INDEX
Product Description .......................................................................................................................03
Warranty of the Equipment............................................................................................................ 03
General Data .................................................................................................................................04
Technical Specifications ................................................................................................................ 05
Symbols ......................................................................................................................................... 06
Dimensions .................................................................................................................................... 07
Operation ....................................................................................................................................... 08
Maintenance ..................................................................................................................................08
Precautions ...................................................................................................................................09
Cleaning .........................................................................................................................................10
Troubleshooting ............................................................................................................................10
Final Considerations ...................................................................................................................... 10
2
DEAR CUSTOMER
Congratulations. You have made a good choice when you decided to buy a GNATUS QUALITY
product comparable to the best products available in the World. This manual is a general presentation of
your product and it will give you important details to help you to solve possible problems.
Please, read it and keep this with you.
PRODUCT DESCRIPTION
Dental light for dental use with gradual adjust of intensity 08.000 - 25.000 Lux through the foot control of the
odontologic chair.
intensity, smooth movement, and standard ice color compatible with all environments.
Head made of resistant material, with a rotation of 620O, propitiating lightness, durability, and ample mobility in
all positions. Activation through the foot control of the Dental Chair, optimizing biosafety.
Bilateral handle shaped grips enable isolation preventing the risk of cross contamination.
Multifaceted mirror with multicoating treatment, generating innumerable light sources, avoiding shadows
created by interpositions. Mirror protector in a resistant, transparent material protecting against aerosols.
Arm in steel with vertical and horizontal movement with rounded edges, smooth paintwork for easy aseptic
cleaning.
ISO 9001/2000 and ISO 13485/2003 Quality System, assuryng the products are manufactured under
standart procedures.
Products manufactured in agreement with RDC-59 - ANVISA (Sanitary Surveillance National Agency)
with guarantees accomplishiment to the sanitary legislation according to BPF (Good Manufacturing
Procedures). In order to comply with directive 93/42/EEC for CE Mark purpose, it is defined that the life
span of this product is estimated in 05 years provided that the enduser follows the requirements and
instructions of this manual.
IMPORTANT: This equipment is for dental use use only. It must be operated and utilized by specialized
professional (certified professional, according to the legislation of the country) and following the
instructions of the manual. The operation of the equipment required, for the professional, the utilization
of correct instruments and it should to be in perfect conditions of the use, and to protect the professional,
the patients and others, in the eventual danger situation.
• This equipment can’t be used in the presence of inflammable anesthetics or products that may
cause explosion.
• After finish life-cycle of the equipment, this equipment is throw way, so it should to be destroyed
in appropriate area (according to the legislation of the country).
•To guarantee the safe functioning of your equipment, use only the assemble configurations (Dental Chair,
Dental and Water Units and Dental Light) supplied by Gnatus authorized Dealers / Technical Assistance.
WARRANTY OF THE EQUIPMENT
This warranty covers product’s manufacturing faults for the warranty period and standards specified
on the Warranty Certificate. The Warranty Certificate is attached to product, and must be completed by
the authorized Gnatus technician when equipment is installed.
Doubts and information: GNATUS Call center+ 55 (16) 2102-5000.
3
GENERAL DATA
Maintenance of the equipment
The equipment doesn’t need preventive maintenance, however when there is any problem that this
manual can’t solve, ask for an authorized Gnatus technician.
List of pieces and circuit scheme
Gnatus Company declares that the supply of the cir-cuit scheme, list of pieces or any other information
that propitiate technical attendance for the user, can be request if there is an agreement between the
user and Gnatus Company.
4
GENERAL DATA
Dental light Persus L
03
02
04
05
TECHNICAL SPECIFICATIONS
Dental light Persus L
• Supply voltage
11V~ and 12V~ (from the
Dental Chair)
• Luminosity
08.000 / 25.000 LUX ±20%
• Net weight
11,50 Kg
• Gross weight
14,90 Kg
01
01 - Protector
02 - Handle
03 - Articulate arm
04 - Column arm
05 - Column
• Lamp
H3 12V 55W
• Distance between the
headstock and the operative
field
70cm
5
TECHNICAL SPECIFICATIONS
Special providence or particular conditions for installation
- Check the electric net, it must be compatible with the specified one in the equipment.
- Verify the thread earth, it must be turned off correctly.
- Verify the general key of the equipment in the position “0”.
OBS: These information also make part of the Manual of Installation and Maintenance of the equipment
that can be found with the authorized Gnatus technician.
Transport and storage conditions
The equipment must be transported and stored with the following observations:
- Carefully, should not suffer drop and neither receive impact.
- With the side of the arrow upward.
- With humidity protection, not to expose to rains, sparkling of water or humidified floor.
