Goodman Mfg GSZ-VSZ 13 SEER User Manual

®
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
ALAL
AL
ALAL
GSZ/VSZ 13 SEER
Split System Heat Pump s
Refer to Service Manual RS6200006 for installation, operation, and troubleshooting information.
All safety information must be followed as provided in the Service Manual.
Refer to the appropriate Parts Catalog for part number information.
Models listed on page 3.
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does not assume any responsibility for property damage or personal injury due to improper service procedures or services performed by an unqualified person.
RT6212006 Rev. 5
August 2010
PRODUCT IDENTIFICATION
The model number is used for positive identification of component parts used in manufacturing. Please use this number when requesting service or parts information.
G S Z 13 024 1 A A
ELECTRICAL:
PRO DUCT FAMILY:
S: Split System
BRAND:
G: G oodm an
(Standard Feature Set Model)
®
Brand
S: Goodm an® Deluxe V: Value
SEER:
SEER Rating
PRO DUCT T YPE:
C: Condens er R-22 X: Condens er R-410A H: Heat P um p R-22 Z: Heat Pum p R-410A
1: 208-230v 1ph/60Hz 3: 208-230v 3ph/60Hz 4: 460v 3ph/60Hz
MAJO R REV IS I O N:
A: Initial Release
NOM I NAL CAPACI T Y
018: 1.5 Tons 024: 2 Tons 030: 2.5 t ons 036: 3 Tons 042: 3.5 Tons 048: 4 Tons 060: 5 tons
MI NOR REV IS I ON:
A: Initial Release
WARNING
WARNING
WARNING
service procedures. If you install or perform service on this unit, you assume responsibility for any personal injury or property damage which may result. Many juris­dictions require a license to install or service heating and air conditioning equipment.
2
Disconnect ALL power before servicing or installing this unit. Multiple power sources may be present. Failure to do so may cause property damage, personal injury or death.
Goodman will not be responsible for any injury or property damage arising from improper service or
WARNING
HIGH VOLTAGE!
WARNING
WARNING
ments of an "entry level technician", at a minimum, as specified by the Air-Conditioning, Heating, and Refrigera­tion Institute (AHRI). Attempting to install or repair this unit without such background may result in product damage, personal injury or death.
Installation and repair of this unit should be performed individuals meeting the require-
ONLY by
PRODUCT IDENTIFICATION
The model number is used for positive identification of component parts used in manufacturing. Please use this number when requesting service or parts information.
GSZ130181A* GSZ130241A* GSZ130301A* GSZ130361A* GSZ130421A* GSZ130481A* GSZ130601A*
GSZ130241B* GSZ130361B*
VSZ130181A* VSZ130241A* VSZ130301A* VSZ130361A* VSZ130421A* VSZ130481A* VSZ130601A*
VSZ130241B* VSZ130361B*
GSZ130363A* GSZ130483A* GSZ130484A* GSZ130603A* GSZ130604A*
* Indicates minor revision & is not used for order entry or inventory management
WARNING
WARNING
WARNING
WARNING
property damage, personal injury, reduced unit perfor­mance and/or hazardous conditions may result from the use of such non-approved devices.
The United States Environmental Protection Agency (“EPA”) has issued various regulations re­garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow these regulations may harm the environment and can lead to the imposition of substantial fines. These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
Do not connect or use any device that is not design certified by Good­man for use with this unit. Serious
WARNING
WARNING
als or use gasoline or other flammable liquids or vapors in the vicinity of this appliance.
To prevent the risk of property damage, personal injury, or death, do not store combustible materi-
3
PRODUCT DESIGN
GSZ/VSZ13 models are available in 1 1/2 through 5 ton sizes and use R-410A refrigerant. They are designed for 208/230 volt single phase applications.
Select GSZ13 models are available in 208/230 and 460 volt 3-phase applications. These models use R-410A refrigerant.
The condenser air is pulled through the condenser coil by a direct drive propeller fan. This condenser air is then dis­charged out of the top of the cabinet.
These units are designed for free air discharge, so no addi­tional resistance like duct work shall be attached.
The suction and liquid line connections on present models are of the sweat type for field piping with refrigerant type cop­per. Front seating valves are factory installed to accept the field run copper. The total refrigerant charge for a normal in­stallation is factory installed in the condensing unit. GSZ units are charged for the matching evaporator coil and a 15 foot refrigerant line set.
Systems should be properly sized by heat gain and loss calculations made according to methods of the Air Condi­tioning Contractors Association (ACCA) or equivalent. It is the contractors responsibility to ensure the system has ad­equate capacity to heat or cool the conditioned space.
GSZ/VSZ models use high-efficiency Copeland® scroll "Ultratech" compressors which are specifically desgined for R-410A refrigerant. There are a number of design character­istics which are different from the scroll compared to the tra­ditional reciprocating compressor.
"Ultratech" Series scroll compressors with Copeland ComfortAlert diagnositics will not have a discharge thermo­stat. Some of the early model scroll compressors required discharge thermostats.
Due to their design Scroll compressors are inherently more tolerant of small quantities of liquid refrigerant.
NOTE: Even though the compressor section of a Scroll com­pressor is more tolerant of liquid refrigerant, continued floodback or flooded start conditions may wash oil from the bearing surfaces causing premature bearing failure.
"Ultratech" Series scroll compressors use "POE" or polyolester oil which is NOT compatible with mineral oil based lubricants like 3GS. "POE" oil must be used if additional oil is required.
NOTE: This unit cannot be completely enclosed. At least one side must be unrestricted.
These clearances will help avoid air recirculation. If installing two or more units at the same location, allow at least 24 inches between units. If only one side is restricted (for ex­ample, against the outside wall of a house), the unit may be placed as close as 8" to that one wall.
DO NOT locate the unit:
* Directly under a vent termination for a gas appliance. * Within 3 feet of a clothes drier vent * Where the refreezing of defrost water would create
a hazard
* Where water may rise into the unit.
