REPAIR PARTS

GPH1424H41AB GPH1430H41AB GPH1436H41AB GPH1442H41AB GPH1448H41AB GPH1460H41AB

GPH14 H-Series

Package Heat Pumps

This manual is to be used by qualified technicians only.

RP-631

www.goodmanmfg.com www.amana-hac.com

September 2010

Important Information Index

Functional Parts List

Illustration and Parts

Views shown are for parts illustrations only, not servicing procedures.

Text Codes:

AR - As Required NA - Not Available NS - Not Shown 00000000 - See Note QTY - Quantity Example (QTY 3) (If Quantity not shown, Quantity = 1) M - Model Example (M1) (If M Code not shown, then part is used on all Models)

Expanded Model Nomenclature:

Example M1 - Model#1 M2 - Model#2 M3 - Model#3

...................................................................................................

4 - 11

Goodman Manufacturing Company, L.P. is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs.

Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Goodman Manufacturing Company, L.P. also recommends contacting an authorized technician and using authorized factory parts.

Goodman Manufacturing Company, L.P. reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations.

For assistance within the U.S.A. contact: Consumer Affairs Department

Goodman Manufacturing Company, L.P. 7401 Security Way Houston, Texas 77040 877-254-4729-Telephone 713-863-2382-Facsimile

www.goodmanmfg.com www.amana-hac.com

For assistance outside the U.S.A. contact:

International Division

International Division Goodman Manufacturing Company, L.P.

Goodman Company, L.P. 7401 Security Way

7401 Security Way Houston, Texas 77040

Houston, Texas 77040 713-861-2500-Telephone

713-861-2500-Telephone 713-863-2382-Facsimile

713-863-2382-Facsimile

RP-631

Functional Parts

Part No:

Description:

0131M00207 BLOWER MOTOR 1/2 HP PROGRAMMED

(M1)

0131M00208 BLOWER MOTOR 1/2 HP PROGRAMMED

(M2)

0131M00209 BLOWER MOTOR 1/2 HP PROGRAMMED

(M3)

0131M00210 BLOWER MOTOR 1/2 HP PROGRAMMED

(M4)

0131M00211 BLOWER MOTOR 3/4 HP PROGRAMMED

(M6)

0131M00206 BLOWER MOTOR 3/4 HP PROGRAMMED

(M5) B1368016S BLOWER WHEEL 10 X 8 (M1, M2, M3, M4, M5) B1368054 BLOWER WHEEL 11 X 8 (M6) CAP050400440RT CAPACITOR 5/40/440V (M1, M2) CAP050450440RT CAPACITOR 5/45/440V (M3, M4, M5) CAP050700440RTS CAPACITOR 5/70/440V (M6) ZP21K5EPFV830 COMPRESSOR 21300, 208/230/60/1 (M1) ZP25K5EPFV830 COMPRESSOR 25200, 208/230/60/1 (M2) ZP31K5EPFV830 COMPRESSOR 31100, 208/230/60/1 (M3) ZP34K5EPFV130 COMPRESSOR 34500, 208/230/60/1 (M4) ZP39K5EPFV830 COMPRESSOR 39000, 208/230/60/1 (M5) ZP51K5EPFV830 COMPRESSOR 51000, 208/230/60/1 (M6) 0131M00007PS COND MOTOR 1/4 HP, 1 SP, 6 PL (M4, M5,

M6) 0131M00061S COND MOTOR 1/4 HP, 1 SP, 8 PL (M3) 0131M00009P COND MOTOR, 1/6 HP, 1 SP, 8 PL (M1, M2) CONT1P025024VS CONTACTOR 25 AMP, 1P, 24V (M1, M2, M3) CONT1P030024VS CONTACTOR 30 AMP, 1P, 24V (M4, M5) CONT2P040024VS CONTACTOR 40 AMP, 2P, 24V (M6) 0230G00005 CRANKCASE HEATER SWITCH (M6) PCBDM133 DEFROST CONTROL BOARD 0130M00057 DEFROST THERMOSTAT (M1, M2, M3, M5) 0130M00009P DEFROST THERMOSTAT OPEN 60º, CLOSE

