PRODUCT SPECIFICATIONS

GPC13M

AIRE ACONDICIONADO TIPO PAQUETE

El Aire Acondicionado Tipo Paquete GPC13M 13 SEER
posee en una sola unidad integrada un sistema de
refrigeración y calefacción que ahorra energía con
un gran rendimiento. Esta unidad se aloja en un
gabinete de acero galvanizado grueso, protegido por
un acabado de pintura resistente a las radiaciones
ultravioletas de alta calidad y permite aplicaciones en
plantas bajas o en techos.

Características Estándar

Compresor con una válvula de escape interna que con-

•
tribuye al ahorro de energía.

Motor EEM, motor PSC en unidades de 3 toneladas.

•
Flujo de aire convertible: horizontal o fl ujo descendente.

•
Tubo de cobre/Bobina de aleta de aluminio.

•
Motor de ventilador condensador completamente cerrado

•
y constantemente lubricado.

Sistema R-22 completamente cargado.

•
Equipo de calefacción eléctrica disponible como un ac-

•
cesorio de instalación en campo

13 SEER

3, 4 Y 5 TONELADAS

CAPACIDAD DE REFRIGERACIÓN:

36,000 - 56,000 BTU/H

Características del Gabinete

Gabinete de acero galvanizado grueso con un atractivo

•
acabado de pintura gris grafi to.

Compartimiento de ventilador completamente aislado con

•
convenientes paneles de acceso.

Protección ventilada de la bobina del condensador.

•
Una superfi cies de apoyo; dos alturas

•

Contents

Nomenclatura ...................................................................... 2

Accesorios ............................................................................. 2

Especi caciones del Producto ....................................... 3

Dimensiones ........................................................................ 4

Especi caciones del Ventilador del Evaporador ..... 5

Valores de Refrigeración Expandida............................ 6

SS-GPC13M-SP www.goodmanmfg.com 1/08

Supersedes 9/07

P

A

RODUCT SPECIFICATIONS

NOMENCLATURA

ACCESORIOS

36 H 2 1GPH13

4,532110986,7

Brand Engineering

G Goodman Minor Revision

or Distinctions™

Product Category Engineering

P Packaged Unit Major Revision

Type Voltage Designator

H Heat Pump 1 208-230/1/60
C Air Conditioner 3 208-230/3/60

Efficiency Refrigerant

13 13 SEER 15 15 SEER 2 R-22
14 14 SEER 16 16 SEER 4 R-410A

Nominal Capacity Configuration

24 2 Tons 42 3½ Tons H Horizontal
30 2½ tons 48 4 Tons M Multi-position
36 3 Tons 60 5 Tons

*

1211

4 460/3/60

Artículo Nro. Descripción

GPH13MED102/103* Economizador de Flujo Descendente para Unidades en Paquete GPC13M/ GPH13M
GPH13MFR102/103* Bastidor del Filtro Interno para Aplicaciones de Flujo Descendente
OT18-60A Equipo del Termostato Externo con Bloqueo Automático
OT/EHR18-60 Equipo de Relé de Calefacción de Emergencia
PGC101/102/103* Borde de techo para GPC13M-/GPH13M –Eléctrico/ Unidad en Paquete Eléctrico
PGMDD101/102* Regulador Manual para Aplicación de Flujo Descendente: Chasis Medio
PGMDMD101/102* Regulador Eléctrico para Aplicación de Flujo Descendente: Chasis Medio
PGMDD103* Regulador Manual para Aplicación de Flujo Descendente: Chasis Grande
PGMDMD103* Regulador Eléctrico para Aplicación de Flujo Descendente: Chasis Grande
PGMDH102* Regulador Manual de un 25% de Aire Fresco: Aplicaciones Horizontales
PGMDH103* Regulador Manual de un 25% de Aire Fresco: Aplicaciones Horizontales
PGMDMH102* Regulador Eléctrico de un 25% de Aire Fresco: Aplicaciones Horizontales
PGMDMH103* Regulador Eléctrico de un 25% de Aire Fresco: Aplicaciones Horizontales
PCFR101-103 Bastidor del Filtro Horizontal Externo
SQRPG101/102* Adaptador Cuadrado a Redondo con Barra Redonda de 16”: Aplicaciones de Flujo Descendente
SQRPG103* Adaptador Cuadrado a Redondo con Barra Redonda de 18”: Aplicaciones de Flujo Descendente
SQRPGH101/102* Adaptadores Cuadrados a Redondos para GPC/ GPH: Unidades en Paquete de 16” y 14”
SQRPGH103* Adaptadores Cuadrados a Redondos para GPC/ GPH: Unidades en Paquete de 18” y 14”

* Ofrecido por McDaniel Metals • Contacto principal: [phone] • Fax: [phone]

2 www.goodmanmfg.com SS-GPC13M-SP

ESPECIFICACIONES

GPC1336M21A* GPC1348M21A* GPC1360M21A*

Capacidad de Refrigeración

BTU/h Total 35,000 47,000 56,500
BTU/h Perceptible 26,200 36,000 42,000
SEER / EER 13/11.1 13/11.1 13/10.8
Decibeles 77 78 78

Motor del Evaporador

Tipo DD DD DD
CFM de refrigeración nominal 1,225 1,750 1,900
Rueda (DxW) 10 x 9 10 x 9 10 x 9
Nº de velocidades 3 5 5
Caballos de fuerza - RPM  ¾ 1.0

Bobina del Evaporador

Área frontal (ft) 4.5 6.2 6.2
Aleta/Profundidad de  las por pulgada 4 4 4
Tamaño del drenaje (NPT) ¾” ¾” ¾”
Carga refrigerante (oz.) 110 158 209

Bobina / Ventilador del Condensador

Caballos de fuerza - RPM ¼ - 1,075  - 1,075  - 1,075
Diámetro del ventilador / 22 22 22
Nº de aletillas del ventilador 3 4 4
Área frontal (ft) 12.5 15.3 21.2
Aletas/Profundidad de  las por pulgada 2 2 2

Datos Eléctricos

Voltaje-Fase 208/230-1 208/230-1 208/230-1
Compresor RLA/LRA 12.2 / 73 19.2 / 97 25 / 148
Ventilador interno FLA / LRA 1.9 / 3.6 6 / - 7.6 / ­Ventilador externo FLA / LRA 1.4 / 3 2.4 / 5.2 2.4 / 5.2
Amperes totales de la unidad 13.5 18.2 25
Ampacidad Min. del Circuito 18.5 32.4 41.2
Protección contra Sobrecorriente Max. 30 amps 50 amps 60 amps
Peso del Embarque (lbs) 416 459 511

P

RODUCT SPECIFICATIONS

 El tamaño del cable se debe determinar conforme a los Códigos Eléctricos Nacionales. Extensas series de cableado requerirán un

cable de mayor tamaño.