NOT
RECOMMENDED
B B B
AA AAA
C
®
AA
A
AA
AA
C
AA
CC
B
AA
Minimum Airflow Clearance
Model Type A B C AA
Residential
Light Commercial
10" 10" 18" 20" 12" 12" 18" 24"
OK!
OK!
OK!
OK!
OK!
OK!
WARNING
To avoid possible injury, explosion or death, practice safe handling of refrigerants.
Operating pressures and amp draws may differ from stan­dard reciprocating and/or scroll compressors. This informa­tion may be found in the "Cooling Performance Data" sec­tion.
This unit is for outdoor installation only. Refer to minimum figure for clearances from the sides of the unit to full walls and other objects.
4
PRODUCT DESIGN
G/VSZ130181A* 26 x 26 x 32¼ G/VS Z130241A* 26 x 26 x 32¼ G/VSZ 130241B * 26 x 26 x 32½
G/VSZ130301A* 26 x 26 x 32¼
Product Dimensions
Mo del Dimensi on s - W x D x H
G/VSZ13036 1A*
GSZ130 363A*
G/VSZ 130361B * 29 x 29 x 32½
G/VSZ130421A* 29 x 29 x 38¼ G/VSZ13048 1A*
GSZ130 483A* GSZ130 484A*
G/VSZ13060 1A*
GZX130603A*
GSZ130 604A*
29 x 29 x 38¼
29 x 29 x 34¼
35½ x 35½ x 34¼
5
HEAT PUMP SPECIFICATIONS
G/VSZ130[18-60]1A*
*SZ130181A
Nominal Capacit ies
Cooling Capacity , B TUH 18,000 24,000 30,000 36,000 42,000 48,000 60,000 Heating Capacity , B TUH 17,000 23, 000 26,400 34,000 40, 500 44,000 58,000
Compressor
R.L. A m ps 9.0 12.8 14.1 16.6 17.9 19.8 26.4 L.R. A m ps 48.0 58.3 73.0 79.0 112.0 109.0 134. 0
Low Pressure Switch
Open 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG Close 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PS IG 610 PS IG 610 P S IG 610 PS IG 610 P SIG 610 P S IG 610 P S IG Close 420 PS IG 420 PS IG 420 P S IG 420 PS IG 420 PS IG 420 P S IG 420 P S IG
Condenser Fan M ot or
Horsepower 1/6 1/6 1/6 1/4 1/4 1/4 1/4
F.L. A m ps 1.10 1.10 1.10 1.50 1.50 1.50 1.50 Liquid Line, Inches O. D.* 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" Suction Line, Inches O.D.* 3/4"3/4"3/4"3/4"7/8"7/8"7/8" Refrigerant Charge 122.0 122.0 127.0 171.0 174. 0 222.0 245.0 Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
Maximum Overcurrent Device Elec trical Conduit Siz e
Power Supply (Inches) 1/2 or 3/4 1/ 2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 Approxim ate S hipping Weight 198 198 202 232 235 240 266
(1)
(2)
12.3 17.1 18.7 22.3 23.9 26.3 34.5 20 25 30 35 40 45 60
*SZ130241A
*SZ130301A
*SZ130361A
*SZ130421A
*SZ130481A
*SZ130601A
*
Up to 24' in equivalent line length
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
Always check the S & R plate for electrical data on the unit being installed.
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT, NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general and electrical information.
6
HEAT PUMP SPECIFICATIONS
G/VSZ130[24,36]B*
*SZ130241B
Nominal Capacities
Cooling Capacity, B TUH 24,000 36,000 Heating Capac ity , BTUH 23,000 34,000
Compress or
R.L. Am ps 12.8 16.7 L.R. Am ps 58.3 79.0
Low P ress ure Switch
Open 22 PSIG 22 PSIG Close 50 P S IG 50 P S IG
High Pressure Switch
O pen 610 P S IG 61 0 PS IG Close 420 PS IG 420 PS IG
Condens er Fan M otor
Horsepower 1/6 1/4
F.L. Am ps 1.10 1.50 Liquid Line, Inches O .D.* 3/8" 3/8" Suc tion Line, Inc hes O .D.* 3/4" 3/4" Refrigerant Charge 113.0 131.0 Pow er Supply 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
Maximum Overcurrent Device E lectric al Conduit Size
P ower S upply (Inc hes) 1/2 or 3/4 1/2 or 3/4
(1)
(2)
17.1 22.3 25 35
*SZ130361B
A pproxim ate Shipping Weight 162 182
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Tested and rated in accordance with AHRI Standard 210/240
NOTES:
Always check the S & R plate for electrical data on the unit being installed.
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT, NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general and electrical information.
7
HEAT PUMP SPECIFICATIONS
GSZ130[36-60][3,4]A*
GSZ130363A*
Nominal Capac it ies
Cooling Capac ity , B TUH 36,000 48,000 48,00 0 6 0,000 60,000
Heating Capac ity , BTUH 34,000 44,000 44,000 58, 000 58 ,000 Decibels 7476767575 Compressor
R.L. A mps 10.4 13.1 6. 1 16. 0 7.8
L.R. A mps 73.0 83.1 41.0 110. 0 52.0
Type Scroll Scroll Scroll Scroll Scroll Condenser F an M ot or
Horsepower 1/ 4 1/4 1/4 1/4 1/4
F.L. A m ps 1.50 1.50 0.80 1. 50 0.80 Refrigerant S y s t em
Liquid Line, Inches O. D. *
Suc t ion Line, Inches O. D.*
Liquid Valve Connect ion, Inches O. D. * 3/8" 3/8" 3/ 8" 3/ 8" 3/ 8"
Suc t ion Valve Connection, Inches O.D. * 3/ 4" 7/ 8" 7/8" 7/ 8" 7/ 8"
Refrigerant Charge 171.0 222.0 222.0 245.0 245.0
Pis t on S iz e 0.068 0.078 0.078 0.088 0.088 Power S upply 208/230-60-3 208/230-60-3 460-60-3 208/230-60-3 460-60-3
Minim um C ircuit A m pac it y
Maximum Overcurrent Device
Min / M ax Volts 197 / 253 197 / 253 414 / 506 197 / 25 3 414 / 506 Elec tric al Condu it S iz e
Power S upply (Inches ) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/ 2 or 3/4 1/2 or 3/4 Approx im ate S hipping Weight 232 235 234 262 261
3
3
(1)
(2)
3/8" 3/8" 3/8" 3/8" 3/ 8" 7/8" 1 1/8" 1 1/8 " 1 1/8" 1 1/8"
14.5 17.9 8. 4 21.5 10.6 20 30 15 35 15
GSZ130483A*
GSZ130484A*
GSZ130603A*
GSZ130604A*
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Tested and rated in accordance with AHRI Standard 210/240
NOTES:
Always check the S & R plate for electrical data on the unit being installed.
