Gold Medal 2033EX, Jumbo 360, 2033BG, 2033DC Instruction Manual

Jumbo 360

Instruction Manual

Model No. 2033BG, 2033EX, 2033DC

10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA

Part No. 74103

DANGER

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

SAFETY PRECAUTIONS

Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. Gas companies have competent service personnel to provide safe installation.

DO NOT use a match or flame to check for gas leaks – you may cause a fire or explosion!

001_010914

003_010914

Never add water to hot oil. When water is added to hot oil a stream explosion may ensue spattering hot oil resulting in serious burns or more seriously hot oil in someone’s eyes.

024_010914

Hot oil is dangerous – severe burns can result when hot oil contacts the skin. Hot oil is flammable – keep open flames away from hot oil and its vapors. Keep a fire extinguisher near this unit. Instruct personnel on what to do if there is a grease fire. DO NOT USE WATER ON A GREASE FIRE! Use only fire extinguishers approved for grease, oil, and electric fire.

002_102214

Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. Keep cord and plug off the ground and away from moisture. Always unplug the equipment before cleaning or servicing. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle.

008_051514

Page 2

gmpopcorn.com

DANGER

WARNING

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

SAFETY PRECAUTIONS (continued)

Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. NEVER make alterations to this equipment. Read the Installation, Operating, and Maintenance Instructions thoroughly before installing, servicing, or operating this equipment.

DO NOT store or use gasoline, or other flammable vapors and liquids, in the vicinity of this equipment.

014_020416

004_010914

Instructions on what to do when a user smells gas can be obtained from the local gas supplier. These instructions must be posted in a prominent location where the unit is to be operated.

005_010914

To avoid burns, DO NOT touch the kettle or any heated surface. DO NOT place or leave objects in contact with heated surfaces.

013_092414

ALWAYS wear safety glasses when servicing this equipment.

010_010914

No user serviceable parts inside. Refer servicing to qualified service personnel.

011_051514

Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862

Page 3

022_060215

gmpopcorn.com

WARNING

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

SAFETY PRECAUTIONS (continued)

DO NOT allow direct contact of this equipment by the public when used in food service locations. Only personnel trained and experienced in the equipment operation may operate this equipment. Carefully read all instructions before operation.

This machine is NOT to be operated by minors.

Note: Improvements are always being made to Gold Medal’s equipment. This

information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. (Gold Medal Products Co. does not assume any liability for injury due to careless handling and/or reckless operation of this equipment.)

012_010914

007_010914

Page 4

gmpopcorn.com

Perforated

Jet Scoop

1/4 Cup Measure

36 oz. Corn

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

INSTALLATION INSTRUCTIONS

Inspection of Shipment

After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual).

Manual

Read and understand the operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862.

Model Description

2033BG: 36 oz. Jumbo 360 Popper, LP Gas, utilizes an electric kettle drive motor.

2033EX: Export, 36 oz. Jumbo 360 Popper, LP Gas, utilizes an electric kettle drive motor.

2033DC: 36 oz. Jumbo 360 Popper, LP Gas, utilizes a DC powered kettle drive motor

(battery is not included with this unit).

Items Included with this Unit

Measure

Tank Regulator

Page 5

Tank Hose

gmpopcorn.com

Counterweight Assembly

1/4-20 Hex Head bolt

Counterweight

Knob

Set Screw

Counterweight Bar

Kettle

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Setup

This unit has been tested at the factory.

1. Remove all packaging and tape prior to operation.

2. This unit is for outdoor use only.

3. Place popper on a level, sufficiently stable base or counter that is strong enough to

safely support it when in use. This unit is certified for use on combustible surfaces.

4. Observe the following clearances to ensure proper air supply and maintenance:

• Minimum of 10 inches clearance on each side of unit.

• Minimum of 30 inches clearance for the front, back, and top of unit.

5. Bolt the popper to the counter to secure it from tipping.

6. Attach the counterweight assembly per illustration below.

7. After setup, the unit should be cleaned prior to use (see Care and Cleaning section of

this manual).

Page 6

gmpopcorn.com

DANGER

CAUTION

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Gas Installation Instructions

DO NOT connect the unit to a power source before gas connection is complete.

Gas Requirements

Converting the unit to an alternate fuel source will void the warranty and may cause a dangerous condition.

