1.85 1.91 - 1.91 1.95 2.02 - 1.99 2.04 2.11 - 2.06 2.11 2.19 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
MBh 23.4 24.3 26.6 - 22.9 23.7 26.0 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 20.7 21.4 23.5 - 19.2 19.9 21.8 -
LO PR 111 118 129 - 118 125 137 - 122 130 142 - 128 137 149 - 135 143 156 - 139 148 162 -
Delta T 181612 - 181612 - 181612 - 18 16 12 - 181612 - 171511 -
AMPS 6.6 6.7 6.9 - 7.1 7.2 7.5 - 7.7 7.8 8.1 - 8.1 8.3 8.6 - 8.6 8.8 9.1 - 9.1 9.3 9.6 -
HI PR 231 249 263 - 259 279 295 - 295 317 335 - 336 361 382 - 37 8 407 4 29 - 418 449 474 -
70 850 KW 1.56 1.59 1.64 - 1.68 1.72 1.78 - 1.79 1.83 1.90 - 1.89 1.93 2.00 - 1.97 2.02 2.09 - 2.05 2.09 2.17 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
MBh 21.6 22.4 24.5 - 21.1 21.9 24.0 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.1 19.8 21.7 - 17.7 18.3 20.1 -
LO PR 110 117 128 - 116 124 135 - 121 129 141 - 127 135 148 - 133 142 155 - 138 147 160 -
Delta T 181612 - 181612 - 181612 - 19 16 12 - 181612 - 171511 -
745 KW 1.52 1.55 1.60 - 1.64 1.68 1.73 - 1.75 1.79 1.85 - 1.84 1.88 1.95 - 1.92 1.97 2.03 - 1.99 2.04 2.11 -
AMPS 6.4 6.6 6.8 - 6.9 7.1 7.3 - 7.5 7.6 7.9 - 7.9 8.1 8.4 - 8.4 8.6 8.9 - 8.9 9.1 9.4 -
HI PR 224 241 255 - 252 271 286 - 286 308 325 - 326 351 370 - 36 7 394 4 17 - 405 436 460 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93
MBh 24.5 25.2 27.3 29.3 23.9 24.7 26.7 28.6 23.4 24.1 26.0 28.0 22.8
Delta T 20181510201915112019151120
955 KW 1.58 1.62 1.67 1.73 1.71 1.75 1.81 1.87 1.82 1.87 1.93 2.00 1.92
AMPS 6.76.87.17.37.27.47.67.97.88.08.28.58.3
HI PR 236 254 268 279 265 285 301 314 301 324 342 357 34 3
S/T 0.81 0.72 0.55 0.35 0.83 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88
MBh 23.8 24.5 26.5 28.5 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1
LO PR 112 120 131 139 119 126 138 147 123 131 143 153 130
Delta T 21191611211916112119161121
75 850 KW 1.57 1.60 1.66 1.71 1.70 1.73 1.79 1.85 1.81 1.85 1.91 1.98 1.91
AMPS 6.66.87.07.27.17.37.57.87.77.98.18.48.2
HI PR 233 251 265 277 262 282 298 310 298 321 339 353 33 9
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85
MBh 22.0 22.6 24.5 26.3 21.5 22.1 23.9 25.7 20.9 21.6 23.3 25.1 20.4
LO PR 111 118 129 138 118 125 137 145 122 130 142 151 128
Delta T 21191611212016112120161121
745 KW 1.53 1.56 1.61 1.67 1.65 1.69 1.75 1.81 1.76 1.80 1.86 1.93 1.86
AMPS 6.56.66.87.17.07.17.37.67.57.77.98.28.0
HI PR 226 244 257 268 254 273 289 301 289 311 328 343 32 9
LO PR 108 115 125 134 114 121 133 141 119 126 138 147 125
* IDB: Entering Indoor Dry Bulb Tempe rature NOTE: Sha ded area is ACCA (TVA) conditions
High and low pr es sures are measured at the liquid and suction access fittings.
13
COOLING PERFORMANCE DA TA GPC1424H41A*
COOLING OPERATION
16 23 22 19 16 21 21 18 14
9.1 8.8 9.0 9.3 9.6 9.3 9.5 9.8 10.2
406 386 415 438 457 426 458 484 505
2.11 2.01 2.06 2.13 2.20 2.08 2.13 2.21 2.28
2.04
160 136 145 158 168 141 150 163 174
8.8
390
151
26.3 21.4 21.9 23.4 25.0 19.8 20.3 21.6 23.1
0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
20
24.6
0.74
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61
MBh 25.0 25.5 27.2 29.1 24.4 24.9 26.6 28.4 23.8 24.3 26.0 27.8 23.2 23.7 25.3 27.1 22.0 22.5 24.1 25.7 20.4 20.9 22.3 23.8
Delta T22211915232219152322191522 22 19 152122191520201714
AMPS 6.86.97.17.47.37.47.77.97.98.08.38.68.4 8.6 8.8 9.18.99.19.49.79.49.69.910.3
HI PR 238 256 271 282 267 288 304 317 304 327 345 360 346 373 393 410 389 41 9 4 43 462 430 463 489 51 0
S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91
MBh 24.2 24.8 26.4 28.3 23.7 24.2 25.8 27.6 23.1 23.6 25.2 27.0 22.5 23.0
LO PR 114 121 132 140 120 128 139 148 125 133 145 154 131 139 152 162 137 146 159 170 142 151 165 176
Delta T23221915232220162322201624 23
AMPS 6.76.87.17.37.27.47.67.97.88.08.28.58.3 8.5
HI PR 236 2 54 2 68 2 79 265 285 301 3 14 3 0 1 324 342 357 343 369
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
MBh 22.4 22.8 24.4 26.1 21.8 22.3 23.8 25.5 21.3 21.8 23.3 24.9 20.8 21.3 22.7 24.3 19.8 20.2 21.6 23.1 18.3 18.7 20.0 21.4
LO PR 112 120 131 139 119 126 138 147 123 131 143 153 130 138
Delta T24232016242320162423201624 23 20 162423201622211815
AMPS 6.56.76.97.17.07.27.47.77.67.88.08.38.1 8.3 8.5 8.88.68.89.09.49.09.39.69.9
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
HI PR 229 246 260 271 257 276 292 304 292 314 332 346 332 358 378 394 374 40 3 4 25 443 413 445 470 49 0
MBh 25.4 25.9 27.1 28.9 24.8 25.3 26.5 28.2 24.2 24.7 25.8 27.6 23.6 24.1 25.2 26.9 22.4 22.9 24.0 25.6 20.8 21.2 22.2 23.7
LO PR 109 116 127 135 115 123 134 143 120 127 139 148 126 134 146 156 132 140 153 163 136 145 158 169
Delta T24232219242422192324221923 23 23 192222221920202118
AMPS 6.87.07.27.47.37.57.78.07.98.18.48.78.4 8.6 8.9 9.28.99.29.59.89.59.710.010.4
HI PR 241 259 273 285 270 290 307 320 307 330 349 364 350 376 397 414 393 42 3 4 47 466 435 468 494 51 5
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
MBh 24.6 25.1 26.3 28.1 24.1 24.5 25.7 27.4 23.5 24.0 25.1 26.8 22.9 23.4 24.5 26.1 21.8 22.2 23.3 24.8 20.2 20.6 21.5 23.0
LO PR 115 122 133 142 121 129 141 150 126 134 146 156 132 141 154 164 139 148 161 172 143 153 167 177
Delta T25242320252523202525232025 25 23 202424232022222219
AMPS 6.86.97.17.47.37.47.77.97.98.08.38.68.4 8.6 8.8 9.18.99.19.49.79.49.69.910.3
HI PR 238 256 271 282 267 288 304 317 304 327 345 360 346 373 393 410 389 41 9 4 43 462 430 463 489 51 0
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
MBh 22.7 23.2 24.3 25.9 22.2 22.6 23.7 25.3 21.7 22.1 23.2 24.7 21.2 21.6 22.6 24.1 20.1 20.5 21.5 22.9 18.6 19.0 19.9 21.2
LO PR 114 121 132 140 120 128 139 148 125 133 145 154 131 139 152 162 137 146 159 170 142 151 165 176
Delta T25252320252524202525242026 25 24 212525232023232219
AMPS 6.66.76.97.27.17.27.57.77.77.88.18.48.1 8.3 8.6 8.98.68.89.19.49.19.39.610.0
HI PR 231 249 263 274 259 279 295 307 295 317 335 349 336 361 382 398 378 40 7 4 29 448 417 449 474 49 5
LO PR 110 117 128 136 116 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 170
14
Design Subcooling, 9 ± 2°F @ the liquid access fitting connection AHRI 95 test conditions. Design Superheat 5 ± 2°F @ the compressor suction access fi t t ing co n n ection.
MODE L: GPC 1424H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
955 KW 1.60 1.63 1.69 1.74 1.72 1.76 1.82 1.89 1.84 1.88 1.95 2.01 1.94 1.99 2.05 2.13 2.03 2.07 2.15 2.22 2.10 2.15 2.22 2.30
80 850 KW 1.58 1.62 1.67 1.73 1.71 1.75 1.81 1.87 1.82 1.87 1.93 2.00 1.92 1.97
745 KW 1.54 1.58 1.63 1.68 1.67 1.70 1.76 1.82 1.78 1.82 1.88 1.94 1.87 1.92 1.98 2.05 1.96 2.00 2.07 2.14 2.03 2.07 2.15 2.22
955 KW 1.61 1.64 1.70 1.76 1.74 1.78 1.84 1.90 1.86 1.90 1.96 2.03 1.96 2.00 2.07 2.14 2.04 2.09 2.16 2.24 2.12 2.17 2.24 2.32
85 850 KW 1.60 1.63 1.69 1.74 1.72 1.76 1.82 1.89 1.84 1.88 1.95 2.01 1.94 1.99 2.05 2.13 2.03 2.07 2.15 2.22 2.10 2.15 2.22 2.30
745 KW 1.56 1.59 1.64 1.70 1.68 1.72 1.78 1.84 1.79 1.83 1.90 1.96 1.89 1.93 2.00 2.07 1.97 2.02 2.09 2.16 2.05 2.09 2.17 2.24
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* N OTE: Shaded are a i s AHR I Rating Cond iti ons ID B: Entering In door Dry B ul b T emperat ure KW = Total system power
COOLING PERFORMANCE DA TA GPC1430H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
15 10 19 18 14 10 18 16 14 9
400 417 396 426 450 469 437 470 497 518
29.3 31.5 25.0 25.8 27.9 29.9 23.2 23.9 25.8 27.7
0.64 0.41 0.98 0.88 0.67 0.43 0.99 0.89 0.67 0.43
18
27.1
0.85
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
151 161 136 145 158 168 141 150 163 174
2.41 2.49 2.38 2.43 2.52 2.61 2.47 2.52 2.61 2.70
10.1 10.5 10.2 10.4 10.7 11.1 10.8 11.0 11.4 11.8
9.8
378
138
2.33
15 11 20 18 15 10 19 17 14 10
396 413 392 422 445 464 433 466 492 513
28.5 30.6 24.3 25.0 27.1 29.0 22.5 23.2 25.1 26.9
0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
19
26.3
0.81
149 159 135 143 156 167 139 148 162 172
2.39 2.47 2.36 2.41 2.50 2.58 2.44 2.50 2.59 2.68
10.0 10.4 10.1 10.3 10.7 11.0 10.7 10.9 11.3 11.7
9.7
375
137
2.31
16 11 20 19 15 11 19 17 14 10
9.8 10.1 9.8 10.1 10.4 10.7 10.4 10.6 11.0 11.4
384 400 380 409 432 450 420 452 477 498
145 154 131 139 152 162 135 144 157 167
26.3 28.2 22.4 23.1 25.0 26.8 20.8 21.4 23.1 24.8
24.3
2.33 2.41 2.30 2.35 2.43 2.52 2.38 2.44 2.52 2.61
0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40
19
9.5
363
133
2.25
0.78
65 75 85 95 105 115
S/T 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.50 -
MBh 27.8 28.8 31.6 - 27.2 28.2 30.9 - 26.5 27.5 30.1 - 25.9 26.8 2 9.4 - 24.6 25.5 27.9 - 22.8 2 3.6 25.9 -
Design Subcooling, 10 ± 2 °F @ the liquid ac cess fitting connection ARI 95 test conditions . Design S uperheat 10 ± 2 °F @ the compressor sucti on acc ess fitting co nnecti o n.
