Glyph GT0621F-1000, GT0621F-120, GT0621F-1500, GT0621F-160, GT0621F-200 Technical Specifications
...Page 1
Features:
• Huge storage capacity up to 2TB.
• Sustain data rates of 80 MB/sec with
Mac OS X 10.4 Tiger.
• Supports four drive modes: RAID 0,
RAID 1, JBOD, and Spanning
• Fast 7,200 RPM, Seagate SATA drives
with an 8MB cache.
• Enclosure has a stainless steel faceplate,
internal quiet fan, and internal power
supply.
• Supported NLE systems: Final Cut Pro,
Avid Xpress, Adobe Premiere.
Triple interface with Four Drive Modes Striping, Mirroring, JBOD, and Spanning
Glyph's GT 062 is a two drive tabletop designed for professional audio
and video applications, and supports four drive modes. JBOD (individual
volumes) is very well suited for audio production, and Spanning mode
simply shows the two internal drives as one large volume. RAID 0
(striping) is designed for increased performance by reading and writing
data from both drives at the same time. RAID 1 (mirroring) offers data
redundancy and real-time backup by writing the same data to the two
internal hard drives at the same time. Should a drive failure happen, data
is still available on the remaining drive. Glyph Manager software, a utility
for Mac OS X and Windows XP, works in conjunction with the GT 062 to
switch between the four internal drive modes, and report the health
status of the GT 062 drives. The back panel features four ports for
multiple connectivity options - two FW800, one FW400, and one USB 2.0.
.
• Ideal for audio and video production,
content creation, and sound libraries.
• Comes complete with Glyph's 24-hour
advance replacement warranty along
with outstanding technical support at
no additional charge.
810049-1.3 GT 062 Datasheet.pdf
© Glyph Technologies, a division of
Ithaca Technologies, LLC
Sept 25, 2007
800.335.0345
glyphtech.com
Technical Specifications
• Capacity: 500GB, 800GB, 1TB, 1.5TB, 2TB
• Interfaces: two FireWire 800, one FireWire 400, one USB 2.0
• Bridging: Oxford 924 chip
• Rotational speed: 7,200 RPM
• A
verage seek time (read): 8 msec
• Max external transfer rate: 800 Mb/sec (100 MB/sec)
• Sustained transfer rate: 80 MB/sec
• Buffer size (cache): 16MB
• Dimensions: H 1.1" x W 4.6" x D 9.4"
eight (lbs/kg): 4.6 lbs / 2 kg
• W
• Internal Power supply: Universal 100-240v
• Operating T
emperature (C/F): 41 - 122/5 - 50
• Warranty: 3 years, with 1st year 24-hour advance replacement
• Compatibility: Mac OS 10.2.5 or later
• Includes: FW800 cable, FW400 cable, power cable, hard-shell plastic carrying
case, CD with Glyph Manager Software and Manual
, 50-60 Hz
, Windows 2000/XP/Vista