34º (M4, M6) 0150G00001S FAN BLADE (M4, M5, M6) 0150G00005 FAN BLADE (M1, M2) B1086765 FAN BLADE, TYPE 3 (M3) 0163R00003 HEATER, CRANKCASE 230V 40W (M6) 0130M00074 HIGH PRESSURE SWITCH 0130M00075 LOW PRESSURE SWITCH 0151M00019 REVERSING VALVE (M1, M2) 0151M00021 REVERSING VALVE (M3, M4, M5, M6) B1225022S SOLENOID COIL B1141643 TRANSFORMER 208/230, 24V

SPECIAL PARTS

IO-398 I&O B1757910 SUPPLEMENTAL INSERT (EBTDR)

Expanded Model Nomenclature

M1 - GPH1424H41AB M2 - GPH1430H41AB M3 - GPH1436H41AB M4 - GPH1442H41AB M5 - GPH1448H41AB M6 - GPH1460H41AB

RP-631

www.goodmanmfg.com

www.amana-hac.com

Cabinet Assembly

www.goodmanmfg.com

www.amana-hac.com

RP-631

Cabinet Assembly

Ref.

Part

No:

Image 1:

Expanded Model Nomenclature

M1 - GPH1424H41AB M2 - GPH1430H41AB M3 - GPH1436H41AB M4 - GPH1442H41AB M5 - GPH1448H41AB M6 - GPH1460H41AB

Description:

INSULATED ASSY, DUCT PANEL 27.5" (M1, M2)0270G00008PS11 INSULATED ASSY, DUCT PANEL 32.5" (M3, M4)0270G00009PS11 INSULATED ASSY, DUCT PANEL 36" (M5, M6)0270G00010PS11 INSULATED ASSY, CORNER PANEL 27.5" (M1, M2)0270G00011PS21 INSULATED ASSY, CORNER PANEL 32.5" (M3, M4)0270G00012PS21 INSULATED ASSY, CORNER PANEL 36" (M5, M6)0270G00013PS21 CORNER POST 27.5" (M1, M2)0121G00047PDGS31 CORNER POST 32.5" (M3, M4)0121G00048PDGS31 CORNER POST 36" (M5, M6)0121G00082PDG31 INSULATED ASSY, BLOWER DOOR 27.5" (M1, M2)0270G00113S41 INSULATED ASSY, BLOWER DOOR 32.5" (M3, M4)0270G00114S41 INSULATED ASSY, BLOWER DOOR 36" (M5, M6)0270G00115S41 EXTERNAL CONTROL BOX PANEL 0121G00276DGS51 LOUVERED PANEL 4 BANK 27.5" (M1, M2)0121G00069PDGS61 LOUVERED PANEL 4 BANK 32.5" (M3, M4)0121G00070PDG61 LOUVERED PANEL 4 BANK 36" (M5, M6)0121G00090PDGS61 LOUVERED PANEL 5 BANK 27.5" (M1, M2)0121G00072PDG71 LOUVERED PANEL 5 BANK 32.5" (M3, M4)0121G00073PDGS71 LOUVERED PANEL 5 BANK 36" (M5, M6)0121G00091PDGS71 EVAP PANEL INSUL ASSY-27.5" (M1, M2)0270G00017P81 EVAP PANEL INSUL ASSY-32.5" (M3, M4)0270G00018P81 EVAP PANEL INSUL ASSY-36" (M5, M6)0270G00019P81 GROMMET / HS .62 - .45 B139201191 COMPRESSOR PANEL 13.68" X 27.50" (M1, M2)0121G00062PDGS101 COMPRESSOR PANEL 8.75" X 32.50" (M3, M4)0121G00060PDGS101 COMPRESSOR PANEL 8.75" X 36" (M5, M6)0121G00087PDGS101 LOUVERED PANEL 4 BANK 27.5" (M1, M2)0121G00069PDGS121 LOUVERED PANEL 5 BANK 32.5" (M3, M4)0121G00073PDGS121 LOUVERED PANEL 5 BANK 36" (M5, M6)0121G00091PDGS121 BASEPAN RAIL (QTY 2)0121G00044PRF131

Ref. No:

Part No:

Description:

RP-631

www.goodmanmfg.com

www.amana-hac.com

Chassis Assembly

www.goodmanmfg.com

www.amana-hac.com

RP-631

Chassis Assembly

Ref.

