Fast, Reliable, FireWire
52x 24x 52A CD Recorder
• The WildFire is a fast, reliable 3-in-1 CD-R/W drive that
writes at 52x, re-writes at 24x,and reads at 52x
• Disc At Once (DAO), Red Book Audio compliant so you can
fully master your CDs
• 4 MB buffer assures smooth transfer of your audio data
• Comes with FireWire cable and CD media
accessory pack
• Compatible with Macintosh & PCs (your PC may require a
host bus adapter and software)
• Burn-Proof technology eliminates buffer underrun errors in
fast write modes, allows for multi-tasking
• Flash ROM allows for easy upgrade over the Internet
• Hot-pluggable dynamic reconfiguration means that you can
re-cable your peripheral devices without re-booting
• Use as alternative to SCSI for a clean configuration
and free up SCSI bus for other devices
800.335.0345 glyphtech.com
UK/Europe 44.(0)1799.584.925
© 2004 Ithaca Technologies, LLC. All rights reserved. Wildfire, Glyph and
the Glyph logo are registered trademarks of Ithaca Technologies, LLC
Wildfire
™
CD Recorder
Page 2
FireWire CD-R/RW Drive
Hardware Specifications
Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEEE 1394
Performance
Read Speed . . . . . . . . . . . . . 52X
Write Speed. . . . . . . . . . . . . 24X
Re-Write Speed . . . . . . . . . . 52X
Average Access Speed . . . . . 120 msec
Buffer size . . . . . . . . . . . . . . 4 MB
Disk Writing Method. . . . . . Track-at-once, Disc-at-once, Session-at-
once, Multisession, Fixed and Variable
Packet Writing
Disk Loading Method . . . . . Tray
Supported Formats . . . . . . . CD-DA; CD-ROM (Mode 1); CD-ROM
(Mixed Mode); CD-ROM XA (Mode 2, Form 1 and Form 2 and Mixed
Form; CD-I; Photo CD; Video CD; CD-Extra; CD+G; CD Text
Reliability
MTBF (power-on hours) . . . . . . . . . . . . . . . . 60,000 hours
Tray Load/Unload cycles. . . . . . . . . . . . . . . . 100,000 times
Limited Warranty (years). . . . . . . . . . . . . . . . One (1) Year
Power Supply
Rack Mount . . . . . . . . . . . . . Switching, 90 - 260V AC Input
Tabletop. . . . . . . . . . . . . . . . Switching, 110 - 230V AC Input
Environmental
Operating Temperature (˙F/˙C) . . . . . . . . . . 41 to 104 / 5 to 40
Physical (Tabletop)
Height, Width, Depth (in/cent). . 2.25 x 6.25 x 11.75 / 5.72 x 16 x 29.9
Weight (lbs/kg) . . . . . . . . . . . . . . . . . . . . . . . 7.25 / 3.29
Included with this Glyph CD-R/RW Drive
(1) FireWire cable
(1) Power Cable
(1) Blank CDR media
(1) QuickStart User’s Manual
(1) Warranty Registration Card
Compatible Computers
Macintosh including AV Models, Power PC, G3, G4, G5
PC Compatible with Windows 98, ME, 2000, XP
BIT/ TRACK AUDIO STORAGE GUIDE
TIME (MINUTES)
CAPACITY (GIGABYTES)
24 24
60
50
40
30
20
10
0
0102030405060
48 kHz 96 kHz 192 kHz
* Be careful not to underestimate your needs. For maximum performance you
should use a drive at least 30% larger than your estimated need. This ensures
that you have the room necessary for operating overhead and extra files
generated during mixing and editing. Please note: This chart illustrates the
capacities required for specific bit depths, sample rates and track counts.
The ability to achieve higher track counts is dependent on your DAW.
Glyph Technologies
227 Cherry Street
Ithaca, New York 14850
Sales: 800.335.0345
Fax: 607.275.9464
Tech Support: 607.275.0154
www.glyphtech.com