 Puede utilizar fusibles o interruptores de circuito del tipo HACR del mismo tamaño.

SS-GPC13M-SP www.goodmanmfg.com 3

P

RODUCT SPECIFICATIONS

DIMENSIONES

57%6+10.+37+&24'5574'21465

%10&'05#6'&4#+0%100'%6+10



026('/#.'





219'49+4'
'064#0%'









$

B



%10641.9+4''064#0%'





#







$

B

5722.;

H



4'6740

Model Medium Large H x D x W

GPC1324M21A X 34¾”x 51”x 47”

GPC1336M21A X 34¾”x 51”x 47”

GPC1348M21A X 42¾”x 51”x 47”

GPC1360M21A X 42¾”x 51”x 47”

4 www.goodmanmfg.com SS-GPC13M-SP

ESPECIFICACIONES DEL VENTILADOR DEL EVAPORADOR

P

RODUCT SPECIFICATIONS

Modelo Velocidad Voltios

Bajo 230

GPC13

36M21A

GPC13

48M21A

GPC13

60M21A

Notas:

Los datos proporcionados son de la bobina de secado. El descenso de presión de la bobina húmeda es aproximadamente de 0.1” H2O,

•
para una bobina interna de dos fi las; 0.2” H2O, para una bobina interna de tres fi las; y 0.3” H2O, para una bobina interna de cuatro fi las

Los datos proporcionados no incluyen el descenso de presión del fi ltro de aproximadamente 0.08” H2O.

•
TODOS LOS MODELOS DEBEN FUNCIONAR A NO MENOS DE 350 CFM/TON. UTILICE UNA TOMA DE MAYOR VELOCIDAD O UN

•
ENSAMBLE DE VENTILADOR DEL MAYOR TAMAÑO QUE LE SIGUE. Consulte la lista de piezas de reparación

Reduzca el fl ujo de aire en un 2% aproximadamente para una operación de 208 voltios.

•

Medio Bajo 230

Medio

Alto

Alto 230

T1 (G) 230

T2 / T3 (W2) 230

T4 / T5 Y 230

T1 (G) 230

T2 / T3 (W2) 230

T4 / T5 Y 230

230

CFM 1,055 1,015 975 895 840 770 - -

Watts 315 310 300 285 270 255 - -

CFM 1,285 1,240 1,190 1,120 1,040 950 850 -

Watts 385 375 365 350 335 315 295 -

CFM 1,470 1,425 1,345 1,285 1,195 1,085 980 865

Watts 455 440 425 410 385 370 350 325

CFM 1,565 1,510 1,415 1,340 1,260 1,135 1,035 885

Watts 495 480 460 445 425 405 385 355

CFM 1,440 1,395 1,360 1,310 1,265 1,235 1,190 1,130

Watts 275 285 295 315 325 335 345 355

CFM 1,795 1,765 1,715 1,695 1,650 1,600 1,500 1,375

Watts 475 490 505 520 530 535 510 475

CFM 1,860 1,820 1,785 1,745 1,700 1,625 1,515 1,395

Watts 515 530 545 565 570 550 535 485

CFM 1,755 1,720 1,685 1,645 1,615 1,570 1,530 1,465

Watts 420 435 455 460 475 490 500 500

CFM 1,850 1,820 1,775 1,735 1,705 1,675 1,610 1,495

Watts 480 500 515 525 535 555 545 520

CFM 2,180 2,125 2,050 1,975 1,875 1,800 1,655 1,530

Watts 770 755 725 700 675 640 575 540

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

E.S.P (In. of H2O)

SS-GPC13M-SP www.goodmanmfg.com 5

P

RODUCT SPECIFICATIONS

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1336M21A

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

∆T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -

kW 2.51 2.56 2.63 - 2.69 2.74 2.82 - 2.84 2.90 2.98 - 2.97 3.03 3.13 - 3.09 3.15 3.25 - 3.19 3.25 3.35 -

S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -

MBh 34.3 35.5 38.9 - 33.5 34.7 38.0 - 32.7 33.9 37.1 - 31.9 33.1 36.2 - 30.3 31.4 34.4 - 28.1 29.1 31.9 -

1378

Amps 10.6 10.8 11.1 - 11.3 11.5 11.8 - 12.1 12.3 12.6 - 12.8 13.0 13.4 - 13.5 13.7 14.1 - 14.1 14.4 14.9 -

Hi PR 153 165 174 - 172 185 196 - 196 211 222 - 223 240 253 - 251 270 285 - 277 298 315 -

Lo PR 65 70 76 - 69 73 80 - 72 76 83 - 75 80 88 - 79 84 92 - 82 87 95 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 2.50 2.54 2.62 - 2.67 2.72 2.80 - 2.82 2.87 2.96 - 2.95 3.01 3.10 - 3.07 3.13 3.22 - 3.16 3.23 3.33 -

S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -

MBh 33.3 34.5 37.8 - 32.5 33.7 36.9 - 31.7 32.9 36.1 - 31.0 32.1 35.2 - 29.4 30.5 33.4 - 27.3 28.3 31.0 -

1225

70

Amps 10.5 10.7 11.0 - 11.2 11.4 11.7 - 12.0 12.2 12.6 - 12.7 12.9 13.3 - 13.3 13.6 14.0 - 14.0 14.3 14.7 -

Hi PR 152 163 173 - 170 183 194 - 194 209 220 - 221 238 251 - 248 267 282 - 274 295 312 -

Lo PR 65 69 75 - 68 73 79 - 71 76 83 - 75 79 87 - 78 83 91 - 81 86 94 -

∆T 18 16 12 - 18 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 2.44 2.49 2.56 - 2.61 2.66 2.74 - 2.76 2.81 2.89 - 2.89 2.94 3.03 - 3.00 3.06 3.15 - 3.09 3.15 3.25 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -

MBh 30.7 31.9 34.9 - 30.0 31.1 34.1 - 29.3 30.4 33.3 - 28.6 29.6 32.5 - 27.2 28.2 30.8 - 25.2 26.1 28.6 -

1072

Amps 10.2 10.4 10.7 - 10.9 11.1 11.4 - 11.7 11.9 12.3 - 12.4 12.6 13.0 - 13.0 13.3 13.7 - 13.7 14.0 14.4 -

