Page 1
Reference Guide
Please read this guide BEFORE you use your gear!
Page 2
Input
30 watt mono-crystalline solar panel
Output
Open circuit voltage: 18V
Charging voltage: 12.5V± 2V
Product weight (no pkg) 13 lbs
Product dimensions 16" x 22"
Warranty Twelve months
Operating Temperatures
Optimal Operating Temperature 32-104F
Optimal Storage Temperature 32-86F
Tested and certified
Technical Specifications
Page 3
Getting Started
Before using your ESCAPE 30M solar briefcase for the first
time, please follow these simple steps.
1. Activate your warranty by registering your GOALØ gear
at http://www.goal0.com/warranty
2. Open the ESCAPE 30M solar briefcase.
3. Prop up the ESCAPE’s legs and angle its panels toward
the sun. The panel’s light sensor will turn on indicating that it
is receiving solar power.
4. Plug the ESCAPE 30M’s charging cable into your power
pack.
You are now ready to charge your power pack!
Hint: The ESCAPE 30M’s performance is enhanced if you
occasionally adjust it’s angle to follow the path of the sun.
Prolong the life of your GOALØ gear and prevent injury to
yourself and others by being mindful of these warnings.
PROTECT the panels from heavy impact.
PROTECT yourself from the panels when left out in the sun.
The surface of the panels can become very hot.
PROTECT the solar panels by keeping them clean by using
a non-abrasive soap and cloth.
Page 4
Recharge & Go!
When you’re off the grid you need to know how long it will
really take to power up. You don’t want numbers that come
out of a laboratory based on perfect conditions. At
GOALØ all of our gear is field tested with an independent
team of extreme adventurers that span from alpinists to
ocean rowers. The charging times listed here come from
countless hours of real world testing. That’s why we call it
TruWatt™ - real numbers that you can count on.
The TruWatt™ Power Grid
Page 5
Get to know your gear...
POWER IT
Highly efficient solar cells
deliver up to 30 watts of
power.
KNOW IT
The blue light turns ON
when the panel detects
light.
MANAGE IT
The convenient cable
tray makes it easy to
neatly store the
ESCAPE 30M’s power
cable.
Page 6
...continued
STAND IT UP
The Scout’s foldable legs open up to
angle the ESCAPE 30M toward the sun.
CARRY IT
Ergonomically
designed and
rubberized handle for
comfortable and easy
carrying.
FOLD IT UP
When you’re done
using the ESCAPE
30M fold it up and
stow it away.
Page 7
Questions you may have...
Q- Is the ESCAPE 30M waterproof?
A-The ESCAPE 30M is weather resistant. Just remember
you are powering electronics and those devices may not be
waterproof.
Q- Does the ESCAPE 30M deliver a full 30 watts?
A-The ESCAPE 30M can deliver up to 30 watts of power
but the angle of the panels and cloud cover can impact its
performance. Try to keep the ESCAPE 30M out of the
shade and adjust its angle to the sun as the day passes to
maximize performance.
Q- Can I chain multiple ESCAPE 30M panels together?
A-Yes. With a GOALØ accessory adapter you can charge
your power packs faster by chaining ESCAPE 30Ms
together. The panel chaining accessory can be purchased at
http://www.goalØ.com.
Q- What kind of solar cells do you use in the ESCAPE 30M?
A-We use the latest mono-crystalline technology. Why? It
provides more power, faster, per square inch than any other
solar technology on the market.
Hint: Visit our website, YouTube and facebook channels
for product tours, support or other questions that you
may have.
Page 8
Collect Power from the Sun
BEST
OKAY
BAD
Optimize the performance of your GOALØ solar gear by angling it
correctly to the sun.
Page 9
Other ESCAPE gear
ESCAPE POWER PACKS
From day trips to camp outs, this
durable power pack provides you with
150 watt-hours of rechargeable power
at a great value.
ESCAPE SOLAR PANELS
Just plug into the Scout power pack to
charge and capture solar energy
everywhere you go with this portable
folding solar briefcase.
ESCAPE LED LIGHTS
With the chainable ESCAPE LED lights
keep the trail, campsite or tent lit for hours
at a time. Chain multiple LAL lights together
for even more light.
Available at www.goalØ.com.
Page 10
FIND US ON:
Did You Know…
By purchasing GOALØ gear you are helping to
sustain the philanthropic initiatives of Tifie
Humanitarian. In fact, GOALØ was originally
created to provide light in schools and
orphanages across Africa. We invite you to
learn more about our charity of choice by
visiting Tifie’s website at:
www.tifie.org
Join Tifie and GOALØ on
Please call us at 888-794-6250
if you have any additional questions.
