Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
2014 Acadia, Acadia Denali, Enclave, Traverse
Infotainment System M
Infotainment System .. . . . . 3
Introduction . . . . . . . . . . . . . . . . . 3
Infotainment . . . . . . . . . . . . . . . . . . . . 3
Overview . . . . . . . . . . . . . . . . . . . . . . . 5
Steering Wheel Controls . . . . . . . 8
Using the System . . . . . . . . . . . . . . 9
Software Updates . . . . . . . . . . . . . 15
Radio . . . . . . . . . . . . . . . . . . . . . . . 16
AM-FM Radio . . . . . . . . . . . . . . . . . 16
HD Radio Technology . . . . . . . . . 19
Satellite Radio . . . . . . . . . . . . . . . . 20
Pandora Internet Radio . . . . . . . 21
Stitcher Internet Radio . . . . . . . . 25
Pictures . . . . . . . . . . . . . . . . . . . . . . . 29
Audio Players . . . . . . . . . . . . . 30
CD/DVD Player . . . . . . . . . . . . . . . 30
MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . 33
USB Port . . . . . . . . . . . . . . . . . . . . . . 36
Auxiliary Devices . . . . . . . . . . . . . . 41
Bluetooth Audio . . . . . . . . . . . . . . . 42
Rear Seat Infotainment . . . 42
Rear Seat Entertainment (RSE)
System . . . . . . . . . . . . . . . . . . . . . . 42
Navigation . . . . . . . . . . . . . . . . . 52
Using the Navigation
System . . . . . . . . . . . . . . . . . . . . . . 52
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Navigation Symbols . . . . . . . . . . . 55
Destination . . . . . . . . . . . . . . . . . . . . 56
OnStar
®
System . . . . . . . . . . . . . . 65
Settings . . . . . . . . . . . . . . . . . . . . . . . 66
Global Positioning
System (GPS) . . . . . . . . . . . . . . . 76
Vehicle Positioning . . . . . . . . . . . . 76
Problems with Route
Guidance . . . . . . . . . . . . . . . . . . . . 77
If the System Needs
Service . . . . . . . . . . . . . . . . . . . . . . 77
Map Data Updates . . . . . . . . . . . . 77
Database Coverage
Explanations . . . . . . . . . . . . . . . . . 78
Voice Recognition . . . . . . . . 78
Bluetooth Phone/
Devices . . . . . . . . . . . . . . . . . . .
85
Bluetooth . . . . . . . . . . . . . . . . . . . . . 85
Text Messaging . . . . . . . . . . . . . . . 97
Trademarks and License
Agreements . . . . . . . . . . . . .
101
Index . . . . . . . . . . . . . . . . . . . . . i-1
Black plate (2,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Black plate (3,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 3
Introduction
Infotainment
The names, logos, emblems,
slogans, vehicle model names, and
vehicle body designs appearing in
this manual including but not limited
to GM, the GM logo, GMC, the GMC
Truck Emblem, BUICK, the BUICK
Emblem, CHEVROLET, the
CHEVROLET Emblem, and the
names ACADIA, ACADIA DENALI,
ENCLAVE, and TRAVERSE are
trademarks and/or service marks of
General Motors LLC, its
subsidiaries, affiliates, or licensors.
The information in this manual
supplements the owner manual.
This manual describes features that
may or may not be on your specific
vehicle either because they are
options that you did not purchase or
due to changes subsequent to the
printing of this owner manual.
Please refer to the purchase
documentation relating to your
specific vehicle to confirm each of
the features found on your vehicle.
For vehicles first sold in Canada,
substitute the name “General
Motors of Canada Limited” for GMC,
Buick, and Chevrolet Motor
Divisions wherever it appears in this
manual.
Keep this manual with the owner
manual in the vehicle, so it will be
there if it is needed. If the vehicle is
sold, leave this manual in the
vehicle.
Read the following pages to
become familiar with the
infotainment system features.
The infotainment system has built-in
features intended to help with this
by disabling some functions when
driving. A grayed-out function is not
available when the vehicle is
moving.
Litho in U.S.A.
Part No. 23107737 B Second Printing
©
2013 General Motors LLC. All Rights Reserved.
Black plate (4,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
4 Infotainment System
All functions are available when the
vehicle is parked. Before driving:
.
Become familiar with the
infotainment system operation,
buttons on the faceplate, and
touch-sensitive screen buttons.
.
Set up the audio by presetting
favorite stations, setting the
tone, and adjusting the
speakers.
.
Set up phone numbers in
advance so they can be called
easily by pressing a single
button or by using a single voice
command for vehicles equipped
with phone capability.
{
Warning
Taking your eyes off the road for
too long or too often while using
the infotainment or navigation
system could cause a crash.
(Continued)
Warning (Continued)
You or others could be injured or
killed. Do not give extended
attention to these tasks while
driving. Limit glances at the
vehicle displays and focus your
attention on driving. Use voice
commands whenever possible.
See “Defensive Driving” in the
owner manual.
The vehicle has Retained
Accessory Power (RAP). With RAP,
the audio system can be played
even after the ignition is turned off.
See “Retained Accessory Power
(RAP)” in the owner manual.
Canadian Vehicle Owners
(Propriétaires des Véhicules
Canadiens)
A French language copy of this
manual can be obtained from your
dealer or from:
On peut obtenir un exemplaire de
ce guide en français auprès du
concessionnaire ou à l'adresse
suivante:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
Numéro de poste 6438 de langue
française
www.helminc.com
Black plate (5,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 5
Overview
The infotainment system is controlled by using the buttons, touch screen,
steering wheel controls, and voice recognition.
