GN Audio USA BT100 Users manual

Bluetooth Mobile Headset

FOR ALL BLUETOOTH MOBILE PHONES

JABRA BT100 User Manual

English ....................................................................................... 3

English Français

Deutsch ................................................................................. 42

Italiano

Nederlands ......................................................................... 82

Español

2 3

................................................................................. 22

................................................................................... 62

............................................................................... 102

Introduction ....................................................................................................................................................... 4

What’s in the package .................................................................................................................................... 5

JABRA BT100 Bluetooth Headset Features ............................................................................................ 6

Charging & Battery Time .............................................................................................................................. 7

Linking the Headset to the Phone ............................................................................................................ 8

Choosing Right or Left Ear Wearing Style ............................................................................................ 12

Placing the Headset on your Ear ............................................................................................................. 13

Speaker Volume & Volume Control Buttons........................................................................................ 14

Using your JABRA BT100 Headset ........................................................................................................... 15

Resetting the Headset ................................................................................................................................. 17

Audio & Visual Indicators............................................................................................................................ 18

FCC Notice to Users / Product Statements........................................................................................... 20

Safety & General Information.................................................................................................................... 21

Introduction

Any device that you want to use with the JABRA BT100 Bluetooth headset has to be compatible with Bluetooth wireless technology and support the headset profile.To be able to use the headset with a mobile phone, the phone needs to have built-in Bluetooth technology,or a compatible Bluetooth phone adapter.

The JABRA BT100 is a cordless handsfree headset based on Bluetooth wireless technology.Please read the user booklet before you start using the product and make sure that you:

•

Charge your JABRA BT100 headset for up to 2 hours before you use it the first time. (See page 7)

•

Make sure that you pair the headset with your Bluetooth phone (or other device) before you start making calls. (See page 8)

Thank you for choosing to buy the JABRA BT100, we hope that you are happy with your choice!

4 5

What’s in the Package?

Your JABRA BT100 Bluetooth headset package comes equipped with a headset and

charging solution.

In this package you will find:

•

One JABRA BT100 Bluetooth Headset

•

One Headset Mains Charger unit

•

One Headset In-car Charger Unit (Not available in some packages)

•

One JABRA BT100 User Guide

(Please use only the approved and compatible chargers for this device)

JABRA BT100 Bluetooth Headset Features

1. Blue Indicator Light: provides the status

of the headset (on call, standby).

2. Volume Control:adjusts the speaker

(receive) volume.

3. Multifunction Button (MFB): controls

various functions of the headset.

4. Speaker: receiver for the other party’s voice.

5. Microphone: voice input for transmission.

6. Boom: contains the microphone and controls

the power (on/off) status of the headset.

7. Earhook: how the headset is worn on either

ear (turn around for left/right ear).

8. Charging Port: receptacle for battery charger.

Charging & Battery Time

Before you can use your headset, you need to charge the

headset’s self-contained battery for up to two hours.

To charge the headset,please follow this guide:

1. Plug the mains travel charger (or in-car charger) into your headset charging port with the headset facing up.

2. Insert the travel charger’s electrical plug into an electrical outlet, or the in-car charger into the socket in your vehicle.

3. While charging, the blue headset indicator light is on and remains on until charging is complete.

4. When charging is complete, the light will go out, you then remove the charger from the headset.

6 7

A fully charged battery provides up to 3 hours of talktime, and over 2 weeks of standby/off time. 3 hours of talk time,7.5 hours of standby time (Bluetooth data link – no audio), 36 hours of standby time (no Bluetooth link,boom open) and 20 days of storage time (boom closed).

Low Battery Warning Tones: When you hear five rapid high tones through the headset’s speaker at 20-second intervals, the headset needs recharging, and you will then need to follow the above steps 1-4.

Linking the Headset to the Phone (Pairing)

Before you use your headset for the first time,you must first pair the headset with the device you want to use it with – for example – a mobile phone.The Bluetooth connection between the headset and your phone can be established by setting up a paired link.With a paired link, the phone remembers the headset's ID, and these 2 items are then ‘paired’ together - eliminating the need to repeat the set up process with future use.Only paired devices can utilize Auto-Answer™ and Auto-Transfer™ functions.

