GPH14M

Packaged Heat Pumps

2 to 5 Tons

Cooling Capacity: 24,000 - 58,000 BTU/h Heating Capacity: 23,000 - 57,500 BTU/h

14 SEER & 8.0 HSPF

Contents

Nomenclature ........................................ 2

Product Specicaons ........................... 3

Expanded Cooling Data ......................... 4

Expanded Heang Data ....................... 16

Airow Data ......................................... 18

Heat Kit Electrical Specs ...................... 20

Dimensions .......................................... 21

Wiring Diagrams ................................. 22

Accessories .......................................... 24

Standard Features

• High-eciency compressor

• EEM (X-13) blower motor

• Liquid-line lter drier

• Converble airow:

horizontal or downow

• All-Aluminum evaporator coil

• Copper tube/aluminum n

condenser coils

• Electric heat kit available as a eld-installed opon

• AHRI Cered; ETL Listed

SS-GPH14M www.goodmanmfg.com 11/14

Cabinet Features

• Heavy-gauge galvanized-steel cabinet with aracve Architectural Gray powder-paint nish

• Fully insulated air-handling compartment with convenient access panels

• Louvered condenser coil protecon

• One footprint; two heights

* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive the 10-Year

Parts Limited Warranty, online registraon must be completed within 60 days of installaon. Online registraon is not required in California or Quebec.

Product Specifications

         

 1 2 3

4,5

6,7

8 9 10 11 12

 

G Goodman®brand MinorRevision

 

P PackagedUnit MajorRevision 

 

H HeatPump 1208230/1/60 C AirCondiJoner  3208230/3/60

 

13 13SEER 1515SEER 4R410A 14 14SEER 1616SEER



 HHorizontal

24 2Tons 423½Tons MMulJposiJon 30 2½tons

484Tons

36 3Tons

605Tons

Nomenclature

2 www.goodmanmfg.com SS-GPH14M

Specifications

Product Specifications

GPH14

24M41A*

Cooling Capacity

Total BTU/h 24,000 28,600 34,400 41,000 48,000 58,000

Sensible BTU/h 18,700 21,700 26,000 29,500 36,500 42,300

SEER / EER 14/11 14/11 14/11 14/11 14/11 14/11

Decibels 76 76 81 80 79 80

AHRI #s

Heating Capacity

BTU/h (47°F) 23,000 28,000 33,200 40,600 45,600 57,500

C.O.P (47°F) 3.6 3.6 3.6 3.6 3.6 3.5

BTU/h (17°F) 12,600 17,000 19,000 23,000 27,000 31,200

C.O.P (17°F) 2.2 2.2 2.2 2.2 2.2 2.2

HSPF

Evaporator Motor

Type EEM EEM EEM EEM EEM EEM

Wheel (D x W) 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9

Nominal Cooling CFM 850 1,050 1,200 1,300 1,600 1,850

FLA / LRA 4.3 / -- 4.3 / -- 4.3 / -- 5.8 / -- 5.8 / -- 7.6 / --

No. of Speeds 5 5 5 5 5 5

Horsepower - RPM

Evaporator Coil

Face Area (²) 4.55 4.55 4.55 4.55 6.20 6.20

Rows Deep/ Fin per Inch 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14

Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"

R-410A Refrigerant Charge (oz.)

Condenser Fan / Coil

Horsepower - RPM ¼ - 830 ¼ - 830 ¼ - 830 ¼ - 1,075 ¼ - 1,075 ⅓ - 1,075

FLA/LRA 1.5 / 3.0 1.5 / 3.0 1.4 / 3.0 1.4 / 2.9 1.4 / 2.9 2.5 / 3.0

Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 4 22 / 3 22 / 3 22 / 3

Face Area (²) 12.21 12.21 12.21 12.21 15.30 21.32

Rows Deep/ Fin per Inch

Compressor

Quanty 1 1 1 1 1 1

Type Scroll Scroll Scroll Scroll Scroll Scroll

Stage

Electrical Data

Voltage/ Phase (60 Hz) 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1

Compressor RLA/ LRA 12.8 / 58.3 14.1 / 73 16.7 / 79 17.9 / 112 21.8 / 117 27.1/ 152.9

Total Unit Amps 18.6 19.9 22.4 25.1 29 37.2

Min. Circuit Ampacity¹ 21.8 23.4 26.6 29.6 34.5 44.0

Max. Overcurrent Protecon² 30 amps 35 amps 40 amps 45 amps 50 amps 70 amps

Shipping Weight (lbs) 380 390 400 410 485 495

Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.

May use fuses or HACR-type circuit breakers of the same size as noted.

Note: Always check the S&R plate for electrical data on the unit being installed.

7470164 7470160 7470161 7470165 7470166 7470162

8.0 8.0 8.0 8.0 8.0 8.0

½ - 1,050 ½ - 1,050 ½ - 1,050 ¾ - 1,050 ¾ - 1,050 1 - 1,050

128 128 115 133 153 180

2 / 16 2 / 16 2 / 16 2 / 16 2 / 16 2 / 16

Single Single Single Single Single 2 Stage

GPH14

30M41A*

GPH14

36M41A*

GPH14

42M41A*

GPH14

48M41A*

GPH14

60M41A*

SS-GPH14M www.goodmanmfg.com 3

Product Specifications

Expanded Cooling Data — GPH1424M41A**

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10.4

6.9 7.1 - 7.2 7.3 7.5 - 7.7 7.8 8.1 - 8.1 8.3 8.5 - 8.6 8.7 9.0 - 9.0 9.2 9.4 -

∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -

S/T 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.83 0.69 0.48 - 0.85 0.71 0.49 - 0.89 0.74 0.51 - 0.89 0.75 0.52 -

MBh 23.2 24.0 26.3 - 22.6 23.5 25.7 - 22.1 22.9 25.1 - 21.6 22.3 24.5 - 20.5 21.2 23.3 - 19.0 19.7 21.5 -

kW 1.55 1.58 1.63 - 1.67 1.70 1.75 - 1.77 1.81 1.87 - 1.86 1.90 1.96 - 1.94 1.98 2.05 - 2.01 2.05 2.12 -

950

HI PR 226 243 257 - 254 273 288 - 288 310 328 - 329 354 373 - 370 398 420 - 408 439 464 -

Amps 6.9 7.0 7.2 - 7.3 7.5 7.7 - 7.9 8.0 8.2 - 8.3 8.5 8.7 - 8.7 8.9 9.2 - 9.2 9.4 9.7 -

LO PR 113 120 131 - 119 127 139 - 124 132 144 - 130 139 151 - 137 145 159 - 141 150 164 -

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -

MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -

kW 1.54 1.57 1.62 - 1.66 1.69 1.75 - 1.76 1.80 1.86 - 1.85 1.89 1.95 - 1.93 1.97 2.03 - 1.99 2.04 2.11 -

850

HI PR 224 242 255 - 252 271 286 - 286 308 326 - 326 351 371 - 367 395 417 - 406 436 461 -

Amps 6.9 7.0 7.2 - 7.3 7.4 7.6 - 7.8 8.0 8.2 - 8.3 8.4 8.7 - 8.7 8.9 9.1 - 9.1 9.3 9.6 -

LO PR 112 119 130 - 119 126 138 - 123 131 143 - 129 138 150 - 136 144 158 - 140 149 163 -

∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.69 0.47 -

kW 1.52 1.55 1.59 - 1.63 1.66 1.72 - 1.73 1.77 1.82 - 1.82 1.86 1.92 - 1.90 1.94 2.00 - 1.96 2.00 2.07 -

MBh 21.7 22.5 24.6 - 21.2 22.0 24.1 - 20.7 21.4 23.5 - 20.2 20.9 22.9 - 19.2 19.9 21.8 - 17.8 18.4 20.2 -

750

Amps 6.8

HI PR 220 237 250 - 247 266 280 - 281 302 319 - 320 344 363 - 360 387 409 - 397 428 452 -

LO PR 110 117 128 - 116 124 135 - 121 129 140 - 127 135 147 - 133 141 154 - 138 146 160 -

MBh 23.6 24.3 26.3 28.2 23.0 23.7 25.7 27.5 22.5 23.1 25.0 26.9 21.9 22.6 24.4 26.2 20.8 21.4 23.2 24.9 19.3 19.9 21.5 23.1

S/T 0.89 0.79 0.60 0.4 0.92 0.82 0.62 0.4 0.94 0.84 0.64 0.4 0.97 0.87 0.66 0.4 1.00 0.90 0.68 0.4 1.00 0.91 0.69 0.4

∆T 20 19 15 11 20 19 15 11 20 19 15 11 21 19 16 11 20 19 15 11 19 17 14 9.9

kW 1.56 1.59 1.64 1.7 1.68 1.71 1.77 1.8 1.78 1.82 1.88 1.9 1.88 1.92 1.98 2.0 1.95 2.00 2.06 2.1 2.02 2.07 2.14 2.2

950

Amps 6.9 7.1 7.3 7.5 7.4 7.5 7.7 8.0 7.9 8.1 8.3 8.6 8.4 8.5 8.8 9.1 8.8 9.0 9.3 9.6 9.3 9.5 9.7 10.1

HI PR 228 246 259 270.6 256 276 291 303.7 291 314 331 345.4 332 357 377 393.4 373 402 424 442.5 413 444 469 488.9

LO PR 114 121 133 141.2 121 128 140 149.2 125 133 146 155.1 132 140 153 162.9 138 147 160 170.7 143 152 166 176.6

MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7

S/T 0.85 0.76 0.57 0.4 0.88 0.79 0.59 0.4 0.90 0.81 0.61 0.4 0.93 0.83 0.63 0.4 0.97 0.86 0.65 0.4 0.97 0.87 0.66 0.4

7.0 7.2 7.4 7.4 7.5 7.7 7.9 7.9 8.0 8.3 8.5 8.3 8.5 8.7 9.0 8.8 9.0 9.2 9.5 9.2 9.4 9.7 10.0

∆T 21 20 16 11 22 20 16 11

kW 1.55 1.58 1.63 1.7 1.67 1.71 1.76 1.8 1.77 1.81 1.87 1.9 1.87 1.91 1.97 2.0 1.94 1.99 2.05 2.1 2.01 2.06 2.12 2.2

HI PR 227 244 258 268.7 254 274 289 301.6 289 311 329 343.0 330 355 375 390.6 371 399 421 439.4 410 441 466 485.5

Amps 6.9

LO PR 113 121 132 140.3 120 127 139 148.2 125 132 145 154.0 131 139 152 161.8 137 146 159 169.5 142 151 165 175.4

850

MBh 22.1 22.7 24.6 26.4 21.5 22.2 24.0 25.8 21.0 21.7 23.4 25.2 20.5 21.1 22.9 24.5 19.5 20.1 21.7 23.3 18.1 18.6 20.1 21.6

S/T 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.86 0.77 0.58 0.4 0.89 0.80 0.60 0.4 0.92 0.83 0.63 0.4 0.93 0.83 0.63 0.4

∆T 22 20 17 11 22 20 17 12 22 21 17 12 22 21 17 12 22 20 17 12 21 19 16 10.8

kW 1.53 1.56 1.61 1.7 1.64 1.68 1.73 1.8 1.75 1.78 1.84 1.9 1.84 1.88 1.94 2.0 1.91 1.95 2.02 2.1 1.98 2.02 2.09 2.2

750

Amps 6.8 6.9 7.1 7.3 7.2 7.4 7.6 7.8 7.8 7.9 8.1 8.4 8.2 8.4 8.6 8.9 8.6 8.8 9.1 9.4 9.1 9.3 9.5 9.8

HI PR 222 239 253 263.4 249 268 283 295.5 284 305 322 336.1 323 348 367 382.8 363 391 413 430.7 401 432 456 475.8

LO PR 111 118 129 137.5 117 125 136 145.2 122 130 142 150.9 128 136 149 158.5 134 143 156 166.1 139 148 161 171.9

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

4 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1424M41A** (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 24.0 24.5 26.2 28.0 23.4 23.9 25.6 27.3 22.9 23.4 25.0 26.7 22.3 22.8 24.4 26.0 21.2 21.7 23.1 24.7 19.6 20.1 21.4 22.9

S/T 0.97 0.91 0.74 0.6 1.00 0.94 0.77 0.6 1.00 0.97 0.79 0.6 1.00 1.00 0.81 0.6 1.00 1.00 0.84 0.6 1.00 1.00 0.85 0.6

∆T 23 22 19 15 23 22 19 15 22 22 19 15 22 22 19 15 21 21 19 15 19 19 18 14.1

kW 1.57 1.61 1.66 1.7 1.69 1.73 1.78 1.8 1.80 1.84 1.90 2.0 1.89 1.93 2.00 2.1 1.97 2.01 2.08 2.2 2.04 2.09 2.15 2.2

950

Amps 7.0 7.1 7.3 7.5 7.4 7.6 7.8 8.0 8.0 8.1 8.4 8.6 8.4 8.6 8.8 9.1 8.9 9.1 9.3 9.6 9.3 9.5 9.8 10.1

HI PR 231 248 262 273.4 259 279 294 306.7 294 317 334 348.9 335 361 381 397.3 377 406 429 447.0 417 448 474 493.9

LO PR 115 123 134 142.7 122 130 142 150.7 127 135 147 156.7 133 142 155 164.6 139 148 162 172.4 144 153 167 178.4

MBh 23.6 24.1 25.8 27.6 23.1 23.6 25.2 26.9 22.5 23.0 24.6 26.3 22.0 22.5 24.0 25.7 20.9 21.3 22.8 24.4 19.3 19.8 21.1 22.6

S/T 0.93 0.87 0.71 0.5 0.96 0.90 0.74 0.5 0.99 0.93 0.75 0.6 1.00 0.96 0.78 0.6 1.00 0.99 0.81 0.6 1.00 1.00 0.82 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 21 19 14.9

kW 1.56 1.60 1.65 1.7 1.68 1.72 1.77 1.8 1.79 1.83 1.89 1.9 1.88 1.92 1.99 2.1 1.96 2.00 2.07 2.1 2.03 2.07 2.14 2.2

850

Amps 7.0 7.1 7.3 7.5 7.4 7.6 7.8 8.0 7.9 8.1 8.3 8.6 8.4 8.6 8.8 9.1 8.8 9.0 9.3 9.6 9.3 9.5 9.8 10.1

HI PR 229 246 260 271.5 257 277 292 304.6 292 315 332 346.4 333 358 378 394.6 375 403 426 443.9 414 445 470 490.4

LO PR 115 122 133 141.7 121 129 141 149.7 126 134 146 155.6 132 141 153 163.4 138 147 161 171.3 143 152 166 177.1

MBh 22.5 22.9 24.5 26.2 21.9 22.4 23.9 25.6 21.4 21.9 23.4 25.0 20.9 21.3 22.8 24.4 19.8 20.3 21.7 23.2 18.4 18.8 20.1 21.4

S/T 0.89 0.84 0.68 0.5 0.92 0.87 0.70 0.5 0.95 0.89 0.72 0.5 0.98 0.92 0.75 0.6 1.01 0.95 0.77 0.6 1.02 0.96 0.78 0.6

∆T 25 24 20 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 16 23 22 19 15.4

kW 1.54 1.57 1.62 1.7 1.66 1.69 1.75 1.8 1.76 1.80 1.86 1.9 1.85 1.89 1.95 2.0 1.93 1.97 2.03 2.1 1.99 2.04 2.11 2.2

