Page 1

FIREWIRE 800FIREWIRE 800

Features:

• Capacity of 3TB with 1TB drives

• Sustain data rates of 80 MB/sec with FireWire (IEEE 1394b)

• FireWire connectivity is hot pluggable and allows 63 devices daisy chained

• Fast 7,200 RPM, ATA/100 Seagate drives with up to an 8MB cache

• Scratch resistant black powder-coated aluminum chassis offers excellent heat transfer properties

• FireWire 400 Port accessible on the front panel

• Dual internal 70w power supplies, and dual whisper quiet fans

• Comes complete with Glyph's 24-hour advance replacement warranty along with outstanding technical support at no additional charge.

Custom Configure Three Drives in a Single Space Rack with the GT 103 FW800.

Specifically designed for applications requiring multiple drives, the GT 103 FW800 can be configured with three FireWire hot-swap GT Key FW800 drives of any capacity. Using Integrity™, Glyph's proprietary hot-swap technology, you can easily shuttle content to other GT Series enclosures with the 7,200 RPM GT Key. Integrity™ is an advanced FireWire hot-swap interface that provides greater reliability than existing hybrid ATA-to-FireWire products. Older FireWire 400 GT Keys are forward-compatible with the FireWire 800 GT 103, and FireWire 800 GT Keys are backward-compatible with all GT Series FireWire 400 enclosures. Glyph's GT 103 FW800 comes standard with a three-year warranty, while GT Keys carry an additional overnight advance replacement warranty in the first year.

GT 103 FW800 Specifications

• Interface: Two IEEE 1394b (FireWire 800) connectors, one FW400 port on front

• Dimensions: H 1.7" x W 19" x D 16"

• Power supply: Universal 100-240v, 50-60 Hz

• Weight (lbs/kg): 16 lbs/7 kg (fully loaded), 11.5 lbs/5.2 kg (empty)

• Compatibility: Mac OS 10.x, Windows 98SE/2000/ME/XP, Linux

• Includes: 2 meter FireWire 800 cable, power cable, rack screws, downloadable manual arranty: 3 years

• W

GT Key FW800 Specifications

• Capacity: 80, 160, 250, 320, 400, 500, 750GB, 1TB

• Rotational speed: 7,200 RPM

• Bridging: Oxford 924 chip on Glyph’s own bridge board

• Buffer size (cache): 8MB (160GB - 250GB), 16MB (320 - 750GB), 32MB (1TB)

• Average seek time (read): 8 msec

• Max external transfer rate: 800 Mb/sec (80 MB/sec)

• Dimensions: H 1.1" x W 4.6" x D 9.4"

• Weight (lbs/kg): 2.9 lbs / 1.3 kg

• Power supply: Gets power from enclosure

• Operating T

• Warranty: 3 years, Overnight advance replacement warranty in the first year

emperature (C/F): 41 - 122/5 - 50

echnologies, LLC

800.335.0345 glyphtech.com
