Goodman DSXC180601 Specifications Sheet

Download

DSXC18

Split SyStem Air ConDitioner

Up to 18 Seer

Cooling CApACity:

34,000 - 56,000 BtU/h

Contents

Nomenclature ....................................... 2

Product Specications .......................... 3

Expanded Cooling Data ........................ 4

AHRI Ratings ........................................ 16

Dimensions ........................................ 26

Wiring Diagram ................................... 27

Accessories .......................................... 28

Standard Features

• R-410A chlorine-free refrigerant

• Two-Stage Copeland® UltraTech™ scroll compressor

• High-density foam compressor sound blanket

• ComfortNet™ Communications System compatible

• Expanded ComfortAlert™ diagnostics built in

• Set-up capable with 2 low-volt-

age wires to outdoor unit

• Diagnostic indicator lights and storage of 6 fault codes

• Color-coded terminal strip for noncommunicating set-up

• High- and low-pressure switches

• Factory-installed lter drier

• Coil and ambient temperature sensors

• Two-speed, super-quiet condenser fan motor

• Sweat connection service valves

with easy access to gauge ports

• AHRI Certied; ETL Listed

Cabinet Features

• Goodman® brand sound control top design

• Wire fan discharge grille

• Steel louver coil guard

• Baked-on powder-paint nish

with 500-hour salt-spray approval

• Top and side maintenance access

• Single-panel access to controls with space

provided for eld-installed accessories

• When properly anchored, meets the 2010 Florida Building Code unit integ-

rity requirements for hurricane-type winds (Anchor bracket kits available.)

* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive

the Lifetime Compressor Limited Warranty (good for as long as you own your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Québec.

SS-DSXC18 www.goodmanmfg.com 9/14

Supersedes 3/14

Product SPecificationS Product SPecificationS

Brand Engineering *

Goodman® Brand

Minor Revision

Product Category Engineering *

S Split System Major Revision

Unit Type Electrical

X Condenser R-410A 1 208/230 V, 1 Phase, 60 Hz

Heat Pump R-410A

2 220/240 V, 1 Phase, 50 Hz

3 208/230 V, 3 Phase, 60 Hz

Communication Feature 4 460 V, 3 Phase, 60 Hz

C ComfortNet 4-wire communications ready 5 380/415 V, 3 Phase, 50 Hz

Efficiency Nominal Capacity

16 16 SEER 3 Tons 060 5 Tons 18 18 SEER 4 Tons

* Neither used for order entry

or inventory management.

5,6S2

DX036

7,8,9

048

036

12A10111

nomenClAtUre

2 www.goodmanmfg.com SS-DSXC18

SpeCifiCAtionS

DSXC18

0361A

Cooling Capacity

Nominal Cooling (BTU/h) 35,000 47,000 57,000

Decibels 71 72 74

Compressor

RLA 15.3 21.2 27.1

LRA 83 104 152.9

Condenser Fan Motor

Horsepower (RPM) ⅓ ⅓ ⅓

FLA 2.80 2.80 2.80

Refrigeration System

Refrigerant Line Size¹

Liquid Line Size (“O.D.) ⅜" ⅜" ⅜"

Sucon Line Size (“O.D.) ⅞" 1⅛" 1⅛"

Refrigerant Connecon Size

Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜"

Sucon Valve Size (“O.D.) ⅞" ⅞" ⅞"

Valve Connecon Type Sweat Sweat Sweat

Refrigerant Charge 184 259 259

Expansion Device TXV TXV TXV

Superheat at Service Valve 7-9°F 7-9°F 7-9°F

Subcooling at Service Valve 5-7°F 5-7°F 5-7°F

Electrical Data

Voltage-Phase-Hz 208/230-1-60 208/230-1-60 208/230-1-60

Minimum Circuit Ampacity ¹ 21.9 29.3 36.7

Max. Overcurrent Protecon ² 35 50 60

Min / Max Volts 197 / 253 197 / 253 197 / 253

Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾"

Equipment Weight (lbs) 206 268 274

Ship Weight (lbs) 228 290 296

DSXC18

0481A

DSXC18

0601A

¹ Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes ² Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.

Notes

• Always check the S&R plate for electrical data on the unit being installed.

• Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.

• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be ad-

justed per Installaon Instrucons Final Charge Procedure.

• Installaon of these units that require a TXV Kit to be installed on the indoor coil.

• PLEASE NOTE: the specied TXV is determined by the outdoor unit, not the indoor coil.

SS-DSXC18 www.goodmanmfg.com 3

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180361A* / CA*f4961*6**+tXV / mBVC2000**-1 low StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 21.1 21.9 24.0 - 20.1 20.8 22.8 - 18.6 19.3 21.1 -

23 21 18 12 23 22 18 12 23 21 17 12 22 20 16 11

∆T 23 21 17 12 23 21 17 12

kW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

5.4 5.6 5.8 5.7 5.9 6.1 6.3 6.2 6.4 6.6 6.9 6.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

Amps 5.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

Lo PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

MBh 23.1 23.8 25.7 27.6 22.5 23.2 25.1 27.0 22.0 22.7 24.5 26.3 21.5 22.1 23.9 25.7 20.4 21.0 22.7 24.4 18.9 19.5 21.1 22.6

S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40

∆T 23 22 18 12 24 22 18 12 24 22 18 12 24 22 18 12 24 22 18 12 22 20 17 11

kW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

Amps 5.2 5.4 5.5 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

5.4 5.5 - 5.7 5.8 6.0 - 6.2 6.3 6.5 - 6.6 6.8 7.0 - 7.1 7.2 7.5 - 7.5 7.7 7.9 -

∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

S/T 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -

MBh 25.3 26.2 28.8 - 24.7 25.6 28.1 - 24.1 25.0 27.4 - 23.6 24.4 26.8 - 22.4 23.2 25.4 - 20.7 21.5 23.5 -

kW 1.30 1.33 1.38 - 1.41 1.45 1.50 - 1.51 1.55 1.60 - 1.60 1.63 1.69 - 1.67 1.71 1.77 - 1.73 1.77 1.84 -

HI PR 210 226 229 - 237 255 259 - 270 290 295 - 308 331 335 - 332 357 362 - 394 423 429 -

Lo PR 124 128 140 - 128 132 144 - 132 136 149 - 135 140 153 - 138 143 156 - 142 146 159 -

Amps 5.3 5.5 5.7 - 5.8 5.9 6.1 - 6.3 6.5 6.7 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 -

∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 18 13 - 20 17 13 - 19 16 12 -

S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -

MBh 24.6 25.5 27.9 - 24.0 24.9 27.3 - 23.4 24.3 26.6 - 22.9 23.7 26.0 - 21.7 22.5 24.7 - 20.1 20.9 22.9 -

kW 1.29 1.32 1.37 - 1.40 1.43 1.48 - 1.50 1.53 1.59 - 1.58 1.62 1.68 - 1.65 1.69 1.75 - 1.72 1.76 1.82 -

HI PR 208 224 227 - 235 253 256 - 267 288 292 - 305 327 332 - 329 354 359 - 390 419 425 -

Lo PR 123 127 138 - 126 130 142 - 131 135 147 - 134 138 151 - 137 141 154 - 140 145 158 -

Amps 5.3 5.4 5.6 - 5.7 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.6 7.7 8.0 -

MBh 22.7 23.5 25.8 - 22.2 23.0 25.2 - 21.6 22.4 24.6

∆T 20 18 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -

kW 1.28 1.31 1.36 - 1.39 1.42 1.47 - 1.48 1.52 1.57 - 1.57 1.60 1.66 - 1.64 1.68 1.74 - 1.70 1.74 1.80 -

HI PR 206 221 225 - 233 250 254 - 265 285 289 - 302 324 329 - 326 350 355 - 386 415 421 -

Lo PR 122 125 137 - 125 129 141 - 129 133 146 - 133 137 150 - 135 140 153 - 139 143 156 -

Amps 5.2

MBh 25.8 26.5 28.7 30.8 25.2 25.9 28.0 30.1 24.6 25.3 27.4 29.4 24.0 24.7 26.7 28.7 22.8 23.4 25.4 27.2 21.1 21.7 23.5 25.2

S/T 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.89 0.67 0.43

∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 12 21 19 16 11

kW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

Amps 5.3 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

Lo PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.0 25.7 27.9 29.9 24.4 25.1 27.2 29.2 23.8 24.5 26.6 28.5 23.3 23.9 25.9 27.8 22.1 22.8 24.6 26.4 20.5 21.1 22.8 24.5

S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41

825

720

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

930

825

720

930

4 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180361A* / CA*f4961*6**+tXV / mBVC2000**-1 low StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 26.2 26.8 28.6 30.6 25.6 26.2 28.0 29.9 25.0 25.5 27.3 29.2 24.4 24.9 26.6 28.5 23.2 23.7 25.3 27.0 21.5 21.9 23.4 25.0

S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62

∆T 25 23 20 16 25 24 21 17 25 24 21 17 24 25 21 17 23 23 21 16 21 22 19 15

kW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

Amps 5.3 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

Lo PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.4 26.0 27.8 29.7 24.9 25.4 27.1 29.0 24.3 24.8 26.5 28.3 23.7 24.2 25.8 27.6 22.5 23.0 24.6 26.2 20.8 21.3 22.7 24.3

S/T 0.90 0.85 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59

∆T 26 25 21 17 26 25 22 17 26 25 22 17 26 25 22 17 25 25 21 17 23 23 20 16

kW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

Amps 5.3 5.4 5.6 5.8 5.7 5.9 6.1 6.3 6.2 6.4 6.6 6.9 6.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

Lo PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

26.1 21.9 22.3 23.9 25.5 20.8 21.2 22.7 24.2 19.2 19.6 21.0 22.4

MBh 23.5 24.0 25.6 27.4 22.9 23.4 25.0 26.8 22.4 22.9 24.5

S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.76 0.56 1.00 0.94 0.76 0.57

∆T 26 25 22 17 26 25 22 18 26 25 22 18 27 26 22 18 26 25 22 17 25 24 20 16

kW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

5.4 5.5 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

Amps 5.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

MBh 26.7 27.2 28.5 30.4 26.0 26.6 27.8 29.7 25.4 25.9 27.1 29.0 24.8 25.3 26.5 28.3 23.6 24.0 25.2 26.8 21.8 22.3 23.3 24.9

S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80

∆T 26 26 24 21 26 26 25 21 25 26 25 21 25 25 25 21 23 24 24 21 22 22 23 20

kW 1.30 1.33 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.55 1.60 1.66 1.60 1.63 1.69 1.75 1.67 1.71 1.77 1.83 1.73 1.77 1.84 1.90

Amps 5.3 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4

HI PR 210 226 229 234 237 255 259 265 270 290 295 301 308 331 335 343 332 357 362 370 394 423 429 439

Lo PR 124 128 140 149 128 132 144 153 132 136 149 158 135 140 153 162 138 143 156 166 142 146 159 170

MBh 25.9 26.4 27.6 29.5 25.3 25.8 27.0 28.8 24.7 25.2 26.4 28.1 24.1 24.6 25.7 27.4 22.9 23.3 24.4 26.1 21.2 21.6 22.6 24.1

S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

28 27 26 22 27 27 26 22 25 26 26 22 24 24 24 21

∆T 27 27 25 22 28 27 26 22

kW 1.29 1.32 1.37 1.42 1.40 1.43 1.48 1.54 1.50 1.53 1.59 1.64 1.58 1.62 1.68 1.74 1.65 1.69 1.75 1.82 1.72 1.76 1.82 1.88

5.4 5.6 5.8 5.7 5.9 6.1 6.3 6.2 6.4 6.6 6.9 6.7 6.8 7.1 7.4 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3

Amps 5.3

HI PR 208 224 227 232 235 253 256 262 267 288 292 298 305 327 332 339 329 354 359 367 390 419 425 435

Lo PR 123 127 138 147 126 130 142 152 131 135 147 157 134 138 151 161 137 141 154 164 140 145 158 168

MBh 23.9 24.4 25.5 27.2 23.3 23.8 24.9 26.6 22.8 23.2 24.3 26.0 22.2 22.7 23.7 25.3 21.1 21.5 22.5 24.1 19.6 19.9 20.9 22.3

S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74

∆T 27.8 27 26 22 28 28 26 23 28 28 26 23 28 28 26 23 27 27 26 23 25 25 24 21

kW 1.28 1.31 1.36 1.40 1.39 1.42 1.47 1.52 1.48 1.52 1.57 1.63 1.57 1.60 1.66 1.72 1.64 1.68 1.74 1.80 1.70 1.74 1.80 1.87

Amps 5.2 5.4 5.5 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.8 7.5 7.7 7.9 8.2

HI PR 206 221 225 230 233 250 254 259 265 285 289 295 302 324 329 336 326 350 355 363 386 415 421 430

Lo PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

930

825

720

930

825

720

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 5

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180361A* / CA*f4961*6**+tXV / mBVC2000**-1 high StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 30.6 31.7 34.8 - 29.1 30.1 33.0 - 26.9 27.9 30.6 -

23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11

∆T 23 21 17 12 23 21 17 12

kW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

Amps 8.1

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

Lo PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

MBh 33.5 34.5 37.3 40.0 32.7 33.6 36.4 39.1 31.9 32.8 35.6 38.2 31.1 32.0 34.7 37.2 29.6 30.4 33.0 35.4 27.4 28.2 30.5 32.8

S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.59 0.38 0.89 0.79 0.60 0.39

∆T 23 21 17 12 23 22 18 12 23 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11

kW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

Amps 8.1 8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

Lo PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

8.3 8.5 - 8.7 9.0 9.3 - 9.5 9.8 10.1 - 10.2 10.5 10.8 - 10.9 11.2 11.5 - 11.6 11.8 12.3 -

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -

S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -

MBh 36.7 38.1 41.7 - 35.9 37.2 40.7 - 35.0 36.3 39.8 - 34.2 35.4 38.8 - 32.4 33.6 36.8 - 30.1 31.2 34.1 -

kW 2.09 2.14 2.21 - 2.26 2.31 2.39 - 2.41 2.47 2.56 - 2.55 2.61 2.70 - 2.66 2.73 2.82 - 2.76 2.83 2.93 -

HI PR 220 237 240 - 249 268 271 - 283 304 309 - 322 347 352 - 348 374 380 - 413 444 450 -

Lo PR 118 122 133 - 122 126 137 - 126 130 142 - 129 134 146 - 132 136 149 - 135 140 152 -

Amps 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.7 9.9 10.3 - 10.4 10.7 11.0 - 11.1 11.4 11.8 - 11.8 12.1 12.5 -

∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

MBh 35.6 36.9 40.5 - 34.8 36.1 39.5 - 34.0 35.2 38.6 - 33.2 34.4 37.7 - 31.5 32.7 35.8 - 29.2 30.2 33.1 -

kW 2.07 2.12 2.19 - 2.24 2.29 2.37 - 2.39 2.45 2.53 - 2.53 2.59 2.68 - 2.64 2.70 2.80 - 2.74 2.80 2.90 -

HI PR 218 234 238 - 246 265 269 - 280 301 306 - 319 343 348 - 345 371 376 - 409 439 446 -

Lo PR 117 121 132 - 121 125 136 - 125 129 141 - 128 132 144 - 131 135 147 - 134 138 151 -

