Goodkit VX User Manual

ALL-IN-ONE PORTABLE & RECHARGEABLE SOLAR POWER PACK

USER MANUAL

Model: VX16

Please read these instructions carefully

and keep for future reference

CONTENT

2

IMPORTANT SAFETY INSTRUCTION…………………………………………………………………..........….3

INTRODUCTION……………………………………..………………………………………………………………4

WHAT’S IN THE BOX? ...……………………….....……………………………………………………………….4

PRODUCT DIAGRAM …………..………………..…………………………………………………………………5
CHARGING / DISCHARGING INTERFACE .…..…………………………………………………………………5
FEATURES ……………………………..…………………………………………………………………..………..6
SPECIFICATION ……………………………..………………………………………………………….…………..6
OPERATION INSTRUCTION ……………………………..……………………………………………..…………7
CHARGING YOUR VX16 ……………………………..………………………………………...……………8
POWERING / CHARGING YOUR DEVICES ……………………………..………………………………….….9
LED LIGHT …………………………………..……………………………………………………………………...10
MAINTENANCE AND CARE ……………………………..……………………………………………………….10
CAUTIONS ……………………………..……………………………………………………………………….…..10
WARRANTY INFORMATION ……………………………..………………………………………………………11

IMPORTANT SAFETY INSTRUCTION

3

RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER.

To reduce the risk of electric shock, do not remove the cover. No user serviceable parts inside this unit. Refer servicing
to a qualified technician.

The lightning flash with the arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of un-insulated 'dangerous voltage' within the products in-closure, that may be
of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle, is intended to alert the user to the presence of
important operating and maintenance (servicing) instruction in the literature accompanying the
appliance.

CAUTION

: always read and observe all warnings and instructions given in the instruction manual and those marked on
the unit.
Read these instructions carefully and keep them in a safe place.
Do not use this appliance near water.
Clean only with a soft dry cloth.
Only use attachments/accessories specified by the manufacturer.
Unplug this unit during lightning storms or when not in use.
Refer all servicing to a qualified service personnel. Servicing is required when the appliance is damaged in anyway.
No object filled with liquids such as vases shall be placed on the appliance.
Do not place naked flame sources such as candles on the appliance.
Make sure all electrical connections are properly made in accordance with the manufacturer’s instructions. Switch off
and unplug from the mains before changing any connections.
Make sure the mains cord is routed so that it is not likely to be walked on, or subjected to water and heat. Should the
power cord need replacing, it must be replaced with a cord of the same type by a qualified technician.
Do not obstruct the vents with such things as newspapers, table cloths, curtains and so on.
Do not operate the appliance if you are in doubt about it working normally, or if it is damaged in any way. Make sure
there is adequate ventilation space around the appliance, at least 10 cm at the sides and on the top.
Always unplug from the mains when not in use.
The mains plug should not be obstructed and remain readily accessible during intended use.
The rating markings are located on the base of the unit.
Do not place this equipment in a confined space such as a book case or similar, it must remain in well ventilated
conditions. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper,
table-clothes curtains etc.
WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information before
installing or operating the apparatus.
WARNING: While charging/discharging with power cords, do not expose this apparatus to rain or moisture. The apparatus
shall not be exposed to dripping or splashing or objects filled with liquids, such as vases shall not be placed on the
apparatus.
WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as direct
sunshine, fire or the like.
WARNING: The mains switch is used as the disconnect device, so the disconnect device shall remain readily operable.

4

INTRODUCTION

Congratulations on the purchase of your VX16, the All-In-One Portable & Rechargeable Solar Power Pack. The
VX16 combines leading-edge technology in mono-crystalline photovoltaic and electronics into one portable device to
provide you with the best that technology has to offer for your portable charging needs.

- Please read the User’s Guide prior to using your VX16.

- Failure to follow the instructions can result in irreparable damage to the device.

- Please keep this User’s Guide for future reference.

WHAT’S IN THE BOX?

a – Good Kit VX16 – Solar Power Pack
b - AC 220V charging cable
c - DC 12V charging cable