750

7.0 7.2 7.4 7.3 7.4 7.6 7.9 7.8 8.0 8.2 8.4 8.3 8.4 8.7 8.9 8.7 8.9 9.1 9.4 9.1 9.3 9.6 9.9

Amps 6.9

HI PR 224 242 255 266.0 252 271 286 298.5 286 308 326 339.5 326 351 371 386.7 367 395 417 435.0 406 436 461 480.6

LO PR 112 119 130 138.8 119 126 138 146.7 123 131 143 152.5 129 138 150 160.1 136 144 158 167.8 140 149 163 173.6

MBh 24.4 24.9 26.1 27.8 23.8 24.3 25.5 27.2 23.3 23.7 24.8 26.5 22.7 23.1 24.2 25.9 21.6 22.0 23.0 24.6 20.0 20.4 21.3 22.8

S/T 1.00 0.98 0.89 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.94 0.8 1.00 1.00 0.97 0.8 1.00 1.00 1.00 0.8 1.00 1.00 1.00 0.8

∆T 24 24 22 19 23 24 23 20 23 23 23 20 22 22 23 20 21 21 22 19 19 20 21 18.2

kW 1.59 1.62 1.67 1.7 1.71 1.74 1.80 1.9 1.81 1.85 1.91 2.0 1.91 1.95 2.01 2.1 1.99 2.03 2.10 2.2 2.06 2.10 2.17 2.2

950

Amps 7.0 7.2 7.4 7.6 7.5 7.7 7.9 8.1 8.0 8.2 8.4 8.7 8.5 8.7 8.9 9.2 9.0 9.1 9.4 9.7 9.4 9.6 9.9 10.2

HI PR 233 251 265 276.1 261 281 297 309.8 297 320 338 352.3 339 364 385 401.3 381 410 433 451.5 421 453 478 498.8

LO PR 116 124 135 144.1 123 131 143 152.2 128 136 149 158.2 134 143 156 166.2 141 150 164 174.2 146 155 169 180.2

MBh 24.0 24.5 25.7 27.4 23.5 23.9 25.1 26.8 22.9 23.4 24.5 26.1 22.4 22.8 23.9 25.5 21.2 21.7 22.7 24.2 19.7 20.1 21.0 22.4

S/T 0.98 0.94 0.85 0.7 1.00 0.98 0.88 0.7 1.00 1.00 0.90 0.7 1.00 1.00 0.93 0.8 1.00 1.00 0.97 0.8 1.00 1.00 0.97 0.8

25 25 24 21 24 25 24 21 23 23 24 21 21 22 22 19.2

∆T 25 25 24 20 25 25 24 21

kW 1.58 1.61 1.66 1.7 1.70 1.73 1.79 1.8 1.80 1.84 1.90 2.0 1.90 1.94 2.00 2.1 1.98 2.02 2.09 2.2 2.04 2.09 2.16 2.2

850

7.1 7.3 7.6 7.5 7.6 7.8 8.1 8.0 8.2 8.4 8.6 8.5 8.6 8.9 9.2 8.9 9.1 9.4 9.7 9.4 9.6 9.8 10.2

Amps 7.0

HI PR 231 249 263 274.2 260 279 295 307.7 295 318 335 349.9 336 362 382 398.5 378 407 430 448.3 418 450 475 495.4

LO PR 116 123 134 143.1 122 130 142 151.2 127 135 148 157.1 133 142 155 165.0 140 149 162 173.0 145 154 168 178.9

MBh 22.8 23.3 24.4 26.0 22.3 22.7 23.8 25.4 21.8 22.2 23.3 24.8 21.2 21.7 22.7 24.2 20.2 20.6 21.6 23.0 18.7 19.1 20.0 21.3

S/T 0.93 0.90 0.81 0.7 0.97 0.93 0.84 0.7 0.99 0.96 0.86 0.7 1.00 0.99 0.89 0.7 1.00 1.00 0.93 0.8 1.00 1.00 0.93 0.8

∆T 26 26 24 21 26 26 25 21 27 26 25 21 26 26 25 21 25 25 24 21 23 23 23 19.8

kW 1.55 1.58 1.63 1.7 1.67 1.71 1.76 1.8 1.77 1.81 1.87 1.9 1.87 1.91 1.97 2.0 1.94 1.99 2.05 2.1 2.01 2.06 2.12 2.2

750

Amps 6.9 7.0 7.2 7.4 7.4 7.5 7.7 7.9 7.9 8.0 8.3 8.5 8.3 8.5 8.7 9.0 8.8 9.0 9.2 9.5 9.2 9.4 9.7 10.0

HI PR 227 244 258 268.7 254 274 289 301.5 289 311 329 342.9 330 355 374 390.5 371 399 421 439.4 410 441 465 485.4

LO PR 113 121 132 140.2 120 127 139 148.2 124 132 145 154.0 131 139 152 161.7 137 146 159 169.5 142 151 165 175.3

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 5

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Cooling Data — GPH1430M41A**

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 23.4 24.2 26.5 - 22.2 23.0 25.2 - 20.6 21.3 23.3 -

8.1 8.4 - 8.5 8.7 8.9 - 9.1 9.3 9.6 - 9.7 9.9 10.1 - 10.2 10.4 10.7 - 10.7 10.9 11.3 -

8.4 8.6 8.9 8.8 9.0 9.2 9.5 9.4 9.6 9.9 10.2 10.0 10.2 10.5 10.8 10.5 10.7 11.1 11.4 11.1 11.3 11.6 12.0

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

∆T 16 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 15 13 10 -

S/T 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.50 -

MBh 27.6 28.6 31.4 - 27.0 28.0 30.6 - 26.3 27.3 29.9 - 25.7 26.6 29.2 - 24.4 25.3 27.7 - 22.6 23.4 25.7 -

kW 1.86 1.90 1.96 - 2.01 2.05 2.12 - 2.13 2.18 2.25 - 2.25 2.30 2.37 - 2.34 2.40 2.48 - 2.43 2.48 2.56 -

1175

HI PR 235 253 267 - 264 284 300 - 300 323 341 - 341 367 388 - 384 413 437 - 424 457 482 -

Amps 8.2 8.4 8.6 - 8.8 8.9 9.2 - 9.4 9.6 9.9 - 9.9 10.2 10.4 - 10.5 10.7 11.0 - 11.0 11.3 11.6 -

LO PR 112 119 130 - 118 126 137 - 123 131 143 - 129 137 150 - 135 144 157 - 140 149 162 -

∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -

kW 1.85 1.89 1.95 - 2.00 2.04 2.11 - 2.12 2.17 2.24 - 2.23 2.28 2.36 - 2.33 2.38 2.46 - 2.41 2.47 2.55 -

MBh 27.2 28.2 30.9 - 26.6 27.5 30.2 - 25.9 26.9 29.5 - 25.3 26.2 28.7 - 24.0 24.9 27.3 - 22.3 23.1 25.3 -

Amps 8.2 8.3 8.6 - 8.7 8.9 9.1 - 9.3 9.5 9.8 - 9.9 10.1 10.4 - 10.4 10.7 11.0 - 11.0 11.2 11.5 -

1050

HI PR 233 251 265 - 262 282 297 - 298 320 338 - 339 365 385 - 381 411 434 - 421 454 479 -

LO PR 111 118 129 - 117 125 136 - 122 130 142 - 128 136 149 - 134 143 156 - 139 148 161 -

MBh 25.1 26.0 28.5 - 24.5 25.4 27.9 - 23.9 24.8 27.2

∆T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

kW 1.81 1.85 1.90 - 1.95 1.99 2.05 - 2.07 2.12 2.18 - 2.18 2.23 2.30 - 2.27 2.32 2.40 - 2.35 2.40 2.48 -

HI PR 226 244 257 - 254 273 289 - 289 311 328 - 329 354 374 - 370 398 420 - 409 440 465 -

Amps 8.0

LO PR 108 115 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 139 151 - 135 143 157 -

920

MBh 28.1 28.9 31.3 33.6 27.4 28.2 30.6 32.8 26.8 27.6 29.8 32.0 26.1 26.9 29.1 31.2 24.8 25.6 27.7 29.7 23.0 23.7 25.6 27.5

S/T 0.86 0.77 0.58 0.4 0.90 0.80 0.61 0.4 0.92 0.82 0.62 0.4 0.95 0.85 0.64 0.4 0.98 0.88 0.67 0.4 0.99 0.89 0.67 0.4

∆T 19 17 14 10 19 18 15 10 19 18 15 10 19 18 15 10 19 18 14 10 18 16 13 9.3

kW 1.88 1.92 1.98 2.0 2.02 2.07 2.14 2.2 2.15 2.20 2.27 2.3 2.27 2.32 2.39 2.5 2.36 2.42 2.50 2.6 2.45 2.50 2.59 2.7

1175

Amps 8.3 8.4 8.7 8.9 8.8 9.0 9.3 9.5 9.5 9.7 9.9 10.3 10.0 10.2 10.5 10.9 10.6 10.8 11.1 11.5 11.1 11.4 11.7 12.1

HI PR 237 255 270 281.3 266 287 303 315.6 303 326 344 359.0 345 371 392 408.8 388 418 441 460.0 429 461 487 508.2

LO PR 113 120 131 139.8 119 127 139 147.7 124 132 144 153.5 130 139 151 161.3 137 145 159 169.0 141 150 164 174.8

MBh 27.7 28.5 30.8 33.1 27.0 27.8 30.1 32.3 26.4 27.2 29.4 31.6 25.7 26.5 28.7 30.8 24.5 25.2 27.3 29.2 22.7 23.3 25.2 27.1

S/T 0.83 0.74 0.56 0.4 0.86 0.77 0.58 0.4 0.88 0.79 0.60 0.4 0.91 0.81 0.61 0.4 0.94 0.84 0.64 0.4 0.95 0.85 0.64 0.4

∆T 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 11 19 17 14 9.8

kW 1.87 1.91 1.97 2.0 2.01 2.06 2.12 2.2 2.14 2.19 2.26 2.3 2.25 2.30 2.38 2.5 2.35 2.40 2.48 2.6 2.43 2.49 2.57 2.7

1050

Amps 8.2

HI PR 236 254 268 279.3 264 285 301 313.4 301 324 342 356.5 343 369 389 406.0 385 415 438 456.8 426 458 484 504.7

LO PR 112 119 130 138.9 119 126 138 146.7 123 131 143 152.5 129 138 150 160.2 136 144 158 167.8 140 149 163 173.6

MBh 25.5 26.3 28.5 30.5 24.9 25.7 27.8 29.8 24.4 25.1 27.1 29.1 23.8 24.5 26.5 28.4 22.6 23.2 25.2 27.0 20.9 21.5 23.3 25.0

S/T 0.80 0.71 0.54 0.3 0.83 0.74 0.56 0.4 0.85 0.76 0.57 0.4 0.88 0.78 0.59 0.4 0.91 0.81 0.61 0.4 0.92 0.82 0.62 0.4

∆T 20 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 20 19 15 11 19 18 14 10.0

kW 1.82 1.86 1.92 2.0 1.96 2.01 2.07 2.1 2.09 2.13 2.20 2.3 2.20 2.25 2.32 2.4 2.29 2.34 2.42 2.5 2.37 2.42 2.50 2.6

920

Amps 8.0 8.2 8.4 8.7 8.6 8.7 9.0 9.3 9.2 9.4 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.8 11.1 10.8 11.0 11.3 11.7

HI PR 229 246 260 271.0 257 276 291 304.0 292 314 332 345.8 332 358 378 393.8 374 402 425 443.1 413 444 469 489.5

LO PR 109 116 126 134.7 115 122 134 142.3 120 127 139 147.9 126 134 146 155.4 132 140 153 162.8 136 145 158 168.4

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

6 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1430M41A** (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 28.6 29.2 31.2 33.4 27.9 28.5 30.5 32.6 27.3 27.9 29.8 31.8 26.6 27.2 29.0 31.0 25.3 25.8 27.6 29.5 23.4 23.9 25.5 27.3

S/T 0.95 0.89 0.72 0.5 0.98 0.92 0.75 0.6 1.00 0.94 0.77 0.6 1.00 0.98 0.79 0.6 1.00 1.00 0.82 0.6 1.00 1.00 0.83 0.6

∆T 21 20 18 14 21 21 18 14 21 21 18 14 21 21 18 14 20 20 18 14 18 19 17 13.3

kW 1.89 1.93 2.00 2.1 2.04 2.09 2.15 2.2 2.17 2.22 2.29 2.4 2.29 2.34 2.41 2.5 2.38 2.44 2.52 2.6 2.47 2.52 2.61 2.7

Amps 8.3 8.5 8.7 9.0 8.9 9.1 9.3 9.6 9.5 9.7 10.0 10.3 10.1 10.3 10.6 11.0 10.7 10.9 11.2 11.6 11.2 11.5 11.8 12.2

HI PR 240 258 272 284.1 269 289 306 318.8 306 329 348 362.6 348 375 396 413.0 392 422 445 464.6 433 466 492 513.3

LO PR 114 121 133 141.2 121 128 140 149.2 125 133 146 155.1 132 140 153 162.9 138 147 160 170.7 143 152 166 176.6

MBh 28.2 28.8 30.7 32.9 27.5 28.1 30.0 32.1 26.9 27.4 29.3 31.3 26.2 26.8 28.6 30.6 24.9 25.4 27.2 29.0 23.1 23.6 25.2 26.9

S/T 0.91 0.85 0.69 0.5 0.94 0.88 0.72 0.5 0.96 0.90 0.74 0.6 1.00 0.93 0.76 0.6 1.00 0.97 0.79 0.6 1.00 0.98 0.80 0.6

∆T 22 21 19 15 23 22 19 15 23 22 19 15 23 22 19 15 22 22 19 15 20 20 18 14.0

kW 1.88 1.92 1.98 2.0 2.03 2.07 2.14 2.2 2.16 2.21 2.28 2.4 2.27 2.32 2.40 2.5 2.37 2.42 2.50 2.6 2.45 2.51 2.59 2.7

Amps 8.3 8.5 8.7 9.0 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.3 10.0 10.3 10.6 10.9 10.6 10.8 11.1 11.5 11.2 11.4 11.7 12.1

HI PR 238 256 271 282.2 267 287 304 316.6 304 327 345 360.1 346 372 393 410.1 389 419 442 461.4 430 463 489 509.8

LO PR 113 121 132 140.3 120 127 139 148.2 125 132 145 154.0 131 139 152 161.8 137 146 159 169.5 142 151 165 175.4

28.9 24.2 24.7 26.4 28.2 23.0 23.5 25.1 26.8 21.3 21.7 23.2 24.8

MBh 26.0 26.6 28.4 30.3 25.4 25.9 27.7 29.6 24.8 25.3 27.1

S/T 0.88 0.82 0.67 0.5 0.91 0.85 0.69 0.5 0.93 0.87 0.71 0.5 0.96 0.90 0.73 0.5 1.00 0.93 0.76 0.6 1.00 0.94 0.77 0.6

∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14.2

kW 1.84 1.88 1.94 2.0 1.98 2.02 2.09 2.2 2.10 2.15 2.22 2.3 2.22 2.26 2.34 2.4 2.31 2.36 2.44 2.5 2.39 2.44 2.53 2.6