Hi PR 147 159 167 - 165 178 188 - 188 202 214 - 214 230 243 - 241 259 274 - 266 286 302 -

Lo PR 63 67 73 - 66 71 77 - 69 73 80 - 72 77 84 - 76 81 88 - 79 84 91 -

MBh 34.9 35.9 38.9 41.7 34.1 35.1 38.0 40.7 33.3 34.2 37.1 39.8 32.4 33.4 36.2 38.8 30.8 31.7 34.4 36.9 28.6 29.4 31.8 34.2

S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43

∆T 20181510201915112019 15 11 20 19 15 11 20 18 15 10 19 17 14 10

kW 2.53 2.58 2.65 2.73 2.71 2.76 2.84 2.92 2.86 2.92 3.00 3.10 3.00 3.06 3.15 3.25 3.11 3.18 3.27 3.37 3.21 3.28 3.38 3.49

1378

Amps 10.6 10.8 11.1 11.5 11.3 11.6 11.9 12.3 12.2 12.4 12.8 13.2 12.9 13.1 13.5 13.9 13.6 13.8 14.2 14.7 14.3 14.6 15.0 15.5

Hi PR 155 167 176 184 174 187 198 206 198 213 225 234 225 242 256 267 253 273 288 300 280 301 318 332

Lo PR 66 70 77 82 70 74 81 86 73 77 84 90 76 81 88 94 80 85 93 99 83 88 96 102

MBh 33.9 34.9 37.7 40.5 33.1 34.1 36.9 39.6 32.3 33.2 36.0 38.6 31.5 32.4 35.1 37.7 29.9 30.8 33.3 35.8 27.7 28.5 30.9 33.2

S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41

∆T 21191611211916112119 16 11 21 20 16 11 21 19 16 11 20 18 15 10

kW 2.51 2.56 2.63 2.71 2.69 2.74 2.82 2.90 2.84 2.90 2.98 3.07 2.97 3.03 3.13 3.22 3.09 3.15 3.25 3.35 3.19 3.25 3.35 3.46

1225

75

Amps 10.6 10.8 11.1 11.4 11.3 11.5 11.8 12.2 12.1 12.3 12.7 13.1 12.8 13.0 13.4 13.8 13.5 13.7 14.1 14.6 14.1 14.4 14.9 15.4

Hi PR 153 165 174 182 172 185 196 204 196 211 223 232 223 240 253 264 251 270 285 297 277 298 315 329

Lo PR 65 70 76 81 69 74 80 85 72 76 83 89 75 80 88 93 79 84 92 98 82 87 95 101

MBh 31.3 32.2 34.8 37.4 30.5 31.4 34.0 36.5 29.8 30.7 33.2 35.6 29.1 29.9 32.4 34.8 27.6 28.4 30.8 33.0 25.6 26.3 28.5 30.6

S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39

∆T 21191611212016112120 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 2.46 2.51 2.58 2.65 2.63 2.68 2.76 2.84 2.78 2.83 2.91 3.00 2.91 2.97 3.05 3.15 3.02 3.08 3.17 3.27 3.11 3.18 3.27 3.38

1072

Amps 10.3 10.5 10.8 11.1 11.0 11.2 11.5 11.9 11.8 12.0 12.4 12.7 12.5 12.7 13.1 13.5 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0

Hi PR 149 160 169 176 167 180 190 198 190 204 216 225 216 233 246 256 243 262 277 288 269 289 306 319

Lo PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 91 77 82 89 95 79 84 92 98

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ACCA (TVA) Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

6 www.goodmanmfg.com SS-GPC13M-SP

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1336M21A (CONT.)

P

RODUCT SPECIFICATIONS

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

MBh 35.5 36.3 38.8 41.4 34.7 35.4 37.9 40.5 33.8 34.6 37.0 39.5 33.0 33.7 36.1 38.5 31.4 32.1 34.2 36.6 29.1 29.7 31.7 33.9

S/T 0.94 0.88 0.72 0.54 1.00 0.91 0.74 0.56 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.82 0.62

∆T 222119152322191523221915222219152121191519201714

kW 2.55 2.60 2.67 2.75 2.73 2.78 2.86 2.95 2.88 2.94 3.03 3.12 3.02 3.08 3.17 3.27 3.14 3.20 3.30 3.40 3.24 3.30 3.41 3.51

1378

Amps 10.7 10.9 11.2 11.6 11.4 11.7 12.0 12.4 12.2 12.5 12.9 13.3 13.0 13.2 13.6 14.1 13.7 14.0 14.4 14.8 14.4 14.7 15.1 15.6

Hi PR 157 168 178 186 176 189 200 208 200 215 227 237 228 245 259 270 256 275 291 303 283 304 321 335

Lo PR 67 71 77 83 70 75 82 87 73 78 85 91 77 82 89 95 81 86 94 100 83 89 97 103

MBh 34.5 35.2 37.6 40.2 33.7 34.4 36.8 39.3 32.9 33.6 35.9 38.4 32.1 32.8 35.0 37.4 30.5 31.1 33.3 35.5 28.2 28.8 30.8 32.9

S/T 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.96 0.78 0.59

∆T 232219152322201623222016242320162322191621211814

kW 2.53 2.58 2.65 2.73 2.71 2.76 2.84 2.92 2.86 2.92 3.00 3.10 3.00 3.06 3.15 3.25 3.11 3.18 3.27 3.38 3.21 3.28 3.38 3.49

1225

80

Amps 10.6 10.8 11.1 11.5 11.3 11.6 11.9 12.3 12.2 12.4 12.8 13.2 12.9 13.1 13.5 13.9 13.6 13.8 14.2 14.7 14.3 14.6 15.0 15.5

Hi PR 155 167 176 184 174 187 198 206 198 213 225 234 225 242 256 267 253 273 288 300 280 301 318 332

Lo PR 66 70 77 82 70 74 81 86 73 77 84 90 76 81 89 94 80 85 93 99 83 88 96 102

MBh 31.8 32.5 34.7 37.1 31.1 31.7 33.9 36.3 30.3 31.0 33.1 35.4 29.6 30.2 32.3 34.5 28.1 28.7 30.7 32.8 26.0 26.6 28.4 30.4

S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57

∆T 242320162423201624232016242320162423201622211815

kW 2.48 2.53 2.60 2.67 2.65 2.70 2.78 2.86 2.80 2.85 2.94 3.02 2.93 2.99 3.08 3.17 3.04 3.10 3.20 3.30 3.14 3.20 3.30 3.40