MODE L: GPC 1430H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T161411 - 171411 - 171411 - 17 15 11 - 171411 - 151310 -
AMPS 7.7 7.9 8.1 - 8.3 8.5 8.7 - 8.9 9.1 9.4 - 9.5 9.7 10.0 - 10.1 10.3 10.7 - 10.7 10.9 11.3 -
HI PR 240 258 272 - 269 289 30 5 - 306 329 347 - 348 375 396 - 392 421 445 - 433 466 492 -
1180 KW 1.86 1.90 1.96 - 2.01 2.06 2.12 - 2.14 2.19 2.27 - 2.26 2.31 2.39 - 2.36 2.41 2.50 - 2.44 2.50 2.59 -
S/T 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.45 - 0.80 0.66 0.46 - 0 .83 0.69 0.48 - 0.83 0.70 0.48 -
MBh 27.0 28.0 30.7 - 26.4 27.4 30.0 - 25.8 26 .7 29.3 - 25.1 26.1 28.5 - 23.9 24.7 27.1 - 22.1 22.9 25.1 -
LO PR 111 119 129 - 118 125 137 - 122 130 142 - 128 137 149 - 135 143 156 - 139 148 162 -
Delta T171511 - 171511 - 171511 - 18 15 11 - 171511 - 161411 -
AMPS 7.6 7.8 8.0 - 8.2 8.4 8.6 - 8.9 9.1 9.3 - 9.4 9.6 10.0 - 10.0 10.2 10.6 - 10.6 10.8 11.2 -
HI PR 237 255 269 - 266 286 30 2 - 303 326 344 - 345 371 392 - 388 417 441 - 428 461 487 -
70 1050 KW 1.84 1.89 1.95 - 1.99 2.04 2.11 - 2.12 2.17 2.25 - 2.24 2.29 2.37 - 2.34 2.39 2.47 - 2.42 2.48 2.56 -
S/T 0.70 0.58 0.40 - 0.72 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0 .80 0.66 0.46 - 0.80 0.67 0.46 -
MBh 24.9 25.8 28.3 - 24.4 25.2 27.7 - 23.8 24 .6 27.0 - 23.2 24.0 26.3 - 22.0 22.8 25.0 - 20.4 21.2 23.2 -
LO PR 110 117 128 - 117 124 135 - 121 129 141 - 127 135 148 - 133 142 155 - 138 147 160 -
Delta T171511 - 181512 - 181512 - 18 15 12 - 181512 - 161411 -
920 KW 1.80 1.84 1.90 - 1.94 1.99 2.05 - 2.07 2.12 2.19 - 2.18 2.23 2.31 - 2.28 2.33 2.41 - 2.36 2.41 2.50 -
AMPS 7.4 7.6 7.8 - 8.0 8.2 8.4 - 8.6 8.8 9.1 - 9.2 9.4 9.7 - 9.7 10.0 10.3 - 10.3 10.5 10.9 -
HI PR 230 248 261 - 258 278 29 3 - 294 316 334 - 334 360 380 - 376 405 427 - 416 447 472 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 138 150 - 134 142 155 -
S/T 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95
MBh 28.3 29.1 31.5 33.9 27.6 28.5 30.8 33.1 27.0 27.8 30.1 32.3 26.3
Delta T19181410191815101918151019
1180 KW 1.88 1.92 1.98 2.05 2.03 2.07 2.14 2.22 2.16 2.21 2.29 2.36 2.28
AMPS 7.87.98.28.58.38.58.89.19.09.29.59.89.6
HI PR 242 2 60 2 75 2 87 272 292 309 3 22 3 0 9 332 351 366 352
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.90
MBh 27.5 28.3 30.6 32.9 26.8 27.6 29.9 32.1 26.2 27.0 29.2 31.3 25.6
LO PR 113 120 131 139 119 126 138 147 124 131 143 153 130
Delta T20181510201815102019151020
75 1050 KW 1.86 1.90 1.96 2.03 2.01 2.06 2.12 2.20 2.14 2.19 2.27 2.34 2.26
AMPS 7.77.98.18.48.38.58.79.08.99.19.49.89.5
HI PR 240 2 58 2 72 2 84 269 289 305 3 19 3 0 6 329 347 362 348
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87
MBh 25.4 26.1 28.3 30.3 24.8 25.5 27.6 29.6 24.2 24.9 26.9 28.9 23.6
LO PR 111 119 129 138 118 125 137 146 122 130 142 151 128
Delta T20191510201915112019151121
920 KW 1.81 1.85 1.92 1.98 1.96 2.00 2.07 2.14 2.09 2.14 2.21 2.28 2.20
AMPS 7.57.77.98.28.18.28.58.88.78.99.29.59.3
HI PR 232 2 50 2 64 2 75 261 281 296 3 09 2 9 7 319 337 351 338
LO PR 108 115 126 134 114 121 133 141 119 126 138 147 125
* IDB: Entering Indoor Dry Bulb Temperature NOTE: Shaded area i s ACCA (TVA) cond itions
High and low pr es sures are measur ed at the liquid and suction access fittings.
15
COOLING PERFORMANCE DA TA GPC1430H41A*
COOLING OPERATION
15 22 21 19 15 20 20 17 14
417 396 426 450 469 437 470 497 518
2.49 2.38 2.43 2.52 2.61 2.47 2.52 2.61 2.70
2.41
161 136 145 158 168 141 150 163 174
10.5 10.2 10.4 10.7 11.1 10.8 11.0 11.4 11.8
400
151
10.1
30.4 24.7 25.3 27.0 28.8 22.9 23.4 25.0 26.7
0.57 1.00 0.97 0.79 0.59 1.00 0.97 0.79 0.59
19
28.4
0.76
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.62 1.00 1.00 0.83 0.62
MBh 28.8 29.4 31.4 33.6 28.1 28.7 30.7 32.8 27.5 28.1 30.0 32.1 26.8 27.4 29.3 31.3 25.5 26.0 27.8 29.7 23.6 24.1 25.7 27.5
Delta T21201814222118142121181421 21 18 142020181418191713
AMPS 7.88.08.28.58.48.68.99.29.19.39.69.99.7 9.9 10.210.610.310.510.811.210.911.111.511.9
HI PR 244 263 278 290 274 295 312 325 312 336 354 370 355 382 404 421 400 43 0 4 54 474 442 475 502 52 3
S/T 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.53 0.96 0.90 0.73 0.55 0.99 0.93
MBh 28.0 28.6 30.5 32.6 27.3 27.9 29.8 31.9 26.7 27.2 29.1 31.1 26.0 26.6
LO PR 114 121 132 141 120 128 139 149 125 133 145 154 131 139 152 162 137 146 160 170 142 151 165 176
Delta T22211815222119152221191523 22
AMPS 7.87.98.28.58.38.58.89.19.09.29.59.89.6 9.8
HI PR 242 2 60 2 75 2 87 272 292 309 3 22 3 0 9 332 351 366 352 379
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57
MBh 25.8 26.4 28.2 30.1 25.2 25.8 27.5 29.4 24.6 25.1 26.9 28.7 24.0 24.5 26.2 28.0 22.8 23.3 24.9 26.6 21.1 21.6 23.1 24.7
LO PR 113 120 131 139 119 126 138 147 124 131 144 153 130 138
Delta T22221915232219152322191523 22 19 152322191521201814
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 0.99 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 0.99 0.81
AMPS 7.6 7.7 8.0 8.2 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.3 9.6 9.9 10.2 9.9 10.1 10.5 10.8 10.5 10.7 11.1 11.5
HI PR 235 253 267 278 263 283 299 312 300 322 340 355 341 367 388 404 384 41 3 4 36 455 424 456 482 50 3
MBh 29.3 29.9 31.3 33.4 28.6 29.2 30.6 32.6 27.9 28.5 29.8 31.8 27.3 27.8 29.1 31.1 25.9 26.4 27.7 29.5 24.0 24.5 25.6 27.3
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 134 146 156 132 140 153 163 136 145 159 169
Delta T23222118222321182222211821 22 22 192021211819192017
AMPS 7.9 8.1 8.3 8.6 8.5 8.7 8.9 9.3 9.2 9.4 9.7 10.0 9.8 10.0 10.3 10.7 10.4 10.6 10.9 11.3 10.9 11.2 11.6 12.0
HI PR 247 266 281 293 277 298 315 328 315 339 358 373 359 386 408 425 404 43 4 4 59 478 446 480 507 52 9
S/T 0.95 0.91 0.83 0.67 0.98 0.95 0.86 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
MBh 28.5 29.0 30.4 32.4 27.8 28.3 29.7 31.7 27.1 27.7 29.0 30.9 26.5 27.0 28.3 30.1 25.1 25.6 26.8 28.6 23.3 23.7 24.9 26.5
LO PR 115 122 133 142 121 129 141 150 126 134 146 156 132 141 154 164 139 148 161 172 144 153 167 178
Delta T24232219242422192424221923 24 22 192222221920212118
AMPS 7.88.08.28.58.48.68.99.29.19.39.69.99.7 9.9 10.210.610.310.510.811.210.911.111.511.9
HI PR 244 263 278 290 274 295 312 325 312 336 354 370 355 382 404 421 400 43 0 4 54 474 442 475 502 52 3
S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.73 1.00 1.00 0.91 0.74
MBh 26.3 26.8 28.0 29.9 25.7 26.1 27.4 29.2 25.0 25.5 26.7 28.5 24.4 24.9 26.1 27.8 23.2 23.7 24.8 26.4 21.5 21.9 23.0 24.5
LO PR 114 121 132 141 120 128 139 149 125 133 145 154 131 139 152 162 137 146 160 170 142 151 165 176
Delta T24242219242423202424232024 24 23 202324221921222118
AMPS 7.67.88.08.38.28.48.68.98.99.19.39.79.4 9.6 10.010.310.010.210.610.910.610.811.211.6
HI PR 237 255 269 281 266 286 302 315 303 326 344 359 345 371 392 408 388 41 7 4 41 459 428 461 487 50 8
LO PR 110 117 128 136 116 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 171
16
Design Subcooling, 10 ± 2 °F @ the liquid ac cess fitting connection ARI 95 test conditions . Design Superheat 10 ± 2 °F @ the c ompr essor suction access fitt in g co n n ection.