Amps 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.6 9.9 10.2 - 10.3 10.6 10.9 - 11.0 11.3 11.7 - 11.7 12.0 12.4 -

MBh 32.9 34.1 37.4 - 32.1 33.3 36.5 - 31.4 32.5 35.6

∆T 20 17 13 - 20 18 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -

S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -

kW 2.05 2.10 2.17 - 2.22 2.27 2.35 - 2.37 2.43 2.51 - 2.50 2.56 2.65 - 2.62 2.68 2.77 - 2.71 2.78 2.88 -

HI PR 216 232 235 - 244 262 266 - 278 298 303 - 316 340 345 - 341 367 372 - 405 435 441 -

Lo PR 116 120 131 - 120 123 135 - 124 127 139 - 127 131 143 - 129 134 146 - 133 137 149 -

Amps 8.1

MBh 37.3 38.4 41.6 44.7 36.5 37.5 40.6 43.6 35.6 36.7 39.7 42.6 34.7 35.8 38.7 41.5 33.0 34.0 36.8 39.5 30.6 31.5 34.1 36.6

S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42

∆T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11

kW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

Amps 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

Lo PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 36.3 37.3 40.4 43.4 35.4 36.5 39.5 42.4 34.6 35.6 38.5 41.3 33.7 34.7 37.6 40.3 32.0 33.0 35.7 38.3 29.7 30.6 33.1 35.5

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

1175

1025

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1330

1175

1025

1330

6 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180361A* / CA*f4961*6**+tXV / mBVC2000**-1 high StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 38.0 38.8 41.5 44.4 37.1 37.9 40.5 43.3 36.2 37.0 39.6 42.3 35.4 36.1 38.6 41.3 33.6 34.3 36.7 39.2 31.1 31.8 34.0 36.3

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.81 0.60

∆T 24 23 20 16 24 23 20 16 25 23 20 16 24 24 21 16 23 24 20 16 22 22 19 15

kW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

Amps 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

Lo PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 36.9 37.7 40.3 43.1 36.0 36.8 39.3 42.1 35.2 35.9 38.4 41.1 34.3 35.1 37.5 40.1 32.6 33.3 35.6 38.1 30.2 30.9 33.0 35.2

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.00 0.94 0.77 0.57

∆T 25 24 21 17 26 25 21 17 26 25 21 17 26 25 22 17 25 24 21 17 24 23 20 16

kW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

Amps 8.1 8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

Lo PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

37.9 31.7 32.4 34.6 37.0 30.1 30.8 32.9 35.1 27.9 28.5 30.4 32.5

MBh 34.1 34.8 37.2 39.7 33.3 34.0 36.3 38.8 32.5 33.2 35.4

S/T 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 0.97 0.91 0.74 0.55

∆T 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16

kW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

Amps 8.1

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

Lo PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

MBh 38.7 39.4 41.3 44.0 37.8 38.5 40.3 43.0 36.9 37.6 39.4 42.0 36.0 36.7 38.4 41.0 34.2 34.8 36.5 38.9 31.7 32.3 33.8 36.1

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.96 0.78

∆T 26 25 24 21 26 26 24 21 25 26 24 21 25 25 24 21 24 24 24 21 22 22 23 19

kW 2.09 2.14 2.21 2.28 2.26 2.31 2.39 2.48 2.41 2.47 2.56 2.65 2.55 2.61 2.70 2.80 2.66 2.73 2.82 2.92 2.76 2.83 2.93 3.03

Amps 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.7 9.9 10.3 10.7 10.4 10.7 11.0 11.5 11.1 11.4 11.8 12.2 11.8 12.1 12.5 13.0

HI PR 220 237 240 245 249 268 271 277 283 304 309 316 322 347 352 359 348 374 380 388 413 444 450 460

Lo PR 118 122 133 142 122 126 137 146 126 130 142 151 129 134 146 155 132 136 149 158 135 140 152 162

MBh 37.5 38.3 40.1 42.8 36.7 37.4 39.1 41.8 35.8 36.5 38.2 40.8 34.9 35.6 37.3 39.8 33.2 33.8 35.4 37.8 30.7 31.3 32.8 35.0

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75

27 27 25 22 27 27 26 22 26 26 25 22 24 25 24 20

∆T 27 27 25 22 27 27 25 22

kW 2.07 2.12 2.19 2.26 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.62 2.53 2.59 2.68 2.77 2.64 2.70 2.80 2.90 2.74 2.80 2.90 3.01

8.3 8.6 9.0 8.8 9.0 9.3 9.7 9.6 9.9 10.2 10.6 10.3 10.6 10.9 11.4 11.0 11.3 11.7 12.1 11.7 12.0 12.4 12.9

Amps 8.1

HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455

Lo PR 117 121 132 141 121 125 136 145 125 129 141 150 128 132 144 154 131 135 147 157 134 138 151 161

MBh 34.6 35.3 37.0 39.5 33.8 34.5 36.1 38.5 33.0 33.7 35.3 37.6 32.2 32.9 34.4 36.7 30.6 31.2 32.7 34.9 28.4 28.9 30.3 32.3

S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.89 0.72

∆T 28 27 26 22 28 27 26 22 28 27 26 22 28 28 26 23 27 27 26 22 25 25 24 21

kW 2.05 2.10 2.17 2.24 2.22 2.27 2.35 2.43 2.37 2.43 2.51 2.60 2.50 2.56 2.65 2.75 2.62 2.68 2.77 2.87 2.71 2.78 2.88 2.98

Amps 8.1 8.3 8.5 8.9 8.7 9.0 9.3 9.6 9.5 9.8 10.1 10.5 10.2 10.5 10.8 11.2 10.9 11.2 11.5 12.0 11.6 11.8 12.3 12.7

HI PR 216 232 235 241 244 262 266 272 278 298 303 309 316 340 345 352 341 367 372 380 405 435 441 451

Lo PR 116 120 131 139 120 123 135 143 124 127 139 148 127 131 143 152 129 134 146 155 133 137 149 159

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1330

1175

1025

1330

1175

1025

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 7

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180481A* / CA*f4961*6**+tXV / mBVC2000**-1 low StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 28.8 29.9 32.7 - 27.4 28.4 31.1 - 25.4 26.3 28.8 -

22 21 17 12 22 21 17 12 22 20 17 12 21 19 16 11

∆T 22 20 17 11 22 21 17 12

kW 1.85 1.89 1.96 2.03 2.00 2.05 2.12 2.20 2.14 2.19 2.27 2.35 2.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

7.3 7.6 7.9 7.7 7.9 8.2 8.5 8.4 8.7 9.0 9.3 9.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

Amps 7.1

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

Lo PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

MBh 31.5 32.4 35.1 37.7 30.8 31.7 34.3 36.8 30.0 30.9 33.5 35.9 29.3 30.2 32.7 35.1 27.8 28.7 31.0 33.3 25.8 26.6 28.7 30.8

S/T 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.91 0.81 0.61 0.39 0.91 0.82 0.62 0.40

∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11

kW 1.83 1.88 1.94 2.01 1.99 2.03 2.10 2.18 2.12 2.17 2.25 2.33 2.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

Amps 7.1 7.2 7.5 7.8 7.7 7.9 8.1 8.4 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

Lo PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

7.2 7.5 - 7.7 7.9 8.1 - 8.4 8.6 8.9 - 9.0 9.2 9.5 - 9.6 9.8 10.1 - 10.2 10.4 10.8 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.83 0.70 0.48 - 0.87 0.72 0.50 - 0.87 0.73 0.51 -

MBh 34.6 35.8 39.3 - 33.8 35.0 38.3 - 33.0 34.2 37.4 - 32.2 33.3 36.5 - 30.5 31.7 34.7 - 28.3 29.3 32.1 -

kW 1.87 1.91 1.97 - 2.02 2.07 2.14 - 2.16 2.21 2.29 - 2.28 2.34 2.42 - 2.39 2.44 2.53 - 2.47 2.53 2.62 -

HI PR 216 232 235 - 244 262 266 - 277 298 303 - 316 340 345 - 356 382 388 - 398 428 434 -

Lo PR 121 125 137 - 125 129 141 - 129 133 146 - 133 137 149 - 135 140 152 - 139 143 156 -

Amps 7.2 7.4 7.6 - 7.8 8.0 8.3 - 8.5 8.7 9.0 - 9.1 9.4 9.7 - 9.7 10.0 10.3 - 10.4 10.6 11.0 -

∆T 19 16 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.66 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

MBh 33.6 34.8 38.1 - 32.8 34.0 37.2 - 32.0 33.2 36.3 - 31.2 32.4 35.5 - 29.7 30.7 33.7 - 27.5 28.5 31.2 -

kW 1.85 1.89 1.96 - 2.00 2.05 2.12 - 2.14 2.19 2.27 - 2.26 2.32 2.40 - 2.36 2.42 2.51 - 2.45 2.51 2.60 -

HI PR 214 230 233 - 242 260 263 - 275 295 300 - 313 336 341 - 352 378 384 - 394 424 430 -

Lo PR 120 124 135 - 124 128 139 - 128 132 144 - 131 136 148 - 134 138 151 - 137 142 155 -

Amps 7.1 7.3 7.6 - 7.7 7.9 8.2 - 8.4 8.7 9.0 - 9.0 9.3 9.6 - 9.7 9.9 10.2 - 10.3 10.5 10.9 -

MBh 31.0 32.1 35.2 - 30.3 31.4 34.4 - 29.5 30.6 33.5

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

S/T 0.70 0.58 0.40 - 0.73 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.67 0.46 - 0.80 0.67 0.46 -

kW 1.83 1.88 1.94 - 1.99 2.03 2.10 - 2.12 2.17 2.25 - 2.24 2.29 2.38 - 2.34 2.40 2.48 - 2.43 2.49 2.58 -

HI PR 212 227 231 - 239 257 261 - 272 292 297 - 310 333 338 - 348 375 380 - 390 420 426 -

Lo PR 119 123 134 - 123 126 138 - 127 131 143 - 130 134 147 - 133 137 149 - 136 140 153 -

Amps 7.1

MBh 35.2 36.2 39.2 42.0 34.3 35.4 38.3 41.1 33.5 34.5 37.4 40.1 32.7 33.7 36.4 39.1 31.1 32.0 34.6 37.2 28.8 29.6 32.1 34.4

S/T 0.86 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.67 0.43 0.99 0.89 0.67 0.43

∆T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 1.87 1.91 1.97 2.04 2.02 2.07 2.14 2.22 2.16 2.21 2.29 2.37 2.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

Amps 7.2 7.4 7.6 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

Lo PR 121 125 137 146 125 129 141 150 129 133 146 155 133 137 149 159 135 140 152 162 139 143 156 166

MBh 34.1 35.1 38.0 40.8 33.3 34.3 37.2 39.9 32.5 33.5 36.3 38.9 31.7 32.7 35.4 38.0 30.2 31.1 33.6 36.1 27.9 28.8 31.1 33.4

S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

1175

1025

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1325

1175

1025

1325

8 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180481A* / CA*f4961*6**+tXV / mBVC2000**-1 low StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 35.8 36.6 39.1 41.8 34.9 35.7 38.2 40.8 34.1 34.9 37.2 39.8 33.3 34.0 36.3 38.8 31.6 32.3 34.5 36.9 29.3 29.9 32.0 34.2

S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.62 1.00 1.00 0.83 0.62

∆T 24 23 20 16 24 23 20 16 24 23 20 16 23 24 20 16 22 22 20 16 20 21 18 15

kW 1.87 1.91 1.97 2.04 2.02 2.07 2.14 2.22 2.16 2.21 2.29 2.37 2.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

Amps 7.2 7.4 7.6 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

Lo PR 121 125 137 146 125 129 141 150 129 133 146 155 133 137 149 159 135 140 152 162 139 143 156 166

MBh 34.7 35.5 37.9 40.5 33.9 34.7 37.0 39.6 33.1 33.8 36.2 38.7 32.3 33.0 35.3 37.7 30.7 31.4 33.5 35.8 28.4 29.1 31.0 33.2

S/T 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.97 0.79 0.59

∆T 25 24 20 16 25 24 21 17 25 24 21 17 25 24 21 17 24 24 21 16 22 22 19 15

kW 1.85 1.89 1.96 2.03 2.00 2.05 2.12 2.20 2.14 2.19 2.27 2.35 2.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

Amps 7.1 7.3 7.6 7.9 7.7 7.9 8.2 8.5 8.4 8.7 9.0 9.3 9.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

Lo PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

35.7 29.8 30.5 32.6 34.8 28.3 29.0 30.9 33.1 26.2 26.8 28.7 30.6

MBh 32.1 32.8 35.0 37.4 31.3 32.0 34.2 36.5 30.6 31.2 33.4

S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57

∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 25 24 21 17 24 23 20 16

kW 1.83 1.88 1.94 2.01 1.99 2.03 2.10 2.18 2.12 2.17 2.25 2.33 2.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

7.2 7.5 7.8 7.7 7.9 8.1 8.4 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

Amps 7.1

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

Lo PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

MBh 36.4 37.1 38.9 41.5 35.6 36.2 38.0 40.5 34.7 35.4 37.1 39.5 33.9 34.5 36.2 38.6 32.2 32.8 34.3 36.6 29.8 30.4 31.8 33.9

S/T 0.99 0.96 0.87 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 0.99 0.81

∆T 25 25 23 20 25 25 24 20 24 25 24 20 23 24 24 21 22 23 23 20 21 21 22 19

kW 1.87 1.91 1.97 2.04 2.02 2.07 2.14 2.22 2.16 2.21 2.29 2.37 2.28 2.34 2.42 2.51 2.39 2.44 2.53 2.62 2.47 2.53 2.62 2.72

Amps 7.2 7.4 7.6 7.9 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.4 9.1 9.4 9.7 10.1 9.7 10.0 10.3 10.8 10.4 10.6 11.0 11.4

HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 356 382 388 396 398 428 434 444

Lo PR 121 125 137 146 125 129 141 150 129 133 146 155 133 137 149 159 135 140 152 162 139 143 156 166

MBh 35.3 36.0 37.7 40.3 34.5 35.2 36.9 39.3 33.7 34.4 36.0 38.4 32.9 33.5 35.1 37.4 31.2 31.8 33.3 35.6 28.9 29.5 30.9 33.0

S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

26 26 25 21 26 26 25 22 24 25 25 21 23 23 23 20

∆T 26 26 24 21 27 26 25 21

kW 1.85 1.89 1.96 2.03 2.00 2.05 2.12 2.20 2.14 2.19 2.27 2.35 2.26 2.32 2.40 2.48 2.36 2.42 2.51 2.60 2.45 2.51 2.60 2.69

7.3 7.6 7.9 7.7 7.9 8.2 8.5 8.4 8.7 9.0 9.3 9.0 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3

Amps 7.1

HI PR 214 230 233 238 242 260 263 269 275 295 300 306 313 336 341 349 352 378 384 392 394 424 430 439

Lo PR 120 124 135 144 124 128 139 148 128 132 144 154 131 136 148 158 134 138 151 161 137 142 155 165

MBh 32.6 33.3 34.8 37.2 31.9 32.5 34.0 36.3 31.1 31.7 33.2 35.4 30.3 30.9 32.4 34.6 28.8 29.4 30.8 32.8 26.7 27.2 28.5 30.4

S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.83 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.91 0.74

