TABLE OF CONTENTS

1. INTRODUCTION Page 3

2. INSTALLATION INSTRUCTIONS Page 4 & 5

3. COMMISSIONING Page 6

4. CLEANING/MAINTENANCE OF CHINESE WOK Page 7

5. CONVERSIONS INSTRUCTIONS Page 8

6. HOURLY GAS CONSUMPTION Page 9

7. OVERALL DIMENSIONS & WEIGHTS Page 9

8. PROBLEM SOLVING Page 10

9. FLOW CONTROL TAP ASSEMBLY Page 11

10. DRAWINGS - SPARE PARTS Page 12-13 -14-15

11. WARRANTY Page 16

12. BRANCHES Page 17

2

Air Cooled Wok-All Models May 2011

1. INTRODUCTION

Congratulations for purchasing your Goldstein commercial cooking
appliance.
J. Goldstein & Co. is a wholly owned Australian company and has been
operating since 1911, building high quality products. The information in this
manual will assist your installer and ensure correct location and connection.
Thoroughly read the user instructions and the user maintenance sections, as
understanding your products, its operation, and its cleaning and service
requirements will provide you with long and satisfactory service. Failure to do
so could shorten the life of the product and decrease its efficiency. Please
ensure only authorised service technicians are called to any difficulties that
may arise.

INTRODUCTION

GOLDSTEIN CHINESE WOK GAS RANGE ALL MODELS

GOLDSTEIN WOKS are designed to give long and satisfactory service and

incorporate the best possible materials and workmanship. Proper
installation, adjustment and preventative maintenance are vitally important if
efficiency and appearance are to be maintained.

Read these instructions carefully as they contain important safety
information regarding the installation, use and maintenance of the appliance.

RECEIVING INSPECTION

•

Check crates for handling damage. After carefully uncrating, check for
“concealed” damage. Report any damage immediately to carrier and to dealer.

•

Remove check all loose items from unit and check contents as found on back of
warranty cards.

•

Check type and capacity of gas supply.

•

The type of gas for which this Wok Series is factory adjusted can be seen on
the rating plate, e.g. Approval No. Serial No, mj/M, Model, Test pressure point,
kPa and injector sizes located on the bottom front panel of the Wok.

“THE EQUIPMENT MUST BE INSTALLED BY A

LICENSED GASFITTER

NOTICE
PLEASE RETURN YOUR WARRANTY CARD
FAILURE TO DO SO MAY VOID WARRANTY

ON THE EQUIPMENT

Air Cooled Wok-All Models May 2011

3

2. INSTALLATION INSTRUCTIONS

PRE-INSTALLATION OF THE WOK

•

Check that there is sufficient clearance between doors and passageways to
move equipment into the cooking area.

•

Lift off wooden base.

•

Lay the Wok back on its back.

•

Place a piece of timber under the body of the Wok not on the Upstand to allow
clearance for your hand.

•

Attach the legs using bolts and washers provided and tighten them.

•

Then lift the Wok off its back being sure to lift on the body by placing hands
under space provided by timber.

•

Single hole Woks mount directly on the stand provided.

•

Peel off all protective film and remove any glue or oil with a suitable solvent.

INSTALLATION (FOR AUTHORISED GASFITTERS ONLY)

These installations MUST comply with the requirements of AS5601/AG601 local
authority gas, electricity and any other statutory regulations.
LPG connection MUST be supplied and connected with regulator as per standard
AS4563/AG300. With every wok that has the two burner option there will be two
regulators supplied, and with CWA-3B2 a standard Bromic 980L for the B2 and a
Jeavons J78R for the 3 burners, due to exceeding 250Mj.

Note: AFTER ANY MAINTENANCE OR ADJUSTING OF GAS CONNECTED
COMPONENTS, A GAS LEAK TEST MUST BE CARRIED OUT, TO ENSURE
THERE ARE NO GAS LEAKING HAZARDS

• Adequate ventilation must be provided by a hood with vent and exhaust fan.

• Check the rating plate to ensure appliance is suitable for the gas supply to

which it will be connected and for information relative to gas input pressure
and consumption.

Please follow instructions carefully:

1. Set the unit in correct position (ENSURE THERE IS A MIN 200MM REAR

WALL CLEARANCE and 225mm SIDE ALL CLEARANCE FROM
COMBUSTIBLE MATERIALS AND THAT THE UNIT IS PLACED ON A
FIRE PROOF BASE) and adjust feet using a spirit levelling side to side and

front to rear. If more than one piece of equipment is in the line up, these
adjustments will have to be made relative to each other.