MODE L: GPC 1430H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
1180 KW 1.89 1.93 2.00 2.07 2.04 2.09 2.16 2.23 2.18 2.23 2.30 2.38 2.30 2.35 2.43 2.52 2.40 2.46 2.54 2.63 2.49 2.55 2.63 2.73
80 1050 KW 1.88 1.92 1.98 2.05 2.03 2.07 2.14 2.22 2.16 2.21 2.29 2.36 2.28 2.33
920 KW 1.83 1.87 1.93 2.00 1.98 2.02 2.09 2.16 2.11 2.15 2.23 2.30 2.22 2.27 2.35 2.43 2.32 2.37 2.45 2.54 2.40 2.46 2.54 2.63
1180 KW 1.91 1.95 2.01 2.08 2.06 2.11 2.18 2.25 2.20 2.25 2.32 2.41 2.32 2.37 2.45 2.54 2.42 2.48 2.56 2.65 2.51 2.57 2.66 2.75
85 1050 KW 1.89 1.93 2.00 2.07 2.04 2.09 2.16 2.23 2.18 2.23 2.30 2.38 2.30 2.35 2.43 2.52 2.40 2.46 2.54 2.63 2.49 2.55 2.63 2.73
920 KW 1.84 1.89 1.95 2.01 1.99 2.04 2.11 2.18 2.12 2.17 2.25 2.32 2.24 2.29 2.37 2.45 2.34 2.39 2.47 2.56 2.42 2.48 2.56 2.65
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* N OTE: Shaded are a i s AHR I Rating Cond iti ons ID B: Entering In door Dry B ul b T emperat ure KW = Total system power
COOLING PERFORMANCE DA TA GPC1436H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
16 11 21 19 16 11 20 18 15 10
397 414 393 423 447 466 435 468 494 515
36.8 39.5 31.4 32.3 34.9 37.5 29.0 29.9 32.4 34.7
0.64 0.41 0.99 0.88 0.67 0.43 0.99 0.89 0.67 0.43
20
34.0
0.85
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
145 155 131 140 152 162 136 144 158 168
3.00 3.10 2.96 3.03 3.13 3.24 3.06 3.13 3.24 3.35
13.5 14.0 13.6 13.9 14.3 14.8 14.3 14.6 15.1 15.6
376
133
2.90
13.2
17 12 22 20 17 11 20 19 15 11
393 410 389 419 443 462 430 463 489 510
35.7 38.3 30.4 31.3 33.9 36.4 28.2 29.0 31.4 33.7
0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
20
33.0
0.81
144 153 130 138 151 161 134 143 156 166
2.97 3.07 2.93 3.00 3.10 3.21 3.04 3.11 3.21 3.32
13.4 13.9 13.5 13.8 14.2 14.7 14.2 14.5 14.9 15.4
373
132
2.88
13.1
17 12 22 21 17 12 21 19 16 11
382 398 378 407 429 448 417 449 474 495
33.0 35.4 28.1 28.9 31.3 33.6 26.0 26.8 29.0 31.1
0.59 0.38 0.91 0.81 0.61 0.39 0.91 0.82 0.62 0.40
21
30.4
0.78
140 149 126 134 146 156 130 139 151 161
2.90 2.99 2.86 2.92 3.02 3.12 2.96 3.03 3.13 3.24
13.1 13.5 13.2 13.4 13.8 14.3 13.8 14.1 14.6 15.0
361
128
2.80
12.7
65 75 85 95 105 115
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0 .87 0.72 0.50 - 0.87 0.73 0.51 -
MBh 34.9 36.2 39.6 - 34.1 35.3 38.7 - 33.3 34 .5 37.8 - 32.5 33.6 36.9 - 30.8 32.0 35.0 - 28.6 29.6 32.4 -
Design Subcooling, 10 ±2 °F @ the liquid a ccess fitting connection ARI 95 test conditions. Design Superheat 9 ± 2 °F @ the compre ssor suct ion access fitting connection.
MODE L: GPC 1436H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T181612 - 181612 - 181612 - 18 16 12 - 181612 - 171511 -
AMPS 10.5 10.8 11.0 - 11.3 11.5 11.8 - 12.1 12.3 12.7 - 12.8 13.1 13.4 - 13.5 13.8 14.2 - 14.2 14.5 14.9 -
HI PR 238 256 271 - 267 288 30 4 - 304 327 345 - 346 372 393 - 389 419 442 - 430 463 489 -
1349 KW 2.33 2.38 2.45 - 2.51 2.57 2.65 - 2.67 2.73 2.82 - 2.81 2.88 2.97 - 2.93 3.00 3.10 - 3.04 3.11 3.21 -
S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0 .83 0.69 0.48 - 0.83 0.70 0.48 -
MBh 33.9 35.1 38.5 - 33.1 34.3 37.6 - 32.3 33 .5 36.7 - 31.5 32.7 35.8 - 29.9 31.0 34.0 - 27.7 28.7 31.5 -
LO PR 107 114 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 138 151 - 134 143 156 -
Delta T191612 - 191713 - 191713 - 19 17 13 - 191612 - 181512 -
AMPS 10.5 10.7 11.0 - 11.2 11.4 11.7 - 12.0 12.2 12.6 - 12.7 12.9 13.3 - 13.4 13.7 14.1 - 14.1 14.4 14.8 -
HI PR 236 254 268 - 265 285 30 1 - 301 324 342 - 343 369 389 - 386 415 438 - 426 458 484 -
70 1200 KW 2.31 2.36 2.43 - 2.49 2.54 2.63 - 2.65 2.71 2.80 - 2.79 2.85 2.95 - 2.91 2.97 3.07 - 3.01 3.08 3.18 -
S/T 0.70 0.58 0.41 - 0.73 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0 .80 0.67 0.46 - 0.80 0.67 0.47 -
MBh 31.3 32.4 35.5 - 30.5 31.6 34.7 - 29.8 30 .9 33.8 - 29.1 30.1 33.0 - 27.6 28.6 31.4 - 25.6 26.5 29.1 -
LO PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 143 - 129 137 149 - 133 142 155 -
Delta T191713 - 191713 - 191713 - 20 17 13 - 191713 - 181612 -
1052 KW 2.25 2.30 2.37 - 2.43 2.48 2.56 - 2.58 2.64 2.73 - 2.72 2.78 2.87 - 2.84 2.90 3.00 - 2.94 3.00 3.10 -
AMPS 10.2 10.4 10.7 - 10.9 11.1 11.4 - 11.7 11.9 12.3 - 12.4 12.6 13.0 - 13.1 13.3 13.7 - 13.7 14.0 14.4 -
HI PR 229 246 260 - 257 276 29 2 - 292 314 332 - 332 358 378 - 374 402 425 - 413 445 470 -
LO PR 103 110 120 - 109 116 127 - 113 121 132 - 119 127 138 - 125 133 145 - 129 137 150 -
S/T 0.87 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95
MBh 35.5 36.5 39.5 42.4 34.7 35.7 38.6 41.4 33.8 34.8 37.7 40.5 33.0
Delta T21191611212016112120161121
1349 KW 2.35 2.40 2.47 2.56 2.53 2.59 2.67 2.76 2.69 2.75 2.84 2.94 2.84
AMPS 10.6 10.8 11.1 11.5 11.3 11.6 11.9 12.3 12.2 12.4 12.8 1 3.2 12.9
HI PR 241 2 59 2 73 2 85 270 290 307 3 20 3 0 7 330 349 364 350
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.78 0.59 0.38 0.91
MBh 34.4 35.5 38.4 41.2 33.6 34.6 37.5 40.2 32.8 33.8 36.6 39.3 32.0
LO PR 109 116 126 134 115 122 133 142 119 127 138 147 125
Delta T22201611222017112220171122
75 1200 KW 2.33 2.38 2.45 2.54 2.51 2.57 2.65 2.74 2.67 2.73 2.82 2.92 2.81
AMPS 10.5 10.8 11.0 11.4 11.3 11.5 11.8 12.2 12.1 12.3 12.7 1 3.1 12.8
HI PR 238 2 56 2 71 2 82 267 288 304 3 17 3 0 4 327 345 360 346
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.87
MBh 31.8 32.7 35.4 38.0 31.1 32.0 34.6 37.1 30.3 31.2 33.8 36.3 29.6
LO PR 107 114 125 133 114 121 132 140 118 126 137 146 124
Delta T22201712222117122221171223
1052 KW 2.27 2.32 2.39 2.47 2.45 2.50 2.58 2.67 2.60 2.66 2.75 2.84 2.74
AMPS 10.3 10.5 10.8 11.1 11.0 11.2 11.5 11.9 11.8 12.0 12.4 1 2.8 12.5
HI PR 231 2 49 2 63 2 74 259 279 295 3 07 2 9 5 317 335 349 336
LO PR 104 111 121 129 110 117 128 136 114 122 133 142 120
* IDB: Entering Indoor Dry Bulb Temperature NOTE: Shaded area i s ACCA (TVA) cond itions
High and low pr es sures are measur ed at the liquid and suction access fittings.
