GN Audio USA WEP150 User Manual
Corona III –
Samsung to provide Commercial product name
Bluetooth Headset
User Manual
The Multi function button on the headset is in this draft manual presented by the
symbol
. The final symbol is to be determined by Samsung.
English
Thank you
1. Check phone compatibility
2. Charge Corona III
3. Read the glossary
4. “Pair” to your Bluetooth® phone
5. Turning headset on/off
6. Choosing wearing preference
7. Making a call
8. Ending a call
9. Answering a call
10. Call-waiting
11. Enhanced features (for Bluetooth phones with hands-free profiles)
12. Frequently asked questions
13. Need more help?
14. Storage of headset
15. Certification and safety approvals
16. Warranty and parts replacement
17. Glossary
Customer service contact details
Thank you
Thank you for purchasing the Corona III Bluetooth® Headset, we hope you will
be delighted with its operation.
Please read the instruction manual to get started and to make best use of the
headset’s many features.
! Drive safely
Using a mobile phone while driving creates a distraction to the driver which may
increase the likelihood of an accident.
When using the phone while driving, keep conversations short and do not make
notes or read documents. Before answering calls consider your circumstances.
Pull off the road and park before making or answering calls when driving
conditions require (e.g. bad weather, high traffic density, presence of children in
the car, difficult junctions or manoeuvres.)
Remember, driving comes first, not the call!
Abide by local laws.
Corona III Overview
1 Blue Indicator Light
2 Multi-Function Button
3 Volume Control Button
4 Charging socket
Fig 1.
STOP: BEFORE USING YOUR HEADSET
1 Check phone compatibility
The Corona III is compatible with most Bluetooth
are compliant with Bluetooth version 1.1 or higher specification and support the
headset and/or hands-free profile(s)
capability by either visiting your phone manufacturer’s web site or Samsung web
site at www.samsung.com
2
. Ensure that your phone has Bluetooth
1
(see Glossary) phones that
2 Charge Corona III
Corona III uses a rechargeable battery that must be charged fully before you use
the headset for the first time.
1. Plug the Corona III AC charging adaptor into the headset’s charging
socket.
2. Plug the AC adaptor into the electrical outlet.
3. Charge your headset until the red light turns to green light on Corona III .
The unit will be fully charged in approximately 2 hours.
5. Remove the headset from the AC charging adaptor . You are now ready to
“pair” Corona III to your mobile phone. If the headset has already been
paired to your phone, then you can begin using it.
Fig. 2
! WARNING: Do not attempt to charge Corona III with anything other than the
AC adaptor provided. Using another AC adaptor may damage or destroy the
headset.
! IMPORTANT: The red indicator light will be on while charging and will turn
green when charging is complete. Removing the headset from the charging
cradle while it’s charging will put the headset into standby mode and stop the
charging sequence.
! IMPORTANT: Corona III cannot be used while charging.
3 Read the glossary
Read the glossary at the end of this document to familiarize yourself with
important terms used in this User Manual.
Once Corona III is fully charged, continue with these instructions.
4 “Pair” to your Bluetooth phone
Pairing
enabled devices such as your Bluetooth phone and Corona III.
1. Ensure the headset is off (see Turning headset on/off section).
2. Press and hold
3. Set your Bluetooth phone to “discover” the headset by following your
4. Your phone will find the “Corona III” headset and ask if you want to pair
5. Enter passkey or PIN
3
will create a unique and encrypted wireless link between two Bluetooth
until you see a solid blue light (approximately 8
seconds), then release* (see Fig. 3).
phone’s instruction guide. Typically, the steps involve going to a “setup”,
“connect”, or “Bluetooth” menu on yo ur phone and then selecting the
option to “discover” a Bluetooth device.
with it. Confirm this by pressing “yes” or “ok”.
4
= 0000 (4 zeros), then press “yes” or “ok”.
Fig. 3
Fig. 4
