GMC 18VDT18V, 18VDT-D Instruction Manual

1

18V

CORDLESS
DRILL/DRIVER

18VDT-D
INSTRUCTION MANUAL

Black

Cyan

Magenta

Yellow

Code: 18VDT-D Drill IM

Date: 070511 Edition: 08 Op: GM

2

Contents

Warranty 2
Environmental protection 3
Description of symbols 3
Specifications 3
General safety rules 4
Additional safety instructions for drills 5
Additional safety instructions for charger 6
Additional safety instructions for battery pack 7
Unpacking 8
Know your product 9
Fitting and removing the battery pack 10
Battery charging 10
To obtain the best life for the battery 10
Using the drill

11
Chuck replacement 11
Forward/Reverse control 11
Inserting and removing bits 11
Adjustment torque 12
Drilling metals 12
Drilling plastics and plastic coated chipboard 12
Drilling masonry 12
Drilling wood 12
Maintenance 12

Warranty Power Tools

Whilst every effort is made to ensure your complete
satisfaction with this tool, occasionally, due to the mass
manufacturing techniques, a tool may not live up to our
required level of performance and you may need the
assistance of our service department.

This product is warranted for a 2-year period for home
domestic use from the date of the original purchase.
If found to be defective in materials or workmanship,
the tool or the offending faulty component will be repaired
or replaced free of charge with another of the same item.

A

small freight charge may apply. Proof of purchase is
essential. We reserve the right to reject any claim where
the purchase cannot be verified.

This warranty does not include damage or defects to the
tool caused by or resulting from abuse, accidents,
alterations or commercial or business use. It also does not
cover any bonus items or included accessories. Only the
power tool is covered under this warranty.

With continuing product development, changes may have
occurred which render the product received slightly
different to that shown in this instruction manual.

Please ensure that you store your receipt in a safe place.
Conditions apply to the above warranty. For full details of

the warranty terms and conditions please refer to our
website – www.gmcompany.com

For prompt service we suggest you log your service
request online - www.gmcservice.com.au, should you
not have access to the internet, please contact our
service department on 1300 880 001 (Australia)
or 0800 445 721 (New Zealand).

3

Description of symbols

The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.

Wear hearing protection.
Wear eye protection.
Wear breathing protection.

Conforms to relevant safety standards.

For indoor use only.

Isolating transformer.

Double insulated for additional protection.

Conforms to relevant standards
for electromagnetic compatibility.

Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.

Read the instruction manual.

Fusable link rated at 130°C.

Polarities of DC connector.

Cadmium contained battery should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.

Specifications

Charger Input: 230–240V ~ 50 Hz

Nominal battery voltage: 18V

No load speed: 0–650min

-1

Drill chuck capacity: 1 - 10mm

Torque settings: 16+1

Charging time: 5–7 hours

Tool weight: 1.7kg

Dear Customer

If you require any help with your product, whether it
is a Warranty claim, spare part or user information,
please phone our Help Line for an immediate response.
Phone [phone] in Australia or
0800 445 721 in New Zealand.

Introduction

Your new GMC power tool will more than satisfy
your expectations. It has been manufactured under
stringent GMC Quality Standards to meet superior
performance criteria.

You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.

CAUTION. Carefully read through this entire Instruction

Manual before using your new GMC Power Tool. Take
special care to heed the Cautions and Warnings.

Your GMC power tool has many features that will make
your job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.

Environmental protection

Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way

.

130˚C

4

General safety rules

WARNING. Read all instructions. Failure to follow all

instructions listed below may result in electric shock,
fire and/or serious injury. The term “power tool” in all of the
warnings listed below refers to your mains operated (corded)
power tool or battery operated (cordless) power tool.

Save these instructions

1. Work area
a. Keep work area clean and well lit. Cluttered and dark

areas invite accidents.

b. Do not operate power tools in explosive

atmospheres, such as in the presence of flammable

liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.

c. Keep children and bystanders away while operating a

power tool. Distractions can cause you to lose control.

2. Electrical safety
a. Power tool plugs must match the outlet. Never modify

the plug in any way. Do not use any adapter plugs with

earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.

b. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock

if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of
electric shock.

d. Do not abuse the cord. Never use the cord for carrying,

pulling or unplugging the power tool. Keep cord away

from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.

e. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a cord

suitable for outdoor use reduces the risk of electric shock.

3. Personal safety
a. Stay alert, watch what you are doing and use

common sense when operating a power tool. Do

not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in
serious personal injury.

b. Use safety equipment. Always wear eye protection.

Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.

c. Avoid accidental starting. Ensure the switch is in the

off position before plugging in. Carrying power tools with
your finger on the switch or plugging in power tools that
have the switch on invites accidents.

d. Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a

rotating part of the power tool may result in personal injury.

e. Do not overreach. Keep proper footing and balance at

all times. This enables better control of the power tool in
unexpected situations.

f. Dress properly. Do not wear loose clothing or jewellery.

Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.

g. If devices are provided for the connection of dust

extraction and collection facilities, ensure these are
connected and properly used. Use of these devices

can reduce dust related hazards.

4. Power tool use and care
a. Do not force the power tool. Use the correct power tool

for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.

b. Do not use the power tool if the switch does not turn

it on and off. Any power tool that cannot be controlled

with the switch is dangerous and must be repaired.

5

c. Disconnect the plug from the power source before

making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally.

d. Store idle power tools out of the reach of children and

do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power

tools are dangerous in the hands of untrained users.

e. Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and
any other condition that may affect the power tools
operation. If damaged, have the power tool repaired

before use. Many accidents are caused by poorly
maintained power tools.

f. Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.

g. Use the power tool, accessories and tool bits etc.,

in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions and
the work to be performed. Use of the power tool for

operations different from those intended could result in a
hazardous situation.

5. Battery tool use and care
a. Ensure the switch is in the off position before

inserting battery pack. Inserting the battery pack into

power tools that have the switch on invites accidents.

b. Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type

of battery pack may create a risk of fire when used with
another battery pack.

c. Use power tools only with specifically designated

battery packs. Use of any other battery packs may

create a risk of injury and fire.

d. When battery pack is not in use, keep it away from

other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.

Shorting the battery terminals together may cause burns
or a fire.

e. Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact accidentally

occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.

6. Service
a. Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool is maintained.

Additional safety rules for drills

• Wear ear protectors with impact drills. Exposure to noise

can cause hearing loss.

• Use auxiliary handles supplied with the tool. Loss of

control can cause personal injury.

• If possible, always use clamps or a vice to hold your work.

• Always switch off before you put the drill down.

• Ensure that the lighting is adequate.

• Do not put pressure on the drill, such that it slows the

motor down. Allow the drill bit to cut without pressure. You
will get better results and you will be taking better care of
your tool.

• Keep the area free of tripping hazards.

• Do not let anyone under 18 years operate this tool.

• Only use accessory bits in good condition.

• Before drilling, check that there is sufficient clearance for

the drill bit under the workpiece.

• Do not touch the bit after operation. It will be very hot.

• Keep your hands away from under the workpiece.

6

• Never use your hands to remove sawdust, chips or waste

close by the bit.

• Rags, cloths, cord, string and the like should never be left

around the work area.

• Support the work properly.

• If you are interrupted when operating the drill, complete

the process and switch off before looking up.

• Periodically check that all nuts, bolts and other fixings are

properly tightened.

• When using the drill, use safety equipment including

safety glasses or shield, ear defenders, and protective
clothing including safety gloves. Wear a dust mask if the
drilling operation creates dust.

If in doubt, do not plug in the tool. Using a power source
with a voltage less than the nameplate rating is harmful to
the motor.

The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual will
be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.

To use this tool properly, you must observe the safety
regulations, the assembly instructions and the operating
instructions to be found in this Manual. All persons who use
and service the machine have to be acquainted with this
Manual and must be informed about its potential hazards.

Children and frail people must not use this tool. Children
should be supervised at all times if they are in the area in
which the tool is being used. It is also imperative that you
observe the accident prevention regulations in force in your
area. The same applies for general rules of occupational
health and safety.

Additional safety instructions for the charger

• Before using the charger, read all the instructions and

cautionary markings on the charger and battery pack as
well as the instructions on using the battery pack.

• Only charge your batteries indoors as the charger is

designed for indoor use only.

• DANGER. If the battery pack is cracked or damaged in

any other way, do not insert it in the charger. There is a
danger of electric shock or electrocution.

• WARNING. Do not allow any liquid to come into contact

with the charger. There is a danger of electric shock.

• To allow the battery pack to cool down after charging, do

not place it in a hot environment such as a metal shed or
open trailer left in the sun.

• Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.

• The charger and battery packs supplied with it are

specifically designed to work together. Do not attempt to
charge the battery pack with any other charger than the
one supplied.

• Do not place any object on top of the charger as it could

cause overheating. Do not place the charger near any
heat source.

• Do not pull on the lead of the charger to disconnect it

from the power source.

• Make sure that the charger cable is positioned where

it will not be stepped on, tripped over or otherwise
subjected to damage or stress.

• Do not use an extension cord unless it is absolutely

necessary. The use of an improper extension cord could
cause the risk of fire, electric shock or electrocution.

• Do not use the charger if it has been subjected to a

heavy knock, dropped or otherwise damaged in any way.
Take the charger to an authorised service centre for a
check or repair.

• Do not disassemble the charger. Take it to an authorised

service centre when service or repair is required.
Incorrect re-assembly may result in the risk of fire,
electric shock or electrocution.

