GN Audio USA GN6110 User Manual

User guide

Bedienungsanleitung

Guide d’utilisation

Manual del usuario

Guia do utilizador

Istruzioni d’uso

Gebruikershandleiding

Brugsanvisning

Bruksanvisning

Käyttöohje

FIN

xxx

1552-099 Rev.A

GN6110_contents_EU_21-10-03.indd 1 23-10-2003, 09:39:19

English – GN 6110 user guide

This user guide provides you with information on setting up, using and maintaining

your GN 6110.

CONTENTS

1. Product information

1.1 GN 6110 – what’s in the box

1.2 Parts and signatures

2. Assembling your GN 6110

2.1 Setting up for desk telephone use

Connecting cords

Charging headset

Clear dial tone adjustment

2.2 Setting up for mobile telephone use

Pairing

3. Operating the GN 6110

3.1 Operation – with desk telephone

3.2 Operation – with mobile telephone

4. Additional functionality and features

4.1 Volume settings and functions

4.2 Wearing and wearing styles

4.3 Setting up your GN 1000 RHL (accessory)

4.4 Operation with your GN 1000 RHL (accessory)

4.5 Battery charging

4.6 Pairing your headset to the desk telephone

4.7 Reset

4.8 Audio and visual indicators

5. Frequently asked questions

6. Cleaning, safety and maintenance

1. Product information

Congratulations on purchasing the GN 6110, which consists of a base and headset. The

GN 6110 accepts calls from both your desk and mobile phone, letting you answer/make

a call from either your desk or mobile phone via your headset. If using your headset

for a call from your desk phone, an incoming call from your mobile phone will not be

accepted by your headset. If using your headset for a call from your mobile phone, an

incoming call from your desk phone will not be accepted by your headset.

To fully beneﬁ t from your GN 6110, follow the instructions in this user guide step by

step.

1.1 GN 6110 – What’s in the box

1 GN 6110 headset, with built-in

rechargeable battery

2 GN 6110 base (connectivity unit)

3 Connection cord for telephone

connection

4 Power adapter with cord

5 Quick Set Up guide

6 User guide

7 Cord management strips

8 Headset travel charger (90-240 V)

2 3

GN6110_contents_EU_21-10-03.indd 2-3 23-10-2003, 09:39:20

1.2 GN 6110 – Parts and signatures

AUX

1 Power adapter socket 2 Telephone socket 3 Handset socket 4 Hook switch [AUX] socket (accessory) 5 Additional functionality port 6 Volume match dial 7 Microphone volume dial 8 Reset button 9 Clear dial tone termination switch 10 Base Multifunction Button (MFB) 11 Pairing indicator 12 Battery indicator

13 On-line indicator 14 Charging cradle 15 Headset release button 16 Headset boom arm 17 Earhook 18 Charging port 19 Speaker 20 Volume buttons 21 Headset Multifunction Button (MFB) 22 Microphone 23 Headset indicator

2. Assembling your GN 6110

First assemble your GN 6110 to work with your desk telephone, and then set it up to

work with your mobile phone. The GN 6110 supports the GN 1000 Remote Handset

Lifter for desk telephones as well as newer telephones with built-in electronic hook

switches.

See Section 4.3 for hook switch set up instructions and use.

2.1 Setting up for desk telephone use

Connecting cords

To set up your GN 6110, connect the cords by

completing the following instructions:

1. Connect the power adapter cord to the socket

marked 2 [A]. All of the base’s indicators

will ﬂ ash once when power is connected.

2. Unplug your telephone’s handset from the

handset port on the bottom of your tele-

phone and plug its cord into the base’s socket

marked 0 . [C]

3. The blue colored cord will go from the blue

socket on the base back to the now free hand-

set port. [B].

4. Place all cords into the base’s slots to ensure

a fully functional product. [D]

AUX

4 5

GN6110_contents_EU_21-10-03.indd 4-5 23-10-2003, 09:39:21

Note: For your convenience, you may also feed the telephone cord through the

base’s right or left slot, depending if your desk telephone is positioned to the right

or left of the base.

Clear dial tone adjustment

Desk telephones operate on a range of standards. In order for your GN 6110 to work

with your desk telephone and to hear a clear, crisp dial tone, you must set the correct

dial tone setting. Consult the inside back cover of this user guide for the most common

telephone models and settings.