2033BG, 2033EX, and 2033DC: Propane Gas, 33,500 BTU/HR

NOTE: For outdoor use only.

Gas Installation

Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. Gas companies have competent service personnel to provide safe installation.

001_010914

When installing this gas unit in the United States, you must conform with local codes, or in the absence of local codes, with National Fuel Gas Code, ANSI Z223.1 (latest edition).

NOTE: Some local codes may require ventilation hoods or automatic fire systems. During

any pressure testing of the gas supply piping system at pressure equal to or less than 1/2 psig (3.45 kPa), the appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve.

After installation, all gas connections must be checked for leaks with a soap

solution (see Checking for Gas Leaks section of this manual).

Be sure to observe all clearances for this unit. Refer to the Setup Section of this manual to ensure proper air supply and adequate clearance for servicing and installation of this gas unit.

033_042814

Page 7

gmpopcorn.com

DANGER

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Important Fire Safety Notice

Consult your local fire protection agency for your area’s requirements. Check local fire protection requirements regularly to ensure compliance with local codes and proper operation. Have a fire extinguisher near the unit. (Use only fire extinguishers approved for grease, oil, and electrical fires.)

Hot oil is dangerous – severe burns can result when hot oil contacts the skin. Hot oil is flammable – keep open flames away from hot oil and its vapors. Keep a fire extinguisher near this unit. Instruct personnel on what to do if there is a grease fire. DO NOT USE WATER ON A GREASE FIRE! Use only fire extinguishers approved for grease, oil, and electric fire.

002_102214

Checking For Gas Leaks

After making any gas connection, or after performing any work on the gas train, ALWAYS check ALL gas connections for leaks with a soap solution.

DO NOT use a match or flame to check for gas leaks – you may cause a fire or explosion! When gas connections are complete, have a qualified professional wire the unit to a power source which will carry the current specified on the unit’s data plate.

034_042814

1. Apply SOAP BUBBLES to all connections and pressurize the gas line to check for leaks.

Perform this test outdoors away from any flames or sparks.

DO NOT use a flame to check for gas leaks.

2. It is recommended to check your flexible gas lines and gas fittings for wear and tear on

a frequent basis. Stop using the appliance immediately if damage is found, and contact a qualified professional to inspect and correct any issue.

3. Securely route all gas lines away from flames and high temperature areas.

4. Contact Gold Medal Technical Support, or a qualified Gas Service Technician with any

questions.

Gas Pressure

We have determined that optimum popping occurs when the gas pressure is adequate. For propane gas, we recommend a manifold pressure setting of 10 inches of water column. The pressure is measured at the appliance when the main burner is ignited.

Lighting and Shutdown Instructions

When gas installation is complete, the unit must be connected to a power source prior to lighting the unit (reference the Electrical Installation Instruction section). For pilot and burner lighting and shutdown instructions, refer to the Operating Instruction section of this manual.

Page 8

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Page 9

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Page 10

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Page 11

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Page 12

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Page 13

gmpopcorn.com

Black Lead

Red Lead

Model 203

3

DC

(wire nuts

Model 203

3BG

(wire nuts and

Black Lead

Green

Lead

White Lead

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Electrical Installation Instructions

DO NOT connect this unit to a power source until gas installation is complete (reference the Gas Installation Instructions section of this manual).

Electrical Requirements

This unit must be wired in accordance with local electric and building code requirements by a qualified technician. Model 2033BG and 2033EX are supplied with a hot, neutral, and ground lead as shown in image below. Model 2033DC is supplied with a black (negative) lead and a red (positive) lead as shown in the image below.

(Ground)

(Positive)

(Negative)

cord/plug not included)

(Positive)

(Negative)

and battery not included)

Page 14

gmpopcorn.com

DANGER

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

The following power supply must be provided:

2033BG: 115 V~, 195 W, 60 Hz 2033EX: 230 V~, 207 W, 50 Hz 2033DC: 12 V~ DC (Battery not included with this unit; customer must supply 12 volt

battery for proper machine operation.) Follow all safety precautions provided by the battery manufacturer. Motor is rated at 12VDC, 9.3 AMPs.

Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. Keep cord and plug off the ground and away from moisture. Always unplug the equipment before cleaning or servicing. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle.

