Goepel Easy CON User Manual

GOEPEL electronic GmbH

Goeschwitzer Str. 58/60 •D-07745 Jena
+ 49-3641-6896-597 • [e-mail] • www.goepel.com

Easy CON

Media Converter

User Manual
(Translation of Original docu)
Document Version 1.2

Issue: September 2015

© 2015 GOEPEL electronic GmbH. All rights reserved.

The software described in this manual as well as the manual itself are supplied under license
and may be used or copied only in accordance with the terms of the license.
The customer may make one copy of the software for safety purposes.

The contents of the manual is subject to change without prior notice and is supplied for information
only.

The hardware and software might be modified also without prior notice due to technical
progress.

In case of inaccuracies or errors appearing in this manual, GOEPEL electronic GmbH assumes
no liability or responsibility.

Without the prior written permission of GOEPEL electronic GmbH, no part of this documentation
may be transmitted, reproduced or stored in a retrieval system in any form or by any means
as well as translated into other languages (except as permitted by the license).

GOEPEL electronic GmbH is neither liable for direct damages nor consequential damages from
the company’s product applications.

Printed: 22.09.2015

All product and company names appearing in this manual are trade names or registered trade names of their respective owners.

Table of Contents

Easy CON Media Converter I

1 CONCEPT OF THE DEVICE .............................................. 1-1

2

USE OF THE DEVICE ...................................................... 2-1

2.1

SPECIFICATIONS AND CONNECTIONS ....................................... 2-1

2.1.1 Technical Data ....................................................... 2-1

2.1.2

Connection ............................................................. 2-2

2.1.3

Liability and Warranty Limitation .............................. 2-2

2.2 INTERFACES ..................................................................... 2-3

2.2.1 Node 1 ................................................................... 2-3

2.2.2

Node 2 ................................................................... 2-3

2.2.3

Status LEDs ............................................................ 2-5

2.3 FIRST STEPS .................................................................... 2-6

3

ACCESSORIES ................................................................ 3-1

Concept of the Device

Easy CON Media Converter 1-1

1 Concept of the Device

The Easy CON device from GOEPEL electronics connects automotive
Ethernet networks using one pair BroadR-Reach Ethernet as physical­layer to standard LAN networks with 10Base-T/ 100Base-Tx physical­layer. The device comes with RJ45 connectors on both links. This
allows the use of shielded standard low-cost high-quality cables (CAT5
or CAT6) for the test-setup. For easy connection to the ECU cabling
harness, an adapter cable with 9-Pol. D-Sub connector is included.

The Easy CON Media Converter can be operated as BroadR-Reach
Master or Slave. Selection is easily done via a switch on the device`s
rear plate (not visible in the following figure).

Figure 1 -1:

Easy CON