7

• To reduce the risk of an electric shock, unplug the

charger from the power supply before attempting to clean
it. Removing the battery alone does not reduce the risk.

• Never attempt to connect two chargers together.

• Do not store or use the tool and battery pack in locations

where the temperature may reach or exceed 104°F
(40°C) such as alongside sheds or metal structures in the
summer.

• The charger is designed for use from a standard

household electrical supply (230–240 volts). Do not
attempt to connect the charger to a supply with a different
supply.

• If you wish to charge a second battery pack, unplug the

charger from the mains supply and leave it for at least
15 minutes. After this time you can charge a second
battery pack

Additional safety instructions for the
battery pack

• The battery pack for this tool has been shipped in a low

charge condition. You should charge the battery pack fully
before use.

• Ensure the switch is in the off position before inserting

battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.

• Use power tools only with specifically designated battery

packs. Use of any other battery packs may create a risk
of injury and fire.

• To ensure the longest battery life and best battery

performance, always charge the battery when the air
temperature is between 18–24°C. Do not charge the
battery pack when the temperature is below 0°C, or
above 40°C. This is important. Failure to observe this
safety rule could cause serious damage to the
battery pack.

• When battery pack is not in use keep it away from other

metal objects like paper clips, coins, keys, nails, screws
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.

• Do not incinerate the battery pack even if it is seriously

damaged or can no longer hold a charge. The battery
pack can explode in a fire.

• Never attempt to open the battery pack for any reason.

If the plastic housing of the battery pack breaks open
or cracks, immediately discontinue its use and do not
recharge it.

• Under abusive conditions, liquid may be ejected from

the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.

• The battery pack utilizes nickel-cadmium cells. Cadmium is

considered to be a toxic material. Use an environmentally
safe disposal unit at a municipal waste disposal centre to
dispose of a damaged or worn out battery.

8

The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual will
be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.

The manufacturer shall not be liable for any changes made
to the tool nor for any damage resulting from such changes.

Even when the tool is used as prescribed it is not possible
to eliminate all residual risk factors. The following hazards
may arise in connection with the tool’s construction and
design:

• Damage to the lungs if an effective dust mask is not worn.

• Damage to hearing if effective earmuffs are not worn.

Unpacking

Due to modern mass production techniques, it is unlikely
that your GMC Power Tool is faulty or that a part is missing.
If you find anything wrong, do not operate the tool until the
parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.

Contents of carton

• 18V Drill/Driver

• 18V Battery

• Charger

9

Know your product

This drill is mainly used for drilling in wood or metal sheet
and screwing. Use the tool and accessories only for
intended applications. All other applications are expressly
ruled out.

1. Keyless chuck

2. Torque collar

3. Trigger with variable speed control

4. Forward/reverse switch

5. Battery pack release tabs

6. Charger plug

7. Charger stand

8. Battery charger

9. Power indicator light (Green)

10. Charge indicator light (Red)

11. On-board bit holder
12 Battery pack

1

4

2

3

11

5

7

8

6

12

10

9

10

Fitting And Removing The Battery Pack

WARNING. Ensure the battery is

inserted straight into the drill and
never on an angle.

To remove the battery pack from
the drill firmly press the battery
pack release tabs (5) at either
side of the battery pack, and pull
the battery pack out of the tool.

To fit the battery pack, slide the
battery pack into the drill until the release tabs (5) lock the
battery into place. The battery should slide fully on to the
drill foot until the battery pack latches “click” into position.

Battery Charging

IMPORTANT. Before inserting into or removing the battery

pack (6) from the battery charger cradle (7) always ensure
that the plug is not in the mains socket.

ATTENTION. Never charge the battery for longer than 7

hours. Doing so will void battery warranty.

1. Insert the charger plug (6) into
the socket on the side of the
charger stand (7).

2. Connect the battery charger to
a suitable power supply socket
and switch on the power.

Note. The green LED power

indicator (9) will show there is
power going to the charger.

3. Insert the battery into the
charger socket taking care that
the battery pack tabs align with
the guides in the charger. It
should fit easily. Do not force.
Check that the battery pack is
firmly seated in the charger.

Note. The red LED charge indicator (10) will show that the

battery is correctly inserted into the charger cradle and is
on charge. The battery charge time is approximately 5 to 7
hours. If the red indicator light does not come ON, check to
make sure the battery pack is inserted fully into the charger
cradle and the electrical outlet is working properly.

Note. The red light will switch off when the battery is fully

charged, indicating the battery is no longer charging.
A further indication for a fully charged battery is the

temperature of the pack, which becomes fairly warm as the
battery becomes fully charged.