008_051514

A certified electrician must furnish sufficient power for proper machine operation. We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. Make sure cord is located to prevent a trip hazard or unit upset.

Before You Connect Power to the Machine

Model 2033BG, 2033EX (Electric)

1. Make sure all machine switches and gas valves are OFF, before plugging the unit into

the receptacle.

2. Make sure the wall outlet can accept the grounded plugs (where applicable) on the

power supply cord.

3. The wall outlet must have the proper polarity. If in doubt, have a competent

electrician inspect the outlet and correct if necessary.

4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).

5. Install the unit in a level position.

Model 2033BG (Battery)

1. Make sure all machine switches and gas valves are OFF, before connecting the unit to

the battery.

2. Cables must be attached to the proper polarity. Red is “+” positive; black is “-” negative.

3. Install the unit in a level position.

Page 15

gmpopcorn.com

Gas Safety Valve

Lock Button

on the

Safety Valve Button

Gas Safety Valve

handle

Gas Safety Valve

handle

Pull out the

Lock Button

on

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

OPERATING INSTRUCTIONS

Controls and Their Functions

GAS SAFETY VALVE

The Gas Safety Valve has three settings used to control gas flow; PILOT, ON, and OFF positions. (Reference the Lighting and Shutdown Instructions in the Operating Instruction section of this manual.)

PILOT position - When the Gas Safety Valve handle is in the PILOT position, the Safety Valve Button may be pressed to provide gas for lighting the pilot.

ON position - Once the pilot is lit, turn the Gas Safety Valve handle to the ON position to ignite the main burner for use.

OFF position – The Lock Button on the Gas Safety Valve handle must be pulled out to rotate the valve into the OFF position.

Press to provide gas for the pilot.

shown in ON position.

Gas Safety Valve.

handle shown in PILOT position.

shown in OFF position.

the Gas Safety Valve to rotate valve into OFF position.

Page 16

gmpopcorn.com

Gas Safety

Gas Safety Valve

Lock

Button

Safety Valve

Kettle

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

KETTLE MOTOR SWITCH

Two position, ON/OFF toggle switch which provides power to the kettle agitator drive motor.

DO NOT pop corn if the agitator is NOT rotating.

Button

Valve

Motor Switch

Page 17

gmpopcorn.com

CAUTION

Air Adjustment Cap on

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Lighting and Shutdown Instructions

Steps to Light the Pilot and Burner:

1. Turn the Gas Safety Valve to the PILOT position.

2. Depress the Safety Valve Button next to the safety valve handle. Hold this button down

for 30-45 seconds.

3. Light the pilot burner with a household match. Continue to hold the Safety Valve

Button for approximately 20 seconds. Release the Safety Valve Button and the pilot burner will remain light.

4. Turn the Gas Safety Valve Handle to the ON position. The main burner will ignite.

Steps to Shut Down the Pilot and Burner:

1. To extinguish both the pilot and the main burner flames, pull the Lock Button on the

Gas Safety Valve, and turn the Safety Valve Handle to the OFF position.

2. Should the burner become extinguished because of the high-limit tripping, shut off the

gas supply until the unit cools down, then re-light.

If pilot is turned off, a five minute shutdown period is required before attempting to re-light.

035_042814

Air Adjustment on Burner

After the main burner is lit, according to the directions, make any needed air adjustments in order to get the best flame. Turn the Air Adjustment Cap (see image below) to supply more or less air. A blue flame provides optimum heat.

burner for small poppers.

Page 18

burner for large poppers.

gmpopcorn.com

WARNING

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

If the Flame Goes Out

If the flame goes out, a five minute shutdown period is required before attempting to re-light.

1. Check to see if you are out of gas.

2. Check to see if the thermocouple is in the proper position.

AT NO TIME during a power failure should an attempt be made to operate this unit.

If power failure occurs during operation, the gas supply is to be turned OFF until power failure has subsided. Then, and only then, should a relight attempt be made per the Lighting and Shutdown Instructions.

036_042814

Page 19

gmpopcorn.com

Kettle Size

Popcorn Charge

Oil Charge

Flavacol (Salt)

3

6 oz.

36 oz. (

1 L) 12

oz. (355 ml) 2

Tblsp. (

29.6

cc)

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Popping Corn

This section describes popping instructions for Standard (Salted) Popcorn using a gas popper.

