User Manual
Luminaire software version 1.20
GLP® impression® FR1 TM (Trackmount) User Manual Revision B
This manual covers firmware version 1.20
© 2017-2019 German Light Products GmbH. All rights reserved.
The marks ‘GLP’ and ‘German Light Products’ are trademarks registered as the property of
German Light Products GmbH in Germany, in the United States of America and in other
countries.
The information contained in this document is subject to change without notice. German Light
Products GmbH and all affiliated companies disclaim liability for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss occasioned by the use of,
inability to use or reliance on the information contained in this document.
Manufacturer head office:
German Light Products GmbH (GLP), Industriestrasse 2, 76307 Karlsbad, Germany
Tel (Germany): +49 7248 92719 - 0
Service & Support EMEA:
GLP, Industriestrasse 2, 76307 Karlsbad, Germany
Tel. (Germany): +49 7248 9271955
Email: support@glp.de
www.glp.de
Service & Support USA:
GLP USA, 1145 Arroyo St., Ste. A, 91340 San Fernando, California
Tel (USA): +1 818 767 8899
Support (US): info@germanlightproducts.com
www.germanlightproducts.com
Contents
Safety ............................................................................................... 4
Avoiding damage ......................................................................... 9
Product overview ........................................................................10
Product features ..........................................................................11
Preparing for use .........................................................................15
Control menus and LCD display ...............................................21
Control menu layout ...................................................................22
DMX channel layout ...................................................................27
Service and maintenance .........................................................30
Technical specifications .............................................................33
Dimensi ons ....................................................................................35
www.glp.de
Safety
Key to symbols
The following symbols are used in this manual:
Warning! Safety hazard.
Risk of severe injury or
death.
Warning! See user
manual for important
safety information.
Warning! Risk of eye
injury.
Warning! Hazardous voltage.
Risk of lethal or severe
electric shock.
Warning! Fire hazard.
General safety information
Read this section carefully before installing or using the impression® FR1 TM
(Trackmount) luminaire. If you have any doubts or questions about how to use the
luminaire safely, contact your GLP® supplier for assistance. Your GLP supplier will be
happy to help.
The impression FR1 TM and this user manual are intended for use by experienced
professionals with the knowledge and skills to set up, operate, and maintain highpowered, remotely controlled lighting equipment safely and efficiently. These
operations require expertise that may not be provided in this manual.
• Respect all warnings and directions given in this user manual and on the luminaire.
Read this manual and familiarize yourself with the safety precautions it contains
before installing or using the luminaire. The manufacturer will take no responsibility for
damages or harm resulting from disregard for the information in this manual.
• Check the GLP website at www.glp.de and make sure that you have the latest
version of this user manual. Check also that the software version indicated on page 2
of the user manual matches the version installed in the luminaire. You can download
the correct version of this user manual if necessary.
• Make the user manual available to all installers and operators and save the manual
for future reference.
4 impression® FR1 TM
User Manual
German Light Products®
• If you have questions about the safe installation, operation or maintenance of the
impression FR1 TM, please contact an authorized GLP distributor (see list of distributors
at www.glp.de).
• Use the luminaire only as directed in this user manual. Observe all markings in this user
manual and on the luminaire.
• Refer any service operation not described in this manual and refer all repairs to a
technician authorized by GLP.
• The light source in this luminaire must not be changed by the end user.
• Read and follow the user documentation for all additional equipment.
Electrical safety
• Do not allow the luminaire to come into contact with water or moisture.
• Install the luminaire on EUTRAC 3 lighting track that is correctly and safely installed in
accordance with the lighting track’s user documentation and with local building and
electrical codes. The lighting track must be electrically connected to ground (earth)
and the installation must have both overload and ground fault (earth fault)
protection. The track must be in perfect condition and be rated for the electrical
requirements of all devices mounted on it. For more information, see the lighting track
manufacturer’s documentation.
• The lighting track must be connected to AC mains power at 100-240 V, 50/60 Hz. Do
not mount the luminaire on lighting track that is supplied with power from a dimmer or
presence detector.
• Shut down and lock out AC mains power to the lighting track before carrying out any
installation or maintenance work.
• Shut down power to the lighting track when the luminaire is not in use.
• Shut down power to the lighting track immediately if the track, luminaire or any seal,
cover, cable, or other component is damaged, defective, deformed, wet or showing
signs of overheating. Do not reapply power until the item has been repaired and
made safe by a qualified technician authorized by GLP.
• If a fuse blows, replace it with one of the original type and rating only. If new fuses
blow, disconnect the luminaire from power and send it to a technician authorized by
GLP for repair.
impression® FR1 TM User Manual 5
www.glp.de
Fire safety and protection from burns
• Do not operate the luminaire if the ambient temperature (Ta) exceeds 45° C (115° F).
• The surface of the luminaire’s casing can reach up to 55° C (131° F) during operation.
Avoid contact by persons and materials. Do not install the luminaire in a location
where there is a risk of accidental contact. Allow the luminaire to cool for at least 10
minutes before handling
• Keep the luminaire well away from flammable materials.
• Keep all combustible materials (e.g. fabric, wood, paper) at least 100 mm (4 in.)
away from the luminaire.
• Ensure that there is free and unobstructed airflow around the luminaire. Provide a
minimum clearance of 100 mm (4 in.) around fans and air vents.
• Do not illuminate surfaces within 500 mm (19.7 in.) of the luminaire.
• Do not install a fuse that has a higher rating than the one originally installed in the
luminaire. Do not bypass fuses.
• Do not stick filters, masks or other materials onto optical components.
• The luminaire’s optical components can focus the sun’s rays, creating a risk of fire and
damage. Do not expose the front of the luminaire to sunlight or any other intense light
source, even from an angle.
Eye safety
• The impression FR1 TM is classified as a Risk Group 2 luminaire according to EN 62471.
Possibly hazardous radiation emitted.
• Do not stare into the light output from the luminaire. May be harmful to the eyes.