- With maximum piling up of 12 units for storage.
Content of acessible and nonacessible demarcations
Product symbols
Warning - see
the manual
Packing symbols
12
Packing to be stored with a
maximum stack of 12 units.
Packing to be transported and / or
stored with the harrows up.
Packing to be transported and / or
stored with care (should not suffer drop
and neither receive impact).
Warning
Landing (in many parts of the
equipment) indicates the condition of
being landed.
Packing to be transported and / or
stored avoiding humidity, rains and wet
floor.
The packing must be stored and
transported away from direct sun light
exposure.
Temperature limit for the packing
to be stored or transported.
6
TECHNICAL SPECIFICATIONS
Dental light Persus L
Dimension (mm)
7
OPERATION
How to turn on the dental light
(Foot control with 7 functions)
To turn-on the Dental Light, press the button (07).
To modify the luminosity, keep it pressed. The
luminosity will increase or diminish gradually of
(08.000 - 25.000 lux). To turn-off, activate the button
(07) again.
How to turn on the dental light
(Foot control with 11 functions)
To turn-on the dental light in the maximum
luminosity press the button (14). To turn it off, press
this button again. To change the luminosity level
press button (13) and keep it pressed. The
luminosity will increase or diminish gradually,
8.000 lux to 25.000 lux. To turn it off press button
(13) again.
07
13 14
Movement of the headstock
The movement of the headstock is made
through the knob (02), totally ergonomic designed
to provide absolute isolation.
IMPORTANT:
Position the headstock 70cm of the operative
field.
02
MAINTENANCE
Recommendations for the dental equipment maintenance.
Your Gnatus equipment has been designed and developed according to the standards of modern
techology. Similarly to other kinds of equipment, it requires special care, which is many times neglected
due to several reasons and circunstances.
Therefore, here are some important reminders for your daily routine. Try to follow these simple rules,
which will save you a lot of time and will avoid unnecessary expenses once they start making part of your
working procedure.
8
MAINTENANCE
Precautions
- Certify the correct voltage when you switch on your apparatus at the electricity.
- Install your apparatus on aproper place protected by solar rays and humidity.
- Whenever off duty turn off the main switch.
How to change the dental light
12
09
10
11
01
01
13
• Turn off the general key of the Syncrus dental chair or turn off the circuit breaker;
• Verify if the dental light is cold;
• Using a screwdriver (12) remove the protection (01) by softly releasing the latch (13) in the direction
shown by the arrow (right).
• In an unclowise job, remove the deflector (11) and pull the lamp out (10) with care, only till locate
terminals (09);
• Only after that, disconnect the terminals and substitute the lamp.
ATTENTION:
Never touch the light bulb with the fingers. Use a handkerchief.
Cleansing of the protector
IMPORTANT: The cleansing of the light’s protector (01), should only be done using a waterdampened flannel or cotton. Do not use chemicals of any sort, for it may stain the protector.
9
MAINTENANCE
Cleaning the equipment
To clean the equipment, we recommend the use of “BactSpray (Reg nº MS:
3.2079.0041.001-5) or any other similar product:
Active component: Benzalkonium chloride (tri-quaternary ammonium)
Chemical composition: Butyl Glycol, Decyl polyglucose, Sodium Benzoate, Sodium
Nitrate, Essence, Deodorized Propane / Butane, demineralized Water.
For more information concerning cleaning procedures, see manufacturer’s
instructions.
WARNING:
• In order to prevent risks and damages to equipment, make sure that the liquid does
not enter into the unit.
• The application of other solvent-based cleaning products or sodium hypochloride
isn’t recommended, because they may damage the equipment.
Solution 50%................................................. 0.329%
TROUBLESHOOTING
Troubleshooting:
- The Dental Light does not turn
on.
ATTENTION:
Any other problem that could happen with its equipment, should only be repaired by an authorized
technician Gnatus.
The bad use, negligence or maintenance not made by technician authorized by the maker, will imply
in the loss of the warranty.
Probable Causes Solution:
- Power failure.
- Burnt fuse of the dental chair.
- Burnt lamp.
- Wait for power to return.
- Replace the fuse of the
dental chair.
- Replace the lamp.
FINAL CONSIDERATIONS
The most important aspect related to equipment care is that concerning spare parts.
To guarantee the life span of your equipment, use only original Gnatus spare parts. They are sure
to follow the technical specifications and standards required by Gnatus.
We must also point out to you our chain of authorized dealers. Only dealers that make part of this
chain will be able to keep your equipment constantly new for they count on technical assistants who have
been trained and on spedific tools for the correct maintenance of your equipment.
Doubts and information: GNATUS Call center (55-16) 2102-5000.