See Using the System on page 9.
CD Radio Shown, CD/DVD Radio Similar
1. PUSH/
O (Volume/Power)
2.
Z (Eject)
3. CD/DVD (if equipped) Slot
4. AUX Port
5. PUSH/SEL (Select)
6.
D (Home Page)
7. SRCE (Source)
8. FAV (Favorites Menu)
9.
© SEEK (Previous/Reverse)
10. SEEK
¨ (Next/Forward)
11.
/ BACK
Black plate (6,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
6 Infotainment System
CD Radio with Navigation Shown, CD/DVD Radio with Navigation Similar
1. PUSH/
O (Volume/Power)
2.
Z (Eject)
3. AUX Port
4. PUSH/SEL (Select)
5.
D (Home Page)
6. SRCE (Source)
7. SEEK
¨ (Next/Forward)
8.
© SEEK (Previous/Reverse)
9. RPT (Repeat)
10. NAV (Navigation)
11. DEST (Destination)
12.
/ BACK
Infotainment Controls
PUSH/O (Volume/Power):
.
Press to turn the system on
and off.
.
Turn to adjust the volume.
Z (Eject): Press to eject a disc
from the CD or DVD player (if
equipped). See CD/DVD Player on
page 30.
AUX Port: 3.5 mm (1/8 in)
connection for external audio
devices.
PUSH/SEL (Select):
.
Turn to manually find a station or
highlight a menu selection.
.
Press to select a highlighted
selection.
D (Home Page): Press to go to
the Home Page. See “Home Page”
in this section.
SRCE (Source): Press to change
the audio source to AM, FM,
SiriusXM
®
(if equipped), Pandora®,
Black plate (7,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 7
Stitcher™, CD/DVD (if equipped),
USB, iPod
®
, AUX, or Bluetooth
®
Audio.
FAV (Favorites Menu) (Radios
without Navigation): In AM, FM,
or SiriusXM, press to scroll through
the favorites banner. The stored
stations for each list display on the
bottom of the screen. To store a
favorite station, press and hold on
the desired position on the banner
until a beep is heard.
Favorite Pages
Under the Home screen Settings
menu, press Favorite Pages to
select the number of favorite pages
displayed on the screen. The choice
is 1–6 pages.
The number of preset favorite pages
can be changed by pressing the
Settings button on a Home Page,
then pressing Favorites Pages, and
then selecting the number of favorite
pages.
DEST (Destination):
.
Press to enter a destination.
.
If a destination has already been
entered, press to access the
Destination Menu. See
Destination on page 56.
NAV (Navigation):
.
Press to view the vehicle's
current position on the map
screen.
.
Continue pressing to cycle
through the full map and split
screens.
RPT (Repeat): Press to repeat the
last voice guidance prompt.
© SEEK (Previous/Reverse):
.
AM, FM, SiriusXM (if equipped):
Press to seek to the previous
strong station. Press and hold to
scan. Press
© SEEK again to
stop the scan.
.
CD, USB, Pandora, Stitcher,
Bluetooth Audio: Press to seek
to the beginning of the current or
previous track.
.
CD, USB, Bluetooth Audio:
Press and hold to quickly
reverse through a track. Release
the button to return to playing
speed. See CD/DVD Player on
page 30, USB Port on page 36,
or Bluetooth Audio on page 42.
SEEK
¨ (Next/Forward):
.
AM, FM, SiriusXM (if equipped):
Press to seek to the next strong
station. Press and hold to scan.
Press SEEK
¨ again to stop
the scan.
Black plate (8,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
8 Infotainment System
.
CD, USB, Pandora, Stitcher,
Bluetooth Audio: Press to seek
or skip the next track or
program.
.
CD, USB, Bluetooth Audio:
Press and hold to fast forward
through a track. Release the
button to return to playing
speed. See CD/DVD Player on
page 30, USB Port on page 36,
or Bluetooth Audio on page 42.
/ BACK: Press to return to the
previous screen in a menu.
Language
To change the language of the
navigation screens, see “Vehicle
Personalization” in the owner
manual.
English or Metric Units
To change the navigation screens
from English or metric, see “Driver
Information Center (DIC)” in the
owner manual.
Steering Wheel Controls
Vehicles with audio steering wheel
controls could differ depending on
the vehicle's options. Some audio
controls can be adjusted at the
steering wheel.
w or c /x (Next/Previous):
Press to select preset or favorite
radio stations, select tracks on a
CD/DVD, or select tracks.
To select tracks on an iPod or USB:
.
Press and hold w or c / x
while listening to a song listed in
the main audio page to quickly
move forward or in reverse
through the tracks.
.
Track information is displayed on
the screen. Release
w or c
/x when the desired track is
reached.
b /g (Mute/Push to Talk):
.
Press to make or accept a call.
.
Press to initiate voice
recognition.
.
Press and hold to silence the
vehicle speakers only.
.
Press and hold again or adjust
the volume using the up and
down arrows to turn the
sound on.
See Voice Recognition on page 78
for more information.
c /x (End): Press to reject an
incoming call, or end a current call.
Black plate (9,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 9
SRCE (Source): Press to switch
between the radio, CD, and for
equipped vehicles, DVD, front
auxiliary, rear auxiliary, Pandora,
Stitcher, and iPod/USB.
¨ (Seek): Press to go to the next
radio station while in AM or FM.