• Do not look at the luminaire’s light output with optical instruments or any device that
may concentrate the light output.
• Make sure that persons working on or near the luminaire are not looking directly into
the light output when the luminaire lights up suddenly. This can happen when power
is applied, when the luminaire receives a DMX signal, or when certain control menu
items are selected.
• Provide well-lit conditions to reduce the pupil diameter of anyone working on or near
the luminaire.
6 impression® FR1 TM
User Manual
German Light Products®
Strobe safety
• Flashing light, particularly at 5 - 30 Hz, may cause seizures in persons with
photosensitive epilepsy. Do not use strobe effects for extended periods.
• Comply with local regulations on the use of strobe lighting and notify the public in
advance with highly visible warning signs when strobe effects are used.
• If a seizure occurs, stop using strobe effects. Seek professional medical help. Note the
time that the seizure starts and finishes. Call emergency medical help urgently if the
seizure lasts more than five minutes, if it is the person’s first seizure, or if the person is
injured. While waiting for help to arrive, consider the following general advice for
caring for a person who is having a seizure: Protect the affected person from injuring
themselves on hard or sharp objects. If necessary, move the person to a safe place.
Lay them on their side with their head supported to prevent it from hitting the floor.
Loosen any tight clothing around their neck. Do not use force to hold the person or
restrict their movements. Do not put anything in their mouth, including your fingers.
Installation safety and protection from personal injury
• Installation must be performed by qualified personnel only and carried out in
accordance with applicable regulations such as DIN VDE 0711-217.
• Restrict access below the work area and work from a stable platform whenever
installing, servicing or moving the luminaire.
• Mount the luminaire only on EUTRAC 3 lighting track that is correctly and safely
installed and rated for the weight of all the devices that will be installed on it.
• When installing a luminaire, support its weight until you have closed both of the two
mechanical fasteners at each side of the luminaire to lock the fasteners into the
lighting track. Do not allow the luminaire to hang from only one mechanical fastener.
• Allow a minimum center-to-center distance of 1000 mm / 40 in. between luminaires
on the lighting track. Do not install luminaires at less than this distance from each other
or you may overload the track and cause a safety hazard.
• Secure the luminaire against falling if the primary trackmount adapter fails by
equipping it with a safety cable as directed in this manual. The safety cable must be
approved for the weight of the luminaire and fastened to a secure anchoring point in
a fixed structure. If no fixed structure is available, secure the luminaire using the safety
cable and retaining collar supplied with the luminaire (or identical replacement items
supplied by GLP) as directed in this manual.
impression® FR1 TM User Manual 7
www.glp.de
• Before applying power to the luminaire, ensure that all fasteners are correctly closed,
that the luminaire is secure, and that the moving head can move through its full
range without risk of collision.
• Do not operate the luminaire with missing or damaged covers, shields or any optical
component.
• If the luminaire becomes damaged, stop using it immediately and remove it from the
installation. Do not attempt to use a luminaire that is obviously damaged.
• Do not modify the luminaire in any way not described in this user manual.
• Install genuine GLP parts only.
8 impression® FR1 TM
User Manual
German Light Products®
Avoiding damage
Do not point the front of the luminaire towards the sun or other strong light sources. The
front lens focuses and concentrates light just like a magnifying glass. Strong light can
cause internal damage to the luminaire, melting components or starting an internal fire
within seconds.
Figure 1. Avoiding damage from light sources
Damage can occur whether the luminaire is powered on or off. See Figure 1.Damage
can also occur if the light hits the front of the luminaire at an angle: the luminaire does
not need to be pointing directly at the sun or other light source.
To avoid problems from strong light sources:
• Do not expose the front of a luminaire to sunlight or any other strong light source.
• For outdoor applications during daylight, make sure that the front face of any
luminaire is shielded or points away from the sun, even when not in use.
• Avoid pointing other high-powered beam lights directly at the luminaire.
Do not pick up or carry the luminaire by the front lens bezel. The LCD display is also
fragile. Picking up or supporting the luminaire in these spots could result in damage
that is not covered by the product warranty.
Use only original spare parts. Any structural modification of the system will void the
product warranty.
Inspect the luminaire regularly and clean it if necessary. Clean the luminaire only as
directed in this manual. Oils, solvents, and other chemicals commonly used for
cleaning can damage the lens coatings and surfaces.
Do not drop the luminaire or expose it to mechanical stress.
Do not expose the luminaire to heat (from other lighting luminaires for example).
Transportation and storage
Transport the impression FR1 TM either in a flightcase or in its original packaging to
protect the luminaire from damage caused by shocks during transportation.
Store the luminaire in a dry location when not in use.
impression® FR1 TM User Manual 9
www.glp.de
Product overview
G
A
B
C
D
E
Figure 2: Product overview
A – Front lens assembly
B – Control panel with backlit LCD display
C – Wireless control antenna
D – Combined mechanical fastener and
power phase selection handscrew
E – Trackmount adapter
I
J
F – Cooling vent
G – Wireless control linking button
H – Fuseholder
I – Mechanical fastener lever
J – Safety cable attachment point
10 impression® FR1 TM
User Manual
German Light Products®
Product features
The impression® FR1 TM from GLP® is a high-quality moving head lighting luminaire with
a 60 watt RGBW LED and advanced optics that give a powerful, homogenous and
sharply defined beam throughout the luminaire’s 10:1 zoom range. Advanced
German design allows exceptional performance and a versatile feature set to be
packed into one of the most compact moving head lighting luminaires currently
available. Smooth pan and tilt head movement, RGB color mixing, color presets, zoom,
strobe, shutter and dimmer effects and wireless DMX control all make the FR1 TM a
spectacular alternative to static lighting track luminaires.
The luminaire is designed for easy mounting on EUTRAC 3 Standard Surface Lighting
Track.
See www.eutrac.de/3/1/en/products/~3_surface_track_standard.
