GLP Impression FR10 LED Bar, schwarz User Manual [EN]

User Manual

Software version V. 30

Rev. 20210901-2

Document revisions

Revision number

Notes

Released

Rev. A

First version available.
Firmware v.20

04/2020

Rev. 20210901-2

Added layer 1/2/3 priority control via
DMX or using control panel (Color Mix
Priority setting).
Firmware v.30

09/2021

GLP® impression FR10 Bar User Manual – Revision 20210901-2

This document covers fixture software V.30

© 2019-2021 German Light Products GmbH. All rights reserved.

The marks ‘GLP’ and ‘German Light Products’ are trademarks registered as the property of German
Light Products GmbH in Germany, in the United States of America and in other countries.

The information contained in this document is subject to change without notice. German Light
Products GmbH and all affiliated companies disclaim liability for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to
use or reliance on the information contained in this document.

Manufacturer’s head office:
German Light Products GmbH (GLP), Industriestrasse 2, 76307 Karlsbad, Germany
Tel (Germany): [phone] - 0

Service & Support EMEA:
GLP, Industriestrasse 2, 76307 Karlsbad, Germany
Tel. (Germany): [phone]
Email: [e-mail]
www.glp.de

Service & Support USA:
GLP USA, 1145 Arroyo St., Ste. A, 91340 San Fernando, California
Tel (USA): [phone]
Support (US): [e-mail]
www.germanlightproducts.com

Table of Contents

1. Safety ........................................................................................................... 4

Key to symbols ....................................................................................... 4

GLP Service and Support ..................................................................... 5

2. FR 10 Bar overview ..................................................................................... 6

3. Features ....................................................................................................... 7

Tilt ............................................................................................................ 7

Intensity/Dimmer ................................................................................... 7

Shutter .................................................................................................... 7

Control/Settings channel ..................................................................... 8

CTC ......................................................................................................... 8

Virtual color wheel ................................................................................ 8

Zoom ....................................................................................................... 9

Individual cell control ........................................................................... 9

Individual pixel control ......................................................................... 9

Individual zoom control ........................................................................ 9

FX engine ............................................................................................... 9

Multi-layer concept .............................................................................. 9

Pattern control .................................................................................... 10

Pattern length and offset ................................................................... 10

Crossfading .......................................................................................... 12

Transition .............................................................................................. 12

4. Control panel and display ...................................................................... 13

Control panel ...................................................................................... 13

Main screen ......................................................................................... 14

Error code display ............................................................................... 15

Button Shortcuts .................................................................................. 15

Contents of the Quick Menu ............................................................. 15

Main menus ......................................................................................... 16

5. Control menu layout ............................................................................... 25

Shortcut menu ..................................................................................... 29

6. DMX control modes overview ................................................................ 30

7. DMX control channel layout................................................................... 35

DMX Mode 1: Normal (default DMX mode) .................................... 36

DMX Mode 2: Multi-Layer ................................................................... 43

DMX Mode 3: MultiPix Normal ........................................................... 55

DMX Mode 4: MultiPix Advanced ..................................................... 59

www.glp.de

4 impression FR10 Bar User Manual Rev. 20210901-2

1. Safety

Key to symbols

The following symbols are used in this document:

Warning! Read the FR10 BAR Quick Start and Safety Manual supplied with
the fixture and available for download from www.glp.de before installing,
operating or servicing the fixture. The Quick Start and Safety Manual

contains important information for the safe use of FR10 BAR fixtures. If you fail
to read that information you may create a safety hazard with a risk of injury,
death or damage.

If you have any doubts or questions about how to use the GLP® impression FR10 BAR
lighting fixture safely, contact your GLP supplier for assistance. Your GLP supplier will be
happy to help.

The user documentation for impression FR10 BAR fixtures consists of three documents:

• The FR10 BAR Quick Start and Safety Manual, supplied with FR10 BAR fixtures and
available for download from www.glp.de. The Quick Start and Safety Manual
contains important safety information and installation instructions that the installer
and user must read. It also contains dimensions drawings and technical
specifications for the fixture.

• The FR10 BAR User Manual, available for download from www.glp.de. The User
Manual explains features and control of FR10 BAR fixtures.

• The FR10 BAR DMX Channel Index, available for download from www.glp.de. The
Channel Index is a separate document containing the DMX control channel layout
and DMX commands available in the fixture. This information is also included in the
User Manual.

The FR10 BAR is intended for use by experienced professionals with the knowledge and
skills to set up, operate, and maintain high-powered, remotely controlled lighting
equipment safely and efficiently. These operations require expertise that may not be
provided in this manual.

Warning! Safety hazard.
Risk of severe injury or
death.

Warning! Hazardous voltage.
Risk of lethal or severe
electric shock.

Warning! See user
manual for important
safety information.

Warning! Fire hazard.

Warning! Risk of eye
injury.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 5

• Respect all warnings and directions given in the fixture’s user documentation and
on the fixture. Read the fixture’s Quick Start and Safety Manual and familiarize
yourself with the safety precautions it contains before installing, using or servicing
the fixture. GLP and affiliated companies will take no responsibility for damage or
injury resulting from disregard for the information in the user documentation.

• Check the GLP website at www.glp.de and make sure that you have the latest
versions of the fixture’s Quick Start and Safety Manual and this user manual.

• Check the fixture software version indicated on page 2 of this user manual and

then use the fixture’s control panel to check the version installed in the fixture. If the

versions are not the same, the user manual may still cover the fixture, because
software updates do not always affect the use of the fixture. However, it is possible
that this manual does not match the fixture perfectly. Software release notes can
help clarify this question. You can consult software release notes and download the
correct version of this user manual on the GLP website if necessary.

• Make both the Quick Start and Safety Manual and this user manual available to all
persons who will install, operate or service the fixture. Save both documents for
future reference.

• If you have any questions about the safe operation of the fixture, please contact
an authorized GLP distributor (see list of distributors at www.glp.de).

GLP Service and Support

Contact information for the nearest GLP Service and Support is available online at
www.glp.de/en/service, by email at [e-mail], or by telephone at the following
numbers:

• GLP Germany: [phone]

• GLP N. America: [phone]

• GLP UK: [phone]

• GLP Asia: [phone]

• GLP Nordic: [phone]

www.glp.de

6 impression FR10 Bar User Manual Rev. 20210901-2

2. FR 10 Bar overview

A – Head

B – Pixel zoom lens

C – Alignment pins button

D – DMX IN (5-pin XLR)

E – AC mains power IN (Neutrik powerCON TRUE1)

F – etherCon Port IN/THRU, fail-safe (Art-Net / sACN)

G – Fuseholder

H – Control panel with backlit display

I – etherCon Port IN/THRU, fail-safe (Art-Net / sACN)

J – AC mains power THRU (Neutrik powerCON TRUE1)

K – DMX THRU (5-pin XLR)

F

H

B

D

J

A

IKE

G

C

Figure 1. FR 10 Bar overview

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 7

3. Features

The impression FR10 BAR is a powerful LED-based linear format lighting fixture from GLP
that features a head that tilts through 200° and ten independently controllable zoom
lenses.

The FR10 Bar contains 10 x 60 Watt RGBW LED sources that are color matched with
GLP’s X4 and FR series. Each source features smooth, full range color mixing with a
homogenized Fresnel lens. Along with individual color control, the impression FR10 Bar
offers a powerful multi-layer zoom and color effects engine.

The fixture has a 10:1 ratio zoom range from 3.7° to 35° one-tenth peak angles. What
makes it unique is the ability to control each of the zoom lenses independently.

A separate CTO DMX channel is available in all the fixture’s DMX control modes, letting
you quickly adjust the warmth of the white light output.

Fixtures feature an alignment system that lets you build unbroken lines of pixels, and
power and data can be daisy-chained for ease of installation. The FR 10 Bar can be
placed upright on a level surface or suspended from a suitable structure as described
in the fixture’s Quick Start and Safety Manual.

A front glass is installed in mounting channels with a quick-release system on the front
of FR10 BAR fixtures. These channels can also be used for mounting optical accessories
from GLP.

Tilt

The impression FR10 Bar offers motorized tilt from +100 to -100 degrees with 16-bit
control and automatic position correction (position feedback).

The Tilt function can be inverted using the FIXTURE SETTINGS → TILT INVERT menu, tilt
position feedback can be disabled using FIXTURE SETTINGS → POSITION FEEDBACK, or
Tilt can be disabled completely using FIXTURE SETTINGS → TILT DISABLE.

Intensity/Dimmer

Output can be controlled by a dimmer channel in 16-bit resolution, following 2
separate dimmer curves (FIXTURE SETTINGS → DIMMER CURVE).

The global intensity channel controls the output of the entire fixture (it dims all layers).

In DMX control modes that offer a separate dimmer/shutter for a layer, that
dimmer/shutter will only affect the layer that offers it.

Shutter

The separate Shutter channel gives control of Open and Blackout as well as different
shutter effects:

• Dimmer Flash sets the fixture to perform one single flash each time there is a
change in the value being sent on the Intensity/Master channel.

• Pulse smoothly fades intensity up and down with same fade-in and fade-out times.

• Opening Pulse fades intensity up and then snaps to blackout.

www.glp.de

8 impression FR10 Bar User Manual Rev. 20210901-2

• Closing Pulse fades intensity down and then snaps to 100%.

• Strobe Double Flash gives a fast double flash.

• Strobe Pixel Random flashes individual pixels at random, giving a sparkling effect.

• Strobe Random flashes all the fixture’s pixels together at random intervals. This lets

you set up a random strobe across multiple fixtures. Note that the random effect
between multiple fixtures really is completely random.

• Strobe flashes all the pixels of a fixture together. It will also flash all the pixels of
multiple fixtures together in perfect synchronization.

The global shutter channel controls the output of the entire fixture (the shutter affects
all layers).

In DMX control modes that offer a separate dimmer/shutter for a layer, that
dimmer/shutter will only affect the layer that offers it.

Control/Settings channel

The special Control/Settings DMX channel lets you adjust certain fixture settings by
DMX. This can be very helpful if you want to adjust fixture performance during a show
or just for special scenes.

CTC

The separate Color Temperature Control channel provides a convenient way of
shifting the fixture’s color temperature in steps from 10 000 K to 2 500 K. This lets you set
a fixed white point.

• If you set the CTC channel to zero, RGBW control goes into RAW mode with
maximum output available.

• If you select a color temperature on the CTC channel, the RGBW system uses that
color temperature as the white point when RGBW is set to 100%.

Virtual color wheel

The virtual color wheel channel gives quick access to saturated and pastel colors.
Continuous color preset scrolling and random color presets are also available.

Colors set using the color wheel have higher priority than any colors set on the RGBW
color mixing channels. To use RGBW color mixing, you must set the virtual color wheel
channel to 000.

If you select Rainbow Colors the fixture will crossfade between the typical colors of a
rainbow: purple, deep blue, light blue, green, yellow, orange, red. You can adjust the
speed of color changes from slow to fast.

If you select Random Colors the fixture will crossfade between the multiple colors
(Colors 01 to 12 and Rainbow Colors) randomly. You can adjust the speed of color
changes from slow to fast.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 9

Zoom

The main Zoom channel varies the beam angle of the fixture from narrow 3.7° to wide
35°. This main zoom channel controls all 10 zoom lenses together.

Zoom is narrow at low DMX Values and wide at high DMX values by default, but this
can be inverted using FIXTURE SETTINGS → ZOOM INVERT.

Individual cell control

Color and zoom of each of the FR 10 Bar’s cells can be controlled individually. Each
cell has a new micro-Fresnel front lens that also gives great visual effects when the
fixture is viewed from wider angles.

Individual pixel control

Each cell houses a 60 W RGBW OSRAM Ostar LED. Intensity and color of each LED can
be controlled individually, giving a huge range of possibilities for creating dynamic
effects and pixel mapping.

Individual zoom control

Each cell offers individual zoom angle control, making it possible to create zoom
chasers and waves and allowing a huge range of combinations of individual pixel
color and zoom.

FX engine

An advanced multi-layer FX Engine is included, with FX separated into Zoom and Color
effects. The combination of different pixel and zoom FX patterns in multiple FX layers
lets you create stunning effects without the need for an external media server.

The different FX are arranged in layers that have different levels of priority.

Multi-layer concept

The DMX Channel Index is designed to let you work with one ‘main fixture’ and,
depending on the DMX mode selected, with additional ‘sub-fixtures’.

• The ‘main fixture’, controlled by the first section of the DMX channels, gives you
direct access to all the main functions of the fixture – the ‘main fixture’ forms the
main layer.

• The two ‘sub-fixtures’, controlled by later sections of the DMX Channel Index, are
layers that can be used in combination with the ‘main fixture’.

By default, the fixture manages color mixing on the different layers using HTP (highest
value takes priority). This means that the color mixing values of Layer 1, Layer 2 and
Layer 3 are merged together and the highest value ‘wins’.

www.glp.de

10 impression FR10 Bar User Manual Rev. 20210901-2

This behavior can be changed by using the Color Mix Priority setting available on the
Control/Settings DMX channel or using the fixture’s control panel. Three options are
available:

• HTP (the default setting).

• True Color L3-L2-L1 – Layer 3 has priority over Layer 2 and Layer 2 has priority over

Layer 1.

• True Color L1-L2-L3 –Layer 1 has priority over Layer 2 and Layer 2 has priority over
Layer 3.

See ‘Color mixing priority’ on page 19 for more details.

Each layer also has its own Dimmer and Shutter channel which lets you set that layer to
Open and Blackout as well as selecting different pulse and strobe effects to run on
that layer.

Pattern control

The FR10 Bar offers a range of different FX patterns that consist of pixel color/intensity
and pixel zoom angle effects. Each pattern comprises a sequence of steps which can
be selected step by step (static) or run continuously (dynamic) forwards or backwards.

Pattern control is similar to rotating gobo control using two DMX channels on an effect
spotlight:

• Use the Pattern Select channel to select the FX pattern that you want to use, just as
you would select a gobo.

• Then use the Pattern Position/Movement channel to either:

- select a static pattern step (DMX 000 to 127 / Step 1 to 20), just as you would select

a gobo indexing angle, or

- select the speed and direction of a continuously running dynamic pattern (DMX

128 to 255), just as you would select gobo movement speed and direction.

