GMC205Pi
UNDER DESK SHREDDER
micro-cut
http://www.monomachines.com/
http://www.monomachines.com/
2
WARNINGS
CAUTION: KEEP THIS DEVICE AWAY FROM CHILDREN AND
PETS! Place the paper shredder in an area less accessible to children.
DO NOT PLACE FINGERS TOO CLOSE TO THE FEED SLOT AS
SERIOUS INJURY MAY OCCUR. Paper shredders can pull children’s
fingers into the shredder mechanism.
AVOID GETTING LOOSE CLOTHING OR JEWELRY NEAR THE
FEED SLOT.
AVOID GETTING HAIR NEAR THE FEED SLOT.
NEVER spray any aerosol-based products in or around the shredder.
NEVER dispose of flammable chemicals, or materials that have
come into contact with flammable chemicals (for example, nail polish,
acetone, gasoline) in the shredder basket. NEVER use any petroleum
based or flammable oils or lubricants in or around the machine, as
some oils can combust causing serious injury. Lubricants specifically
designed for shredders are acceptable.
NEVER place the shredder near water or any heat source.
Avoid direct contact with water.
DO NOT SHRED PAPERS WITH PAPER CLIPS ON THEM.
Please take out any paper clips from paper before shredding.
STOP USE IMMEDIATELY IF:
1. The shredder blades become wadded up with paper.
2. The shredder motor makes loud and/or irregular noises
during operation.
3. The shredder blades or paper guides become bent or
compromised in any way.
Continuing to operate your shredder with any of the above
conditions present could be potentially dangerous.
! !
http://www.monomachines.com/
http://www.monomachines.com/
3
Thank you for choosing the green option in paper shredding.
While meeting the increasing needs in document shredding and
security, our GoECOlife™ Commercial Shredder series were
made with environmental issues in mind.
Carbon
Free
® Certified
This product is carbon neutral. It meets
Carbonfund.org’s Carbon
Free
® Product
Certification protocol which requires third-party
life cycle assessment of the product’s carbon
footprint, and carbon reductions in support of
third-party validated renewable energy and
reforestation projects. To learn more, visit
www.carbonfund.org/products.
Energy-Saving Technology
Prevents power drain (phantom load) when your
shredder is not in use. Save energy! Save money!
Virtually eliminates Vampire Energy loss.
Automatically powers Off after 30 minutes
of being idle.
Green Packaging
Recycled (or partially recycled) and biodegradable
materials were used for packaging and printed
materials. No styrofoam, plastic tape or plastic bags
were used to package this product. Fewer trees were
sacrificed to package your shredder!
http://www.monomachines.com/
http://www.monomachines.com/
4
Technical Specifications
Model .......................................................................................... GMC205Pi
Cutting Style ................................................................................Micro-Cut
Shred Size ............................................................. 0.12 x 0.35 in. (3 x 9mm)
Sheet Capacity ...............................................................................20 sheets
Shred Speed Max Sheet Capacity .........................6.73 ft/min (2.05 m/min)
Intake Throat Width ..........................................................9.06 in. (230mm)
Voltage ........................................................................................ 120V/60Hz
Dimensions (L x W x H) ..........17.56 x 13.98 x 25.91 in. (446 x 355 x 658mm)
Weight ............................................................................. 60.8 lbs. (27.58 kg)
Receptacle Volume .................................................7.85 gallons (29.7 liters)
Noise Level (Motor) ........................................................................... 62 dB
Run-time .....................................................................................20 minutes
2
years
limited
product
warranty
limited
cutter
warranty
LIFE
TIME
UNDER DESK SHREDDER
micro-cut
High Security
Shreds a letter sized sheet of paper into over 2000 particles.
Space-Saving
Uniquely designed to fit under
any standard height desk.
Ergonomic
Convenient, horizontal front-feeding for
efficient shredding right from your seat.
Powerful
Commercial-grade, heavy duty performance.
20-minute continuous run time.
Ultra-Quiet
Low noise level won’t disturb
those around you.
GoECO™
button
Main Power
Switch
Large 7.85 Gallon (29.7L) Waste Bin
http://www.monomachines.com/
http://www.monomachines.com/
5
Installation
• Refer to set-up instructions printed on carton box for proper assembly.
• Only operate this product from the type of power source indicated on the
marking label. If you are not sure of the type of power available, consult
an electrician.
• Make sure the electrical outlet is easily accessible from the shredder.
• Shredder must be operated only in upright position.
• To make sure the shredder has proper ventilation, place it a minimum
distance of 1.97 in. (5 cm) from the wall or furniture.
Safety Instructions
1.
Read and follow all instructions before use. Save these instructions for later use.
2. Always turn off and unplug the machine before moving, servicing,
cleaning, or anything other than normal operation. Serious injury may
result. Clean shredder with a damp cloth, using a mild soap and water
solution.