It is possible to control large numbers of luminaires – individually and/or as groups – via
wireless DMX using the CRMX system from LumenRadio.
See https://lumenradio.com/products/wireless-dmx/.
The impression FR1 TM is not suitable for household use, for use in any location where
unattended children have access to it, or for use in permanent outdoor installations.
Light source
The impression FR1 TM is equipped with an OSRAM Ostar RGBW LED with a rated
lifetime of up to 50 000 hours.
Removable micro-Fresnel lens
A detachable micro-Fresnel lens is fitted to the front of the luminaire to give a smoother
beam. It is possible to remove this lens to obtain a harder-edged beam (see page 30).
Pan and tilt
The impression FR1 TM pans through 540° and tilts through 220° with coarse and fine
control channels and self-correcting position feedback.
Pan and tilt position feedback can be disabled using the control panel or the
Control/Settings DMX channel.
The direction of pan and tilt movement can be reversed by selecting Invert command
using the control panel or the Control/Settings DMX channel, and you can also swap
pan and tilt via the control panel. Inverting and swapping movement is a fast way of
obtaining symmetrical effects without reprogramming at the console.
The default settings for position feedback, inversion and swapping are OFF.
Continuous (endless) pan rotation is also available on a separate DMX channel.
Color
The impression FR1 TM lets you control color using both color presets and 0-100%
continuous RGBW color mixing.
impression® FR1 TM User Manual 11
www.glp.de
If you use the color presets channel, we recommend that you set RGBW levels to 100%
as a starting point before selecting a color preset. After you have selected a color on
the color preset channel you can then fine-tune it using the RGBW channels.
CTC
The CTC DMX channel lets you adjust color temperature from 2500 to 10 000 K.
If you use the CTC channel, we recommend that you set RGBW levels to 100% as a
starting point before setting a color temperature. After you have set a color
temperature on the CTC channel you can then fine-tune it using the RGBW channels.
Shutter effects
The impression FR1 TM features an electronic dimmer / shutter system that provides
pulse and strobe effects.
Dimming
0 – 100% continuous dimming is available.
Light
output
DMX control value
Figure 3. Dimming curves
See Figure 3. You can select from three different dimming curves using the control
panel or the Control/Settings DMX channel: Linear, Soft and Extra soft:
• Light output using the Linear curve will appear to increase and decrease evenly
throughout the dimming range.
• The Soft and Extra soft curves give finer control at low light levels (where the eye is
more sensitive to changes in light level) and coarser control at high levels.
The default setting is Extra soft.
12 impression® FR1 TM
User Manual
German Light Products®
Fan modes
The four different cooling fan modes give you a range of options to choose from
depending on how much you want to give priority to high-intensity light output or to
low fan noise:
• Regulated gives priority to light output. If the luminaire is blacked out, fans run at
minimum speed. When light output intensity is increased, temperature regulation
increases fan speed to the level necessary to keep the luminaire at optimum
temperature.
• If light output is set to maximum intensity but the fans can keep the luminaire at
optimum temperature, there will be no regulation of light intensity. If the luminaire
begins to exceed optimum temperature, light intensity will be reduced until
optimum temperature can be maintained.
• High mode is optimized for maximum light output and suits operation in high ambient
temperatures. Fans are set to constant operation at high speed and light output
intensity is regulated in order to keep luminaire temperature at optimum level.
• Besides maximizing light output in high ambient temperatures, you can use this
mode to cool down a luminaire quickly or to remove dust from cooling fans.
• Medium mode is suitable for low-noise operation in normal ambient temperatures.
Fans are set to constant operation at medium speed and light output intensity is
regulated in order to keep luminaire temperature at optimum level.
• Low mode is optimized for minimum noise. Fans are set to constant operation at low
speed and light output intensity is regulated in order to keep luminaire temperature at
optimum level.
• This mode gives an extremely low fan noise level, but if you use it in high ambient
temperatures there may be a noticeable reduction in light output intensity.
In all fan modes, if luminaire temperature reaches a dangerous level, LEDs will be shut
down for a period until the fans have brought the temperature down to a safe level.
You can set the cooling fan mode using the control panel or the Control/Settings DMX
channel.
Movement performance
Three settings are available for the movement of mechanical effects (pan, tilt, zoom
etc.):
• In Normal mode, movement is set to achieve a balance between speed, noise and
smoothness that will be best in average situations. This is the default setting.
• In Fast mode, all movement is set to high speed. This mode gives impressively fast
effects, but noise levels will be higher than in Normal mode.
• In Smooth mode, movement is optimized to obtain the smoothest action and lowest
noise. This mode gives super low-noise operation and smooth performance, but effect
movement is slower than in Normal mode.
You can select movement performance settings using the control panel or the
Control/Settings DMX channel.
impression® FR1 TM User Manual 13
www.glp.de
No-DMX (behavior when the luminaire is not receiving a DMX signal)
You can set the luminaire to respond in four different ways if no DMX signal is present (if
the luminaire is being controlled by DMX but the DMX signal stops, or if you apply
power to the luminaire when no DMX signal is present):
• Hold sets the luminaire to continue obeying the last DMX values it received. This is the
default setting.
• Blackout sets the luminaire to black out whenever it is not receiving a DMX signal.
• Stand-Alone sets the luminaire to play its stored stand-alone scene (see DMX Shot
below) when the luminaire is not receiving a DMX signal. If no stand-alone scene is
stored in memory, the luminaire will black out.
• DMX Shot takes a snapshot of the DMX values that are currently being received and
stores them in the luminaire’s memory as its stand-alone scene. The luminaire will
display this stand-alone scene if it is set to Stand-Alone (see above) and is not
receiving a DMX signal.
You can select one of the above four settings using the control panel or the
Control/Settings DMX channel.
Zoom
The impression FR1 TM has a 10:1 zoom range. You can narrow the beam angle from
35° in flood mode to 3.7° in spot mode.