Please use the following easy to follow guide –

8 9

a) Configuration Mode

Before you can pair your headset you need to put it into configuration mode. Configuration mode is used to perform two functions – ‘pairing’ and Audio mode selection. Configuration mode is entered simply by pressing and holding down the Multi-Function Button (MFB) with the headset boom closed until the Blue indicator light turns on, then release the MFB. The LED will remain on.The headset is now in configuration mode and stays in this mode for 3 seconds awaiting further user action. The headset will then return to the “off” state if no further action is taken.

b) Pairing Headset to the Phone

1. With the headset boom closed and the headset close to the phone (within 30 feet), enter configuration mode as described above. During pairing it is recommended that the headset and phone (or device) are not more than 1metre (3 feet) apart – with no solid objects in between.

2. Within the 3 seconds, open the boom.The LED will remain on and the headset is now in pairing mode and will remain in pairing mode for 5 minutes.

Perform a “device discovery” from the mobile phone. For details on device discovery consult your phone user guide. Please Note: it may take several seconds to establish connections.

3. Enter the passkey 0000 , when your phone menu prompts you, and the phone will start to pair the headset with the phone (the device ID is now stored in the phone’s memory).

4. Your phone screen will advise that pairing has been successful, and the headset indicator light flashes to let you know this also.

5. If the pairing is unsuccessful. Please return to step 1 and follow the steps 1-4.

6. Once the headset and phone have successfully paired you are ready to place and receive calls (see page 15 “Making a Call”).

7. Please note that once paired the first time, the headset automatically connects to your phone upon opening the boom. (Note: The default headset passkey is 0000.)

c) Two Paired Devices (Audio Mode1/Audio Mode2 Operation)

It is possible for your headset to store pairing data with two different Bluetooth devices.This means that you could have two Bluetooth phones paired, or 1 phone and 1 other device. Operation of the headset in Audio Mode1 will recall the last device that the headset paired to while in Audio Mode1. Similarly, operation in Audio Mode2 will recall the last device that the headset paired to while in Audio Mode2.

To toggle between audio modes, simply follow the procedure below.

1. Starting with the boom in the closed position, enter Configuration Mode as described on page 9.

2. With boom still closed, and the indicator light on solid (indicating Configuration Mode) press either Volume button.

3. Watch the indicator light (one flash for Audio Mode1 or two flashes for Audio Mode2, then off).

4. Open boom and verify repeated indicator light flash signal. (Single flash for Audio Mode1, double flash for Audio Mode2).

5. Now the headset is ready for use in the selected mode, just follow pairing the headset on page 9.

Choose Right or Left Ear Wearing Style

The JABRA BT100 Bluetooth headset comes configured for wearing on your right ear. To change for left ear wearing please use the simple instructions as follows:

1. Open the boom.

2. Put the earhook in its open position.

3. Gently lift and pull the top of the earhook up from the upper hinge pin and pull away to remove.

4. Turn the headset over.

5. Hook the bottom of the earhook on to the lower hinge pin and lift and pull the top of the earhook over the upper hinge pin.

6. The Volume Up/Down buttons will re-orient automatically – so up will always be up,and down will always be down.

12 13

Placing the Headset on your Ear

In order to wear the headset please follow these instructions:

1. Open the boom.

2. Put the earhook in its open position (90° away from the headset).

3. Loop the ear hook behind your ear.

4. Close the headset towards your ear.

5. The boom will then point towards your mouth.

Speaker Volume & Volume Control Buttons

To increase the speaker (receive) volume, press and hold the upper volume control button until the desired level is reached.To decrease the speaker (receive) volume,press and hold the lower volume control button until the desired level is reached. An audible tone is played when either the minimum or maximum volume has been achieved.

The headset is equipped with intelligent volume re-orientation control so that it does not matter whether you are wearing the headset on the left or right ear. When you change the earhook from right to left wearing style - the top volume control button will always increase the speaker volume and the bottom volume control button will always decrease the speaker volume.

14 15

Using your JABRA BT100 Headset

a) Making a call with the headset

There are different ways to make a call using your JABRA BT100 headset.(In each case you will need to make sure that you pair / link your headset and phone as described on page 9.)

If your mobile phone supports voice dialing, you can use this feature with the headset. Please refer to your phone’s user documentation for more information on voice control.

