Glyph Firewire CDR User Manual

Firewire CDR

Quickstart Guide

About This Manual

This is not a technical manual. Technical manuals usually include
information about the drive mechanism (like drive specs, wiring
schematics, pin outs ... stuff like that). Since opening your Glyph
enclosure voids your warranty, our documentation covers the setup
& use of the product, not the drive inside it.

If you have questions or comments of a technical nature, we urge
you to contact the Glyph Technical Support Department at
[phone] or check out our web site for technical resources at
www.glyphtech.com.

2

3

Unpacking, Inspection & General Info

Your Glyph WildFire CDR and accessories are packaged in a sturdy
shipping container. Please inspect the container for evidence of
shipping damage and mishandling. If such evidence is found, file a
report with the carrier or dealer immediately and do not attempt
to unpack and operate the WildFire CDR until the carrier or dealer
confirms the damage. All Glyph products are factory sealed and you
should not accept a box which has been previously opened.

Now, proceed with unpacking the WildFire CDR and verify that all
of the following items are present:

1 - The WildFire CDR itself

2 - One (1) FireWire Cable

3 - One (1) Power Cable

4 - Warranty Card

5 - CD Burning Software (Like Toast)

If any of the items are missing, contact the party from whom the
drive was purchased to arrange for replacement.

• It is a good idea to keep the shipping container and packing
materials if you plan to store or ship your WildFire CDR at some
future date.

4

Parts Identification

To familiarize yourself with the WildFire CDR, take a moment to
study the diagrams below. You will be connecting cables on the
drive shortly, so it will be helpful to know the layout of the
physical connections.

CD Tray

Power Indicator

Light

Power

Button

Headphone

Jack

Volume
Control

Eject

Button

Access

Light

Power Fan FireWire

Ports

Audio RCA

Outs