The Pattern Position DMX range 000 to 127 is split into 20 pattern steps which you can
select one by one. If a pattern only has 10 steps, you can only select steps 0 to 10 – all
other steps are empty.

A pattern has active and inactive cells. An active cell displays the color and zoom of
the pattern. An inactive cell is transparent and will display the color and zoom angle of
the background.

You can select from 50 patterns on the Pattern Select channel. At the end of the
channel there is also a Random Pattern function and a Random Pixel FX function.
Random Pattern auto-selects patterns randomly and runs 10 pattern step cycles of
each pattern. After 10 pattern step cycles, the fixture changes to the next pattern.
Random Pixel FX randomly selects pixels which crossfade to each other.

Pattern length and offset

FX Length and FX Offset let you set up FX pattern chases and similar synchronized
action in multiple fixtures (as opposed to running the same pattern at the same time
on multiple fixtures). The length and offset options work like this:

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 11

• FX Length sets the number of steps the fixture will play back for the current pattern.

- If you set both FX Length and FX Offset to DMX 000, the FX pattern will play back at

the same time on all fixtures. Action is identical.

- If you set FX Length to DMX 000, the fixture will play back all the steps in the FX

pattern in a loop.

- If you set FX Length to DMX 003, the fixture will only play back steps 1 to 3 in a loop.

- If you set FX Length to DMX 100, the fixture will play back all the steps in the FX

pattern and then add empty steps (black) at the end of the pattern until it reaches
step 100. It will continue this action in a loop.

• FX Offset sets the starting point of the FX pattern.

- If you set FX Offset to DMX 000 or DMX 001, the FX pattern will start at the first pixel

with the first step in the pattern.

- If you set FX Offset to DMX 011, the fixture will run 10 empty pattern steps (black)

and then play back the pattern starting at step 1 on pixel 1 of the fixture.

Example A

Settings:

- Fixture A: FX Length = 000, FX Offset = 000, Pattern 01 running CW

- Fixture B: FX Length = 000, FX Offset = 000, Pattern 01 running CW

Result:

- Pattern 1 (single pixel chaser with 10 pattern steps) will run at the same time on

both fixtures from pixel 01 to pixel 10. Action will be identical.

Example B

Settings:

- Fixture A: FX Length = 020, FX offset = 000, Pattern 01 running CW

- Fixture B: FX Length = 020, FX offset = 011, Pattern 01 running CW

Result:

- Fixture A will run Pattern 1 (single pixel chaser with 10 pattern steps) on Pixel 01 to 10

followed by 10 invisible pattern steps.

- Fixture B will run 10 invisible pattern steps and then run Pattern 1 (single pixel chaser

with 10 pattern steps).

- The result is a clean pixel chaser running across two fixtures.

Note that FX Length and Offset only work when you set an FX to Dynamic (forwards or
backwards movement with adjustable speed). If you set an FX pattern to Static, the
fixture will simply display the pattern step that you select. Length and Offset will not
affect action.

www.glp.de

12 impression FR10 Bar User Manual Rev. 20210901-2

Crossfading

Crossfading determines how each step in an FX pattern fades into the next step.
Crossfading can be a snap, a normal crossfade or a fade with tail (quick fade in and
long fade out with variable length).

Transition

Transition determines how each pattern fades into the next pattern. Transition can be
a snap, a soft crossfade, a fade passing through blackout/narrow or a fade passing
through full intensity/wide.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 13

4. Control panel and display

The FR10 has a backlit graphic display and four-button control panel.

Warning! DMX control is disabled when the control menus are active. Be
prepared for the fixture to emit strong light as soon as you exit the control
menus.

Control panel

The four buttons under the display have the following functions:

• BACK – Activates the Quick Menu or goes back one level towards the top of the
menu.

• UP – Scrolls up or increments a number.

• DOWN – Scrolls down or decrements a number.

• ENTER – MENU/ENTER activates the control panel if it is in sleep mode. Then enters a

menu, selects a setting or implements a command depending on where you are in
the menus.

Pressing the UP or DOWN button and holding it pressed in scrolls through menu items or
values continuously until you reach the end of the range.

BACK

UP

DOWN

ENTER

Figure 2. Control panel and display

www.glp.de

14 impression FR10 Bar User Manual Rev. 20210901-2

Main screen

Press any button to activate the main screen.

The main screen contains the following information:

• Top left: Firmware version – Tilt, Zoom and Pixel Mirror settings N (Normal) or I
(Inverted) – DMX Mode – Dimming curve

• Top right: PWM Frequency

• Center: Signal source (DMX, Art-Net…), DMX address and last DMX channel

occupied

• Bottom left: the >> symbol indicates that the left-hand button opens the Quick
menu

• Bottom right: MENU indicates that the right-hand button opens the main menu

The example screen shown in Figure 2 gives the following information:

• The fixture is running firmware v. 20

• Tilt = N (Normal), Zoom = I (Inverted), Pixel Mirror = I (Inverted)

• The fixture is in DMX Mode 1

• The dimming curve is set to Soft

• The PWM frequency is set to 3000

• The fixture is set to receive data via DMX

• The fixture’s DMX address is set to 488 and the fixture uses DMX channels from 488

up to and including channel 512.

Information displayed when using Art-Net / sACN

See Figure 3. If the fixture is set up for control over an Art-Net or sACN network, the
signal source and currently set universe (Uni: starting from 0) appear above the DMX
address. The fixture’s IP address is displayed below the DMX address. See ‘Ethernet
config’ on page 17 for details of how to configure the fixture’s network address.

Figure 3. Display, Art-Net / sACN networks

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 15

The fixture uses a network icon to indicate a connection to a valid, active network.
If displayed to the left of the DMX address, the icon indicates that a network is
connected to the left-hand etherCON port. If displayed to the right of the DMX
address, the icon indicates a network connection at the right-hand etherCON port
(left and right are as seen when facing the control panel).

Network speed is displayed below the network icon.

If the fixture does not detect a network at one of the ports, it displays NO LINK instead
of the network icon for that port.

Error code display

If the fixture detects an error, it displays an error code in place of the DMX address in
the center of the display.

Button Shortcuts

Battery Eco Mode

Holding BACK and MENU/ENTER together for 10 seconds activates Battery Eco Mode,
which switches off the display completely to avoid unwanted discharge of the control
menu battery. This is mode is useful if a fixture is going be stored long-term.

The Battery Eco Mode command is only available when the fixture is disconnected
from AC mains power.

Quick Fixture Overview

Pressing UP or DOWN three times displays an overview of all the main fixture
information and settings. This can be useful while troubleshooting or communicating
with GLP Service.

Flip Display Orientation

Pressing and releasing UP and DOWN together flips the display orientation.

Main Menu

Pressing MENU/ENTER opens the Main Menu.

Quick Menu

Pressing the >> / BACK button on the left opens the Quick Menu containing the most
frequently used menu items.

Contents of the Quick Menu

Display Orientation

Lets you set the control panel display to Normal or Upside-down for most convenient
viewing.

www.glp.de

16 impression FR10 Bar User Manual Rev. 20210901-2

Reset All

Performs a full fixture reset to initialize all features and effects.

Load Settings

Lets you load one of the customized Setting Presets from PRESET 1 to PRESET 3.

Loading the DEFAULT PRESET sets all fixture settings back to their default values. This
does not affect data network configuration settings such as DMX start address, IP
address etc.

Load Factory Backup

Important! The LOAD FACTORY BACKUP command will restore all factory default
settings including data network configuration settings such as DMX start address, IP
address settings, etc. This may mean that you lose communication with your controller.

The LOAD FACTORY BACKUP command does not change device counters and
calibration settings.

Main menus

The FR10 Bar has the following main control menus.

DMX Address

Sets the DMX start address of the fixture. The DMX address is 001 by default.

Control Mode

Selects one of the fixture’s DMX control modes. See ‘DMX control modes overview’ on
page 30.

Protocol Setup

Protocol Type

The fixture is compatible with DMX 512 and RDM control protocols. You can control the
fixture using DMX over a standard DMX cable link or over an Art-Net or sACN network:

• DMX (default setting) – The fixture uses the DMX control data received at its 5-pin
XLR connectors. No IP settings are required.

• Art-Net – The fixture uses the DMX control data received via Art-Net at its Ethernet
port. It is necessary to set up an Ethernet network. To configure the fixture to receive
control data via Art-Net, you need to set an IP Address, IP Subnet and Art-Net
port/universe (see Ethernet Config below).

Note that it is possible to transmit DMX data as broadcast or unicast packages via
Art-Net. If a large number of universes (more than 30) is broadcast, data loss can
occur. If you suspect that this is happening, configure your console to unicast Art­Net DMX packages to fixtures or switch to sACN.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 17

• sACN – The fixture uses the DMX control data received via sACN at its Ethernet port.
It is necessary to set up an Ethernet network. To configure the fixture to receive
control data via sACN, you may need to set an IP Address, IP Subnet and sACN
universe (see Ethernet Config below).

Ethernet config

Lets you set up an IP Network if controlling the fixture by Art-Net or sACN.

Addressing mode

Lets you choose how the fixture acquires its IP Address:

• Auto 2.x.x.x. – the fixture will generate its own IP address within the range 2.x.x.x
(Art-Net specification)

• Auto 10.x.x.x. – the fixture will generate its own IP address within the range 10.x.x.x
(Art-Net specification)

• DHCP – the fixture will acquire its IP address automatically by DHCP

• Custom IP – you can assign IP addresses manually by entering individual IP

addresses and Subnet mask (see Custom IP Address and Custom IP Subnet below)

- Custom IP Address – lets you set a custom IP Address.

- Custom IP Subnet – lets you set a custom IP Subnet mask.

ArtNet Port

Selects an Art-Net port/universe from 00000 (Network 0 / Subnet 0 / Universe 0) to 32767
(Network 7 / Subnet 15 / Universe 255).

Note that the first Art-Net universe is considered to be universe number 00000, not

00001.

sACN Universe

Selects a sACN universe from 00001 to 63999.

Fixture Settings

Tilt Invert

Inverts direction of Tilt:

• OFF (the default setting) – Normal Tilt control: positive Tilt values turn the head
towards the front of the fixture

• ON – Inverted Tilt control: positive Tilt values turn the head towards the back of the
fixture

Position feedback

Enables/disables head position feedback (auto Tilt correction):

• Position Feedback is enabled by default.

• If you disable Position Feedback, the fixture will not automatically correct any errors

in Tilt position. In this case, if the head loses its correct Tilt position you must carry out
a reset to restore correct operation.

www.glp.de

18 impression FR10 Bar User Manual Rev. 20210901-2

Tilt disable

Disables/enables Tilt movement. Disabling Tilt movement can be useful if the fixture is
installed in a location where there is not enough space for tilt movement, for example.
Three settings are available:

• OFF (the default setting) – Gives normal Tilt control.

• Reset disabled – Prevents the Tilt function from resetting if you send a Reset

command, but Tilt can still be controlled via DMX. The Tilt motor is energized so that
the head stays in position.

• Current disabled – Disconnects the Tilt function completely from power and from
DMX control. The Tilt motor will not hold the head in position.

Note: If you change from one setting to the other, the fixture will carry out a Tilt reset to
initialize Tilt position.

Zoom Invert

Lets you invert the Zoom effect:

• At the default setting (Zoom Invert = OFF), increasing values on the Zoom channel
moves the zoom from narrow to wide.

• If invert is enabled (Zoom Invert = ON), increasing values on the Zoom channel
moves the zoom from wide to narrow.

No Signal

Determines what the fixture does if no DMX signal is present (if the fixture is being
controlled by DMX but the DMX signal stops, or if you apply power to the fixture when
no DMX signal is present):

• Blackout – Sets the fixture to black out whenever it is not receiving a DMX signal.

• Hold (the default setting) – Sets the fixture to continue obeying the last DMX values

it received.

• Stand-Alone – Sets the fixture to play its stored stand-alone scene (see CAPTURE
DMX SCENE) when the fixture is not receiving a DMX signal. If no stand-alone scene
is stored in memory, the fixture will black out.

Note: This setting is useful if you want fixtures to automatically start stand-alone
operation when you apply power to them.

• Capture DMX Scene – Takes a snapshot of the DMX values that the fixture is
currently receiving and stores them in the fixture’s memory as its stand-alone scene.

Once captured, the fixture will display this stand-alone scene if it is set to STAND­ALONE and is not receiving a DMX signal.

Dimmer Curve

Selects one of the two dimming curves available:

• Linear – Light intensity appears to increase and decrease evenly throughout the
dimming range.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 19

• Soft (Square) – The Soft dimming curve is the default setting. Using the Soft curve
gives finer control at low light levels (where the eye is more sensitive to changes in
light level) and coarser control at high levels.

Color mixing priority

Gives you three options for managing color mixing on the Main Layer (L1), Layer 2 (L2)
and Layer 3 (L3):

• Mix (HTP) – this is the default setting. The fixture mixes the different layers using HTP
(highest value takes priority): the color mixing values of Layer 1, Layer 2 and Layer 3
are merged together and the highest value ‘wins’

• True Color L3-L2-L1 – Layer 3 has priority over Layer 2 and Layer 2 has priority over
Layer 1.

Example: Colors are mixed in true color. As soon the DMX value of Layer 2 is higher
than 000 the color of Layer 2 will be visible exactly as mixed and Layer 1 will black
out to avoid influencing the color mix of Layer 2.

• True Color L1-L2-L3 – Layer 1 has priority over Layer 2 and Layer 2 has priority over
Layer 3.

Example: Colors are mixed in true color. As soon the DMX value of Layer 1 is higher
than 000, the color of Layer 1 is visible exactly as mixed and Layer 2 blacks out to
avoid influencing the color mix of Layer 1.

Pixel Mirror

Inverts the order of pixels:

• OFF – In the normal, default setting, the first pixel is at the Power IN connector end
of the fixture and the last pixel is at the Power THRU connector end.

• ON – If you enable Pixel Mirror, the first pixel is at the Power THRU connector end of
the fixture and the last pixel is at the Power IN connector end.

Performance

Using this setting allows the operator to select between three different settings for the
movement speed of all the fixture’s mechanical effects:

• Normal (default setting) – All mechanical effect movement is set to achieve an
optimum balance between speed, quietness and smoothness.

• Fast – Sets movement to maximum speed. This setting gives super-fast effects but
can result in higher noise levels.