Making a call from the Mobile Phone

1. Place the headset on your ear in the desired wearing style.

2. Using the phone’s keypad, dial the phone number.

3. To send the call,press the phone’s SEND / CALL key – the phone initiates the call.

Making a call Using Voice Dialing (Voice dialing on your phone must be turned On and voice tags stored)

1. Place the headset in the desired wearing style.

2. On the Headset - Press the Multi Function Button. (MFB)

3. A tone prompts you to say the name of the person you wish to call (as entered in

the phone’s voicedial phonebook directory).

4. Speak the voice tag name.

5. The phone automatically dials your selection, and you see the details of the call on the phone screen.

6. When connected you are free to communicate normally.

(Please refer to the phone’s user guide for instructions on storing voice tags. Some Mobile Phones need you to initiate voice dialing from the handset.)

b) Ending a call from the headset

To end a call when wearing the headset - press the headset’s MFB button. Also if you remove the headset – the call can also be ended by closing the boom arm.

c) Disconnecting your Bluetooth link

To terminate the Bluetooth connection between the headset and your phone, turn the headset Off (just close the boom). If you are on a call when the boom is closed, the call will be held at the phone for up to 30 seconds while the user is prompted to transfer the call back to the phone.Without a response by the user, the call will be terminated after the 30 seconds.

d) Receiving/ Answering a call

When wearing the headset - On and Linked:

A ring tone will sound in your headset, just press the headset’s MFB button to answer the call.

16 17

If not wearing the headset – Off position (boom closed):

Open the headset’s boom to auto-answer the call through to the headset, then place the headset on your ear in the normal wearing position.

e) Transferring a Call

Transferring a call from the headset to your phone:

Must be initiated by the phone (refer to the user guide that accompanied your phone).

Transferring a call from your phone to the headset:

•

Open the boom to activate the Auto-Transfer feature,

•

If boom is already open and the call is on the mobile phone, press the headset’s MFB button.

Resetting the headset

If the phone and headset fail to communicate properly,you may need to reset them.To reset the headset, plug charging jack into headset with charger pulled into appropriate AC socket. Verify the LED turns on,indicating the start of charging, then remove charging jack. This resets the headset.

Audio & Visual Indicators

Indicator Light Chart

Headset State LED Indication State

Power Off LED OFF (no charger)

Charging In Process LED ON (charger plugged in)

Charging Complete LED OFF (charger plugged in)

Configuration Mode LED ON (no charger) with boom closed

Pairing Mode LED ON (no charger) with boom opened

Pairing Successful Series of 10 rapid flashes

Search, Park, Link Flash or Double-Flash 0.1 sec ON, 2.9 sec OFF

(pulse with 3 second interval)

Audio Link (on a call) Flash or Double-Flash 0.5 sec ON,1.5 sec OFF

18 19

Audio Indicator Chart

Headset State Audio Indication

Volume Limit Repeated single high tone when either lower or

upper limit achieved

Low Battery Tone Five rapid high tones repeated every 20 seconds

Out of Range No audio indications, deterioration of audio quality

will alert user

Incoming Call Ring tone

Pairing Confirmation Single high tone

Establish Audio Link Series of 4 tones, low to high

Initiate Voice Dial Single low tone

Voice Tag not Recognized Dual high-low tone

End Call/Audio Link Closed Series of 4 tones, high to low

Power On/OFF No audible tone

FCC Notice to Users / Product Statements

This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received,including interference that may cause undesired operation.

Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by JABRA (GNNetcom) will void the user’s authority to operate the equipment.

BLUETOOTH is a trademark owned by the Bluetooth SIG, Inc.

20 21

SAFETY AND GENERAL INFORMATION

Electro Magnetic Interference / Compatibility – Note : Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic compatibility.

Aircrafts & Hospitals – Please switch OFF the headset before boarding any aircraft to prevent interference with the aircraft communication systems. Also please switch OFF the headset in any facility where posted notices instruct you to do so. Hospitals and Healthcare facilities may be using equipment that is sensitive to EMI .

Warranty – Thank you for choosing to buy this JABRA product. JABRA (a GNNetcom Company) warrants the product to be free from defects in material and workmanship at the time of purchase by the consumer,for a subsequent period of 24 months. Please make sure that you carefully read the instruction booklet in order to have safe and efficient use. Also save your original receipt.You will need to present the original receipt for warranty and repair claims. Should you need to do this please return to the supplier for full details of the warranty process.