1072

Amps 10.4 10.6 10.9 11.2 11.1 11.3 11.6 12.0 11.9 12.1 12.5 12.8 12.6 12.8 13.2 13.6 13.2 13.5 13.9 14.4 13.9 14.2 14.6 15.1

Hi PR 150 162 171 178 169 182 192 200 192 206 218 227 219 235 248 259 246 265 279 291 272 292 309 322

Lo PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 86 91 77 82 90 96 80 85 93 99

MBh 36.1 36.8 38.6 41.1 35.3 36.0 37.7 40.2 34.4 35.1 36.8 39.2 33.6 34.2 35.9 38.3 31.9 32.5 34.1 36.4 29.6 30.1 31.6 33.7

S/T 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.98 0.79 1.00 1.00 0.98 0.80

∆T 242322192424221923232219222323192122221920202118

kW 2.57 2.62 2.69 2.77 2.75 2.80 2.88 2.97 2.90 2.96 3.05 3.14 3.04 3.10 3.20 3.30 3.16 3.23 3.32 3.43 3.26 3.33 3.43 3.54

1378

Amps 10.8 11.0 11.3 11.7 11.5 11.7 12.1 12.4 12.3 12.6 13.0 13.4 13.1 13.3 13.7 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.2 15.7

Hi PR 158 170 180 187 177 191 202 210 202 217 229 239 230 247 261 272 259 278 294 306 286 307 325 339

Lo PR 67 72 78 83 71 76 83 88 74 79 86 92 78 83 90 96 81 87 95 101 84 90 98 104

MBh 35.1 35.7 37.4 39.9 34.3 34.9 36.6 39.0 33.4 34.1 35.7 38.1 32.6 33.3 34.8 37.2 31.0 31.6 33.1 35.3 28.7 29.3 30.6 32.7

S/T 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.71 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.94 0.76

∆T 252423202525232025252320242523202324232022222219

kW 2.55 2.60 2.67 2.75 2.73 2.78 2.86 2.95 2.88 2.94 3.03 3.12 3.02 3.08 3.17 3.27 3.14 3.20 3.30 3.40 3.24 3.30 3.41 3.51

1225

85

Amps 10.7 10.9 11.2 11.6 11.4 11.7 12.0 12.4 12.2 12.5 12.9 13.3 13.0 13.2 13.6 14.1 13.7 14.0 14.4 14.8 14.4 14.7 15.1 15.6

Hi PR 157 168 178 186 176 189 200 208 200 215 227 237 228 245 259 270 256 275 291 303 283 304 321 335

Lo PR 67 71 77 83 70 75 82 87 73 78 85 91 77 82 89 95 81 86 94 100 83 89 97 103

MBh 32.4 33.0 34.6 36.9 31.6 32.2 33.8 36.0 30.9 31.5 32.9 35.1 30.1 30.7 32.1 34.3 28.6 29.2 30.5 32.6 26.5 27.0 28.3 30.2

S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.91 0.73

∆T 252523202525242025252420262524212525242023232219

kW 2.50 2.54 2.61 2.69 2.67 2.72 2.80 2.88 2.82 2.87 2.96 3.05 2.95 3.01 3.10 3.20 3.06 3.13 3.22 3.32 3.16 3.23 3.33 3.43

1072

Amps 10.5 10.7 11.0 11.3 11.2 11.4 11.7 12.1 12.0 12.2 12.5 12.9 12.7 12.9 13.3 13.7 13.3 13.6 14.0 14.5 14.0 14.3 14.7 15.2

Hi PR 152 163 173 180 170 183 194 202 194 209 220 230 221 238 251 262 248 267 282 294 274 295 312 325

Lo PR 65 69 75 80 68 73 79 85 71 76 83 88 75 79 87 92 78 83 91 97 81 86 94 100

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ARI Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

SS-GPC13M-SP www.goodmanmfg.com 7

P

RODUCT SPECIFICATIONS

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1348M21A

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

∆T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 14 11 - 16 14 10 -

kW 3.37 3.43 3.53 - 3.60 3.67 3.78 - 3.81 3.89 4.00 - 3.99 4.07 4.20 - 4.15 4.23 4.36 - 4.28 4.37 4.50 -

S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.88 0.74 0.51 - 0.89 0.74 0.51 -

MBh 46.1 47.7 52.3 - 45.0 46.6 51.1 - 43.9 45.5 49.9 - 42.8 44.4 48.7 - 40.7 42.2 46.2 - 37.7 39.1 42.8 -

1969

Amps 14.2 14.5 14.9 - 15.2 15.5 15.9 - 16.2 16.6 17.0 - 17.2 17.5 18.1 - 18.1 18.5 19.1 - 19.1 19.5 20.0 -

Hi PR 154 166 175 - 173 186 196 - 197 212 223 - 224 241 254 - 252 271 286 - 278 299 316 -

Lo PR 63 67 73 - 66 71 77 - 69 73 80 - 72 77 84 - 76 81 88 - 79 84 91 -

∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -

kW 3.34 3.41 3.51 - 3.58 3.65 3.75 - 3.78 3.86 3.97 - 3.96 4.04 4.16 - 4.12 4.20 4.33 - 4.25 4.34 4.47 -

S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -

MBh 44.7 46.3 50.8 - 43.7 45.3 49.6 - 42.6 44.2 48.4 - 41.6 43.1 47.2 - 39.5 41.0 44.9 - 36.6 37.9 41.6 -

1750

70

Amps 14.1 14.4 14.8 - 15.0 15.3 15.8 - 16.1 16.5 16.9 - 17.1 17.4 17.9 - 18.0 18.4 18.9 - 18.9 19.3 19.9 -

Hi PR 152 164 173 - 171 184 194 - 195 209 221 - 222 239 252 - 249 268 283 - 275 296 313 -

Lo PR 62 66 72 - 66 70 76 - 68 73 79 - 72 76 83 - 75 80 87 - 78 83 90 -

∆T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -

kW 3.27 3.33 3.43 - 3.50 3.57 3.67 - 3.70 3.77 3.88 - 3.87 3.95 4.07 - 4.02 4.10 4.23 - 4.15 4.23 4.36 -

S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -

MBh 41.3 42.8 46.9 - 40.3 41.8 45.8 - 39.4 40.8 44.7 - 38.4 39.8 43.6 - 36.5 37.8 41.4 - 33.8 35.0 38.4 -

1531

Amps 13.8 14.1 14.4 - 14.7 15.0 15.4 - 15.7 16.1 16.5 - 16.7 17.0 17.5 - 17.6 17.9 18.4 - 18.5 18.9 19.4 -