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT, NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general and electrical information.
8
COOLING PERFORMANCE DAT A
COOLING OPERATION
G/VSZ130181A*
16 11 21 19 16 11 20 18 15 10
6.0 6.2 6.0 6.2 6.4 6.6 6.4 6 .5 6.8 7.0
371 387 368 396 418 436 406 437 4 61 481
17.5 18.7 14.9 15.3 16.6 17.8 13.8 14 .2 15.4 16.5
0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
20
16.1
0.79
146 155 131 140 153 162 136 145 1 58 168
1.57 1.62 1.55 1.59 1.64 1.69 1.61 1.64 1.69 1.75
5.8
352
133
1.52
EXPANDED PERFORMANCE DATA
Outdoor Am bient Temper ature
Entering Indoor Wet Bulb Temper ature
65 75 85 95 105 115
T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
MBh 17.1 17.7 19.4 - 16.7 17.3 18.9 - 16.3 16.9 18.5 - 15.9 16.4 18.0 - 15.1 1 5.6 17.1 - 14.0 14.5 15.9 -
HI PR 225 242 255 - 252 271 287 - 287 309 326 - 327 352 371 - 367 395 418 - 406 437 4 61 -
A MPS 4.5 4.6 4.8 - 4.9 5.0 5.2 - 5.3 5.4 5.6 - 5 .7 5.8 6.0 - 6.0 6.2 6.4 - 6.4 6.5 6.8 -
LO PR 109 116 126 - 115 122 133 - 119 127 139 - 125 133 146 - 131 140 152 - 136 144 158 -
T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
MBh 16.6 17.2 18.8 - 16.2 1 6.8 18.4 - 15.8 16.4 17.9 - 15.4 16.0 17.5 - 14.6 15.2 16.6 - 13 .6 14.0 15 .4 -
HI PR 222 239 253 - 250 269 284 - 284 306 323 - 323 348 368 - 364 392 413 - 402 433 4 57 -
A MPS 4.5 4.6 4.7 - 4.8 4.9 5.1 - 5.2 5.4 5.6 - 5 .6 5.7 5.9 - 6.0 6.1 6.3 - 6.3 6.5 6.7 -
T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
MBh 15.3 15.8 17.4 - 14.9 1 5.5 16.9 - 14.6 15.1 16.5 - 14.2 14.7 16.1 - 13.5 14.0 15.3 - 12 .5 13.0 14 .2 -
LO PR 108 114 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 138 151 - 134 143 156 -
HI PR 216 232 245 - 242 261 275 - 275 296 313 - 314 338 356 - 353 380 401 - 390 420 4 43 -
A MPS 4.3 4.5 4.6 - 4.7 4.8 5.0 - 5.1 5.2 5.4 - 5 .5 5.6 5.8 - 5.8 5.9 6.1 - 6.1 6.3 6.5 -
LO PR 104 111 121 - 110 117 128 - 115 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -
T 20181510201915112019151120 19 15 112018151019171410
S/T 0.84 0.76 0 .5 7 0 .3 7 0 .8 8 0 .7 8 0 .5 9 0 .38 0.90 0.80 0.61 0.3 9 0 .9 3 0.83 0.63 0.40 0.96 0.8 6 0 .6 5 0 .4 2 0 .97 0.87 0.66 0.42
MBh 17.34 17.85 19.32 20.74 16.94 1 7.44 1 8.87 20.26 16.53 17.02 18.43 19.78 16.13 16.61 1 7.98 19.2 9 1 5.32 15.78 17.08 18.33 14.19 14.61 15.82 16.98
HI PR 227 244 258 269 255 274 289 302 290 3 12 329 343 330 355 375 391 371 399 422 440 410 441 466 486
AMPS4.64.74.85.04.95.05.25.45.35.55.75.95.7 5.9 6.0 6.36.16.26.46.76.46.66.87.1
LO PR 110 117 127 136 116 123 135 143 120 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170
T 21191611211916112119161121
S/T 0.810.720.550.350.840.750.570.360.860.770.580.370.88
MBh 16.8 17.3 18.8 20.1 16.4 16.9 18 .3 19.7 16 .1 16.5 17 .9 19.2 15.7
HI PR 225 242 255 266 252 271 287 299 287 3 09 326 340 327
AMPS4.54.64.84.94.95.05.25.35.35.45.65.85.7
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125
T 21191611212016112120161122 20 16 112120161120181510
S/T 0.78 0.69 0 .5 3 0 .3 4 0 .8 1 0 .7 2 0 .5 5 0 .35 0.83 0.74 0.56 0.3 6 0 .8 5 0.76 0.58 0.37 0.88 0.7 9 0 .6 0 0 .3 9 0 .89 0.80 0.60 0.39
MBh 15.5 16.0 17.3 18.6 15.2 15.6 16 .9 18.2 14 .8 15.3 16 .5 17.7 14.5 1 4.88 16.1 17.3 13.7 14.1 15.3 16.4 12 .7 13.1 14 .2 15.2
HI PR 218 235 248 258 245 263 278 290 278 2 99 316 330 317 341 360 376 357 384 405 423 394 424 448 467
AMPS4.44.54.64.84.74.95.05.25.25.35.55.75.5 5.6 5.8 6.05.96.06.26.46.26.46.66.8
