•Refer to Service Manual RS6200006 for installation, operation, and troubleshooting information.
•All safety information must be followed as provided in the Service Manual.
•Refer to the appropriate Parts Catalog for part number information.
•Models listed on page 3.
This manual is to be used by qualified, professionally trained HVAC technicians
only. Goodman does not assume any responsibility for property damage or
personal injury due to improper service procedures or services performed by an
unqualified person.
The model number is used for positive identification of component parts used in manufacturing. Please use this number
when requesting service or parts information.
service procedures. If you install or perform service on
this unit, you assume responsibility for any personal
injury or property damage which may result. Many jurisdictions require a license to install or service heating and
air conditioning equipment.
2
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or
WARNING
HIGH VOLTAGE!
WARNING
WARNING
ments (at a minimum) of an "entry level technician", as
specified by the Air Conditioning, Heating, and Refrigeration Institute (AHRI). Attempting to install or repair this
unit without such background may result in product
damage, personal injury or death.
Installation and repair of this unit
should be performed
dividuals meeting the require-
ONLY by in-
PRODUCT IDENTIFICATION
The model number is used for positive identification of component parts used in manufacturing. Please use this number
when requesting service or parts information.
* Indicates minor revision & is not used for order entry or inventory management
WARNING
WARNING
WARNING
WARNING
property damage, personal injury, reduced unit performance and/or hazardous conditions may result from the
use of such non-approved devices.
The United States Environmental Protection Agency (“EPA”) has issued various regulations regarding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
Do not connect or use any device
that is not design certified by Goodman for use with this unit. Serious
WARNING
WARNING
als or use gasoline or other flammable liquids or vapors
in the vicinity of this appliance.
To prevent the risk of property
damage, personal injury, or death,
do not store combustible materi-
3
PRODUCT DESIGN
A
A
GSX/VSX13 models are available in 1 1/2 through 5 ton sizes
and use R-410A refrigerant. They are designed for 208/230
volt single phase applications.
Select GSX13 models are available in 208/230 and 460 volt
3-phase applications. These models use R-410A refrigerant.
The condenser air is pulled through the condenser coil by a
direct drive propeller fan. This condenser air is then discharged out of the top of the cabinet.
These units are designed for free air discharge, so no additional resistance like duct work shall be attached.
The suction and liquid line connections on present models
are of the sweat type for field piping with refrigerant type copper. Front seating valves are factory installed to accept the
field run copper. The total refrigerant charge for a normal installation is factory installed in the condensing unit. GSX/
VSX units are charged for the matching evaporator coil and a
15 foot refrigerant line set.
Systems should be properly sized by heat gain and loss
calculations made according to methods of the Air Conditioning Contractors Association (ACCA) or equivalent. It is
the contractors responsibility to ensure the system has adequate capacity to heat or cool the conditioned space.
GSX/VSX models use the Copeland Scroll "Ultratech" Series compressors which are specifically designed for R-410A
refrigerant. There are a number of design characteristics which
are different from the traditional reciprocating and/or scroll
compressors.
"Ultratech" Series scroll compressors will not have a discharge thermostat, some of the early model scroll compressors required discharge thermostats.
Due to their design Scroll compressors are inherently more
tolerant of small quantities of liquid refrigerant.
NOTE: Even though the compressor section of a Scroll compressor is more tolerant of liquid refrigerant, continued
floodback or flooded start conditions may wash oil from the
bearing surfaces causing premature bearing failure.
"Ultratech" Series scroll compressors use "POE" or
polyolester oil which is NOT compatible with mineral oil based
lubricants like 3GS. "POE" oil must be used if additional oil
is required.
Operating pressures and amp draws may differ from standard reciprocating and/or scroll compressors. This information may be found in the "Cooling Performance Data" section.
IMPORTANT NOTE: Because of the potential damage to
compressors, do not allow suction pressure at service valve
to drop below 20 PSIG when pumping unit system down for
repair. Outdoor section, depending on line set length and
amount of charge in system, may not be able to hold the
entire system charge.
4
WARNING
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
Special consideration must be given to location of the condensing unit(s) in regard to structures, obstructions, other
units, and any/all other factors that may interfere with air
circulation. Where possible, the top of the unit should be
completely unobstructed; however, if vertical conditions require placement beneath an obstruction there should be a
minimum of 60 inches between the top of the unit and
the obstruction(s). The specified dimensions meet require-
ments for air circulation only. Consult all appropriate regulatory codes prior to determining final clearances.
Another important consideration in selecting a location for
the unit(s) is the angle to obstructions. Either side adjacent
the valves can be placed toward the structure provided the
side away from the structure maintains minimum service clearance. Corner installations are strongly discouraged.
DO NOT locate the unit:
–Directly under a vent termination for a gas appliance.
–Within 3 feet of a clothes dryer vent.