Important Charging Information
WARNING. Never leave a battery on charge once it starts

to warm up.
If you wish to charge a second battery pack, pull out the

plug from the mains supply and keep it disconnected for at
least 15 minutes before attempting to charge the second
battery.

To Obtain The Best Life For The Battery

Never allow the drill to come to a complete stand still
before recharging. The battery should be placed on charge
whenever the battery is noticeably running down or the drill
no longer performs a task it previously performed.

Avoid conducting short charges. Make sure that the
battery is fully charged every time by charging for the
recommended charge time (5–7 hours).Avoid allowing lose
items like screws or nails etc. to be stored with battery
packs as these or similar items can short battery packs and
cause a fire or explosion.

Always unplug the charger when not in use and store in a
dry secure place.

Avoid charging or storing your battery in temperatures below

-10ºC and above 40ºC.

11

Operation

Using the drill

Use the forward/reverse switch (4) to select the direction
of rotation. The trigger switch (3) is an electronic variable
speed control which enables the user to vary the speed
continuously. The speed varies according to how far the
trigger switch is depressed, the further it is depressed the
faster the chuck will rotate and the lighter it is depressed,
the slower it will rotate.

To stop the drill, release the trigger switch.

Note. You can only change the direction of rotation of the

drill using the forward/reverse switch (4) when the trigger (3)
is NOT depressed.

Chuck replacement

The chuck (1) of the drill is
fixed by a screw with a left­hand thread. The screw, which
is located in the centre of the
chuck, must be removed before
the chuck can be removed. To
remove the screw, turn it in a
clockwise direction. The chuck
can now be removed by unscrewing it anti-clockwise. If
you have trouble removing the chuck take the drill to your
nearest authorised service centre for chuck replacement.

CAUTION. Always ensure that the drill is switched off

and the battery pack is removed before making any
adjustments.

Forward/reverse switch

The forward/reverse switch (4)
will allow you to change the
direction of the motor while the
trigger switch is not depressed.

Drilling uses the forward mode.
The reverse mode is intended for
the removal of screws.

Inserting and removing bits

This drill has a keyless chuck (1),
which means that a chuck key is not needed to secure a bit
in the drill.

1. Open the chuck by holding the
rear section of the chuck firm
and rotating the front section
in an anti-clockwise direction,
sufficiently enough to allow the
drill bit required to fully enter
the jaws of the chuck.

2. Ensure the drill bit is fully
inserted.

3. Holding the rear section of the
chuck firmly, rotate the front
section of the chuck clock wise
until the jaws tighten on the
drill bit.

4. The front section of the chuck
needs to be tightened firmly
to ensure the drill bit is held
securely.

5. To remove the drill bit, hold the rear section of the chuck
firmly and rotate sharply the front section of the chuck in
an anti-clockwise direction, sufficiently enough to allow
the drill bit to be removed.

12

Adjustable torque

This drill is equipped with 16
torque settings plus one drill
setting which are controlled by
the torque collar (2). By rotating
the collar behind the chuck, it is
possible to adjust the torque.

This will allow better control
when using the drill as a
screwdriver as it prevents over­tightening of the screws.

For drilling, always use the use
the Drill position by aligning the
Drill symbol with the triangular
indicator on the front face of the
drill near the torque collar.

For setting the torque position,
select a low setting on the torque collar and align the
selected number with the triangular indicator on the side
face of the drill, next to the torque collar. Increase gradually
to set the correct torque. It is better to use a scrap piece of
material if possible to set the torque.

Drilling metals

• Always clamp sheet metal.

• Support thin metal with a block of wood to avoid

distorting it.

• Use a punch to mark the centre of the hole.

• Use a suitable lubricant for the material you are

working on.

USE FOR

Oil Steel

Turpentine or paraffin Aluminium

Do not lubricate Brass, copper or cast iron

Drilling plastics and plastic coated chipboard

• Use high speed drill bits

• See drilling wood below

Drilling masonry

• This drill is not designed for drilling masonry.

• Purchase or hire a Hammer drill.

Drilling wood

• Clamp a piece of scrap wood to the back of your work to

prevent splintering.

All drilling operations

• Mark off the centre of the hole using a centre punch

or nail.

Care

• Don’t force the drill, let it work at its own pace

• Keep the drill bit sharp.

• Reduce pressure, as the drill is about to break through

the item being drilled.

Maintenance

Store the tools, instruction manual and where necessary the
accessories in the original packaging. In this way you will
always have all the information and parts ready to hand.

Do not throw used batteries into fire or water. There
is a danger of explosion! Please hand in non-working
or used batteries, or tools with built-in batteries, to the
environmentally-safe disposal unit at a municipal waste­disposal centre, or to your dealer.

General inspection

Regularly check that all the fixing screws are tight. They
may vibrate loose over time.