8.3 8.5 8.7 8.6 8.8 9.1 9.3 9.3 9.5 9.7 10.0 9.8 10.0 10.3 10.6 10.3 10.6 10.9 11.2 10.9 11.1 11.4 11.8

Amps 8.1

HI PR 231 248 262 273.7 259 279 294 307.1 295 317 335 349.3 336 361 381 397.8 378 406 429 447.5 417 449 474 494.5

LO PR 110 117 128 136.0 116 124 135 143.7 121 128 140 149.4 127 135 147 156.9 133 141 154 164.5 138 146 160 170.1

MBh 29.1 29.6 31.1 33.1 28.4 29.0 30.3 32.4 27.7 28.3 29.6 31.6 27.1 27.6 28.9 30.8 25.7 26.2 27.4 29.3 23.8 24.3 25.4 27.1

S/T 0.99 0.96 0.87 0.7 1.00 0.99 0.90 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.99 0.8 1.00 1.00 0.99 0.8

∆T 23 22 21 18 22 23 21 18 22 22 21 18 21 22 21 19 20 20 21 18 19 19 20 17.1

kW 1.91 1.95 2.01 2.1 2.06 2.10 2.17 2.2 2.19 2.24 2.31 2.4 2.30 2.36 2.43 2.5 2.40 2.46 2.54 2.6 2.49 2.54 2.63 2.7

Amps 8.4 8.6 8.8 9.1 9.0 9.1 9.4 9.7 9.6 9.8 10.1 10.4 10.2 10.4 10.7 11.1 10.7 11.0 11.3 11.7 11.3 11.6 11.9 12.3

HI PR 242 261 275 287.0 272 292 309 322.0 309 333 351 366.2 352 379 400 417.1 396 426 450 469.2 437 471 497 518.5

LO PR 115 123 134 142.7 122 130 142 150.7 127 135 147 156.6 133 142 154 164.5 139 148 162 172.4 144 153 167 178.4

MBh 28.7 29.2 30.6 32.6 28.0 28.5 29.9 31.9 27.3 27.9 29.2 31.1 26.7 27.2 28.5 30.4 25.3 25.8 27.0 28.8 23.5 23.9 25.0 26.7

S/T 0.95 0.92 0.83 0.7 0.99 0.95 0.86 0.7 1.00 0.98 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.94 0.8 1.00 1.00 0.95 0.8

∆T 24 23 22 19 24 24 22 19 24 24 22 19 23 24 23 20 22 23 22 19 21 21 21 18.1

kW 1.90 1.94 2.00 2.1 2.05 2.09 2.16 2.2 2.18 2.22 2.30 2.4 2.29 2.34 2.42 2.5 2.39 2.44 2.52 2.6 2.47 2.53 2.61 2.7

8.5 8.8 9.0 8.9 9.1 9.3 9.6 9.6 9.8 10.0 10.4 10.1 10.3 10.6 11.0 10.7 10.9 11.2 11.6 11.2 11.5 11.8 12.2

Amps 8.4

HI PR 240 259 273 285.0 270 290 307 319.8 307 330 349 363.7 349 376 397 414.2 393 423 447 466.0 434 467 494 514.9

LO PR 115 122 133 141.7 121 129 141 149.7 126 134 146 155.5 132 141 153 163.4 138 147 161 171.2 143 152 166 177.1

MBh 26.4 27.0 28.2 30.1 25.8 26.3 27.6 29.4 25.2 25.7 26.9 28.7 24.6 25.1 26.3 28.0 23.4 23.8 25.0 26.6 21.7 22.1 23.1 24.7

S/T 0.92 0.89 0.80 0.6 0.95 0.92 0.83 0.7 0.97 0.94 0.85 0.7 1.00 0.97 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.92 0.7

∆T 24 24 23 20 25 24 23 20 25 24 23 20 25 24 23 20 23 24 23 20 22 22 21 18.3

kW 1.85 1.89 1.95 2.0 2.00 2.04 2.10 2.2 2.12 2.17 2.24 2.3 2.23 2.28 2.36 2.4 2.33 2.38 2.46 2.5 2.41 2.46 2.55 2.6

Amps 8.2 8.3 8.6 8.8 8.7 8.9 9.1 9.4 9.3 9.5 9.8 10.1 9.9 10.1 10.4 10.7 10.4 10.7 11.0 11.3 11.0 11.2 11.5 11.9

HI PR 233 251 265 276.4 262 282 297 310.2 298 320 338 352.8 339 365 385 401.8 381 410 433 452.0 421 453 479 499.4

LO PR 111 118 129 137.4 117 125 136 145.2 122 130 142 150.9 128 136 149 158.5 134 143 156 166.1 139 148 161 171.8

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1175

1050

920

1175

1050

920

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 7

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Cooling Data — GPH1436M41A**

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 28.1 29.1 31.9 - 26.7 27.7 30.3 - 24.7 25.6 28.1 -

10.3 10.6 - 10.8 11.0 11.3 - 11.5 11.8 12.1 - 12.2 12.5 12.8 - 12.9 13.2 13.5 - 13.5 13.8 14.2 -

10.6 10.9 11.2 11.1 11.3 11.6 12.0 11.9 12.2 12.5 12.9 12.6 12.9 13.2 13.7 13.3 13.6 14.0 14.5 14.0 14.3 14.7 15.2

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -

S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.51 -

MBh 33.7 34.9 38.3 - 32.9 34.1 37.4 - 32.1 33.3 36.5 - 31.4 32.5 35.6 - 29.8 30.9 33.8 - 27.6 28.6 31.3 -

kW 2.35 2.40 2.47 - 2.53 2.58 2.67 - 2.69 2.75 2.84 - 2.83 2.89 2.99 - 2.95 3.02 3.12 - 3.05 3.12 3.23 -

1350

HI PR 242 260 275 - 271 292 308 - 309 332 351 - 351 378 399 - 395 426 449 - 437 470 496 -

Amps 10.4 10.6 10.9 - 11.1 11.3 11.6 - 11.9 12.2 12.5 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.0 14.3 14.7 -

LO PR 111 118 129 - 118 125 137 - 122 130 142 - 128 137 149 - 135 143 156 - 139 148 162 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

kW 2.33 2.38 2.46 - 2.51 2.56 2.65 - 2.67 2.73 2.82 - 2.81 2.87 2.96 - 2.93 2.99 3.09 - 3.03 3.10 3.20 -

MBh 32.7 33.9 37.2 - 32.0 33.1 36.3 - 31.2 32.3 35.4 - 30.4 31.6 34.6 - 28.9 30.0 32.8 - 26.8 27.8 30.4 -

Amps 10.3 10.5 10.8 - 11.0 11.2 11.5 - 11.8 12.1 12.4 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 -

1200

HI PR 239 258 272 - 269 289 305 - 306 329 347 - 348 375 395 - 392 421 445 - 433 466 492 -

LO PR 110 117 128 - 116 124 135 - 121 129 141 - 127 135 148 - 133 142 155 - 138 147 160 -

MBh 30.2 31.3 34.3 - 29.5 30.6 33.5 - 28.8 29.9 32.7

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

S/T 0.70 0.58 0.41 - 0.73 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.67 0.46 - 0.80 0.67 0.47 -

kW 2.28 2.32 2.40 - 2.45 2.50 2.58 - 2.60 2.66 2.75 - 2.74 2.80 2.89 - 2.85 2.92 3.01 - 2.95 3.02 3.12 -

HI PR 232 250 264 - 261 280 296 - 296 319 337 - 338 363 384 - 380 409 432 - 420 452 477 -

Amps 10.1

LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -

1050

MBh 34.3 35.3 38.2 41.0 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.8 35.5 38.1 30.3 31.2 33.8 36.2 28.1 28.9 31.3 33.6

S/T 0.87 0.77 0.59 0.4 0.90 0.80 0.61 0.4 0.92 0.82 0.62 0.4 0.95 0.85 0.64 0.4 0.99 0.88 0.67 0.4 0.99 0.89 0.67 0.4

∆T 20 19 15 11 20 19 15 11 20 19 15 11 21 19 16 11 20 19 15 11 19 17 14 9.9

kW 2.37 2.42 2.50 2.6 2.55 2.61 2.69 2.8 2.71 2.77 2.86 3.0 2.86 2.92 3.01 3.1 2.98 3.04 3.14 3.3 3.08 3.15 3.26 3.4

1350

Amps 10.5 10.7 11.0 11.3 11.2 11.4 11.7 12.1 12.0 12.2 12.6 13.0 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6 14.1 14.4 14.8 15.4

HI PR 244 263 278 289.5 274 295 311 324.9 312 335 354 369.5 355 382 403 420.8 399 430 454 473.4 441 475 502 523.1

LO PR 112 120 131 139.0 119 126 138 146.9 123 131 143 152.7 130 138 151 160.4 136 145 158 168.1 141 150 163 173.8

MBh 33.3 34.3 37.1 39.8 32.5 33.5 36.2 38.9 31.7 32.7 35.4 38.0 31.0 31.9 34.5 37.0 29.4 30.3 32.8 35.2 27.2 28.1 30.4 32.6

S/T 0.83 0.74 0.56 0.4 0.86 0.77 0.58 0.4 0.88 0.78 0.59 0.4 0.91 0.81 0.61 0.4 0.94 0.84 0.64 0.4 0.95 0.85 0.64 0.4

∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 20 16 11 20 18 15 10.3

kW 2.35 2.40 2.48 2.6 2.53 2.59 2.67 2.8 2.69 2.75 2.84 2.9 2.83 2.89 2.99 3.1 2.95 3.02 3.12 3.2 3.05 3.12 3.23 3.3

1200

Amps 10.4

HI PR 242 260 275 286.7 271 292 308 321.7 309 332 351 365.8 352 378 399 416.7 396 426 449 468.8 437 470 497 517.9

LO PR 111 118 129 137.7 118 125 137 145.4 122 130 142 151.2 128 137 149 158.8 135 143 156 166.4 139 148 162 172.1

MBh 30.7 31.6 34.2 36.7 30.0 30.9 33.4 35.9 29.3 30.2 32.6 35.0 28.6 29.4 31.8 34.2 27.1 28.0 30.3 32.5 25.1 25.9 28.0 30.1

S/T 0.80 0.71 0.54 0.3 0.83 0.74 0.56 0.4 0.85 0.76 0.57 0.4 0.87 0.78 0.59 0.4 0.91 0.81 0.61 0.4 0.91 0.82 0.62 0.4

∆T 21 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 20 19 15 10.5

kW 2.29 2.34 2.42 2.5 2.47 2.52 2.60 2.7 2.62 2.68 2.77 2.9 2.76 2.82 2.91 3.0 2.88 2.94 3.04 3.1 2.98 3.04 3.15 3.3

1050

Amps 10.2 10.4 10.6 11.0 10.8 11.1 11.4 11.7 11.6 11.9 12.2 12.6 12.3 12.6 12.9 13.3 13.0 13.3 13.6 14.1 13.7 14.0 14.4 14.8

HI PR 235 252 267 278.1 263 283 299 312.0 299 322 340 354.9 341 367 388 404.2 384 413 436 454.7 424 456 482 502.4

LO PR 108 115 125 133.5 114 121 132 141.1 119 126 138 146.6 125 132 145 154.0 130 139 152 161.4 135 144 157 167.0

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

8 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1436M41A** (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 34.9 35.7 38.1 40.7 34.1 34.8 37.2 39.8 33.3 34.0 36.3 38.8 32.5 33.2 35.4 37.9 30.8 31.5 33.7 36.0 28.6 29.2 31.2 33.3

S/T 0.95 0.89 0.72 0.5 1.00 0.92 0.75 0.6 1.00 0.95 0.77 0.6 1.00 1.00 0.80 0.6 1.00 1.00 0.83 0.6 1.00 1.00 0.83 0.6

∆T 23 22 19 15 23 22 19 15 23 22 19 15 22 23 19 15 21 21 19 15 19 20 18 14.1

kW 2.39 2.44 2.52 2.6 2.57 2.63 2.71 2.8 2.74 2.80 2.89 3.0 2.88 2.94 3.04 3.1 3.00 3.07 3.17 3.3 3.11 3.18 3.28 3.4

1350

Amps 10.5 10.8 11.1 11.4 11.3 11.5 11.8 12.2 12.1 12.3 12.7 13.1 12.8 13.1 13.5 13.9 13.5 13.8 14.2 14.7 14.2 14.5 15.0 15.5

HI PR 247 266 280 292.5 277 298 315 328.2 315 339 358 373.2 359 386 408 425.1 403 434 459 478.2 446 480 507 528.4

LO PR 114 121 132 140.4 120 128 139 148.4 125 133 145 154.2 131 139 152 162.0 137 146 159 169.8 142 151 165 175.6

MBh 33.9 34.6 37.0 39.5 33.1 33.8 36.1 38.6 32.3 33.0 35.3 37.7 31.5 32.2 34.4 36.8 29.9 30.6 32.7 34.9 27.7 28.3 30.3 32.4

S/T 0.91 0.85 0.69 0.5 0.94 0.88 0.72 0.5 0.96 0.90 0.73 0.5 0.99 0.93 0.76 0.6 1.00 0.97 0.79 0.6 1.00 0.98 0.79 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 21 18 14.7

kW 2.37 2.42 2.50 2.6 2.55 2.61 2.69 2.8 2.71 2.77 2.86 3.0 2.86 2.92 3.02 3.1 2.98 3.04 3.14 3.3 3.08 3.15 3.26 3.4

1200

Amps 10.5 10.7 11.0 11.3 11.2 11.4 11.7 12.1 12.0 12.2 12.6 13.0 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6 14.1 14.4 14.9 15.4

HI PR 244 263 278 289.6 274 295 312 324.9 312 336 354 369.5 355 382 404 420.9 399 430 454 473.5 441 475 502 523.2

LO PR 112 120 131 139.1 119 126 138 146.9 123 131 143 152.7 130 138 151 160.4 136 145 158 168.1 141 150 163 173.9

MBh 31.3 31.9 34.1 36.5 30.5 31.2 33.3 35.6 29.8 30.5 32.5 34.8 29.1 29.7 31.8 33.9 27.6 28.2 30.2 32.2 25.6 26.2 27.9 29.9

S/T 0.87 0.82 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.87 0.71 0.5 0.96 0.90 0.73 0.5 0.99 0.93 0.76 0.6 1.00 0.94 0.77 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 22 19 15.0

kW 2.31 2.36 2.43 2.5 2.49 2.54 2.62 2.7 2.65 2.70 2.79 2.9 2.78 2.85 2.94 3.0 2.90 2.97 3.06 3.2 3.00 3.07 3.17 3.3

1050

10.4 10.7 11.1 10.9 11.1 11.5 11.8 11.7 12.0 12.3 12.7 12.4 12.7 13.0 13.5 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0

