Ele ct ric Boat s
Su n Lounge r Se rie s
2 0 13 Owne r M a n u al
®
Go-Float Electric Boats
Welcome to Go-Float
We appreciate your choice of Go-Float Electric Boats for your boating
pleasure. We hope you will be completely satisfied with your purchase
and enjoy it for many years.
Your new Go-Float has been designed to give you and your family
years of trouble free fun on the water. Please read this manual carefully
before operating your boat. This manual will assist you in operation,
safe use, and care of your Go-Float. By taking a few moments to
familiarize yourself with the functions of your Go-Float, you can help
make your investment last.
Please do not hesitate to contact us with questions or suggestions. We
want to ensure that your boating experience is as safe and relaxing and
as fun as possible. Enjoy your Go-Float!
Sincerely,
PS. Be safe… always wear a personal flotation device. Know and
comply with all applicable local boating regulations.
Copyright 2013 Go-Float, LLC
The Go
-
Float Team
®
TABLE OF CONTENTS
Overview
Go-Float Fusion & Impulse Overview .............................................. 4
Go-Float Vortex Overview .............................................................. 5
Operation
Getting Started ................................................................................ 6
Speed Control ................................................................................. 7
Steering & Power Control ................................................................ 7
Automatic Bilge Pump ..................................................................... 7
Beach BuddyTM ............................................................................... 8
Listening to the Stereo..................................................................... 8
Monitoring the Battery Life ............................................................... 9
Charging the Battery ....................................................................... 9
Safe Boarding ............................................................................... 10
Storage and Maintenance
Beaching ....................................................................................... 10
Storing On End.............................................................................. 10
Motor Maintenance........................................................................ 10
Propeller, changing ....................................................................... 11
Safety & Troubleshooting
Troubleshooting ............................................................................ 12
Safety ........................................................................................... 12
Go-Float, LLC
810 First Street South
Suite 110
Hopkins, MN 55343
Phone: (952) 955-9500
Fax: (952) 955-9501
Email: info@go-float.com
Website: www.Go-Float.com
Overview of Go-Float Fusion & Impulse Features
Cup Holder
Cooler/ Storage
Compartment
Stereo Control &
Battery Meter
Steering Handle
AC Plug Input
Receptacle
Bow
(front)
Starboard
side
Port side
Stern
(rear)
Seat removes to
access Battery
Speed
Control
Fusion shown
Overview of Go-Float Vortex Features
Cup Holder
Cooler/ Storage
Compartment
Stereo Control
Steering Handle
AC Plug Input
Receptacle
Bow
(front)
Starboard
side
Port side
Stern
(rear)
Seat Back flips
forward to access
Battery
Speed
Control
Battery Meter &
MP3 Player
Storage
Getting Started
Congratulations on your purchase of a Go-Float electric watercraft,
what we consider to be the finest and simplest electric boat on the market today!
This is a sheet to simplify getting you started and on the water, enjoying
your new Go-Float boat.
Battery Connection:
Go-Float boats are shipped with the battery(s) disconnected. If your
battery meter shows a green bar that indicates charge, your batteries
are already connected. If not, you will connect your battery(s) by pulling
forward the seat panel (Vortex) or removing the seat tray (Fusion,
Impulse).
To remove the seat tray, open your cooler and unlatch the seat tiedowns that you will find in the front of the cooler. This is best accomplished with the boat resting on its hull, as the seat tray could slide forward and damage the stereo if it is set on its stern in the upright storage
position. With the tie-downs unlatched, lift the seat tray from the side
away from the stereo to avoid damaging the push buttons on the stereo.
Inside the equipment compartment you will find red and black connectors coming from both the power buss bar and from the battery(s). Hook
one connector set from the buss to a battery, if you have two batteries,
hook one set to each battery. You should now have a battery charge
indication. Replace the seat tray or close the seat panel.
Operation:
To make the boat go, select a speed on the speed selector knob and
push the go-button in the grip of the steering handle with your thumb. It
is best to not run the motor while the boat is out of the water, but a short
test to check your motor’s operation will not harm the motor.