• Smooth – Sets movement to optimize smoothness and give lowest-noise
performance. This setting gives extremely low noise and smooth performance, but
effect movement will be slower than in Normal mode.

PWM Frequency

Lets you select between different PWM frequencies for the fixture’s LEDs to best match
camera shutter frequencies and avoid flicker and beat interference in video images.

www.glp.de

20 impression FR10 Bar User Manual Rev. 20210901-2

You can change the fixture’s PWM frequency using either the Control / Settings DMX
channel or the control panel.

The default PWM setting is 3000 Hz. You can set the PWM frequency to 2200 Hz,
3000 Hz, 4800 Hz, 9600 Hz or 25 kHz.

Note that a higher PWM frequency may affect dimming performance. The PWM
frequency setting is stored in the fixture and is not affected by cycling power off and
on. However, it will be affected if you apply a Factory default command in the control
menus. As a rule, you should set all the fixtures in an installation to the same PWM
frequency in order to ensure the same performance.

Display Mode

Lets you select an option for the fixture’s control panel display:

• Auto (default setting) – The display automatically blacks out after a few seconds if
the fixture is receiving a valid control signal and has not detected an error.

- If the fixture is not receiving a valid control signal, the display flashes.

- If the fixture has detected an error, the display remains constantly on and shows

the error.

• ON – The display stays on constantly. This setting can be useful when you are
configuring or servicing the fixture.

• OFF – The display automatically blacks out after a few seconds, even if the fixture is
not receiving a valid control signal and even if it has detected an error. Pressing
any of the buttons on the control panel will reactivate the display.

Display Orientation

Sets the orientation for the control panel display:

• Normal (default setting) – Display easy to read with the fixture’s head above the
base

• Upside-down – Display easy to read if the fixture is suspended with the head below
the base.

Fan Mode

Selects between different cooling fan and temperature management options. These
can be useful if the fixture is operating in a very hot or very noise-sensitive environment:

• Regulated (default setting) – Balances light output and fan noise, and only
operates fans when necessary. If the fixture is blacked out, fans run at minimum
speed. When light output intensity is increased, temperature regulation increases
fan speed to the level necessary to keep the fixture at optimum temperature.

If light output is set to maximum intensity but the fans can keep the fixture at
optimum temperature, there will be no regulation of light intensity. If the fixture
begins to exceed optimum temperature and fans are running at max. speed, light
intensity will be limited until optimum temperature can be maintained.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 21

• High – Sets fans to constant operation at high speed. The fixture will run at
maximum possible light output. This setting is suitable for operation in high ambient
temperatures.

The fixture limits light output intensity smoothly if it becomes necessary in order to
keep fixture temperature at optimum level.

Besides maximizing light output in high ambient temperatures, you can use this
mode to cool down a fixture quickly or to remove dust from cooling fans.

• Medium – Sets fans to constant operation at medium speed. Light output intensity is
reduced to a level where it will normally remain constant at ambient temperatures
of up to 45° C (113° F). Intensity is smoothly limited further if it becomes necessary in
order to keep fixture temperature at optimum level.

• Low – Sets fans to constant operation at low speed. This setting is optimized for
minimum noise. Light output intensity is reduced to a level where it will normally
remain constant at ambient temperatures of up to 30° C (86° F). Intensity is
smoothly limited further if it becomes necessary in order to keep fixture temperature
at optimum level.

Note: In all fan modes, if fixture temperature reaches a dangerous level, LEDs will be
shut down for a period until the fans have brought the temperature down to a safe
level.

Load Settings

Using this setting allows the operator to load different customized fixture configurations
and to set the fixture back to the Default Fixture Settings. (To save customized Setting
Presets 1 to 3 see SERVICE → ADVANCED → SAVE SETTINGS)

Note: The Load Fixture Presets and Load Fixture Defaults will only affect settings in the
Fixture Settings and will not affect DMX Address, Control Mode, Protocol Type, IP
Settings, etc. That will help to not losing communication with the controller.

• Preset 1 ... 3 – Loads one of three specific customized fixture settings. You have to
confirm the function for 3s before the new settings are loaded. For information on
saving fixture settings to a custom preset, see SERVICE → ADVANCED → SAVE
SETTINGS.

• Default – Loads all the default fixture settings and brings the fixture into standard
show condition. You must confirm the function for 3 seconds before the new
settings will load.

Information

This menu gives fixture information readouts such as a list of any errors that the fixture
has detected, the fixture’s serial number, the currently installed software version,
device info (RDM protocol version, model ID, personality, sub-device, sensor count)
total hours of operation from new, number of power cycles from new, DMX signal
monitoring and signal quality, etc.

www.glp.de

22 impression FR10 Bar User Manual Rev. 20210901-2

Manual Control

This menu gives options to control the fixture manually with no need for a DMX
controller. This can be useful during service or when setting up a stand-alone scene.

• Reset All – Performs a full fixture reset to initialize all features and effects.

• Reset Tilt – Performs a reset of the Tilt only in order to re-initialize Tilt position.

• Reset Head – Performs a reset on all the effects in the head.

• Manual DMX – Allows control of the fixture using the fixture’s own control panel.

An external DMX signal will always have higher priority than manual control values.
Disconnect the fixture from the control data source when using manual DMX.

Important! Be prepared for the fixture to start moving without warning when you
enter manual control.

- Manual DMX – Sends internal values to control each of the fixture’s functions

- Load No-Signal Scene – Loads the DMX values of the stored captured scene from

the No-Signal feature

- Save as No-signal scene – Saves the current manual control values as the

captured scene from the No-Signal feature.

- Capture DMX values – Captures the current external DMX signal values and uses

them as manual control values.

- Reset Manual values – Resets all manual control values to default.

Service

The Service menu contains test sequences that are useful during service and
maintenance. It also contains an ADVANCED submenu which is for use by trained
technicians only. Read the information below carefully before entering this level.

Test Sequences

Runs different test sequences to check fixture functionality. Press the BACK button to
stop a test sequence.

• Test All – Runs a test sequence of all features one by one.

• Test Tilt – Runs a test sequence of Tilt movement only.

• Test LED – Runs a test sequence of LED pixels only.

• Test Zoom – Runs a test sequence of Zoom only.

Advanced Service

Entering this Submenu will allow you to do advanced fixture settings. You need to
confirm to enter the advanced Service level by holding enter for 3s.

Note: The Advanced Service Level is for trained technicians only. Read the information
below before entering this level.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 23

Service Mode

Disables Tilt movement for convenience when servicing the head. Tilt is enabled again
at the next power cycle.

Note: You can also disable Tilt by pressing and holding the MENU / ENTER button for 3
seconds while powering on the fixture.

Offset

Lets you set customized offset values for each of the fixture’s effects. This is a useful way
of temporarily adjusting multiple fixtures without changing fixture calibration.

Note: Offset Values are not calibration values. They are not deleted by a Load Setting
Defaults command but they are deleted by a Load Factory Backup command. If you
want to permanently adjust effects, use Feature Calibration in the Factory menu.

Reset Counters

Lets you reset the different fixture counters.

Note: Device Counters are not reset by a Load Factory Backup command.

Save Settings

Lets you save the current fixture settings to one of three custom fixture presets. After
saving a custom Fixture Setting Preset, you can reload it at any time using the Load
Fixture Setting Preset command (see FIXTURE SETTINGS → LOAD SETTINGS on page 21).

Note that the Default Preset is set at the factory and cannot be changed.

Load Factory Backup

Important! Using this setting will return all the fixture’s settings to factory defaults. This
includes all data network configuration such as DMX start address, IP configuration etc.
Note that you may lose communication with your controller!

LOAD FACTORY BACKUP does not affect device counters and calibration values.

Factory Menu

Important! Do not enter the Factory menu unless you are a trained service
professional. Read the fixture’s service and calibration documentation, if
available, before entering this menu. In the Factory mode you can
change critical settings and cause damage to the fixture that is not
covered by the product warranty.

The Factory menu structure is normally hidden and is for use by the manufacturer or
professional service technicians only.

To enable the Factory menu the fixture must be powered on while holding the MENU /
ENTER button pressed for minimum 5 seconds. A warning message will appear in the
display. The Factory Menu will then be visible as the last item in the Main Menu.

The Factory menu stays enabled until the next power cycle. The control panel display is
set to constantly on and a Factory symbol is visible in the main screen while the Factory
menu is enabled.

www.glp.de

24 impression FR10 Bar User Manual Rev. 20210901-2

RDM Address

Lets you edit the RDM Address of the fixture. This should always be the serial number of
the fixture.

Important! Make sure that the RDM address is correct, especially after changing the
mainboard. This is especially important for rental fixtures. If you have any questions,
please contact your GLP Support.

Feature Calibration

Lets you calibrate the fixture’s effect and LEDs.

Important! Make sure that calibration is carried out correctly so that all fixtures in the
market perform identically. This is important for rental fixtures. If you have any questions,
please contact your GLP Support.

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 25

5. Control menu layout

Menus

Notes

DMX Start Address

001-512

Set fixture’s DMX address

Protocol Setup

Protocol Type

DMX

Control via DMX protocol

Art-Net

Control via Art-Net
protocol

sACN

Control via sACN protocol

Ethernet
Config

Addressing Mode

Auto 2.X.X.X

Auto addressing in the
range 2.X.X.X

Auto 10.X.X.X

Auto addressing in the
range 10.X.X.X

DHCP

Get IP address by DHCP

Custom IP

Use custom IP address

Custom IP Address

xxx.xxx.xxx.xxx

Set custom IP address

Custom IP Subnet

xxx.xxx.xxx.xxx

Set custom subnet

Art-Net Port

0 - 32767

Set Art-Net port

sACN Universe

1 - 63999

Set sACN universe

Fixture Settings

Tilt Invert
OFF

Reverse direction of tilt
movement

ON

Position
Feedback

ON

Enable/disable pan/tilt
position correction

OFF

Tilt Disable

OFF

Tilt normal

Reset disable

No tilt reset but DMX Tilt
control enabled

Current disable

Tilt fully disabled

Zoom Invert
OFF

Zoom narrow to wide

ON

Zoom wide to narrow

No Signal

Blackout

Fixture blacks out if no
DMX signal received

Hold

Fixture continues to display
current effect if no DMX
signal received

Replay DMX scene

Plays the scene stored
with Capture DMX Values
(see below) if no DMX
signal received

Capture DMX Values

Captures current scene
and stores it for use in
Replay DMX Scene (see
above)

Dimmer
Curve

Soft (Square)

Soft (square law) dimming
curve

Linear

Linear dimming curve

www.glp.de

26 impression FR10 Bar User Manual Rev. 20210901-2

Color Mix
Priority

Mix (HTP)

Layers 1 (main), 2 and 3
color mixing: Highest DMX
value takes priority

True Color L3-L2-L1

Layers 1 (main), 2 and 3
color mixing: Layer 3 takes
priority, then Layer 2, then
Layer 1

True Color L1-L2-L3

Layers 1 (main), 2 and 3
color mixing: Layer 1 takes
priority, then Layer 2, then
Layer 3

Pixel Mirror
OFF

Pixel numbering normal 1­10

ON

Pixel numbering reversed
10 - 1

Performance

Normal

Normal pan, tilt and
effects movement

Fast

Optimize pan, tilt and
effects movement for
speed

Smooth

Optimize pan, tilt and
effects movement for
smoothness

PWM
Frequency

2200Hz

Select LED PWM
frequency

3000 Hz

4800Hz

9600Hz

25 kHz

Display Mode

Auto

Display dims to zero after
a short period of inactivity
if no errors and if there is a
valid DMX signal

On

Display constantly on

Off

Display dims even if there
are errors / no DMX signal

Display
Orientation

Normal

Display normal (for use
when fixture is standing)

Upside-down

Display inverted (for use
when fixture is flown head­down)

Fan Mode

Regulated

Fan speed temperature­regulated (optimized for
light output and noise)

High

Fan speed constant high
(maximum cooling)

Medium

Fan speed constant
medium

Low

Fan speed constant low
(lowest possible noise)

Load Settings

Preset 1 (Confirm 3 seconds)

Load one of custom
settings presets stored in
Advanced → Save
settings menu

Preset 2 (Confirm 3 seconds)

Preset 3 (Confirm 3 seconds)

Default (Confirm 3 seconds)

Restore all custom
personality settings and
offsets to factory defaults

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 27

Information

Show errorlist

Show fixture status
information in display

Show Serial Number

Show SW version

Show device info

Show device hours

Show power cycles

Show DMX input

Show signal quality

Show temperature

Show fan monitor

Manual Control

Reset All
No

Reset complete fixture

Yes

Reset Tilt
No

Reset tilt only

Yes

Reset Head
No

Reset all LED and Zoom
functions

Yes

Manual DMX

Intensity … Zoom FX Offset

000 … 255

Manually set a DMX value
on each channel

Load No-Signal Scene

Confirm

Loads currently stored No­Signal Scene

Save as No-Signal Scene

Confirm

Saves current manual
values as No-Signal Scene

Capture DMX values

Confirm

Take external DMX values
and use them as manual
values

Reset Manual values

Confirm

Reset all manual values to
default

www.glp.de

28 impression FR10 Bar User Manual Rev. 20210901-2

Service

Test
Sequences

Test All

Run test sequence on all
effects

Test Tilt

Run test sequence on Tilt
functionality

Test LED

Run test sequence on LEDs

Test Zoom

Run test sequence on
Zoom functionality

Advanced
(Press and
hold Enter for
3 seconds)

Service Mode

OFF

Put fixture into service
mode (disable tilt until
next power cycle)

ON

Offset

Tilt Offset +/-128

-99 … 0 … 99

Set custom effect offsets
(unaffected by power
cycles but deleted if
factory defaults are
loaded)

Zoom offset +/-128

-99 … 0 … 99

…

-99 … 0 … 99
Reset offsets

Confirm

Delete all custom offsets

Reset counters
Device hours

Confirm

Reset resettable counters
/ temperature log

Device power cycles

Confirm

Max. temperatures

Confirm

Save settings
Preset 1

Confirm

Save current personality
settings including offsets
as a custom preset

Preset 2

Confirm

Preset 3

Confirm

Load factory backup

Confirm
(hold for 5
seconds)

Restore personality
settings, fixture
configuration incl. DMX
address, control protocol,
offset values, etc. (will not
affect calibration settings
and device counters)

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 29

Shortcut menu

To open the Shortcut menu, press the BACK button under the >> symbol at the bottom
left of the main screen in the control panel.

