Technical Specifications

Charging: Approximate Charge Times

Goal Zero Switch 8 5-10 hours

Goal Zero Guide 10 Plus 6-12 hours

USB devices (cell phone, MP3 player) 2-5 hours

Not compatible with Smart Phones or larger USB devices

Inputs

Rated Wattage 3.5 W

Cell type mono-crystalline

Open-circuit voltage 6.5-7V

Converting eff. 17-18%

Cell area 0.0199 m

Outputs

USB output 5V, 0.5A max (2.5W), linear regulated

Solar port (for Guide 10) 6-6.5V, 0.5A max (3.0W), not regulated

General

Weight 0.5 lbs (0.22 kg)

Dimensions 6.5 x 1 x 5.5 in (16.5 x 2.5 x 14 cm)

Warranty 12 months

Tested and Certified FCC

Operating usage temperature 0-120F (-17-48C)

₂

Power Ports on Back of Solar Panel

Guide 10 Plus OUTPUT

Charges the Guide 10 Plus,

SOLAR PORTS

faster than USB.

USB OUTPUT

Accepts standard USB cable for charging USB devices.

(Including Switch 8)

Know Your Gear

NOMAD3.5

PORTABLE SOLAR PANEL

• Register your product

• Watch demo video

• Download user manual

We proudly support Tifie Humanitarian www.tifie.org

User Guide

CHARGE

From the sun.

POWER

Plug in any USB or 12V device.

2 3

REPLENISH

To stay prepared

keep devices plugged into USB

or solar panel.

Frequently Asked Questions

Q: Does the solar panel hold a charge? A: No, the panel produces power only when it is exposed to sunlight. To generate the most power, angle the panel towards the sun. This improves your ability to collect power from the sun. Note: Clouds and windows affect collection efficiency. If you would like to store solar power, combine the Nomad 3.5 with the Switch 8 or Guide 10 Plus.

Q: What can I charge directly from the

solar panel?

A: You can charge different USB devices. The Nomad 3.5 will not charge smart phones by itself. We recommend pairing it with the Switch 8 or Guide 10 Plus as an intermediary.

Q: Is the solar panel waterproof?

A: It is weather-resistant and will not be harmed if exposed to rain or snow.

Q: Why can’t I charge my smart phone or

tablet?

A: Smart phones and tablets draw more

current than can be provided. For these devices we suggest using the Switch 8 or Guide 10 Plus with the Nomad 3.5.