Amps 10.2

HI PR 237 255 269 280.9 266 286 302 315.2 302 325 344 358.5 344 371 391 408.3 388 417 440 459.3 428 461 487 507.5

LO PR 109 116 127 134.9 115 123 134 142.5 120 127 139 148.1 126 134 146 155.6 132 140 153 163.0 136 145 158 168.6

MBh 35.5 36.2 37.9 40.4 34.7 35.3 37.0 39.5 33.8 34.5 36.1 38.6 33.0 33.7 35.3 37.6 31.4 32.0 33.5 35.7 29.1 29.6 31.0 33.1

S/T 1.00 0.96 0.87 0.7 1.00 1.00 0.90 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.99 0.8 1.00 1.00 1.00 0.8

∆T 24 24 22 19 24 24 23 20 23 23 23 20 22 23 23 20 21 22 23 19 20 20 21 18.2

kW 2.41 2.46 2.54 2.6 2.59 2.65 2.73 2.8 2.76 2.82 2.91 3.0 2.90 2.97 3.07 3.2 3.03 3.09 3.20 3.3 3.13 3.20 3.31 3.4

1350

Amps 10.6 10.8 11.1 11.5 11.4 11.6 11.9 12.3 12.2 12.4 12.8 13.2 12.9 13.2 13.6 14.0 13.6 13.9 14.3 14.8 14.3 14.7 15.1 15.6

HI PR 249 268 283 295.4 280 301 318 331.5 318 342 361 377.0 362 390 412 429.3 408 439 463 483.0 450 485 512 533.7

LO PR 115 122 133 141.9 121 129 141 149.9 126 134 146 155.8 132 141 154 163.6 139 147 161 171.5 143 153 167 177.4

MBh 34.5 35.1 36.8 39.3 33.7 34.3 35.9 38.3 32.9 33.5 35.1 37.4 32.1 32.7 34.2 36.5 30.5 31.0 32.5 34.7 28.2 28.8 30.1 32.1

S/T 0.95 0.92 0.83 0.7 0.98 0.95 0.86 0.7 1.00 0.97 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.94 0.8 1.00 1.00 0.95 0.8

25 25 24 20 25 25 24 21 23 24 23 20 22 22 22 19.0

∆T 25 25 23 20 25 25 24 20

kW 2.39 2.44 2.52 2.6 2.57 2.63 2.71 2.8 2.74 2.80 2.89 3.0 2.88 2.94 3.04 3.1 3.00 3.07 3.17 3.3 3.11 3.18 3.28 3.4

1200

10.8 11.1 11.4 11.3 11.5 11.8 12.2 12.1 12.3 12.7 13.1 12.8 13.1 13.5 13.9 13.5 13.8 14.2 14.7 14.2 14.5 15.0 15.5

Amps 10.5

HI PR 247 266 280 292.5 277 298 315 328.2 315 339 358 373.2 359 386 408 425.1 403 434 459 478.2 446 480 507 528.4

LO PR 114 121 132 140.4 120 128 139 148.4 125 133 145 154.2 131 139 152 162.0 137 146 159 169.8 142 151 165 175.6

MBh 31.8 32.4 34.0 36.2 31.1 31.7 33.2 35.4 30.3 30.9 32.4 34.5 29.6 30.2 31.6 33.7 28.1 28.7 30.0 32.0 26.0 26.5 27.8 29.7

S/T 0.92 0.88 0.80 0.6 0.95 0.92 0.83 0.7 0.97 0.94 0.85 0.7 1.00 0.97 0.87 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.92 0.7

∆T 25 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 23 22 19.3

kW 2.33 2.38 2.45 2.5 2.51 2.56 2.65 2.7 2.67 2.73 2.81 2.9 2.81 2.87 2.96 3.1 2.93 2.99 3.09 3.2 3.03 3.10 3.20 3.3

1050

Amps 10.3 10.5 10.8 11.1 11.0 11.2 11.5 11.9 11.8 12.1 12.4 12.8 12.5 12.8 13.1 13.6 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1

HI PR 239 258 272 283.7 269 289 305 318.3 305 329 347 362.0 348 374 395 412.3 391 421 445 463.9 432 465 491 512.5

LO PR 110 117 128 136.2 116 124 135 143.9 121 129 140 149.6 127 135 148 157.1 133 142 155 164.7 138 147 160 170.3

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 9

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Cooling Data — GPH1442M41A**

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

16.3 15.9 16.2 16.7 17.3 16.8 17.1 17.6 18.2 17.7 18.0 18.6 19.2

22 21 17 12 23 21 17 12 22 20 17 12 21 19 16 10.8

13.3 - 13.5 13.8 14.2 - 14.5 14.8 15.2 - 15.4 15.7 16.2 - 16.2 16.6 17.1 - 17.1 17.5 18.0 -

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

MBh 40.2 41.6 45.6 - 39.2 40.7 44.6 - 38.3 39.7 43.5 - 37.4 38.7 42.4 - 35.5 36.8 40.3 - 32.9 34.1 37.3 -

kW 2.82 2.88 2.98 - 3.04 3.11 3.21 - 3.24 3.31 3.42 - 3.41 3.48 3.60 - 3.55 3.63 3.76 - 3.68 3.76 3.89 -

HI PR 251 271 286 - 282 304 321 - 321 345 365 - 365 393 415 - 411 442 467 - 454 489 516 -

Amps 13.1 13.3 13.7 - 13.9 14.2 14.6 - 15.0 15.3 15.7 - 15.9 16.2 16.7 - 16.8 17.1 17.6 - 17.7 18.0 18.6 -

LO PR 108 115 126 - 115 122 133 - 119 127 138 - 125 133 145 - 131 139 152 - 136 144 157 -

∆T 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.79 0.66 0.46 -

MBh 39.0 40.4 44.3 - 38.1 39.5 43.3 - 37.2 38.5 42.2 - 36.3 37.6 41.2 - 34.5 35.7 39.1 - 31.9 33.1 36.3 -

kW 2.80 2.86 2.95 - 3.02 3.08 3.18 - 3.21 3.28 3.39 - 3.38 3.46 3.57 - 3.52 3.60 3.72 - 3.65 3.73 3.86 -

HI PR 249 268 283 - 279 301 317 - 318 342 361 - 362 389 411 - 407 438 463 - 450 484 511 -

Amps 13.0 13.2 13.6 - 13.8 14.1 14.5 - 14.9 15.2 15.6 - 15.8 16.1 16.6 - 16.6 17.0 17.5 - 17.5 17.9 18.4 -

LO PR 107 114 125 - 113 121 132 - 118 125 137 - 124 132 144 - 130 138 151 - 134 143 156 -

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.77 0.64 0.44 -

kW 2.73 2.79 2.88 - 2.94 3.01 3.11 - 3.13 3.20 3.30 - 3.30 3.37 3.48 - 3.44 3.51 3.63 - 3.56 3.64 3.76 -

MBh 36.0 37.3 40.9 - 35.2 36.4 39.9 - 34.3 35.6 39.0 - 33.5 34.7 38.0 - 31.8 33.0 36.1 - 29.5 30.5 33.5 -

Amps 12.7 12.9

HI PR 241 260 274 - 271 292 308 - 308 332 350 - 351 378 399 - 395 425 449 - 436 470 496 -

LO PR 104 111 121 - 110 117 128 - 114 122 133 - 120 128 139 - 126 134 146 - 130 138 151 -

MBh 40.9 42.1 45.5 48.9 39.9 41.1 44.5 47.7 39.0 40.1 43.4 46.6 38.0 39.1 42.4 45.5 36.1 37.2 40.2 43.2 33.4 34.4 37.3 40.0

S/T 0.83 0.74 0.56 0.4 0.86 0.76 0.58 0.4 0.88 0.78 0.59 0.4 0.91 0.81 0.61 0.4 0.94 0.84 0.64 0.4 0.95 0.85 0.64 0.4

∆T 21 20 16 11 21 20 16 11 22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10.4

kW 2.85 2.91 3.00 3.1 3.07 3.14 3.24 3.3 3.26 3.34 3.45 3.6 3.44 3.51 3.63 3.8 3.58 3.67 3.79 3.9 3.71 3.80 3.92 4.1

Amps 13.2 13.4 13.8 14.2 14.1 14.4 14.8 15.2 15.1 15.4 15.9 16.4 16.0 16.4 16.8 17.4 16.9 17.3 17.8 18.4 17.8 18.2 18.7 19.4

HI PR 254 273 289 301.1 285 307 324 337.8 324 349 368 384.2 369 397 420 437.6 415 447 472 492.3 459 494 522 543.9

LO PR 109 116 127 135.4 116 123 134 143.1 120 128 140 148.7 126 134 147 156.2 132 141 154 163.7 137 146 159 169.3

MBh 39.7 40.8 44.2 47.4 38.7 39.9 43.2 46.3 37.8 38.9 42.2 45.2 36.9 38.0 41.1 44.1 35.1 36.1 39.1 41.9 32.5 33.4 36.2 38.8

S/T 0.79 0.70 0.53 0.3 0.82 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.86 0.77 0.58 0.4 0.90 0.80 0.61 0.4 0.90 0.81 0.61 0.4

∆T 22 20 17 12 22 21 17 12

kW 2.82 2.88 2.98 3.1 3.04 3.11 3.21 3.3 3.24 3.31 3.42 3.5 3.41 3.49 3.60 3.7 3.55 3.63 3.76 3.9 3.68 3.76 3.89 4.0

HI PR 252 271 286 298.1 282 304 321 334.5 321 345 365 380.4 366 393 415 433.3 411 443 467 487.4 454 489 516 538.6

Amps 13.1 13.3 13.7 14.1 14.0 14.2 14.6 15.1 15.0 15.3 15.7

LO PR 108 115 126 134.1 115 122 133 141.7 119 127 138 147.2 125 133 145 154.7 131 139 152 162.1 136 144 157 167.7

MBh 36.6 37.7 40.8 43.8 35.8 36.8 39.9 42.8 34.9 35.9 38.9 41.8 34.1 35.1 38.0 40.7 32.4 33.3 36.1 38.7 30.0 30.9 33.4 35.8

S/T 0.76 0.68 0.51 0.3 0.79 0.70 0.53 0.3 0.81 0.72 0.55 0.4 0.83 0.74 0.56 0.4 0.86 0.77 0.58 0.4 0.87 0.78 0.59 0.4

∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11.0

kW 2.76 2.81 2.90 3.0 2.97 3.03 3.13 3.2 3.16 3.23 3.33 3.4 3.32 3.40 3.51 3.6 3.46 3.54 3.66 3.8 3.59 3.67 3.79 3.9

Amps 12.8 13.0 13.4 13.8 13.6 13.9 14.3 14.8 14.6 14.9 15.4 15.9 15.5 15.8 16.3 16.8 16.4 16.7 17.2 17.8 17.2 17.6 18.1 18.7

HI PR 244 263 277 289.1 274 295 311 324.4 311 335 354 369.0 355 382 403 420.3 399 429 453 472.8 441 474 501 522.4

LO PR 105 112 122 130.1 111 118 129 137.4 115 123 134 142.8 121 129 141 150.0 127 135 148 157.2 131 140 153 162.6

1300

1140

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1460

1300

1140

1460

10 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1442M41A** (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 39.6 40.5 43.3 46.3 38.7 39.5 42.2 45.1 36.7 37.6 40.1 42.9 34.0 34.8 37.2 39.7

S/T 0.91 0.85 0.69 0.5 0.94 0.88 0.72 0.5 0.96 0.90 0.73 0.5 1.00 0.93 0.76 0.6 1.00 0.97 0.79 0.6 1.00 1.00 0.79 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 22 19 14.8

kW 2.87 2.93 3.03 3.1 3.09 3.16 3.26 3.4 3.29 3.37 3.48 3.6 3.47 3.54 3.66 3.8 3.62 3.70 3.82 4.0 3.74 3.83 3.96 4.1

1460

Amps 13.3 13.5 13.9 14.3 14.2 14.5 14.9 15.4 15.2 15.5 16.0 16.5 16.1 16.5 17.0 17.5 17.1 17.4 17.9 18.6 18.0 18.3 18.9 19.5

HI PR 257 276 292 304.1 288 310 327 341.2 327 352 372 388.1 373 401 424 442.0 420 452 477 497.3 464 499 527 549.4

LO PR 111 118 128 136.8 117 124 136 144.5 121 129 141 150.2 128 136 148 157.8 134 142 155 165.4 138 147 161 171.1

MBh 40.4 41.3 44.1 47.1 39.4 40.3 43.1 46.0 38.5 39.3 42.0 44.9 37.6 38.4 41.0 43.8 35.7 36.5 39.0 41.6 33.0 33.8 36.1 38.6

S/T 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.86 0.70 0.5 0.95 0.89 0.72 0.5 0.98 0.92 0.75 0.6 0.99 0.93 0.76 0.6

∆T 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 15.4

kW 2.85 2.91 3.00 3.1 3.07 3.14 3.24 3.3 3.26 3.34 3.45 3.6 3.44 3.51 3.63 3.8 3.59 3.67 3.79 3.9 3.71 3.80 3.92 4.1

1300

Amps 13.2 13.4 13.8 14.2 14.1 14.4 14.8 15.2 15.1 15.4 15.9 16.4 16.0 16.4 16.8 17.4 16.9 17.3 17.8 18.4 17.8 18.2 18.7 19.4

HI PR 254 273 289 301.1 285 307 324 337.9 324 349 368 384.3 369 397 420 437.6 415 447 472 492.3 459 494 522 544.0

LO PR 110 117 127 135.5 116 123 134 143.1 120 128 140 148.7 126 134 147 156.2 132 141 154 163.7 137 146 159 169.4

MBh 37.3 38.1 40.7 43.5 36.4 37.2 39.7 42.5 35.5 36.3 38.8 41.5 34.7 35.4 37.8 40.5 32.9 33.6 36.0 38.4 30.5 31.2 33.3 35.6

S/T 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.88 0.83 0.68 0.5 0.91 0.86 0.70 0.5 0.95 0.89 0.72 0.5 0.96 0.90 0.73 0.5

∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 24 21 17 25 24 21 17 24 23 20 15.7

kW 2.78 2.84 2.93 3.0 2.99 3.06 3.16 3.3 3.18 3.25 3.36 3.5 3.35 3.43 3.54 3.7 3.49 3.57 3.69 3.8 3.62 3.70 3.82 4.0

1140

13.1 13.5 13.9 13.7 14.0 14.4 14.9 14.7 15.1 15.5 16.0 15.6 16.0 16.4 17.0 16.5 16.9 17.4 17.9 17.4 17.7 18.3 18.9

Amps 12.9

HI PR 246 265 280 292.1 277 298 314 327.7 314 338 357 372.7 358 385 407 424.5 403 434 458 477.6 445 479 506 527.7

LO PR 106 113 123 131.4 112 119 130 138.8 117 124 135 144.3 123 130 142 151.5 128 137 149 158.8 133 141 154 164.3

MBh 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.1 40.3 41.1 43.1 45.9 39.4 40.1 42.0 44.8 37.4 38.1 39.9 42.6 34.6 35.3 37.0 39.4

S/T 0.95 0.92 0.83 0.7 0.98 0.95 0.86 0.7 1.00 0.97 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.94 0.8 1.00 1.00 0.95 0.8

