Gmc DP250LS User Manual

1

1/3 HP

5 SPEED
DRILL PRESS
WITH REDEYE®

DP250LS
INSTRUCTION MANUAL

Black

Cyan

Magenta

Yellow

Code: DP250LS

Date: 071120 Edition: 05 Op: DCR

2

Contents

Warranty 2
Introduction 3
Environmental protection 3
Description of symbols 3
Specifications 3
Safety rules for laser lights 4
General safety instructions 4
Additional safety rules for drill presses 5
Unpacking 7
Required tools 7
Assembly time 7
Components 7
Know your product 8
Assembly 9
Adjusting the table height 9
Adjusting the table angle 9
Installing and removing drill bits 10
Setting the drilling depth 10
Changing the speed of the drill press 11
Turning on and off 11
Turning on the REDEYE® laser line generator 12
Adjusting the laser 12
Operation 12
Wood drilling 13
Metal drilling 13
Maintenance 13
Power cord maintenance 13
Cleaning 13
General inspection 13
Trouble shooting 14

Warranty Power Tools

Whilst every effort is made to ensure your complete
satisfaction with this tool, occasionally, due to the mass
manufacturing techniques, a tool may not live up to our
required level of performance and you may need the
assistance of our service department.

This product is warranted for a 2-year period for home
domestic use from the date of the original purchase.
If found to be defective in materials or workmanship,
the tool or the offending faulty component will be repaired
or replaced free of charge with another of the same item.

A

small freight charge may apply. Proof of purchase is
essential. We reserve the right to reject any claim where
the purchase cannot be verified.

This warranty does not include damage or defects to the
tool caused by or resulting from abuse, accidents,
alterations or commercial or business use. It also does not
cover any bonus items or included accessories. Only the
power tool is covered under this warranty.

With continuing product development, changes may have
occurred which render the product received slightly
different to that shown in this instruction manual.

Please ensure that you store your receipt in a safe place.
Conditions apply to the above warranty. For full details of

the warranty terms and conditions please refer to our
website – www.gmcompany.com

For prompt service we suggest you log your service
request online - www.gmcservice.com.au, should you
not have access to the internet, please contact our
service department on 1300 880 001 (Australia)
or 0800 445 721 (New Zealand).

3

Description of symbols

The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.

Wear hearing protection.
Wear eye protection.
Wear breathing protection.

Conforms to relevant standards
for electromagnetic compatibility.

Specifications

Voltage: 230–240Vac ~ 50Hz

Input Power: 250W

Speeds: 5

No Load Speed: 500, 890, 1400, 1900, 2500 RPM

Chuck Size: 13mm

Chuck Type: Keyed

Drilling Capacity: 13mm

Stroke Length: 50mm

Laser Class: II

Laser Wavelength: 650nm

Laser Output Power: ≤1mW

Dear Customer

If you require any help with your product, whether it
is a Warranty claim, spare part or user information,
please phone our Help Line for an immediate response.
Phone [phone] in Australia or
0800 445 721 in New Zealand.

Introduction

Your new GMC power tool will more than satisfy
your expectations. It has been manufactured under
stringent GMC Quality Standards to meet superior
performance criteria.

You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.

CAUTION. Carefully read through this entire Instruction

Manual before using your new GMC Power Tool. Take
special care to heed the Cautions and Warnings.

Your GMC power tool has many features that will make
your job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.

Environmental protection

Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way

.

WARNING

1. It may be more difficult to see the laser line in conditions
of bright sunshine and on certain surfaces.

4

Safety rules for laser lights

The laser light/laser radiation used in the GMC REDEYE®
system is Class 2 with maximum 1mW power and 650nm
wavelengths. These lasers do not normally present an
optical hazard, although staring at the beam may cause
flash blindness.

WARNING. Do not stare directly at the laser beam.

A hazard may exist if you deliberately stare into the beam,
please observe all safety rules as follows;

• The laser shall be used and maintained in accordance

with the manufacturer’s instructions.

• Never aim the beam at any person or an object other

than the work piece.

• The laser beam shall not be deliberately aimed at

personnel and shall be prevented from being directed
towards the eye of a person for longer than 0.25s.

• Always ensure the laser beam is aimed at a sturdy

work piece without reflective surfaces. i.e. wood or rough
coated surfaces are acceptable. Bright shiny reflective
sheet steel or the like is not suitable for laser use as
the reflective surface could direct the beam back at the
operator.

• Do not change the laser light assembly with a different

type. Repairs must only be carried out by the laser
manufacturer or an authorised agent.

CAUTION. Use of controls or adjustments or performance

of procedures other than those specified herein may result
in hazardous radiation exposure.

Please refer to the relevant Australian standards, AS 2397
and AS/NZS2211 for more information on Lasers.