If the supply cord needs replacing, the task must be carried
out by the manufacturer, the manufacturer’s agent, or an
authorised service centre in order to avoid a safety hazard.

13

Cleaning

1. Keep the tool’s air vents unclogged and clean at all times.

2. Remove dust and dirt regularly. Cleaning is best done
with a soft brush or a rag.

3. Re-lubricate all moving parts at regular intervals.

4. If the body of the sander needs cleaning, wipe it with a
soft damp cloth. A mild detergent can be used but nothing
like alcohol, petrol or other cleaning agent.

5. Never use caustic agents to clean plastic parts.

CAUTION. Water must never come into contact with the

sander.

Repairs

Only an authorised service centre should replace the
cordset or effect other repairs. If the cordset is damaged or
worn, have it repaired or replaced by an authorised service
centre.

1

18V

REMOTE CONTROLLED TRUCK

18VDT-T
INSTRUCTION MANUAL

Black

Cyan

Magenta

Yellow

Code: 18VDT-T Truck IM

Date: 070510 Edition: 06 Op: GM

2

Contents

Warranty 2

Introduction 3

Environmental protection 3

Description of symbols 3

Specifications 3

Safety instructions 4

Contents of carton 7

Know your product 8

Unpacking 9

Fitting and removing the battery pack 9

Battery charging 9

Operation 10

Centring wheel alignment 11

Maintenance 11

Warranty Power Tools

Whilst every effort is made to ensure your complete
satisfaction with this tool, occasionally, due to the mass
manufacturing techniques, a tool may not live up to our
required level of performance and you may need the
assistance of our service department.

This product is warranted for a 2-year period for home
domestic use from the date of the original purchase.
If found to be defective in materials or workmanship,
the tool or the offending faulty component will be repaired
or replaced free of charge with another of the same item.

A

small freight charge may apply. Proof of purchase is
essential. We reserve the right to reject any claim where
the purchase cannot be verified.

This warranty does not include damage or defects to the
tool caused by or resulting from abuse, accidents,
alterations or commercial or business use. It also does not
cover any bonus items or included accessories. Only the
power tool is covered under this warranty.

With continuing product development, changes may have
occurred which render the product received slightly
different to that shown in this instruction manual.

Please ensure that you store your receipt in a safe place.
Conditions apply to the above warranty. For full details of

the warranty terms and conditions please refer to our
website – www.gmcompany.com

For prompt service we suggest you log your service
request online - www.gmcservice.com.au, should you
not have access to the internet, please contact our
service department on 1300 880 001 (Australia)
or 0800 445 721 (New Zealand).

3

Description of symbols

The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.

Wear hearing protection.
Wear eye protection.
Wear breathing protection.

Conforms to relevant safety standards.

For indoor use only.

Isolating transformer.

Double insulated for additional protection.

Conforms to relevant standards
for electromagnetic compatibility.

Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.

Read the instruction manual.

Fusable link rated at 130°C.

Polarities of DC connector.

Cadmium contained battery should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.

Specifications

Charger Input: 230–240V ~ 50 Hz

Operational frequency 27.145MHz

Radio Controller Battery: 9V Alkaline

Nominal battery voltage: 18V

Charging time: 5–7 hours

Tool weight: 1.3kg

Power <1W EIRP in accordance with LIPD Class Licence

Dear Customer

If you require any help with your product, whether it
is a Warranty claim, spare part or user information,
please phone our Help Line for an immediate response.
Phone [phone] in Australia or
0800 445 721 in New Zealand.

Introduction

Your new GMC power tool will more than satisfy
your expectations. It has been manufactured under
stringent GMC Quality Standards to meet superior
performance criteria.

You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.

CAUTION. Carefully read through this entire Instruction

Manual before using your new GMC Power Tool. Take
special care to heed the Cautions and Warnings.

Your GMC power tool has many features that will make
your job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.

Environmental protection

Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way

.

130˚C

4

General safety rules

WARNING. Read all instructions. Failure to follow all

instructions listed below may result in electric shock, fire and/
or serious injury. The term “power tool” in all of the warnings
listed below refers to your mains operated (corded) power
tool or battery operated (cordless) power tool.

Save these instructions

1. Work area
a. Keep work area clean and well lit. Cluttered and dark

areas invite accidents.

b. Do not operate power tools in explosive

atmospheres, such as in the presence of flammable

liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.

c. Keep children and bystanders away while operating a

power tool. Distractions can cause you to lose control.

2. Electrical safety
a. Power tool plugs must match the outlet.

Never modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.

b. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock

if your body is earthed or grounded.

c. Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of
electric shock.

d. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.

e. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a cord

suitable for outdoor use reduces the risk of electric shock.

3. Personal safety
a. Stay alert, watch what you are doing and use

common sense when operating a power tool. Do

not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in
serious personal injury.

b. Use safety equipment. Always wear eye protection.

Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.

c. Avoid accidental starting. Ensure the switch is in the

off position before plugging in. Carrying power tools with
your finger on the switch or plugging in power tools that
have the switch on invites accidents.

d. Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may result
in personal injury.

e. Do not overreach. Keep proper footing and balance at

all times. This enables better control of the power tool in
unexpected situations.

f. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves away from

moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.

g. If devices are provided for the connection of dust

extraction and collection facilities, ensure these are
connected and properly used. Use of these devices

can reduce dust related hazards.

4. Power tool use and care
a. Do not force the power tool. Use the correct power tool

for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.

b. Do not use the power tool if the switch does not turn

it on and off. Any power tool that cannot be controlled

with the switch is dangerous and must be repaired.

5

c. Disconnect the plug from the power source before

making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally.

d. Store idle power tools out of the reach of children

and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained
users.

e. Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and
any other condition that may affect the power tools
operation. If damaged, have the power tool repaired

before use. Many accidents are caused by poorly
maintained power tools.

f. Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.

g. Use the power tool, accessories and tool bits etc.,

in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions and
the work to be performed. Use of the power tool for

operations different from those intended could result in a
hazardous situation.

5. Battery tool use and care
a. Ensure the switch is in the off position before

inserting battery pack. Inserting the battery pack into

power tools that have the switch on invites accidents.

b. Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type

of battery pack may create a risk of fire when used with
another battery pack.

c. Use power tools only with specifically designated

battery packs. Use of any other battery packs may

create a risk of injury and fire.

d. When battery pack is not in use, keep it away from

other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.

Shorting the battery terminals together may cause burns
or a fire.

e. Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact accidentally

occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.

6. Service
a. Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool is maintained.

Additional safety instructions for remote
controlled cars/trucks

WARNING. Do not plug the battery charger into the mains

or install the battery into the truck until you have carefully
read and understood this instruction manual.

WARNING. Never leave the battery pack in the truck when

it is not in use and always switch OFF the truck after each
use and/or when making any adjustments. This will help
prevent the truck from starting accidentally and reduce any
risk of injury.

WARNING. Choking hazard. This product contains small

components and is not suitable for children under 3 years
of age.

• Use only 18V batteries specifically designed for

this car/truck.

• Use only 9V Alkaline batteries in the remote control.

• Remove the battery pack from the truck and the 9V

battery from the transmitter after use. These actions
will reduce the risk of use by unauthorized persons and
reduce the possibility of battery leakage.

• The tool must be used only for its prescribed purpose.

6

• Any use other than those mentioned in this Manual will

be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.

• To use this tool properly, you must observe the safety

regulations, the assembly instructions and the operating
instructions to be found in this Manual. All persons who
use and service the machine have to be acquainted
with this Manual and must be informed about its
potential hazards.

• The manufacturer shall not be liable for any changes

made to the truck nor for any damage resulting from
such changes.

• Even when the tool is used as prescribed it is not

possible to eliminate all residual risk factors.

Additional safety instructions for the charger

• Before using the charger, read all the instructions and

cautionary markings on the charger and battery pack as
well as the instructions on using the battery pack.

• Only charge your batteries indoors as the charger is

designed for indoor use only.

• DANGER. If the battery pack is cracked or damaged in

any other way, do not insert it in the charger. There is a
danger of electric shock or electrocution.

• WARNING. Do not allow any liquid to come into contact

with the charger. There is a danger of electric shock.

• To allow the battery pack to cool down after charging, do

not place it in a hot environment such as a metal shed or
open trailer left in the sun.

• Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.

• The charger and battery packs supplied with it are

specifically designed to work together. Do not attempt to
charge the battery pack with any other charger than the
one supplied.

• Do not place any object on top of the charger as it could

cause overheating. Do not place the charger near any
heat source.

• Do not pull on the lead of the charger to disconnect it

from the power source.

• Make sure that the charger cable is positioned where

it will not be stepped on, tripped over or otherwise
subjected to damage or stress.

• Do not use an extension cord unless it is absolutely

necessary. The use of an improper extension cord could
cause the risk of fire, electric shock or electrocution.

• Do not use the charger if it has been subjected to a

heavy knock, dropped or otherwise damaged in any way.
Take the charger to an authorised service centre for a
check and/or repair.

• Do not disassemble the charger. Take it to an authorised

service centre when service or repair is required.
Incorrect re-assembly may result in the risk of fire, electric
shock or electrocution.

• To reduce the risk of an electric shock, unplug the

charger from the power supply before attempting to clean
it. Removing the battery alone does not reduce the risk.

• Never attempt to connect two chargers together.

• Do not store or use the tool and battery pack in locations

where the temperature may reach or exceed 104°F
(40°C) such as alongside sheds or metal structures in
the summer.