–Where the refreezing of defrost water would create a
hazard.
–Where water may rise into the unit.
NOT
RECOMMENDED
BBB
AAAAA
C
AA
A
AA
AA
C
AA
CC
Minimum Airflow Clearance
Model Type
BCA
Residential10"10"18"20"
Light Commercial
12"12"18"24"
B
AA
OK!
OK!
OK!
OK!
OK!
OK!
PRODUCT DESIGN
DIMENSIONS
H
D
W
ModelDimensions - W x D x H
GSX130181A*26" x 26" x 32¼"
GSX130241A*26" x 26" x 32¼"
GSX130301A*26" x 26" x 32¼"
GSX130361A*29" x 29" x 32¼
GSX130421A*29" x 29" x 34¼"
GSX130481A*29" x 29" x 38¼"
GSX130601A*35½" x 35½" x 38¼"
GSX130181B*26" x 26" x 27½"
GSX130241B*26" x 26" x 27½"
GSX130301B*26" x 26" x 27½"
GSX130361B*
GSX130363A*
GSX130421B*29" x 29" x 36¼"
GSX130481B*
GSX130483A*
GSX130484A*
GSX130601B*
GSX130603A*
GSX130604A*
GSX130181C*26" x 26" x 27½"
29" x 29" x 28¾"
29" x 29" x 36¼"
29" x 29" x 40"
VSX130181A*26" x 26" x 27½"
VSX130241A*26" x 26" x 27½"
VSX130301A*26" x 26" x 27½"
VSX130361A*29" x 29" x 28¾"
VSX130421A*29" x 29" x 36¼"
VSX130481A*29" x 29" x 36¼"
VSX130181B*26" x 26" x 27½"
VSX130601B*29" x 29" x 40"
Open6 10 P S IG610 P S IG610 PSIG610 P SIG
Clos e4 20 P S IG420 P SIG42 0 P S IG420 PSI G
Condenser Fan Motor
Horsepower1/61/61/61/6
F.L . Amps1.101.101 .101.10
Liquid Line, Inches O.D.*3/8"3/8"3 /8"3/8"
Su ction Li ne, Inches O.D.*3/4"3/4"3/4"3/4"
Refrigerant Charge120.0116.0129.0131.0
Po wer Supply208/230- 60- 1208/230-60-1208/230- 60-1208/230-60-1
Minimum Circuit Ampacity
Maximum Over curr ent D evice
(1)
(2)
Electrical Conduit Size
Po wer Supply (Inches)1/2 or 3/ 41/2 or 3/41/2 o r 3/41/2 or 3/ 4
Open6 10 P S IG610 P S IG610 PSIG
Clos e4 20 P S IG420 P SIG42 0 P S IG
Condenser Fan Motor
Horsepower1/61/41/4
F.L . Amps1.101.501 .50
Liquid Line, Inches O.D.*3/8"3/8"3 /8"
Su ction Li ne, Inches O.D.*7/8"7/8"7/8"
Refrigerant Charge
151.0166.0184.0
Po wer Supply208/230- 60- 1208/230-60-1208/230- 60-1
Minimum Circuit Ampacity
Maximum Over curr ent D evice
(1)
(2)
23.
26.
404560
34.5
Electrical Conduit Size
Po wer Supply (Inches)1/2 or 3/ 41/2 or 3/41/2 o r 3/4
Approxi mate S hipping W ei gh t
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
219225240
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
6
CONDENSING UNIT SPECIFICATIONS
9
GSX130181B* GSX130241B* GSX130301B*
Coo li n g Cap aci ty , BT U H18 ,00024,0 0030, 0 0 0
Compressor
R.L. Am ps9.0013.512.8
L.R. Am ps48.058.364.0
High Pressure Switch
OpenN/AN/AN/A
CloseN/AN/AN/A
Co nd enser F a n M otor
Horsepower1 /61/61/6
F.L . Amps1.101.101.10
Liquid Line, In c hes O .D.*3/8"3/8"3/8"
Su ction Line, Inches O.D .*3/4"3/4"3/4"
Refrigeran t Charge72.079.081.0
Power Supply208/230-60-1208/230-60-1208/230-60-1
Minimum Circuit Ampacity
Maximum Ove rcurrent De vice
(1)
(2)
Electrical Conduit Size
Pow er Su pp ly (In c he s )1/ 2 or 3/ 41/ 2 or 3/41/ 2 or 3/4
App r o x imate Shi ppi ng Weight
12.418.017.1
203030
149151152
GSX130[18-60]1B*
GSX130361B* GSX130421B* GSX130481B* GSX130601B*
Coo li n g Cap aci ty , BT U H36 ,00042,0 0048, 0 0 060, 00 0
Compressor
R.L. Am ps16.7
17.