Display
orientation

Normal

Display orientation

Upside down

Reset all

Confirm

Reset entire fixture

Load settings

Preset 1

Confirm (hold for 3 seconds)

Load one of custom
settings presets stored in
Advanced → Save
settings menu

Preset 2

Confirm (hold for 3 seconds)

Preset 3

Confirm (hold for 3 seconds)

Default

Confirm (hold for 3 seconds)

Restore personality
settings to factory
defaults. Will not affect
fixture configuration (DMX
address, control protocol,
offset values etc.).

Load Factory
Backup (!)

Confirm (hold for 5 seconds)

Restore personality
settings, fixture
configuration incl. DMX
address, control protocol,
offset values, etc. Will not
affect calibration settings
and device counters.

Default settings are written in BOLD type.

www.glp.de

30 impression FR10 Bar User Manual Rev. 20210901-2

6. DMX control modes overview

The following four DMX control modes are available in the FR10 Bar.

DMX Mode 1: Normal is the default
DMX mode. It provides 16-bit control of
tilt and dimming, shutter effects, a
Control/Settings channel that lets you
configure the fixture remotely via DMX,
color temperature control, a virtual
color wheel (color presets) and RGBW
color mixing.

It also features a powerful effects
engine with static and dynamic pixel
and zoom effect patterns.

Mode 1

Normal (default mode)

1

Tilt

2

3

Intensity global

4 5 Shutter global

6

Control/Settings

7

CTC

8

Virtual color wheel

9

Red

10

Green

11

Blue

12

White

13

Pixel FX Pattern select

14

Pixel FX Position/Speed

15

Pixel FX Crossfading

16

Pixel FX Transition

17

Pixel FX Length

18

Pixel FX Offset

19

Zoom global

20

Zoom FX Pattern select

21

Zoom FX Position/Speed

22

Zoom FX Crossfading

23

Zoom FX Transition

24

Zoom FX Length

25

Zoom FX Offset

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 31

DMX Mode 2: Multi-Layer provides 16-bit
control of tilt and dimming, shutter
effects, a Control/Settings channel that
lets you configure the fixture remotely via
DMX, color temperature control, a virtual
color wheel (color presets) and RGBW
color mixing.

It also features a powerful effects engine
with static and dynamic pixel and zoom
effect patterns.

Besides the main layer (Layer 1)
described above, DMX Mode 2 features
two additional layers that can be used in
combination with Layer 1.

The fixture decides which of the three
layers takes priority based on the Color
Mix Priority setting on the Control/Settings

DMX channel or in the fixture’s control

panel. The default setting is HTP (highest
DMX value takes priority), but you can set
Layer 1 (the main layer) or Layer 3 to take
priority.

Each of the two additional layers offers a
16-bit layer master (the visibility of the
layer over the lower layers from 0% –
100%), shutter effects, RGBW control and
the same range of pixel FX as in DMX
Mode 1.

Mode 2

Multi-Layer

1

Tilt

Layer 1

– Main Layer

2

3

Intensity global

4

5

Shutter global

6

Control/Settings

7

CTC

8

Virtual color wheel

9

Red

10

Green

11

Blue

12

White

13

Pixel FX Pattern select

14

Pixel FX Position/Speed

15

Pixel FX Crossfading

16

Pixel FX Transition

17

Pixel FX Length

18

Pixel FX Offset

19

Zoom global

20

Zoom FX Pattern select

21

Zoom FX Position/Speed

22

Zoom FX Crossfading

23

Zoom FX Transition

24

Zoom FX Length

25

Zoom FX Offset

26

Layer 2 Master

Layer 2

27

28

Shutter

29

Red intensity

30

Green intensity

31

Blue intensity

32

White intensity

33

Pixel FX Pattern select

34

Pixel FX Position/Speed

35

Pixel FX Crossfading

36

Pixel FX Transition

37

Pixel FX Length

38

Pixel FX Offset

39

Layer 3 Master

Layer 3

40

41

Shutter

42

Red intensity

43

Green intensity

44

Blue intensity

45

White intensity

46

Pixel FX Pattern select

47

Pixel FX Position/Speed

48

Pixel FX Crossfading

49

Pixel FX Transition

50

Pixel FX Length

51

Pixel FX Offset

www.glp.de

32 impression FR10 Bar User Manual Rev. 20210901-2

DMX Mode 3: MultiPix (Multi-pixel)

provides 16-bit control of tilt and
dimming, shutter effects, a
Control/Settings channel that lets you
configure the fixture remotely via DMX
and color temperature control.

This mode also gives individual RGBW
color mixing and individual Zoom control
of each of the fixture’s ten pixels.

Mode 3

MultiPix

1

Tilt

2

3

Intensity global

4

5

Shutter global

6

Control/Settings

7

CTC

8

Pixel 01 Red

9

Pixel 01 Green

10

Pixel 01 Blue

11

Pixel 01 White

12

Pixel 01 Zoom

13

Pixel 02 Red

14

Pixel 02 Green

15

Pixel 02 Blue

16

Pixel 02 White

17

Pixel 02 Zoom

18

Pixel 03 Red

19

Pixel 03 Green

20

Pixel 03 Blue

21

Pixel 03 White

22

Pixel 03 Zoom

23

Pixel 04 Red

24

Pixel 04 Green

25

Pixel 04 Blue

26

Pixel 04 White

27

Pixel 04 Zoom

28

Pixel 05 Red

29

Pixel 05 Green

30

Pixel 05 Blue

31

Pixel 05 White

32

Pixel 05 Zoom

33

Pixel 06 Red

34

Pixel 06 Green

35

Pixel 06 Blue

36

Pixel 06 White

37

Pixel 06 Zoom

38

Pixel 07 Red

39

Pixel 07 Green

40

Pixel 07 Blue

41

Pixel 07 White

42

Pixel 07 Zoom

43

Pixel 08 Red

44

Pixel 08 Green

45

Pixel 08 Blue

46

Pixel 08 White

47

Pixel 08 Zoom

48

Pixel 09 Red

49

Pixel 09 Green

50

Pixel 09 Blue

51

Pixel 09 White

52

Pixel 09 Zoom

53

Pixel 10 Red

54

Pixel 10 Green

55

Pixel 10 Blue

56

Pixel 10 White

57

Pixel 10 Zoom

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 33

DMX Mode 4: MultiPix (Multi-pixel)
Advanced provides 16-bit control of tilt

and dimming, shutter effects, a
Control/Settings channel that lets you
configure the fixture remotely via DMX,
color temperature control, a virtual color
wheel (color presets) and RGBW color
mixing.

It also features a powerful effects engine
with static and dynamic pixel and zoom
effect patterns.

Besides the main layer (Layer 1)
described above, DMX Mode 4 features
two additional layers that can be used in
combination with Layer 1:

• Layer 2 offers shutter effects and
individual pixel RGBW color mixing
with 16-bit Master control (visibility of
Layer 2 from 0% – 100%).

• Layer 3 offers individual pixel zoom
control with Master control (visibility of
Layer 3 from 0% – 100%).

The fixture decides which of the three
layers takes priority based on the Color
Mix Priority setting on the Control/Settings

DMX channel or in the fixture’s control

panel. The default setting is HTP (highest
DMX value takes priority), but you can set
Layer 1 (the main layer) or Layer 3 to take
priority.

Mode 4

MultiPix Advanced

1

Tilt

Layer 1

– Main layer

2

3

Intensity global

4 5 Shutter global

6

Control/Settings

7

CTC

8

Virtual color wheel

9

Red

10

Green

11

Blue

12

White

13

Pixel FX Pattern select

14

Pixel FX Position/Speed

15

Pixel FX Crossfading

16

Pixel FX Transition

17

Pixel FX Length

18

Pixel FX Offset

19

Zoom global

20

Zoom FX Pattern select

21

Zoom FX Position/Speed

22

Zoom FX Crossfading

23

Zoom FX Transition

24

Zoom FX Length

25

Zoom FX Offset

26

Layer 2 (individual pixel intensity)
Master

Layer 2

– Pixel intensity

27

28

Shutter

29

Pixel 01 Red

30

Pixel 01 Green

31

Pixel 01 Blue

32

Pixel 01 White

33

Pixel 02 Red

34

Pixel 02 Green

35

Pixel 02 Blue

36

Pixel 02 White

37

Pixel 03 Red

38

Pixel 03 Green

39

Pixel 03 Blue

40

Pixel 03 White

41

Pixel 04 Red

42

Pixel 04 Green

43

Pixel 04 Blue

44

Pixel 04 White

45

Pixel 05 Red

46

Pixel 05 Green

47

Pixel 05 Blue

48

Pixel 05 White

49

Pixel 06 Red

50

Pixel 06 Green

51

Pixel 06 Blue

52

Pixel 06 White

www.glp.de

34 impression FR10 Bar User Manual Rev. 20210901-2

53

Pixel 07 Red

Layer 2

– Pixel intensity (continued)

54

Pixel 07 Green

55

Pixel 07 Blue

56

Pixel 07 White

57

Pixel 08 Red

58

Pixel 08 Green

59

Pixel 08 Blue

60

Pixel 08 White

61

Pixel 09 Red

62

Pixel 09 Green

63

Pixel 09 Blue

64

Pixel 09 White

65

Pixel 10 Red

66

Pixel 10 Green

67

Pixel 10 Blue

68

Pixel 10 White

69

Layer 3 (individual pixel zoom)
Master

Layer 3

– Pixel zoom

70

Pixel 01 Zoom

71

Pixel 02 Zoom

72

Pixel 03 Zoom

73

Pixel 04 Zoom

74

Pixel 05 Zoom

75

Pixel 06 Zoom

76

Pixel 07 Zoom

77

Pixel 09 Zoom

78

Pixel 09 Zoom

79

Pixel 10 Zoom

German Light Products®

impression FR10 Bar User Manual Rev. 20210901-2 35

7. DMX control channel layout

In the following DMX channel layout tables:

● Default settings are indicated with bold type.

● Where commands are marked (3s hold) or (5s hold), you must send the DMX value

continuously for 3 or 5 seconds to apply the command.

• Percentage equivalents are rounded up or down to the nearest 0.1%

www.glp.de DMX MODE 1 impression FR10 Bar

36 impression FR10 Bar User Manual Rev. 20210901-2

DMX Mode 1: Normal (default DMX mode)

25 DMX Channels

Channel

Command

DMX

range

Percent

Default

DMX

Fade

1

Tilt coarse

Tilt backwards > forwards (16-bit)

0

65535

0

100

32768

Fade

2

Tilt fine

3

Intensity
coarse

Global intensity 0-100% (16-bit)

0

65535

0

100

32768

Fade

4

Intensity fine

5

Shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

6

Control /
Settings

No function

0

38 0 14.9

0

Snap

Dimmer curve: Soft (square) (3s
hold)

39

41

15.3

16.1

Dimmer curve: Linear (3s hold)

42

44

16.5

17.3

No function

45

53

17.6

20.8

Display mode: Off (3s hold)

54

56

21.2

22

Display mode: Auto (3s hold)

57

59

22.4

23.1

Display mode: On (3s hold)

60

62

23.5

24.3

Display orientation: Normal (3s hold)

63

65

24.7

25.5

Display orientation: Inverted (3s
hold)

66

68

25.9

26.7

No function

69

71

27.1

27.8

No DMX: Blackout (3s hold)

72

74

28.2

29.0

No DMX: Hold (3s hold)

75

77

29.4

30.2

No DMX: Captured scene (3s hold)

78

80

30.6

31.4

Capture Scene (3s hold)

81

83

31.8

32.5

No function

84

86

32.9

33.7

Fan mode: Regulated (3s hold)

87

89

34.1

34.9

Fan mode: High (3s hold)

90

92

35.3

36.1

Fan mode: Medium (3s hold)

93

95

36.5

37.3

Fan mode: Low (3s hold)

96

98

37.6

38.4

No function

99

104

38.8

40.8

Position feedback: Off (3s hold)

105

107

41.2

42.0

Position feedback: On (3s hold)

108

110

42.4

43.1

Tilt disable: Off (3s hold)

111

113

43.5

44.3

Tilt disable: Reset Disabled

114

116

44.7

45.5

Tilt disable: Current Disabled

117

119

45.9

46.7

Tilt inversion: Off (3s hold)

120

122

47.1

47.8

Tilt inversion: On (3s hold)

123

125

48.2

49.0

No function

126

128

49.4

50.2

Zoom inversion: Off (3s hold)

129

131

50.6

51.4

Zoom inversion: On (3s hold)

132

134

51.8

52.5

No function

135

140

52.9

54.9

Pixel mirror: Off (3s hold)

141

143

55.3

56.1

Pixel mirror: On (3s hold)

144

146

56.5

57.3

German Light Products® DMX MODE 1 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 37

No function

147

155

57.6

60.8

Performance: Fast (3s hold)

156

158

61,2

62,0

Performance: Normal (3s hold)

159

161

62,4

63,1

Performance: Smooth (3s hold)

162

164

63.5

64.3

No function

165

170

64.7

66.7

Color mix priority: Mix (HTP)

171

173

67.1

67.8

Color mix priority: L3-L2-L1

174

176

68.2

69.0

Color mix priority: L1-L2-L3

177

179

69.4

70.2

No function

180

191

70.6

74.9

PWM: 2200 Hz (5s hold)

192

194

75.3

76.1

PWM: 3000 Hz (5s hold)

195

197

76.5

77.3

PWM: 4800 Hz (5s hold)

198

200

77.6

78.4

PWM: 9600 Hz (5s hold)

201

203

78.8

79.6

No function

204

206

80.0

80.8

PWM: 25 kHz (5s hold)

207

209

81.2

82.0

No function

210

245

82.4

96.1

Reset Tilt (3s hold)

246

248

96.5

97.3

Reset Head (3s hold)

249

251

97.6

98.4

Reset All (3s hold)