Press
¨ to go to the next track or
chapter while sourced to the CD or
DVD slot.
When connected, press
¨ to select
a track on an iPod or USB device.
1. Press and hold
¨ until a beep is
heard to place the radio into
scan mode. A station will play for
five seconds before moving to
the next station.
2. To stop the scan function, press
¨ again.
3. In CD/DVD, iPod, or AUX USB,
press and hold to quickly move
forward through the tracks.
Release to stop on the desired
track.
+
e or − e (Volume): Use to
increase or to decrease the volume.
Using the System
The infotainment system is
controlled by touching the screen
and by using the knobs and other
buttons.
Voice recognition, through the
steering wheel controls, can be
used to control the infotainment
features.
Press
b / g on the steering wheel
controls to begin voice recognition.
See Voice Recognition on page 78.
For vehicles with Bluetooth through
the OnStar
®
system, press to
interact, then say “OnStar.” See
Bluetooth on page 85. See ”OnStar
Overview” in the owner manual.
Home Page
The infotainment system displays a
Home Page to access all of the
applications.
Back: Press to go back to the
previous page or menu.
Home: From any page, press to
cycle through the Home Pages to
start a different application. The
Home Page can have up to three
pages with eight icons per page.
Each of these pages can be
customized to contain your choice
of icons. They may also be
re-ordered on each screen
according to your preference.
Black plate (10,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
10 Infotainment System
FAV (Favorites): Keep pressing to
scroll through the favorites banner.
The stored stations for each list
display on the bottom of the screen.
To store a favorite station, press and
hold on the desired position on the
banner until a beep is heard.
! (Voice Recognition): Press to
begin voice recognition. See Voice
Recognition on page 78. Press and
hold to mute the radio.
Menu: Press to enter the Home
Page menu.
Next
r : Press to go to the next
Home Page.
q Previous: Press to go to the
previous Home Page.
Home Page Customization
All three Home Pages can be
individually customized.
To change screen buttons on the
current Home Page:
1. Press Menu.
2. Press Customize Home Page.
3. Press a screen button to add or
remove from the first Home
Page. A checkmark indicates it
will be displayed. The maximum
number of buttons on any Home
Page is eight.
4. Press Done.
To re-order buttons on the current
Home Screen:
1. Press Menu.
2. Press an icon to move it.
3. Press another icon to swap the
position with the icon pressed in
Step 2.
4. Press Done.
To restore Home Page defaults:
1. Press Menu.
2. Press Restore Home Page
Defaults.
Home Page Features
Some features are disabled when
the vehicle is moving and some
icons may not be active.
Touch screen buttons are
highlighted in color when available
or grayed-out when not available.
Various functions are disabled when
the vehicle is moving.
Black plate (11,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 11
Press the Now Playing screen
button to display the active source
page. The sources available are
AM, FM, SiriusXM (if equipped), CD,
USB/iPod, Pandora (if equipped),
Stitcher, and AUX.
See AM-FM Radio on page 16,
Satellite Radio on page 20, CD/DVD
Player on page 30, USB Port on
page 36, Pandora Internet Radio on
page 21, Stitcher Internet Radio on
page 25, and Auxiliary Devices on
page 41.
Press the Navigation screen button
to display a map of your current
vehicle position. See Using the
Navigation System on page 52,
Maps on page 55, Navigation
Symbols on page 55, Destination on
page 56, and Settings on page 66.
Press the Destination screen button
to display the Destination Entry
home page or the Destination Menu.
The available screen buttons
provide easy access to a variety of
ways to enter a destination. See
Destination on page 56.
Press the Text Messaging screen
button to display a pop-up message
display stating, “Retrieving
Messages.” Once messages are
retrieved, select a message for
viewing, or press the Sent screen
button to view a listing of sent or
received messages. See Text
Messaging on page 97.
Press the Phone screen button to
display the Phone main page. See
Bluetooth on page 85.
Black plate (12,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
12 Infotainment System
Press the Settings screen button to
display the Settings main page.
From this display, adjust features
such as time and date, radio,
phone, navigation, audio prompts,
display, etc. See Settings on
page 66.
Press the Tone screen button to
display the Tone main page. Adjust
the tone and speaker ’s balance by
pressing the screen buttons. There
are options such as EQ (equalizer),
Bass, Middle, Treble, and Balance.
See AM-FM Radio on page 16.
Press the Picture Viewer screen
button to view pictures on your USB
drive or SD card. Pictures on the SD
card can only be viewed through a
USB adapter. See Pictures on
page 29.
Press the FM screen button to
display the FM main page and play
the current or last tuned FM station.
See AM-FM Radio on page 16.
Press the AM screen button to
display the AM main page and play
the current or last tuned AM station.
See AM-FM Radio on page 16.
Press the XM screen button (if
equipped) to display the XM main
page and play the current or last
tuned SiriusXM channel. See
Satellite Radio on page 20.
Black plate (13,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 13
Press the Pandora screen button (if
equipped) to display the Pandora
home page and stream
personalized radio stations based
on artists, songs, genres, and
comedians. See Pandora Internet
Radio on page 21.
Press the Stitcher screen button (if
equipped) to display the Stitcher
home page and stream news,
sports, and entertainment shows
through the audio system. See
Stitcher Internet Radio on page 25.
Press the CD screen button to
display the CD main page and play
the current or last CD track
selected. See CD/DVD Player on
page 30.
Press the E Bluetooth screen button
to display the Bluetooth Audio main
page to play music through a
Bluetooth device. See Bluetooth
Audio on page 42.
