REPAIR PARTS
GSC130181AB
GSC130181CA
GSC130241AB
GSC130301AB
GSC130361BB
GSC130361DA
GSC130361DB
GSC130361DF
GSC130361EA
GSC130361EB
GSC130363AB
GSC130363AC
GSC130421AB
GSC130481AB
GSC130481AC
GSC130483AB
GSC130483AC
GSC130484AB
GSC130601BB
GSC130601BC
GSC130603AB
GSC130603AC
GSC130604AB
GSC130604AC
GSC13
Remote Condensing Units
This manual is to be used by qualified technicians only.
© 2006-2009 Goodman Manufacturing Company, L.P. ◊ 5151 San Felipe, Suite 500 ◊ Houston, TX 77056
RP-431G
www.goodmanmfg.com www.amana-hac.com
This manual replaces RP-431F.
June 2009
Important Information
Index
Functional Parts List
Illustration and Parts
Views shown are for parts illustrations only, not servicing procedures.
Rev. G: Added missing motor for GSC130361EB.
08/19/09: Changed compressor for GSC130181CA from ZR16K4PFV930 to H21J383ABCAS.
Text Codes:
AR - As Required
NA - Not Available
NS - Not Shown
00000000 - See Note
QTY - Quantity Example (QTY 3) (If Quantity not shown, Quantity = 1)
M - Model Example (M1) (If M Code not shown, then part is used on all Models)
Expanded Model Nomenclature:
Example
M1 - Model#1
M2 - Model#2
M3 - Model#3
...................................................................................................
...................................................................................................
3
4 - 9
Goodman Manufacturing Company, L.P. is not responsible for personal injury or property damage resulting from
improper service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is
required after the warranty expires, Goodman Manufacturing Company, L.P. also recommends contacting an
authorized technician and using authorized factory parts.
Goodman Manufacturing Company, L.P. reserves the right to discontinue, or change at any time, specifications
or designs without notice or without incurring obligations.
For assistance within the U.S.A. contact:
Consumer Affairs Department
Goodman Manufacturing Company, L.P.
7401 Security Way
Houston, Texas 77040
877-254-4729-Telephone
713-863-2382-Facsimile
2
www.goodmanmfg.com www.amana-hac.com
For assistance outside the U.S.A. contact:
International Division
International Division
Goodman Manufacturing Company, L.P.
Goodman Company, L.P.
7401 Security Way
7401 Security Way
Houston, Texas 77040
Houston, Texas 77040
713-861-2500-Telephone
713-861-2500-Telephone
713-863-2382-Facsimile
713-863-2382-Facsimile
RP-431G
Functional Parts
Part
No:
Description:
CAP050350440RSS CAPACITOR 5/35/440V [CONTROL BOX] (M1,
M2, M3, M6, M7, M8, M9, M10)
