Welcome

The Motorola HT820 Bluetooth Stereo Headset makes connectivity invisible and reliable. It is astonishingly advanced and simple to use.

Motorola is actively creating

Bluetooth

home, and life everywhere around the globe.

Thank you for choosing the Motorola HT820 stereo headset with Bluetooth technology!

solutions for work, play,

Export Law Assurances

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

The use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. All other product or service names are the property of their respective owners. © Motorola, Inc., 2005.

6809489A96--O

Contents

Safety and General Information Introduction

Headset Features . . . . . . . . . . . . . 10

Using Your Headset

Pairing Your Headset and Phone . . 16

Wearing Your Headset. . . . . . . . . . 20

Controlling Headset Volume . . . . . 21

Making and Receiving Calls. . . . . . 21

Music Controls . . . . . . . . . . . . . . . 26

Headset Indicators . . . . . . . . . . . . 30

Audio Tones. . . . . . . . . . . . . . . . . . 34

Connecting To A Music Device Using The Included Stereo Audio Cable . 36

. . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . 13

. . . 4

Safety and

General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR DEVICE.

Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the

Safety and General

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).

Electromagnetic Interference/Compatibility

Note:

susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic compatibility.

Nearly every electronic device is

Facilities

To avoid electromagnetic interference and/or compatibility conflicts, turn off your device in any facility where posted

Safety and General

notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external radio frequency (RF) energy.

Aircraft

When instructed to do so, turn off your device when on board an aircraft. Any use of a device must be in accordance with applicable regulations per airline crew instructions.

Medical Devices

Hearing Aids

Some devices may interfere with some hearing aids. In the event of such interference, you may want to consult with your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical

Safety and General

device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Industry Canada Notice to Users

Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See Ref IC: RSS 210 Sec. 5.11. The term “IC:” before the certification/registration number signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were

Safety and General

met. It does not imply that Industry Canada approved the equipment. See Ref IC Self-Marking 6(f) and RSP-100 Sec. 4.

FCC Notice to Users

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this

Safety and General

equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Safety and General

Introduction

Headset Features

Headset Music Controls (Left Side)

1—Skip Reverse Button <

you to skip back to the previous music track.

2—Skip Forward Button >

you to skip forward to the next music track.

3—Play/Pause/Stop $

play, pause, or stop music.

Introduction

Allows you to

Allows

4—Headset Jack

connect non Bluetooth devices to

your stereo headset.

Allows you to

Headset Call Controls (Right Side)

5—Volume Up Button + 6—Volume Down Button 7—Multifunction Button (MFB)

Used to answer and end calls. Also

used for other phone call functions.

Introduction

Using Your

Headset

Charging Your Headset

First-Time Use

your headset, you need to charge its self-contained battery for two hours.

Recharging

rapid high tones through the headset speaker, repeated at 20-second intervals, the headset battery needs to be recharged.

Over time, batteries gradually wear down and require longer charging times. This is normal. The more you talk on the phone with the headset, the less standby time your battery has.

—Before you can use

—When you hear five

Using Your Headset

The rechargeable batteries that power this product must

be disposed of properly and may need to be recycled. Contact your local recycling center for proper disposal methods. Never dispose of batteries in a fire because they may explode.

How to Charge

Action

Plug the Motorola charger into your

headset.

Using Your Headset

Action

Plug the other end of the charger into an electrical outlet.

While charging, the headset indicator turns on and remains on until charging is complete. The headset will not function while charging. Your headset fully charges in approximately 2 hours.

When charging is complete (indicators off), remove the charger from the electrical outlet, and detach the charger cord from the headset.

Using Your Headset

Note:

You can also use a Motorola Original™ Vehicle Power Adapter to charge your headset while in your vehicle.

A fully charged headset battery provides approximately:

Pairing Your Headset and Phone

Note:

phone before you can make a call.

“Pairing” creates a link between devices equipped with Bluetooth

•

Stereo music listening time – 12

hours

•

Phone call talk time – 15 hours

•

standby time –200 hours

You must pair your headset and

Using Your Headset

wireless technology and allows the

phone to remember your headset’s

unique ID. After your headset and phone are paired, your headset automatically connects to your phone any time you turn it on.