252

255

98.8

100

7

Color
Temperature
Control

RAW 0 15 0 5.9

Snap

10000 K

16

18

6.3

7.1

9900 K

19

21

7.5

8.2

9800 K

22

24

8.6

9.4

9700 K

25

27

9.8

10.6

9600 K

28

30

11.0

11.8

9500 K

31

33

12.2

12.9

9400 K

34

36

13.3

14.1

9300 K

37

39

14.5

15.3

9200 K

40

42

15.7

16.5

9100 K

43

45

16.9

17.6

9000 K

46

48

18.0

18.8

8900 K

49

51

19.2

20.0

8800 K

52

54

20.4

21.2

8700 K

55

57

21.6

22.4

8600 K

58

60

22.7

23.5

8500 K

61

63

23.9

24.7

8400 K

64

66

25.1

25.9

8300 K

67

69

26.3

27.1

8200 K

70

72

27.5

28.2

8100 K

73

75

28.6

29.4

8000 K

76

78

29.8

30.6

7900 K

79

81

31.0

31.8

7800 K

82

84

32.2

32.9

7700 K

85

87

33.3

34.1

7600 K

88

90

34.5

35.3

7500 K

91

93

35.7

36.5

7400 K

94

96

36.9

37.6

7300 K

97

99

38.0

38.8

7200 K

100

102

39.2

40.0

7100 K

103

105

40.4

41.2

7000 K

106

108

41.6

42.4

6900 K

109

111

42.7

43.5

6800 K

112

114

43.9

44.7

6700 K

115

117

45.1

45.9

6600 K

118

120

46.3

47.1

6500 K

121

123

47.5

48.2

6400 K

124

126

48.6

49.4

6300 K

127

129

49.8

50.6

www.glp.de DMX MODE 1 impression FR10 Bar

38 impression FR10 Bar User Manual Rev. 20210901-2

6200 K

130

132

51.0

51.8

6100 K

133

135

52.2

52.9

6000 K

136

138

53.3

54.1

5900 K

139

141

54.5

55.3

5800 K

142

144

55.7

56.5

5700 K

145

147

56.9

57.6

5600 K

148

150

58.0

58.8

5500 K

151

153

59.2

60.0

5400 K

154

156

60.4

61.2

5300 K

157

159

61.6

62.4

5200 K

160

162

62.7

63.5

5100 K

163

165

63.9

64.7

5000 K

166

168

65.1

65.9

4900 K

169

171

66.3

67.1

4800 K

172

174

67.5

68.2

4700 K

175

177

68.6

69.4

4600 K

178

180

69.8

70.6

4500 K

181

183

71.0

71.8

4400 K

184

186

72.2

72.9

4300 K

187

189

73.3

74.1

4200 K

190

192

74.5

75.3

4100 K

193

195

75.7

76.5

4000 K

196

198

76.9

77.6

3900 K

199

201

78.0

78.8

3800 K

202

204

79.2

80.0

3700 K

205

207

80.4

81.2

3600 K

208

210

81.6

82.4

3500 K

211

213

82.7

83.5

3400 K

214

216

83.9

84.7

3300 K

217

219

85.1

85.9

3200 K

220

222

86.3

87.1

3100 K

223

225

87.5

88.2

3000 K

226

228

88.6

89.4

2900 K

229

231

89.8

90.6

2800 K

232

234

91.0

91.8

2700 K

235

237

92.2

92.9

2600 K

238

240

93.3

94.1

2500 K

241

255

94.5

100

8

Virtual color
wheel

Off (RGBW)

0 7 0

2.7

0

Snap

Color 01 - Red

8

15

3.1

5.9

Snap

Color 02 - Amber

16

23

6.3

9.0

Snap

Color 03 - Warm Yellow

24

31

9.4

12.2

Snap

Color 04 - Yellow

32

39

12.5

15.3

Snap

Color 05 - Green

40

47

15.7

18.4

Snap

Color 06 - Turquoise

48

55

18.8

21.6

Snap

Color 07 - Cyan

56

63

22.0

24.7

Snap

Color 08 - Blue

64

71

25.1

27.8

Snap

Color 09 - Lavender

72

79

28.2

31.0

Snap

Color 10 - Male

80

87

31.4

34.1

Snap

Color 11 - Magenta

88

95

34.5

37.3

Snap

Color 12 - Pink

96

103

37.6

40.4

Snap

Color 13 - White 3200K

104

111

40.8

43.5

Snap

Color 14 - White 5600K

112

119

43.9

46.7

Snap

Color 15 - White 7200K

120

127

47.1

49.8

Snap

Stop

128

128

50.2

50.2

Snap

Rainbow colors crossfade slow > fast

129

223

50.6

87.5

Fade

Random colors crossfade slow > fast

224

255

87.8

100

Fade

German Light Products® DMX MODE 1 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 39

9

Red

Red intensity 0-100%

0

255 0 100

255

Fade

10

Green

Green intensity 0-100%

0

255 0 100

255

Fade

11

Blue

Blue intensity 0-100%

0

255 0 100

255

Fade

12

White

White intensity 0-100%

0

255 0 100

0

Fade

13

Pixel FX
pattern select

No effect

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random pixel FX pattern

246

250

96.5

98.0

Random pixel FX

251

255

98.4

100

www.glp.de DMX MODE 1 impression FR10 Bar

40 impression FR10 Bar User Manual Rev. 20210901-2

14

Pixel FX
pattern static
position /
dynamic
movement

Pattern static Step 01

0 5 0.0

2.0 0 Snap

Pattern static Step 02

6

11

2.4

4.3

Snap

Pattern static Step 03

12

17

4.7

6.7

Snap

Pattern static Step 04

18

23

7.1

9.0

Snap

Pattern static Step 05

24

29

9.4

11.4

Snap

Pattern static Step 06

30

35

11.8

13.7

Snap

Pattern static Step 07

36

41

14.1

16.1

Snap

Pattern static Step 08

42

47

16.5

18.4

Snap

Pattern static Step 09

48

53

18.8

20.8

Snap

Pattern static Step 10

54

59

21.2

23.1

Snap

Pattern static Step 11

60

65

23.5

25.5

Snap

Pattern static Step 12

66

71

25.9

27.8

Snap

Pattern static Step 13

72

77

28.2

30.2

Snap

Pattern static Step 14

78

83

30.6

32.5

Snap

Pattern static Step 15

84

89

32.9

34.9

Snap

Pattern static Step 16

90

95

35.3

37.3

Snap

Pattern static Step 17

96

101

37.6

39.6

Snap

Pattern static Step 18

102

107

40.0

42.0

Snap

Pattern static Step 19

108

113

42.4

44.3

Snap

Pattern static Step 20

114

119

44.7

46.7

Snap

Stop / no function

120

127

47.1

49.8

Snap

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Fade

Stop

191

192

74.9

75.3

Snap

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

Fade

15

Pixel pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

16

Pixel FX
transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FOB (fade over blackout) transition,
0s to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOF (fade over full intensity) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

17

Pixel FX
pattern length

Off (pattern length normal)

0 0 0

0 0 Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

18

Pixel FX
pattern offset

Off (pattern starts at first pixel)

0 0 0

0

0

Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

19

Zoom

Narrow > wide

0

255 0 100

0

Snap

German Light Products® DMX MODE 1 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 41

20

Zoom FX
pattern select

No effect, all lenses have normal
zoom functionality

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random zoom FX pattern

246

250

96.5

98.0

Random pixel zoom

251

255

98.4

100

www.glp.de DMX MODE 1 impression FR10 Bar

42 impression FR10 Bar User Manual Rev. 20210901-2

21

Zoom FX static
pattern
position /
dynamic
pattern
movement

Pattern static Step 01

0 5 0.0

2.0

0

Snap

Pattern static Step 02

6

11

2.4

4.3

Pattern static Step 03

12

17

4.7

6.7

Pattern static Step 04

18

23

7.1

9.0

Pattern static Step 05

24

29

9.4

11.4

Pattern static Step 06

30

35

11.8

13.7

Pattern static Step 07

36

41

14.1

16.1

Pattern static Step 08

42

47

16.5

18.4

Pattern static Step 09

48

53

18.8

20.8

Pattern static Step 10

54

59

21.2

23.1

Pattern static Step 11

60

65

23.5

25.5

Pattern static Step 12

66

71

25.9

27.8

Pattern static Step 13

72

77

28.2

30.2

Pattern static Step 14

78

83

30.6

32.5

Pattern static Step 15

84

89

32.9

34.9

Pattern static Step 16

90

95

35.3

37.3

Pattern static Step 17

96

101

37.6

39.6

Pattern static Step 18

102

107

40.0

42.0

Pattern static Step 19

108

113

42.4

44.3

Pattern static Step 20

114

119

44.7

46.7

Stop / no function

120

127

47.1

49.8

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Stop

191

192

74.9

75.3

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

22

Zoom pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

23

Zoom pattern
FX transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FON (fade over narrow) transition, 0s
to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOW (fade over wide) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

24

Zoom pattern
FX length

Off (pattern length normal)

0 0 0

0 0 Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

25

Zoom pattern
FX offset

Off (pattern starts at first pixel)

0 0 0

0

0

Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 43

DMX Mode 2: Multi-Layer

51 DMX Channels

Channel

Command

DMX

range

Percent

Default

DMX

Fade

Layer 1 (Main layer)

1

Tilt coarse

Tilt backwards > forwards (16-bit)

0

65535

0

100

32768

Fade

2

Tilt fine

3

Intensity
coarse

Global intensity 0-100% (16-bit)

0

65535

0

100

32768

Fade

4

Intensity fine

5

Shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

6

Control /
Settings

No function

0

38 0 14.9

0

Snap

Dimmer curve: Soft (square) (3s
hold)

39

41

15.3

16.1

Dimmer curve: Linear (3s hold)

42

44

16.5

17.3

No function

45

53

17.6

20.8

Display mode: Off (3s hold)

54

56

21.2

22

Display mode: Auto (3s hold)

57

59

22.4

23.1

Display mode: On (3s hold)

60

62

23.5

24.3

Display orientation: Normal (3s hold)

63

65

24.7

25.5

Display orientation: Inverted (3s
hold)

66

68

25.9

26.7

No function

69

71

27.1

27.8

No DMX: Blackout (3s hold)

72

74

28.2

29.0

No DMX: Hold (3s hold)

75

77

29.4

30.2

No DMX: Captured scene (3s hold)

78

80

30.6

31.4

Capture Scene (3s hold)

81

83

31.8

32.5

No function

84

86

32.9

33.7

Fan mode: Regulated (3s hold)

87

89

34.1

34.9

Fan mode: High (3s hold)

90

92

35.3

36.1

Fan mode: Medium (3s hold)

93

95

36.5

37.3

Fan mode: Low (3s hold)

96

98

37.6

38.4

No function

99

104

38.8

40.8

Position feedback: Off (3s hold)

105

107

41.2

42.0

Position feedback: On (3s hold)

108

110

42.4

43.1

Tilt disable: Off (3s hold)

111

113

43.5

44.3

Tilt disable: Reset Disabled

114

116

44.7

45.5

Tilt disable: Current Disabled

117

119

45.9

46.7

Tilt inversion: Off (3s hold)

120

122

47.1

47.8

Tilt inversion: On (3s hold)

123

125

48.2

49.0

No function

126

128

49.4

50.2

Zoom inversion: Off (3s hold)

129

131

50.6

51.4

Zoom inversion: On (3s hold)

132

134

51.8

52.5

No function

135

140

52.9

54.9

Pixel mirror: Off (3s hold)

141

143

55.3

56.1

www.glp.de DMX MODE 2 impression FR10 Bar

44 impression FR10 Bar User Manual Rev. 20210901-2

Pixel mirror: On (3s hold)

144

146

56.5

57.3

No function

147

155

57.6

60.8

Performance: Fast (3s hold)

156

158

61,2

62,0

Performance: Normal (3s hold)

159

161

62,4

63,1

Performance: Smooth (3s hold)

162

164

63.5

64.3

No function

165

170

64.7

66.7

Color mix priority: Mix (HTP)

171

173

67.1

67.8

Color mix priority: L3-L2-L1

174

176

68.2

69.0

Color mix priority: L1-L2-L3

177

179

69.4

70.2

No function

180

191

70.6

74.9

PWM: 2200 Hz (5s hold)

192

194

75.3

76.1

PWM: 3000 Hz (5s hold)

195

197

76.5

77.3

PWM: 4800 Hz (5s hold)

198

200

77.6

78.4

PWM: 9600 Hz (5s hold)

201

203

78.8

79.6

No function

204

206

80.0

80.8

PWM: 25 kHz (5s hold)

207

209

81.2

82.0

No function

210

245

82.4

96.1

Reset Tilt (3s hold)

246

248

96.5

97.3

Reset Head (3s hold)

249

251

97.6

98.4

Reset All (3s hold)

252

255

98.8

100

7

Color
Temperature
Control

RAW 0 15 0 5.9

Snap

10000 K

16

18

6.3

7.1

9900 K

19

21

7.5

8.2

9800 K

22

24

8.6

9.4

9700 K

25

27

9.8

10.6

9600 K

28

30

11.0

11.8

9500 K

31

33

12.2

12.9

9400 K

34

36

13.3

14.1

9300 K

37

39

14.5

15.3

9200 K

40

42

15.7

16.5

9100 K

43

45

16.9

17.6

9000 K

46

48

18.0

18.8

8900 K

49

51

19.2

20.0

8800 K

52

54

20.4

21.2

8700 K

55

57

21.6

22.4

8600 K

58

60

22.7

23.5

8500 K

61

63

23.9

24.7

8400 K

64

66

25.1

25.9

8300 K

67

69

26.3

27.1

8200 K

70

72

27.5

28.2

8100 K

73

75

28.6

29.4

8000 K

76

78

29.8

30.6

7900 K

79

81

31.0

31.8

7800 K

82

84

32.2

32.9

7700 K

85

87

33.3

34.1

7600 K

88

90

34.5

35.3

7500 K

91

93

35.7

36.5

7400 K

94

96

36.9

37.6

7300 K

97

99

38.0

38.8

7200 K

100

102

39.2

40.0

7100 K

103

105

40.4

41.2

7000 K

106

108

41.6

42.4

6900 K

109

111

42.7

43.5

6800 K

112

114

43.9

44.7

6700 K

115

117

45.1

45.9

6600 K

118

120

46.3

47.1

6500 K

121

123

47.5

48.2

6400 K

124

126

48.6

49.4

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 45

6300 K

127

129

49.8

50.6

6200 K

130

132

51.0

51.8

6100 K

133

135

52.2

52.9

6000 K

136

138

53.3

54.1

5900 K

139

141

54.5

55.3

5800 K

142

144

55.7

56.5

5700 K

145

147

56.9

57.6

5600 K

148

150

58.0

58.8

5500 K

151

153

59.2

60.0

5400 K

154

156

60.4

61.2

5300 K

157

159

61.6

62.4

5200 K

160

162

62.7

63.5

5100 K

163

165

63.9

64.7

5000 K

166

168

65.1

65.9

4900 K

169

171

66.3

67.1

4800 K

172

174

67.5

68.2

4700 K

175

177

68.6

69.4

4600 K

178

180

69.8

70.6

4500 K

181

183

71.0

71.8

4400 K

184

186

72.2

72.9

4300 K

187

189

73.3

74.1

4200 K

190

192

74.5

75.3

4100 K

193

195

75.7

76.5

4000 K

196

198

76.9

77.6

3900 K

199

201

78.0

78.8

3800 K

202

204

79.2

80.0

3700 K

205

207

80.4

81.2

3600 K

208

210

81.6

82.4

3500 K

211

213

82.7

83.5

3400 K

214

216

83.9

84.7

3300 K

217

219

85.1

85.9

3200 K

220

222

86.3

87.1

3100 K

223

225

87.5

88.2

3000 K

226

228

88.6

89.4

2900 K

229

231

89.8

90.6

2800 K

232

234

91.0

91.8

2700 K

235

237

92.2

92.9

2600 K

238

240

93.3

94.1

2500 K

241

255

94.5

100

8

Virtual color
wheel

Off (RGBW)