∆T 25 25 24 20 26 25 24 21 25 25 24 21 25 25 24 21 24 24 24 20 22 22 22 19.1

kW 2.89 2.96 3.05 3.1 3.12 3.19 3.29 3.4 3.32 3.39 3.51 3.6 3.50 3.57 3.69 3.8 3.65 3.73 3.85 4.0 3.78 3.86 3.99 4.1

1460

Amps 13.4 13.6 14.0 14.5 14.3 14.6 15.0 15.5 15.3 15.7 16.1 16.7 16.3 16.6 17.1 17.7 17.2 17.6 18.1 18.7 18.1 18.5 19.1 19.7

HI PR 259 279 294 307.2 291 313 330 344.7 331 356 376 392.0 377 405 428 446.4 424 456 482 502.2 468 504 532 554.9

LO PR 112 119 130 138.2 118 126 137 146.0 123 130 142 151.7 129 137 150 159.4 135 144 157 167.0 140 149 162 172.8

MBh 41.1 41.9 43.9 46.8 40.1 40.9 42.8 45.7 39.2 39.9 41.8 44.6 38.2 39.0 40.8 43.5 36.3 37.0 38.8 41.3 33.6 34.3 35.9 38.3

S/T 0.90 0.87 0.79 0.6 0.94 0.90 0.82 0.7 0.96 0.93 0.84 0.7 0.99 0.96 0.86 0.7 1.00 0.99 0.90 0.7 1.00 1.00 0.90 0.7

27 26 25 21 27 26 25 22 26 26 25 21 24 24 23 19.9

∆T 26 26 24 21 27 26 25 21

kW 2.87 2.93 3.03 3.1 3.09 3.16 3.26 3.4 3.29 3.37 3.48 3.6 3.47 3.54 3.66 3.8 3.62 3.70 3.82 4.0 3.74 3.83 3.96 4.1

1300

13.5 13.9 14.3 14.2 14.5 14.9 15.4 15.2 15.5 16.0 16.5 16.1 16.5 17.0 17.5 17.1 17.4 17.9 18.6 18.0 18.3 18.9 19.5

Amps 13.3

HI PR 257 276 292 304.1 288 310 327 341.2 327 352 372 388.1 373 401 424 442.0 420 452 477 497.3 464 499 527 549.4

LO PR 111 118 128 136.8 117 124 136 144.5 121 129 141 150.2 128 136 148 157.8 134 142 155 165.4 138 147 161 171.1

MBh 37.9 38.6 40.5 43.2 37.0 37.7 39.5 42.2 36.2 36.9 38.6 41.2 35.3 36.0 37.7 40.2 33.5 34.2 35.8 38.2 31.0 31.6 33.1 35.4

S/T 0.87 0.84 0.76 0.6 0.90 0.87 0.79 0.6 0.93 0.89 0.81 0.7 0.96 0.92 0.83 0.7 0.99 0.96 0.87 0.7 1.00 0.97 0.87 0.7

∆T 27 26 25 21 27 27 25 22 27 27 25 22 27 27 25 22 27 26 25 22 25 25 23 20.2

kW 2.80 2.86 2.95 3.0 3.02 3.08 3.18 3.3 3.21 3.28 3.39 3.5 3.38 3.45 3.57 3.7 3.52 3.60 3.72 3.9 3.65 3.73 3.86 4.0

1140

Amps 13.0 13.2 13.6 14.0 13.8 14.1 14.5 15.0 14.9 15.2 15.6 16.1 15.7 16.1 16.6 17.1 16.6 17.0 17.5 18.1 17.5 17.9 18.4 19.1

HI PR 249 268 283 295.0 279 301 317 331.0 318 342 361 376.5 362 389 411 428.8 407 438 462 482.4 450 484 511 532.9

LO PR 107 114 125 132.7 113 121 132 140.2 118 125 137 145.7 124 132 144 153.1 130 138 151 160.4 134 143 156 165.9

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 11

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Cooling Data — GPH1448M41A**

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

22 20 17 12 22 21 17 12 22 20 17 12 21 19 16 10.7

∆T 22 20 17 11 22 20 17 12

kW 3.22 3.29 3.40 3.5 3.47 3.55 3.66 3.8 3.69 3.77 3.90 4.0 3.89 3.97 4.11 4.2 4.05 4.14 4.28 4.4 4.20 4.29 4.43 4.6

1600

13.9 14.3 14.8 14.6 14.9 15.3 15.9 15.7 16.1 16.6 17.1 16.7 17.1 17.6 18.2 17.7 18.1 18.6 19.3 18.6 19.1 19.7 20.4

Amps 13.6

HI PR 250 269 284 295.8 280 301 318 331.9 319 343 362 377.5 363 390 412 430.0 408 439 464 483.7 451 485 512 534.4

LO PR 111 118 129 137.0 117 124 136 144.7 122 129 141 150.4 128 136 148 158.0 134 142 155 165.6 138 147 161 171.2

MBh 42.9 44.1 47.8 51.3 41.9 43.1 46.7 50.1 40.9 42.1 45.5 48.9 39.9 41.1 44.4 47.7 37.9 39.0 42.2 45.3 35.1 36.1 39.1 42.0

S/T 0.79 0.71 0.54 0.3 0.82 0.74 0.56 0.4 0.84 0.75 0.57 0.4 0.87 0.78 0.59 0.4 0.90 0.81 0.61 0.4 0.91 0.81 0.62 0.4

∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 10.9

kW 3.15 3.21 3.31 3.4 3.39 3.46 3.57 3.7 3.60 3.68 3.80 3.9 3.79 3.87 4.00 4.1 3.95 4.04 4.17 4.3 4.09 4.18 4.32 4.5

1400

Amps 13.3 13.6 14.0 14.4 14.2 14.5 15.0 15.5 15.3 15.7 16.1 16.7 16.3 16.6 17.1 17.7 17.2 17.6 18.2 18.8 18.2 18.6 19.2 19.8

HI PR 242 261 275 286.9 272 292 309 322.0 309 332 351 366.2 352 379 400 417.1 396 426 450 469.2 437 471 497 518.4

LO PR 107 114 125 132.9 113 121 132 140.4 118 125 137 145.9 124 132 144 153.2 130 138 151 160.6 134 143 156 166.1

13.5 13.8 - 14.1 14.4 14.8 - 15.2 15.5 16.0 - 16.1 16.5 17.0 - 17.1 17.5 18.0 - 18.0 18.4 19.0 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -

MBh 47.0 48.8 53.4 - 45.9 47.6 52.2 - 44.8 46.5 50.9 - 43.8 45.4 49.7 - 41.6 43.1 47.2 - 38.5 39.9 43.7 -

kW 3.22 3.29 3.40 - 3.47 3.55 3.66 - 3.69 3.77 3.90 - 3.89 3.97 4.10 - 4.05 4.14 4.28 - 4.19 4.29 4.43 -

1800

HI PR 250 269 284 - 280 301 318 - 318 343 362 - 363 390 412 - 408 439 464 - 451 485 512 -

Amps 13.6 13.9 14.3 - 14.6 14.9 15.3 - 15.7 16.1 16.5 - 16.7 17.1 17.6 - 17.7 18.1 18.6 - 18.6 19.1 19.7 -

LO PR 111 118 129 - 117 124 136 - 122 129 141 - 128 136 148 - 134 142 155 - 138 147 161 -

∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -

MBh 45.7 47.3 51.9 - 44.6 46.2 50.7 - 43.5 45.1 49.4 - 42.5 44.0 48.2 - 40.4 41.8 45.8 - 37.4 38.7 42.5 -

kW 3.20 3.26 3.37 - 3.44 3.52 3.63 - 3.66 3.74 3.86 - 3.85 3.94 4.07 - 4.02 4.11 4.24 - 4.16 4.25 4.40 -

1600

HI PR 247 266 281 - 277 298 315 - 315 339 358 - 359 386 408 - 404 435 459 - 446 480 507 -

Amps 13.5 13.8 14.2 - 14.5 14.8 15.2 - 15.6 15.9 16.4 - 16.6 16.9 17.4 - 17.5 17.9 18.5 - 18.5 18.9 19.5 -

LO PR 110 117 127 - 116 123 135 - 120 128 140 - 126 135 147 - 132 141 154 - 137 146 159 -

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -

MBh 42.1 43.7 47.9 - 41.2 42.7 46.8 - 40.2 41.7 45.6 - 39.2 40.6 44.5 - 37.2 38.6 42.3 - 34.5 35.8 39.2 -

kW 3.12 3.19 3.29 - 3.36 3.43 3.54 - 3.57 3.65 3.77 - 3.76 3.84 3.97 - 3.92 4.00 4.14 - 4.05 4.14 4.28 -

1400

Amps 13.2

HI PR 240 258 272 - 269 289 306 - 306 329 348 - 348 375 396 - 392 422 445 - 433 466 492 -

LO PR 106 113 123 - 112 120 130 - 117 124 136 - 123 130 142 - 129 137 149 - 133 141 154 -

MBh 47.8 49.2 53.3 57.2 46.7 48.1 52.1 55.9 45.6 47.0 50.8 54.6 44.5 45.8 49.6 53.2 42.3 43.5 47.1 50.6 39.2 40.3 43.6 46.8

S/T 0.86 0.77 0.58 0.4 0.89 0.80 0.61 0.4 0.92 0.82 0.62 0.4 0.95 0.85 0.64 0.4 0.98 0.88 0.66 0.4 0.99 0.89 0.67 0.4

∆T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10.3

kW 3.25 3.32 3.42 3.5 3.50 3.58 3.69 3.8 3.72 3.81 3.93 4.1 3.92 4.01 4.14 4.3 4.09 4.18 4.32 4.5 4.23 4.33 4.47 4.6

1800

Amps 13.7 14.0 14.4 14.9 14.7 15.0 15.5 16.0 15.9 16.2 16.7 17.3 16.8 17.2 17.7 18.4 17.8 18.2 18.8 19.5 18.8 19.2 19.8 20.5

HI PR 252 271 286 298.8 283 304 321 335.3 322 346 366 381.3 366 394 416 434.3 412 444 468 488.5 455 490 518 539.8

LO PR 112 119 130 138.3 118 126 137 146.2 123 131 143 151.9 129 137 150 159.6 135 144 157 167.2 140 149 162 173.0

MBh 46.4 47.8 51.8 55.5 45.4 46.7 50.6 54.3 44.3 45.6 49.3 53.0 43.2 44.5 48.1 51.7 41.0 42.3 45.7 49.1 38.0 39.1 42.4 45.5

S/T 0.82 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.87 0.78 0.59 0.4 0.90 0.81 0.61 0.4 0.94 0.84 0.63 0.4 0.94 0.84 0.64 0.4

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

12 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1448M41A** (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 48.7 49.7 53.1 56.8 47.6 48.6 51.9 55.5 46.4 47.4 50.7 54.2 45.3 46.3 49.4 52.9 43.0 44.0 47.0 50.2 39.9 40.7 43.5 46.5

S/T 0.95 0.89 0.72 0.5 1.00 0.92 0.75 0.6 1.00 0.94 0.77 0.6 1.00 1.00 0.79 0.6 1.00 1.00 0.82 0.6 1.00 1.00 0.83 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 23 24 20 16 22 22 20 16 20 21 18 14.7

kW 3.27 3.34 3.45 3.6 3.53 3.61 3.72 3.8 3.75 3.84 3.96 4.1 3.95 4.04 4.17 4.3 4.12 4.21 4.35 4.5 4.27 4.36 4.51 4.7

1800

Amps 13.8 14.1 14.5 15.0 14.8 15.2 15.6 16.1 16.0 16.3 16.8 17.4 17.0 17.4 17.9 18.5 18.0 18.4 19.0 19.6 19.0 19.4 20.0 20.7

HI PR 255 274 289 301.8 286 307 325 338.6 325 350 369 385.1 370 398 421 438.6 416 448 473 493.5 460 495 523 545.2

LO PR 113 120 131 139.7 119 127 139 147.6 124 132 144 153.4 130 139 151 161.2 137 145 159 168.9 141 150 164 174.7

MBh 47.3 48.3 51.6 55.2 46.2 47.2 50.4 53.9 45.1 46.1 49.2 52.6 44.0 44.9 48.0 51.3 41.8 42.7 45.6 48.7 38.7 39.5 42.2 45.2

S/T 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.96 0.90 0.73 0.5 0.99 0.93 0.76 0.6 1.00 0.96 0.78 0.6 1.00 0.97 0.79 0.6

∆T 25 23 20 16 25 24 21 17 25 24 21 17 25 24 21 17 24 24 21 16 22 22 19 15.3

kW 3.25 3.32 3.42 3.5 3.50 3.58 3.69 3.8 3.72 3.81 3.93 4.1 3.92 4.01 4.14 4.3 4.09 4.18 4.32 4.5 4.23 4.33 4.47 4.6

1600

Amps 13.7 14.0 14.4 14.9 14.7 15.0 15.5 16.0 15.9 16.2 16.7 17.3 16.8 17.2 17.7 18.4 17.8 18.2 18.8 19.5 18.8 19.2 19.8 20.5

HI PR 252 271 286 298.8 283 304 321 335.3 322 346 366 381.3 366 394 416 434.3 412 444 468 488.6 455 490 518 539.8

LO PR 112 119 130 138.3 118 126 137 146.2 123 131 143 151.9 129 137 150 159.6 135 144 157 167.2 140 149 162 173.0

MBh 43.6 44.6 47.6 50.9 42.6 43.5 46.5 49.7 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 38.6 39.4 42.1 45.0 35.7 36.5 39.0 41.7

S/T 0.87 0.82 0.66 0.5 0.90 0.85 0.69 0.5 0.92 0.87 0.71 0.5 0.95 0.89 0.73 0.5 0.99 0.93 0.76 0.6 1.00 0.94 0.76 0.6

∆T 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 20 15.6

kW 3.17 3.24 3.34 3.4 3.42 3.49 3.60 3.7 3.63 3.71 3.83 4.0 3.82 3.91 4.04 4.2 3.98 4.07 4.21 4.4 4.12 4.22 4.36 4.5

1400

13.7 14.1 14.5 14.3 14.7 15.1 15.6 15.5 15.8 16.3 16.8 16.4 16.8 17.3 17.9 17.4 17.8 18.3 19.0 18.3 18.7 19.3 20.0

Amps 13.4

HI PR 245 263 278 289.8 274 295 312 325.2 312 336 355 369.9 355 383 404 421.3 400 430 454 473.9 442 475 502 523.6

LO PR 108 115 126 134.2 115 122 133 141.8 119 127 138 147.4 125 133 145 154.8 131 140 152 162.2 136 144 158 167.8

MBh 49.5 50.5 52.9 56.4 48.4 49.3 51.7 55.1 47.2 48.1 50.4 53.8 46.1 47.0 49.2 52.5 43.8 44.6 46.7 49.9 40.5 41.3 43.3 46.2

S/T 0.99 0.96 0.86 0.7 1.00 0.99 0.89 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.98 0.8 1.00 1.00 0.99 0.8

∆T 25 25 23 20 25 25 24 20 24 25 24 20 24 24 24 21 22 23 23 20 21 21 22 19.0

kW 3.30 3.37 3.48 3.6 3.56 3.64 3.75 3.9 3.79 3.87 4.00 4.1 3.99 4.07 4.21 4.4 4.16 4.25 4.39 4.5 4.30 4.40 4.55 4.7