With your headset and phone in close proximity:

Step

Put your headset into pairing mode.

With the headset off, press and

hold the Multifunction Button until the headset indicator turns on and remains on (about 6 seconds).

Using Your Headset

Step

Perform a the phone.

For details on device discovery for your phone, refer to the phone’s user’s guide.

When the scan is complete, the phone displays the devices found.

Select the Motorola HT820 from the discovered devices list and confirm following the on screen prompts.

When prompted by the phone, enter the passkey the headset with the phone.

The device ID is now stored in the phone’s memory.

Pairing is successful when the headset indicator flashes 10 times rapidly.

device discovery

from

0000

and confirm to pair

Using Your Headset

Paring to Additional Devices

Use the procedure “Pairing Your

Headset and Phone” on page 16 to pair your headset to a stereo music source. The music source must support streaming stereo audio over Bluetooth.

Your headset can store pairing information for up to eight different devices that have Bluetooth wireless technology. Devices are stored in a “Paired Device List” in memory in chronological order. When an attempt to pair to more than eight devices is made, the oldest paired device is removed from the list.

Any of the eight paired devices can initiate a paired connection to your headset.

Using Your Headset

When you turn on your headset it will only automatically initiate a paired connection with the device (such as a mobile phone) and the last music source it was If you want to connect your headset to another device in the paired device list, you must initiate the connection from that device. When any one of the eight devices initiates a connection to the headset afterwards, that device then becomes the “last connected” device.

Wearing Your Headset

Your Motorola Bluetooth Stereo Headset is designed to be worn comfortably with the neckband behind your head. The microphone is hidden inside the right ear cup. Digital signal

last

hands free

connected to

Using Your Headset

processing is used for clear pickup of your voice.

Controlling Headset Volume

Press the volume + or - button repeatedly until you reach the desired volume level.

Making and Receiving Calls

Your headset supports both Handsfree and Headset Profiles. Accessing call functions depends on which profile your phone supports.

Note:

Some phones do not support all features listed. Please consult your phone user’s guide.

Using Your Headset

You can activate call functions according to the following table:

Device Status

Phone Headset

Enter Pairing Mode:

On Off Press & hold T

Make a Voice Dial Call:

On in idle On Short press T,

Dial a Number:

On– the user dials a number on phone.

On Press SEND on the

Using Your Headset

Action

(MFB) for 5 seconds until LED remains on. Release

speak name, phone dials call.

phone to complete the call.

Device Status

Phone Headset

Redial a Number:

On–Idle On–

(Idle)

End a Call:

On–in call On Short press

Put Active Call On Hold:

On–in call On Long press

Put Active Call On Hold:

On–in call On Long press

Receive a Call:

On–

phone rings

On Short press T (call

Action

Long press

is answered)

Using Your Headset

Device Status

Phone Headset

Reject a Call:

On–phone rings

Answer 2nd incoming call:

On–in call, 2nd call coming in

Toggle between two active calls:

On–in call, 2nd call on hold

On Long press

On Long press T,

On Long press

Action

places 1st call on hold, answers incoming call

Using Your Headset

Device Status

Phone Headset

Join two calls (3-way calling):

On - in call, 2nd call on hold

Transfer call from phone to Headset:

On–in call On Short press T, (call

Note:

disconnected (for example, out of range) the headset tries to reestablish the link.

On Press both Volume

If the link is abnormally

Action

buttons simultaneously. Both calls will become active.

transferred to headset)

Using Your Headset

Music Controls

When the headset is on a phone call, the music control buttons are disabled.

Using Your Headset

Music Control Functions

When headset is Idle:

Press Result

play/pause

short press

MFB headset controls

When headset is playing music from a remote source:

Press Result

Headset commands remote source to start playing music.

phone functions

Go to previous

track.

Go to next track.

Using Your Headset

Press Result

play/pause

(short press play)

Stop

(long press)

MFB Stop music and

Pause music

Stop music

open a hands free connection to phone.

Using Your Headset

When music track is paused:

Press Result

play/pause

(short press play)

Stop (Long

press)

MFB Stop music and

Go to previous track.

Go to next track.

Restart music track.

Stop music

open a hands free connection to phone.

Using Your Headset

When headset is in a phone call and music paused:

Headset Indicators

Press Result

MFB (end call) Phone ends call.