0 7 0

2.7

0

Snap

Color 01 - Red

8

15

3.1

5.9

Snap

Color 02 - Amber

16

23

6.3

9.0

Snap

Color 03 - Warm Yellow

24

31

9.4

12.2

Snap

Color 04 - Yellow

32

39

12.5

15.3

Snap

Color 05 - Green

40

47

15.7

18.4

Snap

Color 06 - Turquoise

48

55

18.8

21.6

Snap

Color 07 - Cyan

56

63

22.0

24.7

Snap

Color 08 - Blue

64

71

25.1

27.8

Snap

Color 09 - Lavender

72

79

28.2

31.0

Snap

Color 10 - Male

80

87

31.4

34.1

Snap

Color 11 - Magenta

88

95

34.5

37.3

Snap

Color 12 - Pink

96

103

37.6

40.4

Snap

Color 13 - White 3200K

104

111

40.8

43.5

Snap

Color 14 - White 5600K

112

119

43.9

46.7

Snap

Color 15 - White 7200K

120

127

47.1

49.8

Snap

Stop

128

128

50.2

50.2

Snap

Rainbow colors crossfade slow > fast

129

223

50.6

87.5

Fade

Random colors crossfade slow > fast

224

255

87.8

100

Fade

www.glp.de DMX MODE 2 impression FR10 Bar

46 impression FR10 Bar User Manual Rev. 20210901-2

9

Red

Red intensity 0-100%

0

255 0 100

255

Fade

10

Green

Green intensity 0-100%

0

255 0 100

255

Fade

11

Blue

Blue intensity 0-100%

0

255 0 100

255

Fade

12

White

White intensity 0-100%

0

255 0 100

0

Fade

13

Pixel FX
pattern select

No effect

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random pixel FX pattern

246

250

96.5

98.0

Random pixel FX

251

255

98.4

100

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 47

14

Pixel FX
pattern static
position /
dynamic
movement

Pattern static Step 01

0 5 0.0

2.0 0 Snap

Pattern static Step 02

6

11

2.4

4.3

Snap

Pattern static Step 03

12

17

4.7

6.7

Snap

Pattern static Step 04

18

23

7.1

9.0

Snap

Pattern static Step 05

24

29

9.4

11.4

Snap

Pattern static Step 06

30

35

11.8

13.7

Snap

Pattern static Step 07

36

41

14.1

16.1

Snap

Pattern static Step 08

42

47

16.5

18.4

Snap

Pattern static Step 09

48

53

18.8

20.8

Snap

Pattern static Step 10

54

59

21.2

23.1

Snap

Pattern static Step 11

60

65

23.5

25.5

Snap

Pattern static Step 12

66

71

25.9

27.8

Snap

Pattern static Step 13

72

77

28.2

30.2

Snap

Pattern static Step 14

78

83

30.6

32.5

Snap

Pattern static Step 15

84

89

32.9

34.9

Snap

Pattern static Step 16

90

95

35.3

37.3

Snap

Pattern static Step 17

96

101

37.6

39.6

Snap

Pattern static Step 18

102

107

40.0

42.0

Snap

Pattern static Step 19

108

113

42.4

44.3

Snap

Pattern static Step 20

114

119

44.7

46.7

Snap

Stop / no function

120

127

47.1

49.8

Snap

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Fade

Stop

191

192

74.9

75.3

Snap

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

Fade

15

Pixel pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9 0 Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

16

Pixel FX
transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FOB (fade over blackout) transition,
0s to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOF (fade over full intensity) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

17

Pixel FX
pattern length

Off (pattern length normal)

0 0 0

0

0

Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

18

Pixel FX
pattern offset

Off (pattern starts at first pixel)

0 0 0

0

0

Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

19

Zoom

Narrow > wide

0

255 0 100

0

Snap

www.glp.de DMX MODE 2 impression FR10 Bar

48 impression FR10 Bar User Manual Rev. 20210901-2

20

Zoom FX
pattern select

No effect, all lenses have normal
zoom functionality

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random zoom FX pattern

246

250

96.5

98.0

Random pixel zoom

251

255

98.4

100

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 49

21

Zoom FX static
pattern
position /
dynamic
pattern
movement

Pattern static Step 01

0 5 0.0

2.0

0

Snap

Pattern static Step 02

6

11

2.4

4.3

Pattern static Step 03

12

17

4.7

6.7

Pattern static Step 04

18

23

7.1

9.0

Pattern static Step 05

24

29

9.4

11.4

Pattern static Step 06

30

35

11.8

13.7

Pattern static Step 07

36

41

14.1

16.1

Pattern static Step 08

42

47

16.5

18.4

Pattern static Step 09

48

53

18.8

20.8

Pattern static Step 10

54

59

21.2

23.1

Pattern static Step 11

60

65

23.5

25.5

Pattern static Step 12

66

71

25.9

27.8

Pattern static Step 13

72

77

28.2

30.2

Pattern static Step 14

78

83

30.6

32.5

Pattern static Step 15

84

89

32.9

34.9

Pattern static Step 16

90

95

35.3

37.3

Pattern static Step 17

96

101

37.6

39.6

Pattern static Step 18

102

107

40.0

42.0

Pattern static Step 19

108

113

42.4

44.3

Pattern static Step 20

114

119

44.7

46.7

Stop / no function

120

127

47.1

49.8

Pattern dynamic, forwards fast >
slow (run from Step 1 to end in loop)

128

190

50.2

74.5

Stop

191

192

74.9

75.3

Pattern dynamic, backwards slow >
fast (run from end to Step 1 in loop)

193

255

75.7

100.0

22

Zoom pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

23

Zoom pattern
FX transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FON (fade over narrow) transition, 0s
to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOW (fade over wide) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

24

Zoom pattern
FX length

Off (pattern length normal)

0 0 0

0

0

Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

25

Zoom pattern
FX offset

Off (pattern starts at first pixel)

0 0 0

0 0 Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

Layer 2

26

Layer 2 master
coarse

Layer 2 master 0-100% (16-bit)

0

65535

0

100

32768

Fade

27

Layer 2 master
fine

28

Layer 2 shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

www.glp.de DMX MODE 2 impression FR10 Bar

50 impression FR10 Bar User Manual Rev. 20210901-2

29

Layer 2 Red

Red intensity 0-100%

0

255 0 100

255

Fade

30

Layer 2 Green

Green intensity 0-100%

0

255 0 100

255

Fade

31

Layer 2 Blue

Blue intensity 0-100%

0

255 0 100

255

Fade

32

Layer 2 White

White intensity 0-100%

0

255 0 100

0

Fade

33

Layer 2 pixel
FX pattern
select

No effect

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random pixel FX pattern

246

250

96.5

98.0

Random pixel FX

251

255

98.4

100

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 51

34

Layer 2 pixel
FX pattern
static position
/ dynamic
movement

Pattern static Step 01

0 5 0.0

2.0 0 Snap

Pattern static Step 02

6

11

2.4

4.3

Snap

Pattern static Step 03

12

17

4.7

6.7

Snap

Pattern static Step 04

18

23

7.1

9.0

Snap

Pattern static Step 05

24

29

9.4

11.4

Snap

Pattern static Step 06

30

35

11.8

13.7

Snap

Pattern static Step 07

36

41

14.1

16.1

Snap

Pattern static Step 08

42

47

16.5

18.4

Snap

Pattern static Step 09

48

53

18.8

20.8

Snap

Pattern static Step 10

54

59

21.2

23.1

Snap

Pattern static Step 11

60

65

23.5

25.5

Snap

Pattern static Step 12

66

71

25.9

27.8

Snap

Pattern static Step 13

72

77

28.2

30.2

Snap

Pattern static Step 14

78

83

30.6

32.5

Snap

Pattern static Step 15

84

89

32.9

34.9

Snap

Pattern static Step 16

90

95

35.3

37.3

Snap

Pattern static Step 17

96

101

37.6

39.6

Snap

Pattern static Step 18

102

107

40.0

42.0

Snap

Pattern static Step 19

108

113

42.4

44.3

Snap

Pattern static Step 20

114

119

44.7

46.7

Snap

Stop / no function

120

127

47.1

49.8

Snap

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Fade

Stop

191

192

74.9

75.3

Snap

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

Fade

35

Layer 2 pixel
pattern FX
crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9 0 Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

36

Layer 2 pixel
FX transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FOB (fade over blackout) transition,
0s to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOF (fade over full intensity) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

37

Layer 2 pixel
FX pattern
length

Off (pattern length normal)

0 0 0

0

0

Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

38

Layer 2 pixel
FX pattern
offset

Off (pattern starts at first pixel)

0 0 0

0

0

Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

www.glp.de DMX MODE 2 impression FR10 Bar

52 impression FR10 Bar User Manual Rev. 20210901-2

Layer 3

39

Layer 3 master
coarse

Layer 3 master 0-100% (16-bit)

0

65535

0

100

32768

Fade

40

Layer 3 master
fine

41

Layer 3 shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

42

Layer 3 Red

Red intensity 0-100%

0

255 0 100

255

Fade

43

Layer 3 Green

Green intensity 0-100%

0

255 0 100

255

Fade

44

Layer 3 Blue

Blue intensity 0-100%

0

255 0 100

255

Fade

45

Layer 3 White

White intensity 0-100%

0

255 0 100

0

Fade

46

Layer 3 pixel
FX pattern
select

No effect

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

German Light Products® DMX MODE 2 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 53

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random pixel FX pattern

246

250

96.5

98.0

Random pixel FX

251

255

98.4

100

47

Layer 3 pixel
FX pattern
static position
/ dynamic
movement

Pattern static Step 01

0 5 0.0

2.0 0 Snap

Pattern static Step 02

6

11

2.4

4.3

Snap

Pattern static Step 03

12

17

4.7

6.7

Snap

Pattern static Step 04

18

23

7.1

9.0

Snap

Pattern static Step 05

24

29

9.4

11.4

Snap

Pattern static Step 06

30

35

11.8

13.7

Snap

Pattern static Step 07

36

41

14.1

16.1

Snap

Pattern static Step 08

42

47

16.5

18.4

Snap

Pattern static Step 09

48

53

18.8

20.8

Snap

Pattern static Step 10

54

59

21.2

23.1

Snap

Pattern static Step 11

60

65

23.5

25.5

Snap

Pattern static Step 12

66

71

25.9

27.8

Snap

Pattern static Step 13

72

77

28.2

30.2

Snap

Pattern static Step 14

78

83

30.6

32.5

Snap

Pattern static Step 15

84

89

32.9

34.9

Snap

Pattern static Step 16

90

95

35.3

37.3

Snap

Pattern static Step 17

96

101

37.6

39.6

Snap

Pattern static Step 18

102

107

40.0

42.0

Snap

Pattern static Step 19

108

113

42.4

44.3

Snap

Pattern static Step 20

114

119

44.7

46.7

Snap

Stop / no function

120

127

47.1

49.8

Snap

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Fade

Stop

191

192

74.9

75.3

Snap

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

Fade

48

Layer 3 pixel
pattern FX
crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

49

Layer 3 pixel
FX transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9 0 Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FOB (fade over blackout) transition,
0s to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOF (fade over full intensity) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

www.glp.de DMX MODE 2 impression FR10 Bar

54 impression FR10 Bar User Manual Rev. 20210901-2

50

Layer 3 pixel
FX pattern
length

Off (pattern length normal)

0 0 0

0 0 Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

51

Layer 3 pixel
FX pattern
offset

Off (pattern starts at first pixel)

0 0 0

0 0 Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

German Light Products® DMX MODE 3 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 55

DMX Mode 3: MultiPix Normal

57 DMX Channels

Channel

Command

DMX

range

Percent

Default

DMX

Fade

1

Tilt coarse

Tilt backwards > forwards (16-bit)

0

65535

0

100

32768

Fade

2

Tilt fine

3

Intensity
coarse

Global intensity 0-100% (16-bit)

0

65535

0

100

32768

Fade

4

Intensity fine

5

Shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

6

Control /
Settings

No function

0

38 0 14.9

0

Snap

Dimmer curve: Soft (square) (3s
hold)

39

41

15.3

16.1

Dimmer curve: Linear (3s hold)

42

44

16.5

17.3

No function

45

53

17.6

20.8

Display mode: Off (3s hold)

54

56

21.2

22

Display mode: Auto (3s hold)

57

59

22.4

23.1

Display mode : On (3s hold)

60

62

23.5

24.3

Display orientation: Normal (3s hold)

63

65

24.7

25.5

Display orientation: Inverted (3s
hold)

66

68

25.9

26.7

No function

69

71

27.1

27.8

No DMX: Blackout (3s hold)

72

74

28.2

29.0

No DMX: Hold (3s hold)

75

77

29.4

30.2

No DMX: Captured scene (3s hold)