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 122 129 141 150 127 136 148 158 132 140 153 163
675 KW 1.25 1.27 1.31 - 1.34 1.37 1.41 - 1.42 1.45 1.50 - 1.49 1.52 1.5 7 - 1.55 1.59 1.64 - 1.61 1.64 1.69 -
MODEL: G/VSZ130181A* / AR*F182416 **
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
70 600 KW 1.24 1.26 1.30 - 1.33 1.36 1.4 0 - 1.41 1.44 1.48 - 1.48 1.51 1.56 - 1.54 1.57 1.62 - 1.59 1.63 1.68 -
525 KW 1.21 1.23 1.27 - 1.30 1.32 1.36 - 1.38 1.40 1.45 - 1.44 1.47 1.5 2 - 1.50 1.53 1.58 - 1.55 1.59 1.64 -
675 KW 1.26 1.28 1 .3 2 1 .3 6 1 .3 5 1 .3 8 1 .4 2 1 .46 1.43 1.46 1.51 1.56 1.50 1.54 1.58 1.64 1 .57 1.60 1.6 5 1 .7 0 1 .62 1.65 1.71 1.76
75 600 KW 1.251.271.311.351.341.371.411.451.421.451.501.541.49
525 KW 1.22 1.24 1 .2 8 1 .3 2 1 .3 1 1 .3 3 1 .3 8 1 .42 1.39 1.42 1.46 1.51 1.46 1.49 1.53 1.58 1 .51 1.55 1.6 0 1 .6 5 1 .57 1.60 1.65 1.71
Shaded area is ACCA (TV A) conditions IDB: Entering Indoor Dry Bulb Temperatur e KW=Total system power AMPS=outdoor unit amps (comp.+fan
High and low pressu re s are measur ed at the liquid and suction service valves .
9
COOLING PERFORMANCE DAT A
COOLING OPERATION
16 23 22 19 16 21 21 18 15
6.3 6.1 6.2 6.4 6.7 6.4 6.6 6.8 7.1
391 371 400 422 440 410 441 466 486
1.64 1.57 1.60 1.65 1.70 1.62 1.65 1.71 1.76
1.59
157 133 141 154 164 137 146 159 170
6.1
375
147
18.6 15.1 15 .5 16.5 17.7 14.0 14.3 15.3 16.4
0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
20
17.4
0.74
G/VSZ130181A*
EXPANDED PERFORM ANCE DATA
Outdoor Ambient Tempe rature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
DT 22 21 19 15 23 22 19 15 23 22 19 15 22 22 1 9 15 21 22 19 15 20 20 17 14
S/T 0.93 0.87 0.71 0.53 0.9 6 0.90 0 .73 0.55 1.00 0.92 0.75 0 .56 1.0 0 0.95 0.78 0.58 1.00 1.00 0.81 0 .60 1.0 0 1 .00 0.8 1 0.61
MBh 17.6 18.0 19.3 20.6 17.2 17.6 18.8 20.1 16.8 17 .2 18.4 19.6 16.4 16.8 17.9 19.2 15.6 15.9 17.0 18.2 14.4 14.8 15.8 16.9
HI PR 229 247 261 272 2 57 277 292 305 293 315 333 347 333 359 379 395 375 404 426 444 414 446 471 491
AMPS 4.6 4.7 4.9 5.0 5.0 5.1 5.3 5.4 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.8 6.5 6.7 6.9 7.2
LO PR 111 118 129 137 117 125 136 1 45 122 129 141 151 128 136 148 158 134 143 156 166 139 147 161 171
DT 23 22 19 15 23 23 20 16 24 23 20 16 24 23
S/T 0.88 0.83 0.67 0.50 0.9 2 0.86 0 .70 0.52 0.94 0.88 0.72 0 .54 0.9 7 0.91
MBh 17.1 17.5 18.7 20.0 16.7 17.1 18.3 19.5 16.3 16 .7 17.8 19.1 15.9 16.3
HI PR 227 244 258 269 2 55 274 290 302 290 312 329 343 330 355
AMPS 4.6 4.7 4.8 5.0 4.9 5.0 5.2 5.4 5.3 5.5 5.7 5.9 5.7 5.9
LO PR 110 117 127 136 116 123 135 1 43 120 128 140 149 127 135
DT 24 23 20 16 24 23 20 16 24 23 20 16 24 23 2 0 16 24 23 20 16 22 21 18 15
S/T 0.85 0.80 0.65 0.49 0.8 8 0.83 0 .67 0.50 0.91 0.85 0.69 0 .52 0.9 3 0.88 0.71 0.53 0.97 0.91 0.74 0 .55 0.9 8 0 .92 0.7 5 0.56
MBh 15.8 16.2 17.3 18.5 15.4 15.8 16.9 18.0 15.1 15 .4 16.5 17.6 14.7 15.0 16.1 17.2 14.0 14.3 15.3 16.3 12.9 13.2 14.1 15.1
HI PR 220 237 250 261 2 47 266 281 293 281 302 319 333 320 344 364 379 360 388 409 427 398 428 452 472
AMPS 4.4 4.5 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
LO PR 106 113 124 132 112 120 131 1 39 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165
DT 24 23 22 19 24 24 22 19 23 24 22 19 23 23 2 3 20 22 22 22 19 20 20 21 18
S/T 0.97 0.94 0.85 0.69 1.0 0 0.97 0 .88 0.71 1.00 1.00 0.90 0 .73 1.0 0 1.00 0.93 0.75 1.00 1.00 0.96 0 .78 1.0 0 1 .00 0.9 7 0.79
MBh 18.0 18.3 19.2 20.5 17.5 17.9 18.7 20.0 17.1 17 .5 18.3 19.5 16.7 17.0 17.8 19.0 15.9 16.2 16.9 18.1 14.7 15.0 15.7 16.7