Music play resumes.

There are two lights on the HT820, one on the left in the Multifunction Button, and one on the right in the Play/Pause/Stop button. These lights indicate the following conditions:

When the charger cord is plugged in:

Headset Indicators

ON Battery Charging

Using Your Headset

Headset

Headset Indicators

OFF Charging complete

When no charger cord attached:

Headset Indicator

MFB

Button

OFF OFF Power off

ON (steady)

10 rapid flashes

Flashes every 3 seconds

Headset

Play

Button

Headset Mode

OFF Pairing mode

OFF Pairing

successful

OFF standby

(not on a call)

no audio.

Using Your Headset

Headset Indicator

MFB

Button

Flashes every 8 seconds

Note:

When your wireless headset is paired to your phone and there is no activity for 5 minutes, the blue flashing LED turns off. Any button press on the headset turns on your headset and it resumes the flashing. You can disable the Headset Indicators by pressing the FF and REW buttons simultaneously. The Headset Indicators can be turned

Play

Button

OFF connected

Flashes every 8 seconds

Headset Mode

(on a call)

Phone Audio

Music mode

Using Your Headset

back on by pressing the FF and REW buttons simultaneously again.

Using Your Headset

Audio Tones

Audio Tone Headset Status

One high tone when pressing volume button

Five rapid high tones, repeated every 20 seconds

No audio indications; deteriorating audio quality

Series of 4 tones, low to high

Ring tone Incoming call

Single high tone Pairing

Using Your Headset

Volume maximum or minimum reached

Low battery

Out of range

Audio link open (Headset mode), active call (Hands Free mode)

confirmation

Audio Tone Headset Status

One low tone Initiate voice

activation

Dual high/low tone

One high tone End call

Series of 4 tones, high to low

Fast high/low tone every 5 seconds (max. & min. volume confirm beep)

No tone Power ON/OFF

Voice tag not recognized

Audio link closed (Headset mode),

call ended (Handsfree mode)

No network/service

Using Your Headset

Connecting To A Music Device Using The Included Stereo Audio Cable

There is a headset jack connector on the HT820 that allows the headset to plug in to either a stereo music player or a multimedia phone. The volume buttons on the stereo headset do not control the volume of the inline audio. All volume control of the inline audio is done through the input device.

Presence of the inline stereo audio will not disable the Bluetooth link between your mobile phone and your HT820. If your phone rings, your HT820 mutes the music and lets you answer the call with

Using Your Headset

the HT820. When the call ends, the headset unmutes the stereo music.

Airplane Mode

Your HT820 can be used to listen to music through the inline stereo connector even when switched off. The Bluetooth link will be ended but inline audio will still function.

Low Battery

If the headset battery is discharged, the inline audio function will not work until the battery has been recharged.

Range

Your HT820 headset conforms to Bluetooth power class 2 for a range of 30 feet (10m). The range of the headset is extended to 150 feet (50m) when

Using Your Headset

used with a Bluetooth power class 1 device such as the Motorola DC800 Bluetooth Transceiver or USB PC Adapter PC850 (see next page).

Other Motorola Bluetooth Stereo Products

DC800 Bluetooth Transceiver

•

The Motorola Bluetooth Stereo

Transceiver connects to your

home stereo turning it into a

wireless music system!

•

Listen to music from your phone’s

built-in MP3 player over your

home stereo speakers

•

Play music on your home stereo

and send the music wirelessly to

your Motorola Bluetooth Stereo

Headset HT820

Using Your Headset

•

The Stereo Transceiver supports

high power Bluetooth (Class 1)

which allows you to roam up to

150 feet (50 meters) away while

listening to crystal clear digital

music

•

Stream MP3’s from your home

computer or laptop and play them

over your home stereo speakers

by using the Motorola USB PC

Adapter PC850

Motorola USB PC Adapter PC850

•

Fully Bluetooth 1.2 compliant

•

USB 1.1 connection to PC

•

Speeds up to 720kbps

•

Windows 98SE, ME, 2000, XP

compatible

Using Your Headset

Supports stereo audio, sychronization, file transfer, dial up networking, and other profiles

Using Your Headset

motorola.com

GN Audio USA HT820 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