78

80

30.6

31.4

Capture Scene (3s hold)

81

83

31.8

32.5

No function

84

86

32.9

33.7

Fan mode: Regulated (3s hold)

87

89

34.1

34.9

Fan mode: High (3s hold)

90

92

35.3

36.1

Fan mode: Medium (3s hold)

93

95

36.5

37.3

Fan mode: Low (3s hold)

96

98

37.6

38.4

No function

99

104

38.8

40.8

Position feedback: Off (3s hold)

105

107

41.2

42.0

Position feedback: On (3s hold)

108

110

42.4

43.1

Tilt disable: Off (3s hold)

111

113

43.5

44.3

Tilt disable: Reset Disabled

114

116

44.7

45.5

Tilt disable: Current Disabled

117

119

45.9

46.7

Tilt inversion: Off (3s hold)

120

122

47.1

47.8

Tilt inversion: On (3s hold)

123

125

48.2

49.0

No function

126

128

49.4

50.2

Zoom inversion: Off (3s hold)

129

131

50.6

51.4

Zoom inversion: On (3s hold)

132

134

51.8

52.5

No function

135

140

52.9

54.9

Pixel mirror: Off (3s hold)

141

143

55.3

56.1

Pixel mirror: On (3s hold)

144

146

56.5

57.3

www.glp.de DMX MODE 3 impression FR10 Bar

56 impression FR10 Bar User Manual Rev. 20210901-2

No function

147

155

57.6

60.8

Performance: Fast (3s hold)

156

158

61,2

62,0

Performance: Normal (3s hold)

159

161

62,4

63,1

Performance: Smooth (3s hold)

162

164

63.5

64.3

No function

165

170

64.7

66.7

Color mix priority: Mix (HTP)

171

173

67.1

67.8

Color mix priority: L3-L2-L1

174

176

68.2

69.0

Color mix priority: L1-L2-L3

177

179

69.4

70.2

No function

180

191

70.6

74.9

PWM: 2200 Hz (5s hold)

192

194

75.3

76.1

PWM: 3000 Hz (5s hold)

195

197

76.5

77.3

PWM: 4800 Hz (5s hold)

198

200

77.6

78.4

PWM: 9600 Hz (5s hold)

201

203

78.8

79.6

No function

204

206

80.0

80.8

PWM: 25 kHz (5s hold)

207

209

81.2

82.0

No function

210

245

82.4

96.1

Reset Tilt (3s hold)

246

248

96.5

97.3

Reset Head (3s hold)

249

251

97.6

98.4

Reset All (3s hold)

252

255

98.8

100

7

Color
Temperature
Control

RAW 0 15 0 5.9

Snap

10000 K

16

18

6.3

7.1

9900 K

19

21

7.5

8.2

9800 K

22

24

8.6

9.4

9700 K

25

27

9.8

10.6

9600 K

28

30

11.0

11.8

9500 K

31

33

12.2

12.9

9400 K

34

36

13.3

14.1

9300 K

37

39

14.5

15.3

9200 K

40

42

15.7

16.5

9100 K

43

45

16.9

17.6

9000 K

46

48

18.0

18.8

8900 K

49

51

19.2

20.0

8800 K

52

54

20.4

21.2

8700 K

55

57

21.6

22.4

8600 K

58

60

22.7

23.5

8500 K

61

63

23.9

24.7

8400 K

64

66

25.1

25.9

8300 K

67

69

26.3

27.1

8200 K

70

72

27.5

28.2

8100 K

73

75

28.6

29.4

8000 K

76

78

29.8

30.6

7900 K

79

81

31.0

31.8

7800 K

82

84

32.2

32.9

7700 K

85

87

33.3

34.1

7600 K

88

90

34.5

35.3

7500 K

91

93

35.7

36.5

7400 K

94

96

36.9

37.6

7300 K

97

99

38.0

38.8

7200 K

100

102

39.2

40.0

7100 K

103

105

40.4

41.2

7000 K

106

108

41.6

42.4

6900 K

109

111

42.7

43.5

6800 K

112

114

43.9

44.7

6700 K

115

117

45.1

45.9

6600 K

118

120

46.3

47.1

6500 K

121

123

47.5

48.2

6400 K

124

126

48.6

49.4

German Light Products® DMX MODE 3 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 57

6300 K

127

129

49.8

50.6

6200 K

130

132

51.0

51.8

6100 K

133

135

52.2

52.9

6000 K

136

138

53.3

54.1

5900 K

139

141

54.5

55.3

5800 K

142

144

55.7

56.5

5700 K

145

147

56.9

57.6

5600 K

148

150

58.0

58.8

5500 K

151

153

59.2

60.0

5400 K

154

156

60.4

61.2

5300 K

157

159

61.6

62.4

5200 K

160

162

62.7

63.5

5100 K

163

165

63.9

64.7

5000 K

166

168

65.1

65.9

4900 K

169

171

66.3

67.1

4800 K

172

174

67.5

68.2

4700 K

175

177

68.6

69.4

4600 K

178

180

69.8

70.6

4500 K

181

183

71.0

71.8

4400 K

184

186

72.2

72.9

4300 K

187

189

73.3

74.1

4200 K

190

192

74.5

75.3

4100 K

193

195

75.7

76.5

4000 K

196

198

76.9

77.6

3900 K

199

201

78.0

78.8

3800 K

202

204

79.2

80.0

3700 K

205

207

80.4

81.2

3600 K

208

210

81.6

82.4

3500 K

211

213

82.7

83.5

3400 K

214

216

83.9

84.7

3300 K

217

219

85.1

85.9

3200 K

220

222

86.3

87.1

3100 K

223

225

87.5

88.2

3000 K

226

228

88.6

89.4

2900 K

229

231

89.8

90.6

2800 K

232

234

91.0

91.8

2700 K

235

237

92.2

92.9

2600 K

238

240

93.3

94.1

2500 K

241

255

94.5

100

8

Pixel 01 Red

Pixel 01 red intensity 0-100%

0

255 0 100

255

Fade

9

Pixel 01 Green

Pixel 01 green intensity 0-100%

0

255 0 100

255

Fade

10

Pixel 01 Blue

Pixel 01 blue intensity 0-100%

0

255 0 100

255

Fade

11

Pixel 01 White

Pixel 01 white intensity 0-100%

0

255 0 100

0

Fade

12

Pixel 01 Zoom

Pixel 01 zoom wide > narrow

0

255 0 100

128

Fade

13

Pixel 02 Red

Pixel 02 red intensity 0-100%

0

255 0 100

255

Fade

14

Pixel 02 Green

Pixel 02 green intensity 0-100%

0

255 0 100

255

Fade

15

Pixel 02 Blue

Pixel 02 blue intensity 0-100%

0

255 0 100

255

Fade

16

Pixel 02 White

Pixel 02 white intensity 0-100%

0

255 0 100

0

Fade

17

Pixel 02 Zoom

Pixel 02 zoom wide > narrow

0

255 0 100

128

Fade

18

Pixel 03 Red

Pixel 03 red intensity 0-100%

0

255 0 100

255

Fade

19

Pixel 03 Green

Pixel 03 green intensity 0-100%

0

255 0 100

255

Fade

20

Pixel 03 Blue

Pixel 03 blue intensity 0-100%

0

255 0 100

255

Fade

21

Pixel 03 White

Pixel 03 white intensity 0-100%

0

255 0 100

0

Fade

22

Pixel 03 Zoom

Pixel 03 zoom wide > narrow

0

255 0 100

128

Fade

www.glp.de DMX MODE 3 impression FR10 Bar

58 impression FR10 Bar User Manual Rev. 20210901-2

23

Pixel 04 Red

Pixel 04 red intensity 0-100%

0

255 0 100

255

Fade

24

Pixel 04 Green

Pixel 04 green intensity 0-100%

0

255 0 100

255

Fade

25

Pixel 04 Blue

Pixel 04 blue intensity 0-100%

0

255 0 100

255

Fade

26

Pixel 04 White

Pixel 04 white intensity 0-100%

0

255 0 100

0

Fade

27

Pixel 04 Zoom

Pixel 04 zoom wide > narrow

0

255 0 100

128

Fade

28

Pixel 05 Red

Pixel 05 red intensity 0-100%

0

255 0 100

255

Fade

29

Pixel 05 Green

Pixel 05 green intensity 0-100%

0

255 0 100

255

Fade

30

Pixel 05 Blue

Pixel 05 blue intensity 0-100%

0

255 0 100

255

Fade

31

Pixel 05 White

Pixel 05 white intensity 0-100%

0

255 0 100

0

Fade

32

Pixel 05 Zoom

Pixel 05 zoom wide > narrow

0

255 0 100

128

Fade

33

Pixel 06 Red

Pixel 06 red intensity 0-100%

0

255 0 100

255

Fade

34

Pixel 06 Green

Pixel 06 green intensity 0-100%

0

255 0 100

255

Fade

35

Pixel 06 Blue

Pixel 06 blue intensity 0-100%

0

255 0 100

255

Fade

36

Pixel 06 White

Pixel 06 white intensity 0-100%

0

255 0 100

0

Fade

37

Pixel 06 Zoom

Pixel 06 zoom wide > narrow

0

255 0 100

128

Fade

38

Pixel 07 Red

Pixel 07 red intensity 0-100%

0

255 0 100

255

Fade

39

Pixel 07 Green

Pixel 07 green intensity 0-100%

0

255 0 100

255

Fade

40

Pixel 07 Blue

Pixel 07 blue intensity 0-100%

0

255 0 100

255

Fade

41

Pixel 07 White

Pixel 07 white intensity 0-100%

0

255 0 100

0

Fade

42

Pixel 07 Zoom

Pixel 07 zoom wide > narrow

0

255 0 100

128

Fade

43

Pixel 08 Red

Pixel 08 red intensity 0-100%

0

255 0 100

255

Fade

44

Pixel 08 Green

Pixel 08 green intensity 0-100%

0

255 0 100

255

Fade

45

Pixel 08 Blue

Pixel 08 blue intensity 0-100%

0

255 0 100

255

Fade

46

Pixel 08 White

Pixel 08 white intensity 0-100%

0

255 0 100

0

Fade

47

Pixel 08 Zoom

Pixel 08 zoom wide > narrow

0

255 0 100

128

Fade

48

Pixel 09 Red

Pixel 09 red intensity 0-100%

0

255 0 100

255

Fade

49

Pixel 09 Green

Pixel 09 green intensity 0-100%

0

255 0 100

255

Fade

50

Pixel 09 Blue

Pixel 09 blue intensity 0-100%

0

255 0 100

255

Fade

51

Pixel 09 White

Pixel 09 white intensity 0-100%

0

255 0 100

0

Fade

52

Pixel 09 Zoom

Pixel 09 zoom wide > narrow

0

255 0 100

128

Fade

53

Pixel 10 Red

Pixel 10 red intensity 0-100%

0

255 0 100

255

Fade

54

Pixel 10 Green

Pixel 10 green intensity 0-100%

0

255 0 100

255

Fade

55

Pixel 10 Blue

Pixel 10 blue intensity 0-100%

0

255 0 100

255

Fade

56

Pixel 10 White

Pixel 10 white intensity 0-100%

0

255 0 100

0

Fade

57

Pixel 10 Zoom

Pixel 10 zoom wide > narrow

0

255 0 100

128

Fade

German Light Products® DMX MODE 4 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 59

DMX Mode 4: MultiPix Advanced

79 DMX Channels

Channel

Command

DMX

range

Percent

Default

DMX

Fade

Layer 1 (Main layer)

1

Tilt coarse

Tilt backwards > forwards (16-bit)

0

65535

0

100

32768

Fade

2

Tilt fine

3

Intensity
coarse

Global intensity 0-100% (16-bit)

0

65535

0

100

32768

Fade

4

Intensity fine

5

Shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

6

Control /
Settings

No function

0

38 0 14.9

0

Snap

Dimmer curve: Soft (square) (3s
hold)

39

41

15.3

16.1

Dimmer curve: Linear (3s hold)

42

44

16.5

17.3

No function

45

53

17.6

20.8

Display mode: Off (3s hold)

54

56

21.2

22

Display mode: Auto (3s hold)

57

59

22.4

23.1

Display mode : On (3s hold)

60

62

23.5

24.3

Display orientation: Normal (3s hold)

63

65

24.7

25.5

Display orientation: Inverted (3s
hold)

66

68

25.9

26.7

No function

69

71

27.1

27.8

No DMX: Blackout (3s hold)

72

74

28.2

29.0

No DMX: Hold (3s hold)

75

77

29.4

30.2

No DMX: Captured scene (3s hold)

78

80

30.6

31.4

Capture Scene (3s hold)

81

83

31.8

32.5

No function

84

86

32.9

33.7

Fan mode: Regulated (3s hold)

87

89

34.1

34.9

Fan mode: High (3s hold)

90

92

35.3

36.1

Fan mode: Medium (3s hold)

93

95

36.5

37.3

Fan mode: Low (3s hold)

96

98

37.6

38.4

No function

99

104

38.8

40.8

Position feedback: Off (3s hold)

105

107

41.2

42.0

Position feedback: On (3s hold)

108

110

42.4

43.1

Tilt disable: Off (3s hold)

111

113

43.5

44.3

Tilt disable: Reset Disabled

114

116

44.7

45.5

Tilt disable: Current Disabled

117

119

45.9

46.7

Tilt inversion: Off (3s hold)

120

122

47.1

47.8

Tilt inversion: On (3s hold)

123

125

48.2

49.0

No function

126

128

49.4

50.2

Zoom inversion: Off (3s hold)

129

131

50.6

51.4

Zoom inversion: On (3s hold)

132

134

51.8

52.5

No function

135

140

52.9

54.9

Pixel mirror: Off (3s hold)

141

143

55.3

56.1

www.glp.de DMX MODE 4 impression FR10 Bar

60 impression FR10 Bar User Manual Rev. 20210901-2

Pixel mirror: On (3s hold)

144

146

56.5

57.3

No function

147

155

57.6

60.8

Performance: Fast (3s hold)

156

158

61,2

62,0

Performance: Normal (3s hold)

159

161

62,4

63,1

Performance: Smooth (3s hold)

162

164

63.5

64.3

No function

165

170

64.7

66.7

Color mix priority: Mix (HTP)