2 Have a licensed gas fitter or your local gas company connect the appliance

to the gas supply. The gas inlet connection can be seen on Page 9. The
appliance must be installed in accordance with rules of any authority having
jurisdiction. The regulator supplied must be installed on the gas inlet to the
appliance.

The pressure regulator (NG) and LPG standards (AS4563/AG300 1.1.05)
are supplied as a loose item and a hand stop tap must be supplied as
close to the appliance as possible.

4

Air Cooled Wok-All Models May 2011

2. INSTALLATION INSTRUCTIONS

3. DRAIN CONNECTION
The drain must be connected in conformity with requirements of local

authority. The diameter of the drain pipe must always be greater than the
drain outlet from the appliance. Drain connection is 51 mm BSP.

4. All gas equipment MUST have an exhaust hood as per AS5601/AG601.

5. WATER CONNECTION
The unit is fitted with a flow controlled timer tap to control the flow of water to
the swivel arm at the rear. The appliance must be connected to a cold water
supply with pressure between 2 and 5 bar (300 kPa to 750 kPa).

5

Air Cooled Wok-All Models May 2011

3. COMMISSIONING INSTRUCTIONS

COMMISSIONING (FOR AUTHORISED TECHNICIANS ONLY)

Note: All the appliances that leave our factory have been tested and adjusted
according to the specifications for the required gas. The regulator may have
to be adjusted to achieve the required gas pressure.

Note: Before igniting the wok ensure that all the protective plastic on unit has
been removed.

Each wok burner is fitted with an adjustable pilot (black knob) and a control for the
wok burner. The pilots should be ignited with a hand sparking unit.

After installation of the appliance the installer should light all burners to ensure that
they are operating correctly. The burner flames should not have yellow tips nor
should they be too “hard”.

All appliances are tested and preset before leaving our factory, but small
adjustments may be necessary to suit local conditions.

Ensure that the pressure at the pressure test point on the manifold is as per the
rating plate.. If the two values are not the same, use a screwdriver to adjust the
pressure regulator (turning screw clockwise will increase the pressure).

Flame Failure

Turn the control knob to low and check that the flame size has decreased
substantially. If flame has not decreased, then using a small flat headed
screwdriver adjust the ‘min gas screw’ on the front of the gas control until the min
flame gets to desired size (turning screw clockwise will decrease the flame size).

If the appliance fails to operate correctly, check the following:

1. Data plate for correct gas type and pressure and adjust if necessary.

2. Correct aeration by adjusting the interrupter screws on the side of the burner
head (twin ring burner only). The flame should have a purple inner cone and
a blue out cone.

3. Injector size – check against data plate.

4. Check pilot flame size and adjust if necessary.

CAUTION WARNING

If flame or pilot goes out wait (5) minutes before relighting (reigniting).

6

Air Cooled Wok-All Models May 2011

4. CLEANING/MAINTENANCE OF CHINESE WOK

DO NOT USE STEEL WOOL, ABRASIVE CLOTHS, CLEANSERS OR
POWDERS!

If it is necessary to scrape stainless steel to remove encrusted materials, soak
the area with hot cloths to loosen the material, and then use a wood or nylon
scraper.

DO NOT USE a metal knife, spatula, or any other metal tool to scrape stainless
Steel. Scratches are almost impossible to remove

CLEANING

For continued reliable operation of your Wok, regular cleaning is most essential.
Spillages of food products or liquids on the Wok will occur and these must not be
allowed to “burn on” (these spillages should be immediately cleaned up).

For the cleaning of the stainless steel or vitreous enamel surfaces, use hot soapy
water and a soft cloth. Never use an abrasive cloth.

A CLEANER THAT IS COMPATIBLE WITH ALUMINIUM MUST BE USED
ON THE EQUIPMENT OTHERWISE THE GAS PIPING WITHIN THE UNIT
WILL BE DAMAGED AND THIS WILL AUTOMATICALLY VOID THE
WARRANTY.

SERVICE

An authorised person must handle any service problems that arise. If Authorised
Gasfitter cannot commission or adjust appliance they can contact the state branch
on Page 16. The operator should carry out only regular cleaning.

WARNING

NO FLAMMABLE MATERIALS OR FLUIDS SHOULD BE KEPT NEAR OR
ON APPLIANCE.

DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE
WHILE IT IS IN OPERATION.

NOTE

WASH HOSES SHOULD NEVER BE USED ON THE APPLIANCE.