∆T 26.8 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 24 23 20

kW 1.83 1.88 1.94 2.01 1.99 2.03 2.10 2.18 2.12 2.17 2.25 2.33 2.24 2.29 2.38 2.46 2.34 2.40 2.48 2.57 2.43 2.49 2.58 2.67

Amps 7.1 7.2 7.5 7.8 7.7 7.9 8.1 8.4 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.8 11.2

HI PR 212 227 231 236 239 257 261 267 272 292 297 303 310 333 338 345 348 375 380 388 390 420 426 435

Lo PR 119 123 134 143 123 126 138 147 127 131 143 152 130 134 147 156 133 137 149 159 136 140 153 163

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1325

1175

1025

1325

1175

1025

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 9

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180481A* / CA*f4961*6**+tXV / mBVC2000**-1 high StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 40.2 41.7 45.6 - 38.2 39.6 43.4 - 35.4 36.7 40.2 -

21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10

∆T 21 19 16 11 21 19 16 11

kW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

Amps 10.1

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

MBh 43.9 45.2 49.0 52.6 42.9 44.2 47.8 51.3 41.9 43.1 46.7 50.1 40.9 42.1 45.6 48.9 38.8 40.0 43.3 46.4 36.0 37.0 40.1 43.0

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

∆T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

Amps 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

10.3 10.6 - 10.9 11.1 11.5 - 11.9 12.2 12.6 - 12.7 13.0 13.5 - 13.6 13.9 14.4 - 14.4 14.8 15.3 -

∆T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -

S/T 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -

MBh 48.2 50.0 54.8 - 47.1 48.8 53.5 - 46.0 47.7 52.2 - 44.9 46.5 50.9 - 42.6 44.2 48.4 - 39.5 40.9 44.8 -

kW 2.87 2.94 3.03 - 3.10 3.17 3.27 - 3.30 3.37 3.48 - 3.47 3.55 3.67 - 3.62 3.70 3.83 - 3.75 3.84 3.97 -

HI PR 228 245 248 - 257 277 280 - 292 315 319 - 333 358 363 - 375 403 409 - 420 451 458 -

Lo PR 121 124 136 - 124 128 140 - 128 132 145 - 132 136 148 - 134 139 151 - 138 142 155 -

Amps 10.2 10.5 10.8 - 11.1 11.4 11.7 - 12.1 12.4 12.8 - 13.0 13.3 13.7 - 13.8 14.2 14.7 - 14.7 15.1 15.6 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -

MBh 46.8 48.5 53.2 - 45.7 47.4 51.9 - 44.6 46.3 50.7 - 43.5 45.1 49.5 - 41.4 42.9 47.0 - 38.3 39.7 43.5 -

kW 2.85 2.91 3.01 - 3.07 3.14 3.24 - 3.27 3.34 3.45 - 3.44 3.52 3.64 - 3.59 3.67 3.80 - 3.72 3.80 3.93 -

HI PR 225 242 246 - 255 274 278 - 290 311 316 - 330 355 360 - 371 399 405 - 416 447 453 -

Lo PR 119 123 134 - 123 127 138 - 127 131 143 - 130 135 147 - 133 137 150 - 136 141 154 -

Amps 10.1 10.4 10.7 - 11.0 11.2 11.6 - 12.0 12.3 12.7 - 12.8 13.2 13.6 - 13.7 14.0 14.5 - 14.5 14.9 15.4 -

MBh 43.2 44.8 49.1 - 42.2 43.7 47.9 - 41.2 42.7 46.8

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

kW 2.83 2.89 2.98 - 3.05 3.12 3.22 - 3.24 3.32 3.43 - 3.42 3.49 3.61 - 3.56 3.64 3.76 - 3.69 3.77 3.90 -

HI PR 223 240 243 - 252 271 275 - 287 308 313 - 327 351 356 - 367 395 401 - 411 442 449 -

Lo PR 118 122 133 - 122 125 137 - 126 130 142 - 129 133 145 - 132 136 148 - 135 139 152 -

Amps 10.0

MBh 49.0 50.5 54.6 58.7 47.9 49.3 53.4 57.3 46.8 48.1 52.1 55.9 45.6 47.0 50.8 54.6 43.3 44.6 48.3 51.8 40.1 41.3 44.7 48.0

S/T 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.92 0.83 0.63 0.40 0.95 0.85 0.65 0.42 0.99 0.89 0.67 0.43 1.00 0.89 0.68 0.44

∆T 20 18 15 10 20 19 15 10 20 19 15 11 20 19 15 11 20 18 15 10 19 17 14 10

kW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

Amps 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

Lo PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 47.6 49.0 53.1 56.9 46.5 47.9 51.8 55.6 45.4 46.7 50.6 54.3 44.3 45.6 49.4 53.0 42.1 43.3 46.9 50.3 39.0 40.1 43.4 46.6

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

1750

1530

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1970

1750

1530

1970

10 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180481A* / CA*f4961*6**+tXV / mBVC2000**-1 high StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 49.9 51.0 54.5 58.2 48.7 49.8 53.2 56.9 47.6 48.6 52.0 55.5 46.4 47.4 50.7 54.2 44.1 45.1 48.1 51.5 40.9 41.7 44.6 47.7

S/T 0.95 0.89 0.73 0.54 1.00 0.93 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

∆T 22 21 19 15 23 22 19 15 22 22 19 15 22 22 19 15 21 21 19 15 19 19 17 14

kW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

Amps 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

Lo PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 48.5 49.5 52.9 56.5 47.3 48.4 51.7 55.2 46.2 47.2 50.4 53.9 45.1 46.1 49.2 52.6 42.8 43.8 46.7 50.0 39.7 40.5 43.3 46.3

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.80 0.60

∆T 23 22 19 15 23 22 20 16 23 22 20 16 24 23 20 16 22 22 19 16 21 21 18 14

kW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

Amps 10.1 10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

49.8 41.6 42.5 45.4 48.6 39.5 40.4 43.1 46.1 36.6 37.4 40.0 42.7

MBh 44.7 45.7 48.8 52.2 43.7 44.6 47.7 51.0 42.6 43.6 46.6

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.01 0.94 0.77 0.57

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15

kW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

Amps 10.0

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

MBh 50.8 51.8 54.2 57.8 49.6 50.6 53.0 56.5 48.4 49.4 51.7 55.1 47.2 48.2 50.4 53.8 44.9 45.7 47.9 51.1 41.6 42.4 44.4 47.3

S/T 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81

∆T 24 23 22 19 23 24 22 19 23 23 22 19 22 22 22 19 21 21 22 19 19 20 21 18

kW 2.87 2.94 3.03 3.13 3.10 3.17 3.27 3.38 3.30 3.37 3.48 3.60 3.47 3.55 3.67 3.80 3.62 3.70 3.83 3.96 3.75 3.84 3.97 4.10

Amps 10.2 10.5 10.8 11.2 11.1 11.4 11.7 12.2 12.1 12.4 12.8 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.7 15.3 14.7 15.1 15.6 16.2

HI PR 228 245 248 254 257 277 280 287 292 315 319 326 333 358 363 371 375 403 409 418 420 451 458 468

Lo PR 121 124 136 145 124 128 140 149 128 132 145 154 132 136 148 158 134 139 151 161 138 142 155 165

MBh 49.3 50.3 52.6 56.2 48.2 49.1 51.4 54.8 47.0 47.9 50.2 53.5 45.9 46.7 49.0 52.2 43.6 44.4 46.5 49.6 40.4 41.1 43.1 46.0

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77

25 25 23 20 24 25 23 20 23 23 23 20 21 22 22 19

∆T 25 24 23 20 25 25 23 20

kW 2.85 2.91 3.01 3.10 3.07 3.14 3.24 3.35 3.27 3.34 3.45 3.57 3.44 3.52 3.64 3.76 3.59 3.67 3.80 3.93 3.72 3.80 3.93 4.07

10.4 10.7 11.1 11.0 11.2 11.6 12.1 12.0 12.3 12.7 13.2 12.8 13.2 13.6 14.2 13.7 14.0 14.5 15.1 14.5 14.9 15.4 16.0

Amps 10.1

HI PR 225 242 246 251 255 274 278 284 290 311 316 323 330 355 360 368 371 399 405 414 416 447 453 463

Lo PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 154 163

MBh 45.5 46.4 48.6 51.8 44.4 45.3 47.5 50.6 43.4 44.2 46.3 49.4 42.3 43.1 45.2 48.2 40.2 41.0 42.9 45.8 37.3 38.0 39.8 42.4

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75

∆T 25 25 23 20 25 25 24 20 25 25 24 21 25 25 24 21 24 25 24 20 22 23 22 19

kW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.32 3.24 3.32 3.43 3.54 3.42 3.49 3.61 3.73 3.56 3.64 3.76 3.89 3.69 3.77 3.90 4.03

Amps 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.6 13.9 14.4 15.0 14.4 14.8 15.3 15.9

HI PR 223 240 243 249 252 271 275 281 287 308 313 320 327 351 356 364 367 395 401 409 411 442 449 459

Lo PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1970

1750

1530

1970

1750

1530

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 11

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180601A* / CA*f4961*6** +tXV / mBVC2000**-1 low StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 35.3 36.6 40.1 - 33.5 34.8 38.1 - 31.1 32.2 35.3 -

23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11

∆T 22 21 17 12 23 21 17 12

kW 2.41 2.47 2.55 2.64 2.61 2.68 2.77 2.87 2.80 2.86 2.96 3.07 2.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

9.5 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

Amps 9.3

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

Lo PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

MBh 38.6 39.7 43.0 46.2 37.7 38.8 42.0 45.1 36.8 37.9 41.0 44.0 35.9 37.0 40.0 42.9 34.1 35.1 38.0 40.8 31.6 32.5 35.2 37.8

S/T 0.76 0.68 0.51 0.33 0.79 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.75 0.56 0.36 0.87 0.77 0.59 0.38 0.87 0.78 0.59 0.38

∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11

kW 2.39 2.44 2.53 2.62 2.59 2.65 2.75 2.84 2.77 2.84 2.94 3.04 2.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

Amps 9.2 9.4 9.8 10.1 10.0 10.2 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

Lo PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

9.4 9.8 - 10.0 10.2 10.6 - 10.9 11.2 11.6 - 11.7 12.0 12.4 - 13.7 14.0 14.5 - 14.5 14.8 15.4 -

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -

MBh 42.4 43.9 48.1 - 41.4 42.9 47.0 - 40.4 41.9 45.9 - 39.4 40.8 44.7 - 37.4 38.8 42.5 - 34.7 35.9 39.4 -

kW 2.43 2.49 2.57 - 2.64 2.70 2.79 - 2.82 2.89 2.99 - 2.98 3.05 3.16 - 3.12 3.19 3.31 - 3.24 3.31 3.43 -

HI PR 226 243 247 - 248 267 271 - 291 313 317 - 331 356 361 - 372 400 406 - 430 463 469 -

Lo PR 118 122 133 - 121 125 137 - 125 129 141 - 129 133 145 - 131 136 148 - 135 139 152 -

Amps 9.4 9.6 10.0 - 10.2 10.4 10.8 - 11.1 11.4 11.8 - 11.9 12.2 12.6 - 14.0 14.3 14.8 - 14.8 15.1 15.7 -

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -

MBh 41.1 42.6 46.7 - 40.2 41.6 45.6 - 39.2 40.6 44.5 - 38.3 39.6 43.4 - 36.3 37.7 41.3 - 33.7 34.9 38.2 -

kW 2.41 2.47 2.55 - 2.61 2.68 2.77 - 2.80 2.86 2.96 - 2.95 3.03 3.13 - 3.09 3.16 3.28 - 3.21 3.28 3.40 -

HI PR 224 241 244 - 246 264 268 - 288 309 314 - 328 352 357 - 369 397 402 - 426 458 465 -

Lo PR 117 120 131 - 120 124 135 - 124 128 140 - 128 132 144 - 130 134 146 - 133 137 150 -

Amps 9.3 9.5 9.9 - 10.1 10.3 10.7 - 11.0 11.3 11.7 - 11.8 12.1 12.5 - 13.8 14.2 14.7 - 14.6 15.0 15.5 -

MBh 38.0 39.3 43.1 - 37.1 38.4 42.1 - 36.2 37.5 41.1

∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -

S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.64 0.44 - 0.77 0.64 0.44 -

kW 2.39 2.44 2.53 - 2.59 2.65 2.75 - 2.77 2.84 2.94 - 2.93 3.00 3.10 - 3.06 3.14 3.25 - 3.18 3.25 3.37 -

HI PR 222 238 242 - 243 262 265 - 285 306 311 - 325 349 354 - 365 393 398 - 422 454 460 -

Lo PR 116 119 130 - 119 123 134 - 123 127 138 - 126 130 142 - 129 133 145 - 132 136 149 -

Amps 9.2

MBh 43.1 44.3 48.0 51.5 42.1 43.3 46.9 50.3 41.1 42.3 45.8 49.1 40.1 41.3 44.7 47.9 38.1 39.2 42.4 45.5 35.3 36.3 39.3 42.2

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

∆T 22 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 11

kW 2.43 2.49 2.57 2.67 2.64 2.70 2.79 2.89 2.82 2.89 2.99 3.10 2.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

Amps 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

Lo PR 118 122 133 141 121 125 137 146 125 129 141 150 129 133 145 154 131 136 148 158 135 139 152 161

MBh 41.8 43.1 46.6 50.0 40.8 42.1 45.5 48.9 39.9 41.1 44.4 47.7 38.9 40.1 43.4 46.5 37.0 38.0 41.2 44.2 34.2 35.2 38.1 40.9

S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39

1350

1180

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1520

1350

1180

1520

12 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180601A* / CA*f4961*6** +tXV / mBVC2000**-1 low StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 43.8 44.8 47.9 51.2 42.8 43.8 46.7 50.0 41.8 42.7 45.6 48.8 40.8 41.7 44.5 47.6 38.7 39.6 42.3 45.2 35.9 36.7 39.2 41.9

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.79 0.59

∆T 24 23 20 16 24 23 20 16 24 23 20 16 25 23 20 16 23 23 20 16 22 22 19 15

kW 2.43 2.49 2.57 2.67 2.64 2.70 2.79 2.89 2.82 2.89 2.99 3.10 2.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

Amps 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

Lo PR 118 122 133 141 121 125 137 146 125 129 141 150 129 133 145 154 131 136 148 158 135 139 152 161

MBh 42.6 43.5 46.5 49.7 41.6 42.5 45.4 48.5 40.6 41.5 44.3 47.4 39.6 40.5 43.2 46.2 37.6 38.4 41.1 43.9 34.8 35.6 38.0 40.7

S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57

∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 24 21 17 25 24 21 17 24 23 20 16

kW 2.41 2.47 2.55 2.64 2.61 2.68 2.77 2.87 2.80 2.86 2.96 3.07 2.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

Amps 9.3 9.5 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

Lo PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

43.7 36.5 37.3 39.9 42.6 34.7 35.5 37.9 40.5 32.2 32.9 35.1 37.5

MBh 39.3 40.1 42.9 45.8 38.4 39.2 41.9 44.8 37.5 38.3 40.9

S/T 0.83 0.78 0.64 0.48 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.96 0.90 0.73 0.55

∆T 26 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16

kW 2.39 2.44 2.53 2.62 2.59 2.65 2.75 2.84 2.77 2.84 2.94 3.04 2.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