Press the iPod screen button to
display the iPod main page and play
the current or last track selected.
See USB Port on page 36.
Press the USB screen button to
display the USB main page and play
the current or last track selected.
See USB Port on page 36.
Black plate (14,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
14 Infotainment System
Press the Front AUX screen button
to access any connected auxiliary
device. See Auxiliary Devices on
page 41.
Press the optional Rear AUX screen
button to access a connected
auxiliary device such as a DVD for
rear seat entertainment playback.
See Rear Seat Entertainment (RSE)
System on page 42.
Press the Weather screen button (if
equipped) to display the Weather
main page. Select other
weather-related options from that
list. See “Weather (If Equipped)”
under Settings on page 66.
Press the Traffic screen button (if
equipped) to display the Traffic main
page. Select other traffic-related
options from that list. See
“SiriusXM
®
NavTraffic (If Equipped)”
under Settings on page 66.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
For vehicles with high gloss
surfaces or vehicle displays, use a
microfiber cloth to wipe surfaces.
Before wiping the surface with the
microfiber cloth, use a soft bristle
brush to remove dirt that could
scratch the surface. Then use the
microfiber cloth by gently rubbing to
clean. Never use window cleaners
or solvents. Periodically hand wash
the microfiber cloth separately,
using mild soap. Do not use bleach
or fabric softener. Rinse thoroughly
and air dry before next use.
{
Caution
Do not attach a device with a
suction cup to the display. This
may cause damage and would
not be covered by the vehicle
warranty.
Black plate (15,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 15
Software Updates
The vehicle may require updates
downloaded from the GM website.
Log into the website with either a
new username and password, or an
existing OnStar.com username and
password. Periodically check the
website for software updates. These
updates can provide feature
enhancements, new features, and
support for new devices. Detailed
instructions will be provided on the
website. After the update is saved to
the USB drive, save the update to
the vehicle. Your dealer may need
to be contacted to complete the
software update.
After the update, Bluetooth devices
will need to be re-paired and USB
devices may need to be re-indexed.
All stored navigation addresses will
be erased.
To update:
1. Place the vehicle in P (Park),
start the engine, and turn the
radio on. The engine must be
running until the update is
completed.
2. Insert the USB drive into the
USB port.
3. Choose Update to proceed or
Dismiss to cancel the update.
4. The radio will search the USB
drive for software and verify the
update.
5. The radio will also show the
progress for each update.
Upon successful completion of the
software update, a message will
pop up: “Software Update
Successful.” The radio will restart.
Remove the USB drive after the
radio has restarted.
Following is the website information.
Website Information
Buick
In the U.S., visit www.buick.com.
In Canada, visit www.buick.ca.
GMC
In the U.S., visit www.gmc.com.
In Canada, visit www.gmc.gm.ca.
Chevrolet
In the U.S., visit www.chevrolet.com.
In Canada, visit www.chevrolet.ca.
Customer Assistance Offices
See the owner manual for Customer
Assistance Office phone numbers.
Black plate (16,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
16 Infotainment System
Radio
AM-FM Radio
Playing the Radio
PUSH/O (Power/Volume):
.
Press to turn the radio on or off.
.
Turn to increase or decrease the
volume of the active source.
The steering wheel controls can
also be used to adjust the volume.
See Steering Wheel Controls on
page 8.
Audio Source
To access AM, FM, or SiriusXM (if
equipped), do one of the following:
.
On one of the Home Pages,
press the AM, FM, or XM (if
equipped) screen button.
.
Press the SRCE radio button to
scroll through the options.
A source ribbon will appear at
the bottom of the screen
allowing you to select the one
you want.
.
Use voice recognition by
pressing one of the voice
recognition buttons. After the
voice prompt and the beep, say
one of the following: “Tune AM,”
“Tune FM,” or “Tune XM,” or
“AM,” “FM,” or “XM”.
Infotainment System Settings
Tone Settings
To access the tone settings, press
the Tone button on the Home Page,
or press the PUSH/SEL knob while
in an audio source.
To adjust the settings:
.
Bass: Press + or − to change
the level.
.
Middle: Press + or − to change
the level.
.
Treble: Press + or − to change
the level.
.
EQ (Equalizer) (If Equipped):
Press
o or p to scroll through
the preset EQ options.
.
Stereo/Surround/DSP Mode (If
Equipped): Press
o or p to
scroll through the preset Digital
Signal Processing (DSP) or
toggle between Stereo and
Surround (5.1 DVD only) modes.
.
Fade: Press the F button to fade
the audio to the front speakers.
Press the R button to fade the
audio to the rear speakers. The
middle position balances the
sound between the front and
rear speakers.
.
Balance: Press the L button to
balance the audio to the left
speakers. Press the R button to
balance the audio to the right
speakers. The middle position
balances the sound between the
left and right speakers.
Black plate (17,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 17
Finding a Station
Press the SRCE button to go to the
currently playing source. Press it
again to select a different source.
Turn the PUSH/SEL knob to find a
radio station. To select a preset
station, press FAV to scroll through
the favorite banner. Press the
desired station on the banner.
Seeking a Station
Press
© SEEK or SEEK ¨ to search
for a station, or use
¨ on the
steering wheel controls.
Press and hold the
© SEEK or
SEEK
¨ button to scan up or down
the band, pausing on each station
for five seconds. Touch
© SEEK or
SEEK
¨ again to cancel the scan.