HI PR 232 249 263 275 2 60 280 295 308 296 318 336 350 337 362 383 399 379 408 430 449 418 450 475 496
AMPS 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.6 6.8 6.6 6.7 7.0 7.2
LO PR 112 119 130 138 118 126 137 1 46 123 131 143 152 129 137 150 160 135 144 157 167 140 149 163 173
DT 25 24 23 20 25 25 23 20 25 25 23 20 25 25 2 3 20 24 24 23 20 22 22 22 19
S/T 0.93 0.89 0.81 0.65 0.9 6 0.93 0 .84 0.68 0.98 0.95 0.86 0 .70 1.0 0 0.98 0.89 0.72 1.00 1.00 0.92 0 .75 1.0 0 1 .00 0.9 3 0.75
MBh 17.4 17.8 18.6 19.9 17.0 17.4 18.2 19.4 16.6 16 .9 17.7 18.9 16.2 16.5 17.3 18.5 15.4 15.7 16.4 17.5 14.3 14.5 15.2 16.3
HI PR 229 247 261 272 2 57 277 292 305 293 315 333 347 333 359 379 395 375 404 426 444 414 446 471 491
AMPS 4.6 4.7 4.9 5.0 5.0 5.1 5.3 5.4 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.8 6.5 6.7 6.9 7.2
LO PR 111 118 129 137 117 125 136 1 45 122 129 141 151 128 136 148 158 134 143 156 166 139 147 161 171
DT 25 25 23 20 25 25 24 21 26 25 24 21 26 25 2 4 21 25 25 24 20 23 23 22 19
S/T 0.89 0.86 0.78 0.63 0.9 3 0.89 0 .81 0.65 0.95 0.92 0.83 0 .67 0.9 8 0.95 0.85 0.69 1.00 0.98 0.89 0 .72 1.0 0 0 .99 0.8 9 0.72
MBh 16.1 16.4 17.2 18.3 15.7 16.0 16.8 17.9 15.3 15 .6 16.4 17.5 15.0 15.3 16.0 17.0 14.2 14.5 15.2 16.2 13.2 13.4 14.1 15.0
HI PR 222 239 253 264 2 50 269 284 296 284 305 323 336 323 348 367 383 364 391 413 431 402 432 457 476
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.4 5.6 5.8 5.6 5.7 5.9 6.2 6.0 6.1 6.3 6.6 6.3 6.5 6.7 7.0
LO PR 108 114 125 133 114 121 132 1 40 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
10
675 KW 1.27 1.29 1.33 1.37 1.36 1.39 1.43 1.48 1.44 1.47 1.52 1.57 1.52 1.55 1.60 1.65 1.58 1.61 1.66 1.72 1.63 1.67 1.72 1.78
M OD EL: G/VSZ130181A* / AR*F182416**
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
80 600 KW 1.26 1.28 1.32 1.36 1.35 1.38 1.42 1.46 1.43 1.46 1.51 1.56 1.50 1.54
525 KW 1.23 1.25 1.29 1.33 1.32 1.34 1.39 1.43 1.40 1.43 1.47 1.52 1.47 1.50 1.55 1.60 1.53 1.56 1.61 1.66 1.58 1.61 1.67 1.72
675 KW 1.28 1.30 1.34 1.38 1.37 1.40 1.44 1.49 1.45 1.49 1.53 1.58 1.53 1.56 1.61 1.66 1.59 1.63 1.68 1.73 1.65 1.68 1.74 1.79
85 600 KW 1.27 1.29 1.33 1.37 1.36 1.39 1.43 1.48 1.44 1.47 1.52 1.57 1.52 1.55 1.60 1.65 1.58 1.61 1.66 1.72 1.63 1.67 1.72 1.78
525 KW 1.24 1.26 1.30 1.34 1.33 1.36 1.40 1.44 1.41 1.44 1.48 1.53 1.48 1.51 1.56 1.61 1.54 1.57 1.62 1.68 1.59 1.63 1.68 1.73
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system pow er AMPS=outdoor unit amps (c omp.+f an
High and low pressures ar e measured at the liquid and s uction serv ice valves.
COOLING PERFORMANCE DAT A
COOL ING OP ER ATIO N
G/VSZ130241A*
EXPANDE D PERF ORMANCE DATA
15 10 19 18 15 10 18 17 14 9
8.2 8.5 8.2 8.4 8.7 9.1 8.7 9.0 9.3 9.6
378 394 374 403 425 443 413 445 470 490
2.08 2.15 2.05 2.10 2.17 2.24 2.12 2.17 2.24 2.32
2.01
141 150 127 135 148 157 132 140 153 163
7.9
358
129
23.8 25.5 20.3 20.9 22.6 24.2 18.8 19.3 20.9 22.4
0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
18
22.0
0.83
Outdoor Ambient Temperature
Entering Indoor Wet Bulb Temperature
15 11 20 19 15 11 19 17 14 10
8.1 8.4 8.2 8.4 8.7 9.0 8.7 8.9 9.2 9.5
374 390 370 399 421 439 409 441 465 485
2.06 2.13 2.04 2.08 2.15 2.22 2.11 2.15 2.22 2.30
2.00
140 149 126 134 146 156 130 139 151 161
7.9
354
128
23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8
0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40
19
21.3
0.79
16 11 21 19 16 11 19 18 14 10
7.9 8.2 7.9 8.1 8.4 8.7 8.4 8.6 8.9 9.3