Part

No:

Image 1:

0270G0007521

0270G0007621

0270G0007721

121

Description:

TUBING ASSY, COND COIL (M4)0201G00123S11 TUBING ASSY, COND COIL (M3)0201G00126S11 TUBING ASSY, COND COIL (M5)0201G0014511 TUBING ASSY, COND COIL (M2)0201G0015011 TUBING ASSY, COND COIL (M6)0201G0015611 TUBING ASSY, COND COIL (M1)0201G0016011 INSULATED ASSY, PARTITION PANEL 27.5" (M1,

M2) INSULATED ASSY, PARTITION PANEL 32.5" (M3,

M4) INSULATED ASSY, PARTITION PANEL 36" (M5,

M6) TUBING ASSY, EVAP COIL (M3)0202G00271S31 TUBING ASSY, EVAP COIL (M2)0202G0029831 TUBING ASSY, EVAP COIL (M1)0202G0030031 TUBING ASSY, EVAP COIL (M6)0202G0030231 TUBING ASSY, EVAP COIL (M5)0202G0030531 TUBING ASSY, EVAP COIL (M4)0202G0030731 REVERSING VALVE (M1, M2)0151M0001941 REVERSING VALVE (M3, M4, M5, M6)0151M0002141 HIGH PRESSURE SWITCH 0130M0007451 BI-FLOW FILTER DRIER B121920461 DRAIN PAN ASSY 0270G00004PS71 LOW PRESSURE SWITCH 0130M0007581 POST 27.5" (M1, M2)0121G00045P91 POST 32.5" (M3, M4)0121G00079P91 POST 36" (M5, M6)0121G00083P91 ACCUMULATOR (M1, M2)B1226206101 ACCUMULATOR .875 (M3, M4, M5, M6)B1226207101 COMPRESSOR GROMMET (QTY 4)B1339533111 COMPRESSOR 21300, 208/230/60/1 (M1)ZP21K5EPFV830121 COMPRESSOR 25200, 208/230/60/1 (M2)ZP25K5EPFV830121 COMPRESSOR 31100, 208/230/60/1 (M3)ZP31K5EPFV830121 COMPRESSOR 34500, 208/230/60/1 (M4)ZP34K5EPFV130121 COMPRESSOR 39000, 208/230/60/1 (M5)ZP39K5EPFV830121 COMPRESSOR 51000, 208/230/60/1 (M6)ZP51K5EPFV830 FLOWRATOR .057 [EVAP] (M1)0162M00111S131 FLOWRATOR .065 [EVAP] (M2)0162M00018PS131 FLOWRATOR .068 [EVAP] (M3)0162M00053131 FLOWRATOR .072 [EVAP] (M4)0162M00109S131 FLOWRATOR .076 [EVAP] (M5)0162M00019P131 FLOWRATOR .088 [EVAP] (M6)0162M00093131 INSULATED ASSY, BASEPAN 0273G00001P141 TF SHOULDER SCREW (QTY 4)M0221641211 CRANKCASE HEATER SWITCH (M6)0230G00005221 HEATER, CRANKCASE 230V 40W (M6)0163R00003231

Ref.

Part

No:

Description:

Image 1:

COMPRESSOR SCROLL HARNESS 0159G00004NS EVAP DRIP SHIELD 0121G00043PNS SOLENOID COIL B1225022SNS

Image 2:

FLOWRATOR .047 [COND] (M2)0162M00021P22 FLOWRATOR .049 [COND] (M1)0162M00112S22 FLOWRATOR .065 [COND] (M3, M4, M5)0162M00098S22 FLOWRATOR .071 [COND] (M6)0162M00012P22 DEFROST THERMOSTAT (M1, M2, M3, M5)0130M00057102

0130M00009P102

DEFROST THERMOSTAT OPEN 60º, CLOSE 34º (M4, M6)

Image 3:

PROCESS TUBE ASSY - SUCTION 0201G00031P13 PROCESS TUBE ASSY - LIQUID 0201G00030P23 ACCESS FITTING BOX 0161G00001P33 ACCESS FITTING (QTY 2)B137331543 FASTEST FITTING NUT (QTY 2)0163G00000P53 CAP W/O-RING (QTY 2)B910209763

Expanded Model Nomencla t u r e

M1 - GPH1424H41AB M2 - GPH1430H41AB M3 - GPH1436H41AB M4 - GPH1442H41AB M5 - GPH1448H41AB M6 - GPH1460H41AB

RP-631

www.goodmanmfg.com

www.amana-hac.com

Top Panel and Control Box Assembly

www.goodmanmfg.com

www.amana-hac.com

RP-631

Top Panel and Control Box Assembly

Ref.