CAP050000370VAS CAPACITOR 5/370V (M11, M12, M16, M17,
M18, M21, M22, M23, M24)
CAP050400370RSS CAPACITOR 5/40/370V [CONTROL BOX] (M4)
CAP050450370RSS CAPACITOR 5/45/370V [CONTROL BOX] (M5)
CAP050500440RTS CAPACITOR 5/50/440V (M13)
CAP050550440RTS CAPACITOR 5/55/440V (M14, M15)
CAP050800440RTS CAPACITOR 5/80/440V [CONTROL BOX]
(M19, M20)
CR14K7PFV970 COMPRESSOR 14100, 208/230/6 0/1 (M 1)
ZR16K4PFV930 COMPRESSOR 16500, 208/230/ 60/ 1 (M2 )
CR18K7PFV930 COMPRESSOR 17500, 208/230/6 0/1 (M 3)
CR23K7PFV930 COMPRESSOR 22600, 208/230/6 0/1 (M 4)
CR28K7TF5970 COMPRESSOR 28000, 200/230/60/3 (M11,
M12)
CR28K7PFV930 COMPRESSOR 28300, 208/230/60/1 (M6, M7)
ZR30K3PFV930 COMPRESSOR 31100, 208/230/ 60/ 1 (M5 )
ZR34K3PFV930 COMPRESSOR 34400, 208/230/ 60/ 1 (M1 3)
ZR40K3PFV930 COMPRESSOR 40600, 208/230/ 60/ 1 (M1 4,
M15)
ZR40K3TF5930 COMPRESSOR 40600, 208/230/60/3 (M16,
M17)
ZR40K3TFD930 COMPRESSOR 40600, 460/60/3 (M18)
ZR52K3PFV930 COMPRESSOR 52000, 208/230/ 60/ 1 (M1 9,
M20)
ZR54K3TF5930 COMPRESSOR 54200, 200/230/60/3 (M21,
M22)
ZR54K3TFD930 COMPRESSOR 54500, 460/60/3 (M23, M24)
H20J293ABCAS COMPRESSOR, BRISTOL (M8, M9, M10 )
0131M00018PS COND MOTOR 1/4 HP, 1 SP, 6 PL (M13)
0131M00007PS COND MOTOR 1/4 HP, 1 SP, 6 PL (M5, M11,
M14, M16)
0131M00014PS COND MOTOR 1/4 HP, 1 SP, 8 PL (M15, M17)
0131M00022S COND MOTOR 1/4 HP, 8 PL, 460V (M18)
0131M00012PS COND MOTOR 1/6 HP, 1 SP, 8 PL (M19, M20,
M21, M22)
0131M00060S COND MOTOR 1/6 HP, 1 SP, 8 PL (M1, M2,
M3, M4, M6, M7, M8, M9, M10, M12)
0131M00023S COND MOTOR 1/6 HP, 8 PL, 460V (M23, M24)
CONT2P025024VS CONTACTOR 25 AMP, 2P, 24V (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M13)
CONT3P025024VS CONTACTOR 25 AMP, 3P, 24V (M11, M12,
M16, M17, M18, M21, M22, M23, M24)
CONT2P030024VS CONTACTOR 30 AMP, 2P, 24V (M14, M15)
CONT2P040024VS CONTACTOR 40 AMP, 2P, 24V (M19, M20)
SPECIAL PARTS
IO-258F INSTALLATION INSTRUCTIONS (M2, M8,
M20, M22, M24)
0161R00009P NAMEPLATE
RP-431G REPAIR PARTS MANUAL
Expanded Model Nomenclature
M1 - GSC130181AB
M2 - GSC130181CA
M3 - GSC130241AB
M4 - GSC130301AB
M5 - GSC130361BB
M6 - GSC130361DA
M7 - GSC130361DB
M8 - GSC130361DF
M9 - GSC130361EA
M10 - GSC130361EB
M11 - GSC130363AB
M12 - GSC130363AC
M13 - GSC130421AB
M14 - GSC130481AB
M15 - GSC130481AC
M16 - GSC130483AB
M17 - GSC130483AC
M18 - GSC130484AB
M19 - GSC130601BB
M20 - GSC130601BC
M21 - GSC130603AB
M22 - GSC130603AC
M23 - GSC130604AB
M24 - GSC130604AC
RP-431G
www.goodmanmfg.com
www.amana-hac.com
3
Control Cover/Control Box
G
4
www.goodmanmfg.com www.amana-hac.com
RP-431
Control Cover/Control Box
Ref.