363 379 359 387 408 426 397 427 451 471
2.01 2.08 1.99 2.03 2.10 2.17 2.05 2.10 2.17 2.24
1.95
135 144 122 130 142 151 126 134 147 156
7.6
344
124
21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1
0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
19
19.7
0.76
65 75 85 95 105 115
DT 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
MBh 22.5 23.4 25.6 - 22.0 22.8 25.0 - 21.5 22.3 24.4 - 21.0 21.7 23.8 - 19.9 20.6 22.6 - 18.4 19.1 21.0 -
MODEL: G/VSZ130241A* / AR*F182416**
IDB*Airflow 59 63 677159 636771596367 7159 63 67 715963677159636771
HI PR 227 244 257 - 254 274 289 - 289 311 328 - 329 354 374 - 370 399 421 - 409 440 465 -
AMPS 6.1 6.2 6.4 - 6.6 6.8 7.0 - 7.2 7.3 7.6 - 7.7 7.9 8.1 - 8.2 8.4 8.7 - 8.7 8.9 9.2 -
LO PR 104 111 121 - 110 117 128 - 114 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -
923 KW 1.63 1.66 1.71 - 1.75 1.79 1.84 - 1.86 1.90 1.96 - 1.95 2.00 2.06 - 2.04 2.08 2.15 - 2.11 2.15 2.22 -
DT 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
MBh 21.9 22.7 24.8 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 20.4 21.1 23.1 - 19.3 20.0 22.0 - 17.9 18.6 20.3 -
HI PR 224 241 255 - 252 271 286 - 286 308 325 - 326 351 370 - 367 395 417 - 405 436 460 -
AMPS 6.0 6.2 6.4 - 6.5 6.7 6.9 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.1 8.3 8.6 - 8.6 8.8 9.1 -
LO PR 103 110 120 - 109 116 127 - 113 120 132 - 119 127 138 - 125 133 145 - 129 137 150 -
70 820 KW 1.61 1.65 1.70 - 1.74 1.77 1.83 - 1.84 1.88 1.94 - 1.94 1.98 2.05 - 2.02 2.06 2.13 - 2.09 2.14 2.21 -
DT 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
MBh 20.2 20.9 22.9 - 19.7 20.4 22.4 - 19.3 20.0 21.9 - 18.8 19.5 21.3 - 17.8 18.5 20.3 - 16.5 17.1 18.8 -
HI PR 218 234 247 - 244 263 277 - 278 299 315 - 316 340 359 - 356 383 404 - 393 423 447 -
AMPS 5.9 6.0 6.2 - 6.4 6.5 6.7 - 6.9 7.1 7.3 - 7.4 7.6 7.8 - 7.9 8.1 8.3 - 8.3 8.5 8.8 -
LO PR 100 106 116 - 106 112 123 - 110 117 128 - 115 123 134 - 121 129 140 - 125 133 145 -
718 KW 1.58 1.61 1.66 - 1.70 1.73 1.79 - 1.80 1.84 1.90 - 1.89 1.93 1.99 - 1.97 2.01 2.08 - 2.04 2.08 2.15 -
DT 19 18 15 10 20 18 15 10 20 18 15 10 20
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93
MBh 22.9 23.6 25.5 27.4 22.4 23.0 24.9 26.8 21.9 22.5 24.4 26.1 21.3
923 KW 1.64 1.67 1.73 1.78 1.76 1.80 1.86 1.92 1.87 1.91 1.98 2.04 1.97
HI PR 229 246 260 271 257 276 292 304 292 314 332 346 333
AMPS 6.2 6.3 6.5 6.8 6.7 6.8 7.0 7.3 7.2 7.4 7.7 8.0 7.7
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121
DT 20 18 15 10 20 19 15 11 20 19 15 11 20
S/T 0.80 0.72 0.54 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88
MBh 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7
75 820 KW 1.63 1.66 1.71 1.77 1.75 1.79 1.84 1.90 1.86 1.90 1.96 2.02 1.96
HI PR 227 244 257 269 254 274 289 301 289 311 329 343 329
AMPS 6.1 6.2 6.4 6.7 6.6 6.8 7.0 7.2 7.2 7.3 7.6 7.9 7.7
LO PR 104 111 121 129 110 117 128 136 114 122 133 142 120
DT 20 19 15 11 21 19 16 11 21 19 16 11 21
S/T 0.78 0.69 0.53 0.34 0.80 0.72 0.54 0.35 0.82 0.74 0.56 0.36 0.85
MBh 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1
718 KW 1.59 1.62 1.67 1.72 1.71 1.74 1.80 1.86 1.81 1.85 1.91 1.97 1.91
HI PR 220 237 250 260 247 265 280 292 280 302 319 332 319
AMPS 5.9 6.1 6.3 6.5 6.4 6.6 6.8 7.0 7.0 7.1 7.4 7.7 7.5
LO PR 101 108 117 125 107 114 124 132 111 118 129 137 117
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps ( comp.+fan
High and low pressur es ar e measured at the liquid and suction service valves .
