GoGEN PDX 923 SUDVBT2 User Manual
PDX 923 SUDVBT2
USER MANUAL
TABLE OF CONTENTS
Contents
Table of Contents ................................................................................................................ 2
Important Safety Instructions ............................................................................................. 3
Safety Precautions .............................................................................................................. 4
Identication of Controls .................................................................................................... 5
Main Unit ............................................................................................................................... 5
Remote control unit ............................................................................................................... 6
SETUP Menu Setting ........................................................................................................... 8
General Setup Page .............................................................................................................. 8
Audio Setup Page .................................................................................................................. 9
Video Setup Page .................................................................................................................. 10
Preference Page .................................................................................................................... 10
Password Setup Page ........................................................................................................... 11
Parameters and specications ........................................................................................... 12
System ................................................................................................................................... 12
Battery Parameters ................................................................................................................ 12
First Time Installation ......................................................................................................... 13
Basic Operation ..................................................................................................................... 13
Technical Specications ..................................................................................................... 20
Troubleshooting .................................................................................................................. 20
EN - 2
IMPORTANT SAFETY INSTRUCTIONS
Warning: To reduce the risk of electric shock, do not remove the cover or back.
There are no user-serviceable parts inside. Refer servicing to qualied personnel.
Warning: To prevent re or electric shock hazard, do not expose the unit to rain
or moisture.
• Do not expose the Adaptor and portable DVD to water (dripping or splashing) and no objects
lled with liquids, such as vases, should be placed on the unit.
• Keep the portable DVD away from direct sunlight and heat source such as radiators
or stoves.
• Do not block the ventilation openings. Slots and openings on the unit are provided
for ventilation. The openings should never be blocked by placing your portable DVD
on a cushion, sofa or other similar surface.
• Do not place the portable DVD on unstable cart, stand, tripod, bracket or table.
The unit may fall, resulting in possible damage or injury.
• Never place heavy or sharp objects on the LCD panel or frame.
• Only use the AC adapter included with portable DVD. Using any other adapter will void your
warranty
• The plug of AC adaptor is used as the disconnect device, the disconnect device shall remain
readily operable.
• Unplug the power from the outlet when the unit is not in use.
• Attention should be drawn to the environmental aspects of battery disposal.
EN
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
WARNNING: The battery (battery or batteries or battery pack) shall not be exposed
to excessive heat such as sunshine, re or the like.
WARNNING: Excessive sound pressure from earphones or headphones can cause
hearing loss.
WARNNING: Only use attachments/accessories specied provided by the manufacturer,
the portable DVD is supplied by AC adapter, the AC adapter is used as disconnect
device, the disconnect device shall remain readily operable.
Caution: Danger of explosion if battery is incorrectly replaced, replaced only
with the same or equivalent type (Lithium battery)
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this
product for environmental safe recycling.
EN - 3
SAFETY PRECAUTIONS
Warning: This digital video disc player employs a laser system.
Use of controls,adjustments, or the performance of procedures other than those specied
herein may result in hazardous radiation Exposure.
Warning: To prevent direct exposure to laser beam, do not open the enclosure.
Visible laser radiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do not install this product in a conned space such
as a book case or similar unit.
Warning: when the unit using by child, parents must make sure to let the child
understand all contents in Instruction book how battery using to guarantee using battery
correctly all the time.
Warning: when nd battery overheat, swell or dour, please stop using battery and contact
service centre for getting replacement.
Warning: do not charging battery on the place of insufcient ventilation such as:
mattress, sofa, cushion , soft mat...
Warning: we will not take any responsibility if user incorrectly use battery, not following
our warning instruction label on the battery case.
Warning: more than 250 mm USB extension cord is prohibited to use for USB port
Notes on Copyrights:
• It is forbidden by law to copy, broadcast, show,broadcast via cable, play in public,
or rent copyrighted material without permission.