17
COOLING PERFORMANCE DA TA GPC1436H41A*
COOLING OPERATION
17 24 23 20 16 22 22 19 15
414 393 423 447 466 435 468 494 515
3.10 2.96 3.03 3.13 3.24 3.06 3.13 3.24 3.35
3.00
155 131 140 152 162 136 144 158 168
14.0 13.6 13.9 14.3 14.8 14.3 14.6 15.1 15.6
397
145
13.5
38.1 31.0 31.7 33.8 36.2 28.7 29.3 31.3 33.5
0.57 1.00 0.97 0.79 0.59 1.00 0.97 0.79 0.59
21
35.6
0.76
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.59 1.00 1.00 0.83 0.62 1.00 1.00 0.83 0.62
MBh 36.1 36.9 39.4 42.1 35.3 36.0 38.5 41.2 34.4 35.2 37.6 40.2 33.6 34.3 36.7 39.2 31.9 32.6 34.8 37.2 29.6 30.2 32.3 34.5
Delta T23221916242320162323201623 23 20 162222201620211815
AMPS 10.7 10.9 11.2 11.6 11.4 11.7 12.0 12.4 12.3 12.5 12.9 13.3 13.0 13.3 13.6 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.2 15.7
HI PR 243 261 276 288 273 293 310 323 310 334 352 368 353 380 401 419 397 42 8 4 51 471 439 472 499 52 0
S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.73 0.55 0.99 0.93
MBh 35.1 35.8 38.3 40.9 34.2 35.0 37.4 40.0 33.4 34.2 36.5 39.0 32.6 33.3
LO PR 110 117 127 136 116 123 135 143 120 128 140 149 126 135 147 156 133 141 154 164 137 146 159 170
Delta T24232016252421162524211625 24
AMPS 10.6 10.8 11.1 11 .5 11.3 1 1.6 11.9 12.3 12.2 12.4 12.8 13.2 12.9 13.2
HI PR 241 2 59 2 73 2 85 270 290 307 3 20 3 0 7 330 349 364 350 376
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.77 0.57
MBh 32.4 33.1 35.3 37.8 31.6 32.3 34.5 36.9 30.9 31.5 33.7 36.0 30.1 30.8 32.9 35.1 28.6 29.2 31.2 33.4 26.5 27.1 28.9 30.9
LO PR 109 116 126 134 115 122 133 142 119 127 138 147 125 133
Delta T25242116252421172524211725 24 21 172524211723221915
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 1.00 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81
AMPS 10.4 10.6 10.9 11.2 11.1 11.3 11.6 12.0 11.9 12.1 12.5 12.9 12.6 12.8 13.2 13.6 13.3 13.6 14.0 14.4 14.0 14.3 14.7 15.2
HI PR 233 251 265 277 262 282 298 310 298 320 338 353 339 365 385 402 382 41 1 4 34 452 422 454 479 50 0
MBh 36.7 37.4 39.2 41.8 35.9 36.6 38.3 40.9 35.0 35.7 37.4 39.9 34.2 34.8 36.5 38.9 32.5 33.1 34.7 37.0 30.1 30.7 32.1 34.3
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
Delta T25252320242523202424232023 24 24 202223232021212219
AMPS 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.5 12.4 12.6 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.9 15.3 15.8
HI PR 245 264 279 291 275 296 313 326 313 337 356 371 357 384 405 423 401 43 2 4 56 476 443 477 504 52 5
S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.70 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
MBh 35.7 36.4 38.1 40.6 34.8 35.5 37.2 39.7 34.0 34.7 36.3 38.7 33.2 33.8 35.4 37.8 31.5 32.1 33.7 35.9 29.2 29.8 31.2 33.3
LO PR 111 118 129 137 117 124 136 145 122 129 141 150 128 136 148 158 134 142 155 166 138 147 161 171
Delta T26262421262624212626242125 26 25 212425242122232320
AMPS 10.7 10.9 11.2 11.6 11.4 11.7 12.0 12.4 12.3 12.5 12.9 13.3 13.0 13.3 13.6 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.2 15.7
HI PR 243 261 276 288 273 293 310 323 310 334 352 368 353 380 401 419 397 42 8 4 51 471 439 472 499 52 0
S/T 0.92 0.88 0.80 0.65 0.95 0.92 0.83 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74
MBh 32.9 33.6 35.1 37.5 32.2 32.8 34.3 36.6 31.4 32.0 33.5 35.8 30.6 31.2 32.7 34.9 29.1 29.7 31.1 33.1 26.9 27.5 28.8 30.7
LO PR 110 117 127 136 116 123 135 143 120 128 140 149 126 135 147 156 133 141 154 164 137 146 159 170
Delta T26262421272625212726252127 26 25 222526252124242320
AMPS 10.5 10.7 11.0 11.3 11.2 11.4 11.7 12.1 12.0 12.2 12.6 13.0 12.7 12.9 13.3 13.8 13.4 13.7 14.1 14.5 14.1 14.4 14.8 15.3
HI PR 236 254 268 279 264 285 301 313 301 324 342 356 343 369 389 406 385 41 5 4 38 457 426 458 484 50 5
LO PR 106 113 124 132 112 120 131 139 117 124 136 144 123 131 142 152 129 137 149 159 133 141 154 165
18
Design Subcooling, 10 ±2 °F @ the liquid a ccess fitting connection ARI 95 test conditions. Design Superheat 9 ±2 °F @ the compre sso r suction access fitting conn ection .
MODE L: GPC 1436H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
1349 KW 2.37 2.42 2.50 2.58 2.55 2.61 2.69 2.78 2.72 2.78 2.87 2.97 2.86 2.93 3.02 3.13 2.98 3.05 3.15 3.26 3.09 3.16 3.27 3.38
80 1200 KW 2.35 2.40 2.48 2.56 2.53 2.59 2.67 2.76 2.69 2.75 2.84 2.94 2.84 2.90
1052 KW 2.29 2.34 2.41 2.49 2.47 2.52 2.60 2.69 2.63 2.68 2.77 2.87 2.77 2.83 2.92 3.02 2.88 2.95 3.05 3.15 2.99 3.05 3.16 3.26
1349 KW 2.39 2.44 2.52 2.60 2.57 2.63 2.72 2.81 2.74 2.80 2.89 2.99 2.89 2.95 3.05 3.15 3.01 3.08 3.18 3.29 3.12 3.19 3.30 3.41
85 1200 KW 2.37 2.42 2.50 2.58 2.55 2.61 2.69 2.78 2.72 2.78 2.87 2.97 2.86 2.93 3.02 3.13 2.98 3.05 3.15 3.26 3.09 3.16 3.27 3.38
1052 KW 2.31 2.36 2.43 2.51 2.49 2.54 2.63 2.71 2.65 2.71 2.80 2.89 2.79 2.85 2.95 3.05 2.91 2.97 3.07 3.18 3.01 3.08 3.18 3.29
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* NOTE: Shaded areas is AHR I Rat ing Condi tions IDB: Enter ing Indoor Dry Bu lb Temperatu re KW = Total system power
COOLING PERFORMANCE DA TA GPC1442H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
17 12 22 20 16 11 20 19 15 11
394 411 390 420 443 462 431 464 490 511
41.8 44.9 35.7 36.7 39.7 42.7 33.0 34.0 36.8 39.5
0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.66 0.43
20
38.7
0.84
Outdoor Ambient Temperature
Entering Indoor Wet Bulb Te mperature
148 158 134 142 155 165 138 147 161 171
3.28 3.39 3.23 3.31 3.42 3.54 3.35 3.43 3.54 3.66
15.0 15.5 15.1 15.4 15.8 16.4 15.9 16.2 16.7 17.3
373
136
3.17
14.5
17 12 23 21 17 12 21 20 16 11
390 407 386 415 439 458 427 459 485 506
40.6 43.6 34.6 35.7 38.6 41.4 32.1 33.0 35.7 38.4
0.60 0.39 0.93 0.83 0.63 0.40 0.93 0.84 0.63 0.41
21
37.5
0.80
147 156 132 141 154 164 137 146 159 169
3.25 3.36 3.21 3.28 3.39 3.51 3.32 3.40 3.51 3.63
14.9 15.4 14.9 15.3 15.7 16.3 15.7 16.1 16.6 17.1
369
134
3.14
14.4
18 12 23 21 17 12 22 20 16 11
378 394 374 403 425 444 414 445 470 490
37.5 40.2 32.0 32.9 35.6 38.2 29.6 30.5 33.0 35.4
0.58 0.38 0.89 0.80 0.61 0.39 0.90 0.81 0.61 0.39
22
34.6
0.77
142 152 128 137 149 159 133 141 154 164
3.17 3.27 3.13 3.20 3.30 3.42 3.24 3.31 3.42 3.54
14.5 15.0 14.6 14.9 15.3 15.8 15.3 15.7 16.1 16.7
358
130
3.06
14.1
65 75 85 95 105 115
S/T 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.86 0.71 0.49 - 0.86 0.72 0.50 -
MBh 39.7 41.1 45.1 - 38.8 40.2 44.0 - 37.8 39.2 43.0 - 36.9 38.3 41.9 - 35.1 36.4 39.8 - 32.5 33.7 36.9 -
Desi gn Subcooling, 8 ± 2 °F @ the liq uid acc ess fitting connecti on AHRI 95 test conditions. Design Super hea t 8 ± 2 °F @ the compressor suction access fi t t ing c onn ection .
