GL Technologies GL-B1300 User Manual

HOME AC ROUTER

ver. 20171218.1

HARDWARE

Repair / Reset

If you cannot access the web-based setup page or cannot connect to the router,
you can press the Reset button:

Press and hold for 3 seconds then release to repair your network.

Press and hold for 10 seconds then release to reset the router
to factory settings. All user data will be cleared.

Package Contents

GL-B1300 AC router

Ethernet cable

12V/1.5A power adapter

User guide

Mesh

FIRST-TIME SETTINGS

When powered up, your router will broadcast a
Wi-Fi signal with the SSID: GL-XXXXX-xxx.

Visit http://192.168.8.1 in your browser to set up your
router; start by choosing your preferred language.

Plug the Internet

cable into WAN

Power

Power In

Data In

INTERNET SETTINGS

After you have set up your router, you will see the main web interface. Find
the Internet Settings icon, then click the New Connection button. Choose
Cable from the pop-up Internet Settings window.

Power In

Data In

The default protocol is DHCP. If your network needs a static
setting, you can change it to Static.