General safety instructions

To use this tool properly, you must observe the safety
regulations, the assembly instructions and the operating
instructions to be found in this Manual. All persons who use
and service the machine have to be acquainted with this
Manual and must be informed about its potential hazards.
Children and infirm people must not use this tool. Children
should be supervised at all times if they are in the area in
which the tool is being used. It is also imperative that you
observe the accident prevention regulations in force in your
area. The same applies for general rules of occupational
health and safety.

WARNING. When using power tools, basic safety

precautions should always be taken to reduce the risk of
fire, electric shock and personal injury. Also, please read
and heed the advice given in the additional important
safety instructions.

1. Keep the work area clean and tidy. Cluttered work

areas and benches invite accidents and injury.

2. Consider the environment in which you are working.

Do not use power tools in damp or wet locations. Keep
the work area well lit. Do not expose power tools to rain.
Do not use power tools in the presence of flammable
liquids or gases.

3. Keep visitors away from the work area. All visitors and

onlookers, especially children and infirm persons, should
be kept well away from where you are working. Do not
let others in the vicinity make contact with the tool or
extension cord.

4. Store tools safely. When not in use, tools should be

locked up out of reach.

5. Do not force the tool. The tool will do the job better and

safer working at the rate for which it was designed.

6. Use the correct tool for the job. Do not force small

tools or attachments to do the job best handled by a
heavier duty tool. Never use a tool for a purpose for
which it was not intended.

LASER LIGHT. LASER RADIATION

Do not stare into beam.

Only turn laser beam on when tool

is on workpiece. Class 2 laser product

5

7. Dress correctly. Do not wear loose clothing or jewellery.

They can be caught in moving parts. Rubber gloves
and non-slip footwear are recommended when working
outdoors. If you have long hair, wear a protective hair
covering.

8. Use safety accessories. Safety glasses and earmuffs

should always be worn. A face or dust mask is also
required if the sanding operation creates dust.

9. Do not abuse the power cord. Never pull the cord to

disconnect the tool from the power point. Keep the cord
away from heat, oil and sharp edges.

10. Secure the work piece. Use clamps or a vice to hold

the work piece. It is safer than using your hand and
frees both hands to operate the tool.

11. Do not overreach. Keep your footing secure and

balanced at all times.

12. Look after your tools. Keep tools sharp and clean for

better and safer performance. Follow the instructions
regarding lubrication and accessory changes. Inspect
tool cords periodically and, if damaged, have them
repaired by an authorised service facility. Inspect
extension cords periodically and replace them if
damaged. Keep tool handles dry, clean and free from oil
and grease.

13. Disconnect idle tools. Switch off the power and

disconnect the plug from the power point before
servicing, when changing accessories and when the tool
is not in use.

14. Remove adjusting keys and wrenches. Check to see

that keys and adjusting wrenches are removed from the
tool before switching on.

15. Avoid unintentional starting. Always check that the

switch is in the OFF position before plugging in the tool
to the power supply. Do not carry a plugged in tool with
your finger on the switch.

16. Use outdoor rated extension cords. When a tool

is used outdoors, use only extension cords that are
intended for outdoor use and are so marked.

17. Stay alert. Watch what you are doing. Use common

sense. Do not operate a power tool when you are tired.

18. Check for damaged parts. Before using a tool, check

that there are no damaged parts. If a part is slightly
damaged, carefully determine if it will operate properly
and perform its intended function. Check for alignment
of moving parts, binding of moving parts, breakage
of parts, proper mounting and any other conditions
that may affect the operation of the tool. A part that is
damaged should be properly repaired or replaced by an
authorised service facility, unless otherwise indicated in
this Instruction Manual.
Defective switches must be replaced by an authorised
service facility. Do not use a tool if the switch does not
turn the tool on and off correctly.

19. Guard against electric shock. Prevent body contact

with grounded objects such as water pipes, radiators,
cookers and refrigerator enclosures.

20. Use only approved parts. When servicing, use only

identical replacement parts. Use an authorised service
facility to fit replacement parts.

Additional safety rules for drill presses

WARNING. For your own safety, do not try to use your

drill press or plug it in until it is completely assembled and
installed according to the instructions and until you have
read and understood the following:

1. Your drill press must be bolted securely to a workbench.

In
addition, if there is any tendency for your drill press to move
during certain operations, bolt the workbench to the floor.

2. This drill press is intended for use in dry conditions and
indoor use only.

3. Always wear safety goggles which comply to a recognised
standard. Use a face or dust mask along with safety
goggles if the drilling operation is dusty. Use ear protectors,
especially during extended periods of operation.

4. Do not try to drill material too small to be securely held.
Do not drill material that does not have a flat surface
unless it is clamped securely.