1800

Amps 13.9 14.2 14.7 15.1 14.9 15.3 15.7 16.3 16.1 16.5 17.0 17.6 17.1 17.5 18.0 18.7 18.1 18.5 19.1 19.8 19.1 19.6 20.2 20.9

HI PR 257 277 292 304.8 289 311 328 342.0 328 353 373 389.0 374 402 425 443.0 421 453 478 498.4 465 500 528 550.7

LO PR 114 121 133 141.1 121 128 140 149.1 125 133 146 155.0 132 140 153 162.8 138 147 160 170.6 143 152 166 176.5

MBh 48.1 49.0 51.3 54.8 47.0 47.9 50.1 53.5 45.9 46.7 49.0 52.2 44.7 45.6 47.8 51.0 42.5 43.3 45.4 48.4 39.4 40.1 42.0 44.8

S/T 0.95 0.91 0.82 0.7 0.98 0.95 0.85 0.7 1.00 0.97 0.88 0.7 1.00 1.00 0.90 0.7 1.00 1.00 0.94 0.8 1.00 1.00 0.95 0.8

26 26 25 21 26 26 25 21 24 25 24 21 23 23 23 19.8

∆T 26 26 24 21 26 26 25 21

kW 3.27 3.34 3.45 3.6 3.53 3.61 3.72 3.8 3.75 3.84 3.96 4.1 3.95 4.04 4.17 4.3 4.12 4.21 4.35 4.5 4.27 4.36 4.51 4.7

1600

14.1 14.5 15.0 14.8 15.2 15.6 16.1 16.0 16.3 16.8 17.4 17.0 17.4 17.9 18.5 18.0 18.4 19.0 19.6 19.0 19.4 20.0 20.7

Amps 13.8

HI PR 255 274 289 301.8 286 307 325 338.6 325 350 369 385.1 370 398 421 438.6 416 448 473 493.5 460 495 523 545.2

LO PR 113 120 131 139.7 119 127 139 147.6 124 132 144 153.4 130 139 151 161.2 137 145 159 168.9 141 150 164 174.7

MBh 44.4 45.2 47.4 50.6 43.4 44.2 46.3 49.4 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.0 39.2 40.0 41.9 44.7 36.3 37.0 38.8 41.4

S/T 0.91 0.88 0.79 0.6 0.95 0.91 0.82 0.7 0.97 0.94 0.84 0.7 1.00 0.97 0.87 0.7 1.00 1.00 0.90 0.7 1.00 1.00 0.91 0.7

∆T 27 26 25 21 27 26 25 22 27 26 25 22 27 27 25 22 26 26 25 22 24 24 23 20.1

kW 3.20 3.26 3.37 3.5 3.44 3.52 3.63 3.8 3.66 3.74 3.86 4.0 3.85 3.94 4.07 4.2 4.02 4.11 4.24 4.4 4.16 4.25 4.39 4.5

1400

Amps 13.5 13.8 14.2 14.7 14.5 14.8 15.2 15.7 15.6 15.9 16.4 17.0 16.6 16.9 17.4 18.0 17.5 17.9 18.5 19.1 18.5 18.9 19.5 20.2

HI PR 247 266 281 292.7 277 298 315 328.5 315 339 358 373.6 359 386 408 425.5 404 435 459 478.7 446 480 507 528.9

LO PR 110 117 127 135.5 116 123 134 143.2 120 128 140 148.8 126 134 147 156.3 132 141 154 163.8 137 146 159 169.5

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 13

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Cooling Data — GPH1460M41A** – High Stage

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

22 21 17 12 23 21 17 12 22 20 17 12 21 19 16 10.8

∆T 22 20 17 11 22 21 17 12

kW 4.07 4.16 4.29 4.4 4.39 4.49 4.64 4.8 4.68 4.79 4.95 5.1 4.93 5.04 5.21 5.4 5.15 5.26 5.44 5.6 5.33 5.45 5.64 5.8

1850

6.6 7.2 7.8 7.6 8.0 8.6 9.3 9.1 9.6 10.2 11.0 10.4 10.9 11.6 12.5 11.8 12.3 13.0 13.9 13.1 13.6 14.4 15.4

Amps 6.3

HI PR 258 277 293 305.5 289 311 329 342.8 329 354 374 389.8 375 403 426 444.0 421 454 479 499.5 466 501 529 551.9

LO PR 107 114 124 132.5 113 120 131 140.0 118 125 137 145.5 124 131 144 152.9 130 138 150 160.2 134 143 156 165.7

MBh 51.8 53.3 57.7 62.0 50.6 52.1 56.4 60.5 49.4 50.8 55.0 59.1 48.2 49.6 53.7 57.6 45.8 47.1 51.0 54.7 42.4 43.7 47.3 50.7

S/T 0.76 0.68 0.52 0.3 0.79 0.71 0.54 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.87 0.78 0.59 0.4 0.88 0.78 0.59 0.4

∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11.0

kW 3.97 4.06 4.19 4.3 4.28 4.38 4.52 4.7 4.56 4.66 4.82 5.0 4.81 4.91 5.08 5.3 5.01 5.13 5.30 5.5 5.19 5.31 5.49 5.7

1620

Amps 5.8 6.2 6.7 7.3 7.1 7.5 8.1 8.8 8.6 9.0 9.7 10.4 9.9 10.4 11.0 11.8 11.1 11.7 12.4 13.3 12.4 13.0 13.7 14.7

HI PR 250 269 284 296.3 281 302 319 332.5 319 343 363 378.1 363 391 413 430.7 409 440 465 484.5 452 486 513 535.3

LO PR 104 111 121 128.6 110 117 128 135.8 114 121 133 141.2 120 128 139 148.3 126 134 146 155.4 130 138 151 160.8

6.0 6.6 - 6.9 7.3 7.9 - 8.4 8.9 9.5 - 9.7 10.2 10.8 - 10.9 11.5 12.2 - 12.2 12.8 13.5 -

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.49 -

MBh 56.8 58.9 64.5 - 55.5 57.5 63.0 - 54.2 56.2 61.5 - 52.9 54.8 60.0 - 50.2 52.1 57.0 - 46.5 48.2 52.8 -

kW 4.07 4.16 4.29 - 4.39 4.49 4.64 - 4.68 4.78 4.94 - 4.93 5.04 5.21 - 5.15 5.26 5.44 - 5.33 5.45 5.64 -

2080

HI PR 258 277 293 - 289 311 329 - 329 354 374 - 375 403 426 - 421 453 479 - 466 501 529 -

Amps 6.2 6.6 7.2 - 7.6 8.0 8.6 - 9.1 9.6 10.2 - 10.4 10.9 11.6 - 11.7 12.3 13.0 - 13.1 13.6 14.4 -

LO PR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 144 - 130 138 150 - 134 143 156 -

∆T 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -

MBh 55.2 57.2 62.7 - 53.9 55.9 61.2 - 52.6 54.5 59.7 - 51.3 53.2 58.3 - 48.8 50.5 55.4 - 45.2 46.8 51.3 -

kW 4.04 4.12 4.26 - 4.36 4.45 4.60 - 4.64 4.74 4.90 - 4.89 5.00 5.17 - 5.10 5.22 5.40 - 5.28 5.41 5.59 -

1850

HI PR 255 275 290 - 286 308 325 - 326 350 370 - 371 399 421 - 417 449 474 - 461 496 524 -

Amps 6.1 6.5 7.0 - 7.4 7.8 8.4 - 8.9 9.4 10.0 - 10.2 10.7 11.4 - 11.5 12.1 12.8 - 12.8 13.4 14.2 -

LO PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.77 0.64 0.45 -

MBh 50.9 52.8 57.8 - 49.7 51.6 56.5 - 48.6 50.3 55.1 - 47.4 49.1 53.8 - 45.0 46.7 51.1 - 41.7 43.2 47.3 -

kW 3.94 4.02 4.15 - 4.25 4.34 4.48 - 4.52 4.62 4.78 - 4.76 4.87 5.04 - 4.97 5.08 5.26 - 5.15 5.27 5.45 -

1620

Amps 5.7

HI PR 247 266 281 - 278 299 316 - 316 340 359 - 360 387 409 - 405 435 460 - 447 481 508 -

LO PR 103 109 120 - 109 116 126 - 113 120 131 - 119 126 138 - 124 132 144 - 129 137 149 -

MBh 57.8 59.5 64.4 69.1 56.5 58.1 62.9 67.5 55.1 56.7 61.4 65.9 53.8 55.4 59.9 64.3 51.1 52.6 56.9 61.1 47.3 48.7 52.7 56.6

S/T 0.83 0.74 0.56 0.4 0.86 0.77 0.58 0.4 0.88 0.79 0.60 0.4 0.91 0.81 0.62 0.4 0.94 0.85 0.64 0.4 0.95 0.85 0.65 0.4

∆T 21 20 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10.4

kW 4.10 4.19 4.33 4.5 4.43 4.53 4.68 4.8 4.72 4.83 4.99 5.2 4.97 5.09 5.26 5.4 5.19 5.31 5.49 5.7 5.38 5.50 5.69 5.9

2080

Amps 6.4 6.8 7.3 8.0 7.7 8.2 8.8 9.5 9.3 9.8 10.4 11.2 10.6 11.1 11.8 12.7 12.0 12.5 13.3 14.2 13.3 13.9 14.7 15.6

HI PR 260 280 296 308.5 292 314 332 346.2 332 357 378 393.7 378 407 430 448.4 426 458 484 504.5 470 506 534 557.4

LO PR 108 115 126 133.9 114 122 133 141.4 119 126 138 147.0 125 133 145 154.4 131 139 152 161.8 135 144 157 167.4

MBh 56.1 57.8 62.5 67.1 54.8 56.4 61.1 65.6 53.5 55.1 59.6 64.0 52.2 53.7 58.2 62.4 49.6 51.1 55.3 59.3 45.9 47.3 51.2 54.9

S/T 0.79 0.71 0.54 0.3 0.82 0.73 0.56 0.4 0.84 0.75 0.57 0.4 0.87 0.78 0.59 0.4 0.90 0.81 0.61 0.4 0.91 0.81 0.62 0.4

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

14 www.goodmanmfg.com SS-GPH14M

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Expanded Cooling Data — GPH1460M41A** – High Stage (cont.)

Product Specifications

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 58.8 60.1 64.2 68.7 57.5 58.7 62.7 67.1 56.1 57.3 61.2 65.5 54.7 55.9 59.7 63.9 52.0 53.1 56.8 60.7 48.2 49.2 52.6 56.2

S/T 0.91 0.85 0.69 0.5 0.94 0.88 0.72 0.5 0.97 0.91 0.74 0.6 1.00 0.94 0.76 0.6 1.00 1.00 0.79 0.6 1.00 1.00 0.80 0.6

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 22 19 14.8

kW 4.14 4.23 4.37 4.5 4.47 4.57 4.72 4.9 4.76 4.87 5.03 5.2 5.02 5.13 5.31 5.5 5.24 5.36 5.54 5.7 5.42 5.55 5.74 5.9

Amps 6.5 6.9 7.5 8.2 7.9 8.3 8.9 9.7 9.5 9.9 10.6 11.4 10.8 11.3 12.0 12.9 12.2 12.7 13.5 14.4 13.5 14.1 14.9 15.9

HI PR 263 283 299 311.6 295 318 335 349.7 336 361 381 397.7 382 411 434 453.0 430 463 489 509.6 475 511 540 563.0

LO PR 109 116 127 135.2 116 123 134 142.9 120 128 139 148.5 126 134 146 156.0 132 141 153 163.5 137 145 159 169.1

MBh 57.1 58.4 62.4 66.7 55.8 57.0 60.9 65.1 54.5 55.6 59.5 63.6 53.1 54.3 58.0 62.0 50.5 51.6 55.1 58.9 46.8 47.8 51.0 54.6

S/T 0.87 0.81 0.66 0.5 0.90 0.84 0.69 0.5 0.92 0.87 0.70 0.5 0.95 0.89 0.73 0.5 0.99 0.93 0.75 0.6 1.00 0.93 0.76 0.6

∆T 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 15.4

kW 4.10 4.19 4.33 4.5 4.43 4.53 4.68 4.8 4.72 4.83 4.99 5.2 4.97 5.09 5.26 5.4 5.19 5.31 5.49 5.7 5.38 5.50 5.69 5.9

Amps 6.4 6.8 7.3 8.0 7.7 8.2 8.8 9.5 9.3 9.8 10.4 11.2 10.6 11.1 11.8 12.7 12.0 12.5 13.3 14.2 13.3 13.9 14.7 15.6

HI PR 260 280 296 308.6 292 314 332 346.2 332 358 378 393.8 378 407 430 448.5 426 458 484 504.6 470 506 534 557.5

LO PR 108 115 126 133.9 114 122 133 141.5 119 126 138 147.0 125 133 145 154.4 131 139 152 161.8 135 144 157 167.4

58.7 49.0 50.1 53.5 57.2 46.6 47.6 50.9 54.4 43.2 44.1 47.1 50.4

MBh 52.7 53.9 57.5 61.5 51.5 52.6 56.2 60.1 50.3 51.4 54.9

S/T 0.84 0.79 0.64 0.5 0.87 0.81 0.66 0.5 0.89 0.83 0.68 0.5 0.92 0.86 0.70 0.5 0.95 0.89 0.73 0.5 0.96 0.90 0.73 0.5

∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 24 21 17 25 24 21 17 24 23 20 15.7

kW 4.00 4.09 4.22 4.4 4.32 4.42 4.56 4.7 4.60 4.70 4.86 5.0 4.85 4.96 5.12 5.3 5.06 5.17 5.35 5.5 5.24 5.36 5.54 5.7

6.3 6.9 7.5 7.3 7.7 8.3 8.9 8.8 9.2 9.9 10.6 10.0 10.5 11.2 12.0 11.3 11.9 12.6 13.5 12.6 13.2 14.0 14.9

Amps 6.0

HI PR 253 272 287 299.3 283 305 322 335.8 322 347 366 382.0 367 395 417 435.0 413 444 469 489.4 456 491 518 540.7

LO PR 105 112 122 129.9 111 118 129 137.2 115 123 134 142.6 121 129 141 149.8 127 135 147 157.0 131 140 152 162.4

MBh 59.9 61.0 63.9 68.2 58.5 59.6 62.4 66.6 57.1 58.2 60.9 65.0 55.7 56.8 59.4 63.4 52.9 53.9 56.5 60.2 49.0 49.9 52.3 55.8

S/T 0.95 0.92 0.83 0.7 0.99 0.95 0.86 0.7 1.00 0.98 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.95 0.8

∆T 25 25 23 20 26 25 24 21 25 25 24 21 25 25 24 21 23 24 24 20 22 22 22 19.1

kW 4.17 4.26 4.40 4.6 4.51 4.61 4.76 4.9 4.80 4.91 5.07 5.2 5.06 5.18 5.35 5.5 5.28 5.40 5.59 5.8 5.47 5.60 5.79 6.0

Amps 6.7 7.1 7.7 8.3 8.1 8.5 9.1 9.8 9.6 10.1 10.8 11.6 11.0 11.5 12.2 13.1 12.4 12.9 13.7 14.6 13.7 14.3 15.1 16.1