Zoom can be inverted from flood spot to spot flood using the control panel and
the Control/Settings DMX channel. The default setting for zoom inversion is OFF.
Control panel
The control panel on the side of the yoke has a backlit graphic LCD display for setting
up the luminaire and changing luminaire settings. See ‘Control menu layout’ on page
22 for a table showing the control menu structure and options available.
PWM frequency
You can change the LED dimming PWM frequency using either a DMX command or a
control panel setting in order to avoid flicker and beat frequencies in video images.
The default PWM setting is 582 Hz. You can adjust the PWM frequency continuously
from 582 to 618 Hz, or you can set it to either 1200, 2400, 4800 or 9600 Hz. Note that a
higher PWM frequency may affect dimming performance.
The PWM frequency setting is stored in the luminaire and is not affected by cycling
power off and on. However, it will be affected if you use the Factory default command
in the control menus.
You should set all the luminaires in an installation to the same PWM frequency in order
to ensure the same performance. As described above, you can do this using the PWM
frequency selection or Factory default commands in the control menus or using the
PWM frequency DMX channel.
14 impression® FR1 TM
User Manual
German Light Products®
Preparing for use
Warning! Read ‘Safety’ starting on page 4 for important safety information
that you must understand before you install or operate the luminaire.
Included Items
See Figure 4. The impression FR1 TM is supplied with the following items:
• Retaining collar A for installing in lighting track
• Safety cable B with lockable clip and eyebolt for fastening to a retaining collar.
A
Figure 4. Included items
B
Installing the luminaire on lighting track
To install the luminaire:
Check that the lighting track is safely and correctly installed in accordance with
the track manufacturer’s instructions. Check that the track can safely support a
load of 5 kg per 500 mm / 11.1 lbs. per 20 in. Do not install more than one FR1 TM
luminaire per 1000 mm / 40 in.
Check that the head of the luminaire will be at least 0.5 m (20 in.) away from
combustible materials (paper, textiles, wood, etc.) when the luminaire is installed.
Shut down and lock out power to the lighting track.
Check that the fasteners at both ends of the luminaire’s track adapter are in the
open position and oriented so that they will fit correctly into the track.
Lift the luminaire up to the lighting track and pass the track adapter and fasteners
into the track. If the fasteners are not correctly oriented, remove the luminaire from
the track, turn it 180° end-to-end and pass the track adapter and fasteners into the
track again.
Warning! Support the weight of the luminaire until you have closed both
of the two mechanical fasteners at the ends of the track adapter. Do
not allow a luminaire to hang from one fastener only.
impression® FR1 TM User Manual 15
www.glp.de
See Figure 5. At the end of the track
adapter next to the wireless linking
button, use the lever (arrowed) to
close the main mechanical fastener.
This will fix one side of the luminaire
into the track and make the
connection to the Neutral line inside
the track. You must continue to
support the weight of the luminaire
until you have closed the other
mechanical fastener – do not allow
the luminaire to hang from one
Figure 5. Main mechanical fastener
fastener only.
At the antenna end of the track adapter, close the second fastener to fix the other
side of the luminaire into the track. Make the connection to one of the three power
phases by turning and/or pulling the knob on the fastener as follows:
• Turn clockwise = Phase 1
• Turn counter-clockwise =
Phase 2
• Pull and turn counter-
clockwise = Phase 3
• Pull and turn clockwise =
Neutral
See Figure 6. Note the position
of the safety cable
attachment point (arrowed) in
the luminaire’s baseplate.
Install a safety cable as
directed below.
Warning! Secure the luminaire with a safety cable using one of the two
options described in the following section. Do not leave an FR1 TM
luminaire suspended in lighting track unless it is secured with a safety cable.
Attachment point
Figure 6. Safety cable
attachment point
Option 1: Anchoring to a building or rigging structure
Provide a secure anchoring point such as a building member, eyebolt screwed into
a secure surface or rigging structure.
Obtain a safety cable that is approved by TÜV, UL or a similar organization as a
safety attachment for the weight of the luminaire. Fasten the safety cable to the
16 impression® FR1 TM
User Manual
German Light Products®
anchoring point and to the safety cable attachment point in the luminaire’s
baseplate so that it will hold the luminaire if the rigging clamp fails. Take up as
much slack as possible in the safety cable (by looping it more than once around
the rigging structure, for example).
Check that the luminaire will be held securely by the safety cable if the primary
attachment method fails.
Make sure that the head will not collide with another luminaire or any other object
when it tilts and rotates.
If you are going to install another luminaire on the same lighting track, allow a 1000
mm / 40 in. center-to-center distance between luminaires, or you may overload the
lighting track and cause a safety hazard.
Option 2: Anchoring to the lighting track
Check that power to the lighting track is still locked out.
See Figure 7. Note the flanges (arrowed) on the sides of the retaining collar that is
supplied with the luminaire.
Pass the flanges into the lighting track immediately next to the luminaire and turn
the retaining collar fully clockwise so that the flanges extend fully into the track.
Figure 7. Installing a retaining collar and safety cable
Screw the M8 eyebolt on the end of the safety cable that is supplied with the
luminaire firmly into the retaining collar. Check that the eyebolt is now held securely
in the lighting track.
impression® FR1 TM User Manual 17
www.glp.de
See Figure 8. Attach the free end of the safety
cable to the safety cable anchoring point in the
luminaire’s baseplate using the lockable
carabiner clip (arrowed in Figure 8) on the end of
the safety cable. Fasten the lock on the carabiner
clip so that the safety cable cannot become
unfastened from the luminaire.
Check that the luminaire will be held securely by
the safety cable if the primary attachment
method fails.
Make sure that the head will not collide with
another luminaire or any other object when it tilts
and rotates.
If you are going to install another luminaire on the
same lighting track, allow a 1000 mm / 40 in.
center-to-center distance between luminaires, or
you may overload the lighting track and cause a
safety hazard.