Hi PR 148 159 168 - 166 179 189 - 189 203 214 - 215 231 244 - 242 260 275 - 267 288 304 -

Lo PR 60 64 70 - 64 68 74 - 66 70 77 - 70 74 81 - 73 78 85 - 75 80 88 -

MBh 46.8 48.2 52.2 56.0 45.7 47.1 51.0 54.7 44.7 46.0 49.8 53.4 43.6 44.9 48.6 52.1 41.4 42.6 46.1 49.5 38.3 39.5 42.7 45.9

S/T 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.93 0.84 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.90 0.68 0.44 1.00 0.90 0.68 0.44

∆T 19181510191815101918 15 10 20 18 15 10 19 18 15 10 18 17 14 9

kW 3.39 3.46 3.56 3.66 3.63 3.70 3.81 3.92 3.84 3.92 4.03 4.16 4.02 4.11 4.23 4.36 4.18 4.27 4.40 4.53 4.31 4.40 4.54 4.68

Amps 14.3 14.6 15.0 15.5 15.3 15.6 16.0 16.5 16.4 16.7 17.2 17.7 17.3 17.7 18.2 18.8 18.3 18.7 19.2 19.8 19.2 19.6 20.2 20.9

Hi PR 156 167 177 184 175 188 198 207 199 214 226 235 226 243 257 268 254 274 289 302 281 302 319 333

Lo PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 91 77 82 89 95 79 84 92 98

1969

MBh 45.5 46.8 50.7 54.4 44.4 45.7 49.5 53.1 43.4 44.6 48.3 51.9 42.3 43.6 47.1 50.6 40.2 41.4 44.8 48.1 37.2 38.3 41.5 44.5

S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42

∆T 20181510201915112019 15 11 20 19 15 11 20 19 15 10 19 17 14 10

kW 3.37 3.43 3.53 3.63 3.60 3.67 3.78 3.89 3.81 3.89 4.00 4.12 3.99 4.07 4.20 4.33 4.15 4.23 4.36 4.50 4.28 4.37 4.51 4.65

1750

75

Amps 14.2 14.5 14.9 15.3 15.2 15.5 15.9 16.4 16.2 16.6 17.1 17.6 17.2 17.6 18.1 18.6 18.1 18.5 19.1 19.7 19.1 19.5 20.1 20.7

Hi PR 154 166 175 183 173 186 196 205 197 212 223 233 224 241 254 265 252 271 286 299 278 299 316 330

Lo PR 63 67 73 78 66 71 77 82 69 73 80 85 72 77 84 90 76 81 88 94 79 84 91 97

MBh 42.0 43.2 46.8 50.2 41.0 42.2 45.7 49.0 40.0 41.2 44.6 47.9 39.0 40.2 43.5 46.7 37.1 38.2 41.3 44.4 34.4 35.4 38.3 41.1

S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40

∆T 20191511211916112119 16 11 21 19 16 11 20 19 15 11 19 18 14 10

kW 3.30 3.36 3.45 3.55 3.52 3.59 3.70 3.81 3.72 3.80 3.91 4.03 3.90 3.98 4.10 4.23 4.05 4.13 4.26 4.39 4.18 4.27 4.40 4.54

1531

Amps 13.9 14.2 14.5 15.0 14.8 15.1 15.5 16.0 15.9 16.2 16.6 17.2 16.8 17.1 17.6 18.2 17.7 18.1 18.6 19.2 18.6 19.0 19.6 20.2

Hi PR 149 161 170 177 168 180 191 199 191 205 217 226 217 234 247 257 244 263 278 290 270 291 307 320

Lo PR 61 65 71 75 64 68 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 88 94

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ACCA (TVA) Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

8 www.goodmanmfg.com SS-GPC13M-SP

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1348M21A (CONT.)

P

RODUCT SPECIFICATIONS

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

MBh 47.7 48.7 52.0 55.6 46.6 47.6 50.8 54.3 45.5 46.4 49.6 53.0 44.3 45.3 48.4 51.8 42.1 43.0 46.0 49.2 39.0 39.9 42.6 45.5

S/T 0.96 0.90 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.84 0.63 1.00 1.00 0.84 0.63

∆T 212118142221181421211814212118152020181418191713

kW 3.42 3.48 3.58 3.69 3.66 3.73 3.84 3.95 3.87 3.95 4.06 4.19 4.05 4.14 4.26 4.40 4.21 4.30 4.43 4.57 4.35 4.44 4.58 4.72

1969

Amps 14.4 14.7 15.1 15.6 15.4 15.7 16.1 16.6 16.5 16.8 17.3 17.9 17.5 17.8 18.3 18.9 18.4 18.8 19.4 20.0 19.4 19.8 20.4 21.1

Hi PR 157 169 179 186 176 190 200 209 201 216 228 238 228 246 260 271 257 277 292 305 284 306 323 337

Lo PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 86 91 77 82 90 96 80 85 93 99

MBh 46.3 47.3 50.5 54.0 45.2 46.2 49.4 52.8 44.1 45.1 48.2 51.5 43.1 44.0 47.0 50.2 40.9 41.8 44.7 47.7 37.9 38.7 41.4 44.2

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.98 0.80 0.60 1.00 0.99 0.81 0.60

∆T 222119152322191523221915232219 15 21 22 19 15 20 20 18 14

kW 3.39 3.46 3.56 3.66 3.63 3.70 3.81 3.92 3.84 3.92 4.03 4.16 4.02 4.11 4.23 4.36 4.18 4.27 4.40 4.54 4.32 4.41 4.54 4.69

1750

80

Amps 14.3 14.6 15.0 15.5 15.3 15.6 16.0 16.5 16.4 16.7 17.2 17.7 17.3 17.7 18.2 18.8 18.3 18.7 19.2 19.9 19.2 19.6 20.2 20.9

Hi PR 156 167 177 184 175 188 198 207 199 214 226 235 226 243 257 268 254 274 289 302 281 303 319 333

Lo PR 63 68 74 78 67 71 78 83 70 74 81 86 73 78 85 91 77 82 89 95 79 84 92 98

MBh 42.7 43.6 46.6 49.9 41.7 42.6 45.6 48.7 40.7 41.6 44.5 47.5 39.7 40.6 43.4 46.4 37.8 38.6 41.2 44.1 35.0 35.7 38.2 40.8

S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.95 0.77 0.58 1.02 0.95 0.78 0.58