9.4 9.8 10.1 10.0 10.2 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

Amps 9.2

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

Lo PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

MBh 44.6 45.5 47.6 50.8 43.6 44.4 46.5 49.6 42.5 43.4 45.4 48.4 41.5 42.3 44.3 47.3 39.4 40.2 42.1 44.9 36.5 37.2 39.0 41.6

S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.70 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77

∆T 26 25 24 21 26 26 24 21 26 26 24 21 25 26 24 21 24 24 24 21 22 23 22 19

kW 2.43 2.49 2.57 2.67 2.64 2.70 2.79 2.89 2.82 2.89 2.99 3.10 2.98 3.05 3.16 3.28 3.12 3.19 3.31 3.43 3.24 3.31 3.43 3.56

Amps 9.4 9.6 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 14.0 14.3 14.8 15.4 14.8 15.1 15.7 16.3

HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 372 400 406 415 430 463 469 480

Lo PR 118 122 133 141 121 125 137 146 125 129 141 150 129 133 145 154 131 136 148 158 135 139 152 161

MBh 43.3 44.1 46.2 49.3 42.3 43.1 45.2 48.2 41.3 42.1 44.1 47.0 40.3 41.1 43.0 45.9 38.3 39.0 40.9 43.6 35.4 36.1 37.8 40.4

S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.73

27 27 25 22 27 27 25 22 26 26 25 22 24 25 23 20

∆T 27 26 25 22 27 27 25 22

kW 2.41 2.47 2.55 2.64 2.61 2.68 2.77 2.87 2.80 2.86 2.96 3.07 2.95 3.03 3.13 3.25 3.09 3.16 3.28 3.40 3.21 3.28 3.40 3.53

9.5 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 13.8 14.2 14.7 15.3 14.6 15.0 15.5 16.1

Amps 9.3

HI PR 224 241 244 250 246 264 268 274 288 309 314 321 328 352 357 365 369 397 402 411 426 458 465 475

Lo PR 117 120 131 140 120 124 135 144 124 128 140 149 128 132 144 153 130 134 146 156 133 137 150 160

MBh 40.0 40.7 42.7 45.5 39.0 39.8 41.7 44.5 38.1 38.8 40.7 43.4 37.2 37.9 39.7 42.3 35.3 36.0 37.7 40.2 32.7 33.4 34.9 37.3

S/T 0.87 0.84 0.76 0.62 0.91 0.87 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.96 0.87 0.70 1.00 0.97 0.87 0.71

∆T 27.2 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 27 27 25 22 25 25 24 21

kW 2.39 2.44 2.53 2.62 2.59 2.65 2.75 2.84 2.77 2.84 2.94 3.04 2.93 3.00 3.10 3.22 3.06 3.14 3.25 3.37 3.18 3.25 3.37 3.49

Amps 9.2 9.4 9.8 10.1 10.0 10.2 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 13.7 14.0 14.5 15.1 14.5 14.8 15.4 16.0

HI PR 222 238 242 247 243 262 265 271 285 306 311 318 325 349 354 362 365 393 398 407 422 454 460 470

Lo PR 116 119 130 139 119 123 134 143 123 127 138 147 126 130 142 151 129 133 145 154 132 136 149 158

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1520

1350

1180

1520

1350

1180

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 13

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

ExpandEd data ExpandEd data

Cooling DAtA – DSXC180601A* / CA*f4961*6** +tXV / mBVC2000**-1 high StAge

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

- 48.8 50.5 55.4 - 46.3 48.0 52.6 - 42.9 44.5 48.7 -

21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

∆T 21 19 16 11 21 20 16 11

kW 3.84 3.93 4.05 4.19 4.15 4.24 4.38 4.52 4.41 4.51 4.66 4.82 4.65 4.75 4.91 5.08 4.85 4.96 5.13 5.31 5.02 5.14 5.31 5.50

14.0 14.5 15.1 14.9 15.2 15.8 16.4 16.2 16.6 17.2 17.9 17.4 17.8 18.5 19.2 20.4 21.0 21.7 22.6 21.6 22.2 23.0 23.9

Amps 13.7

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

Lo PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

MBh 53.3 54.9 59.4 63.8 52.1 53.6 58.0 62.3 50.8 52.3 56.7 60.8 49.6 51.1 55.3 59.3 47.1 48.5 52.5 56.4 43.6 44.9 48.6 52.2

S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38

∆T 21 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 11

kW 3.81 3.89 4.02 4.15 4.11 4.20 4.34 4.49 4.38 4.47 4.62 4.78 4.61 4.71 4.87 5.04 4.81 4.92 5.08 5.26 4.98 5.09 5.27 5.45

Amps 13.5 13.9 14.4 14.9 14.7 15.1 15.6 16.2 16.1 16.5 17.1 17.7 17.2 17.7 18.3 19.0 20.2 20.8 21.5 22.3 21.4 22.0 22.7 23.6

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

Lo PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

13.9 14.4 - 14.7 15.1 15.6 - 16.1 16.5 17.1 - 17.2 17.7 18.3 - 20.2 20.8 21.5 - 21.4 22.0 22.7 -

∆T 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -

S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -

MBh 58.5 60.6 66.4 - 57.1 59.2 64.9 - 55.8 57.8 63.3 - 54.4 56.4 61.8 - 51.7 53.6 58.7 - 47.9 49.6 54.4 -

kW 3.87 3.96 4.09 - 4.18 4.27 4.41 - 4.45 4.55 4.70 - 4.69 4.80 4.96 - 4.89 5.00 5.17 - 5.07 5.18 5.36 -

HI PR 241 259 263 - 265 285 289 - 310 333 338 - 353 380 385 - 397 427 433 - 459 493 500 -

Lo PR 115 119 130 - 118 122 133 - 123 126 138 - 126 130 142 - 128 132 144 - 131 136 148 -

Amps 13.8 14.2 14.7 - 15.0 15.4 15.9 - 16.4 16.8 17.4 - 17.6 18.0 18.7 - 20.6 21.2 21.9 - 21.8 22.4 23.2 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -

MBh 56.8 58.9 64.5 - 55.5 57.5 63.0 - 54.2 56.1 61.5 - 52.8 54.8 60.0 - 50.2 52.0 57.0 - 46.5 48.2 52.8 -

kW 3.84 3.93 4.05 - 4.15 4.24 4.38 - 4.41 4.51 4.66 - 4.65 4.75 4.91 - 4.85 4.96 5.13 - 5.02 5.14 5.31 -

HI PR 239 257 260 - 262 282 286 - 307 330 335 - 349 376 381 - 393 423 429 - 454 488 495 -

Lo PR 114 118 128 - 117 121 132 - 121 125 137 - 125 128 140 - 127 131 143 - 130 134 147 -

Amps 13.7 14.0 14.5 - 14.9 15.2 15.8 - 16.2 16.6 17.2 - 17.4 17.8 18.5 - 20.4 21.0 21.7 - 21.6 22.2 23.0 -

MBh 52.4 54.3 59.5 - 51.2 53.1 58.1 - 50.0 51.8 56.8

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -

S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -

kW 3.81 3.89 4.02 - 4.11 4.20 4.34 - 4.38 4.47 4.62 - 4.61 4.71 4.87 - 4.81 4.92 5.08 - 4.98 5.09 5.27 -

HI PR 236 254 258 - 259 279 283 - 304 327 331 - 346 372 377 - 389 419 424 - 450 484 490 -

Lo PR 113 116 127 - 116 120 131 - 120 124 135 - 123 127 139 - 126 130 142 - 129 133 145 -

Amps 13.5

MBh 59.5 61.3 66.3 71.2 58.1 59.8 64.8 69.5 56.7 58.4 63.2 67.8 55.3 57.0 61.7 66.2 52.6 54.1 58.6 62.9 48.7 50.1 54.3 58.3

S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42

∆T 20 19 15 11 20 19 15 11 21 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10

kW 3.87 3.96 4.09 4.22 4.18 4.27 4.41 4.56 4.45 4.55 4.70 4.86 4.69 4.80 4.96 5.13 4.89 5.00 5.17 5.35 5.07 5.18 5.36 5.55

Amps 13.8 14.2 14.7 15.2 15.0 15.4 15.9 16.6 16.4 16.8 17.4 18.1 17.6 18.0 18.7 19.4 20.6 21.2 21.9 22.8 21.8 22.4 23.2 24.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

Lo PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 57.8 59.5 64.4 69.1 56.4 58.1 62.9 67.5 55.1 56.7 61.4 65.9 53.7 55.3 59.9 64.3 51.0 52.6 56.9 61.1 47.3 48.7 52.7 56.6

S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40

2000

1750

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

2250

2000

1750

2250

14 www.goodmanmfg.com SS-DSXC18

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Cooling DAtA – DSXC180601A* / CA*f4961*6** +tXV / mBVC2000**-1 high StAge (Cont.)

Outdoor Ambient Temperature

Entering Indoor Wet Bulb Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

MBh 60.6 61.9 66.1 70.7 59.1 60.4 64.6 69.0 57.7 59.0 63.0 67.4 56.3 57.6 61.5 65.7 53.5 54.7 58.4 62.4 49.6 50.6 54.1 57.8

S/T 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 1.00 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.80 0.60

∆T 23 22 19 15 23 22 19 15 24 22 19 15 23 22 19 15 22 22 19 15 20 21 18 14

kW 3.87 3.96 4.09 4.22 4.18 4.27 4.41 4.56 4.45 4.55 4.70 4.86 4.69 4.80 4.96 5.13 4.89 5.00 5.17 5.35 5.07 5.18 5.36 5.55

Amps 13.8 14.2 14.7 15.2 15.0 15.4 15.9 16.6 16.4 16.8 17.4 18.1 17.6 18.0 18.7 19.4 20.6 21.2 21.9 22.8 21.8 22.4 23.2 24.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

Lo PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 58.8 60.1 64.2 68.6 57.4 58.7 62.7 67.0 56.1 57.3 61.2 65.4 54.7 55.9 59.7 63.8 52.0 53.1 56.7 60.6 48.1 49.2 52.5 56.2

S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15

kW 3.84 3.93 4.05 4.19 4.15 4.24 4.38 4.52 4.41 4.51 4.66 4.82 4.65 4.75 4.91 5.08 4.85 4.96 5.13 5.31 5.02 5.14 5.31 5.50

Amps 13.7 14.0 14.5 15.1 14.9 15.2 15.8 16.4 16.2 16.6 17.2 17.9 17.4 17.8 18.5 19.2 20.4 21.0 21.7 22.6 21.6 22.2 23.0 23.9

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

Lo PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

60.4 50.5 51.6 55.1 58.9 48.0 49.0 52.3 56.0 44.4 45.4 48.5 51.8

MBh 54.3 55.4 59.2 63.3 53.0 54.2 57.9 61.9 51.7 52.9 56.5

S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.66 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.53 0.96 0.90 0.73 0.55 0.96 0.90 0.74 0.55

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 22 19 15

kW 3.81 3.89 4.02 4.15 4.11 4.20 4.34 4.49 4.38 4.47 4.62 4.78 4.61 4.71 4.87 5.04 4.81 4.92 5.08 5.26 4.98 5.09 5.27 5.45

13.9 14.4 14.9 14.7 15.1 15.6 16.2 16.1 16.5 17.1 17.7 17.2 17.7 18.3 19.0 20.2 20.8 21.5 22.3 21.4 22.0 22.7 23.6

Amps 13.5

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

Lo PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

MBh 61.6 62.8 65.8 70.2 60.2 61.3 64.2 68.5 58.7 59.9 62.7 66.9 57.3 58.4 61.2 65.3 54.4 55.5 58.1 62.0 50.4 51.4 53.8 57.4

S/T 0.96 0.92 0.83 0.68 0.99 0.96 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78

∆T 24 24 22 19 24 24 23 20 24 24 23 20 23 24 23 20 22 23 23 20 21 21 21 18

kW 3.87 3.96 4.09 4.22 4.18 4.27 4.41 4.56 4.45 4.55 4.70 4.86 4.69 4.80 4.96 5.13 4.89 5.00 5.17 5.35 5.07 5.18 5.36 5.55

Amps 13.8 14.2 14.7 15.2 15.0 15.4 15.9 16.6 16.4 16.8 17.4 18.1 17.6 18.0 18.7 19.4 20.6 21.2 21.9 22.8 21.8 22.4 23.2 24.1

HI PR 241 259 263 269 265 285 289 295 310 333 338 345 353 380 385 393 397 427 433 443 459 493 500 511

Lo PR 115 119 130 138 118 122 133 142 123 126 138 147 126 130 142 151 128 132 144 154 131 136 148 158

MBh 59.8 61.0 63.9 68.1 58.4 59.6 62.4 66.5 57.0 58.1 60.9 65.0 55.6 56.7 59.4 63.4 52.9 53.9 56.4 60.2 49.0 49.9 52.3 55.8

S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.73 1.00 1.00 0.91 0.74

25 25 24 20 26 25 24 21 24 25 23 20 23 23 22 19

∆T 25 25 23 20 25 25 24 20

kW 3.84 3.93 4.05 4.19 4.15 4.24 4.38 4.52 4.41 4.51 4.66 4.82 4.65 4.75 4.91 5.08 4.85 4.96 5.13 5.31 5.02 5.14 5.31 5.50

14.0 14.5 15.1 14.9 15.2 15.8 16.4 16.2 16.6 17.2 17.9 17.4 17.8 18.5 19.2 20.4 21.0 21.7 22.6 21.6 22.2 23.0 23.9

Amps 13.7

HI PR 239 257 260 266 262 282 286 292 307 330 335 342 349 376 381 389 393 423 429 438 454 488 495 506

Lo PR 114 118 128 137 117 121 132 141 121 125 137 145 125 128 140 149 127 131 143 152 130 134 147 156

MBh 55.2 56.3 58.9 62.9 53.9 55.0 57.6 61.4 52.6 53.7 56.2 60.0 51.4 52.4 54.8 58.5 48.8 49.7 52.1 55.6 45.2 46.1 48.2 51.5

S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.79 0.64 0.94 0.90 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.98 0.88 0.71

∆T 26 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 26 25 24 21 24 24 22 19

kW 3.81 3.89 4.02 4.15 4.11 4.20 4.34 4.49 4.38 4.47 4.62 4.78 4.61 4.71 4.87 5.04 4.81 4.92 5.08 5.26 4.98 5.09 5.27 5.45

Amps 13.5 13.9 14.4 14.9 14.7 15.1 15.6 16.2 16.1 16.5 17.1 17.7 17.2 17.7 18.3 19.0 20.2 20.8 21.5 22.3 21.4 22.0 22.7 23.6

HI PR 236 254 258 263 259 279 283 289 304 327 331 339 346 372 377 386 389 419 424 434 450 484 490 501

Lo PR 113 116 127 135 116 120 131 139 120 124 135 144 123 127 139 148 126 130 142 151 129 133 145 155

