Glyph GT0501F-120, GT0501F-160, GT0501F-250, GT0501F-320, GT0501F-500 Technical Specifications
...Page 1
Features:
• Huge storage capacity up to 750GB
• Sustain data rates of 40 MB/sec with
FireWire (IEEE 1394a/iLink)
• Internal power supply, no wall wart.
Internal, quiet fan.
• Fast 7,200 RPM, ATA/100 Seagate
drives with up to an 8MB cache
• Ships in Hard shell plastic protective
carrying case.
• Stainless steel, fan cooled enclosure is
rack-mountable
Engineered for Professional Audio
•
and Video Production
• Comes complete with Glyph's 24-hour
advance replacement warranty along
with outstanding technical support at
no additional charge.
Shown with optional rack ears
Fast, sleek and portable.
Setting the standard for disk-based audio recording storage, the GT 050’s
durable design features an internal power supply, whisper-quiet fan, and
1/8” thick brushed stainless steel faceplate. The scratch-resistant black
powder coated aluminum chassis offers additional heat transfer
properties while allowing the drive to be lightweight and portable. Both
rugged and portable, Available with a variety of large-capacity Seagate
7,200 RPM drives to provide top notch performance with audio and
video applications, the GT 050 comes standard with a three-year warranty
that includes overnight advance replacement in the first year.
Technical Specifications
• Capacity: 80, 160, 250, 320, 400, 500, 750GB
• Interface: Two IEEE 1394a/iLink (FireWire 400) connectors
• Bridging: Oxford 911 chip on Glyph’s own bridge board
• Rotational speed: 7,200 RPM
• Average seek time (read): 8 msec
• Max external transfer rate: 400 Mb/sec (50 MB/sec)
• Buffer (cache): 2MB (80GB), 8MB (160 - 250GB), 16MB (320 - 750GB)
• Dimensions: H 1.72" x W 8.61" x D 9.47"
eight (lbs/kg): 4.30 lbs / 1.94 kg
• W
• Internal Power supply: Universal 100-240v
• Operating Temperature (C/F): 41 - 122/5 - 50
• Warranty: 3 years
• Compatibility: Mac OS 8.6/9.x/10.x, Windows 98SE/2000/ME/XP, Linux
• Includes: 2 meter FireWire cable, power cable, downloadable manual, hard-
shell plastic carrying case
, 50-60 Hz
810029-1.09 GT 050 DATA.pdf
© Glyph Technologies, a division of Ithaca Technologies, LLC
November 30, 2007
800.335.0345
glyphtech.com