∆T 232219152322191523221915232219152322191521201814

kW 3.32 3.38 3.48 3.58 3.55 3.62 3.72 3.84 3.75 3.83 3.94 4.06 3.93 4.01 4.13 4.26 4.08 4.17 4.29 4.43 4.21 4.30 4.43 4.57

1531

Amps 14.0 14.3 14.7 15.1 14.9 15.2 15.6 16.1 16.0 16.3 16.8 17.3 16.9 17.3 17.8 18.3 17.8 18.2 18.7 19.4 18.8 19.2 19.7 20.4

Hi PR 151 162 172 179 169 182 192 201 193 207 219 228 219 236 249 260 247 266 280 293 273 293 310 323

Lo PR 62 65 71 76 65 69 76 80 68 72 78 84 71 76 82 88 74 79 86 92 77 82 89 95

MBh 48.5 49.4 51.8 55.2 47.4 48.3 50.6 54.0 46.2 47.1 49.4 52.7 45.1 46.0 48.2 51.4 42.9 43.7 45.8 48.8 39.7 40.5 42.4 45.2

S/T 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.97 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

∆T 232321182223221922222219212122192020211919192017

kW 3.44 3.51 3.61 3.72 3.68 3.76 3.87 3.98 3.90 3.98 4.10 4.22 4.09 4.17 4.30 4.43 4.25 4.33 4.47 4.61 4.38 4.47 4.61 4.76

1969

Amps 14.5 14.8 15.2 15.7 15.5 15.8 16.3 16.8 16.6 17.0 17.5 18.0 17.6 18.0 18.5 19.1 18.6 19.0 19.5 20.2 19.5 20.0 20.5 21.2

Hi PR 159 171 180 188 178 192 202 211 203 218 230 240 231 248 262 273 260 279 295 308 287 309 326 340

Lo PR 65 69 75 80 68 73 79 85 71 76 83 88 75 79 87 92 78 83 91 97 81 86 94 100

MBh 47.1 48.0 50.3 53.6 46.0 46.9 49.1 52.4 44.9 45.8 47.9 51.1 43.8 44.7 46.8 49.9 41.6 42.4 44.4 47.4 38.5 39.3 41.2 43.9

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78

∆T 242322192424221924242219232323202222221920212118

kW 3.42 3.48 3.58 3.69 3.66 3.73 3.84 3.95 3.87 3.95 4.06 4.19 4.05 4.14 4.26 4.40 4.21 4.30 4.43 4.57 4.35 4.44 4.58 4.72

1750

85

Amps 14.4 14.7 15.1 15.6 15.4 15.7 16.1 16.6 16.5 16.8 17.3 17.9 17.5 17.8 18.3 18.9 18.4 18.8 19.4 20.0 19.4 19.8 20.4 21.1

Hi PR 157 169 179 186 176 190 200 209 201 216 228 238 228 246 260 271 257 277 292 305 284 306 323 337

Lo PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 86 91 77 82 90 96 80 85 93 99

MBh 43.5 44.3 46.4 49.5 42.5 43.3 45.3 48.4 41.4 42.2 44.2 47.2 40.4 41.2 43.2 46.0 38.4 39.2 41.0 43.7 35.6 36.3 38.0 40.5

S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75

∆T 242423202524232025242320242423202324232021222118

kW 3.34 3.41 3.50 3.61 3.58 3.65 3.75 3.86 3.78 3.86 3.97 4.09 3.96 4.04 4.16 4.29 4.11 4.20 4.33 4.46 4.25 4.33 4.47 4.61

1531

Amps 14.1 14.4 14.8 15.2 15.0 15.3 15.8 16.3 16.1 16.4 16.9 17.5 17.1 17.4 17.9 18.5 18.0 18.4 18.9 19.5 18.9 19.3 19.9 20.5

Hi PR 152 164 173 181 171 184 194 203 195 209 221 231 222 238 252 263 249 268 283 295 275 296 313 326

Lo PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ARI Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

SS-GPC13M-SP www.goodmanmfg.com 9

P

RODUCT SPECIFICATIONS

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1360M21A

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -

kW 4.26 4.35 4.48 - 4.58 4.67 4.82 - 4.86 4.96 5.12 - 5.11 5.22 5.39 - 5.32 5.44 5.61 - 5.50 5.62 5.81 -

S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -

MBh 55.4 57.4 62.9 - 54.1 56.1 61.4 - 52.8 54.7 59.9 - 51.5 53.4 58.5 - 48.9 50.7 55.6 - 45.3 47.0 51.5 -

2138

Amps 19.5 19.9 20.4 - 20.8 21.2 21.8 - 22.3 22.8 23.4 - 23.6 24.1 24.8 - 24.9 25.4 26.2 - 26.2 26.8 27.5 -

Hi PR 166 179 189 - 186 200 212 - 212 228 241 - 241 260 274 - 271 292 308 - 300 323 341 -

Lo PR 62 66 73 - 66 70 77 - 69 73 80 - 72 77 84 - 75 80 88 - 78 83 91 -

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

kW 4.23 4.31 4.44 - 4.54 4.64 4.78 - 4.82 4.92 5.08 - 5.07 5.18 5.34 - 5.28 5.39 5.57 - 5.46 5.58 5.76 -

S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -

MBh 53.8 55.7 61.0 - 52.5 54.4 59.6 - 51.3 53.1 58.2 - 50.0 51.8 56.8 - 47.5 49.2 53.9 - 44.0 45.6 50.0 -

1900

70

Amps 19.4 19.7 20.3 - 20.6 21.1 21.6 - 22.1 22.6 23.2 - 23.4 23.9 24.6 - 24.7 25.2 26.0 - 26.0 26.5 27.3 -

Hi PR 164 177 187 - 184 198 210 - 210 226 238 - 239 257 271 - 269 289 305 - 297 320 337 -

Lo PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -

kW 4.13 4.21 4.34 - 4.43 4.53 4.67 - 4.70 4.80 4.96 - 4.94 5.05 5.21 - 5.15 5.26 5.43 - 5.32 5.44 5.61 -

S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -

MBh 49.6 51.4 56.3 - 48.5 50.2 55.0 - 47.3 49.0 53.7 - 46.2 47.8 52.4 - 43.8 45.4 49.8 - 40.6 42.1 46.1 -

1663

Amps 18.9 19.3 19.8 - 20.2 20.6 21.1 - 21.6 22.1 22.7 - 22.9 23.3 24.0 - 24.1 24.6 25.3 - 25.4 25.9 26.7 -