Part
No:
No:
Image 1:
4400202PDG11
4400205PDG11
CONT2P025024VS71
CONT3P025024VS71
CAP050350440RSS81
CAP050000370VAS81
CAP050800440RTS81
Description:
LOWER ACCESS PANEL (M2)0121R00094PDG11
LOWER ACCESS PANEL (M1)4400200PDG11
LOWER ACCESS PANEL (M6, M7, M8, M11, M12,
M13)
LOWER ACCESS PANEL (M3, M4, M5, M9, M10)4400203PDG11
LOWER ACCESS PANEL (M14, M15, M16, M17,
M18, M19, M20, M21, M22, M23, M24)
CONTROL COVER 0121R00053PDG21
CONTACTOR 25 AMP, 2P, 24V (M1, M2, M3, M4,
M5, M6, M7, M8, M9, M10, M13)
CONTACTOR 25 AMP, 3P, 24V (M11, M12, M16,
M17, M18, M21, M22, M23, M24)
CONTACTOR 30 AMP, 2P, 24V (M14, M15)CONT2P030024VS71
CONTACTOR 40 AMP, 2P, 24V (M19, M20)CONT2P040024VS71
CAPACITOR 5/35/440V [CONTROL BOX] (M1, M2,
M3, M6, M7, M8, M9, M10)
CAPACITOR 5/370V (M11, M12, M16, M17, M18,
M21, M22, M23, M24)
CAPACITOR 5/40/370V [CONTROL BOX] (M4)CAP050400370RSS81
CAPACITOR 5/45/370V [CONTROL BOX] (M5)CAP050450370RSS81
CAPACITOR 5/50/440V (M13)CAP050500440RTS81
CAPACITOR 5/55/440V (M14, M15)CAP050550440RTS81
CAPACITOR 5/80/440V [CONTROL BOX] (M19,
M20)
CAPACITOR STRAP 440006591
NAMEPLATE 0161R00009PNS
Ref.
Part
No:
No:
Description:
Expanded Model Nomenclature
M1 - GSC130181AB
M2 - GSC130181CA
M3 - GSC130241AB
M4 - GSC130301AB
M5 - GSC130361BB
M6 - GSC130361DA
M7 - GSC130361DB
M8 - GSC130361DF
M9 - GSC130361EA
M10 - GSC130361EB
M11 - GSC130363AB
M12 - GSC130363AC
M13 - GSC130421AB
M14 - GSC130481AB
M15 - GSC130481AC
M16 - GSC130483AB
M17 - GSC130483AC
M18 - GSC130484AB
M19 - GSC130601BB
M20 - GSC130601BC
M21 - GSC130603AB
M22 - GSC130603AC
M23 - GSC130604AB
M24 - GSC130604AC
RP-431G
www.goodmanmfg.com
www.amana-hac.com
5
Compressor/Tubing Assembly
G
6
www.goodmanmfg.com www.amana-hac.com
RP-431
Compressor/Tubing Assembly
Ref.
Part
No:
No:
Image 1:
0151R00002P31
0151R00003P31
B133953061
B133953361
B1219212131
B1219225131
0121R00006PDG141
NS
B1789874NS
B1789882NS
Image 2:
Description:
3/8” SERVICE VALVE B1282517121
3/4" SERVICE VALVE OPEN LEFT (M1, M2, M3,
M4, M5, M6, M7, M8, M9, M10, M11, M12)
7/8" SERVICE VALVE OPEN LEFT (M13, M14, M15,
M16, M17, M18, M19, M20, M21, M22, M23, M24)
COMPRESSOR 14100, 208/230/60/1 (M1)CR14K7PFV97051
COMPRESSOR 16500, 208/230/60/1 (M2)ZR16K4PFV93051
COMPRESSOR 17500, 208/230/60/1 (M3)CR18K7PFV93051
COMPRESSOR 22600, 208/230/60/1 (M4)CR23K7PFV93051