19.925.0
L.R. Am ps79.0112.0109.0134.0
High Pressure Switch
OpenN/AN/AN/AN/A
CloseN/AN/AN/AN/A
Co nd enser F a n M otor
Horsepower1 /61/41/41/4
F.L. Amps1.101.501.501.50
Liquid Line, In c hes O .D.*3/8"3/8"3/8"3/8"
Su ction Line, Inches O.D .*3/4"7/8"7/8"7/8"
Refrigeran t Charge92.0
124.0128.0125.0
Po wer Supply208/230-60-1208/230-60-1208/230-6 0- 1208/230-60 - 1
Minimum Circuit Ampacity
(1)
Maximum Ove rcurrent De vice
(2)
22.0
35
23.926.432.8
404550
Electrical Conduit Size
Power Supply (Inches)1/2 or 3/41/2 or 3/41/2 or 3/41/2 or 3/4
App r o x imate Shi ppi ng Weight
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
F.L . Am ps1.10
Liquid Line, Inc hes O.D.*3/8"
Su cti on Li ne, In ches O .D .*3/4"
Ref rigerant Charge71. 0
GSX130181C*
Po w er Supply20 8/230-60-1
Minimum Circuit Ampacity
(1)
Maximum Overcurrent De vice
(2)
9.5
15
Electrical Conduit Size
Power Supply (Inch es )1/2 or 3/4
Appr ox imate S hippi ng Weigh t
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
135
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
8
CONDENSING UNIT SPECIFICATIONS
GSX130[36-60][3,4]* *
GSX130363A* GSX130 483A* GS X 130484A* GSX130603A* GSX13 0604A *
Cooling Capaci ty, BTUH36,00048,00048,00060,00060,000
De c ibe ls7 476767777
Com pressor
R.L. A m ps10.4013.16.115.97.1
L.R. A m ps7 3.083.141.0110.052.0
TypeSc rollScrol lS crollScrol lScroll
Liqu id Line, Inches O .D .*3/8"3 /8"3/8"3 /8"3/8"
Su ction Li ne, In ches O .D .*7/8"1 1/8"1 1/8"1 1/8"1 1/8"
Liquid Val ve Connection, Inches O.D.*3/8"3 /8"3/8"3/8"3/8"
Su ction V al ve Connection, Inc hes O.D. *
Po wer S up ply2 08/23 0-60 -3 208 /230-6 0-3460 -60-3208/23 0-60 -3460-6 0-3
Minimum Circuit Ampacity
(1)
Maximum Overcurr ent Device
(2)
1 4.117.98.421. 49.7
2030153515
Mi n / Max Vol ts197 / 25319 7 / 253414 / 50619 7 / 25 34 14 / 506
Electrical Conduit Size
Po w er Supply (Inch es)1/2 or 3/41/2 or 3/41/2 or 3/41 /2 or 3/41/2 or 3/4
Approximate Shippi ng Weight196190189197196
4
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
(3)
Installer must supply a 3/4" to 7/8" adapter for suction line connections.
(4)
Installer must supply a 7/8" to 1 1/8" adapter for suction line connections.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
F.L. Amps1.101. 101.1 0
Li quid Line, Inches O .D .*3/8"3/8"3/8"
Suction Line, In ches O.D .*3/4"3/4"3/4"
Ref rigerant Charge72. 079.081.0
Po wer S upply20 8/ 230-60-1208/230- 60-12 08/230-60-1
Minimum Circuit Ampacity
Maximum Overcurrent De vice
Electrical Conduit Size
Powe r Su ppl y (I nches)1 / 2 or 3/41/2 or 3/41/2 or 3/4
F.L. Amps1.101. 501.5 0
Li quid Line, Inches O .D .*3/8"3/8"3/8"
Suction Line, In ches O.D .*3/4"7/8"7/8"
Ref rigerant Charge95. 0
124.0128.0
Po wer S upply20 8/ 230-60-1208/230- 60-12 08/230-60-1
Minimum Circuit Ampacity
(1)
Maximum Overcurrent De vice
(2)
21. 9
35
23. 926.3
4045
Electrical Conduit Size
Powe r Su ppl y (I nches)1 / 2 or 3/41/2 or 3/41/2 or 3/4
App r oxim ate S hi p ping We igh t
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
197194195
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
F.L. Amps1.101.50
Li quid Li ne, Inches O .D .*3/8"3/8"
Suct ion Li ne, Inches O .D.*3/4"1 1/8"
Ref rigerant Charge71. 0
Power Supply20 8/230- 60 - 1208/230-6 0- 1
Minimum Ci rcuit Amp acity
(1)
Maximum Overcurr ent D evice
(2)
9.5
15
Electrical Conduit Size
Power Sup p ly (Inches)1/2 or 3/ 41/2 or 3/4
Approxim ate Shipping Weight
135200
25. 0
125.0
26. 3
45
VSX130[18 & 60]1B*
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