Part

No:

Image 1:

Image 2:

Expanded Model Nomenclature

M1 - GPH1424H41AB M2 - GPH1430H41AB M3 - GPH1436H41AB M4 - GPH1442H41AB M5 - GPH1448H41AB M6 - GPH1460H41AB

Description:

INSULATED ASSY, TOP PANEL 0274G0003711 FAN BLADE (M4, M5, M6)0150G00001S21 FAN BLADE (M1, M2)0150G0000521 FAN BLADE, TYPE 3 (M3)B108676521 COND MOTOR 1/4 HP, 1 SP, 6 PL (M4, M5, M6)0131M00007PS31 COND MOTOR 1/4 HP, 1 SP, 8 PL (M3)0131M00061S31 COND MOTOR, 1/6 HP, 1 SP, 8 PL (M1, M2)0131M00009P31 FAN GRILLE 0152G00002S41 SMALL SCREW (QTY 6)M022181761 ACORN NUT 5/16 HEX BLACK (QTY 4)0163M00006P71 PVC CONDUIT 8.25" 17788000083FNS

DEFROST CONTROL BOARD PCBDM13312 TRANSFORMER 208/230, 24V B114164332 CONTACTOR 25 AMP, 1P, 24V (M1, M2, M3)CONT1P025024VS42 CONTACTOR 30 AMP, 1P, 24V (M4, M5)CONT1P030024VS42 CONTACTOR 40 AMP, 2P, 24V (M6)CONT2P040024VS42 CAPACITOR 5/40/440V (M1, M2)CAP050400440RT52 CAPACITOR 5/45/440V (M3, M4, M5)CAP050450440RT52 CAPACITOR 5/70/440V (M6)CAP050700440RTS52 CAPACITOR STRAP 2052090162 WIRE HARNESS, ELECTRIC HEAT 0259G00003NS

Ref. No:

Part No:

Description:

RP-631

www.goodmanmfg.com

www.amana-hac.com

Blower Assembly

www.goodmanmfg.com

www.amana-hac.com

RP-631

Blower Assembly

Ref.

Part

No:

Image 1:

Expanded Model Nomenclature

M1 - GPH1424H41AB M2 - GPH1430H41AB M3 - GPH1436H41AB M4 - GPH1442H41AB M5 - GPH1448H41AB M6 - GPH1460H41AB

Description:

BLOWER HOUSING 10 X 8 (M1, M2, M3, M4, M5)1032424811 BLOWER HOUSING 11 X 8 (M6)0271G0001711 BLOWER MOTOR 1/2 HP PROGRAMMED (M1)0131M0020721 BLOWER MOTOR 1/2 HP PROGRAMMED (M2)0131M0020821 BLOWER MOTOR 1/2 HP PROGRAMMED (M3)0131M0020921 BLOWER MOTOR 1/2 HP PROGRAMMED (M4)0131M0021021 BLOWER MOTOR 3/4 HP PROGRAMMED (M5)0131M0020621 BLOWER MOTOR 3/4 HP PROGRAMMED (M6)0131M0021121 BLOWER WHEEL 10 X 8 (M1, M2, M3, M4, M5)B1368016S31 BLOWER WHEEL 11 X 8 (M6)B136805431 HEATER KIT COVER 0121G00039PS61 BLOWER SUPPORT 0121G00040P91 MOTOR MOUNT BAND 0121M00038161 MOTOR MOUNT ARM (M1, M2, M3, M4, M5)B1376853171 MOTOR MOUNT ARM (M6)B1376857171 MACHINE SCREW HWH 1/4-20 X 1-1/2 BZ B1393323201 TC SCREW 1.25" (QTY 3)M0250565211 LOCKNUT, NYLON, INSERT 1/4, 20 B1393800221 BLOWER CUT-OFF (M1, M2, M3, M4, M5)C6121810NS BLOWER CUT-OFF 11 X 8 (M6)2964700NS

Ref. No:

Part No:

Description:

RP-631

www.goodmanmfg.com

www.amana-hac.com

THIS PAGE INTENTIONALLY LEFT BLANK