• This product features the copy protection function developed by Macrovision.Copy protection
signals are recorded on some discs. When recording and playing the pictures of these discs
picture noise will appear.This product incorporates copyright protection technology that
is protected by method claims of certain U.S. Patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners.Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by macrovision Corporation.
Reverse engineering or disassembly is prohibited.
• SERIAL NUMBER:
You can nd the serial number on the back of the unit.This number is unique to this unit and
not available to others.
EN - 4
IDENTIFICATION OF CONTROLS
Main Unit
EN
1. PLAY/ PAUSE
2. STOP
3. SOURCE
4. VOL-
5. VOL+
6. MENU
7. ▲/▼/◄/►(up/down/right/left)
Select an item in the menu.OK key confirms menu selection.
When playing,VCD,DVD,if available:
►: fast forward
◄: fast reverse
▲: previous track
▼: next track
8. ENTER
9. OPEN
10. SETUP
11. SD/MMC
12. USB
13. AV OUT
14. Earphone Socket
15. COAXIAL
16. ON/OFF
17. DC IN 9-12 V
18. ANT
19. HDMI
EN - 5
IDENTIFICATION OF CONTROLS
Remote control unit
1. SOURCE
DVD/CARD/USB.
2. MUTE
Disable Audio output.
3. 0-9 NUMBER BUTTON
Selects numbered items in a menu.
4. DISPLAY
To display the playtime and status information.
5. 10+ BUTTON
In order to select a track 10 or greater, rst press 10+, For example; select track 12, rst press
10+, and then press number 2 button.
6. PBC/FAV
PBC on/off switch(VCD) in DVD mode.
Open Favorite Programs List Menu in DVB mode.
7. AUDIO
: Press AUDIO repeatedly during playback to hear a different audio language or audio track,
if avilable.
: Press AUDIO repeatedly during playback to hear a different audio channel
(Left,Right,Mix,Stereo).
8. PLAY/PAUSE
Press PLAY/PAUSE once to pause playback, pressing PLAY/PAUSE second time will resume
the playback.
9. STOP
When this buttom is pressed once, the unit records the stopped point,from where playback will
resume if PLAY ()is pressed after wards. But if STOP button is pressd again instead
of PLAY () button, there will be no resume function.
10. STEP/TV/RADIO
Step the motion in DVD mode.
Switch between TV and Radio source in DVB mode.
EN - 6
11. VOL+
23. VOL-
Adjust volume
12. Forward Skip
Go to next chapter/ track.
13. Reverse Skip
Go to previous chapter/ track to the beginning.
14. BUTTON
Press BUTTON allow skipping ahead at 5-level speed (X2->X4->X8->X16->X32->PLAY),
press PLAY button return to normal playback.
15. BUTTON
Press BUTTON allow skipping back at 5-level speed (X2->X4->X8->X16->X32 PLAY),
press PLAY button return to normal playback.
16.
Turn on/off the power.
17. SEARCH
Goto time point, title or chapter you want in DVD Mode.
EN
18. SUBTITLE
Press SUBTITLE repeatedly during playback to hear a different
subtitle languages.
19. ANGLE
: Press ANGLE will change the view angle, on DVDs that support this feature.
20. ●/ TITLE
DVB Enter Record
Return to DVD title menu.
21. ENTER
Conrms menu selection.
22. REPEAT
Press REPEAT during playback to select a desired repeat mode.
: you can play select repeat chapter/title/off.
: you can select repeat single/all/off.
: you can select repeat single/folder/off.
24. SETUP
Accesses or removes setup menu.
25. SLOW
Press Slow button repeatedly to enter slow playback, and cycle between different speeds.
The speeds are 1/2,1/4,1/8,1/16,and normal.
26. PROGRAM
: The program function enables you to store your favourite tracks from the disc.
Press PROGRAM button,then PROGRAM MENU will appear on screen, now you can use
the number key to direct input the titles,chapters or tracks number and select PLAY option.
TO resume normal playback, press PROGRAM and select clear program option on the program
menu, press PROGRAM again to exit program menu.
EN - 7