MODEL: GPC1442H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T 191612 - 191612 - 191612 - 19 17 13 - 191612 - 181512 -
AMPS 11.6 11.8 12.1 - 12.4 12.6 13.0 - 13.3 13.6 14.0 - 14.1 14.4 14.9 - 14.9 15.3 15.7 - 15.7 16.1 16.6 -
HI PR 236 254 268 - 265 285 301 - 301 324 342 - 343 369 390 - 386 415 4 39 - 426 459 48 5 -
1461 KW 2.54 2.60 2.68 - 2.74 2.80 2.89 - 2.92 2.98 3.08 - 3.07 3.14 3.25 - 3.21 3.28 3.39 - 3.32 3.40 3.51 -
S/T 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.45 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
MBh 38.5 39.9 43.8 - 37.6 39.0 42.7 - 36.7 38.1 41.7 - 35.8 37.1 40.7 - 34.1 35.3 38.7 - 31.5 32.7 35.8 -
LO PR 110 116 127 - 116 123 134 - 120 128 140 - 126 134 147 - 132 141 154 - 137 146 159 -
Delta T 201713 - 201713 - 201713 - 20 17 13 - 201713 - 181612 -
AMPS 11.5 11.7 12.0 - 12.3 12.5 12.9 - 13.2 13.5 13.9 - 14.0 14.3 14.7 - 14.8 15.1 15.6 - 15.6 15.9 16.4 -
HI PR 234 251 266 - 262 282 298 - 298 321 339 - 340 366 386 - 382 411 4 34 - 422 454 48 0 -
70 1300 KW 2.52 2.58 2.66 - 2.72 2.78 2.87 - 2.89 2.96 3.06 - 3.05 3.12 3.22 - 3.18 3.25 3.36 - 3.29 3.37 3.48 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.79 0.66 0.46 -
MBh 35.6 36.9 40.4 - 34.7 36.0 39.4 - 33.9 35.1 38.5 - 33.1 34.3 37.6 - 31.4 32.6 35.7 - 29.1 30.2 33.1 -
LO PR 108 115 126 - 115 122 133 - 119 127 138 - 125 133 145 - 131 139 152 - 136 144 157 -
Delta T 201713 - 201713 - 201713 - 20 18 13 - 201713 - 191612 -
1139 KW 2.46 2.51 2.59 - 2.65 2.71 2.80 - 2.82 2.88 2.98 - 2.97 3.04 3.14 - 3.10 3.17 3.27 - 3.21 3.28 3.39 -
AMPS 11.2 11.4 11.8 - 12.0 12.2 12.6 - 12.9 13.2 13.5 - 13.7 14.0 14.4 - 14.4 14.8 15.2 - 15.2 15.5 16.0 -
HI PR 227 244 258 - 254 274 289 - 289 311 329 - 329 355 374 - 371 399 4 21 - 410 441 46 5 -
LO PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 148 - 131 140 153 -
S/T 0.850.760.580.370.880.790.600.390.910.810.610.400.94
MBh 40.4 41.6 45.0 48.3 39.4 40.6 43.9 47.2 38.5 39.6 42.9 46.0 37.5
Delta T 22201611222017112220171122
1461 KW 2.562.622.702.792.772.832.923.022.943.013.113.213.10
AMPS 11.7 11.9 12.2 12.6 12.5 12.7 13.1 13.5 13.4 13.7 14.1 14.6 14.2
HI PR 238 257 271 283 268 288 304 317 3 04 327 346 36 1 34 7
S/T 0.810.730.550.350.840.750.570.370.870.770.590.380.89
MBh 39.2 40.3 43.7 46.9 38.3 39.4 42.7 45.8 37.4 38.5 41.6 44.7 36.5
LO PR 111 118 128 137 117 124 136 145 121 129 141 150 128
Delta T 23211712232117122321171223
75 1300 KW 2.542.602.682.772.742.802.892.992.922.983.083.193.07
AMPS 11.6 11.8 12.1 12.5 12.4 12.6 13.0 13.4 13.3 13.6 14.0 14.5 14.1
HI PR 236 254 268 280 265 285 301 314 3 01 324 342 35 7 34 3
S/T 0.790.700.530.340.810.730.550.350.830.750.560.360.86
MBh 36.2 37.2 40.3 43.3 35.3 36.4 39.4 42.3 34.5 35.5 38.4 41.2 33.6
LO PR 110 117 127 135 116 123 134 143 120 128 140 149 126
Delta T 23211712232118122321181223
1139 KW 2.482.532.622.702.672.732.822.922.852.913.003.113.00
AMPS 11.3 11.5 11.9 12.2 12.1 12.3 12.7 13.1 13.0 13.3 13.7 14.1 13.8
HI PR 229 246 260 271 257 277 292 305 2 92 314 332 34 6 33 3
LO PR 106 113 123 131 112 119 130 139 117 124 135 144 123
* IDB: Entering Indo or D r y Bulb Temperature NOTE: Shaded area is ACC A (T VA) c onditions
High and low pre ssures are measured at the liquid and suction access fittings.
19
COOLING PERFORMANCE DA TA GPC1442H41A*
COOLING OPERATION
17 25 24 21 17 23 23 20 16
411 390 420 443 462 431 464 490 511
3.39 3.23 3.31 3.42 3.54 3.35 3.43 3.54 3.67
3.28
158 134 142 155 165 138 147 161 171
15.5 15.1 15.4 15.8 16.4 15.9 16.2 16.7 17.3
394
148
15.0
43.3 35.2 36.0 38.5 41.1 32.6 33.4 35.6 38.1
0.56 1.00 0.95 0.78 0.58 1.00 0.96 0.78 0.59
21
40.5
0.75
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.94 0.88 0.71 0.53 0.97 0.91 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.59 1.00 1.00 0.81 0.61 1.00 1.00 0.82 0.61
MBh 41.1 42.0 44.8 47.9 40.1 41.0 43.8 46.8 39.2 40.0 42.8 45.7 38.2 39.0 41.7 44.6 36.3 37.1 39.6 42.4 33.6 34.4 36.7 39.2
Delta T24232016252320162524201624 24 21 162323201621221915
AMPS 11.8 12.0 12.3 12.7 12.6 12.8 13.2 13.6 13.5 13.8 14.2 14.7 14.4 14.7 15.1 15.6 15.2 15.5 16.0 16.5 16.0 16.3 16.8 17.4
HI PR 241 259 274 285 270 291 307 320 307 331 349 364 350 377 398 415 394 42 4 4 48 467 435 468 494 51 6
S/T 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.72 0.54 0.98 0.92
MBh 39.9 40.8 43.5 46.5 39.0 39.8 42.5 45.5 38.0 38.9 41.5 44.4 37.1 37.9
LO PR 112 119 130 138 118 126 137 146 123 131 142 152 129 137 150 159 135 144 157 167 140 149 162 173
Delta T25242117252421172624211726 25
AMPS 11.7 11.9 12.2 12 .6 12.5 1 2.7 13.1 13.5 13.4 13.7 14.1 14.6 14.2 14.5
HI PR 238 2 57 2 71 2 83 268 288 304 3 17 3 0 4 327 346 361 347 373
S/T 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.75 0.56
MBh 36.8 37.6 40.2 43.0 36.0 36.7 39.3 42.0 35.1 35.9 38.3 41.0 34.2 35.0 37.4 40.0 32.5 33.2 35.5 38.0 30.1 30.8 32.9 35.2
LO PR 111 118 128 137 117 124 136 145 121 129 141 150 128 136
Delta T26252117262522172625221726 25 22 172625211724232016
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.79 1.00 1.00 0.98 0.80
AMPS 11.4 11.6 12.0 12.3 12.2 12.4 12.8 13.2 13.1 13.4 13.8 14.2 13.9 14.2 14.6 15.1 14.7 15.0 15.4 16.0 15.5 15.8 16.3 16.8
HI PR 231 249 263 274 260 279 295 308 295 318 335 350 336 362 382 398 378 40 7 4 30 448 418 450 475 49 5
MBh 41.8 42.6 44.6 47.6 40.8 41.6 43.6 46.5 39.9 40.6 42.5 45.4 38.9 39.6 41.5 44.3 36.9 37.6 39.4 42.1 34.2 34.9 36.5 39.0
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 160 134 143 156 166
Delta T26252421262624212526242124 25 24 212324242122222320
AMPS 11.8 12.1 12.4 12.8 12.7 12.9 13.3 13.8 13.6 13.9 14.3 14.8 14.5 14.8 15.2 15.7 15.3 15.6 16.1 16.7 16.1 16.5 17.0 17.6
HI PR 243 262 276 288 273 294 310 324 310 334 353 368 354 380 402 419 398 42 8 4 52 471 439 473 499 52 1
S/T 0.94 0.90 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.94 0.76
MBh 40.6 41.4 43.3 46.2 39.6 40.4 42.3 45.1 38.7 39.4 41.3 44.1 37.7 38.5 40.3 43.0 35.9 36.6 38.3 40.8 33.2 33.9 35.5 37.8
LO PR 113 120 131 140 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 175
Delta T27262522272725222727252227 27 25 222526252223242320
AMPS 11.8 12.0 12.3 12.7 12.6 12.8 13.2 13.6 13.5 13.8 14.2 14.7 14.4 14.7 15.1 15.6 15.2 15.5 16.0 16.5 16.0 16.3 16.8 17.4
HI PR 241 259 274 285 270 291 307 320 307 331 349 364 350 377 398 415 394 42 4 4 48 467 435 468 494 51 6
S/T 0.90 0.87 0.79 0.64 0.94 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.90 0.73
MBh 37.5 38.2 40.0 42.7 36.6 37.3 39.1 41.7 35.7 36.4 38.1 40.7 34.8 35.5 37.2 39.7 33.1 33.7 35.3 37.7 30.7 31.3 32.7 34.9
LO PR 112 119 130 138 118 126 137 146 123 131 142 152 129 137 150 159 135 144 157 167 140 149 162 173
Delta T27272522282726222827262228 27 26 222727262225252421
AMPS 11.5 11.7 12.0 12.4 12.3 12.5 12.9 13.3 13.2 13.5 13.9 14.3 14.0 14.3 14.7 15.2 14.8 15.1 15.6 16.1 15.6 15.9 16.4 17.0
HI PR 234 251 265 277 262 282 298 311 298 321 339 353 340 365 386 402 382 41 1 4 34 453 422 454 480 50 0
LO PR 108 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 139 152 162 136 144 157 168
20
Design Subcooling, 8 ± 2 °F @ the liquid access fitting conn ection AHRI 95 test con ditions. Design Superheat 8 ± 2 ° F @ the co mpressor suction access fi tting connection.
MODE L: GPC 1442H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
1461 KW 2.58 2.64 2.73 2.82 2.79 2.85 2.94 3.04 2.97 3.03 3.14 3.24 3.13 3.20 3.30 3.42 3.26 3.34 3.45 3.57 3.38 3.46 3.57 3.70
80 1300 KW 2.56 2.62 2.70 2.79 2.77 2.83 2.92 3.02 2.94 3.01 3.11 3.21 3.10 3.17
1139 KW 2.50 2.56 2.64 2.72 2.70 2.76 2.85 2.94 2.87 2.93 3.03 3.13 3.02 3.09 3.19 3.30 3.15 3.22 3.33 3.45 3.26 3.34 3.45 3.57
1461 KW 2.61 2.66 2.75 2.84 2.81 2.87 2.97 3.07 2.99 3.06 3.16 3.27 3.15 3.22 3.33 3.45 3.29 3.36 3.48 3.60 3.41 3.49 3.60 3.73
85 1300 KW 2.58 2.64 2.73 2.82 2.79 2.85 2.94 3.04 2.97 3.03 3.14 3.24 3.13 3.20 3.30 3.42 3.26 3.34 3.45 3.57 3.38 3.46 3.57 3.70
1139 KW 2.52 2.58 2.66 2.75 2.72 2.78 2.87 2.97 2.89 2.96 3.06 3.16 3.05 3.12 3.22 3.33 3.18 3.25 3.36 3.48 3.29 3.37 3.48 3.60
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* NOTE: Shaded areas is AHR I Rat ing Condi tions IDB: Enter ing Indoor Dry Bu lb Temperatu re KW = Total system power
COOLING PERFORMANCE DA TA GPC1448H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
16 11 21 19 16 11 19 18 15 10
393 410 389 419 442 461 430 463 489 510
48.0 51.6 41.0 42.2 45.6 49.0 37.9 39.1 42.3 45.4
0.64 0.41 0.99 0.88 0.67 0.43 1.00 0.89 0.67 0.43
19
44.4
0.85
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
149 159 135 143 157 167 139 148 162 173
3.78 3.90 3.73 3.81 3.94 4.07 3.86 3.95 4.08 4.22
16.6 17.2 16.7 17.1 17.6 18.2 17.6 18.0 18.6 19.2
372
137
3.66
16.1
16 11 22 20 16 11 20 18 15 10
389 406 385 415 438 457 426 458 484 505
46.6 50.1 39.8 40.9 44.3 47.6 36.8 37.9 41.0 44.0
0.61 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
20
43.1
0.81
148 158 134 142 155 165 138 147 160 171
3.75 3.87 3.70 3.78 3.91 4.04 3.83 3.91 4.05 4.18
16.5 17.0 16.6 16.9 17.4 18.1 17.5 17.9 18.4 19.1
369
136
3.63
16.0
17 12 22 20 17 11 20 19 15 11
378 394 374 402 425 443 413 444 469 489
43.0 46.2 36.7 37.8 40.9 43.9 34.0 35.0 37.9 40.7
0.59 0.38 0.91 0.81 0.61 0.40 0.92 0.82 0.62 0.40
20
39.8
0.78
144 153 129 138 150 160 134 143 156 166
3.65 3.77 3.61 3.69 3.81 3.94 3.73 3.81 3.94 4.08
16.1 16.6 16.1 16.5 17.0 17.6 17.0 17.4 17.9 18.6
358
131
3.54
15.6
65 75 85 95 105 115
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0 .87 0.73 0.50 - 0.88 0.73 0.51 -
MBh 45.6 47.2 51.7 - 44.5 46.1 50.5 - 43.4 45 .0 49.3 - 42.4 43.9 48.1 - 40.3 41.7 45.7 - 37.3 38.7 42.4 -
Design Subcooling, 10 ± 2 °F @ the liquid access fitting connection AHRI 95 test condi tions. Design Superheat 10 ± 2 °F @ the compre ssor suction access fitting connection.