USE OF HOSES WILL VOID WARRANTY

7

Air Cooled Wok-All Models May 2011

5. CONVERSION INSTRUCTIONS

To convert from N.G. to L.P. Propane gas do the following:

1. Replace N.G. burner injectors with L.P.G. injectors (refer to table on this
page).

2. Adjust needle valve to achieve desired pilot flame size.

3. Disconnect regulator from gas supply line, disconnect natural gas regulator
from gas line reconnect LPG regulator on line..

4. Reset pressure test point on manifold.

5. Adjust burner aeration (if applicable).

Relevant required gas pressure for use in conversion

Natural 1.0 kPa W.G.
L.P. 2.5 kPa W.G.

AN AUTHORISED GAS FITTER MUST CARRY OUT GAS CONVERSION.

8

Air Cooled Wok-All Models May 2011

6. NOMINAL HOURLY GAS CONSUMPTION AND INJECTOR SIZES

NG LPG BURNER

Mj/hr Mm Mj/hr mm
Twin ring 54 1.80/2.85 47 1.05/1.75
Mongolian 90 1.10, 16 off 75 0.68, 16 off
Duck Bill 120 1.20, 18 off 105 0.7, 18 of
Side burner 26 2.35, 1 off 25 1.4 1 off

7. OVERALL DIMENSIONS & WEIGHTS

BURNER Height (mm) Width (mm) Depth (mm) Weight (kg)
CWA1 1280 650 850 55
CWA1B2 1280 960 850 90
CWA2 1280 1200 850 100
CWA2B2 1280 1510 850 135
CWA3 1280 1875 850 145
CWA3B2 1280 2180 850 180

9

Air Cooled Wok-All Models May 2011

8. PROBLEM SOLVING

TROUBLE SHOOTING

These troubleshooting procedures must be carried out only by a Goldstein
Authorised Maintenance & Repair Centre or Company specialising in restaurant
cooking appliances. The problems and possible solutions given below cover those
most commonly encountered.

FACTORY APPROVAL MUST BEOBTAINED PRIOR TO ANY WARRANTY
WORK BEING DONE OR GOLDSTEIN CANNOT BE HELD RESPONSIBLE.

1. Low Flame on Burner

a) Check gas supply pressure on TPP or Manifold – adjust if needed.
b) Check air vent on regulator – Clean or replace.
c) Look at ports on burner may be blocked – clean or drill out.
d) Burner may be blocked inside – pull out and clean.

e) Check injector size (Rating plate).

2. Flame too high

a) Check gas pressure on TPP on Manifold – (behind S/S front). should

be 1.0 kPa NG 2.5 kPa LPG.
b) Only part of burner works – Clean ports or injectors
c) Check size of injector on Rating Plate.

3. Water not draining from trough

a) Make sure drain not blocked at back of Wok. Clean
b) Check main drain.

4. Pilot keeps going out

a) Check Pilot may need to be cleaned or replaced.
b) Check thermocouple loose – Tighten
c) Replace thermocouple if necessary.

5. Gas Tap hard to turn

a) Turn off gas pull tap apart – clean re-grease – reassemble test for

leaks
b) Replace if it cannot be fixed.

