0.5MHz 68MHz
125MHz 862MHz
TV
120MHz
88MHz
RADIO
2400MHz950MHz
SAT
- female con. for SAT, IEC connector male for
TV and FEMALE for RADIO
- RFI shielded zinc die-casting housing
- Screening efficiency acc. EN 50083-2 Class A
- Power passing 24V DC, 0.5A, IN <> SAT
Frequencyrange (MHz) Strength (dB)
Insertion loss (IN-OUT) 5-40 3.2
40-1000 4.0
1000-2150
2150-2400
Insertion loss (IN-RADIO) 0.15-26 -
88-108 12.5
111-120
120-139
Insertion loss (IN-TV)
Return loss (IN-SAT)
5-30
47-68
120-139
139-150
150-862
950-1750
1750-2150
2150-2400
IN/OUT/TV/RADIO/SAT
5.5
6.0
13.5
-
12.5
16.0
14.0
12.5
8.0
- 3-Loch Antennen-Dose (SAT/TV/Radio)
- Durchgangsdose
BK-, SAT und
Rundfunkanlagen
- ohne DC-Durchgang
28.01.2014 tf
28.01.2014 tf
Änderungen vorbehalten / Subject to change
SAT AD 03-10
67047
- 3 hole Antenna Wall Socket (SAT/TV/Radio)
- through wall socket
for BK, SAT and Radio systems
- without DC pass through