MODE L: GPC 1448H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T181512 - 181612 - 181612 - 18 16 12 - 181512 - 171411 -
AMPS 12.7 13.0 13.4 - 13.7 14.0 14.4 - 14.7 15.0 15.5 - 15.6 16.0 16.5 - 16.6 16.9 17.4 - 17.5 17.9 18.4 -
HI PR 236 254 268 - 264 284 30 0 - 301 324 342 - 342 369 389 - 385 415 438 - 426 458 484 -
1800 KW 2.94 3.01 3.10 - 3.17 3.24 3.34 - 3.37 3.44 3.56 - 3.55 3.63 3.75 - 3.70 3.78 3.91 - 3.83 3.91 4.04 -
S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0 .83 0.69 0.48 - 0.84 0.70 0.48 -
MBh 44.2 45.9 50.2 - 43.2 44.8 49.1 - 42.2 43 .7 47.9 - 41.2 42.7 46.7 - 39.1 40.5 44.4 - 36.2 37.5 41.1 -
LO PR 110 117 128 - 117 124 135 - 121 129 141 - 127 135 148 - 133 142 155 - 138 147 160 -
Delta T181612 - 191612 - 191612 - 19 16 12 - 191612 - 171511 -
AMPS 12.6 12.9 13.3 - 13.6 13.8 14.3 - 14.6 14.9 15.4 - 15.5 15.9 16.3 - 16.4 16.8 17.3 - 17.3 17.7 18.2 -
HI PR 233 251 265 - 262 282 29 7 - 298 320 338 - 339 365 385 - 381 410 433 - 421 454 479 -
70 1600 KW 2.92 2.98 3.08 - 3.14 3.21 3.32 - 3.34 3.42 3.53 - 3.52 3.60 3.71 - 3.67 3.75 3.87 - 3.80 3.88 4.01 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0 .80 0.67 0.46 - 0.81 0.67 0.47 -
MBh 40.8 42.3 46.4 - 39.9 41.3 45.3 - 38.9 40 .4 44.2 - 38.0 39.4 43.1 - 36.1 37.4 41.0 - 33.4 34.6 38.0 -
LO PR 109 116 127 - 116 123 134 - 120 128 139 - 126 134 146 - 132 141 153 - 137 145 159 -
Delta T191612 - 191613 - 191613 - 19 17 13 - 191612 - 181512 -
1400 KW 2.85 2.91 3.00 - 3.07 3.13 3.23 - 3.26 3.33 3.44 - 3.43 3.51 3.62 - 3.57 3.65 3.78 - 3.70 3.78 3.91 -
AMPS 12.3 12.6 13.0 - 13.2 13.5 13.9 - 14.2 14.5 15.0 - 15.1 15.5 15.9 - 16.0 16.4 16.9 - 16.9 17.2 17.8 -
HI PR 226 243 257 - 254 273 28 9 - 289 311 328 - 329 354 374 - 370 398 420 - 409 440 465 -
LO PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -
S/T 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95
MBh 46.3 47.7 51.6 55.4 45.3 46.6 50.4 54.1 44.2 45.5 49.2 52.8 43.1
Delta T21191511211916112119161121
1800 KW 2.97 3.03 3.13 3.23 3.20 3.27 3.37 3.48 3.40 3.47 3.59 3.71 3.58
AMPS 12.8 13.1 13.5 14.0 13.8 14.1 14.5 15.0 14.8 15.2 15.6 1 6.2 15.8
HI PR 238 2 56 2 70 2 82 267 287 303 3 17 3 0 4 327 345 360 346
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.59 0.38 0.91
MBh 45.0 46.3 50.1 53.8 43.9 45.2 49.0 52.6 42.9 44.2 47.8 51.3 41.9
LO PR 112 119 130 138 118 125 137 146 122 130 142 152 129
Delta T21201611222016112220161122
75 1600 KW 2.94 3.01 3.10 3.20 3.17 3.24 3.34 3.45 3.37 3.44 3.56 3.68 3.55
AMPS 12.7 13.0 13.4 13.8 13.7 14.0 14.4 14.9 14.7 15.0 15.5 1 6.0 15.6
HI PR 236 2 54 2 68 2 79 264 285 300 3 13 3 0 1 324 342 356 343
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.87
MBh 41.5 42.8 46.3 49.7 40.6 41.8 45.2 48.5 39.6 40.8 44.1 47.4 38.6
LO PR 110 118 128 137 117 124 136 144 121 129 141 150 127
Delta T22201611222017112220171122
1400 KW 2.87 2.93 3.03 3.12 3.09 3.16 3.26 3.37 3.29 3.36 3.47 3.58 3.46
AMPS 12.4 12.7 13.1 13.5 13.3 13.6 14.0 14.5 14.4 14.7 15.1 1 5.6 15.2
HI PR 229 2 46 2 60 2 71 256 276 291 3 04 2 9 2 314 331 346 332
LO PR 107 114 124 133 113 120 131 140 118 125 137 146 124
* IDB: Entering Indoor Dry Bulb Temperature NOTE: Shaded area i s ACCA (TVA) cond itions
High and low pr es sures are measur ed at the liquid and suction access fittings.
21
COOLING PERFORMANCE DA TA GPC1448H41A*
COOLING OPERATION
16 23 23 20 16 22 21 19 15
410 389 419 442 461 430 463 489 510
3.91 3.73 3.81 3.94 4.07 3.86 3.95 4.08 4.22
3.78
159 135 143 157 167 139 148 162 173
17.2 16.7 17.1 17.6 18.2 17.6 18.0 18.6 19.2
393
149
16.6
49.7 40.5 41.3 44.2 47.2 37.5 38.3 40.9 43.7
0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.79 0.59
20
46.5
0.76
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.95 0.89 0.73 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.83 0.62
MBh 47.2 48.2 51.5 55.0 46.1 47.1 50.3 53.8 45.0 46.0 49.1 52.5 43.9 44.8 47.9 51.2 41.7 42.6 45.5 48.6 38.6 39.5 42.1 45.1
Delta T23221915242219152322191522 23 19 162122191520201814
AMPS 13.0 13.2 13.6 14.1 13.9 14.2 14.6 15.1 15.0 15.3 15.8 16.3 15.9 16.3 16.8 17.3 16.8 17.2 17.7 18.4 17.8 18.2 18.7 19.4
HI PR 240 259 273 285 270 290 307 320 307 330 349 364 349 376 397 414 393 42 3 4 47 466 434 467 494 51 5
S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.74 0.55 0.99 0.93
MBh 45.8 46.8 50.0 53.4 44.7 45.7 48.8 52.2 43.7 44.6 47.7 51.0 42.6 43.5
LO PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
Delta T24232016242320162423201624 23
AMPS 12.9 13.1 13.5 14 .0 13.8 1 4.1 14.5 15.0 14.8 15.2 15.6 16.2 15.8 16.1
HI PR 238 2 56 2 70 2 82 267 287 304 3 17 3 0 4 327 345 360 346 372
S/T 0.87 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.94 0.77 0.57
MBh 42.3 43.2 46.1 49.3 41.3 42.2 45.1 48.2 40.3 41.2 44.0 47.0 39.3 40.2 42.9 45.9 37.3 38.2 40.8 43.6 34.6 35.4 37.8 40.4
LO PR 112 119 130 138 118 125 137 146 122 130 142 152 129 137
Delta T24232016252420162524201625 24 21 162423201623221915
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 1.00 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81
AMPS 12.5 12.8 13.2 13.6 13.4 13.7 14.1 14.6 14.5 14.8 15.2 15.8 15.4 15.7 16.2 16.8 16.3 16.6 17.1 17.7 17.2 17.5 18.1 18.7
HI PR 231 248 262 274 259 279 294 307 295 317 335 349 336 361 381 398 378 40 6 4 29 447 417 449 474 49 4
MBh 48.0 48.9 51.2 54.7 46.9 47.8 50.0 53.4 45.8 46.6 48.8 52.1 44.6 45.5 47.7 50.8 42.4 43.2 45.3 48.3 39.3 40.0 41.9 44.7
LO PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
Delta T24242320242423202324232023 23 23 202222232020202118
AMPS 13.1 13.3 13.7 14.2 14.0 14.3 14.7 15.2 15.1 15.4 15.9 16.4 16.0 16.4 16.9 17.5 17.0 17.4 17.9 18.5 17.9 18.3 18.9 19.6
HI PR 243 261 276 288 272 293 310 323 310 333 352 367 353 380 401 418 397 42 7 4 51 471 439 472 499 52 0
S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
MBh 46.6 47.5 49.7 53.1 45.5 46.4 48.6 51.8 44.4 45.3 47.4 50.6 43.3 44.2 46.3 49.4 41.2 42.0 44.0 46.9 38.1 38.9 40.7 43.4
LO PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 152 162 138 146 160 170 142 151 165 176
Delta T25252420262524212625242125 25 24 212424242122222219
AMPS 13.0 13.2 13.6 14.1 13.9 14.2 14.6 15.1 15.0 15.3 15.8 16.3 15.9 16.3 16.8 17.3 16.8 17.2 17.7 18.4 17.8 18.2 18.7 19.4
HI PR 240 259 273 285 270 290 307 320 307 330 349 364 349 376 397 414 393 42 3 4 47 466 434 467 494 51 5
S/T 0.92 0.88 0.80 0.65 0.95 0.92 0.83 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74
MBh 43.0 43.8 45.9 49.0 42.0 42.8 44.8 47.8 41.0 41.8 43.8 46.7 40.0 40.8 42.7 45.6 38.0 38.7 40.6 43.3 35.2 35.9 37.6 40.1
LO PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
Delta T26252421262624212626242126 26 25 212525242123242320
AMPS 12.6 12.9 13.3 13.7 13.5 13.8 14.2 14.7 14.6 14.9 15.4 15.9 15.5 15.8 16.3 16.9 16.4 16.8 17.3 17.9 17.3 17.7 18.2 18.9
HI PR 233 251 265 276 262 282 297 310 298 320 338 353 339 365 385 402 381 41 0 4 33 452 421 453 479 49 9
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 134 146 156 132 141 153 163 137 145 159 169
22
Design Subcooling, 10 ± 2 °F @ the liquid ac cess fitting connection AHRI 95 test conditions. Design Superheat 10 ± 2°F @ the compre ssor suction access fitting connection.