COMPRESSOR 28000, 200/230/60/3 (M11, M12)CR28K7TF597051
COMPRESSOR 28300, 208/230/60/1 (M6, M7)CR28K7PFV93051
COMPRESSOR 31100, 208/230/60/1 (M5)ZR30K3PFV93051
COMPRESSOR 34400, 208/230/60/1 (M13)ZR34K3PFV93051
COMPRESSOR 40600, 208/230/60/1 (M14, M15)ZR40K3PFV93051
COMPRESSOR 40600, 208/230/60/3 (M16, M17)ZR40K3TF593051
COMPRESSOR 40600, 460/60/3 (M18)ZR40K3TFD93051
COMPRESSOR 52000, 208/230/60/1 (M19, M20)ZR52K3PFV93051
COMPRESSOR 54200, 200/230/60/3 (M21, M22)ZR54K3TF593051
COMPRESSOR 54500, 460/60/3 (M23, M24)ZR54K3TFD93051
COMPRESSOR GROMMET (M1, M3, M4, M6, M7,
M8, M9, M10, M12)
COMPRESSOR GROMMET (M5, M11, M13, M14,
M15, M16, M17, M18, M19, M20, M21, M22, M23,
M24)
COMPRESSOR GROMMET-PANASONIC (M2)0164M00000P61
TF SHOULDER SCREW (QTY 4)M022164171
SINGLE-FLOW FILTER DRIER, STEEL (M1, M2,
M3, M4, M5, M6, M7, M8, M9, M10, M11, M12)
SINGLE-FLOW FILTER DRIER, STEEL (M13, M14,
M15, M16, M17, M18, M19, M20, M21, M22, M23,
M24)
BASE PAN 26" (M1, M2, M3)0121R00005PDG141
BASE PAN 29" (M4, M5, M6, M7, M8, M9, M10,
M11, M12, M13, M14, M15, M16, M17, M18)
BASE PAN 35" (M19, M20, M21, M22, M23, M24)0121R00007PDG141
COMPRESSOR SCROLL HARNESS (M13)0159R00002PNS
FLOW CHECK PISTON KIT .055 (M1, M2)B1789855NS
FLOW CHECK PISTON KIT .059 (M3)B1789859NS
FLOW CHECK PISTON KIT .065 (M4)B1789865
FLOW CHECK PISTON KIT .071 (M5)B1789871NS
FLOW CHECK PISTON KIT .074 (M6, M7, M9, M10,
M11, M12)
FLOW CHECK PISTON KIT .078 (M13)B1789878NS
FLOW CHECK PISTON KIT .082 (M14, M15, M16,
M17, M18)
FLOW CHECK PISTON KIT .093 (M19, M21, M23)B1789893NS
MUFFLER 1/2 X 1/2 (M8, M9, M10)B121930132
COMPRESSOR, BRISTOL (M8, M9, M10)H20J293ABCAS52
Ref.
Part
No:
No:
Description:
Expanded Model Nomenclature
M1 - GSC130181AB
M2 - GSC130181CA
M3 - GSC130241AB
M4 - GSC130301AB
M5 - GSC130361BB
M6 - GSC130361DA
M7 - GSC130361DB
M8 - GSC130361DF
M9 - GSC130361EA
M10 - GSC130361EB
M11 - GSC130363AB
M12 - GSC130363AC
M13 - GSC130421AB
M14 - GSC130481AB
M15 - GSC130481AC
M16 - GSC130483AB
M17 - GSC130483AC
M18 - GSC130484AB
M19 - GSC130601BB
M20 - GSC130601BC
M21 - GSC130603AB
M22 - GSC130603AC
M23 - GSC130604AB
M24 - GSC130604AC
RP-431G
www.goodmanmfg.com
www.amana-hac.com
7
Coil/Cabinet Top/Side Panels
G
8
www.goodmanmfg.com www.amana-hac.com
RP-431
Coil/Cabinet Top/Side Panels
Ref.
