GN Audio USA BT130 User Manual
© 2004 GN Netcom A/S. All rights reserved. Jabra is a registered
trademark, wholly owned by GN Netcom Inc., and MiniGels is a
trademark of GN Netcom Inc. in the USA, and these trademarks
may be registered in other countries. US and foreign patents
pending. Design and specifications subject to change without
notice.
The Bluetooth® word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by the companies in
the GN Netcom Group is under license.
www.jabra.com
User manual
Bluetooth Headset
Fig. 1
Fig. 4Fig. 2
Fig. 3
PART NUMBER 00-00000
Fig. 5
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Français
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Español
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1
English
English
Thank you. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1. Charge your headset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Turn on your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
3. Pair it with your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
4. Wear it how you like it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
5. How to... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
6. What the lights mean
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7. Using a Jabra Bluetooth adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
8. Troubleshooting & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
9. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
10. Taking care of your headset
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
11. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
12. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
13. Glossary
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Charge your headset
Make sure that your Jabra BT130 headset is fully charged before you start using it. Use
the AC adapter to charge from a power socket, or charge directly from your PC with
the USB cable provided. Connect your headset as shown in fig. 3. When the LED is solid
blue, your headset is charging. When the solid blue LED turns off, it is fully charged.
1
3
English
The Jabra BT130 is easy to operate. The answer/end button on the headset performs
different functions depending on how long you press it.
Instruction: Duration of press:
Tap Press briefly
Press Approx: 1 second
Press and hold Approx: 5 seconds
2
English
Your Jabra BT130 lets you do all this:
•
Answer calls
•
Voice dialing (phone dependent)
•
End calls
•
Last number redialing
•
Reject calls (phone dependent)
Specifications:
•
Talk time/standby time 4-6 hours talk time (subject to phone), 110 hours standby
•
Rechargeable battery with charging option from AC power supply or car charger
(not included)
•
Weight 18 g
•
Operating range up to 33 feet / 10 m
•
Headset and hands-free Bluetooth profiles
•
Bluetooth1 specification (see glossary) version 1.2
What your headset can do
Getting started
Thank you for purchasing the Jabra BT130 Bluetooth® Headset. We hope you enjoy it!
This instruction manual will get you started and ready to make the most of your headset.
Thank you
Using a mobile phone while driving can distract you and increase the likelihood of an
accident. If driving conditions demand it (such as bad weather, high traffic density,
presence of children in the car, difficult road conditions), pull off the road and park before
making or answering calls. Also, try to keep conversations short and do not make notes or
read documents.
Always drive safely and follow local laws.
Remember, driving comes first, not the call!
!
About your Jabra BT130
1 LED light
Blue indicates mode
(pairing, active or standby)
and battery charging
Red indicates low battery level
2 Volume up (
+
), volume down (
–
)
3 Charging socket
4 Answer/end button
Press to turn headset on
Press and hold to turn headset off
Tap to answer or end a call
Press this, and press volume up (
+
) button at same time, to
put headset in pairing mode
5 Earhook – flip and rotate 180° to fit left ear. (See fig. 2)
Wear it how you like it
4
5
English
The Jabra BT130 is ready to wear on your right ear. If you prefer the left, gently flip and
rotate the earhook 180°. (See fig. 2
)
For optimal performance, wear the Jabra BT130 and your mobile phone on the same
side of your body or within line of sight. In general, you will get better performance
when there are no obstructions between your headset and your mobile phone.
Fun with color – changing your cover plate
•
Remove current plate by pulling from thumbnail slot at top
•
Push new cover plate into place (See fig. 5)
Answer a call
•
Tap the answer/end button on your headset to answer a call
End a call
•
Tap the answer/end button to end an active call
Reject a call (Dependent on your phone supporting this feature)
•
Press the answer/end button when the phone rings to reject an incoming call.
Depending on your phone settings, the person who called you will either be
forwarded to your voice mail or hear a busy signal
Make a call
•
When you make a call from your mobile phone, the call will (subject to phone
settings) automatically transfer to your headset
Activate voice dialing (Dependent on your phone supporting this feature)
•
Tap the answer/end button. For best results, record the voice-dialing tag through
your headset. Please consult your phone’s user manual for more information about
using this feature
Redial last number (Dependent on your phone supporting this feature)
•
Press the answer/end button
Adjust sound and volume
•
Press the volume up or down (
+
or –) to adjust the volume
(See fig. 1)
How to...
5
Before you use your Jabra BT130, you need to pair it with your mobile phone.
1. Put the headset in pairing2 mode
Make sure that the headset is on.