Charging:
Plug an extension cord into the charging port. This can be done while
the battery(s) are connected or disconnected, but should not be done
while the boat is in the water. After charging, if the meter does not show
a full charge, disconnect the extension cord, disconnect the
battery(s), count ten and reconnect the battery(s). Your meter should
now indicate a full charge.
Steering and Power Control Handle
Power “GO” Button: To turn on the motor, press the “GO” button with
your thumb at the end of the
steering handle. To turn off the
motor, release thumb pressure from the
“GO” button.
IMPORTANT! Be alert for swimmers
near your boat! Always release the
“GO” button to turn off your motor when
others approach your boat.
Steering: When in forward motion, to
steer right, push the handle forward. To steer left, pull the handle back.
Steering directions are opposite when in reverse.
Speed Control
Each number indicates a rate of speed.
“OFF 0” is neutral with no forward or reverse
motion.
FORWARD 1 thru 5. 1 is the slowest forward
speed, good for navigating around other
boats, for docking and beaching. Each higher
number increases speed, with 5 being the
highest speed.
REVERSE 1 is a slow speed, good for navigating around other boats
and for docking.
REVERSE 2 is a higher speed, good for quickly slowing the boat and
for spinning weeds off of the prop.
The speed can be changed while the boat is underway, but it is
recommended to stop the motor (release thumb pressure from the “GO”
button) to change direction. Changing direction suddenly while
underway could damage the motor.
“GO” Button
Right
Le turn
Automatic bilge pump. Any water that accumulates inside the hull will activate the bilge pump to
automatically remove the water. Water is ejected
through the hull via the round plastic fitting found
on the port side of your Go-Float (shown at left).
Keep this opening unobstructed during use of
your Go-Float.
Automatic Bilge Pump
Beach Buddy with optional wheel
kit for paved surfaces.
Beach Buddy with optional wheel
kit for sandy surfaces.
The Beach BuddyTM, is designed to protect the
motor and propeller from underwater objects
while cruising or beaching your Go-Float. It is
also used to stand your Go-Float on end for
storage in small areas. For instructions on
storing upright, see page 10. While underway it
may catch weeds. If you think you have slowed
because of weeds on the Beach Buddy, follow the same procedure as
for removing weeds from the propeller on page 11. Wheel Kits are available to add to your Go-Float Beach BuddyTM for easier movement
across lawns, driveways, etc.
Do not use the Beach Buddy as a step to enter the boat.
Beach BuddyTM
Stereo (optional). iPod ready. Compatible with most MP3 players and
other audio devices. Refer to the manufacturer’s manual included with
your boat.
Caution: close media tray before entering or leaving the boat to prevent
damage to it.
Stereo
The Battery Status Indicator is
specifically designed to monitor the
charge status of the battery(s)
onboard your Go-Float.
Interpreting Battery Status. The
battery indicator has ten vertical
bars that light green to indicate the
charge status of your
battery(s). If no bar is lit, the battery
(s) are disconnected or are dead. A
fully charged battery will indicate a green bar on the right side of the
meter, while a green bar on the left of the meter indicates a depleted
battery charge. A good time to recharge your battery(s) is when the lit
bar is indicated three from the left.
CAUTION: This is not a fool-proof device and no warranty is made that
your battery(s) condition is good. All charge levels are approximate.
Monitoring the Battery
Keep your batteries fully charged prior to use.
Onboard charger. Your Go-Float is equipped
with the an onboard charger, Use a UL
approved three-pronged extension cord
designed for outdoor use to connect to your
source of electricity. The AC Plug Receptacle
is located on the deck of your Go-Float.
Battery(s) can also be charged with a standard
automobile battery charger. Access the battery
by removing the seat back (Vortex) or
removing the entire seat (Fusion, Impulse). The battery may remain in
the boat or be removed to recharge. Be sure to connect the battery
charger to the battery poles Positive-to-Positive and Negative-toNegative. Consult your charger’s operating manual to determine the
appropriate settings.
CAUTION: Do not charge battery(s) while boat is in the water.
Move your boat to dry land first.