Figure 8. Carabiner clip
18 impression® FR1 TM
User Manual
German Light Products®
Setting up for DMX control
To configure the luminaire for control via DMX, open the menus in the fixture’s control
panel and set the fixture’s DMX Address. Note the following:
• The FR1 TRM uses 16 DMX channels. If individual control of luminaires is required, each
luminaire must have its own 16 channels in the 512 channels that are available in one
DMX universe. If you give the first luminaire DMX address 1, for example, you should
give the next luminaire DMX address 17.
• If you want two or more luminaires to behave identically at all times, you can give
them the same DMX address.
• The default DMX address is 1.
• If you need to use more than 512 DMX channels, use a DMX controller that can
manage two or more DMX universes.
Use certified DMX cable for DMX links between XLR-type DMX connectors.
Connecting to a CRMX wireless control system
The impression FR1 TM has an onboard wireless receiver that allows remote control by
DMX over a Lumenradio CRMX wireless network. You can use any transmitter that is
CRMX-compatible.
See Figure 9. Either connect a PC running a DMX control application via a USB-DMX
interface or connect a dedicated DMX control console to a CRMX transmitter. Check
the user documentation of those devices (make sure that the luminaires will be within
the transmitter’s range, for example).
Figure 9. CRMX wireless control system
To establish wireless connections between the CRMX transmitter and luminaires:
Apply power to the luminaires and to the CRMX transmitter.
impression® FR1 TM User Manual 19
www.glp.de
If the luminaires are set up with any existing network connections, delete them by
pressing and holding the wireless linking button on the side of the luminaire for
around 10 seconds. The luminaire is now ready for a new connection.
Put the CRMX transmitter into discovery mode following the instructions in the
transmitter’s user documentation. The transmitter will now search for unlinked
luminaires for a limited period.
To link one or more impression FR1 TM luminaires to the transmitter, press the wireless
linking button on the side of the luminaire(s) once. As soon the button is pressed the
luminaire will try to connect to any CRMX transmitter that is within range and in
discovery mode.
If a handshake between a luminaire and a transmitter is successful and a connection is
established, the connection is stored in both the luminaire and the transmitter. The
luminaire and transmitter will remember the connection after a power cycle.
It is normally a good idea to delete any connections that are stored in a transmitter
before starting new linking processes. Deleting stored connections will help to ensure a
clean new installation.
Unlinking and linking luminaires
You can unlink a luminaire from a CRMX network at any time by pressing the wireless
linking button on the side of the luminaire and holding for around 10 seconds.
You can link an unlinked luminaire to a CRMX Network at any time by putting the
transmitter into discovery mode and pressing the wireless linking button on the side of
the luminaire once. The luminaire will then connect to the transmitter automatically. If
the luminaire fails to connect, press the wireless linking button for about 10 seconds to
delete any stored links, and then try the procedure again.
Advice and assistance
If you would like advice with planning or implementing a DMX control system over
Lumenradio CRMX, your GLP supplier will be happy to help.
20 impression® FR1 TM
User Manual
German Light Products®
Control menus and LCD display
Warning! DMX control is disabled when the control menus are active. Be
prepared for the head to move as soon as you exit the control menus.
The control panel and LCD display provide access to user settings, readouts, and
utilities. See ‘Control menu layout’ on page 22 for details of the options available. Note
that many of these options are also available via DMX on the Control/Settings DMX
channel-
When power is applied, the luminaire resets. After the reset has completed, the main
menu is displayed:
V:1.20/NE 582
-214
Next
198
DMX Start Address
215
Mode Enter Down UP
O O
Figure 10. Main menu
See Figure 10. From left to right, the top line of the main menu displays:
• Main CPU software version
• DMX control mode: N (Normal)
• Dimming curve: L (Linear), S (Soft) or E (Extra Soft)
• PWM frequency.
In the example shown in Figure 10, the luminaire is running CPU software version 1.20.
The luminaire is in Normal DMX control mode and set to the Extra-soft dimming curve.
The current PWM frequency is 582.
A flashing display indicates loss of DMX.
To use the control panel:
O
O
• Use the Down and Up buttons to scroll between menu options.
• Press the Enter button to select a setting, confirm a command or enter a submenu.
• Press the Mode button to escape and return to the top of the menu.