AM
To access the AM menu press the
Menu screen button from the AM
source screen:
Favorites List: Press to display the
favorites list.
AM Station List: The station list
may need to be updated before
pressing to display a list of AM
stations.
Update Station List: Press to
update and then display the list of
AM stations.
Tag Song: Press to tag a song to
download to an iPod when it is
connected, and to purchase it at a
later time. Song tagging is only
available while listening to an HD
broadcast.
HD Enable/Disable: Press to
enable or disable the HD Radio
®
function.
FM
Black plate (18,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
18 Infotainment System
To access the FM menu, press the
Menu screen button from the FM
source screen.
Favorites List: Press to display the
favorites list.
FM Station List: The station list
may need to be updated before
pressing to display a list of FM
stations.
Update Station List: Press to
update and then display the list of
FM stations. An FM station list
update may take several minutes.
To decrease the time to build a
station list will only be populated
with non HD stations.
Tag Song: Press to tag a song to
download to an iPod when it is
connected, and to purchase it at a
later time. Song tagging is only
available while listening to an HD
broadcast.
HD Enable/Disable: Press to
enable or disable the HD function.
FM Category List: Press to select
the desired genre.
SiriusXM (If Equipped)
To access the XM Menu, press the
Menu screen button and the
following may display:
Favorites List: Press to display the
favorites list.
XM Channel List: Press to display
a list of SiriusXM channels.
XM Category List: Press to display
a list of SiriusXM categories.
Tune Select (Navigation Only):
If equipped with SiriusXM, press
and the following may display:
.
Artist: Press to set an audio alert
when the current artist is playing
on a SiriusXM channel.
Black plate (19,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 19
.
Song: Press to set an audio alert
when the current song is playing
on a SirusXM channel.
.
Tune Select Manager: Press
Disable/Enable All Alerts to
enable or disable all alerts.
A checkmark next to the alert
means it is turned on. Press an
alert to turn it off. Press Delete
to delete an alert.
.
Audible Alert: This feature will
give an audio alert when certain
artists or songs are available on
a specific station. Press to turn
on or off.
Storing Radio Station Presets
Up to 30 preset stations can be
stored into the favorites banner: AM,
FM, and SiriusXM (if equipped) can
be mixed.
1. From the AM, FM, or XM main
page, press and hold one of the
preset screen buttons at the
bottom of the screen. After a few
seconds, a beep is heard and
the new preset information
displays on that screen button.
2. Repeat for each preset.
Mixed-Band Presets
Each favorite page can store five
preset stations. The presets within a
page can be from different radio
bands.
To scroll through the pages, press
FAV or the FAV screen button on the
top bar. The current page number
displays above the preset buttons.
To change the number of favorite
pages displayed:
1. Press Settings on the
Home Page.
2. Press Favorite Pages.
3. Select the number of pages to
display.
Recalling a Preset Station
To recall a preset station from a
favorites page, do one the following:
.
Press the FAV screen button at
the top bar to display the preset
pop-up. Press one of the preset
screen buttons to go to the
selected preset station.
.
In the AM, FM, or XM (if
equipped) main page, press one
of the preset screen buttons to
go to the selected preset station.
HD Radio Technology
HD Radio Technology is the
DIGITAL evolution of AM and FM
radio. HD Radio Technology is a
free service that offers new features
like static-free sound, more
programming choices on local FM
HD2/HD3/HD4/HD5/HD6/HD7
channels, on-screen information
such as artist and song title, as well
as album art if the station is
broadcasting it. Some HD Radio
stations broadcast station art and
album art as part of the HD service.
Black plate (20,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
20 Infotainment System
HD Radio station art is stored in the
radio and may take up to
five minutes to learn for each station
that supports station art. Album art
is broadcast at the beginning of
songs. If tuning into the middle of a
song, the art may not be available.
HD Radio Technology Station
Access
To access HD Radio stations:
1. Tune the radio to the station.
If the station is broadcasting HD
Radio Technology, the radio will
automatically switch to digital
audio and will have an orange
HD logo.
2. Press
© SEEK or SEEK ¨ to
tune to the previous or next HD
sub channel.
There might be a delay before the
station starts playing while the
signal is processed.
The HD Radio channel number is
indicated next to the logo.
HD Radio channels can be saved
as favorites. Songs can be tagged
for download to a connected
iPhone
®
or iPod touch®. See
AM-FM Radio on page 16 or USB
Port on page 36.
For a list of all channels, see
www.hdradio.com.
HD Radio Technology
Troubleshooting
Digital Audio Delay: Once tuned
to an HD station, there may be up to
an eight second wait for the signal
to process and start playing. This is
indicated by an orange HD icon.
Volume Change, Audio Skip,
Echo, Digital Audio Lost: Station
signal strength may be weak or the
station is out of range. Verify proper
reception on another channel.
If listening to channel HD1 and the
signal is losing reception, the radio
will go back to the main non-HD
Radio station.
If listening to channels HD2 to
HD7 and the signal is losing
reception, the radio mutes until the
signal can be recovered or until the
station is changed.
Digital HD broadcasting signals are
weaker than the normal signal
strength of the analog station, so
HD listening may not deliver the
same range as non HD station
listening. The radio will indicate loss
of HD signal by displaying “No HD
Signal.”
Satellite Radio
Vehicles with a valid SiriusXM
®
satellite radio subscription can
receive SiriusXM programming.
SiriusXM satellite radio has a wide
variety of programming and
commercial-free music, coast to
coast, and in digital-quality sound.