3. Do not use abrasives or petroleum-based cleaners.
4. Place this product as close as possible to power source for quick and easy
unplugging.
5. Turn off the power switch before removing waste bin. It is advisable to
disconnect the power cord before opening the shredder.
6. This product should never be placed near a radiator or other heat source.
7. Do not allow anything to rest on the power cord. Do not place the power
cord where people may walk on the it.
8. If an extension cord is used with this product, make sure the total of the
ampere (amps) ratings on the products plugged into the extension cord do
not exceed the extension cord’s ampere rating.
9. Do not attempt to service this product yourself, as in opening or removing
covers may expose you to risks of getting injured. Also, doing this will
void the warranty of the shredder.
10. Unplug this product and contact technical support when:
• The power cord or plug is damaged or frayed.
• Liquid has been spilled on the product.
• The product has been exposed to rain.
• The product does not operate normally even when the operating
instructions are followed.
• The product has been dropped, or the casing has been damaged.
11. This shredder should be operated only with an operator in attendance.
12. Regularly empty the waste bin so that the waste output is not impeded.
13. This machine can shred normal paper, credit cards, CDs and DVDs.
However, you should shred only one of these items at a time to avoid
causing an overload.
http://www.monomachines.com/
http://www.monomachines.com/
6
Operation
Please read instructions carefully before operating your shredder.
TO POWER ON:
1. Connect the power cord to any standard 120V AC, 60Hz outlet.
2. Toggle the main power switch on the rear panel to the ON position.
FOR NORMAL OPERATION:
3. Press the GoECO™ Energy-Saving button to turn ON the shredder.
It will run automatically for 2 seconds. The shredder is now in
AUTO mode and ready to accept paper.
4. Feed up to the maximum allowed sheets of paper for shredding into
the paper feeding throat.
TO PUT INTO REVERSE MODE:
5. Press the “R” button on the control panel. The shredder is now in
Reverse mode, and the motor will move in reverse to push out paper.
TO PUT INTO FORWARD MODE:
6. Press the “F” button on the control panel. The shredder is now in
manual forward mode, and the motor will move forward to shred paper.
TO PUT BACK INTO AUTO MODE:
7. Press the GoECO™ Energy-Saving button on the control panel. The
shredder is now in AUTO mode, and when you insert papers into the
paper throat, the shredder will start automatically.
FOR PAPER JAMS:
8. If you insert more than the maximum number of paper sheets allowed
and jamming occurs, the machine will automatically go into reverse to
push out the jammed papers.
TO TURN OFF:
9. There are 3 ways to stop the shredder where all power to the shredder
will be shut off. This also cuts off any phantom load power leakage.
a. Press the “Off” button on the control panel.
b. Toggle the power switch to “OFF” on the rear panel of the shredder.
c. Or, do nothing, and the GoECO™ technology will turn off
automatically after 30 minutes of being idle.
DOOR OPEN:
10. When the waste bin is open or ajar, the shredder will not start until the
waste bin is completely closed.
OVERHEATING:
11. During long periods of continuous shredding, the motor temperature will
rise. When the temperature reaches the maximum allowed level, the
shredder will automatically shut off the motor until it has cooled to an
acceptable temperature. The shredder will be ready to resume paper
shredding when the motor has sufficiently cooled.
http://www.monomachines.com/
http://www.monomachines.com/
7
Limited Product Warranty
The manufacturer warrants the cutting cylinders of the machine to be free
from defects in material and workmanship from the original date of purchase
by the original consumer. The manufacturer warrants all other parts of the
machine to be free from defects in material and workmanship for two (2)
years from the original date of purchase by the original consumer. If any part
is found to be defective during the warranty period, your sole and exclusive
remedy will be repair or replacement, at the manufacturer’s option and
expense.
This warranty is valid for the original consumer only with original proof of
purchase and is not transferable. This warranty does not apply in cases of
abuse, mishandling or unauthorized repair. ANY IMPLIED WARRANTY,
INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE
APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event
shall the manufacturer be liable for any consequential or incidental damages
attributable to this product. This warranty gives you specific legal rights. You
may have other legal rights that vary.
Repairs must be performed by the manufacturer’s authorized technician.
For more details, or to obtain service under this warranty, please contact us at
866-377-4771.
Please retain original proof of purchase to ensure that your product is
recorded and warranty information received.
Return Instructions
Call 866-377-4771 for a Return Authorization Number (RA#) and for
instructions on how to return your shredder.
Product Registration:
Please register your new product at www.goecolife.com,
or call
866-377-4771.
Contact Us:
For more information, please call 866-377-4771, or
email us at
info@goecolife.com.
http://www.monomachines.com/
http://www.monomachines.com/
Copyright © 2011 INTEK America, Inc. Rancho Dominguez, CA 90220. ALL RIGHTS RESERVED.