Amount of Popcorn and Oil

The popper unit is equipped with a corn, salt, and oil measure. We recommend flavored and colored coconut oil. Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in your kettle like other oils. Use only top quality, fresh popcorn from reputable suppliers.

Popping Popcorn

1. Turn Main Burner ON (follow the burner lighting instructions found in the Operating

Instructions section of this manual).

2. Turn Kettle Motor Switch ON.

3. To determine when the kettle is ready to pop corn, test pop three kernels of corn and

one ounce (30 ml) of popping oil. When kernels pop, kettle is ready.

4. Lift the lid and pour in the pre-measured amounts of popcorn and Flavacol (see chart

above), then add oil in premeasured amount; close lid.

5. When corn has finished popping, gently dump the popcorn.

6. On final kettle of corn, turn the Main Burner OFF just as the lids are forced open by the

popping corn. This procedure helps eliminate smoke/odor from any oil residue that remains after popping has stopped.

7. When finished popping, make sure the MAIN BURNER and KETTLE MOTOR switch are

turned OFF.

NEVER LEAVE THE MAIN BURNER IN OPERATION WHEN NOT POPPING CORN!

Page 20

gmpopcorn.com

DANGER

WARNING

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Care and Cleaning

Machine must be properly grounded to prevent electrical shock to personnel.

DO NOT immerse in water.

Always unplug the equipment before cleaning or servicing.

To avoid serious burns, DO NOT touch the kettle while it is hot!

Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of advertising your product.

025_020314

028_082715

Note: It is extremely important to follow all of the cleaning procedures, otherwise parts

damage and equipment failure will result. The warranty does not cover parts that are damaged due to improper cleaning.

Daily Kettle Cleaning Instructions

CAUTION: A hot kettle will cause burns if you touch it with your hand. Allow kettle to cool

at least 1 hour before attempting to clean. DO NOT use ice or water to cool down a hot kettle! Severe kettle damage will result!

1. When cool, wipe outside of kettle with a clean, soft cloth. DO NOT use oven cleaners or

abrasive materials as they will damage the kettle.

2. Every night, mix Gold Medal’s Heat’n Kleen solution (Item No. 2095), 2 tablespoons

per gallon of water. It is not necessary to use the entire gallon at once; only use enough to fill the kettle 1/2 inch deep.

3. Turn kettle heat ON. When water starts to boil, turn kettle heat OFF.

4. Allow to cool at least 1 hour, then dump solution into a bucket and wipe inside of

kettle with a clean cloth. Make sure all solution goes into the bucket; do not spill any in the interior of machine.

For an extra dirty kettle, the process may be repeated; or, after turning kettle heat OFF, allow solution to sit in kettle overnight. The next morning, dump solution into a bucket and wipe inside of kettle with a clean cloth.

Page 21

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Daily Unit Cleaning Instructions

1. Follow the burner shutdown instructions, turn machine OFF, and allow unit to cool.

Once cool, disconnect unit from its power source before attempting to clean.

2. Clean all pans/accessories in order to sanitize them before each use.

3. Take a clean, SLIGHTLY damp cloth and wipe excess grease from unit.

4. Wipe stainless steel parts with a clean cloth and cleaner designed for stainless steel,

such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088).

DO NOT use oven cleaners or abrasive materials as they will damage parts of machine.

Page 22

gmpopcorn.com

Issue

Possible Cause

Solution

Gas Issues

A. For gas issues

refer to the initial Gas Setup

Long Popping Cycles

A. Inferior Corn

A. Inferior quality corn would result in longer

Kettle Agitator not

A. Kettle

Motor Switch

A. Check to make sure the unit has power and

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Troubleshooting

Instructions.

(Longer than 4 minutes)

Rotating

popping cycles. Use only top quality hybrid popcorn from reputable suppliers. Even then, if you let your corn pick up moisture or dry out, your popping cycles will be slow.

the Kettle Motor Switch is ON. If the switch is ON, and the agitator is not rotating, DO NOT pop corn. The switch may be faulty, contact qualified service personnel for inspection/repair.

Page 23

gmpopcorn.com

DANGER

WARNING

CAUTION

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

MAINTENANCE INSTRUCTIONS

Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. Keep cord and plug off the ground and away from moisture. Always unplug the equipment before cleaning or servicing. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle.

Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. NEVER make alterations to this equipment. Read the Installation, Operating, and Maintenance Instructions thoroughly before installing, servicing, or operating this equipment.

008_051514

014_020416

No user serviceable parts inside. Refer servicing to qualified service personnel.

THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE OPERATOR.

THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH GAS EQUIPMENT. THESE ARE NOT INTENDED FOR THE OPERATOR.

011_051514

027_010914

027b_051514

Page 24

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

ORDERING SPARE PARTS

1. Identify the needed part by checking it against the photos, illustrations, and/or

parts list.

2. Use only approved replacement parts when servicing this unit.

3. When ordering, please include part number, part name, and quantity needed.

4. Please include your model number, serial number, and date of manufacture (located

on the machine nameplate/data plate) with your order.

5. Address all parts orders to:

Parts Department Gold Medal Products Co. 10700 Medallion Drive Cincinnati, Ohio 45241-4807

Or, place orders by phone or online:

Phone: (800) 543-0862

(513) 769-7676

Fax: (800) 542-1496

(513) 769-8500 E-mail: info@gmpopcorn.com Web Page: gmpopcorn.com

Page 25

gmpopcorn.com

16

8

* NOTE:

The position of the Belville Washers

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Kettle Assembly

1, 2

is IMPORTANT. Conical surfaces must face each other as shown.

3

9

4

5

6

7

15

14*

13

12

11

17

18

19

20

21

10

22

23

24

25

26

Page 26

gmpopcorn.com

2033BG 2033EX 2033DC

1 SCREW #8

-

32X1/2 PAN HD PH

74147

2 HEX NUT #8

-

32 ESLOK

74146

3 SET SCREW #8

-

32 X 5/8

74571

4 KNOB LID LIFT

47120

5 COUNTER WEIGHT,W

-

8/32 TAP

82108

6 COUNTER WEIGHT BAR

-

36 OZ

74002

7 1/4-20 X 3/4 GRADE 5 BOLT

74520

8 KETTLE DUMP CHUTE ASSY

74066

9 LID ASSY JUMBO 360

74062

AGITATOR

ASSEMBLY (assembly includes Items

11 NUT,HEX JAM 7/8

-

14

74106

12 KETTLE BEARING HUB ASSY

(Includes Bearing)

74004

13 BEARING, KETTLE HUB

(Bearing Only)

74005

14*

1/2 BELVILLE WASHER

27039

15 AGITATOR ASSY JUMBO 360

74073

16 DOWEL PIN 3/16 X 1

-

1/4

10072

17 HUB CAP, AGITATOR

27038

18 AGITATOR SPRING

41138

19 UPPER AGIT DRIVE SHAFT

74003

20 WASHER, COMPRESSIO

N 74007

74007

21 WASHER, BRONZE THRUST

74006

22 KETTLE ONLY JUMBO 360

74070

23 LOCKING PLATE

74009

24 DRIVE

SHAFT ASSEMBLY

74187

25 AIR SHIELD AGIT SHAFT

74010

26 MOTOR SUPPORT

74185

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Kettle Assembly Cross Section – Parts List

Item

10

11 thru 20 listed below)

Part Description

Part Number

74109 74109 74109

Page 27

gmpopcorn.com

2033BG 2033EX 2033DC

1 DUMP BAR HANDLE

74112

2 DUMP BAR HANDLE ASSY

74113

3 COLLAR

74661

4 TORSION SPRING

74660

5 SPACER

74658

6 LARGE SPACER

74690

7 KETTLE MOUNT BAR

74018

8 KETTLE STOP

74019

9 KETTLE STOP ROD

74020

10 SET COLLAR 1/2ID X 7/8OD

47326

11 HEAT RING ASSEMBLY

74057

12 PIN QUICK DISCONNECT

74011

13 LOCKING PLATE

74009

14 BURNER ASSY, JUMBO 360

74095

15 AIR ADJUSTMENT CAP

74023

16 PILOT BURNER

74032

17 PILOT ORIFICE .010 LP

74050

18 PILOT BURNER MT BRKT

74094

3

5 6 9 10

See Gas Line Parts

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Unit Top View (under Kettle)

4

7

8

11

12

2

1

16

13

17

18

14

Breakdown Section.