Charging the Battery
AC Plug Receptacle
Upright, Temporary: Be sure that the battery hold down strap is
secured. Remove all items from the cooler-storage compartment and
the passenger area. Rest the boat on a flat surface on the Beach Buddy
and raise the bow until the boat is completely upright and resting on its
transom. Be sure that your Go-Float is out of the wind so as not to blow
over.
Upright, Long Term: Follow the above procedure, but to extend the life
of your battery, remove it first. Store the battery on a wooden surface,
such as a piece of lumber, indoors. Use a trickle charger about every
4-6 weeks to keep the battery powered up.
IMPORTANT! Use a heavy line attached to the bow eye to secure your
Go-Float to a solid fixture, such as a rafter. This will prevent your GoFloat from accidently falling over. Do not store upright outdoors—wind
may blow over. Vortex not recommended for upright storage.
Storage
Beaching
IMPORTANT! When your Go-Float
is on shore in a horizontal position,
it is recommended that you do not
step into the boat. Serious damage
may occur to the hull, deck, and
Beach BuddyTM.
Battery
The battery included with your boat
is sealed, so do not worry about it
leaking during upright storage.
Safe Boarding
With your Go-Float in the water, to
safely board, step as far as you are
able into the center aft portion of
the seat. This will keep the boat as
stable as possible while you are
boarding. This will also place your
weight onto the strongest area of
the deck. Reverse the procedure
for safe disembarking.
Bow Eye
Motor Maintenance
We recommend after use to rinse motor to remove sand and other
debris. Check the propeller for line or weeds. Regularly check for loose
fasteners, corroded or loose terminal connections and frayed wires.
Keep moving parts lubricated. An aerosol lubricant works well.
Electrical Connections
Before removing or installing the battery, ensure that all switches are in
the OFF position and have the propeller area clear. If replacing or
adding a battery, we highly recommend ordering your battery from GoFloat to ensure safety and good performance.
Changing the Propeller
Before doing anything with the propeller, ensure the cables to the
battery are disconnected. Detaching the propeller it is a simple mat-
ter of unscrewing and removing the locknut using the special tool supplied. When doing this, take hold of the propeller to stop it turning. Under no circumstances should you attempt to loosen the locknut with a
hammer or similar tool as this may damage the locknut or shaft – or
both. (F)
Once the locknut is removed, you will be able to slide the propeller off.
When putting the propeller back on, verify there is a proper fit of the
groove and shear pin otherwise the propeller will not be locked in place.
(G)
After using the motor always check and clear any weed or fishing line
that may have become tangled around the propeller. Next, give the
motor a wipe down with warm water to remove any salt or sand particles and then spray it with fresh water.
Troubleshooting
Symptom Possible Cause/Solution
Speed loss
1. Check for weeds or fishing line on
the propeller and remove.
2. Check battery charge status.
3. Check battery connections.
Motor noise or vibration
1. Check propeller for weeds or
fishing line.
2. Check to see propeller is secure
and not damaged.
Weeds on prop
Weeds on Beach BuddyTM
Weed Removal while Underway:
1. Set the speed control at Forward 5
and spin the propeller briefly.
2. Stop the motor, set the speed at
Reverse 2 and spin the propeller
briefly.
3. Reset the speed to forward and
check for improved performance.
4. Repeat steps 1-3 until weeds are
cleared and satisfactory
performance has returned.
Weeds on prop
Weeds on Beach BuddyTM
Weed Removal Manually:
CAUTION! TURN MOTOR OFF before
attempting to remove weeds by hand.
Personal Flotation Device. We recommend that a proper personal
flotation device be worn by all occupants of the boat.
Motor and Prop. Always watch for other boaters or hazards while on
the water. This boat is not designed to be a swimming or diving
platform. Watch out for swimmers near your boat.
Spinning props can cause serious injury or death.
Motor. Do not run the motor out of the water. The motor needs to be
submerged in water to stay cool. Running the motor when dry can
seriously damage motor’s seals.
Go-Float Electric Boats can not be responsible for accidents due to
misuse, modifications or for using the boat in any manner other than its
intended use.
Boating Safety
Loading...
