2181ER
User Manual
77 pgs1.15 Mb0

Gold Medal Products 2181ER User Manual

Download
Pralinator 2180EL, 2180ER, 2181EL, 2181ER, 2181DEL, 2181DER
11
Circuit Breaker, 15
AMP p/n 47364
Switch, Rocker DPDT
Lighted (2) p/n 48616
Relay, 30A DPST,
120V p/n 55219
Timer, Percentage
60 sec. p/n 48688
Resistor, 910 k, ½ W
(front, “On”) p/n 48691
Resistor, 82 k, ½ W
(rear, “Off”) p/n 48692
Capacitor, 7.5 µF 370 V
p/n 46107
Temperature Control,
RTD p/n 55057
Potentiometer, 500
Ohm p/n 46326
Switch, Rocker DPDT
Lighted (2) p/n 48616
Circuit Breaker, 15
AMP p/n 47364
Capacitor Strap
p/n 48301
Hole Plug, ½ Dia.SS
p/n 45395
Front Panel with
Hole Plug shown
Pralinator System Controller – For Models 2180EL(ER) and 2181EL(ER)
For electronic models made after 9/04