For more information, see
www.siriusxm.com or call
1-866-635-2349 in the U.S. In
Canada, see www.xmradio.ca or call
1-877-209-0079.
Black plate (21,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 21
When SiriusXM is active, the station
name, number, category name,
song title, and artist display on the
screen. SiriusXM may update the
background picture at any time.
SiriusXM Categories
SiriusXM stations are organized in
categories.
Adding or Removing SiriusXM
Categories
Using the Home Page:
1. Press the Settings screen button
on the Home Page.
2. Select XM Categories.
3. Select or deselect a category.
A checkmark will indicate that
the category is selected.
Press “Restore All” to restore all
SiriusXM categories.
Using the XM playing screen:
1. Press the Menu screen button.
2. Select XM Category List.
3. Select or deselect a category.
A checkmark will indicate that
the category is selected.
Pandora Internet Radio
Pandora
®
Pandora is a free Internet radio
service that streams personalized
radio stations based on artists,
songs, genres, and comedians.
Create stations with the Pandora
application downloaded on a phone
or device, then use
- (thumbs up)
or
, (thumbs down) to personalize
stations. To set up an account, or for
more information, go to
www.pandora.com. Pandora may
not be available in Canada or
Mexico.
A phone or tablet with Internet
connection is required for this
application. Personal cell phone
data plans are used. Make sure the
latest version is installed on the
device and the volume is turned up.
To install Pandora:
.
On an Android™ phone or
Android Tablet, go to the Android
Market and search for Pandora.
Install to the phone, not to the
SD card.
.
On a BlackBerry®phone, go to
the BlackBerry App World™ and
search for Pandora.
.
On an iPhone®, iPad®, or iPod
touch
®
, go to the iTunes®Store
and search for Pandora.
Launching Pandora
Connect the iPhone, iPad, or iPod
touch to the USB port, or connect
an Android or BlackBerry through
Black plate (22,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
22 Infotainment System
Bluetooth. See Auxiliary Devices on
page 41 or Bluetooth on page 85.
For first-time use, set up the
stations before connecting to the
vehicle. The Pandora icon will be
available on the Home Page.
The USB jack in the front storage
bin will charge Apple
®
devices
drawing up to 1 amp of current.
There are two additional, charging
only, 2.1 amp USB ports at the rear
of the center console, capable of
charging the iPad.
The signal strength and battery level
meters indicate the conditions of the
paired phone. Performance issues
of this feature may arise when either
signal or battery levels are low.
Launch Using the iPhone, iPod
touch, or iPad
1. Plug the device into the USB
port. The phone screen must be
unlocked.
2. To launch, do one of the
following:
.
Make sure the device is
unlocked so the Allow
button can be pressed on
the device.
.
Press Pandora on the
Home Page.
.
Press b / g and say
“Pandora” or “Play
Pandora.”
.
Press the SRCE button and
select from the source
ribbon of options.
If nothing happens when the
available Pandora screen button is
pressed, download the latest
Pandora application to the device
and retry. Also, verify you are in a
good signal area.
Pandora will always be highlighted
on the Home Page when an iPhone,
iPad, or iPod touch having the
application capability is connected
using the USB port. To use, log into
your account.
Launch Using an Android Phone
1. Pair the Android phone using
Bluetooth.
2. Use one of the following to
launch:
.
Press Pandora on the
Home Page.
.
Press b / g and say
“Pandora” or “Play
Pandora.”
.
Press the SRCE button and
select from the source
ribbon of options.
If nothing happens when the
available Pandora screen button is
pressed, download the latest
Pandora application to the device
and retry. Also, verify you are in a
good signal area.
Launch Using a BlackBerry Phone
The phone must be unlocked. To
launch Pandora service:
1. Pair the BlackBerry phone using
Bluetooth.
Black plate (23,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 23
2. Use one of the following to
launch:
.
Press Pandora on the
Home Page.
.
Press b / g and say
“Pandora” or “Tune
Pandora.”
.
Press the SRCE button and
select from the source
ribbon of options.
If nothing happens when the
available Pandora screen button is
pressed, download the latest
Pandora application to the device
and retry. Also, verify you are in a
good signal area.
If the “Please See Device” message
is shown, the login screen may
display on the device.
Pandora Menus
Press Menu on the Pandora
main page.
Pandora has a menu system with
the following:
Bookmark: When pressed during a
song, a choice displays to bookmark
the artist or song. This sends the
bookmark to the Pandora account.
Shuffle: Press to play the stations
in random order.
User-Created Stations: Press to
play a user-created station. Press
the
b / g button on the steering
wheel controls and say “Play [your
station].” See Steering Wheel
Controls on page 8. See Voice
Recognition on page 78 for
additional voice commands.
Pandora Features
Pandora service has features to rate
songs, skip songs, or change
stations.
, (Thumbs Down): When
pressed, Pandora stores this
information, changes to the next
song, and does not play this song
on this station again. This helps
Pandora choose which songs
should not play on this station. This
feature is only available on
user-created stations.
Black plate (24,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
24 Infotainment System
- (Thumbs Up): When pressed,
Pandora stores this information and
- is checkmarked for the remainder
of the song. This helps Pandora
choose which songs should play on
this station.
d (Next Song): When pressed,
Pandora changes to the next song.
Free Pandora App Has a Limit on
How Many Songs Could be
Skipped
Pandora offers a skip song service.
The current limit is six songs per
hour per station. This also applies to
the thumbs down feature. The song
will continue to play, but Pandora
stores this information and will not
play that song again.