Hi PR 159 172 181 - 179 193 203 - 203 219 231 - 232 249 263 - 261 281 296 - 288 310 327 -

Lo PR 60 64 70 - 63 67 74 - 66 70 76 - 69 74 80 - 72 77 84 - 75 80 87 -

MBh 56.3 58.0 62.7 67.3 55.0 56.6 61.3 65.8 53.7 55.3 59.8 64.2 52.4 53.9 58.4 62.6 49.8 51.2 55.5 59.5 46.1 47.5 51.4 55.1

S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42

∆T 20191511211916112119 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 4.29 4.38 4.52 4.66 4.61 4.71 4.86 5.02 4.90 5.00 5.16 5.33 5.15 5.26 5.43 5.61 5.36 5.48 5.66 5.85 5.55 5.67 5.86 6.05

2138

Amps 19.6 20.0 20.6 21.2 21.0 21.4 22.0 22.7 22.5 22.9 23.6 24.4 23.8 24.3 25.0 25.8 25.1 25.6 26.4 27.3 26.4 27.0 27.8 28.7

Hi PR 168 180 191 199 188 202 214 223 214 230 243 254 244 262 277 289 274 295 312 325 303 326 344 359

Lo PR 63 67 73 78 67 71 77 82 69 74 80 86 73 77 84 90 76 81 89 94 79 84 92 98

MBh 54.7 56.3 60.9 65.4 53.4 55.0 59.5 63.9 52.1 53.7 58.1 62.3 50.9 52.4 56.7 60.8 48.3 49.7 53.8 57.8 44.7 46.1 49.9 53.5

S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40

∆T 21201611222016112220 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 4.26 4.35 4.48 4.62 4.58 4.67 4.82 4.98 4.86 4.96 5.12 5.29 5.11 5.22 5.39 5.56 5.32 5.44 5.61 5.80 5.50 5.62 5.81 6.00

1900

75

Amps 19.5 19.9 20.4 21.1 20.8 21.2 21.8 22.5 22.3 22.8 23.4 24.2 23.6 24.1 24.8 25.6 24.9 25.4 26.2 27.1 26.2 26.8 27.6 28.5

Hi PR 166 179 189 197 186 200 212 221 212 228 241 251 241 260 274 286 271 292 309 322 300 323 341 356

Lo PR 62 66 73 77 66 70 77 82 69 73 80 85 72 77 84 89 75 80 88 93 78 83 91 97

MBh 50.5 51.9 56.2 60.3 49.3 50.7 54.9 58.9 48.1 49.5 53.6 57.5 46.9 48.3 52.3 56.1 44.6 45.9 49.7 53.3 41.3 42.5 46.0 49.4

S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39

∆T 22201611222017112220 17 11 22 20 17 12 22 20 16 11 20 19 15 11

kW 4.16 4.24 4.37 4.51 4.47 4.56 4.71 4.85 4.74 4.84 5.00 5.16 4.98 5.09 5.25 5.43 5.19 5.30 5.47 5.65 5.37 5.48 5.66 5.85

Amps 19.1 19.4 20.0 20.6 20.3 20.7 21.3 22.0 21.8 22.2 22.9 23.6 23.1 23.5 24.2 25.0 24.3 24.8 25.6 26.4 25.6 26.1 26.9 27.8

Hi PR 161 173 183 191 181 194 205 214 206 221 234 244 234 252 266 277 263 283 299 312 291 313 331 345

Lo PR 61 64 70 75 64 68 74 79 67 71 77 82 70 74 81 86 73 78 85 91 76 81 88 94

1663

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ACCA (TVA) Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

10 www.goodmanmfg.com SS-GPC13M-SP

VALORES DE REFRIGERACIÓN EXPANDIDA — GPC1360M21A (CONT.)

P

RODUCT SPECIFICATIONS

Temperatura Ambiente Externa

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Temperatura inicial del bulbo húmedo interno

59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

Flujo de aire

IDB

MBh 57.3 58.6 62.6 66.9 56.0 57.2 61.1 65.3 54.6 55.8 59.6 63.8 53.3 54.5 58.2 62.2 50.6 51.7 55.3 59.1 46.9 47.9 51.2 54.7

S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61

∆T 232219152322191524221915232219162222191520211814

kW 4.33 4.41 4.55 4.69 4.65 4.75 4.90 5.06 4.94 5.04 5.21 5.38 5.19 5.31 5.48 5.66 5.41 5.53 5.71 5.90 5.59 5.72 5.91 6.10

2138

Amps 19.8 20.2 20.7 21.4 21.1 21.5 22.1 22.9 22.7 23.1 23.8 24.6 24.0 24.5 25.2 26.0 25.3 25.9 26.6 27.5 26.6 27.2 28.0 29.0

Hi PR 169 182 192 201 190 205 216 225 216 233 246 256 246 265 280 292 277 298 315 328 306 329 348 363

Lo PR 64 68 74 79 67 72 78 83 70 74 81 87 73 78 85 91 77 82 89 95 80 85 93 99

MBh 55.6 56.9 60.7 64.9 54.3 55.5 59.3 63.4 53.0 54.2 57.9 61.9 51.8 52.9 56.5 60.4 49.2 50.2 53.7 57.4 45.5 46.5 49.7 53.2

S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58

∆T 242320162423201624232016242320162423201622211915

kW 4.29 4.38 4.52 4.66 4.61 4.71 4.86 5.02 4.90 5.00 5.16 5.33 5.15 5.26 5.43 5.61 5.36 5.48 5.66 5.85 5.55 5.67 5.86 6.05

1900

80

Amps 19.6 20.0 20.6 21.2 21.0 21.4 22.0 22.7 22.5 22.9 23.6 24.4 23.8 24.3 25.0 25.8 25.1 25.7 26.4 27.3 26.4 27.0 27.8 28.7

Hi PR 168 180 191 199 188 203 214 223 214 230 243 254 244 262 277 289 274 295 312 325 303 326 344 359

Lo PR 63 67 73 78 67 71 77 82 69 74 80 86 73 77 85 90 76 81 89 94 79 84 92 98

MBh 51.4 52.5 56.1 59.9 50.2 51.3 54.8 58.5 49.0 50.0 53.5 57.1 47.8 48.8 52.1 55.7 45.4 46.4 49.5 53.0 42.0 43.0 45.9 49.1

S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56

∆T 242320162423201625232016252421162423201623221915

kW 4.19 4.28 4.41 4.55 4.50 4.60 4.74 4.89 4.78 4.88 5.04 5.20 5.02 5.13 5.30 5.47 5.23 5.35 5.52 5.70 5.41 5.53 5.71 5.90