Press the answer/end button and press the volume up (
+
) button at the same time,
until a solid blue light comes on.
2. Set your Bluetooth phone to ‘discover’ the Jabra BT130
Follow your phone’s instruction guide. This usually involves going to a ‘setup,’
‘connect’ or ‘Bluetooth’ menu on your phone and selecting the option to ‘discover’
or ‘add’ a Bluetooth device.* (See example from a typical mobile phone in fig. 4)
3. Your phone will find the Jabra BT130
Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’ or ‘OK’ on
the phone and confirm with the passkey or PIN
3
= 0000 (4 zeros).
Your phone will confirm when pairing is complete. In case of unsuccessful pairing,
repeat steps 1 to 3.
Pair it with your phone
3
4
English
Turn on your headset
2
•
Press the answer/end button to turn on your headset
•
Press and hold the answer/end button to turn off your headset
What the lights mean
6
What you see What this means about your headset
Flashing blue light Flashing every second: active on a call
Flashing blue light Flashing every three seconds: in standby mode
4
Flashing red light Running low on battery
Solid blue light Charging
Solid blue light off Fully charged
Solid blue light In pairing mode – (See section 3
)
7
English
Troubleshooting & FAQ
8
I hear crackling noises
For the best audio quality, always wear your headset on the same side of the body
as your mobile phone.
I cannot hear anything in my headset
• Increase the volume on the headset
• Ensure that the headset is paired with the phone
• Make sure that the phone is connected to the headset – if it does not connect
either from the phone’s Bluetooth menu or by tapping the answer/end button,
follow the pairing procedure (See section 3
)
I have pairing problems even though my phone indicates otherwise
You may have deleted your headset pairing connection in your mobile phone.
Follow the pairing instructions in section 3.
6
English
Using a Jabra Bluetooth adapter
7
If you want to use the Jabra BT130 with a non Bluetooth mobile phone, the Jabra A210
adapter is the answer.
It gives you a cordless connection with the following headset features: answer/end call
and voice dial function (if supported by the phone). Rejecting a call and last number
redial might not be supported through the headset jack in the mobile phone.
To pair the Jabra BT130 with the Jabra A210
The pairing process is a little different:
•
Put your Jabra BT130 in pairing mode
•
Put the Jabra A210 adapter in pairing mode
•
Place them close together. You do not need a dedicated pin code to pair the two
Jabra products. Consult the Jabra A210 user manual for more information
Making/answering a call when using the Jabra A210
•
When you make a call from your mobile phone, the call will automatically transfer
to the headset (if it is turned on)
•
To answer a call: either tap the answer/end button on your headset or press the
answer button on your mobile phone
Need more help?
9
•
Web: www.jabra.com (for the latest support info and online User Manuals)
•
E-mail: Tech Support: techsupp@jabra.com
Information: info@jabra.com
•
Phone: 1 (800) 327-2230 (toll-free in USA and Canada)
Taking care of your headset
10
1. Always store the Jabra BT130 with power off and safely protected.
2. Avoid storage at high temperatures (above 60°C / 134°F) – such as in a hot vehicle
or in direct sunlight. (Storage at high temperatures can degrade performance and
reduce battery life).
3. Do not expose the headset or any of its supplied parts to rain or other liquids.
I cannot use Reject call, Call on hold, Redial or Voice dialing
These functions are dependent on your phone supporting them. Please check your
phone’s manual for further details.
Will the Jabra BT130 work with other Bluetooth equipment?
The Jabra BT130 is designed to work with Bluetooth mobile phones. It can also work
with other Bluetooth devices that are compliant with Bluetooth version 1.1 or 1.2
and support a headset and/or hands-free profile.
Warranty
11
Jabra limited product warranty. Jabra warrants to Purchaser that for a period of one (1)
year after the date of purchase (the “Warranty Period”) of any Jabra Product (“Product”) by
Purchaser, the Product will substantially conform to Jabra’s published specifications for the
Product on the date of Purchaser’s purchase of the Product, subject to the terms herein.
Purchaser shall notify Jabra of any nonconformance during the Warranty Period and obtain
a written return material authorization (“RMA”) and an RMA number for the nonconforming
Product from Jabra and return the nonconforming Product to Jabra, freight prepaid, with
a statement describing the nonconformity. Jabra’s exclusive obligation with respect to
nonconforming Product shall be, at Jabra’s option and expense, to repair or replace such
Product so that it substantially conforms with its published specifications on the date of
Purchaser’s purchase, or, if Jabra, in Jabra’s sole discretion, determines that it is not possible to
repair or replace the Product, Jabra may, at Jabra’s option, refund to Purchaser the purchase