impression® FR1 TM User Manual 21
www.glp.de
Control menu layout
DMX Start
Address
Setup DMX Mode NORM
Settings
1 - 512 DMX start address
Pan/Tilt
Zoom
Shutter
Init Positions
Dimming
Curve
Invert Pan
Invert Tilt ON / OFF Invert tilt up/down
Swap
Pan/Tilt
Position
Feedback
Pan
Enable
Tilt Enable ON / OFF
Movement
performance
Invert
Zoom
Error
Blackout
No DMX
Blackout
Save
Reset
Linear
Soft
Extra Soft
ON / OFF Invert pan left/right
ON / OFF Swap Pan/Tilt channels
ON / OFF
ON / OFF
Fast
Normal
Smooth
ON / OFF
ON / OFF
ON / OFF
Disable position encoders
for Pan/Tilt
On: Enabled and
controllable via DMX
Off: Disabled and no
motor current
On: Enabled and
controllable via DMX
Off: Disabled and no
motor current
Effects movement
optimized for highest
speed
Effects movement
standard
Effects movement
optimized for smoothness
and lowest noise
Zoom inverted from Flood
Spot to
Spot Flood
Light output is stopped if
an error occurs
Light output is stopped if
DMX fails for 3 seconds
Save current positions as
initial positions after reset
without DMX
Reset initial positions after
reset without DMX
Select dimming curve
option
22 impression® FR1 TM
User Manual
German Light Products®
DMX Hold
PWM
Frequency
Settings
(continued)
Information
Display
Temperature
Unit
Fan Mode
Reset
Factory
Settings
System Errors List
System
Versions
Blackout
Hold
Stand-Alone
DMX Shot
582-618 Hz / 1200 Hz /
2400 Hz
Contrast 0 - 50 -100 % Set display contrast
Brightness 0 - 100 %
Blackout
Time
Display
Orientation
No DMX
Flash
°C / °F Sets units shown in display
Regulated
High
Medium
Low
Confirm (Yes/No)
Main (SW/HW)
Pan/Tilt (SW/HW)
LED Driver (SW/HW)
1 - 10 -30 s
Normal /
Inverted
ON / OFF Display flashes if DMX fails
Luminaire blacks out if
DMX signal is lost
Last DMX values are held
if signal is lost
Luminaire goes to stored
stand-alone scene if DMX
signal is lost
Take snapshot of current
scene and save it as
stand-alone scene
Set LED PWM frequency
Set display brightness
(Auto Brightness must be
disabled)
Set time until display
blackout after last
keystroke (Auto Blackout
must be enabled)
Flip display up/down
Temperature- regulated
cooling fan operation
Constant cooling fan
speed
Reset all values (except
serial number) to factory
defaults
Show all recent errors
(permanent)
Main luminaire software
(main application, boot
loader) and hardware
versions
Pan/tilt software and
hardware versions
LED driver and hardware
versions
impression® FR1 TM User Manual 23
www.glp.de
Temperatures
Luminaire
Information
Information
(continued)
DMX Input
Monitor
Fans Monitor
-128 - 127
°C/°F
-128 - 127
°C/°F
-128 - 127
°C/°F
-128 - 127
°C/°F
-128 - 127
°C/°F
-128 - 127
°C/°F
0-99999 h
Main
Temperature
LED
Temperature
Luminaire
Hours
Current
Maximum
resettable
Maximum
nonresettable
Current
Maximum
resettable
Maximum
nonresettable
Total hours 0-99999 h
Resettable
hours
Boot count 0-99999
Pan rotation
Zoom
Special
CTC
Dimmer
Shutter
White
Blue
Green
Red
Color Wheel
Tilt
Pan rotation
PSU Fan RPM (/U)
Head Fan RPM (/U)
Main head
temperature
sensor readouts
LED
temperature
readouts
Total operation
time from new
Resettable hours
counter
Number of times
luminaire has
been started up
(non-resettable)
DMX values
received on
each channel
Fan speeds (and
voltages)
24 impression® FR1 TM
User Manual
German Light Products®
Reset
Manual
Control
Manual
DMX
Full System
Reset
Pan/Tilt
Reset
LED Driver
Reset
Pan
Confirm (Yes/No) Reset luminaire
Confirm (Yes/No)
Confirm (Yes/No) Reset LED driver only
0 - 255
Zoom 0 - 255
Pan rotation 0 - 255
Special 0 - 255
CTC 0 - 255
Dimmer 0 - 255
Shutter 0 - 255
White 0 - 255
Blue 0 - 255
Green 0 - 255
Red 0 - 255
Color Wheel 0 - 255
Tilt 0 - 255
Pan 0 - 255
Reset All
Values
Confirm (Yes/No)
Reset pan and tilt
only
Manually apply
DMX values (these
commands are
available if no DMX
is present – values
are overwritten by a
DMX signal). Values
are reset to initial
values after a
luminaire reset.
Set all manual DMX
values to 0
impression® FR1 TM User Manual 25
www.glp.de
Pan/Tilt ON / OFF
Test
Service
Colour ON / OFF
All ON / OFF
Enter Code 0 - 255
Serial 0 - 99999
Clear
EEPROM
LED
Calibration
Pan 0 - 128 - 255
Tilt 0 - 128 - 255
Zoom 0 - 128 - 255
0 - 255
Red-Max
Green-Max 0 - 128 - 255
Blue-Max 0 - 128 - 255
White-Max 0 - 128 - 255
0 - 128 - 255
Run test sequence
Enter code (contact
GLP if you would like
the code) to access
Service Menu (resets
automatically after
luminaire restart or
after 10 min. with no
control panel input)
Last 5 digits of
luminaire’s serial
number. Needed for
correct RDM
operation
Clear time and
power on values
Adjust base RGBW
intensity
Adjust pan home
position
Adjust tilt home
position
Adjust zoom home
position
Default values are shown in bold type.
User-settable values are displayed in grey boxes.