HI PR 266 286 302 314.8 298 321 339 353.2 339 365 385 401.7 386 415 439 457.5 434 467 493 514.7 480 516 545 568.7

LO PR 110 117 128 136.6 117 124 135 144.3 121 129 141 150.0 127 135 148 157.5 133 142 155 165.1 138 147 160 170.8

MBh 58.1 59.2 62.0 66.2 56.8 57.9 60.6 64.6 55.4 56.5 59.2 63.1 54.1 55.1 57.7 61.6 51.4 52.3 54.8 58.5 47.6 48.5 50.8 54.2

S/T 0.91 0.88 0.79 0.6 0.94 0.91 0.82 0.7 0.97 0.93 0.84 0.7 1.00 0.96 0.87 0.7 1.00 1.00 0.90 0.7 1.00 1.00 0.91 0.7

∆T 26 26 24 21 27 26 25 21 27 26 25 21 27 26 25 22 26 26 25 21 24 24 23 19.9

kW 4.14 4.23 4.37 4.5 4.47 4.57 4.72 4.9 4.76 4.87 5.03 5.2 5.02 5.13 5.31 5.5 5.24 5.36 5.54 5.7 5.42 5.55 5.74 5.9

6.9 7.5 8.2 7.9 8.3 8.9 9.7 9.5 9.9 10.6 11.4 10.8 11.3 12.0 12.9 12.2 12.7 13.5 14.4 13.5 14.1 14.9 15.9

Amps 6.5

HI PR 263 283 299 311.6 295 318 335 349.7 336 361 381 397.7 382 411 434 453.0 430 463 489 509.6 475 511 540 563.0

LO PR 109 116 127 135.2 116 123 134 142.9 120 128 139 148.5 126 134 146 156.0 132 141 153 163.5 137 145 159 169.1

MBh 53.6 54.7 57.3 61.1 52.4 53.4 55.9 59.7 51.1 52.1 54.6 58.2 49.9 50.9 53.3 56.8 47.4 48.3 50.6 54.0 43.9 44.8 46.9 50.0

S/T 0.88 0.85 0.76 0.6 0.91 0.88 0.79 0.6 0.93 0.90 0.81 0.7 0.96 0.93 0.84 0.7 1.00 0.96 0.87 0.7 1.00 0.97 0.88 0.7

∆T 27 26 25 21 27 27 25 22 27 27 25 22 27 27 25 22 27 26 25 22 25 25 23 20.2

kW 4.04 4.12 4.26 4.4 4.36 4.45 4.60 4.8 4.64 4.74 4.90 5.1 4.89 5.00 5.17 5.3 5.10 5.22 5.39 5.6 5.28 5.41 5.59 5.8

Amps 6.1 6.5 7.0 7.7 7.4 7.8 8.4 9.1 8.9 9.4 10.0 10.8 10.2 10.7 11.4 12.2 11.5 12.1 12.8 13.7 12.8 13.4 14.2 15.1

HI PR 255 274 290 302.3 286 308 325 339.2 325 350 370 385.8 371 399 421 439.4 417 449 474 494.3 461 496 524 546.2

LO PR 106 113 123 131.2 112 119 130 138.6 116 124 135 144.0 122 130 142 151.3 128 136 149 158.6 133 141 154 164.0

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

2080

1850

1620

2080

1850

1620

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-GPH14M www.goodmanmfg.com 15

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Product Specifications

Expanded Heating Data

GPH1424M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 28.9 27.4 25.8 24.1 23.0 22.3 20.7 19.1 15.7 14.5 13.3 12.6 12.1 10.9 9.7 8.4 7.2 5.9

T/R 31.5 29.8 28.1 26.2 25.1 24.3 22.5 20.8 17.1 15.8 14.5 13.7 13.2 11.9 10.5 9.2 7.8 6.4

kW 1.90 1.87 1.83 1.79 1.77 1.75 1.72 1.68 1.70 1.66 1.62 1.60 1.58 1.55 1.51 1.47 1.43 1.39

Amps 10.1 9.4 8.9 8.5 8.2 8.1 7.7 7.4 7.1 6.9 6.6 6.5 6.4 6.1 5.8 5.6 5.2 4.8

COP 4.45 4.29 4.12 3.93 3.80 3.72 3.53 3.32 2.70 2.55 2.41 2.30 2.24 2.06 1.87 1.68 1.47 1.24

HI PR 377 361 347 332 324 318 306 293 281 269 258 252 247 238 229 219 211 204

LO PR 139 129 121 111 105 101 92 82 74 66 58 54 52 44 38 32 28 22

GPH1430M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 35.2 33.3 31.4 29.3 28.0 27.1 25.2 23.2 18.7 17.3 15.9 15.0 14.4 13.0 11.5 10.0 8.6 7.0

T/R 31.0 29.4 27.7 25.9 24.7 23.9 22.2 20.5 16.5 15.2 14.0 13.2 12.7 11.4 10.1 8.8 7.5 6.2

kW 2.36 2.31 2.26 2.21 2.19 2.17 2.12 2.07 2.05 2.00 1.95 1.93 1.91 1.86 1.81 1.77 1.72 1.67

Amps 5.6 5.4 5.1 4.9 4.8 4.8 4.6 4.5 4.3 4.2 4.1 4.1 4.0 3.9 3.8 3.7 3.5 3.4

COP 4.37 4.22 4.06 3.87 3.75 3.66 3.48 3.28 2.67 2.52 2.38 2.28 2.22 2.04 1.86 1.66 1.46 1.23

HI PR 385 370 355 340 332 325 313 300 288 275 264 257 253 243 234 224 216 209

LO PR 138 128 120 110 104 100 92 82 74 66 58 54 52 44 38 32 28 22

GPH1436M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 41.7 39.5 37.2 34.8 33.2 32.2 29.9 27.6 23.7 21.9 20.1 19.0 18.3 16.4 14.6 12.7 10.8 8.9

T/R 32.2 30.5 28.7 26.8 25.6 24.8 23.1 21.3 18.3 16.9 15.5 14.7 14.1 12.7 11.2 9.8 8.4 6.8

kW 2.76 2.71 2.66 2.60 2.57 2.55 2.49 2.44 2.53 2.47 2.41 2.38 2.36 2.30 2.24 2.18 2.13 2.07

Amps 7.0 6.6 6.4 6.1 6.0 5.9 5.7 5.5 5.4 5.2 5.1 5.0 5.0 4.9 4.7 4.5 4.4 4.2

COP 4.42 4.27 4.10 3.91 3.78

HI PR 391 375 361 345 337 330 318 305 292 279 268 261 257 247 237 228 220 212

LO PR 134 125 117 107 101 97 90 80 72 64 57 53 51 43 37 31 27 21

Notes

Above informaon is for nominal CFM and 70-degree indoor dry bulb. Instantaneous capacity listed. High pressure is measured at the liquid line access ng. Amps: Unit amps (comp.+ evaporator motor + condenser fan motor) Low pressure is measured at the compressor sucon access ng. kW = Total system power

3.70 3.51 3.30 2.74 2.59 2.44 2.34 2.27 2.09 1.90 1.70 1.49 1.26

16 www.goodmanmfg.com SS-GPH14M

Product Specifications

Expanded Heating Data (cont.)

GPH1442M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 50.9 48.2 45.4 42.4 40.5 39.2 36.5 33.6 28.0 25.9 23.8 22.5 21.7 19.4 17.2 15.0 12.8 10.5

T/R 36.3 34.3 32.3 30.2 28.8 28.0 26.0 23.9 20.0 18.4 17.0 16.0 15.4 13.8 12.3 10.7 9.1 7.5

kW 3.49 3.42 3.35 3.28 3.24 3.21 3.15 3.08 3.00 2.93 2.86 2.82 2.79 2.72 2.65 2.58 2.51 2.45

Amps 18.9 17.7 16.7 15.8 15.3 15.0 14.3 13.7 13.2 12.7 12.2 11.9 11.8 11.3 10.6 10.1 9.5 8.8

COP 4.26 4.12 3.96 3.78 3.65 3.57 3.39 3.20 2.74 2.59 2.44 2.34 2.27 2.09 1.90 1.70 1.49 1.26

HI PR 406 389 374 358 349 343 329 316 303 289 278 271 266 256 246 236 228 220

LO PR 134 124 117 107 101 97 89 80 72 64 56 52 51 43 37 31 27 21

GPH1448M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 57.3 54.3 51.1 47.7 45.6 44.2 41.0 37.8 33.0 30.5 28.1 26.5 25.5 22.9 20.3 17.7 15.1 12.4

T/R 33.2 31.4 29.6 27.6 26.4 25.6 23.8 21.9 19.1 17.6 16.2 15.3 14.8 13.3 11.7 10.2 8.7 7.2

kW 3.87 3.79 3.71 3.64 3.59 3.56 3.49 3.41 3.41 3.33 3.25 3.21 3.18 3.10 3.02 2.94 2.86 2.79

Amps 19.0 17.7 16.7 15.8 15.3 15.0 14.2 13.6 13.1 12.5 12.0 11.8 11.6 11.1 10.5 10.0 9.3 8.5

COP 4.34 4.19 4.02 3.84 3.71 3.63 3.44 3.25 2.84 2.68 2.53 2.42 2.35 2.16 1.97 1.76 1.54 1.30

HI PR 387 371 356 341 333 326 314 301 289 276 265 258 254 244 235 225 217 209

LO PR 129 120 112 103 97 93 86 77 69 62 54 50 49 41 35 30 26 21

GPH1460M41A*

Outdoor Ambient Temperature

65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10

MBh 71.6 67.8 63.8 59.7 57.0 55.2 51.3 47.3 39.1 36.1 33.3 31.4 30.2 27.1 24.1 21.0 17.9 14.7

T/R 35.9 33.9 32.0 29.9 28.5 27.6 25.7 23.7 19.6 18.1 16.6 15.7 15.1 13.6 12.0 10.5 9.0 7.3

kW 5.06 4.96 4.85 4.75 4.69 4.65 4.55 4.44 4.10 4.00 3.91 3.85 3.81 3.72 3.62 3.53 3.43 3.34

Amps 30.1 27.1 24.6 22.5 21.2 20.6 18.8 17.3 16.0 14.8 13.6 13.0 12.7 11.4 9.9 8.7 7.2 5.3

COP 4.15 4.01

HI PR 426 409 393 376 367 360 346 332 318 304 292 285 280 269 259 248 239 231

LO PR 126 117 110 101 95 92 84 75 68 61 53 49 48 40 35 29 26 20

Notes

3.85 3.68 3.56 3.48 3.30 3.12 2.79 2.64 2.49 2.39 2.32 2.14 1.94 1.74 1.53 1.29

SS-GPH14M www.goodmanmfg.com 17

Product Specifications

Airflow Data

GPH1424M41*

Model

Horizontal

Position

Downshot

Position

GPH1430M41*

Model

Horizontal

Position

Downshot

Position

Motor

Speed

T1 230

T2/T3 230

T4/T5 230

T1 230

T2/T3 230

T4/T5 230

Motor

Speed

T1 230

T2/T3 230

T4/T5 230

T1 230

T2/T3 230

T4/T5 230

Volts

E.S.P (In. of H₂O)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

CFM 782 709 652 561 --- --- --- --- ---

Was 71 78 86 100 --- --- --- --- ---

CFM 941 872 777 746 614 --- --- --- ---

Was 105 112 113 128 138 --- --- --- ---

CFM 1347 1315 1256 1194 1152 1096 1051 972 891

Was 239 256 265 271 282 286 293 297 305

CFM 790 710 634 566 506 --- --- --- ---

Was 82 86 96 103 108 --- --- --- ---

CFM 919 855 782 695 631 578 523 --- ---

Was 108 117 121 132 143 144 149 --- ---

CFM 1312 1275 1216 1153 1096 1028 943 869 816

Was 260 269 274 285 295 300 304 310 316

E.S.P (In. of H₂O)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

CFM 851 803 712 635 575 506 460 --- ---

Was 79 88 91 100 114 116 120 --- ---

CFM 1146 1098 1044 991 934 817 764 698 653

Was 157 170 176 186 194 201 210 215 215

CFM 1440 1418 1364 1307 1265 1219 1168 1094 1049

Was 290 306 312 321 326 332 348 353 360

CFM 848 761 646 578 511 --- --- --- ---

Was 84 94 98 111 113 --- --- --- ---

CFM 1103 1038 978 922 806 731 676 622 564

Was 162 168 179 188 199 205 208 214 219

CFM 1401 1357 1305 1244 1179 1118 1046 934 884

Was 311 326 318 334 341 349 353 352 357

0.9

GPH1436M41*

Model

Horizontal

Position

Downshot

Position

Motor

Speed

T1 230

T2/T3 230

T4/T5 230

T1 230

T2/T3 230

T4/T5 230

Volts

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

CFM 846 762 716 585 519 --- --- --- ---

Was 74 83 94 98 108 --- --- --- ---

CFM 1278 1214 1182 1129 1072 1013 950 853 788

Was 221 218 232 245 253 264 265 275 272

CFM 1604 1560 1507 1468 1415 1364 1321 1276 1218

Was 396 402 408 424 426 423 444 454 454

CFM 809 730 623 542 485 441

Was 73 85

CFM 1284 1223 1175 1097 1031 974 871 804 761

Was 220 227 241 247 255 262 272 277 285

CFM 1578 1539 1498 1452 1396 1332 1279 1224 1161

Was 401 409 421 425 438 439 452 453 455

E.S.P (In. of H₂O)

0.9

--- --- ---

92 98 107 112 --- --- ---

18 www.goodmanmfg.com SS-GPH14M

Airflow Data (cont.)