5. Use the cord management strips to fasten and organise the cords. [E]

Charging headset

Before using your headset, charge it for a minimum of

two hours. You may charge the headset by placing it in

the base or with the travel charger cord.

During initial (and subsequent) charging, you may con-

tinue to use your desk telephone as normal.

Complete the following instructions to set the correct dial tone adjustment:

1. Open the compartment cover on the bottom of the base and

locate the termination switch [A].

2. Put on your headset and press the base’s Multifunction but-

ton. An audible tone will shortly be heard.

3. Lift the telephone’s handset from the cradle and listen for a dial tone in your headset.

4. If there is no dial tone or it is not clear, stepwise slide the termination switch

through all 7 settings (along the A-G range), listening for the clearest possible dial

See Section 4.5 for full details on charging batteries and

the battery charge level indication.

Pairing of headset to the desk telephone and verifying

tone. If the dial tone is just as clear in position A as in position G, leave the switch in

position A.

5. When you hear the clearest dial tone, you have located the correct termination set-

ting.

pairing

The headset and the base in their original product box have been factory-paired to

ensure proper functioning of your GN 6110. You do not need to pair these two devices,

and you may now proceed to the Clear dial tone adjustment section.

Microphone volume adjustment

In order to ensure that your voice is neither too loud nor too soft when calling others,

adjust the transmit sound volume. You will need to make a call with your desk tele-

phone to adjust it.

If original pairing is lost (by resetting the base, changing your headset or changing your

base), you will have to pair your headset to the base again. You may also verify pairing

between the headset and base at any point (except during telephone conversations).

See Section 4.6 for these instructions.

Complete the following instructions to adjust the transmit volume:

1. Open the compartment cover on the bottom of the base and

locate the blue microphone volume adjustment button [A].

6 7

GN6110_contents_EU_21-10-03.indd 6-7 23-10-2003, 09:39:21

2. Put on your headset and press the Multifunction Button on the base. An audible

tone will shortly be heard.

3. Lift the telephone’s handset from the cradle and listen for a dial tone in your headset.

4. Using your desk telephone, make a call to someone who will act as your test person.

5. While speaking with your test person, adjust the blue microphone volume adjust-

ment button until he/she hears your voice at an appropriate level.

2.2 Setting up for mobile telephone use

The GN 6110 headset is also compatible with Bluetooth mobile phones. The mobile

phone you use with your GN 6110 must be Bluetooth technology-equipped.

Note: Ensure that the mobile device and

the headset are within 1 metre of each

other. [C]

max

5. When your mobile phone prompts you, enter the following

4-digit passkey code: 0000.

The mobile phone will now begin pairing and store your GN 6110 headset in its

memory. Your mobile phone screen will advise that pairing has been successful.

The headset indicator will rapidly ﬂ ash 10 times, and a beep will be heard in the

headset to indicate successful pairing.

Setting up the headset to a mobile phone (pairing)

Before using your headset for the ﬁ rst time with a mobile

phone, you must pair your headset and mobile telephone

After successful pairing, your headset is ready to use with your mobile phone. Consult

your mobile phone’s user guide for full details on utilising a Bluetooth headset with

your mobile phone.

by completing the following:

1. Press and hold down the Multifunction Button on the

3.0 Operating the GN 6110

headset for 5 seconds, after which the headset indica-

tor will light. [A]

2. Within 3 seconds, open the headset boom arm. The

headset can be paired within the next 5 minutes.

3.1 Operation – with desk telephone

If your headset is in its base, press the release headset button to free the headset before

using it.

3. Put the mobile phone into pairing mode, according to

your mobile phone’s user manual. [B]

Note: Your mobile phone must be Bluetooth-equip-

ped in order to pair it with the GN 6110.

Turning headset ON:

Open the headset boom arm. The headset indicator will light for 2 seconds, and then

continue to ﬂ ash slowly as long as the headset is on.

4. From your mobile phone, perform a device discovery

so that your mobile phone will ﬁ nd your headset and

pair to it. This may take several seconds.

Bluetooth™ is a trademark owned by Bluetooth SIG, Inc. USA and licensed to GN Netcom.

Turning headset OFF:

Close the headset boom arm. The headset indicator will light for 2 seconds, after which

it will turn off.

8 9

GN6110_contents_EU_21-10-03.indd 8-9 23-10-2003, 09:39:22