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

2250

2000

1750

2250

2000

1750

IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

SS-DSXC18 www.goodmanmfg.com 15

High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

AHRI RAtIngs AHRI RAtIngs

Outdoor

Unit

DSXC18 0361A*

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

CHPF4860D6D*+TXV A*VM960805CXB* 36,000 27,400 18.00 13.25 1,250 6497815 CHPF3642D6C*+TXV A*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 6497781 CA*F4961*6D*+TXV G*EC961004CNA* 35,000 26,600 17.50 13.00 1,150 7366145 CA*F3743*6D*+TXV G*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 5620886 CA*F4961*6D*+TXV A*VM960805CXB* 35,000 26,600 18.00 13.25 1,225 6497771 CA*F4961*6D*+TXV G*VM960604CXB* 35,000 26,600 17.50 13.30 1,225 5620870 CHPF3743D6B*+TXV G*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 5620903 CHPF3642C6C*+MBVC1600**-1A*+TXV 35,000 26,600 18.00 13.00 1,250 3654252 CA*F4961*6D*+TXV G*VM971205DNA* 34,800 26,400 17.50 13.00 1,150 7356702 CSCF3642N6D*+TXV G*VC950704CXB* 34,600 26,200 17.00 13.00 1,225 5620830 CA*F4961*6D*+TXV A*VC950915DXB* 35,000 26,600 18.00 13.50 1,225 5620855 CA*F4961*6D*+TXV G*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356568 CA*F3743*6D*+TXV G*VM960805CXB* 35,000 26,600 18.00 13.25 1,200 5620879 CHPF3743C6B*+TXV G*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 5620896 CHPF3743C6B*+TXV G*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 5620890 CSCF3642N6D*+TXV G*VC951155DXB* 34,600 26,200 17.50 13.00 1,225 5620862 CA*F3743*6D*+TXV G*VM971205DNA* 34,600 26,200 17.00 13.00 1,150 7356701 CA*F4961*6D*+TXV G*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356523 CHPF3743C6B*+TXV G*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356575 CHPF3743C6B*+TXV G*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356525 CHPF3743C6B*+TXV G*VC950704CXB* 35,000 26,600 17.50 13.00 1,275 5620827 CHPF4860D6D*+TXV G*VM961155DXB* 35,000 26,600 18.30 13.25 1,225 5620904 CA*F3743*6D*+TXV ADVC80805C*B* 35,000 26,600 17.00 13.00 1,190 5039119 CHPF3642D6C*+TXV A*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 6497779 CHPF4860D6D*+TXV G*VM971005CNA* 34,600 26,200 17.50 13.00 1,175 7356585 CHPF3743C6B*+TXV A*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5038819 CHPF3743C6B*+TXV A*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356615 DV48PTCC14A* 34,000 25,800 16.00 12.50 1,100 7079243 CAPT4961*4A* A*VM970804CNA* 34,600 26,200 17.00 13.00 1,190 7356663 CSCF3642N6D*+TXV G*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356536 CHPF3743C6B*+TXV G*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 5620883 CSCF3642N6D*+TXV A*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356656 CHPF3642C6C*+TXV G*VM960604CXB* 35,000 26,600 17.50 13.00 1,275 5620872 CA*F3743*6D*+TXV A*VM971005CNA* 34,400 26,200 17.00 13.00 1,175 7356714 CSCF4860N6D*+TXV G*VC961205DNA* 34,600 26,200 17.00 13.00 1,150 7356698 CHPF3743D6B*+TXV A*VC950905CXB* 35,000 26,600 18.00 13.25 1,250 6497799 CA*F3743*6D*+MBVC1600**-1A*+TXV 35,000 26,600 18.00 13.00 1,200 4415028 CHPF4860D6D*+TXV G*VC961005CNA* 34,600 26,200 17.50 13.00 1,175 7356545 CSCF3642N6D*+TXV A*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 6497820 CHPF3743C6B*+TXV A*VC960804CNA* 34,600 26,200 17.00 13.00 1,190 7356624 CA*F3743*6D*+TXV G*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 5620893 CHPF3642D6C*+TXV G*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 5620859 CAPT4961*4A* G*VC961005CNA* 34,600 26,200 17.00 13.00 1,175 7356543 CA*F4961*6D*+MBVC2000**-1A*+TXV 36,000 27,400 19.00 13.50 1,250 4431666 CHPF4860D6D*+TXV A*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 6497809 CHPF3743C6B*+TXV A*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 6497792 CHPF4860D6D*+TXV A*VC951155DXB* 35,000 26,600 18.30 13.25 1,225 6497813 CA*F4961*6D*+TXV A*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356608 CHPF3743D6B*+TXV G*VC950905CXB* 35,000 26,600 CA*F3743*6D*+TXV G*VM960604CXB* 35,000 26,600 17.50 13.00 1,250 5620868 CA*F3743*6D*+TXV A*VM970803BNA* 33,600 25,600 16.00 13.00 1,100 7356657 CHPF4860D6D*+TXV A*V CHPF3642D6C*+TXV G*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 5620882 CHPF4860D6D*+TXV A*VC961005CNA* 34,600 26,200 17.50 13.00 1,175 7356630 CSCF3642N6D*+TXV G*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 5620823 CAPT4961*4A* G*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356569

C950905CXB*

36,000

27,400 18.00 13.25 1,250 6497811

18.00 13.25 1,250 5620840

CFM AHRI #

See Notes on Page 25.

16 www.goodmanmfg.com SS-DSXC18

Outdoor

Unit

DSXC18 0361A*

(cont.)

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

CAPT4961*4A* A*VC961205DNA* 34,800 26,400 17.00 13.00 1,150 7356710 CA*F3743*6D*+TXV G*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497758 CA*F4961*6D*+TXV G*VC960804CNA* 34,600 26,200 17.50 13.00 1,190 7356537 CA*F4961*6D*+TXV G*VC950453BXB* 35,000 26,600 17.00 13.00 1,200 5620819 CA*F3743*6D*+TXV A*VM971205DNA* 34,600 26,200 17.00 13.00 1,150 7356715 CA*F4961*6D*+TXV A*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356653 CHPF3743D6B*+TXV A*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 6497803 CA*F4961*6D*+TXV G*VC950704CXB* 35,000 26,600 17.50 13.30 1,225 5620825 CHPF3743D6B*+TXV A*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 6497801 CA*F4961*6D*+TXV A*EC960603BNA* 35,000 26,600 17.00 13.00 1,150 7366158 CSCF3642N6D*+TXV A*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356616 CHPF4860D6D*+TXV A*VC960804CNA* 34,600 26,200 17.50 13.00 1,190 7356625 CA*F3743*6D*+TXV G*VC961005CNA* 34,400 26,200 17.00 13.00 1,175 7356693 CA*F3743*6D*+TXV G*VM971005CNA* 34,400 26,200 17.00 13.00 1,175 7356700 CA*F3743*6D*+TXV A*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5038969 CHPF3743C6B*+TXV G*VC960804CNA* 34,600 26,200 17.00 13.00 1,190 7356539 CA*F4860*6D*+MBVC2000**-1A*+TXV 36,000 27,400 19.00 13.50 1,250 6497759 CHPF3743D6B*+TXV G*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5038939 CHPF3743C6B*+TXV A*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356610 CHPF3743D6B*+TXV G*VC950905DXB* 35,000 26,600 18.00 13.25 1,250 5620847 CAPT4961*4A* G*VM971005CNA* 34,600 26,200 17.00 13.00 1,175 7356583 CAPT4961*4A* A*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356614 CHPF4860D6D*+TXV G*VC950905DXB* 36,000 27,400 18.00 13.25 1,250 5620848 CA*F3743*6D*+TXV G*VC961205DNA* 34,600 26,200 17.00 13.00 1,150 7356694 CHPF3743C6B*+TXV G*VM970804CNA* 34,600 26,200 17.00 13.00 1,190 7356579 CAPT4961*4A* A*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356654 CA*F4961*6D*+TXV G*VM960805CXB* 35,000 26,600 18.00 13.25 1,225 5620881 CA*F4961*6D*+TXV A*VC950905DXB* 35,000 26,600 18.00 13.50 1,225 6497768 CAPT4961*4A* A*VM971005CNA* 34,600 26,200 17.00 13.00 1,175 7356668 CHPF3743C6B*+TXV G*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5039229 CA*F4961*6D*+TXV G*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356528 CA*F3743*6D*+TXV G*VC950905DXB* 35,000 26,600 18.00 13.25 1,200 5620843 CSCF4860N6D*+TXV A*VM971205DNA* 34,600 26,200 17.00 13.00 1,150 7356719 CA*F3743*6D*+TXV G*VM970804CNA* 34,400 26,200 17.00 13.00 1,190 7356699 CHPF3743C6B*+TXV A*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 6497793 CSCF3642N6D*+TXV A*VC961005CNA* 34,400 26,200 17.00 13.00 1,175 7356631 CSCF3642N6D*+TXV G*VC961005CNA* 34,400 26,200 17.00 13.00 1,175 7356546 CA*F4961*6D*+TXV G*VC81005C*B* 36,000 27,400 18.00 13.70 1,210 6497775 CHPF3743C6B*+TXV A*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356620 CHPF3743D6B*+TXV G*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 5620884 CHPF3743C6B*+TXV G*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5039016 CSCF3642N6D*+TXV G*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356571 CA*F3743*6D*+MBVC2000**-1A*+TXV 35,000 26,600 18.00 13.00 1,200 4415029 CA*F3743*6D*+TXV G*EC961004CNA* 34,000 25,800 17.00 13.00 1,150 7366144 CA*F3743*6D*+TXV G*VC960403BNA* 33,600 25,600 16.00 13.00 1,075 7356522 CA*F4961*6D*+TXV G*VC950714CXB* 35,000 26,600 17.50 13.30 1,225 5620834 CSCF3642N6D*+TXV A*VC960804CNA* 34,400 26,200 17.00 13.00 1,190 7356626 CAPT4961*4A* G*EC960803BNA* 35,000 26,600 17.00 12.50 1,150 7366142 CA*F4961*6D*+TXV G*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356573 CA*F3743*6D*+TXV G*V CA*F3743*6D*+TXV A*VC960804CNA* 34,400 26,200 17.00 13.00 1,190 7356706 CHPF3743D6B*+TXV A*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 6497802 CHPF3642C6C*+TXV A*VM960604CXB* 35,000 26,600 17.50 13.00 1,275 5620871 CA*F4961*6D*+TXV G*VC950905DXB* 35,000 26,600 18.00 13.50 1,225 5620845 CA*F4961*6D*+TXV G*VC950915DXB* 35,000 26,600 18.00 13.50 1,225 5620856 CA*F3743*6D*+TXV G*VC91155DXA* 35,000 26,600 18.00 13.00 1,225 4415050

C950905CXB*

35,000

26,600 18.00 13.25 1,200 5620835

CFM AHRI #

See Notes on Page 25.

SS-DSXC18 www.goodmanmfg.com 17

AHRI RAtIngs AHRI RAtIngs

Outdoor

Unit

DSXC18 0361A*

(cont.)

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

CA*F4860*6D*+TXV G*VC950915DXB* 35,000 26,600 17.50 13.00 1,225 5620854 CSCF3642N6D*+TXV A*VC951155DXB* 34,600 26,200 17.50 13.00 1,225 6497824 CHPF3743D6B*+TXV G*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5038940 CHPF3743C6B*+TXV A*VC961005CNA* 34,600 26,200 17.00 13.00 1,175 7356629 CA*F3743*6D*+TXV A*VC950704CXB* 35,000 26,600 17.50 13.00 1,275 6497750 CAPT4961*4A* G*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356529 CHPF3743C6B*+TXV A*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5039122 CHPF3743C6B*+TXV A*VM971005CNA* 34,600 26,200 17.00 13.00 1,175 7356669 CHPF3743C6B*+TXV A*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 6497790 CA*F3743*6D*+TXV G*EC960603BNA* 34,000 25,800 16.00 13.00 1,150 7366136 CHPF3642D6C*+TXV G*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 5620889 CA*F3743*6D*+TXV G*VM970803BNA* 33,600 25,600 16.00 13.00 1,100 7356572 CHPF3743D6B*+TXV G*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 5620860 CA*F4961*6D*+TXV ADVC80805C*B* 36,000 27,400 18.00 13.70 1,190 5038968 CSCF4860N6D*+EEP+TXV 36,000 27,400 15.00 12.50 1,250 5357213 CA*F4961*6D*+TXV G*VC961205DNA* 34,800 26,400 17.50 13.00 1,150 7356695 CA*F3743*6D*+TXV A*VC960803BNA* 33,600 25,600 16.00 13.00 1,100 7356617 CHPF4860D6D*+TXV G*VC960804CNA* 34,600 26,200 17.50 13.00 1,190 7356540 CSCF3642N6D*+TXV G*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356531 CAPT4961*4A* G*VM970804CNA* 34,600 26,200 17.00 13.00 1,190 7356578 CHPF4860D6D*+TXV G*VM970804CNA* 34,600 26,200 17.50 13.00 1,190 7356580 CA*F4860*6D*+TXV G*VM960805DXB* 35,000 26,600 17.50 13.00 1,225 5620887 CHPF4860D6D*+TXV A*VM971205DNA* 34,800 26,400 17.50 13.00 1,150 7356718 CSCF4860N6D*+TXV G*VM971205DNA* 34,600 26,200 17.00 13.00 1,150 7356705 CHPF3743D6B*+TXV A*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 6497805 CHPF4860D6D*+TXV A*VC950905DXB* 36,000 27,400 18.00 13.25 1,250 6497812 CA*F4961*6D*+TXV A*VC961005CNA* 34,600 26,200 17.50 13.00 1,175 7356627 CHPF3743C6B*+TXV A*VC950905CXB* 35,000 26,600 18.00 13.25 1,250 6497787 CA*F4961*6D*+TXV G*VC950905CXB* 35,000 26,600 18.00 13.25 1,225 5620837 CA*F3743*6D*+TXV A*VM960805CXB* 35,000 26,600 18.00 13.25 1,200 6497754 CHPF3743C6B*+TXV G*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356570 CHPF3743D6B*+TXV G*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497807 CHPF4860D6D*+TXV A*VM961005DXB* 35,000 26,600 18.30 13.25 1,225 6497817 CHPF4860D6D*+TXV G*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 5620822 CA*F3743*6D*+TXV A*VC960403BNA* 33,600 25,600 16.00 13.00 1,075 7356607 CHPF3642D6C*+TXV A*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 6497780 CA*F4961*6D*+TXV A*EC961004CNA* 35,000 26,600 17.50 13.00 1,150 7366166 CSCF3642N6D*+TXV G*VM970804CNA* 34,400 26,200 17.00 13.00 1,190 7356581 CAPT4961*4A* G*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356534 CA*F3743*6D*+TXV G*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 5620857 CA*F4961*6D*+TXV G*VC80805C*B* 36,000 27,400 18.00 13.70 1,190 5038816 CSCF3642N6D*+TXV A*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356661 CA*F4860*6D*+TXV A*VC950915DXB* 35,000 26,600 17.50 13.00 1,225 5620853 CA*F4961*6D*+TXV G*VM961155DXB* 36,000 27,400 18.30 13.25 1,225 5620900 CHPF3743C6B*+TXV G*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 5620864 CA*F4961*6D*+TXV G*EC960603BNA* 35,000 26,600 17.00 13.00 1,150 7366137 CSCF3642N6D*+TXV A*VC950905CXB* 34,600 26,200 17.50 13.00 1,150 6497822 CAPT4961*4A* G*EC960603BNA* 35,000 26,600 17.00 13.00 1,150 CA*F4961*6D*+TXV A*V CHPF3743D6B*+TXV A*VC950704CXB* 34,600 26,200 17.00 13.00 1,225 6497798 CHPF4860D6D*+TXV G*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 5620866 AVPTC48D14A* 36,000 27,400 17.50 13.00 1,200 5924368 CHPF3743C6B*+TXV G*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356530 CHPF4860D6D*+MBVC2000**-1A*+TXV 35,000 26,600 18.30 13.00 1,250 3654297 CA*F4860*6D*+TXV A*VC950905DXB* 35,000 26,600 17.50 13.00 1,225 6497761 CSCF3642N6D*+TXV G*VC960804CNA* 34,400 26,200 17.00 13.00 1,190 7356541

C950704CXB*

35,000

26,600 17.50 13.30 1,225 6497766

CFM AHRI #

7366138

See Notes on Page 25.