Item

Part Description

15

Part Number

Page 28

gmpopcorn.com

8 9

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Gas Line – Rear View – Parts Breakdown

1

2

7

11

12

6

10

5

4

3

15

13

14

Page 29

gmpopcorn.com

2033BG 2033EX 2033DC

1 AIR ADJUSTMENT CAP

74023

2 ELBOW,BULKHEAD SPECIAL

74037

3 5/16 OD AL

UM TUBE

(uses 0.6 ft.)

74123

4 STRAIGHT FITTING

74040

5 1/4 ALUM TUBE 15 IN LONG

74122

6 THERMOCOUPLE

57030

7 GAS SAFETY VALVE

74027

8 T-FITTING

89764

9 BRASS PIPE PLUG,

1/8” NPT

74562

10 PRESSURE REGULATOR NG&LP

74115

ADAPTER, GAS LINE 3/8 NPT (Flare Pipe

12 CONTROL SUPPORT BRACKET

89910

KETTLE DRIVE MOTOR

82085B

82413

R

DC DRIVE MOTOR

82085DC

EXHAUST BLOWER 120V,

60CY

48018

EXHAUST BLOWER

220V

, 50

CY

48037

AXIAL FAN

48018DC

15 SWITCH, TOGGLE SPST

47201

7.5 MFD CAPACITOR

(not shown)

46107

CAPACITOR 5 MFD

(not shown)

82217

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Gas Line – Rear View – Parts List

Item

11

Fitting, use with Gas Hose P/N 109000)

13

14

Part Description

Part Number

74595 74595 74595

Page 30

gmpopcorn.com

1 PERF JET SCOOP REGULAR RH

2072

2 MEASURE 1/4 CUP

47169

3 CORN CUP ASSY 36 OZ

67905

-36

4 TANK REGULATOR

89920

5 GAS HOSE (has a Flared Hose Fitting)

109000

2

4

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Accessories

1

Item

3

5

Part Description Part No.

Page 31

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Wiring Diagram

Model No. 2033BG

Page 32

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Model No. 2033EX

Page 33

gmpopcorn.com

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

Model No. 2033DC

Page 34

gmpopcorn.com

10700 Medallion Drive, Cincinnati, Ohio 45241

-

4807 USA

Jumbo 360 Model No. 2033BG, 2033EX, 2033DC

WARRANTY

Gold Medal Products Co. warrants to the original purchaser each item of its manufacture to be free of defects in workmanship and material under normal use and service. Gold Medal Products Co.’s obligation under this warranty is limited solely to repairing or replacing parts, f.o.b. Cincinnati, Ohio, which in its judgment are defective in workmanship or material and which are returned, freight prepaid, to its Cincinnati, Ohio factory or other designated point. Except for “Perishable Parts” on specific machines, the above warranty applies for a period of two (2) years from the date of original sale to the original purchaser of equipment when recommended operating instructions and maintenance procedures have been followed. These are packed with the machine. Parts warranty is two (2) years, labor is six (6) months.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR PART, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. In no event shall Gold Medal Products Co. be liable for special, incidental or consequential damages. No claim under this warranty will be honored if the equipment covered has been misused, neglected, damaged in transit, or has been tampered with or changed in any way. No claim under this warranty shall be honored in the event that components in the unit at the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty is effective only when electrical items have been properly attached to city utility lines only at proper voltages. This warranty is not transferable without the written consent of Gold Medal Products Co.

The term “Original Purchaser” as used in this warranty shall be deemed to mean that person, firm, association, or corporation who was billed by the GOLD MEDAL PRODUCTS CO., or their authorized distributor for the equipment.

THIS WARRANTY HAS NO EFFECT AND IS VOID UNLESS THE ORIGINAL PURCHASER FIRST CALLS GOLD MEDAL PRODUCTS CO. AT 1-800-543-0862 TO DISCUSS WITH OUR SERVICE REPRESENTATIVE THE EQUIPMENT PROBLEM, AND, IF NECESSARY, FOR INSTRUCTIONS CONCERNING THE REPAIR OR REPLACEMENT OF PARTS.

NOTE: This equipment is manufactured and sold for commercial use only.

Phone: (800) 543-0862 Fax: (800) 542-1496 (513) 769-7676 (513) 769-8500

© 2016 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.

gmpopcorn.com

Page 35

gmpopcorn.com