Part
No:
No:
Image 1:
0121R00010PDG11
0131M00007PS21
0131M00012PS21
0131M00060S21
0150M00008S51
10625738S51
0161R00007P61
0121R00025PDGB111
0121R00027PDGB111
0121R00043PDGB111
0121R00031PDGB121
0121R00033PDGB121
0121R00047PDGB121
Description:
TOP PANEL 26" (M1, M2, M3)0121R00008PDG11
TOP PANEL 29" (M4, M5, M6, M7, M8, M9, M10,
M11, M12, M13, M14, M15, M16, M17, M18)
TOP PANEL 35" (M19, M20, M21, M22, M23, M24)0121R00012PDG11
COND MOTOR 1/4 HP, 1 SP, 6 PL (M5, M11, M14,
M16)
COND MOTOR 1/4 HP, 1 SP, 6 PL (M13)0131M00018PS21
COND MOTOR 1/4 HP, 1 SP, 8 PL (M15, M17)0131M00014PS21
COND MOTOR 1/4 HP, 8 PL, 460V (M18)0131M00022S21
COND MOTOR 1/6 HP, 1 SP, 8 PL (M19, M20, M21,
M22)
COND MOTOR 1/6 HP, 1 SP, 8 PL (M1, M2, M3,
M4, M6, M7, M8, M9, M10, M12)
COND MOTOR 1/6 HP, 8 PL, 460V (M23, M24)0131M00023S21
ACORN NUT 5/16 HEX BLACK (QTY 4)0163M00006P41
FAN BLADE 20" (M1, M3)0150M00018S51
FAN BLADE 20" CCW (M2)0150M00012S51
FAN BLADE 22" (M5, M11)0150M00007S51
FAN BLADE 22" (M13, M14, M16)B1086775S51
FAN BLADE 22" TNT2203-25 (M4, M6, M7, M8, M9,
M10, M12, M18)
FAN BLADE 26" ALUM CCW (M19, M20, M21, M22,
M23, M24)
FAN BLADE TYPE 3 (M15, M17)B1086765S51
VENTURI RING 22" (M14, M15, M16, M17, M18)0161L0000061
VENTURI RING 35" (M19, M20, M21, M22, M23,
M24)
LOUVERED SIDE PANEL (M1)0121R00014PDGB111
LOUVERED SIDE PANEL (M3)0121R00016PDGB111
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00026PDGB111
LOUVERED SIDE PANEL (M2)0121R00102PDGB111
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
LOUVERED SIDE PANEL (M1)0121R00017PDGB121
LOUVERED SIDE PANEL (M3)0121R00019PDGB121
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00032PDGB121
LOUVERED SIDE PANEL (M2)0121R00109PDGB121
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
LOUVERED SIDE PANEL (M1)0121R00020PDG131
LOUVERED SIDE PANEL (M3)0121R00022PDG131
Ref.
Part
No:
No:
Description:
Image 1:
0121R00037PDG131
0121R00039PDG131
0121R00051PDG131
1362104141
1362105141
1362106141
0161R00003PNS
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00038PDG131
LOUVERED SIDE PANEL (M2)0121R00116S131
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
TUBING ASSY, COND COIL (M2)0201R00177S141
TUBING ASSY, COND COIL (M1)1362100141
TUBING ASSY, COND COIL (M3)1362101141
TUBING ASSY, COND COIL (M4, M5, M9, M10)1362103141
TUBING ASSY, COND COIL (M6, M7, M8, M11,
M12, M13)
TUBING ASSY, COND COIL (M14, M15, M16, M17,
M18)
TUBING ASSY, COND COIL (M19, M20, M21, M22,
M23, M24)
CONDUIT (M1, M2, M3)0161R00001PNS
CONDUIT (M14, M15, M16, M17, M18)0161R00002PNS
CONDUIT (M4, M5, M6, M7, M8, M9, M10, M11,
M12, M13)
CONDUIT (M19, M20, M21, M22, M23, M24)0161R00004PNS
Expanded Model Nomenclature
M1 - GSC130181AB
M2 - GSC130181CA
M3 - GSC130241AB
M4 - GSC130301AB
M5 - GSC130361BB
M6 - GSC130361DA
M7 - GSC130361DB
M8 - GSC130361DF
M9 - GSC130361EA
M10 - GSC130361EB
M11 - GSC130363AB
M12 - GSC130363AC
M13 - GSC130421AB
M14 - GSC130481AB
M15 - GSC130481AC
M16 - GSC130483AB
M17 - GSC130483AC
M18 - GSC130484AB
M19 - GSC130601BB
M20 - GSC130601BC
M21 - GSC130603AB
M22 - GSC130603AC
M23 - GSC130604AB
M24 - GSC130604AC
RP-431G
www.goodmanmfg.com
www.amana-hac.com
9
Loading...