1663

Amps 19.2 19.6 20.1 20.7 20.5 20.9 21.5 22.1 22.0 22.4 23.0 23.8 23.2 23.7 24.4 25.2 24.5 25.0 25.8 26.6 25.8 26.3 27.1 28.0

Hi PR 163 175 185 193 183 196 207 216 208 223 236 246 236 254 269 280 266 286 302 315 294 316 334 348

Lo PR 61 65 71 76 65 69 75 80 67 71 78 83 71 75 82 87 74 79 86 91 76 81 89 95

MBh 58.3 59.4 62.2 66.4 56.9 58.1 60.8 64.9 55.6 56.7 59.4 63.3 54.2 55.3 57.9 61.8 51.5 52.5 55.0 58.7 47.7 48.7 51.0 54.4

S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79

∆T 242423202424232024242320232423202223232021212118

kW 4.36 4.45 4.59 4.73 4.69 4.79 4.94 5.10 4.98 5.09 5.25 5.42 5.23 5.35 5.52 5.70 5.45 5.57 5.75 5.95 5.64 5.77 5.96 6.15

2138

Amps 19.9 20.3 20.9 21.5 21.3 21.7 22.3 23.0 22.8 23.3 24.0 24.8 24.2 24.7 25.4 26.2 25.5 26.1 26.8 27.7 26.8 27.4 28.2 29.2

Hi PR 171 184 194 203 192 207 218 228 218 235 248 259 249 268 283 295 280 301 318 332 309 333 351 366

Lo PR 64 68 75 80 68 72 79 84 71 75 82 87 74 79 86 92 78 83 90 96 80 86 93 100

MBh 56.6 57.7 60.4 64.5 55.3 56.4 59.0 63.0 54.0 55.0 57.6 61.5 52.7 53.7 56.2 60.0 50.0 51.0 53.4 57.0 46.3 47.2 49.5 52.8

S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75

∆T 252524202625242126252421252524212425242122232219

kW 4.33 4.41 4.55 4.69 4.65 4.75 4.90 5.06 4.94 5.04 5.21 5.38 5.19 5.31 5.48 5.66 5.41 5.53 5.71 5.90 5.59 5.72 5.91 6.10

1900

85

Amps 19.8 20.2 20.7 21.4 21.1 21.5 22.1 22.9 22.7 23.1 23.8 24.6 24.0 24.5 25.2 26.0 25.3 25.9 26.6 27.5 26.6 27.2 28.0 29.0

Hi PR 169 182 192 201 190 205 216 225 216 233 246 256 246 265 280 292 277 298 315 328 306 329 348 363

Lo PR 64 68 74 79 67 72 78 83 70 74 81 87 73 78 85 91 77 82 89 95 80 85 93 99

MBh 52.2 53.3 55.8 59.5 51.0 52.0 54.5 58.1 49.8 50.8 53.2 56.7 48.6 49.5 51.9 55.4 46.2 47.1 49.3 52.6 42.8 43.6 45.7 48.7

S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72

∆T 262524212626242126262421262624212626242124242320

kW 4.22 4.31 4.44 4.58 4.54 4.64 4.78 4.93 4.82 4.92 5.08 5.24 5.07 5.17 5.34 5.52 5.27 5.39 5.56 5.75 5.46 5.58 5.76 5.95

1663

Amps 19.3 19.7 20.3 20.9 20.6 21.1 21.6 22.3 22.1 22.6 23.2 24.0 23.4 23.9 24.6 25.4 24.7 25.2 26.0 26.8 26.0 26.5 27.3 28.2

Hi PR 164 177 187 195 184 198 210 219 210 226 238 249 239 257 271 283 269 289 305 318 297 319 337 352

Lo PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 96

IDB: Temperatura inicial del bulbo de secado interno El área sombreada re eja las condiciones ARI Amps = amperes de la unidad externa (comp.+ventilador)

Las presiones altas y bajas se miden en válvulas de servicio de succión y líquidas. kW = Energía total del sistema

SS-GPC13M-SP www.goodmanmfg.com 11

P

RODUCT SPECIFICATIONS

DATOS ELÉCTRICOS DEL EQUIPO DE CALEFACCIÓN

(SÓLO VENTILADOR, MODO DE CALEFACCIÓN)

Modelo y Uso del Equipo de

Calefacción
GPC1336M21AA 1.9 / 1.9 -- -- -- --

HKR-05*, HKR-05C* 24 / 27 30 / 30 -- -- 4.75 / 16,200
HKR-08*, HKR-08C* 34 / 39 40 / 40 -- -- 7.0 / 23,800
HKR-10*, HKR-10C* 45 / 52 60 / 60 -- -- 9.5 / 32,400
HKR-15*, HKR-15C* 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600

GPC1348M21AA 5.8 / 5.8 -- -- -- --

HKR-05*, HKR-05C* 25 / 28 30 / 30 -- -- 4.75 / 16,200
HKR-08*, HKR-08C* 38 / 40 40 / 40 -- -- 7.0 / 23,800
HKR-10*, HKR-10C* 49 / 56 60 / 60 -- -- 9.5 / 32,400
HKR-15*, HKR-15C* 49 / 56 60 / 60 22 / 25 30 / 30 14.25 / 48,600
HKR-20*, HKR-20C* 49 / 56 60 / 60 43 / 49 60 / 60 19.5 / 66,500

GPC1360M21AA 7.6 / 7.6 -- -- -- --

HKR-05*, HKR-05C* 29 / 30 30 / 30 -- -- 4.75 / 16,200
HKR-08*, HKR-08C* 39 / 40 40 / 40 -- -- 7.0 / 23,800
HKR-10*, HKR-10C* 51 / 58 60 / 60 -- -- 9.5 / 32,400
HKR-15*, HKR-15C* 51 / 58 60 / 60 22 / 25 30 / 30 14.25 / 48,600
HKR-20*, HKR-20C* 51 / 58 60 / 60 43 / 49 60 / 60 19.5 / 66,500

Circuit #1 Circuit #2

MCA MOP MCA MOP

Actual kW /
BTU@ 240V

Goodman Manufacturing Company, L.P., se reserva el derecho de discontinuar o cambiar en cualquier momento, las especi caciones o los diseños

sin aviso previo o sin contraer obligaciones. Copyright © 2008 • Goodman Manufacturing Company, L.P. • Houston, Texas • Impreso en los EE. UU.

12 www.goodmanmfg.com SS-GPC13M-SP