10

Air Cooled Wok-All Models May 2011

9. FLOW CONTROL TAP ASSEMBLY

Fig. 1

Fig. 3

Fig. 2

Flow control tap assembly

1. You will receive the unit with the plastic nozzle removed. (Fig. 1)

2. The nozzle consists of 4 parts.

3. Place all parts inside the nozzle but for the washer which goes over the threaded area in fig.1

4. Screw in nozzle with internal parts and assembly is complete. (fig. 3)

11

Air Cooled Wok-All Models May 2011

10. DRAWING - SPARE PARTS

MODEL: CWA, CWA2, CWA3, CWA-B2, CWA-282, CWA-3B2

25

24

1

2

3

4

5

11

6

26

9

8

23

10

14

13

12

20

15

16

17

18

19

7

21

22

12

Air Cooled Wok-All Models May 2011

10. DRAWING - SPARE PARTS

MODEL: CWA, CWA2, CWA3

ITEM No. CODE DESCRIPTION

1. MTAC0019 BALL VALVE ¾” LONG ARM

2. MKNPLCW1 KNOB TO SUIT FLAME FAILURE

3. GIJGPCWA INJECTOR

4. GCU00010 MONGOLIAN – GAS COCK

5. GTC10600 THERMOCOUPLE – 600mm

6. MTAW0002 TIMER VALVE

7. WW-00P05 DRIP TRAY

8. GBNCWJ01 WOK BURNER (NG)

9. WW-00P04 PILOT BRACKET FOR JET BURNER

10. GPICWA01 PILOT (NG)

11. WW-00A02 TOP RING

12. WW-00P11 STRAINER

13. WW-00P21 SUPPORT BRACKET FOR DRIP TRAY

14. MTAC0600 WATER SPOUT

15. WW-2-P08 TOP TRAY

16. WW-2-P09 HEAT SHIELD

17. CW-00P07 SHELF BRACKET

18. WW-00P10 WATER HOLDER

19. WW-00A01 TOP RING ASSY

20. WW-00P15 PILOT BRACKET

21. CW-00P20 LEG BRACKET

22. CW-00T02 S/S LEGS

23. GPI00002 2 WAY PILOT FOR DUCKBILL BURNER

24. GBNCWB18 NEW DUCKBILL BURNER

25. GBNCWB18-1 CHIMNEY – DUCKBILL BURNER

26. GBNCWJ01-1 CHIMNEY – MONGOLIAN BURNER

13

Air Cooled Wok-All Models May 2011

10. DRAWING - SPARE PARTS

MODEL: CW-B2
BOILING TOP

1

NEW CHINESE WOK SIDE BURNERS

MODEL VARIATION(PARTS)

9

8

7

6

5

4

3

2

10

11

12

13

CWW2

14

Air Cooled Wok-All Models May 2011

10. DRAWING - SPARE PARTS

MODEL: CW-B2

ITEM No. CODE DESCRIPTION

1. MKNPLN21 CONTROL KNOB

2. GCKPF001 GASCOCK PEL N21

3. GBNSP001 BURNER SUPPORT BRACKET

4. GTCI0600 THERMOCOUPLE – 600mm

5. GTCI0450 THERMOCOUPLE – 450mm

6. PFPTA001 ALUMINIUM FRONT PILOT TUBE

7. PFPTA002 ALUMINIUM REAR PILOT TUBE

8. GIJBT### INJECTOR – BOILING TOP

9. PF-00P33 AIR INLET CONTROL

10. GTR00002 TRIVET – PF66

11. GBNCWL00 BURNER – CW SIDE (LONG)

12. GBNCWS00 BURNER – CW SIDE (SHORT)

13. GPI00001 SINGLE PILOT

Air Cooled Wok-All Models May 2011

15

11. WARRANTY

Installation must be carried out according to local regulations by qualified trade
persons.

Isolating switch(es), shut-off valves etc must be within easy reach of the machine
for future service and maintenance requirements.

If in doubt call GOLDSTEIN/ESWOOD or their representative for further
information. No responsibility will be accepted for defects or damages by improper
installation, for changes to the product not authorised by GOLDSTEIN/ESWOOD or
for operation outside the technical specifications.

GOLDSTEIN/ESWOOD warrants their products to be free from defects in material
and workmanship under “normal use and service”. This does not include normal
wear and tear of parts. GOLDSTEIN/ESWOOD will repair or replace any parts,
which in GOLDSTEIN/ESWOOD’s sole judgement are defective in material or
workmanship, in accordance with the warranty offered.

This undertaking covers the provision of labour and parts for 12 months from the
date of delivery to the purchaser. This undertaking applies only to state capitals.
Remote areas are not covered by this commitment and special enquiries should be
made. (Note: Travel time not covered by warranty).

“To the maximum extent permitted by law, any liability on Goldstein/Eswood’s part
or on the part of its servants or agents for loss or damage of any kind whatsoever in
connection with the products, including liability for or in respect of any claim arising
out of contract, negligence or statute, shall not, in any event, exceed $100”

Labour under warranty is supplied free of charge during normal working hours,
Monday to Friday. Should warranty work be requested outside of our normal
working hours a labour charge will be applied equivalent to a normal hour rate,
without out of hours penalty rates. (Refer to last page of this manual for your
closest branch for warranty repair services).

16

Air Cooled Wok-All Models May 2011

12. GOLDSTEIN/ESWOOD BRANCHES

For inquiries please call your nearest state branch:

Head Office

211-213 Woodpark Road
Smithfield New South Wales 2164
Phone: [phone]
Fax: [phone]

Victoria Queensland

47 Stubbs Rd Nautilus Complex
Kensington Unit 12
Victoria 3031 210 Queensport Road
Murrarie Qld 4172
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]

Western Australia

Unit 2

9 Meares Way
Canning Vale
Western Australia 6155
Phone: [phone]

Fax: [phone]

17

Air Cooled Wok-All Models May 2011