MODE L: GPC 1448H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
1800 KW 2.99 3.05 3.15 3.25 3.22 3.29 3.40 3.51 3.43 3.50 3.62 3.74 3.61 3.69 3.81 3.94 3.76 3.85 3.97 4.11 3.89 3.98 4.11 4.26
80 1600 KW 2.97 3.03 3.13 3.23 3.20 3.27 3.37 3.48 3.40 3.47 3.59 3.71 3.58 3.66
1400 KW 2.90 2.96 3.05 3.15 3.12 3.19 3.29 3.40 3.31 3.39 3.50 3.61 3.49 3.57 3.68 3.81 3.64 3.72 3.84 3.97 3.76 3.85 3.98 4.11
1800 KW 3.01 3.08 3.18 3.28 3.25 3.32 3.43 3.54 3.46 3.53 3.65 3.77 3.64 3.72 3.84 3.97 3.79 3.88 4.01 4.14 3.93 4.02 4.15 4.29
85 1600 KW 2.99 3.05 3.15 3.25 3.22 3.29 3.40 3.51 3.43 3.50 3.62 3.74 3.61 3.69 3.81 3.94 3.76 3.85 3.97 4.11 3.89 3.98 4.11 4.26
1400 KW 2.92 2.98 3.07 3.17 3.14 3.21 3.31 3.42 3.34 3.42 3.53 3.64 3.52 3.60 3.71 3.84 3.67 3.75 3.87 4.00 3.79 3.88 4.01 4.15
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* NOTE: Shaded areas is AHR I Rat ing Condi tions IDB: Enter ing Indoor Dry Bu lb Temperatu re KW = Total system power
COOLING PERFORMANCE DA TA GPC1460H41A*
COOLING OPERATION
EXPANDED PERFORMANCE DATA
18 13 24 22 18 12 22 21 17 12
397 415 393 423 447 466 435 468 494 515
59.4 63.8 50.6 52.1 56.4 60.6 46.9 48.3 52.3 56.1
0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41
22
54.9
0.80
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
146 155 132 140 153 163 136 145 158 168
4.79 4.96 4.73 4.84 5.01 5.18 4.90 5.02 5.19 5.37
20.7 21.4 20.8 21.3 21.9 22.7 21.9 22.5 23.2 24.0
376
134
4.64
20.0
19 13 25 23 19 13 23 21 18 12
394 410 390 419 443 462 430 463 489 510
57.7 61.9 49.2 50.6 54.8 58.8 45.5 46.9 50.8 54.5
0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
23
53.3
0.76
144 154 130 139 151 161 135 143 157 167
4.75 4.92 4.69 4.80 4.96 5.14 4.86 4.97 5.14 5.32
20.5 21.2 20.6 21.1 21.7 22.5 21.7 22.3 23.0 23.8
373
132
4.60
19.9
19 13 25 23 19 13 24 22 18 12
382 398 378 407 429 448 418 449 474 495
53.2 57.1 45.4 46.7 50.6 54.3 42.0 43.3 46.8 50.3
0.55 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.37
24
49.2
0.73
140 149 126 134 147 156 131 139 152 162
4.63 4.79 4.57 4.67 4.83 5.00 4.73 4.84 5.01 5.18
19.9 20.7 20.0 20.5 21.2 21.9 21.2 21.7 22.4 23.2
361
128
4.48
19.3
65 75 85 95 105 115
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0 .81 0.68 0.47 - 0.82 0.69 0.47 -
MBh 56.3 58.4 64.0 - 55.0 57.0 62.5 - 53.7 55 .7 61.0 - 52.4 54.3 59.5 - 49.8 51.6 56.5 - 46.1 47.8 52.4 -
Design Sub coolin g, 6 ± 2 °F @ th e liquid access fitting connecti on AHRI 9 5 test conditions. Design Superheat 9 ± 2°F @ the compressor suction ac cess fitting connection.
MODE L: GPC 1460H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
Delta T211814 - 211814 - 211814 - 21 18 14 - 211814 - 191713 -
AMPS 15.7 16.0 16.5 - 16.9 17.2 17.8 - 18.2 18.6 19.2 - 19.4 19.9 20.5 - 20.6 21.1 21.7 - 21.7 22.3 23.0 -
HI PR 238 256 271 - 267 288 30 4 - 304 327 345 - 346 373 393 - 390 419 443 - 430 463 489 -
1800 KW 3.70 3.78 3.91 - 4.00 4.09 4.23 - 4.26 4.36 4.51 - 4.49 4.60 4.75 - 4.69 4.80 4.96 - 4.86 4.97 5.14 -
S/T 0.68 0.57 0.39 - 0.71 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0 .78 0.65 0.45 - 0.78 0.65 0.45 -
MBh 54.7 56.7 62.1 - 53.4 55.4 60.7 - 52.2 54 .1 59.2 - 50.9 52.7 57.8 - 48.3 50.1 54.9 - 44.8 46.4 50.9 -
LO PR 108 115 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 139 151 - 135 143 156 -
Delta T211914 - 221914 - 221914 - 22 19 14 - 221914 - 201713 -
AMPS 15.6 15.9 16.4 - 16.7 17.1 17.6 - 18.1 18.5 19.1 - 19.2 19.7 20.3 - 20.4 20.9 21.5 - 21.6 22.1 22.8 -
HI PR 236 254 268 - 265 285 30 1 - 301 324 342 - 343 369 390 - 386 415 438 - 426 459 484 -
70 1600 KW 3.67 3.75 3.88 - 3.97 4.06 4.19 - 4.23 4.32 4.47 - 4.46 4.56 4.71 - 4.65 4.76 4.92 - 4.82 4.93 5.10 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0 .75 0.62 0.43 - 0.75 0.63 0.44 -
MBh 50.5 52.3 57.3 - 49.3 51.1 56.0 - 48.1 49 .9 54.7 - 47.0 48.7 53.3 - 44.6 46.2 50.7 - 41.3 42.8 46.9 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 133 142 155 -
Delta T221914 - 221914 - 221915 - 22 19 15 - 221914 - 201813 -
1400 KW 3.58 3.66 3.78 - 3.87 3.95 4.08 - 4.12 4.21 4.35 - 4.34 4.44 4.59 - 4.53 4.63 4.79 - 4.69 4.80 4.97 -
AMPS 15.2 15.5 16.0 - 16.3 16.7 17.2 - 17.6 18.0 18.6 - 18.7 19.2 19.8 - 19.9 20.3 21.0 - 21.0 21.5 22.2 -
HI PR 229 246 260 - 257 276 29 2 - 292 314 332 - 333 358 378 - 374 403 425 - 413 445 470 -
LO PR 103 110 120 - 109 116 127 - 114 121 132 - 119 127 139 - 125 133 145 - 129 138 150 -
S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.38 0.89
MBh 57.3 59.0 63.9 68.5 56.0 57.6 62.4 66.9 54.6 56.3 60.9 65.3 53.3
Delta T24221812242218132422181324
1800 KW 3.73 3.82 3.94 4.07 4.03 4.12 4.26 4.41 4.30 4.40 4.55 4.70 4.53
AMPS 15.8 16.2 16.7 17.2 17.0 17.4 17.9 18.6 18.4 18.8 19.4 2 0.1 19.6
HI PR 241 2 59 2 73 2 85 270 291 307 3 20 3 0 7 330 349 364 350
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.74 0.56 0.36 0.85
MBh 55.6 57.3 62.0 66.5 54.3 55.9 60.6 65.0 53.0 54.6 59.1 63.4 51.8
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126
Delta T25231913252319132523191325
75 1600 KW 3.70 3.79 3.91 4.04 4.00 4.09 4.23 4.37 4.26 4.36 4.51 4.66 4.49
AMPS 15.7 16.0 16.5 17.1 16.9 17.3 17.8 18.4 18.2 18.6 19.2 1 9.9 19.4
HI PR 238 2 56 2 71 2 82 267 288 304 3 17 3 0 4 327 346 360 346
S/T 0.75 0.67 0.51 0.33 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.82
MBh 51.3 52.9 57.2 61.4 50.2 51.6 55.9 60.0 49.0 50.4 54.6 58.6 47.8
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124
Delta T25231913252319132624191326
1400 KW 3.61 3.69 3.81 3.94 3.90 3.99 4.12 4.26 4.15 4.25 4.39 4.54 4.38
AMPS 15.3 15.6 16.1 16.7 16.4 16.8 17.3 17.9 17.8 18.2 18.7 1 9.4 18.9
HI PR 231 2 49 2 63 2 74 259 279 295 3 07 2 9 5 317 335 350 336
LO PR 105 111 121 129 110 118 128 137 115 122 133 142 121
* IDB: Entering Indoor Dry Bulb Temperature NOTE: Shaded area i s ACCA (TVA) cond itions
High and low pr es sures are measur ed at the liquid and suction access fittings.