• The charger is designed for use from a standard

household electrical supply (230–240 volts). Do not
attempt to connect the charger to a supply with a
different supply.

• If you wish to charge a second battery pack, unplug the

charger from the mains supply and leave it for at least
15 minutes. After this time you can charge a second
battery pack.

7

Additional safety instructions
for the battery pack

WARNING. Use only batteries and chargers recommended

for this remote controlled truck. Follow instructions that
accompany the batteries and chargers. Use of improper
batteries or chargers may cause injury to the operator or
damage to the remote controlled truck.

• The battery pack for this tool has been shipped in a low

charge condition. You should charge the battery pack fully
before use.

• Ensure the switch is in the off position before inserting

battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.

• Use power tools only with specifically designated battery

packs. Use of any other battery packs may create a risk
of injury and fire.

• To ensure the longest battery life and best battery

performance, always charge the battery when the air
temperature is between 18–24°C. Do not charge the
battery pack when the temperature is below 0°C, or
above 40°C. This is important. Failure to observe this
safety rule could cause serious damage to the
battery pack.

• When battery pack is not in use keep it away from other

metal objects like paper clips, coins, keys, nails, screws
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.

• Do not incinerate the battery pack even if it is seriously

damaged or can no longer hold a charge. The battery
pack can explode in a fire.

• Never attempt to open the battery pack for any reason.

If the plastic housing of the battery pack breaks open
or cracks, immediately discontinue its use and do not
recharge it.

• Under abusive conditions, liquid may be ejected from

the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.

• The battery pack utilizes nickel-cadmium cells. Cadmium is

considered to be a toxic material. Use an environmentally
safe disposal unit at a municipal waste disposal centre to
dispose of a damaged or worn out battery.

IMPORTANT. Do not use any batteries or chargers

unless you have completely read the instructions or
Owner’s Manual.

• The battery pack utilizes nickel-cadmium cells. Cadmium is

considered to be a toxic material. Use an environmentally
safe disposal unit at a municipal waste disposal centre to
dispose of a damaged or worn out battery.

Contents of carton

• Remote controlled truck

• Remote control

LIPD (Low Interference Potential Devices)
Licence notation

• This radio controlled truck is supported under the LIPD

Class Licence and can be expected to be operating
in radio frequency spectrum also used by other radio
communication devices.

• It is recognised that interference arising from the

operation of this LIPD is still possible, although under
less likely circumstances. Under the condition of the
operation of this Radio control (LIPD) Class Licence the
Radio should not cause interference with other radio
communication devices.

• Should interference occur, the onus is on the user of the

Radio Control (LIPD) to take measures to resolve the
interference, for example, by returning it to an authorised
service centre for retuning or ceasing to operate it.

8

Know your product

1. Forward/Reverse stick

2. Left/Right stick

3. On/Off switch

4. Roof release button

5. Roof

6. Charger plug

7. Charger stand

8. Battery charger

9. Power indicator light (green)

10. Charge indicator light (red)

11. Wheel centring lever

12. Battery pack

13. Signal receiver

2

1

13

11

5

4

3

7

8

6

12

9

10

9

Unpacking

Due to modern mass production techniques, it is unlikely
that your GMC Power Tool is faulty or that a part is missing.
If you find anything wrong, do not operate the tool until the
parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.

Fitting and removing the battery pack

WARNING. Only use GMC 18VDT-BAT 18V batteries in

this truck.

1. Open the roof of the truck by pressing the roof release
button (4) located at the rear of the truck.

2. Lift the rear of the roof (5) upward and pull it away from
the truck.

3. Insert the terminal end of the freshly charged battery (not
supplied) into the battery cavity inside the truck. Ensure
the battery is fully inserted into the battery cavity of the
truck.

4. To re-install the roof, insert the two tabs located on the
front of the roof into the matching slots on the truck.

5. Lower the rear of roof onto the truck and press downward
until the roof ‘clicks’ into place.

Battery charging

IMPORTANT. Before inserting into or removing the battery

pack (6) from the battery charger cradle (7) always ensure
that the plug is not in the mains socket.

ATTENTION. Never charge

the battery for longer than 7
hours. Doing so will void battery
warranty.

1. Insert the charger plug (6) into
the socket on the side of the
charger stand (7).

2. Connect the battery charger to
a suitable power supply socket
and switch on the power.

Note. The green LED power

indicator (9) will show there is
power going to the charger.

3. Insert the battery into the
charger socket taking care that
the battery pack tabs align with
the guides in the charger. It
should fit easily. Do not force. Check that the battery pack
is firmly seated in the charger.

Note. The red LED charge indicator (10) will show that the

battery is correctly inserted into the charger cradle and is
on charge. The battery charge time is approximately 5 to 7
hours. If the red indicator light does not come ON, check to
make sure the battery pack is inserted fully into the charger
cradle and the electrical outlet is working properly.