26 impression® FR1 TM
User Manual
German Light Products®
DMX channel layout
Normal mode (16 DMX channels)
Channel Function Description
1
2
3
4
5
6
7
8
9
10
11
12
13
Pan coarse
Pan fine
Tilt coarse
Tilt fine
Color presets
(virtual color
wheel)
Red Color mixing - Red 0 – 255 255 0 – 100% Fade
Green Color mixing - Green 0 – 255 255 0 – 100% Fade
Blue Color mixing - Blue 0 – 255 255 0 – 100% Fade
White Color mixing - White 0 – 255 0 0 – 100% Fade
Shutter / strobe
Dimmer coarse
Dimmer fine
CTC RGBW raw
Left – right in 1.2°
increments (16 bit)
Up – down in 1.2° increments
(16 bit)
RGBW control
Color 01 - Red
Color 02 - Amber
Color 03 - Warm yellow
Color 04 - Yellow
Color 05 - Green
Color 06 - Turquoise
Color 07 - Cyan
Color 08 - Blue
Color 09 - Lavender
Color 10 - Mauve
Color 11 - Magenta
Color 12 - Pink
White – CTO
White
White – CTB
Rainbow effect stop
Rainbow effect active
Random colors slow – fast
Shutter closed
Shutter pulse random
Fade on, snap off (random
patterns)
Snap on, fade off (random
patterns)
Fade on, fade off (random
patterns)
Strobe with blackout pause
Strobe effect slow - fast
Shutter open
Intensity 0 – 100% 0 – 65535 0 0 – 100% Fade
CTC 10 000 K – 2500 K
DMX
range
0 – 65535 32768 0 – 100% Fade
0 – 65535 32768 0 – 100% Fade
0 – 7
8 – 15
16 – 23
24 – 31
32 – 39
40 – 47
48 – 55
56 – 63
64 – 71
72 – 79
80 – 87
88 – 95
96 – 103
104 – 111
112 – 119
120 – 127
128
129 – 223
224 – 255
0 – 15
16 – 47
48 – 79
80 – 111
112 – 143
144 – 199
200 – 239
240 – 255
0 – 15
16 – 255
Default
DMX
0 0 – 2.5%
255 0 – 5.5%
0 0 – 5.9%
% Range* Fade
3 – 5.5%
6 – 9%
9.5 – 12%
12.5 – 15%
15.5 – 19.5%
20 – 21.5%
22 – 24.5%
25 – 27.5%
28 – 31%
31.5 – 34%
34.5 – 37%
37.5 – 40.5%
41 – 43.5%
44 – 46.5%
47 – 49.5%
50.2%
50.5 – 87.5%
88 – 100%
6 – 18.5%
19 – 31.5%
32 – 43.5%
44 – 62.5%
63 – 77.5%
78 – 94.5%
95 – 100%
6 – 100%
Snap
Fade
Fade
Snap
Fade
Fade
Fade
Fade
Fade
Fade
Snap
Snap
Fade
impression® FR1 TM User Manual 27
www.glp.de
14
Control/Settings
(see notes at
end of this
table)
Idle
No function
Performance = Fast*
Performance = Normal*
Performance = Smooth*
No function
Dimmer curve = Extra-soft*
Dimmer curve = Linear*
Dimmer curve = Soft*
No function
Display auto-off*
Display permanently on*
Display invert off*
Display invert on*
No function
No DMX = Blackout*
No DMX = Hold current effect*
No DMX = Stand-Alone*
No DMX = Save Snapshot*
No function
Fans temperature-regulated*
Fans constant high*
Fans constant medium*
Fans constant low*
No function
P/T position feedback off*
P/T position feedback on*
No function
Tilt invert off*
Tilt invert on*
Pan invert off*
Pan invert on*
Zoom invert off*
Zoom invert on*
No function
PWM frequency:
582 Hz**
583 Hz**
584 Hz**
585 Hz**
586 Hz**
587 Hz**
588 Hz**
589 Hz**
590 Hz**
591 Hz**
592 Hz**
593 Hz**
594 Hz**
595 Hz**
596 Hz**
597 Hz**
598 Hz**
599 Hz**
600 Hz**
601 Hz**
602 Hz**
603 Hz**
604 Hz**
605 Hz**
606 Hz**
0 – 11
12 – 26
27 – 29
30 – 32
33 – 35
36 – 38
39 – 41
42 – 44
45 – 47
48 – 56
57 – 59
60 – 62
63 – 65
66 – 68
69 – 71
72 – 74
75 – 77
78 – 80
81 – 83
84 – 86
87 – 89
90 – 92
93 – 95
96 – 98
99 – 104
105 – 107
108 – 110
111 – 116
117 – 119
120 – 122
123 – 125
126 – 128
129 – 131
132 – 134
135 – 149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
0 0 – 4.3%
4.7 – 10.2%
10.6 – 11.4%
11.8 – 12.5%
12.9 – 13.7%
14.1 – 14.9%
15.3 – 16.1%
16.5 – 17.3%
17.6 – 18.4%
18.8 – 22.0%
22.4 – 23.1%
23.5 – 24.3%
24.7 – 25.5%
25.9 – 26.7%
27.1 – 27.8%
28.2 – 29.0%
29.4 – 30.2%
30.6 – 31.4%
31.8 – 32.5%
32.9 – 33.7%
34.1 – 34.9%
35.3 – 36.1%
36.5 – 37.3%
37.6 – 38.4%
38.8 – 40.8%
41.2 – 42%
42.4 – 43.1%
43.5 – 45.5%
45.9 – 46.7%
47.1 – 47.8%
48.2 – 49%
49.4 – 50.2%
50.6 – 51.4%
51.8 – 52.5%
52.9 – 58.4%
58.8%
59.2%
59.6%
60%
60.4%
60.8%
61.2%
61.6%
62%
62.4%
62.7%
63.1%
63.5%
63.9%
64.3%
64.7%
65.1%
65.5%
65.9%
66.3%
66.7%
67.1%
67.5%
67.8%
68.2%
Snap
28 impression® FR1 TM
User Manual
German Light Products®
14
continued
15
16
607 Hz**
608 Hz**
609 Hz**
610 Hz**
611 Hz**
612 Hz**
613 Hz**
614 Hz**
615 Hz**
616 Hz**
617 Hz**
618 Hz**
No function
1200 Hz**
2400 Hz**
4800 Hz**
9600 Hz**
No function
Reset entire luminaire*
Zoom Flood wide – narrow 0 – 255 0 0 – 100% Fade
Endless pan
rotation
Stop
Pan rotation CW fast – slow
Stop
Pan rotation CCW slow – fast
Stop
175
176
177
178
179
180
181
182
183
184
185
186
187 – 191
192 – 194
195 – 197
198 – 200
201 – 203
204 –251
252 – 255
0
1 – 127
128
129 – 254
255
68.6%
69.0%
69.4%
69.8%
70.2%
70.6%
71.0%
71.4%
71.8%
72.2%
72.5%
72.9%
73.3 – 74.9%
75.3 – 76.1%
76.5 – 77.3%
77.6 – 78.4%
78.8 – 79.6%
80 – 98.4%
98.8 – 100%
0 0%
0.5 – 49.5%
50.2%
50.5 – 99.5%
100%
Snap
Fade
Snap
Fade
Snap
Notes:
Percentage values are calculated by dividing DMX values by 2.56 and rounding to the
nearest 0.1%.
*To apply a command on Channel 14 (Control/Settings), start at a value of zero, then
move to the required value and hold it for at least 3 seconds. If you move to the
required value from any other value than zero, the command will not be applied.
