Golden Source Electronics FRS5970900 User Manual

Golden Source Electronics Ltd.
Operation Manual
Family Radio Service
(FRS)
5970-901
5970-902
Written By:
Proprietary information of Golden Source Electronics Ltd. , not to be disclosed w itho ut wr itten aut horiza ti on.
Golden Source Electronics Ltd.
Operation Manual for FRS Model Coleman
Warning
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected. Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Modifications not authorized by the manufacturer may void the user’s authority to operate this device.
Proprietary information of Golden Source Electronics Ltd. , not to be disclose d witho ut wr itten aut horiza tio n.
Rev. 0.0 06 April 2006 Page 2 of 6
Golden Source Electronics Ltd.
Operation Manual for FRS Model Coleman
1.0 Feature List
1.1 UHF FM transmission
1.2 No license required
1.3 500mW output power
1.4 Up to 3Km transmission range
1.5 Water proof up to 1 meter
1.6 14 Channels
1.7 Electronics volume – 8 levels
1.8 PTT/Call function
1.9 Automatic squelch function
1.10 Low battery alert function
1.11 Key tone function
1.12 LCD Backlight
2.0 Controls and display
2.1 System controls
1. TALK
2. (UP) (VOL)
Button symbol
(DOWN)
3. (UP) (CHAN)
(DOWN)
4. (POWER)
2.2 LED indicator
Blue LED for indication of Tx and Rx status, battery low alert.
Press and hold for TALK.
Press twice shortly for call tone
transmission.
Volume adjusting
Channel select
Press and hold for Power On and Off
Description
Proprietary information of Golden Source Electronics Ltd. , not to be disclose d witho ut wr itten aut horiza tio n.
Rev. 0.0 06 April 2006 Page 3 of 6
Golden Source Electronics Ltd.
Operation Manual for FRS Model Coleman
2.3 LCD panel
TX
RX
Numerical digits, display cha nnel and volume level
TX icon, light on in Transmission mode
Rx icon, light on in Receiving mode
3.0 Operation
3.1 Turning the Unit ON and OFF
Press and hold (POWER button) for 1 second to turn the FRS unit ON. Press and hold
(POWER button) for 1 second again to turn the FRS unit OFF.
3.2 Adjusting the Speaker Volume Adjusting the Speaker Volume Up
Press
(UP_VOL) button to increase the speaker volume.
Adjusting Speaker Volume Down
Press
(DOWN_VOL) button to decrease the speaker volume.
Proprietary information of Golden Source Electronics Ltd. , not to be disclose d witho ut wr itten aut horiza tio n.
Rev. 0.0 06 April 2006 Page 4 of 6
Golden Source Electronics Ltd.
Operation Manual for FRS Model Coleman
3.3 Selecting a Channel
z
3.3.1 Press (UP_CHAN) button, The channel number (1-14) will be changed
ascending in one step.
z 3.3.2 Press (DOWN_CHAN) button , The channel number (1-14) will be changed
descending in one step.
3.4 Talking and Listening
z In order to speak to someone, each of you must be set to the same channel. z Press and hold TALK (push to talk button) to transmit. Transmissions commence and
the Blue LED indicator lights.
z Speak into the microphone with 5 to 7cm away from you mouth. Release TALK button
at the end of transmission. You can now receive incoming calls. While receiving, the RX icon will appear on the LCD screen and Blue LED indicator lights.
3.5 Sending call tone
z Press TALK button twice shortly to send a page to other FRS in the same channel. The
Blue LED indicator lights.
3.6 Automatic Power Save Feature
z After 6 seconds for the last operation, the FRS enters to the power saving mode
automatically. The life of the batteries would be extended. The FRS is still able to receive transmission in this mode.
3.7 Low battery alert
z When the batteries in the unit are low, an alert tone will be heard and blue LED will
flash once every 15 seconds. Replace new batteries immediately.
3.8 LCD backlight
Press any Key, Blue LED is lighted about 3 seconds.
3.9 Using batteries
z The FRS units operate with 3 x 1.5V AAA batteries. z CAUTION: Danger of explosion if battery is incorrectly replaced. For regular
battery, replace only with the AAA equivalent type. Batteries should not be thrown with domestic rubbish. You may hand them in at your nearest collection point.
z Do not leave batteries installed over a long period of time as leakage may occur
and this can destroy the radio.
Proprietary information of Golden Source Electronics Ltd. , not to be disclose d witho ut wr itten aut horiza tio n.
Rev. 0.0 06 April 2006 Page 5 of 6
Golden Source Electronics Ltd.
Operation Manual for FRS Model Coleman
4.0 Channel and frequency table
Frequency
CH
(MHz)
1 462.5625 6 462.6875 11 467.6375 2 462.5875 7 462.7125 12 467.6625 3 462.6125 8 467.5625 13 467.6875 4 462.6375 9 467.5875 14 467.7125 5 462.6625 10 467.6125
CH
Frequency (MHz)
CH
Frequency (MHz)
Proprietary information of Golden Source Electronics Ltd. , not to be disclose d witho ut wr itten aut horiza tio n.
Rev. 0.0 06 April 2006 Page 6 of 6