Note. The red light will switch off when the battery is fully

charged, indicating the battery is no longer charging.
A further indication for a fully charged battery is the

temperature of the pack, which becomes fairly warm as the
battery becomes fully charged.

Important Charging Information
WARNING. Never leave a battery on charge once it starts

to warm up.

10

If you wish to charge a second battery pack, pull out the
plug from the mains supply and keep it disconnected for
at least 15 minutes before attempting to charge the
second battery.

To obtain the best life for the battery

Never allow the truck to come to a complete stand still
before recharging the battery. The battery should be placed
on charge whenever the battery is noticeably running down
or the truck no longer performs as it previously performed.

Avoid conducting short charges. Make sure that the battery
is fully charged every time by allowing the charger to
complete its full charging cycle.

Avoid allowing lose items like screws or nails etc to be
stored with battery packs as these or similar items can short
battery packs and cause a fire or explosion.

Always unplug the charger when not in use and store in a
dry secure place.

Avoid charging or storing your battery in temperatures below
0ºC and above 40ºC.

Installing the battery into the remote control
IMPORTANT. Only use an alkaline 9V battery in

this transmitter.

1. Remove the screw of the
battery cover on the back of
the remote control by turning
it anti- clockwise using a small
Philips head screwdriver (not
included).

2. Slide the battery cover off the
remote control.

3. Press the battery into the
battery cavity.

Note. Ensure the terminals of the

battery line up with the terminals
inside the remote control.

IMPORTANT: Ensure the ‘+’

battery terminal is contacting the
‘+’ terminal inside the remote
control. See diagram inside
remote control for proper battery
orientation.

4. Reinstall battery cover.

Operation

Truck ON/OFF switch

To switch the truck ON, move the
switch (3) located on the bottom
of the truck forward. To turn
the truck OFF, slide the switch
backwards.

Controlling the truck
WARNING. Ensure the truck is being operated in a safe

environment free from motor vehicles and pedestrians.

11

WARNING. High voltage wires and/or transformers,

concrete walls or narrow places may promote erratic
behaviour or loss of control of the vehicle as a result of
interference. Interference may also be encountered if
another remote/radio controlled product or CB radio is
operating on a similar frequency.

If control of the vehicle is lost due to interference, move to
another location to operate the truck.

1. Turn the ON/OFF switch to the ON position.

2. To accelerate the truck
(move forward), press the
forward/reverse stick (1)
forward. To reverse the truck
(move backwards), move
the forward/reverse stick
backward.

Note. The further the forward/

reverse stick is pushed forward,
the faster it will run.

3. To turn the truck right, move
the left/right stick (2) to the
right. To turn the truck left,
move the RIGHT stick to
the left.

Note. The wheels will remain

turned until the stick is moved
back to the middle position.

Centring wheel alignment

If the truck wheels fail to travel in a straight line when the
left/right stick is released and centred, the wheel control
must be adjusted to straighten up the wheels.

1. Turn the truck onto its roof.

2. Rotate the wheel centring lever
(11) slightly in one direction. If
the truck turns more with the
stick in the neutral position
after the centring lever is
adjusted, move the centring
lever in the opposite direction.

Maintenance

Always ensure the battery terminals of the truck and remote
control are clean. If there is build-up on the terminals, clean
them with a cotton swab and alcohol.

IMPORTANT. Use a clean cloth to clean the plastic parts of

the truck and its components. Never use solvents as it will
ruin the plastic parts and void warranty.

WARNING. Do not allow brake fluids, gasoline, petroleum-

based products, etc. to come in contact with plastic parts as
they may damage or destroy the plastic.

DO NOT deliberately abuse the equipment. Abusive

practices can damage the equipment and become
dangerous to the operator.

GMC customer assist

If your product needs repairing, replacing,
technical service or you simply need help or advice,
please contact us on our Customer Assist Line
1300 880 001 (Australia) or 0800 445 721 (New Zealand).

For prompt service we suggest you log your service request
online at www.gmcservice.com.au. Should you not have
access to the Internet, please contact our service department
on 1300 880 001 (Australia) or 0800 445 721 (New Zealand).

7am –7pm, 7days a week (AEST).

Please note that if repair or replacement is required,
you must provide a valid original purchase receipt.

You will need the following details at hand to log your service request;

Personal details: First & Last name, address, pick up address,
contact phone numbers, email address

Product details: Product number, date of purchase, retailer bought from,
State & postcode, receipt number,

reason for the request,

c

opy of official purchase receipt

Attach your purchase receipt and save with this Manual for future reference

.

Please refer to our website www.gmcompany.com for full GMC warranty Terms and Conditions.