18 www.goodmanmfg.com SS-DSXC18

Outdoor

Unit

DSXC18 0361A*

(cont.)

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

CSCF3642N6D*+TXV G*VM971005CNA* 34,400 26,200 17.00 13.00 1,175 7356586 CA*F3743*6D*+TXV G*EC960803BNA* 34,000 25,800 16.00 12.50 1,150 7366140 CSCF3642N6D*+TXV A*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356621 CA*F4961*6D*+TXV A*VC81005C*B* 36,000 27,400 18.00 13.70 1,210 6497764 CA*F3743*6D*+TXV A*EC961004CNA* 34,000 25,800 17.00 13.00 1,150 7366165 CSCF3642N6D*+TXV A*VM971005CNA* 34,400 26,200 17.00 13.00 1,175 7356671 CHPF3743C6B*+TXV G*VC950905CXB* 35,000 26,600 18.00 13.25 1,250 5620839 CHPF3743C6B*+MBVC1600**-1A*+TXV 35,000 26,600 18.00 13.00 1,250 3654262 CHPF4860D6D*+TXV A*VC81005C*B* 36,000 27,400 18.00 13.70 1,210 6497808 AVPTC48C14A* 34,000 25,800 16.00 12.50 1,100 7079242 CHPF3743D6B*+TXV A*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497796 CHPF3743C6B*+TXV A*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497784 CAPT4961*4A* A*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356659 CHPF3743D6B*+TXV G*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 5620897 CHPF3743C6B*+TXV A*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 6497794 CA*F4961*6D*+TXV A*VM960603BXB* 35,000 26,600 17.00 13.00 1,200 6497770 CHPF3642D6C*+TXV G*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 5620895 CSCF3642N6D*+TXV A*VM970804CNA* 34,400 26,200 17.00 13.00 1,190 7356666 CA*F4860*6D*+TXV G*VC950905DXB* 35,000 26,600 17.50 13.00 1,225 5620844 CA*F3743*6D*+TXV A*VM960604CXB* 35,000 26,600 17.50 13.00 1,275 5620867 CHPF3642C6C*+TXV A*VC950704CXB* 35,000 26,600 17.50 13.00 1,275 6497776 CHPF4860D6D*+TXV A*VM971005CNA* 34,600 26,200 17.50 13.00 1,175 7356670 CHPF4860D6D*+TXV A*VC80805C*B* 36,000 27,400 18.00 13.70 1,190 5038970 CHPF4860D6D*+TXV G*VM960604CXB* 35,000 26,600 17.50 13.30 1,225 5620878 CA*F4961*6D*+MBVC1600**-1A*+TXV 36,000 27,400 17.50 13.00 1,200 4431665 CHPF4860D6D*+TXV G*VM960805CXB* 36,000 27,400 18.00 13.25 1,250 5620885 CA*F3743*6D*+TXV A*EC960803BNA* 34,000 25,800 16.00 12.50 1,150 7366161 CAPT4961*4A* G*VC961205DNA* 34,800 26,400 17.00 13.00 1,150 7356696 CHPF3743C6B*+TXV G*VC961005CNA* 34,600 26,200 17.00 13.00 1,175 7356544 CHPF4860D6D*+TXV G*VC961205DNA* 34,800 26,400 17.50 13.00 1,150 7356697 CA*F3743*6D*+TXV G*VC960804CNA* 34,400 26,200 17.00 13.00 1,190 7356692 CA*F3743*6D*+TXV A*VC950905CXB* 35,000 26,600 18.00 13.25 1,200 6497751 CHPF4860D6D*+TXV G*VC80805C*B* 36,000 27,400 18.00 13.70 1,190 5039107 CA*F4961*6D*+TXV A*VM971205DNA* 34,800 26,400 17.50 13.00 1,150 7356716 CSCF3642N6D*+TXV G*VC950905DXB* 34,600 26,200 17.50 13.00 1,150 5620850 CHPF3743D6B*+TXV G*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 5620891 CA*F4961*6D*+TXV A*VC960804CNA* 34,600 26,200 17.50 13.00 1,190 7356622 CAPT4961*4A* A*EC960803BNA* 35,000 26,600 17.00 12.50 1,150 7366163 CHPF3743C6B*+TXV A*VC950905DXB* 35,000 26,600 18.00 13.25 1,250 6497788 CHPF3642C6C*+TXV G*VC950704CXB* 35,000 26,600 17.50 13.00 1,275 5620826 CHPF4860D6D*+TXV G*VC951155DXB* 35,000 26,600 18.30 13.25 1,225 5620861 CHPF4860D6D*+TXV A*VC80604B*B* 36,000 27,400 17.50 13.20 1,220 5039017 CAPT4961*4A* A*VC961005CNA* 34,600 26,200 17.00 13.00 1,175 7356628 CHPF4860D6D*+TXV G*VM971205DNA* 34,800 26,400 17.50 13.00 1,150 7356704 CA*F4961*6D*+TXV A*VC80805C*B* 36,000 27,400 18.00 13.70 1,190 5038942 CHPF3743C6B*+TXV G*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 5620902 CA*F3743*6D*+TXV G*VC950704CXB* 35,000 26,600 17.50 13.00 1,250 5620824 CA*F4860*6D*+TXV A*VM960805DXB* 35,000 26,600 17.50 13.00 1,225 6497763 CHPF3743C6B*+TXV CAP

T4961*4A* A*E CA*F3743*6D*+TXV A*EC960603BNA* 34,000 25,800 16.00 13.00 1,150 7366157 CHPF3743C6B*+TXV G*VM971005CNA* 34,600 26,200 17.00 13.00 1,175 7356584 CA*F4961*6D*+TXV G*VC961005CNA* 34,600 26,200 17.50 13.00 1,175 7356542 CHPF3743D6B*+TXV A*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5038943 CA*F3743*6D*+TXV G*VC960603BNA* 33,600 25,600 16.00 13.00 1,075 7356527 CHPF3743C6B*+TXV A*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 6497785

A*EC960803BNA* 34,000 25,800 16.50 12.50 1,150 7366164

C960603BNA*

35,000 26,600 17.00 13.00 1,150 7366159

CFM AHRI #

See Notes on Page 25.

SS-DSXC18 www.goodmanmfg.com 19

AHRI RAtIngs AHRI RAtIngs

Outdoor

Unit

CSCF3642N6D*+TXV G*VC950905CXB* 34,600 26,200 17.50 13.00 1,150 5620842 CA*F4961*6D*+TXV G*VC80604B*B* 36,000 27,400 17.50 13.20 1,220 5039228 CHPF3743C6B*+TXV G*EC960803BNA* 34,000 25,800 16.50 12.50 1,150 7366143 CA*F3743*6D*+TXV A*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5038941 CHPF4860D6D*+TXV A*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 6497814 CHPF3743C6B*+TXV G*EC960603BNA* 34,000 25,800 16.50 13.00 1,150 7366139 CHPF3743D6B*+TXV A*VM960604CXB* 34,600 26,200 17.00 13.00 1,225 5620875 CA*F4961*6D*+TXV G*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356533 CA*F4860*6D*+TXV A*VM960805CXB* 35,000 26,600 17.50 13.00 1,225 6497762 CA*F4961*6D*+TXV A*VC950714CXB* 35,000 26,600 17.50 13.30 1,225 5620833 CA*F4961*6D*+TXV G*EC960803BNA* 35,000 26,600 17.00 12.50 1,150 7366141 CA*F4860*6D*+TXV A*VC950905CXB* 35,000 26,600 17.50 13.00 1,225 6497760 CSCF3642N6D*+TXV A*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356611 CA*F4961*6D*+TXV ADVC81005C*B* 36,000 27,400 18.00 13.70 1,230 6497774 CA*F4961*6D*+TXV G*VM961005DXB* 36,000 27,400 18.30 13.25 1,225 5620894 CHPF4860D6D*+TXV A*VC950704CXB* 35,000 26,600 17.50 13.30 1,225 6497810 CHPF3743D6B*+TXV A*VM960805DXB* 35,000 26,600 18.00 13.25 1,250 6497804 CHPF3743C6B*+TXV A*VM970804CNA* 34,600 26,200 17.00 13.00 1,190 7356664 CA*F4961*6D*+TXV A*VC80604B*B* 36,000 27,400 17.50 13.20 1,220 5038818 CA*F3743*6D*+TXV A*VC961205DNA* 34,600 26,200 17.00 13.00 1,150 7356708 CHPF3743C6B*+TXV A*EC961004CNA* 34,000 25,800 17.00 12.50 1,150 7366168 CA*F4860*6D*+TXV G*VM960805CXB* 35,000 26,600 17.50 13.00 1,225 5620880 CA*F3743*6D*+TXV A*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 6497753 CSCF4860N6D*+TXV A*VC961205DNA* 34,600 26,200 17.00 13.00 1,150 7356712 CHPF3642D6C*+TXV G*VC950905CXB* 35,000 26,600 18.00 13.25 1,250 5620838 CSCF3642N6D*+TXV G*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356576 CA*F3743*6D*+TXV A*VC950714CXB* 35,000 26,600 17.50 13.00 1,275 5620831 CHPF4860D6D*+TXV A*VM961155DXB* 35,000 26,600 18.30 13.25 1,225 6497818

DSXC18 0361A*

(cont.)

See Notes on Page 25.

CHPF3743C6B*+TXV A*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356660 CA*F3743*6D*+TXV G*VC80604B*B* 35,000 26,600 17.00 13.00 1,220 5038845 CA*F3743*6D*+TXV A*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 6497755 CA*F3743*6D*+TXV A*VC960603BNA* 33,600 25,600 16.00 13.00 1,075 7356612 CHPF3743C6B*+TXV G*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 5620820 CA*F4961*6D*+TXV A*VC950905CXB* 35,000 26,600 18.00 13.25 1,225 6497767 CA*F3743*6D*+TXV G*VC950915DXB* 35,000 26,600 18.00 13.25 1,250 5620852 CA*F4961*6D*+TXV A*EC960803BNA* 35,000 26,600 17.00 12.50 1,150 7366162 CHPF3743D6B*+TXV A*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5039108 CHPF4860D6D*+TXV A*VM960604CXB* 35,000 26,600 17.50 13.30 1,225 5620877 CA*F3743*6D*+TXV A*VM970603BNA* 33,600 25,600 16.00 13.00 1,075 7356652 CAPT4961*4A* G*VC960804CNA* 34,600 26,200 17.00 13.00 1,190 7356538 CHPF4860D6D*+TXV A*VC961205DNA* 34,800 26,400 17.50 13.00 1,150 7356711 CHPF3743C6B*+TXV G*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497795 CA*F4961*6D*+TXV G*VM971005CNA* 34,600 26,200 17.50 13.00 1,175 7356582 CA*F4961*6D*+TXV A*VC950453BXB* 35,000 26,600 17.00 13.00 1,200 6497765 AVPTC42D14A* 35,000 26,600 17.00 13.00 1,280 5924367 CHPF3743C6B*+TXV A*VM960604CXB* 35,000 26,600 17.50 13.00 1,275 5620873 CA*F3743*6D*+TXV A*VM970804CNA* 34,400 26,200 17.00 13.00 1,190 7356713 CHPF4860D6D*+TXV G*VC950905CXB* 36,000 27,400 18.00 13.25 1,250 CA*F3743*6D*+TXV A*V CHPF3642D6C*+MBVC2000**-1A*+TXV 35,000 26,600 18.00 13.00 1,250 3654256 CA*F4961*6D*+TXV A*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356658 CA*F4961*6D*+EEP+TXV 36,000 27,400 15.00 12.50 1,250 5357211 CAPT4961*4A* G*VM970803BNA* 34,000 25,800 16.50 13.00 1,100 7356574 CHPF3743D6B*+MBVC2000**-1A*+TXV 35,000 26,600 18.00 13.00 1,250 3654277 CHPF4860D6D*+TXV G*VM960805DXB* 36,000 27,400 18.00 13.25 1,250 5620892 CA*F4961*6D*+TXV A*VM961155DXB* 36,000 27,400 18.30 13.25 1,225 6497773 CA*F4961*6D*+TXV A*VM970804CNA* 34,600 26,200 17.50 13.00 1,190 7356662 CHPF4860D6D*+EEP+TXV 36,000 27,400 15.00 12.50 1,250 5357212 CHPF4860D6D*+TXV G*VC80604B*B* 36,000 27,400 17.50 13.20 1,220 5038846

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

C950905D

XB*

35,000 26,600 18.00 13.25 1,250 6497752

CFM AHRI #

5620841

20 www.goodmanmfg.com SS-DSXC18

Outdoor

Unit

CA*F4961*6D*+TXV A*VM971005CNA* 34,600 26,200 17.50 13.00 1,175 7356667 CHPF3743D6B*+TXV G*VC950704CXB* 34,600 26,200 17.00 13.00 1,225 5620828 CHPF3642D6C*+TXV A*VC950905DXB* 35,000 26,600 18.00 13.25 1,250 6497778 CHPF3743D6B*+TXV A*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 6497806 CHPF4860D6D*+TXV G*VM961005DXB* 35,000 26,600 18.30 13.25 1,225 5620898 CAPT4961*4A* G*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356524 CSCF3642N6D*+TXV A*VC950704CXB* 34,600 26,200 17.00 13.00 1,225 6497821 CAPT4961*4A* G*EC961004CNA* 35,000 26,600 17.00 13.00 1,150 7366146 CA*F4961*6D*+TXV A*VM961005DXB* 36,000 27,400 18.30 13.25 1,225 6497772 CA*F4860*6D*+TXV G*VC950905CXB* 35,000 26,600 17.50 13.00 1,225 5620836 CA*F3743*6D*+TXV A*VC950915DXB* 35,000 26,600 18.00 13.25 1,250 5620851 CA*F3743*6D*+TXV A*VC961005CNA* 34,400 26,200 17.00 13.00 1,175 7356707 CA*F4961*6D*+TXV A*VC961205DNA* 34,800 26,400 17.50 13.00 1,150 7356709 CHPF3743D6B*+TXV G*VM960604CXB* 34,600 26,200 17.00 13.00 1,225 5620876 CA*F3743*6D*+TXV G*VC80805C*B* 35,000 26,600 17.00 13.00 1,190 5038938 CHPF3642D6C*+TXV A*VM961005DXB* 35,000 26,600 18.00 13.00 1,225 6497782 CHPF4860D6D*+TXV G*VC950704CXB* 35,000 26,600 17.50 13.30 1,225 5620829 CA*F4961*6D*+TXV G*VM970804CNA* 34,600 26,200 17.50 13.00 1,190 7356577 CA*F4961*6D*+TXV G*VM960805DXB* 35,000 26,600 18.00 13.50 1,225 5620888 CHPF4860D6D*+TXV A*VM960805DXB* 36,000 27,400 18.00 13.25 1,250 6497816 CHPF3743C6B*+TXV G*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356535 CHPF4860D6D*+TXV G*VC81005C*B* 36,000 27,400 18.00 13.70 1,210 6497819 CHPF3743C6B*+TXV A*VC950704CXB* 35,000 26,600 17.50 13.00 1,275 6497786 CA*F3743*6D*+TXV G*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 5620899 CA*F4961*6D*+TXV A*VC951155DXB* 36,000 27,400 18.30 13.25 1,225 6497769 CA*F3743*6D*+TXV A*VC81005C*B* 35,000 26,600 17.00 13.00 1,210 6497749 CAPT4961*4A* A*VC960804CNA* 34,600 26,200 17.00 13.00 1,190 7356623 CAPT4961*4A* A*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356619

DSXC18 0361A*

(cont.)