11
COOLING PERFORMANCE DAT A
n
COOLING OPERATION
15 22 22 19 15 21 20 18 14
8.5 8.2 8.4 8.7 9.1 8.7 9.0 9.3 9.6
394 374 403 425 444 413 445 470 490
150 127 135 148 157 132 140 153 163
2.15 2.05 2.10 2.17 2.24 2.12 2.17 2.24 2.32
24.6 20.0 20.5 21.9 23.4 18.5 18.9 2 0.2 21.6
0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
19
8.2
378
141
2.08
23.0
0.74
G/VSZ130241A*
Outdoor Ambient Temperature
Entering Indoor Wet Bulb Tem perature
EXPANDED PERFORM ANCE DATA
65 75 85 95 105 115
DT 22 21 18 14 22 21 18 15 22 21 18 15 22 21 18 15 21 21 18 14 19 19 17 13
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.0 0 0.92 0.75 0.56 1.0 0 0.95 0.78 0.58 1. 00 1.00 0.80 0.60 1.00 1.00 0.81 0.61
MBh 23.3 23.8 25.5 27.2 22.8 23.3 24.9 26.6 22.2 22.7 24.3 26.0 21.7 22.2 23.7 25.3 20.6 21.1 22.5 24.1 19.1 19.5 20.8 22.3
HI PR 231 249 263 274 259 279 295 307 295 317 335 350 336 362 382 398 378 407 430 448 418 449 475 495
A MPS 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.3 7.5 7.7 8.0 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.2 8.8 9.0 9.4 9.7
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
DT 22 21 19 15 23 22 19 15 23 22 19 15 23 22
S/T 0.88 0.83 0.67 0.50 0.91 0.86 0.70 0.52 0.9 4 0.88 0.72 0.54 0.9 7 0.91
MBh 22.6 23.1 24.7 26.4 22.1 22.6 24.2 25.8 21.6 22.1 23.6 25.2 21.1 21.5
HI PR 229 246 260 271 257 276 292 304 292 314 332 346 333 358
AMPS 6.2 6.3 6.5 6.8 6.7 6.8 7.0 7.3 7.2 7.4 7.7 8.0 7.7 7.9
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129
DT 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 21 18 14
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.9 0 0.85 0.69 0.52 0.9 3 0.88 0.71 0.53 0. 97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
MBh 20.9 21.4 22.8 24.4 20.4 20.9 22.3 23.8 19.9 20.4 21.8 23.3 19.4 19.9 21.2 22.7 18.5 18.9 20.2 21.6 17.1 17.5 18.7 20.0
HI PR 222 239 252 263 249 268 283 295 283 305 322 336 323 347 367 382 363 391 412 430 401 432 456 475
A MPS 6.0 6.1 6.3 6.6 6.5 6.6 6.9 7.1 7.0 7.2 7.5 7.7 7.5 7.7 8.0 8.3 8.0 8.2 8.5 8.8 8.5 8.7 9.0 9.3
LO PR 102 109 119 126 108 115 125 133 112 119 130 139 118 125 137 146 123 131 143 153 128 136 148 158
DT 23 23 21 18 23 23 22 19 23 23 22 19 22 22 22 19 21 21 21 19 19 20 20 17
S/T 0.97 0.94 0.84 0.69 1.00 0.97 0.88 0.71 1.0 0 0.99 0.90 0.73 1.0 0 1.00 0.93 0.75 1. 00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
MBh 23.7 24.2 25.3 27.0 23.2 23.6 24.8 26.4 22.6 23.1 24.2 25.8 22.1 22.5 23.6 25.1 21.0 21.4 22.4 23.9 19.4 19.8 20.7 22.1
HI PR 233 251 265 277 262 282 298 310 298 321 339 353 339 365 386 402 382 411 434 452 422 454 479 500
A MPS 6.3 6.4 6.6 6.9 6.8 6.9 7.2 7.4 7.4 7.6 7.8 8.1 7.9 8.1 8.4 8.7 8.4 8.6 8.9 9.2 8.9 9.1 9.4 9.8
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 161 134 143 156 166
DT 24 24 22 19 24 24 22 19 24 24 23 19 24 24 23 20 23 23 22 19 21 22 21 18
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.9 8 0.95 0.86 0.69 1.0 0 0.98 0.88 0.72 1. 00 1.00 0.92 0.74 1.00 1.00 0.93 0.75
MBh 23.0 23.5 24.6 26.2 22.5 22.9 24.0 25.6 22.0 22.4 23.5 25.0 21.4 21.9 22.9 24.4 20.4 20.8 21.7 23.2 18.9 19.2 20.1 21.5
HI PR 231 249 263 274 259 279 295 307 295 317 335 350 336 362 382 398 378 407 430 448 418 449 475 495
A MPS 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.3 7.5 7.7 8.0 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.2 8.8 9.0 9.4 9.7
LO PR 106 113 123 131 112 119 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164
DT24.32242320 25 2423202524 23 2025 24 23 202424232022222118
S/T 0.89 0.86 0.78 0.63 0.92 0.89 0.81 0.65 0.9 5 0.91 0.83 0.67 0.9 8 0.94 0.85 0.69 1. 00 0.98 0.88 0.72 1.00 0.99 0.89 0.72
MBh 21.3 21.7 22.7 24.2 20.8 21.2 22.2 23.7 20.3 20.7 21.7 23.1 19.8 20.2 21.1 22.5 18.8 19.2 20.1 21.4 17.4 17.7 18.6 19.8
HI PR 224 241 255 266 252 271 286 298 286 308 325 339 326 351 370 386 367 395 417 435 405 436 460 480
A MPS 6.0 6.2 6.4 6.6 6.5 6.7 6.9 7.2 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.4 8.1 8.3 8.6 8.9 8.6 8.8 9.1 9.4
LO PR 103 110 120 128 109 116 127 135 113 120 132 140 119 127 138 147 125 133 145 154 129 137 150 159
12
923 KW 1.65 1.69 1.74 1.80 1.78 1.82 1.87 1.94 1.89 1.93 1.99 2.06 1.99 2.03 2.10 2.17 2.07 2.12 2.19 2.26 2.14 2.19 2.26 2.34
M ODEL: G/VSZ130241A* / AR* F 1 824 16 * *
IDB*Airflow 59 63 6771 59 6367715963 67 7159 63 67 715963677159636771
80 820 KW 1.64 1.67 1.73 1.78 1.76 1.80 1.86 1.92 1.87 1.91 1.98 2.04 1.97 2.01
718 KW 1.60 1.63 1.69 1.74 1.72 1.76 1.81 1.87 1.83 1.87 1.93 1.99 1.92 1.96 2.03 2.10 2.00 2.05 2.11 2.18 2.07 2.12 2.19 2.26
923 KW 1.67 1.70 1.75 1.81 1.79 1.83 1.89 1.95 1.90 1.95 2.01 2.08 2.00 2.05 2.11 2.18 2.09 2.13 2.20 2.28 2.16 2.21 2.28 2.36
85 820 KW 1.65 1.69 1.74 1.80 1.78 1.82 1.87 1.94 1.89 1.93 1.99 2.06 1.99 2.03 2.10 2.17 2.07 2.12 2.19 2.26 2.14 2.19 2.26 2.34
718 KW 1.61 1.65 1.70 1.75 1.74 1.77 1.83 1.89 1.84 1.88 1.94 2.01 1.94 1.98 2.05 2.11 2.02 2.06 2.13 2.20 2.09 2.14 2.21 2.28
High and low pressures are measured at the liquid and suction service valves.