**To adjust the PWM frequency using the Control/Settings channel, start at a value of
zero, move to the required value and hold it for at least 5 seconds.
impression® FR1 TM User Manual 29
www.glp.de
Service and maintenance
Warning! Read ‘Safety’ starting on page 4 for important safety information
that you must understand before you service the luminaire. Work in well-lit
conditions. Do not look directly into the light output.
Maintenance
Suggested maintenance intervals
The cleaning schedule depends on the operating environment. The intervals below are
suggestions from our experience with typical installations. Adjust as necessary.
Maintenance Task Interval How
Clean front lens Weekly
Clean fans and air channel Monthly
Lubricate zoom rails
Yearly or as
necessary
Wipe with soft cloth and glass cleaning
fluid.
Use soft brush and vacuum cleaner. Hold
fan blades still with pen or screwdriver to
avoid spinning them too fast with vacuum.
Apply tiny quantity of Klüber Barrierta to
rails.
Cleaning
impression FR1 TM components require occasional cleaning to prevent the buildup of
dust, dirt, and smoke fluid residue. Pay special attention to the air vents and front lens.
Failure to keep the luminaire clean will significantly reduce light output and may cause
damage. Do not let optical parts come into contact with oil or grease or touch with
bare fingers.
Regular cleaning will ensure the maximum performance and reliable operation. The
lenses and glass gobos may be cleaned with alcohol wipes or a soft cloth moistened
with isopropyl alcohol.
Wait until all parts are dry before operating the luminaire.
Lubrication
The only parts that may require occasional lubrication are the focus/zoom rails.
Contact GLP Service and Support for advice.
Removing and reinstalling the micro-Fresnel lens
If you would like to obtain a sharper-edged beam, you can remove the micro-Fresnel
lens that is installed in the front of the head (bear in mind that this will result in a slight
loss of evenness in the beam projection). The lens is held by three screws. A frost filter is
installed immediately under the lens.
30 impression® FR1 TM
User Manual
German Light Products®
To remove the micro-Fresnel lens:
Shut down power to the luminaire and allow it to cool.
Figure 11. Removing a micro-Fresnel lens
See Figure 11. Remove the three Phillips #1 screws (arrowed) from the lens in the
front of the head.
Tilt the head downwards and allow the lens A and frost
filter B to slide out of the head. Store the lens for possible
re-use.
Reinstall the frost filter in the head by passing the three
screws through the notches in the filter and tightening
them into their holes in the head.
If you reinstall the micro-Fresnel lens later, use the three
Phillips screws to fasten it into its original position over the
frost filter. See Figure 12. The smooth side of the lens must
face inwards and the ridges must face out of the head.
Figure 12. Lens
orientation
impression® FR1 TM User Manual 31
www.glp.de
Main fuse
See Figure 13. The main fuse sits in a holder
in the bottom of the base.
If the luminaire appears to be completely
shut down even though power is applied,
the main fuse may have blown. Shut
down power to the track system before
replacing the fuse. Replace only with a
fuse of the same type and rating.
Figure 13. Main fuse
GLP Service and Support
Contact information for the nearest GLP Service and Support is available online at
www.glp.de/en/service, by request via email at info@glp.de, or by telephone at the
following numbers:
• GLP Germany: +49 (7248) 927 1955
• GLP N. America: +1 818 767-8899
• GLP U.K.: +44 1392 690140
• GLP Asia: +852 (3151) 7730
• GLP Nordic: +46 737 57 11 40
32 impression® FR1 TM
User Manual
German Light Products®
Technical specifications
Light source
LED type: Osram Ostar RGBW
LED lifetime: 50.000 hours
Number of LEDs: 1
CRI (Ra): 80
TLCI: 80
TM30-15 77/106
Optics
Min. zoom angle: 3.7°
Max. zoom angle: 35°
Zoom range: 10:1
Effects
Color mixing: RGBW continuous
Color presets: 12 + 3 whites, adjustable via RGBW
Color temperature correction: 2500 K – 10 000 K, electronic, adjustable via RGBW
Dimmer: 0-100% continuous, electronic
Shutter/strobe: Pulse and strobe effects, max. 14 Hz, electronic
Variable PWM frequency
Movement
Resolution: 8 - 16 bit
Positional feedback: Yes
Pan range: 540°
Tilt range: 220°
Endless movement: 360° endless pan rotation
Control
Control system: USITT DMX512
Control data communication: LumenRadio CRMX wireless system
Onboard interface: Control panel with backlit LCD graphical display
Luminaire settings: Onboard control panel or via wireless DMX
Installation
Hanging vertical installation from EUTRAC 3 Standard Surface Lighting Track
Minimum center-to-center distance when installed: 1000 mm / 40 in.
Safety cable for secondary attachment of luminaire required
impression® FR1 TM User Manual 33
www.glp.de
Electrical
AC power: 100-240 V, 50/60 Hz
Maximum power consumption @230 V: 80 W
Power consumption at idle: 14 W
Primary fuse: 20 mm T 2A
EEC (Energy Efficiency Class): E
EEI (Energy Efficiency Index): 1.193
Energy consumption (kWh/1 000 h): 68
Thermal
Temperature-regulated forced air cooling
Thermal protection system
Maximum ambient temperature: 45° C / 115° F
Minimum ambient temperature: 5° C / 41° F
Product color
White (standard)
Included items
Lighting track safety cable with carabiner clip and M8 eyebolt
Retaining collar for M8 eybolt
Shipping options
Single product: Cardboard packing case
Dimensions and weight
Depth: 140 mm / 5,5 ins.
Width: 190 mm / 7.5 ins.
Height (head vertical, zoom at max. extension): 355 mm / 14.0 in.
Weight: 5 kg / 11 Ibs.
Minimum center-to-center distance: 1000 mm / 40 in.
Note: Specifications are subject to change without notice.
34 impression® FR1 TM
User Manual
German Light Products®
Dimensions
Dimensions given in millimeters
impression® FR1 TM User Manual 35
Loading...