GPH1442M41*

Product Specifications

Model

Horizontal

Position

Downshot

Position

GPH1448M41*

Model

Horizontal

Position

Downshot

Position

Motor

Speed

T2/T3 230

T4/T5 230

T2/T3 230

T4/T5 230

Motor

Speed

T2/T3 230

T4/T5 230

T2/T3 230

T4/T5 230

Volts

T1 230

Volts

T1 230

E.S.P (In. of H₂O)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

CFM 1030 955 908 826 761 678 633 563 504

Was 130 126 139 143 154 168 171 181 185

CFM 1419 1387 1327 1274 1219 1171 1111 1041 986

Was 273 281 287 298 309 315 318 326 336

CFM 1750 1710 1673 1611 1556 1499 1443 1399 1353

Was 470 475 488 493 502 502 501 514 520

CFM 1001 936 852 810 700 643 579 526 491

Was 125 133 136 154 160 166 172 177 185

CFM 1411 1361 1299 1240 1173 1112 1048 955 887

Was 281 294 301 309 312 320 327 335 339

CFM 1734 1678 1613 1558 1509 1449 1383 1341 1279

Was 475 485 496 504 509 505 519 514 520

0.9

E.S.P (In. of H₂O)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

CFM 1167 1101 1045 992 939 870 802 732 681

Was 139 144 156 165 177 193 203 217 223

CFM 1723 1637 1598 1554 1509 1467 1420 1361 1295

Was 372 370 381 390 404 411 420 427 441

CFM 2012 1965 1912 1871 1809 1770 1741 1691 1635

Was 578 593 599 606 610 627 626 634 638

CFM 1155 1074 1023 969 896 805 755 667 626

Was 153 156 169 180 195 205 216 226 230

CFM 1670 1596 1558 1484 1467 1383 1339 1259 1168

Was 383 392 399 408 419 434 436 447 449

CFM 1949 1881 1853 1792 1753 1699 1621 1561 1522

Was 603 607 608 616 622 626 648 650 645

0.9

GPH1460M41*

Model

Horizontal

Position

Downshot

Position

Motor

Speed

T2/T3 230

T4/T5 230

T2/T3 230

T4/T5 230

Volts

T1 230

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

CFM 1427 1370 1317 1273 1204 1165 1111 1058 1003

Was 222 229 237 256 256 276 291 299 320

CFM 1935 1885 1848 1809 1755 1705 1659 1616 1567

Was 498 512 515 520 541 549 559 567 569

CFM 2232 2188 2144 2087 2035 2017 1963 1926 1869

Was 805 795 790 827 830 842 864 864 848

CFM 1347 1293 1236 1184 1117 1054 996 934 871

Was

CFM 1827 1780 1739 1683 1633 1588 1518 1462 1404

Was 529

CFM 2111 2057 2030 1979 1947 1957 1922 1868 1818

Was 835 843 846 852 870 959 956 960 966

242 251 268 276 290 305 321 330 348

538 548 557 557 576 578 604 601

E.S.P (In. of H₂O)

0.9

SS-GPH14M www.goodmanmfg.com 19

Product Specifications

Heat Kit Electrical Data (Blower Only, Heat Mode)

Model and

Heat Kit Usage

GPH1424M41** 4.3 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 47 50 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 58 60 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 71 80 9.5 / 32,400

GPH1430M41** 4.3 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 48 50 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 60 60 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 73 80 9.5 / 32,400

HKP-15C* 43 / 49 45 / 50 21 / 25 25 / 25 98 110 14.25 / 48,600

GPH1436M41** 4.3 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 51 60 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 63 70 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 76 80 9.5 / 32,400

HKP-15C* 43 / 49 45 / 50 21 / 25 25 / 25 101 110 14.25 / 48,600

GPH1442M41** 5.8 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 54 60 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 66 70 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 79 80 9.5 / 32,400

HKP-15C* 43 / 49 45 / 50 21 / 25 25 / 25 104 110 14.25 / 48,600

GPH1448M41** 5.8 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 59 70 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 71 80 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 84 90 9.5 / 32,400

HKP-15C* 43 / 49 45 / 50 21 / 25 25 / 25 109 110 14.25 / 48,600

HKP-20C 43 / 49 45 / 50 43 / 49 45 / 50 133 150 19.0 / 64,800

GPH1460M41** 7.6 --- --- --- -- -- ---

HKP-05C* 21 / 25 25 / 25 --- --- 69 90 4.75 / 16,200

HKR-08C* 32 / 36 35 / 40 --- --- 80 100 7.0 / 23,800

HKP-10C* 43 / 49 45 / 50 --- --- 94 110 9.5 / 32,400

HKP-15C* 43 / 49 45 / 50 21 / 25 25 / 25 118 125 14.25 / 48,600

HKP-20C 43 / 49 45 / 50 43 / 49 45 / 50 142 150 19.0 / 64,800

¹ Minimum Circuit Ampacity @ 208 / 240 V ² Maximum Overcurrent Protecon Device @ 208 / 240 V * Revision level that may or may not be designated C Circuit breaker opon

Note: HKP-15C* and HKP-20C* replace HKR-15C and HKR-20C respecvely to meet new UL1995 requirements.

Circuit #1 Circuit #2 Single-Point Kit

MCA¹ MOD² MCA¹ MOD² MCA¹ MOP²

Actual kW /

BTU@ 240V

20 www.goodmanmfg.com SS-GPH14M

Dimensions



Product Specifications











 



































Model W" D" H" Chassis Size B H

GPH1424M41 47 51 34¾ Med. 16" 32½"

GPH1430M41 47 51 34¾ Med. 16" 32½"

GPH1436M41 47 51 34¾ Med. 16" 32½"

GPH1442M41 47 51 34¾ Med. 16" 32½"

GPH1448M41 47 51 42¾ Large 18" 40"

GPH1460M41 47 51 42¾ Large 18" 40"

SS-GPH14M www.goodmanmfg.com 21

Product Specifications

WIRE CODE

BK BLACK

BL BLUE

BR BROWN

GR GREEN

OR ORANGE

PU PURPLE

RD RED

WH WHITE

YL YELLOW

CTORY WIRING

LINE VOLTAGE

LOW VOLTAGE

OPTIONAL HIGH

VOLTAGE

FIELD WIRING

HIGH VOLTAGE

LOW VOLTAGE

CONTROL

BOX

240

24V

208

GND

LVJB

RCCF

RVC

COMP

LPS

DFT

HPS

LVTB

PLM-P

654

PLF-C

PS2

R-PS1

R-DFT

DFT

CNT

CCR

HVDR

LVDR

C-RV

0-RV

DF2

DF1

SEE NOTE 5

SEE NOTE 4

SEE

NOTE

SEE

NOTES

7 AND 8

PLF-H

C L G N

2 3

4 5

PLM-B

SEE NOTE 2

GR YL

SEE NOTE 2

SEE NOTE 3

208-230

208-230/1/60

SUPPLY VOLTAGE

COMP

S.A.

ST1R

DF1

SEE NOTE 4

RCCF

HVDR

DF2

3 1

CHS

G C

PLF

EM 1

HPS

THERMOSTAT

24V

DFT

RVC

LPS

CNT

R-PS1 PS2

R-DFT

DFT

O-RV

C-RV

2 POLE ONLY

SEE NOTE 7

SEE NOTE 6

SEE NOTE 2

NOTES:

1. REPLACEMENT WIRE MUST BE SAME SIZE AND TYPE INSULATION AS

ORIGINAL (AT LEAST 105°C) USE COPPER CONDUCTOR ONLY.

2. TO CHANGE EVAPORATOR MOTOR SPEED MOVE YELLOW AND WHITE

LEADS FROM EM"2" AND "3" TO "4" AND "5". IF BOTH LEADS ARE

ENERGIZED, THE HIGHER SPEED SETTING IS USED.

3 FOR 208 VOLT TRANSFORMER OPERATION MOVE BLACK WIRE

FROM TERMINAL 3 TO TERMINAL 2 ON TRANSFORMER.

4. START ASSIST FACTORY EQUIPPED WHEN REQUIRED

5. USE COPPER CONDUCTORS ONLY

++ USE N.E.C. CLASS 2 WIRE

6. CRANKCASE HEATER AND CRANKCASE HEATER SWITCH FACTORY

EQUIPPED WHEN REQUIRED.

7. DOUBLE POLE CONTACTOR SHOWN. SINGLE POLE CONTACTOR

COULD BE FACTORY EQUIPPED AS AN ALTERNATE CONFIGURATION.

8. COMMON SIDE OF CONTACTOR CAN NOT BE GROUNDED OR

CONNECTED TO ANY OTHER COMMON (24V).

SEE UNIT RATING PLATE FOR TYPE AND SIZE

OF OVER CURRENT PROTECTION

8-230/1/60 0140G03220-B

COMPONENT LEGEND

C CONTACTOR

CCR COMPRESSOR CONTACTOR RELAY

CH CRANKCASE HEATER

CHS CRANKCASE HEATER SWITCH

CM CONDENSER MOTOR

COMP COMPRESSOR

DC DEFROST CONTROL

DFT DEFROST THERMOSTAT

EM EVAPORATOR MOTOR

GND EQUIPMENT GROUND

HPS HIGH PRESSURE SWITCH

HVDR HIGH VOLTAGE DEFROST RELAY

LPS LOW PRESSURE SWITCH

LVDR LOW VOLTAGE DEFROST RELAY

LVJB LOW VOLTAGE JUNCTION BOX

LVTB LOW VOLTAGE TERMINAL BLOCK

PLF-C FEMALE PLUG/CONNECTOR - CONTROL

PLF-H FEMALE PLUG/CONNECTOR - HEAT KIT

PLF-P FEMALE PLUG/CONNECTOR - PESSURE SWITCH

PLM-B MALE PLUG/CONNECTOR - BLOWER

PLM-P MALE PLUG/CONNECTOR - PRESSURE SWITCH

RVC REVERSING VALVE COIL

RCCF RUN CAPACITOR FOR COMPRESSOR AND FAN

SA START ASSIST

TR TRANSFORMER

CHS

PLF-P

SEE NOTE 6

208/230/1/60

THERMOSTAT ++

Wiring Diagram — GPH14024M-048M41**

⚡

High Voltage: Disconnect all power before servicing or installing this unit. Mulple power

sources may be present. Failure to do so may cause property damage, personal injury, or death.

⚠ Warning

22 www.goodmanmfg.com SS-GPH14M

Wiring is subject to change. Always

refer to the wiring diagram or the

unit for the most up-to-date wiring.

Wiring Diagram — GPH14060M41**

SEE NOTE 2

SEE NOTE 3

208-230

208-230/1/60

SUPPLY VOLTAGE

COMP

S.A

DF1

RCCF

HVDR

DF2

R W2 O

W1 Y1

G C

EM 1

CSR

SEE NOTE 6

THERMOSTAT

CHS

SOL

HPS

24V

DFT

RVC

LPS

CNT

R-PS1 PS2

R-DFT

O-RV

C-RV

DFT

2 POLE ONLY

SEE NOTE 7

SEE NOTE 4

PLF

SEE NOTE 2

CONTROL

BOX

240

24V

208

GND

LVJB

RCCF

RVC

BKCOMP

LPS

DFT

HPS

SOL

CSR

LVTB

789

PLM-P

PLF-C

PS2

R-PS1

R-DFT

DFT

CNT

CCR

HVDR

LVDR

C-RV

0-RV

DF2

DF1

SEE NOTE 5

SEE NOTE 7

SEE

NOTE

PLF-H

C L G N

PLM-B

SEE NOTE 2

GR YL

NOTES:

1. REPLACEMENT WIRE MUST BE SAME SIZE AND TYPE INSULATION AS

ORIGINAL (AT LEAST 105°C) USE COPPER CONDUCTOR ONLY.

2. TO CHANGE EVAPORATOR MOTOR SPEED MOVE YELLOW AND WHITE

LEADS FROM EM"2" AND "3" TO "4" AND "5". IF BOTH LEADS ARE

ENERGIZED, THE HIGHER SPEED SETTING IS USED.

3 FOR 208 VOLT TRANSFORMER OPERATION MOVE BLACK WIRE

FROM TERMINAL 3 TO TERMINAL 2 ON TRANSFORMER.

4. START ASSIST FACTORY EQUIPPED WHEN REQUIRED

5. USE COPPER CONDUCTORS ONLY

++ USE N.E.C. CLASS 2 WIRE

6. CRANKCASE HEATER AND CRANKCASE HEATER SWITCH FACTORY

EQUIPPED WHEN REQUIRED.

7. DOUBLE POLE CONTACTOR SHOWN. SINGLE POLE CONTACTOR

COULD BE FACTORY EQUIPPED AS AN ALTERNATE CONFIGURATION.

SEE UNIT RATING PLATE FOR TYPE AND SIZE

OF OVER CURRENT PROTECTION

208-230/1/60 0140G03223-B

COMPO

NENT LEGEND

C CONTACTOR

CCR COMPRESSOR CONTACTOR RELAY

CH CRANKCASE HEATER

CHS CRANKCASE HEATER SWITCH

CM CONDENSER MOTOR

COMP COMPRESSOR

CSR COMPRESSOR SOLENOID RELAY

DC DEFROST CONTROL

DFT DEFROST THERMOSTAT

EM EVAPORATOR MOTOR

GND EQUIPMENT GROUND

HPS HIGH PRESSURE SWITCH

HVDR HIGH VOLTAGE DEFROST RELAY

LPS LOW PRESSURE SWITCH

LVDR LOW VOLTAGE DEFROST RELAY

LVJB LOW VOLTAGE JUNCTION BOX

LVTB LOW VOLTAGE TERMINAL BLOCK

PLF-C FEMALE PLUG/CONNECTOR - CONTROL

PLF-H FEMALE PLUG/CONNECTOR - HEAT KIT

PLF-P FEMALE PLUG/CONNECTOR - PESSURE SWITCH

PLM-B MALE PLUG/CONNECTOR - BLOWER

PLM-P MALE PLUG/CONNECTOR - PRESSURE SWITCH

RVC REVERSING VALVE COIL

RCCF RUN CAPACITOR FOR COMPRESSOR AND FAN

SA START ASSIST

TR TRANSFORMER

WIRE CO

BK BLACK

BL BLUE

BR BROWN

GR GREEN

OR ORANGE

PU PURPLE

RD RED

WH WHITE

YL YELLOW

CTORY WIRING

LINE VOLTAGE

LOW VOLTAGE

OPTIONAL HIGH

VOLTAGE

FIELD WIRING

HIGH VOLTAGE

LOW VOLTAGE

208/230/1/60

THERMOSTAT ++

SEE

NOTE 4

CHS

BK P

PLF-P

SEE NOTE 6

Product Specifications

⚡

High Voltage: Disconnect all power before servicing or installing this unit. Mulple power

sources may be present. Failure to do so may cause property damage, personal injury, or death.

⚠ Warning

Wiring is subject to change. Always

refer to the wiring diagram or the

unit for the most up-to-date wiring.

SS-GPH14M www.goodmanmfg.com 23

Product Specifications

Accessories

Accessory

Description

Concentric Kit CDK36 CDK4872

Downow Economizer GPH13MED102 GPH13MED103

Downow Internal Filter Rack GPH13MFR102 GPH13MFR103

Downow Manual Damper PGMDD101/102 PGMDD103

Downow Motorized Damper PGMDMD101/102 PGMDMD103

Downow Square to Round SQRPG101/102 SQRPG103

External Horizontal Filter Rack GPGHFR101-103 GPGHFR101-103

Horizontal Duct Cover 20464501PDGK 20464502PDGK

Horizontal Economizer PEHH101/102 PEHH103

Horizontal manual Damper PGMDH102 PGMDH103

Horizontal Motorized Damper PGMDMH102 PGMDMH103

Horizontal Square to Round SQRPGH101/102 SQRPGH103

Outdoor Thermostat & Emergency Heat Relay Kit OT/EHR18-60 OT/EHR18-60

Outdoor Thermostat Kit w/ Lockout Stat OT18-60A OT18-60A

Roof Curb PGC101/102/103 PGC101/102/103

Medium Chassis Large Chassis

Item Number

Single-Point Kit Accessory Kits

Select the single-point kit accessory based on the unit model.

Model Single-Point Kit

GPH1424M41** SPK-30

GPH1430M41** SPK-35

GPH1436M41** SPK-40

GPH1443M41** SPK-40

GPH1449M41** SPK-50

GPH1460M41** SPK-60

Goodman Manufacturing Company, L.P., reserves the right to disconnue, or change at any me, specicaons or designs without

24 www.goodmanmfg.com SS-GPH14M

Goodman GPH1424M41A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Nomenclature

Expanded Heating Data

Airflow Data

Dimensions

Accessories