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system pow er AMPS=outdoor unit amps (comp.+fa
COOLING PERFORMANCE DAT A
g
G/VSZ130241B*
16 11 21 19 16 11 20 18 15 10
8.0 8.3 8.1 8.3 8.5 8.9 8.5 8.8 9.0 9.4
139 148 125 133 145 155 129 138 150 160
377 393 373 402 424 443 413 444 469 489
23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8
21.3
2.05 2.12 2.03 2.07 2.14 2.21 2.10 2.14 2.21 2.28
0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
20
7.8
127
357
1.99
0.80
EXPANDED PER FORMANC E DA TA
Outdoor Ambient Temperature
Entering Indoor Wet Bulb Temperature
65 75 85 95 105 115
T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
M B h 22.5 23.4 25.6 - 22.0 22.8 25.0 - 21.5 22.3 24.4 - 21.0 21.7 23.8 - 19.9 20.6 22.6 - 18.4 19.1 21.0 -
HI PR 228 246 259 - 256 276 291 - 291 314 331 - 332 357 377 - 373 402 424 - 413 444 469 -
AMPS 6.1 6.2 6.4 - 6.5 6.7 6.9 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.1 8.3 8.5 - 8.5 8.8 9.0 -
LO PR 103 110 120 - 109 116 127 - 114 121 132 - 119 127 139 - 125 133 145 - 129 138 150 -
T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
M B h 21.9 22.7 24.8 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 20.4 21.1 23.1 - 19.3 20.0 22.0 - 17.9 18.6 20.3 -
HI PR 226 243 257 - 254 273 288 - 288 310 328 - 329 354 373 - 370 398 420 - 408 440 464 -
AMPS 6.0 6.2 6.3 - 6.5 6.6 6.9 - 7.0 7.2 7.4 - 7.5 7.7 8.0 - 8.0 8.2 8.5 - 8.5 8.7 9.0 -
LO PR 102 109 119 - 108 115 126 - 112 120 131 - 118 126 137 - 124 132 144 - 128 136 149 -
T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
M B h 20.2 20.9 22.9 - 19.7 20.4 22.4 - 19.3 20.0 21.9 - 18.8 19.5 21.3 - 17.8 18.5 20.3 - 16.5 17.1 18.8 -
HI PR 219 236 249 - 246 265 280 - 280 301 318 - 319 343 362 - 359 386 407 - 396 426 450 -
AMPS 5.9 6.0 6.2 - 6.3 6.5 6.7 - 6.8 7.0 7.2 - 7.3 7.5 7.7 - 7.8 8.0 8.2 - 8.2 8.4 8.7 -
LO PR 99 106 115 - 105 112 122 - 109 116 127 - 115 122 133 - 120 128 139 - 124 132 144 -
T201815102019151120191511201915112019151119171410
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43
M B h 22.92 23.60 25.54 27.41 22.39 23.05 24.95 26.78 21.85 22.50 24.36 26.14 21.32 21.95 23.76 25.50 20.25 20.85 22.57 24.23 18.76 19.32 20.91 22.44
HI PR 231 248 262 273 259 279 294 307 294 317 334 349 335 361 381 397 377 406 429 447 417 448 474 494
AMPS 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.2 7.2 7.3 7.6 7.9 7.7 7.8 8.1 8.4 8.1 8.3 8.6 8.9 8.6 8.8 9.1 9.5
LO PR 104 111 121 129 110 117 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
T21191611211916112119161121
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90
M B h 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7
HI PR 228 246 260 271 256 276 291 304 291 314 331 345 332
LO PR 103 110 120 128 109 116 127 135 114 121 132 141 119
AMPS 6.1 6.2 6.4 6.6 6.5 6.7 6.9 7.2 7.1 7.3 7.5 7.8 7.6
T212016112220161122201611222016112120161120181510
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
M B h 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1 19.7 21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1
HI PR 222 238 252 263 249 267 282 295 283 304 321 335 322 346 366 382 362 390 412 429 400 431 455 474
AMPS 5.9 6.0 6.2 6.5 6.4 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.6 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1
LO PR 100 107 117 124 106 113 123 131 110 117 128 136 116 123 134 143 121 129 141 150 125 133 146 155
900 KW 1.63 1.66 1.71 - 1.75 1.78 1.84 - 1.85 1.89 1.95 - 1.95 1.99 2.05 - 2.03 2.07 2.14 - 2.10 2.14 2.21 -
MODEL: G/VSZ130241B*/ AR*F182416* * COOLING OPERATION
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70 800 KW 1.62 1.65 1.70 - 1.74 1.77 1.83 - 1.84 1.88 1.94 - 1.93 1.97 2.04 - 2.01 2.05 2.12 - 2.08 2.12 2.19 -
700 KW 1.58 1.61 1.66 - 1.69 1.73 1.78 - 1.80 1.83 1.89 - 1.89 1.93 1.99 - 1.96 2.00 2.07 - 2.03 2.07 2.14 -
900 KW 1.64 1.67 1.73 1.78 1.76 1.80 1.85 1.91 1.87 1.91 1.97 2.03 1.96 2.01 2.07 2.14 2.04 2.09 2.16 2.23 2.11 2.16 2.23 2.30
75 800 KW 1.63 1.66 1.71 1.77 1.75 1.79 1.84 1.90 1.85 1.89 1.95 2.02 1.95
700 KW 1.59 1.62 1.67 1.72 1.71 1.74 1.80 1.85 1.81 1.85 1.91 1.97 1.90 1.94 2.00 2.07 1.98 2.02 2.09 2.15 2.05 2.09 2.16 2.23
h and low pressures are measured at the liquid and suction service valves.
Shaded area is ACCA (TVA) conditions ID B: Entering Indoor Dry Bulb Temperature KW= Total system power AMPS=outdoor unit am ps (comp.+fan)
Hi
13
Loading...
+ 30 hidden pages