Pandora Advertisement While
Using the Free Version
Pandora may play advertisements.
Ads normally displayed on the
phones will not be seen while
connected to the vehicle. Artist
name and song title will not be
displayed, and the skip track button
is not available.
Pandora Troubleshooting
Unable to Connect Device to
Vehicle
If the device is unable to connect to
the USB or Bluetooth:
1. Turn the vehicle off.
2. Remove the key from the
ignition.
3. Open and close the driver door,
wait about one minute, and try to
connect the device again.
Unable to Start Pandora
If the device is unable to launch
Pandora:
.
Check that the latest version of
Pandora is installed.
.
Check that there is an active
account logged into Pandora.
.
Check that there is good signal
strength. The signal strength and
phone battery level can be
checked on the radio screen.
.
Have at least one station
created.
.
For Android and BlackBerry
devices, check that the device is
paired with the vehicle, and the
Bluetooth icon on the display is
highlighted.
.
For iPhone, iPod touch, or iPad
devices, check that the USB
cable is connected to the USB
port and the screen is unlocked.
.
Close Pandora on the device
and launch again. Devices that
allow multitasking may require
an extra step to quit the Pandora
application. See the cell phone
manufacturer's user guide.
Black plate (25,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 25
Thumbs Up or Thumbs Down
Error
If there is an error trying to rate a
song with the
, or - buttons, the
message “Thumbs Down Error” or
“Thumbs Up Error” may display.
Press OK to retry.
Loss of Audio
Loss of Pandora audio can happen
in different ways:
.
Weak or lost data connection.
The signal strength and phone
battery level can be checked on
the radio screen.
.
Device needs to be charged.
.
Application needs to be
relaunched.
.
Connection between phone and
radio lost.
.
If any iPhone, iPod touch,
or iPad is connected to
Bluetooth and the dock
connector, unplug the dock
connector and plug it in again.
.
Volume is too low. Turn up the
volume on the device.
If the connection is lost between the
application and device, a message
“Please unlock your phone or restart
the phone app and try again” may
display. Press OK to retry.
Common Pandora Messages
Paused or Audio Paused:
Playback is paused on the radio or
device. Press the
r button in the
middle of the time bar on the bottom
of the screen to play or press the
j
button to pause.
No Stations Found: Logged in but
no stations have been created.
Communication Failure or
Application Unexpectedly Quit or
Network Connection Could Not
Be Established: Communication
failure between the radio and the
phone application, or between the
phone and data connection, or the
device is locked.
See www.pandora.com/help for
more information. If the service will
not work, see your dealer for
assistance.
Stitcher Internet Radio
Stitcher
Stitcher SmartRadio is an Internet
radio service that streams news,
sports, and entertainment shows
through the audio system. Create
personalized, on-demand stations or
discover new shows through
Stitcher’s preset stations. To set up
an account, or for more information,
go to www.stitcher.com. Stitcher
may be available as a worldwide
Internet service.
A phone or tablet with Internet
connection is required for this
application. Personal cell phone
data plans are used. Make sure the
latest version is installed on the
device and the volume is turned up.
Black plate (26,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
26 Infotainment System
To install Stitcher:
.
On an Android phone or Android
Tablet, go to the Android Market
and search for Stitcher. Install to
the phone, not to the SD card.
.
On an iPhone, iPad, or iPod
touch, go to the iTunes Store
and search for Stitcher.
Launching Stitcher
Connect the iPhone, iPad, or iPod
touch to the USB port, or connect
an Android through Bluetooth. See
Auxiliary Devices on page 41 or
Bluetooth on page 85. For first time
use, set up the stations before
connecting to the vehicle. The
Stitcher icon will be available on the
Home Page.
The signal strength and battery level
meters indicate the conditions of the
paired phone. Performance issues
of this feature may arise when either
signal or battery levels are low.
Launch Using the iPhone, iPod
touch, or iPad
1. Plug the device into the USB
port. The phone screen must be
unlocked.
2. To launch, do one of the
following:
.
Make sure the device is
unlocked so the Allow
button can be pressed on
the device.
.
Press Stitcher on the
Home Page.
.
Press SRCE and press
Stitcher on the ribbon.
.
Press b / g and say
“Stitcher” or “Play Stitcher.”
To relaunch Stitcher, press the
Stitcher source again from either the
Home Page or source ribbon.
If nothing happens when the
available Stitcher screen button is
pressed, download the latest
Stitcher application to the device
and retry. Also, verify you are in a
good signal area.
Stitcher will always be highlighted
on the Home Page when an iPhone,
iPad, or iPod touch is connected
using the USB port. To use, log into
your account.
If the “Please See Device” message
is shown, the login screen may
display on the device.
Launch Using an Android Phone
1. Pair the Android phone using
Bluetooth.
2. Use one of the following to
launch:
.
Press Stitcher on the
Home Page.
.
Press the SRCE button.
Black plate (27,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 27
.
Press b / g and say
“Stitcher” or “Play Stitcher.”
If nothing happens when the
available Stitcher screen button is
pressed, download the latest
Stitcher application to the device
and retry. Also, verify you are in a
good signal area.
If the “Please See Device” message
is shown, the login screen may
display on the device.
Stitcher Menu
To access the Stitcher Menu, press
the Menu icon on the main Stitcher
screen.
Stitcher has a menu system with the
following:
Favorites Playlist: If favorite
stations are stored on your device,
they can be accessed through “My
On Demand Stations” in the
Menu list.