23
COOLING PERFORMANCE DA TA GPC1460H41A*
COOLING OPERATION
19 28 27 23 19 26 25 22 17
415 394 423 447 466 435 468 494 515
4.96 4.73 4.84 5.01 5.18 4.90 5.02 5.19 5.37
4.80
155 132 140 153 163 136 145 158 168
21.4 20.8 21.3 21.9 22.7 21.9 22.5 23.2 24.0
398
146
20.7
61.5 50.0 51.1 54.6 58.4 46.3 47.4 50.6 54.1
0.53 0.97 0.91 0.74 0.55 0.98 0.91 0.74 0.56
24
57.5
0.71
EXPANDED PERFORMANCE DATA
Outdoor Ambient Temp erature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
S/T 0.89 0.84 0.68 0.51 0.92 0.87 0.70 0.53 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
MBh 58.3 59.6 63.7 68.1 57.0 58.2 62.2 66.5 55.6 56.8 60.7 64.9 54.3 55.4 59.2 63.3 51.5 52.7 56.3 60.1 47.7 48.8 52.1 55.7
Delta T27252218272622182726221828 26 23 182626221824242117
AMPS 16.0 16.3 16.8 17.4 17.2 17.5 18.1 18.7 18.5 19.0 19.6 20.3 19.8 20.2 20.8 21.6 21.0 21.4 22.1 22.9 22.1 22.7 23.4 24.2
HI PR 243 262 276 288 273 294 310 323 310 334 352 368 353 380 401 419 397 42 8 4 52 471 439 473 499 52 0
S/T 0.85 0.80 0.65 0.48 0.88 0.83 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87
MBh 56.6 57.9 61.8 66.1 55.3 56.5 60.4 64.5 54.0 55.2 58.9 63.0 52.7 53.8
LO PR 110 117 128 136 116 124 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 160 170
Delta T28262318282723192827231928 27
AMPS 15.8 16.2 16.7 17 .2 17.0 1 7.4 17.9 18.6 18.4 18.8 19.4 20.1 19.6 20.0
HI PR 241 2 59 2 73 2 85 270 291 307 3 20 3 0 7 331 349 364 350 376
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.48 0.87 0.82 0.66 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.72 0.54
MBh 52.3 53.4 57.1 61.0 51.0 52.2 55.7 59.6 49.8 50.9 54.4 58.2 48.6 49.7 53.1 56.7 46.2 47.2 50.4 53.9 42.8 43.7 46.7 49.9
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134
Delta T28272319282724192827241929 27 24 192827241926252218
NO TE: Shaded area r eflec ts AH RI ra ting condi tions
S/T 0.93 0.90 0.81 0.66 0.97 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.93 0.75 1.00 1.00 0.93 0.76
AMPS 15.4 15.8 16.2 16.8 16.6 17.0 17.5 18.1 17.9 18.3 18.9 19.6 19.1 19.5 20.1 20.8 20.2 20.7 21.3 22.1 21.4 21.9 22.6 23.4
HI PR 233 251 265 277 262 282 298 310 298 321 339 353 339 365 386 402 382 41 1 4 34 452 422 454 479 50 0
MBh 59.3 60.5 63.3 67.6 58.0 59.1 61.9 66.0 56.6 57.7 60.4 64.4 55.2 56.3 58.9 62.9 52.4 53.5 56.0 59.7 48.6 49.5 51.9 55.3
LO PR 106 112 123 131 112 119 130 138 116 123 135 143 122 130 141 151 128 136 148 158 132 140 153 163
Delta T28282623292827232928272328 28 27 232727262325252521
AMPS 16.1 16.5 17.0 17.5 17.3 17.7 18.2 18.9 18.7 19.1 19.7 20.4 19.9 20.4 21.0 21.8 21.1 21.6 22.3 23.1 22.3 22.9 23.6 24.5
HI PR 245 264 279 291 275 296 313 326 313 337 356 371 357 384 405 423 401 43 2 4 56 476 444 477 504 52 6
S/T 0.89 0.86 0.78 0.63 0.92 0.89 0.80 0.65 0.95 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 0.99 0.89 0.72
MBh 57.6 58.7 61.5 65.6 56.3 57.4 60.1 64.1 54.9 56.0 58.6 62.6 53.6 54.6 57.2 61.0 50.9 51.9 54.4 58.0 47.2 48.1 50.3 53.7
LO PR 111 118 129 137 117 125 136 145 122 130 142 151 128 136 149 158 134 143 156 166 139 148 161 172
Delta T29292724302928243029282430 30 28 242929282427272622
AMPS 16.0 16.3 16.8 17.4 17.2 17.5 18.1 18.7 18.5 19.0 19.6 20.3 19.8 20.2 20.8 21.6 21.0 21.4 22.1 22.9 22.1 22.7 23.4 24.2
HI PR 243 262 276 288 273 294 310 323 310 334 352 368 353 380 401 419 397 42 8 4 52 471 439 473 499 52 0
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 0.99 0.95 0.86 0.70
MBh 53.2 54.2 56.8 60.6 51.9 52.9 55.4 59.2 50.7 51.7 54.1 57.7 49.5 50.4 52.8 56.3 47.0 47.9 50.2 53.5 43.5 44.4 46.5 49.6
LO PR 110 117 128 136 116 124 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 160 170
Delta T30302824303028243030282431 30 28 253030282428282623
AMPS 15.6 15.9 16.4 17.0 16.7 17.1 17.6 18.2 18.1 18.5 19.1 19.7 19.2 19.7 20.3 21.0 20.4 20.9 21.5 22.3 21.5 22.1 22.8 23.6
HI PR 236 254 268 279 265 285 301 314 301 324 342 357 343 369 389 406 386 41 5 4 38 457 426 458 484 50 5
LO PR 107 113 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 159 133 142 155 165
24
Design Subcooling, 6 ± 2 °F @ the liquid access fitting conne ction AHRI 95 test conditi ons. Design Superheat 9 ± 2°F @ the compressor suction access fitting connection.
MODE L: GPC 1460H41A*
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
1800 KW 3.77 3.85 3.98 4.11 4.07 4.16 4.30 4.45 4.34 4.43 4.58 4.74 4.57 4.68 4.84 5.00 4.77 4.88 5.05 5.23 4.95 5.06 5.24 5.42
80 1600 KW 3.73 3.82 3.94 4.08 4.03 4.13 4.26 4.41 4.30 4.40 4.55 4.70 4.53 4.64
1400 KW 3.64 3.72 3.84 3.97 3.93 4.02 4.15 4.29 4.19 4.28 4.43 4.58 4.42 4.52 4.67 4.83 4.61 4.71 4.88 5.05 4.78 4.89 5.05 5.23
1800 KW 3.80 3.88 4.01 4.14 4.10 4.20 4.34 4.48 4.37 4.47 4.62 4.78 4.61 4.72 4.88 5.05 4.81 4.93 5.09 5.27 4.99 5.10 5.28 5.47
85 1600 KW 3.77 3.85 3.98 4.11 4.07 4.16 4.30 4.45 4.34 4.43 4.58 4.74 4.57 4.68 4.84 5.00 4.77 4.88 5.05 5.23 4.95 5.06 5.24 5.42
1400 KW 3.67 3.75 3.88 4.01 3.97 4.05 4.19 4.33 4.23 4.32 4.47 4.62 4.45 4.56 4.71 4.87 4.65 4.76 4.92 5.09 4.82 4.93 5.10 5.28
High and low pres sures are meas ur ed at the liquid and suction access fit tings. AMPS: U nit amps (comp.+ ev aporator + condenser fan motors)
* NOTE: Shaded areas is AHR I Rat ing Condi tions IDB: Enter ing Indoor Dry Bu lb Temperatu re KW = Total system power
COOLING PERFORMANCE DA TA
PERFORMANCE TEST
All data based upon listed indoor dry bulb temperature. .00 inches external static pressure on coil of outdoor section. Indoor
air cubic feet per minute (CFM) as listed in the Performance Data Sheets:
If conditions vary from this, results will change as follows:
1. As indoor dry bulb temperatures increase, a slight increase will occur in indoor air temperature drop (Delta T). Low
and high side pressures and power will not change.
2. As indoor CFM decreases, a slight increase will occur in indoor temperature drop (Delta T). A slight decrease will
occur in low and high side pressures and power.
A properly operating unit should be within plus or minus 3 degrees of the typical (Delta T) value shown.
A properly operating unit should be within plus or minus 7 PSIG of the HI PR shown.
A properly operating unit should be within plus or minus 3 PSIG of the LO PR shown.
A properly operating unit should be within plus or minus 3 Amps of the typical value shown.
25
WIRING DIAGRAMS
WARNING
HIGH VOLTAGE!
DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS
UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO
DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
A
GPC14[24-60]H41A*
BK
PU
BL
GR
C L G N
1
SEE NOTE 2
2 3
4 5
WH
EM
PU
BK
YL
SA
(IF USED) SEE NOTE 4
YL
GR
WH
RD
BK
1
2
208
C
24V
BL
YL
RD
BR
H
C
F
RCCF
PU
NOTE #3
T2
T1
GR
RD
RD
CR
PU
BK
L2
C
L1
YL
BR
BL
GR
WH
LVJB
YL
RD
SEE NOTE 5
GND
HPS
Y
R
G
W1
W2
C
++
CONTROL
BOX
2
0
8
2
4
0
/
1
/
60
T
H
E
R
M
O
S
T
T
PU
3
240
BL
RD
GR
WH
WH
BL
PLF
3
9
BR
8
562
41
7
BR
BK
PU
BR
BK
CM
BL
RD
RD
BK
BK
YL
RD
BK
YL
S
COMP
L1
C
NOTE #2
N
1
4
5
6
PLF
SUPPLY VOLTAGE
T1
EM
R
COMP
C
S
S.A.
IF USED
3
G
2
NOTE #4
R W2 W1 Y G C
208-240/1/60
RCCF
H
NOTE #4
L
208-240
3 1
24V
THERMOSTAT
T2
C
C
F
CM
2
TR
C
1
EM
2 3
HPS
SEE NOTE #2
L2
CO
MPONENT LEGEND
C
CONTACTOR
CM
CONDENSER MOTOR
COMP
COMPRESSOR
EM
EVAPORATOR MOTOR
GND
EQUIPMENT GROUND
LVJB
LOW VOLTAGE JUNCTION BOX
PLF
FEMALE PLUG / CONNECTOR
RCCF
RUN C APACIT O R FO R
COMPRESSOR AND FAN
SA
STAR T AS SIST
TR
TRANSFORMER
HPS
HIGH PRESSURE SWITCH
FACTOR
LINE VOLTAGE
LOW VOLTAGE
OPTINAL HIGH
VOLTAGE
HIGH VOLTAGE
LOW VOLTAGE
Y WIRING
FIELD WIRING
W
IRE CODE
BK BLACK
BL BLUE
BR BROWN
GR GREEN
OR ORANGE
PU PURPLE
RD RED
WH WHITE
YL YELLOW
NOTES:
1. REPLACEMENT WIRE MUST BE SAME SIZE AND TYPE INSULATION AS
ORIGINAL (AT LE AS T 105°C) USE COPPER CONDUCTOR ONLY.
2. TO CHANGE EVAPORATOR MOTOR SPEED MOVE WHITE AND YELLOW
LEADS FROM EM "2" AND "3" TO "4" AND "5". IF BOTH LEADS ARE
ENERGIZED, THE HIGHER SPEED SETTING IS USED.
3. FOR 208 VOLT TRANSFOR MER OPERATION MOVE PURPLE WIRES
FROM TERMINAL 3 TO TERMINAL 2 ON TRANSFORMER.
4. START ASSIST FACTORY EQUIPED WHEN REQUIRED
5. USE COPPER CONDUCTOR S ONLY.
++ USE N.E.C. CLASS 2 WIRE
C
SEE UNIT RATING PLATE FOR TYPE AND SIZE
OF OVER CURRENT PROTECTION
208-240/1/60 0140G00871 REV. B
Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
26
Loading...