See Notes on Page 25.

CHPF3743C6B*+TXV G*EC961004CNA* 34,000 25,800 17.00 12.50 1,150 7366147 CAPT4961*4A* A*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356609 CAPT4961*4A* A*VM971205DNA* 34,800 26,400 17.00 13.00 1,150 7356717 CHPF3743C6B*+TXV A*VM970603BNA* 34,000 25,800 16.50 13.00 1,075 7356655 CHPF3743C6B*+TXV A*EC960603BNA* 34,000 25,800 16.50 13.00 1,150 7366160 CAPT4961*4A* A*EC961004CNA* 35,000 26,600 17.00 13.00 1,150 7366167 CHPF3743C6B*+TXV A*VM960805CXB* 35,000 26,600 18.00 13.25 1,250 6497791 CHPF3743C6B*+TXV G*VM960604CXB* 35,000 26,600 17.50 13.00 1,275 5620874 CA*F4961*6D*+TXV A*VM960604CXB* 35,000 26,600 17.50 13.30 1,225 5620869 CHPF3743D6B*+TXV A*VC950905DXB* 35,000 26,600 18.00 13.25 1,250 6497800 CHPF3743D6B*+TXV G*VC950453BXB* 34,600 26,200 17.00 13.00 1,200 5620821 CHPF3642D6C*+TXV A*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 6497783 CSCF3642N6D*+TXV A*VC950905DXB* 34,600 26,200 17.50 13.00 1,150 6497823 CHPF3743D6B*+TXV G*VM960603BXB* 34,600 26,200 17.00 13.00 1,200 5620865 CA*F3743*6D*+TXV G*VM970603BNA* 33,600 25,600 16.00 13.00 1,075 7356567 CSCF3642N6D*+TXV G*VC960403BNA* 34,000 25,800 16.50 13.00 1,075 7356526 CA*F3743*6D*+TXV A*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 6497756 CA*F4961*6D*+TXV G*VM960603BXB* 35,000 26,600 17.00 13.00 1,200 5620863 CA*F4961*6D*+TXV A*VC960603BNA* 34,000 25,800 16.50 13.00 1,075 7356613 CHPF3743D6B*+TXV A*VC950453BXB* 34,600 26,200 17.00 13.00 CA*F4961*6D*+TXV G*VC951155DXB* CA*F3743*6D*+TXV G*VC950714CXB* 35,000 26,600 17.50 13.00 1,250 5620832 CA*F3743*6D*+TXV ADVC81005C*B* 35,000 26,600 17.00 13.00 1,230 6497757 CA*F4961*6D*+TXV A*VC960803BNA* 34,000 25,800 16.50 13.00 1,100 7356618 CHPF3642D6C*+TXV A*VC950905CXB* 35,000 26,600 18.00 13.25 1,250 6497777 CA*F3743*6D*+TXV G*VC960803BNA* 33,600 25,600 16.00 13.00 1,100 7356532 CHPF3642D6C*+TXV G*VM961155DXB* 35,000 26,600 18.00 13.00 1,225 5620901 CAPT4961*4A* G*VM971205DNA* 34,800 26,400 17.00 13.00 1,150 7356703 CHPF3642D6C*+TXV G*VC950905DXB* 35,000 26,600 18.00 13.25 1,250 5620846 CHPF4860D6D*+TXV A*VM970804CNA* 34,600 26,200 17.50 13.00 1,190 7356665 CHPF3743C6B*+TXV A*VC951155DXB* 35,000 26,600 18.00 13.00 1,225 6497789 CA*F3743*6D*+EEP+TXV 35,000 26,600 15.00 12.50 1,250 5357210

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

36,000 27,400 18.30 13.25 1,225 5620858

CFM AHRI #

1,200 6497797

SS-DSXC18 www.goodmanmfg.com 21

AHRI RAtIngs AHRI RAtIngs

Outdoor

Unit

CSCF4860N6D*+TXV A*VC960804CNA* 45,000 34,200 16.50 12.80 1,525 7356635 CHPF4860D6D*+TXV A*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356674 CAPT4961*4A* A*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366170 CAPT4961*4A* A*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356681 CA*F4961*6D*+TXV A*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356632 CA*F4961*6D*+TXV A*VM961005DXB* 47,500 36,200 18.00 13.00 1,600 6497831 CA*F4961*6D*+TXV A*VC951155DXB* 47,500 36,200 18.00 13.00 1,600 6497829 CHPF4860D6D*+TXV G*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356557 CA*F4961*6D*+TXV G*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356551 CHPF4860D6D*+TXV G*VC81005C*B* 48,000 36,400 17.00 12.20 1,520 6497843 CA*F4961*6D*+TXV ADVC80805C*B* 48,000 36,400 17.00 12.80 1,580 5039231 CHPF4860D6D*+TXV G*VM960805DXB* 47,000 35,800 17.50 13.00 1,750 5620920 CAPT4961*4A* G*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366149 CA*F4961*6D*+TXV G*VC951155DXB* 47,000 35,800 18.00 13.00 1,750 5620912 CAPT4961*4A* G*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366152 CA*F4961*6D*+TXV G*VM961005DXB* 47,000 35,800 18.00 13.00 1,750 5620921 CAPT4961*4A* A*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356637 CHPF4860D6D*+TXV G*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356597 CSCF4860N6D*+TXV G*VM970804CNA* 45,000 34,200 16.50 12.80 1,525 7356590 CA*F4961*6D*+MBVC2000**-1A*+TXV 47,500 36,200 18.00 13.25 1,750 4431668 CA*F4961*6D*+TXV G*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356587 CA*F4961*6D*+TXV A*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356676 CA*F4961*6D*+TXV A*VC950905DXB* 47,000 35,800 17.50 13.00 1,750 6497828 DV48PTCC14A* 45,000 34,200 16.00 12.00 1,450 7079245 CAPT4961*4A* A*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356677 CA*F4961*6D*+TXV A*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356636 CA*F4961*6D*+TXV G*VM961155DXB* 47,000 35,800 18.00 13.00 1,750 5620923 AVPTC48C14A* 45,000 34,200 16.00 12.00 1,450 7079244

DSXC18 0481A*

See Notes on Page 25.

CHPF4860D6D*+TXV A*VC81005C*B* 48,000 36,400 17.00 12.20 1,520 6497835 CSCF4860N6D*+TXV A*VM970804CNA* 45,000 34,200 16.50 12.80 1,525 7356675 CA*F4961*6D*+TXV A*VM961155DXB* 47,500 36,200 18.00 13.00 1,600 6497832 CHPF4860D6D*+TXV A*VC80805C*B* 48,000 36,400 17.00 12.80 1,590 5038820 CA*F4961*6D*+TXV G*VM960604CXB* 46,000 35,000 17.00 13.00 1,725 5620915 CHPF4860D6D*+TXV A*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366174 CA*F4961*6D*+TXV A*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356680 CHPF4860D6D*+TXV A*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366171 CA*F4961*6D*+TXV A*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366169 CA*F4961*6D*+TXV G*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356595 CAPT4961*4A* A*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356641 CHPF4860D6D*+TXV G*VM960604CXB* 46,000 35,000 17.00 13.00 1,725 5620917 CA*F4961*6D*+TXV G*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356591 CAPT4961*4A* G*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356556 CA*F4961*6D*+TXV G*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366151 CAPT4961*4A* A*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366173 CHPF4860D6D*+TXV G*VC950905CXB* 47,000 35,800 16.50 13.00 1,750 5620907 CA*F4961*6D*+TXV G*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366148 CAPT4961*4A* A*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356633 CHPF4860D6D*+EEP+TXV 48,000 36,400 15.50 12.50 1,500 5357215 CHPF4860D6D*+TXV A*VC950905CXB* 47,000 35,800 CSCF4860N6D*+TXV G*VM971005CNA* 45,000 34,200 16.50 12.80 1,520 7356594 CHPF4860D6D*+TXV A*VM961005DXB* 47,500 CAPT4961*4A* G*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356552 CHPF4860D6D*+TXV A*VM960805CXB* 47,000 35,800 16.50 13.00 1,750 6497839 CA*F4961*6D*+TXV G*VC81005C*B* 48,000 36,400 17.00 12.20 1,520 6497834 CSCF4860N6D*+TXV A*VC961205DNA* 45,500 34,600 17.00 12.80 1,530 7356643 AVPTC48D14A* 47,000 35,800 17.50 13.00 1,700 5924369 CA*F4961*6D*+TXV A*VC81005C*B* 48,000 36,400 17.00 12.20 1,520 6497826 CHPF4860D6D*+TXV A*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356634

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

16.50 13.00 1,750 6497836

36,200 18.00 13.00 1,600 6497841

CFM AHRI #

22 www.goodmanmfg.com SS-DSXC18

Outdoor

Unit

CHPF4860D6D*+TXV G*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356549 CSCF4860N6D*+TXV G*VC961005CNA* 45,000 34,200 16.50 12.80 1,520 7356554 CAPT4961*4A* G*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356548 CA*F4961*6D*+TXV G*VC950714CXB* 46,000 35,000 17.00 13.00 1,725 5620906 CA*F4961*6D*+TXV G*VC91155DXA* 46,500 35,400 16.50 13.00 1,650 4431743 CHPF4860D6D*+TXV G*VC80805C*B* 48,000 36,400 17.00 12.80 1,590 5039018 CA*F4961*6D*+TXV A*VC950915DXB* 47,000 35,800 17.50 13.00 1,750 5620910 CA*F4961*6D*+TXV A*VM960604CXB* 46,000 35,000 17.00 13.00 1,725 5620914 CA*F4860*6D*+EEP+TXV 47,000 35,800 15.00 12.00 1,500 6497825 CA*F4961*6D*+TXV A*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356640 CA*F4961*6D*+TXV A*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356672 CA*F4961*6D*+TXV G*VC950905DXB* 47,000 35,800 17.50 13.00 1,750 5620908 CHPF4860D6D*+TXV G*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356553 CSCF4860N6D*+TXV A*VM971205DNA* 45,500 34,600 17.00 12.80 1,530 7356683 CHPF4860D6D*+TXV G*VC950905DXB* 47,000 35,800 17.50 13.00 1,750 5620909 CA*F4961*6D*+TXV G*VC950915DXB* 47,000 35,800 17.50 13.00 1,750 5620911 CA*F4961*6D*+TXV A*VC80805C*B* 48,000 36,400 17.00 12.80 1,590 5038944 CA*F4961*6D*+MBVC1600**-1A*+TXV 46,000 35,000 17.00 13.00 1,725 4431667 CSCF4860N6D*+TXV G*VC961205DNA* 45,500 34,600 17.00 12.80 1,530 7356558 CHPF4860D6D*+TXV A*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356682 CHPF4860D6D*+TXV G*EC961004CNA* 45,500 34,600 17.00 13.00 1,550 7366150 CA*F4961*6D*+TXV ADVC81005C*B* 48,000 36,400 17.00 12.20 1,550 6497833 CA*F4961*6D*+TXV G*VM960805DXB* 47,000 35,800 17.50 13.00 1,750 5620919 CA*F4961*6D*+TXV A*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366172 CA*F4961*6D*+TXV G*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356555 CHPF4860D6D*+TXV G*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356589 CHPF4860D6D*+TXV G*VC951155DXB* 47,500 36,200 18.00 13.00 1,600 5620913

DSXC18 0481A*

(cont.)

See Notes on Page 25.

CHPF4860D6D*+TXV A*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356678 CA*F4961*6D*+TXV A*VC950714CXB* 46,000 35,000 17.00 13.00 1,725 5620905 CHPF4860D6D*+TXV G*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356593 CHPF4860D6D*+MBVC1600**-1A*+TXV 46,000 35,000 17.00 13.00 1,725 3654393 CA*F4961*6D*+EEP+TXV 48,000 36,400 15.50 12.50 1,500 5357214 CHPF4860D6D*+TXV A*VC951155DXB* 47,500 36,200 18.00 13.00 1,600 6497838 CSCF4860N6D*+EEP+TXV 48,000 36,400 15.50 12.50 1,500 5357216 CHPF4860D6D*+TXV G*EC961205DNA* 45,500 34,600 17.00 13.00 1,550 7366153 CA*F4961*6D*+TXV G*VC960804CNA* 45,500 34,600 17.00 12.80 1,525 7356547 CAPT4961*4A* G*VM971005CNA* 45,500 34,600 17.00 12.80 1,520 7356592 CA*F4961*6D*+TXV G*VC80805C*B* 48,000 36,400 17.00 12.80 1,590 5039230 CSCF4860N6D*+TXV A*VM971005CNA* 45,000 34,200 16.50 12.80 1,520 7356679 CHPF4860D6D*+TXV A*VC961005CNA* 45,500 34,600 17.00 12.80 1,520 7356638 CSCF4860N6D*+TXV G*VC960804CNA* 45,000 34,200 16.50 12.80 1,525 7356550 CHPF4860D6D*+TXV G*VM960805CXB* 47,000 35,800 16.50 13.00 1,750 5620918 CSCF4860N6D*+TXV A*VC961005CNA* 45,000 34,200 16.50 12.80 1,520 7356639 CHPF4860D6D*+TXV A*VM961155DXB* 47,500 36,200 18.00 13.00 1,600 6497842 CA*F4961*6D*+TXV A*VC950905CXB* 46,000 35,000 16.50 13.00 1,650 6497827 CAPT4961*4A* A*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356673 CHPF4860D6D*+TXV A*VC961205DNA* 46,000 35,000 17.50 12.80 1,530 7356642 CHPF4860D6D*+TXV A*VM960604CXB* 46,000 35,000 17.00 13.00 1,725 5620916 CA*F4961*6D*+TXV A*VM960805DXB* 47,000 CHPF4860D6D*+TXV G*VM961005DXB* 47,500 CHPF4860D6D*+TXV A*VC950905DXB* 47,000 35,800 17.50 13.00 1,750 6497837 CHPF4860D6D*+TXV G*VM961155DXB* 47,500 36,200 18.00 13.00 1,600 5620924 CAPT4961*4A* G*VM970804CNA* 45,500 34,600 17.00 12.80 1,525 7356588 CSCF4860N6D*+TXV G*VM971205DNA* 45,500 34,600 17.00 12.80 1,530 7356598 CHPF4860D6D*+TXV A*VM960805DXB* 47,000 35,800 16.50 13.00 1,750 6497840 CHPF4860D6D*+MBVC2000**-1A*+TXV 47,500 36,200 18.00 13.25 1,750 3654394 CAPT4961*4A* G*VM971205DNA* 46,000 35,000 17.50 12.80 1,530 7356596