Stitcher Station Categories:
Displays categories by topic. When
a category then subcategory is
selected, the radio will start playing
the first program in that
subcategory.
Turn the PUSH/SEL knob to bring
up the first 24 stations of that
subcategory.
Current Station Playlist: While
listening to a show, turn the PUSH/
SEL knob to display the menu list of
shows available for the current
station.
Stitcher Features
If available, Stitcher has a thumbs
up or down method of rating
programs.
q (Favorites): Press to mark the
program as a favorite.
Stitcher Troubleshooting
Unable to Connect Device to
Vehicle
If the device is unable to connect to
the USB or Bluetooth:
1. Turn the vehicle off.
2. Remove the key from the
ignition.
Black plate (28,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
28 Infotainment System
3. Open and close the driver door,
wait about one minute, and try to
connect the device again.
Unable to Start Stitcher
If the device is unable to launch
Stitcher:
.
Check that the latest version of
Stitcher is installed.
.
Check that there is an active
account logged into Stitcher.
.
Check that you have good signal
strength.
.
Have at least one station
created.
.
For Android devices, check that
the device is paired with the
vehicle, and the Bluetooth icon
on the display is highlighted.
.
For iPhone, iPod touch, or iPad
devices, check that the USB
cable is connected to the USB
port and the screen is unlocked.
.
Close Stitcher on the device and
launch again. Devices that allow
multitasking may require an
extra step to quit the Stitcher
application. See the cell phone
manufacturer's user guide.
Thumbs Up or Thumbs Down
Error
If there is an error trying to rate a
song with the
, or - buttons, the
message “Thumbs Down Error” or
“Thumbs Up Error” may display.
Press OK to retry.
Loss of Audio
Loss of Stitcher audio can happen
in different ways:
.
Weak or lost data connection.
.
Device needs to be charged.
.
Application needs to be
relaunched.
.
Connection between phone and
radio lost.
.
If any iPhone, iPod touch,
or iPad is connected to
Bluetooth and the dock
connector, unplug the dock
connector and plug it in again.
.
Volume is too low. Turn up the
volume on the device.
If the connection is lost between the
application and device, a message
“Please unlock your phone or restart
the phone app and try again” may
display. Press OK to retry.
Common Stitcher Messages
Paused or Audio Paused:
Playback is paused on the radio or
device. Press
k or play on the
radio page for Stitcher source.
No Stations Found: Logged in but
no stations have been created.
Press OK to continue.
Communication Failure or
Application Unexpectedly Quit or
Network Connection Could Not
Be Established: Communication
failure between the radio and the
phone application, or between the
phone and data connection, or the
device is locked.
Black plate (29,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
Infotainment System 29
See www.stitcher.com/help for more
information. If the service will not
work, see your dealer for
assistance.
Pictures
Pictures can only be viewed using
USB devices. If pictures are on an
SD card, transfer to a USB device
or use a USB-SD adapter.
A maximum 5Mb uncompressed
photo size is supported, however to
achieve this, use a 4 Megapixel or
lower resolution camera setting.
Only jpeg, bmp, gif, and png files
are supported.
1. Press the Picture Viewer screen
icon on the Home Page.
2. The system does a search to
find the picture folders.
A “Please wait” message
displays until the search is
finished.
3. A list displays. Select a picture
to view.
4. Once a picture displays, the
following options are available:
Info: Press to turn file name
information on or off.
S : Press to display the previous
picture.
T : Press to display the next
picture.
Menu: Press to open the Picture
Viewer Main Settings screen.
If the displayed picture screen is not
used within six seconds, the upper
and lower bar options will disappear.
Touch-tap the screen to re-display
the upper and lower bar.
Black plate (30,1)
Acadia, Acadia Denali, Enclave, Traverse Infotainment System (GMNALocalizing-U.S./Canada/Mexico-6014304) - 2014 - crc - 8/27/13
30 Infotainment System
Audio Players
CD/DVD Player
The player can be used to play both
CDs and DVDs containing audio
and video content. Different file
types are supported such as MP3.
With the radio on, insert a disc into
the slot, label side up. The player
pulls it in and begins playing.
The system is capable of playing:
.
Most audio CDs
.
CD-R
.
CD-RW
.
MP3 or unprotected WMA
formats
.
DVD-Video
.
DVD-R/RW
.
DVD+R/RW
When playing any compatible
recordable disc, the sound quality
can be reduced due to disc quality,
the method of recording, the quality
of the music that has been
recorded, or the way the disc has
been handled.
There can be increased skipping,
difficulty in recording tracks,
difficulty in finding tracks, and/or
difficulty in loading and ejecting.
If these problems occur, check the
disc for damage or try a known
good disc.
To avoid damage to the CD/DVD
player:
.
Do not use scratched or
damaged discs.
.
Do not apply labels to discs. The
labels could get caught in the
player.
.
Insert only one disc at a time.
.
Keep the loading slot free of
foreign materials, liquids, and
debris.
.
Use a marking pen to label the
top of the disc.
DVD-A is not a supported media.
Although sound may be heard, full
function is not available.
Loading and Ejecting Discs
To load a disc:
1. Turn the radio on.
2. Insert a disc into the slot, label
side up. The player pulls it in the
rest of the way. If the disc is
damaged or improperly loaded,
an error message displays, “Disc
error.” The disc ejects.
The disc automatically plays once
loaded.
Press
Z to eject a disc from the
CD/DVD player. If the disc is not
removed within a short period of
time, it is automatically pulled back
into the player.
Loading...