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

35,800 17.50 13.00 1,750 6497830 36,200 18.00 13.00 1,600 5620922

CFM AHRI #

SS-DSXC18 www.goodmanmfg.com 23

AHRI RAtIngs AHRI RAtIngs

Outdoor

Unit

DSXC18 0601A*

Indoor Units Cooling Ratings

Coils/Air Handlers Furnaces Total¹ Sens.¹ SEER² EER³

CA*F4961*6D*+TXV A*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356644

CAPT4961*4A* A*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356685

CHPF4860D6D*+MBVC2000**-1A*+TXV 58,000 42,000 17.00 12.00 2,000 3654439

CA*F4961*6D*+TXV G*VC950905DXB* 58,000 42,000 16.00 11.50 1,750 5620927

CHPF4860D6D*+TXV A*VM961005DXB* 58,000 42,000 16.00 11.75 1,750 6497857

CA*F4961*6D*+TXV G*VM961155DXB* 58,000 42,000 16.00 11.50 1,900 5620939

CA*F4961*6D*+TXV G*VC961205DNA* 56,000 40,500 16.00 11.80 1,600 7356563

CHPF4860D6D*+TXV G*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356561

CA*F4961*6D*+TXV G*VC80805C*B* 56,000 40,500 16.00 11.20 1,890 6484852

CAPT4961*4A* A*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356689

CA*F4961*6D*+TXV G*VC951155DXB* 58,000 42,000 16.00 11.50 1,900 5620931

CSCF4860N6D*+TXV A*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356647

CA*F4961*6D*+MBVC2000**-1A*+TXV 58,000 42,000 17.00 12.00 2,000 4431669

CHPF4860D6D*+TXV G*VM961155DXB* 58,000 42,000 16.00 11.75 1,750 5620940

CAPT4961*4A* G*VC961205DNA* 56,000 40,500 16.00 11.80 1,600 7356564

CA*F4961*6D*+TXV G*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356559

CHPF4860D6D*+TXV G*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356605

CHPF4860D6D*+TXV G*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356601

CHPF4860D6D*+TXV G*VM960805CXB* 58,000 42,000 16.00 11.50 1,900 5620934

CA*F4961*6D*+TXV A*VM960805CXB* 58,000 42,000 16.00 11.50 1,750 6497847

CHPF4860D6D*+TXV A*VM961155DXB* 58,000 42,000 16.00 11.75 1,750 6497858

CHPF4860D6D*+TXV G*VC950905CXB* 58,000 42,000 16.00 11.50 1,900 5620926

CAPT4961*4A* A*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356645

CHPF4860D6D*+TXV A*VC80805C*B* 56,000 40,500 16.00 11.20 1,890 6484854

CHPF4860D6D*+TXV A*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356646

CA*F4961*6D*+EEP+TXV 57,000 41,000 15.00 12.00 1,500 5357217

CA*F4961*6D*+TXV G*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356603

CAPT4961*4A* A*VC961205DNA* 56,000 40,500 16.00 11.80 1,600 7356649

CA*F4961*6D*+TXV G*VM960805DXB* 58,000 42,000 16.00 11.50 1,750 5620935

CHPF4860D6D*+TXV G*VM961005DXB* 58,000 42,000 16.00 11.75 1,750 5620938

CA*F4961*6D*+TXV A*VM961005DXB* 58,000 42,000 16.00 11.50 1,900 6497848

CA*F4961*6D*+TXV G*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356599

AVPTC60D14A* 58,000 42,000 16.00 11.75 1,780 5924370

CHPF4860D6D*+TXV A*VC950905DXB* 58,000 42,000 16.00 11.50 1,900 6497853

CA*F4961*6D*+TXV A*VM961155DXB* 58,000 42,000 16.00 11.50 1,900 6497849

CHPF4860D6D*+TXV A*VC951155DXB* 58,000 42,000 16.00 11.75 1,750 6497854

CAPT4961*4A* G*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356600

CA*F4961*6D*+TXV A*VC81005C*B* 56,000 40,500 16.00 11.20 1,800 6484851

CAPT4961*4A* G*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366155

CSCF4860N6D*+TXV G*VM971205DNA* 55,500 40,000 15.50 11.80 1,600 7356606

CHPF4860D6D*+TXV A*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356690

CHPF4860D6D*+TXV G*VC961205DNA* 56,000 40,500 16.00 11.80 1,600 7356565

CHPF4860D6D*+TXV G*VC950905DXB* 58,000 42,000 16.00 11.50 1,900 5620928

CSCF4860N6D*+TXV G*VC961205DNA* 55,500 40,000 15.50 11.80 1,600 7356566

CHPF4860D6D*+TXV G*VC951155DXB* 58,000 42,000 16.00 11.75 1,750 5620932

CA*F4961*6D*+TXV A*VC951155DXB* 58,000 42,000 16.00 11.50 1,900 6497846

CA*F4961*6D*+TXV A*VC950905CXB* 58,000 42,000 16.00 11.50 1,750 6497844

CHPF4860D6D*+TXV A*VM960805DXB* 58,000 42,000 16.00 11.50 1,900 6497856

CA*F4961*6D*+TXV A*VC961205DNA* 56,000 40,500

CHPF4860D6D*+TXV A*VC950905CXB* 58,000

CA*F4961*6D*+TXV ADVC81005C*B* 56,000 40,500 16.00 11.20 1,820 6497851

CSCF4860N6D*+TXV A*VM971205DNA* 55,500 40,000 15.50 11.80 1,600 7356691

42,000 16.00 11.50 1,900 6497852

16.00 11.80 1,600 7356648

CFM AHRI #

See Notes on Page 25.

24 www.goodmanmfg.com SS-DSXC18





CHPF4860D6D*+TXV A*VC961205DNA* 56,000 40,500 16.00 11.80 1,600 7356650

CA*F4961*6D*+TXV A*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356684

CHPF4860D6D*+TXV A*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366177

CAPT4961*4A* A*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366176

CA*F4961*6D*+TXV A*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356688

CHPF4860D6D*+TXV G*VC80805C*B* 56,000 40,500 16.00 11.20 1,890 6484856

CHPF4860D6D*+TXV A*VM960805CXB* 58,000 42,000 16.00 11.50 1,900 6497855

CA*F4961*6D*+TXV G*VC950915DXB* 58,000 42,000 16.00 11.50 1,750 5620930

CA*F4961*6D*+TXV A*VC950915DXB* 58,000 42,000 16.00 11.50 1,750 5620929

CSCF4860N6D*+TXV G*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356602

CA*F4961*6D*+TXV A*VC80805C*B* 56,000 40,500 16.00 11.20 1,890 6484850

CA*F4961*6D*+TXV G*VC950905CXB* 58,000 42,000 16.00 11.50 1,750 5620925

CSCF4860N6D*+EEP+TXV 57,000 41,000 15.00 12.00 1,500 5357219

CA*F4961*6D*+TXV G*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366154

DSXC18 0601A*

(cont.)

¹ BTU/h

² Seasonal Energy Eciency Rao; Cered per AHRI 210/240 @ 80°F/ 67°F/ 95°F ³ Energy Eciency Rao @ 80°F/ 67°F/ 95°F



• Always check the S&R plate for electrical data on the unit being installed.

• When matching the outdoor unit to the indoor unit, use the piston supplied with the out-

door unit or that specied on the piston kit chart supplied with the indoor unit.

• EEP - Order from Service Dept. Part No. B13707-38 or new Solid State Board B13707-35S. Part No. B13707-38 is not in-

terchangeable with B13707-35S. The Goodman Gas Furnace contains the EEP cooling me delay

CAPT4961*4A* G*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356560

CSCF4860N6D*+TXV A*VC961205DNA* 55,500 40,000 15.50 11.80 1,600 7356651

CA*F4961*6D*+TXV A*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366175

CA*F4961*6D*+TXV G*VM960805CXB* 58,000 42,000 16.00 11.50 1,750 5620933

CHPF4860D6D*+TXV A*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356686

CA*F4961*6D*+TXV A*VC950905DXB* 58,000 42,000 16.00 11.50 1,750 6497845

CA*F4961*6D*+TXV G*VM961005DXB* 58,000 42,000 16.00 11.50 1,900 5620937

CAPT4961*4A* G*VM971205DNA* 56,000 40,500 16.00 11.80 1,600 7356604

CA*F4961*6D*+TXV ADVC80805C*B* 56,000 40,500 16.00 11.20 1,940 6497850

CHPF4860D6D*+TXV A*VC81005C*B* 56,000 40,500 16.00 11.20 1,800 6484855

CHPF4860D6D*+TXV G*VM960805DXB* 58,000 42,000 16.00 11.50 1,900 5620936

CSCF4860N6D*+TXV A*VM971005CNA* 56,000 40,500 15.50 11.80 1,750 7356687

CHPF4860D6D*+TXV G*EC961205DNA* 56,000 40,500 16.00 11.50 1,550 7366156

CA*F4961*6D*+TXV G*VC81005C*B* 56,000 40,500 16.00 11.20 1,800 6484853

CHPF4860D6D*+EEP+TXV 57,000 41,000 15.00 12.00 1,500 5357218

CHPF4860D6D*+TXV G*VC81005C*B* 56,000 40,500 16.00 11.20 1,800 6484857

CSCF4860N6D*+TXV G*VC961005CNA* 56,000 40,500 15.50 11.80 1,750 7356562

    SEER² EER³

 

 

SS-DSXC18 www.goodmanmfg.com 25

Product SPecificationS Product SPecificationS

DimenSionS

  D H

DSXC180361A* 35½ 35½ 38¼

DSXC180481A* 35½ 35½ 38¼

DSXC180601A* 35½ 35½ 38¼

26 www.goodmanmfg.com SS-DSXC18

wiring DiAgrAm

WIRING COD

FACTORY WIRING

HIGH VOLTAGE

LOW VOLTAGE

HIGH VOLTAGE

FIELD

COLOR

CODE

BK --------------- BLACK

BL --------------- BLUE

BL/PK ---------- BLUE/PINK STRIPE

BR --------------- BROWN

OR --------------- ORANGE

PU --------------- PURPLE

RD --------------- RED

WH -------------- WHITE

YL --------------- YELLOW

YL/PK ---------- YELLOW/PINK STRIPE

E11

E16

COM

FAN

HERM

GR/YL

RELAY

HERM

COM

START

RUN

230 VAC

SUPPLY

E13

L2 OUT

E10

START

CAP COM

CCH

E21

E17

START

RLY

UC BOARD

LPS

HPS

FUSE

FAN

RUN

RELAY

E25

E29

E28

E26

E24

E23

E22

E14

HIGH

LPCO

HPCO

E47 E1

OAT

OCT

OAS

GND

LOW VOLTAGE

BARRIER

BL/PK

YL/PK

BL/PK

RCCF

AUX

MAIN

COMP

CONTROL BOX

L (OPTIONAL)

Y2Y1W1

LEGACY INDOOR T-STAT

CR2

INDOOR POWER SUPPLY 24 VAC

COMMUNICATING INDOOR T-STAT

INDOOR POWER SUPPLY 24 VAC

TO INDOOR COMMUNICATING PCB

0140R00142-D

THIS WIRING SCHEMATIC SHOWS THE LEGACY WIRING FROM

THE FACTORY. THE WIRES GO TO INDOOR T-STAT AS SHOWN

IN "LEGACY INDOOR T-STAT". TO WIRE THE SYSTEM IN

COMMUNICATING MODE, THE INSTALLER HAS TO WORK

THE WIRING AS SHOWN IN "COMMUNICATING INDOOR T-STAT".

REFER TO THE IO MANUAL LOCATED IN COMMUNICATING

T-STAT KIT FOR MORE DETAILS.

FROM

OUTDOOR

UNIT

FROM

OUTDOOR

UNIT

GND

RES

SR SC

OPTIONAL HARD START

2L 1L

COMP

HERM

CCH

UC CONTROL

HERM

CAP COM

LPC

HPC

E14

TO uP

OPTIONAL HARD

START

RUN

CAPACITOR

1 2

2Y 1Y C

FAN

ECM FAN

MOTOR

HIGH/LOW ON/OFF

24V

CAPACITY

SOLENOID

VALVE

COMPONENT CODE

C --------------- CONTACTOR

CH ------------- CRANKCASE HEATER

CM ------------ CONDENSER FAN MOTOR

COMP -------- COMPRESSOR

CS ------------- COMPRESSOR SOLENOID

DT ------------- DISCHARGE THERMOSTAT

HPS ----------- HIGH PRESSURE SWITCH

IO -------------- INTERNAL OVERLOAD

LPS ---------- LOW PRESSURE SWITCH

OAS ----------- OUTDOOR AIR SENSOR

RCCF --------- RUN CAPACITOR FOR COMPRESSOR & FAN

SC ------------- START CAPACITOR FOR COMPRESSOR (OPTIONAL)

SR ------------- START RELAY FOR COMP

RESSO

R (OPTIONAL)

CONTROLS SHOWN WITH THERMOSTAT IN 'OFF' POSITION.

YLPUBL

SEE NOTE 1

NOTES:

1. IF DT IS NOT PRESENT, HPS BL/PK WIRE

GOES DIRECTLY TO TERMINAL E29.

2. USE COPPER SUPPLY WIRES ONLY.

3. USE 40VA TRANSFORMER MINIMUM.

⚡

  Disconnect all power before servicing or installing this unit. Mulple power

sources may be present. Failure to do so may cause property damage, personal injury, or death.

SS-DSXC18 www.goodmanmfg.com 27

⚠ Warning

Wiring is subject to change. Always

refer to the wiring diagram or the

unit for the most up-to-date wiring.

Product SPecificationS Product SPecificationS

ACCeSSorieS

 

ABK-20 Anchor Bracket Kit

DSXC18

036**

◊

X X X

DSXC18

048**

DSXC18

ASC-01 An-Short Cycle Kit X X X

B1141643¹ 24V Transformer X X X

CSR-U-1 Hard-start Kit X X

CSR-U-2 Hard-start Kit

CSR-U-3 Hard-start Kit X

FSK01A

Freeze Protecon Kit X X X

LSK02A Liquid Line Solenoid Valve X X X

OT18-60A

TX3N4

Outdoor Thermostat/Lockout Thermostat X X X

TXV Kit X

TX5N4 TXV Kit X X

◊

Contains 20 brackets; four brackets needed to anchor unit to pad ¹ This component is included in the CTK01AA communicang thermostat kit. ² Installed on indoor coil ³ Available in 24V legacy mode only. This feature is integrated in the communicang mode. ⁴ Condensing units and heat pumps with reciprocang compressors require the use of start-assist components when

used in conjuncon with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device or liquid line solenoid kit. The TXV should always be sized based on the tonnage of the outdoor unit.

060**

Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specications or designs without

28 www.goodmanmfg.com SS-DSXC18

Goodman DSXC180601 Specifications Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual

nomenClAtUre

DimenSionS

wiring DiAgrAm

ACCeSSorieS