171

173

67.1

67.8

Color mix priority: L3-L2-L1

174

176

68.2

69.0

Color mix priority: L1-L2-L3

177

179

69.4

70.2

No function

180

191

70.6

74.9

PWM: 2200 Hz (5s hold)

192

194

75.3

76.1

PWM: 3000 Hz (5s hold)

195

197

76.5

77.3

PWM: 4800 Hz (5s hold)

198

200

77.6

78.4

PWM: 9600 Hz (5s hold)

201

203

78.8

79.6

No function

204

206

80.0

80.8

PWM: 25 kHz (5s hold)

207

209

81.2

82.0

No function

210

245

82.4

96.1

Reset Tilt (3s hold)

246

248

96.5

97.3

Reset Head (3s hold)

249

251

97.6

98.4

Reset All (3s hold)

252

255

98.8

100

7

Color
Temperature
Control

RAW 0 15 0 5.9

Snap

10000 K

16

18

6.3

7.1

9900 K

19

21

7.5

8.2

9800 K

22

24

8.6

9.4

9700 K

25

27

9.8

10.6

9600 K

28

30

11.0

11.8

9500 K

31

33

12.2

12.9

9400 K

34

36

13.3

14.1

9300 K

37

39

14.5

15.3

9200 K

40

42

15.7

16.5

9100 K

43

45

16.9

17.6

9000 K

46

48

18.0

18.8

8900 K

49

51

19.2

20.0

8800 K

52

54

20.4

21.2

8700 K

55

57

21.6

22.4

8600 K

58

60

22.7

23.5

8500 K

61

63

23.9

24.7

8400 K

64

66

25.1

25.9

8300 K

67

69

26.3

27.1

8200 K

70

72

27.5

28.2

8100 K

73

75

28.6

29.4

8000 K

76

78

29.8

30.6

7900 K

79

81

31.0

31.8

7800 K

82

84

32.2

32.9

7700 K

85

87

33.3

34.1

7600 K

88

90

34.5

35.3

7500 K

91

93

35.7

36.5

7400 K

94

96

36.9

37.6

7300 K

97

99

38.0

38.8

7200 K

100

102

39.2

40.0

7100 K

103

105

40.4

41.2

7000 K

106

108

41.6

42.4

6900 K

109

111

42.7

43.5

6800 K

112

114

43.9

44.7

6700 K

115

117

45.1

45.9

6600 K

118

120

46.3

47.1

6500 K

121

123

47.5

48.2

6400 K

124

126

48.6

49.4

German Light Products® DMX MODE 4 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 61

6300 K

127

129

49.8

50.6

6200 K

130

132

51.0

51.8

6100 K

133

135

52.2

52.9

6000 K

136

138

53.3

54.1

5900 K

139

141

54.5

55.3

5800 K

142

144

55.7

56.5

5700 K

145

147

56.9

57.6

5600 K

148

150

58.0

58.8

5500 K

151

153

59.2

60.0

5400 K

154

156

60.4

61.2

5300 K

157

159

61.6

62.4

5200 K

160

162

62.7

63.5

5100 K

163

165

63.9

64.7

5000 K

166

168

65.1

65.9

4900 K

169

171

66.3

67.1

4800 K

172

174

67.5

68.2

4700 K

175

177

68.6

69.4

4600 K

178

180

69.8

70.6

4500 K

181

183

71.0

71.8

4400 K

184

186

72.2

72.9

4300 K

187

189

73.3

74.1

4200 K

190

192

74.5

75.3

4100 K

193

195

75.7

76.5

4000 K

196

198

76.9

77.6

3900 K

199

201

78.0

78.8

3800 K

202

204

79.2

80.0

3700 K

205

207

80.4

81.2

3600 K

208

210

81.6

82.4

3500 K

211

213

82.7

83.5

3400 K

214

216

83.9

84.7

3300 K

217

219

85.1

85.9

3200 K

220

222

86.3

87.1

3100 K

223

225

87.5

88.2

3000 K

226

228

88.6

89.4

2900 K

229

231

89.8

90.6

2800 K

232

234

91.0

91.8

2700 K

235

237

92.2

92.9

2600 K

238

240

93.3

94.1

2500 K

241

255

94.5

100

8

Virtual color
wheel

Off (RGBW)

0 7 0

2.7

0

Snap

Color 01 - Red

8

15

3.1

5.9

Snap

Color 02 - Amber

16

23

6.3

9.0

Snap

Color 03 - Warm Yellow

24

31

9.4

12.2

Snap

Color 04 - Yellow

32

39

12.5

15.3

Snap

Color 05 - Green

40

47

15.7

18.4

Snap

Color 06 - Turquoise

48

55

18.8

21.6

Snap

Color 07 - Cyan

56

63

22.0

24.7

Snap

Color 08 - Blue

64

71

25.1

27.8

Snap

Color 09 - Lavender

72

79

28.2

31.0

Snap

Color 10 - Male

80

87

31.4

34.1

Snap

Color 11 - Magenta

88

95

34.5

37.3

Snap

Color 12 - Pink

96

103

37.6

40.4

Snap

Color 13 - White 3200K

104

111

40.8

43.5

Snap

Color 14 - White 5600K

112

119

43.9

46.7

Snap

Color 15 - White 7200K

120

127

47.1

49.8

Snap

Stop

128

128

50.2

50.2

Snap

Rainbow colors crossfade slow > fast

129

223

50.6

87.5

Fade

Random colors crossfade slow > fast

224

255

87.8

100

Fade

www.glp.de DMX MODE 4 impression FR10 Bar

62 impression FR10 Bar User Manual Rev. 20210901-2

9

Red

Red intensity 0-100%

0

255 0 100

255

Fade

10

Green

Green intensity 0-100%

0

255 0 100

255

Fade

11

Blue

Blue intensity 0-100%

0

255 0 100

255

Fade

12

White

White intensity 0-100%

0

255 0 100

0

Fade

13

Pixel FX
pattern select

No effect

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random pixel FX pattern

246

250

96.5

98.0

Random pixel FX

251

255

98.4

100

German Light Products® DMX MODE 4 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 63

14

Pixel FX
pattern static
position /
dynamic
movement

Pattern static Step 01

0 5 0.0

2.0 0 Snap

Pattern static Step 02

6

11

2.4

4.3

Snap

Pattern static Step 03

12

17

4.7

6.7

Snap

Pattern static Step 04

18

23

7.1

9.0

Snap

Pattern static Step 05

24

29

9.4

11.4

Snap

Pattern static Step 06

30

35

11.8

13.7

Snap

Pattern static Step 07

36

41

14.1

16.1

Snap

Pattern static Step 08

42

47

16.5

18.4

Snap

Pattern static Step 09

48

53

18.8

20.8

Snap

Pattern static Step 10

54

59

21.2

23.1

Snap

Pattern static Step 11

60

65

23.5

25.5

Snap

Pattern static Step 12

66

71

25.9

27.8

Snap

Pattern static Step 13

72

77

28.2

30.2

Snap

Pattern static Step 14

78

83

30.6

32.5

Snap

Pattern static Step 15

84

89

32.9

34.9

Snap

Pattern static Step 16

90

95

35.3

37.3

Snap

Pattern static Step 17

96

101

37.6

39.6

Snap

Pattern static Step 18

102

107

40.0

42.0

Snap

Pattern static Step 19

108

113

42.4

44.3

Snap

Pattern static Step 20

114

119

44.7

46.7

Snap

Stop / no function

120

127

47.1

49.8

Snap

Pattern dynamic, forwards
fast > slow (run pattern from Step 1
to end in loop)

128

190

50.2

74.5

Fade

Stop

191

192

74.9

75.3

Snap

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

Fade

15

Pixel pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

16

Pixel FX
transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FOB (fade over blackout) transition,
0s to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOF (fade over full intensity) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

17

Pixel FX
pattern length

Off (pattern length normal)

0 0 0

0 0 Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

18

Pixel FX
pattern offset

Off (pattern starts at first pixel)

0 0 0

0 0 Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

19

Zoom

Narrow > wide

0

255 0 100

0

Snap

www.glp.de DMX MODE 4 impression FR10 Bar

64 impression FR10 Bar User Manual Rev. 20210901-2

20

Zoom FX
pattern select

No effect, all lenses have normal
zoom functionality

0

10 0 3.9

0

Snap

Pattern 01

11

14

4.3

5.5

Pattern 02

15

18

5.9

7.1

Pattern 03

19

22

7.5

8.6

Pattern 04

23

26

9.0

10.2

Pattern 05

27

30

10.6

11.8

Pattern 06

31

34

12.2

13.3

Pattern 07

35

38

13.7

14.9

Pattern 08

39

42

15.3

16.5

Pattern 09

43

46

16.9

18.0

Pattern 10

47

50

18.4

19.6

Pattern 11

51

54

20.0

21.2

Pattern 12

55

58

21.6

22.7

Pattern 13

59

62

23.1

24.3

Pattern 14

63

66

24.7

25.9

Pattern 15

67

70

26.3

27.5

Pattern 16

71

74

27.8

29.0

Pattern 17

75

78

29.4

30.6

Pattern 18

79

82

31.0

32.2

Pattern 19

83

86

32.5

33.7

Pattern 20

87

90

34.1

35.3

Pattern 21

91

94

35.7

36.9

Pattern 22

95

98

37.3

38.4

Pattern 23

99

102

38.8

40.0

Pattern 24

103

106

40.4

41.6

Pattern 25

107

110

42.0

43.1

Pattern 26

111

114

43.5

44.7

Pattern 27

115

118

45.1

46.3

Pattern 28

119

122

46.7

47.8

Pattern 29

123

126

48.2

49.4

Pattern 30

127

130

49.8

51.0

Pattern 31

131

134

51.4

52.5

Pattern 32

135

138

52.9

54.1

Pattern 33

139

142

54.5

55.7

Pattern 34

143

146

56.1

57.3

Pattern 35

147

150

57.6

58.8

Pattern 36

151

154

59.2

60.4

Pattern 37

155

158

60.8

62.0

Pattern 38

159

162

62.4

63.5

Pattern 39

163

166

63.9

65.1

Pattern 40

167

170

65.5

66.7

Pattern 41

171

174

67.1

68.2

Pattern 42

175

178

68.6

69.8

Pattern 43

179

182

70.2

71.4

Pattern 44

183

186

71.8

72.9

Pattern 45

187

190

73.3

74.5

Pattern 46

191

194

74.9

76.1

Pattern 47

195

198

76.5

77.6

Pattern 48

199

202

78.0

79.2

Pattern 49

203

206

79.6

80.8

Pattern 50

207

210

81.2

82.4

No pattern – no function

211

246

82.7

96.5

Random zoom FX pattern

246

250

96.5

98.0

Random pixel zoom

251

255

98.4

100

German Light Products® DMX MODE 4 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 65

21

Zoom FX static
pattern
position /
dynamic
pattern
movement

Pattern static Step 01

0 5 0.0

2.0

0

Snap

Pattern static Step 02

6

11

2.4

4.3

Pattern static Step 03

12

17

4.7

6.7

Pattern static Step 04

18

23

7.1

9.0

Pattern static Step 05

24

29

9.4

11.4

Pattern static Step 06

30

35

11.8

13.7

Pattern static Step 07

36

41

14.1

16.1

Pattern static Step 08

42

47

16.5

18.4

Pattern static Step 09

48

53

18.8

20.8

Pattern static Step 10

54

59

21.2

23.1

Pattern static Step 11

60

65

23.5

25.5

Pattern static Step 12

66

71

25.9

27.8

Pattern static Step 13

72

77

28.2

30.2

Pattern static Step 14

78

83

30.6

32.5

Pattern static Step 15

84

89

32.9

34.9

Pattern static Step 16

90

95

35.3

37.3

Pattern static Step 17

96

101

37.6

39.6

Pattern static Step 18

102

107

40.0

42.0

Pattern static Step 19

108

113

42.4

44.3

Pattern static Step 20

114

119

44.7

46.7

Stop / no function

120

127

47.1

49.8

Pattern dynamic, forwards fast >
slow (run pattern from Step 1 to end
in loop)

128

190

50.2

74.5

Stop

191

192

74.9

75.3

Pattern dynamic, backwards
slow > fast (run pattern from end to
Step 1 in loop)

193

255

75.7

100.0

22

Zoom pattern
FX crossfade
(Xfade
between
steps)

Off (no crossfade between steps in
pattern)

0

10

0.0

3.9

0

Snap

1 – 3 sec. crossfade

11

125

4.3

49.0

Fade

Stop

126

130

49.4

51.0

Snap

1 – 3 sec. crossfade with tail

131

255

51.4

100.0

Fade

23

Zoom pattern
FX transition
(Xfade
between
patterns)

No transition time, snap

0

10

0.0

3.9

0

Snap

Normal transition, 0s to 5s crossfade

11

68

4.3

26.7

Fade

No transition time, snap

69

73

27.1

28.6

Snap

FON (fade over narrow) transition, 0s
to 5s crossfade

74

130

29.0

51.0

Fade

No transition time, snap

131

135

51.4

52.9

Snap

FOW (fade over wide) 0s to 5s
crossfade

136

193

53.3

75.7

Fade

No function

194

255

76.1

100.0

24

Zoom pattern
FX length

Off (pattern length normal)

0 0 0

0 0 Snap

Pattern length 1 > 255 steps

1

255

0.4

100

Fade

25

Zoom pattern
FX offset

Off (pattern starts at first pixel)

0 0 0

0 0 Snap

Pattern start offset 1 > 255 pixels

1

255

0.4

100

Fade

www.glp.de DMX MODE 4 impression FR10 Bar

66 impression FR10 Bar User Manual Rev. 20210901-2

Layer 2 (individual pixel intensity layer)

26

Layer 2 master
coarse

Layer 2 (pixel intensity) master
0-100% (16-bit)

0

65535

0

100

32768

Fade

27

Layer 2 master
fine

28

Layer 2 shutter

Shutter closed

0 4 0

1.6

255

Snap

Dimmer flash (at intensity change)

5 9 2.0

3.5

Snap

Pulse slow > fast

10

39

3.9

15.3

Fade

Opening pulse slow > fast

40

69

15.7

27.1

Fade

Closing pulse slow > fast

70

99

27.5

38.8

Fade

Double flash slow > fast

100

129

39.2

50.6

Fade

Random pixel strobe slow > fast

130

159

51.0

62.4

Fade

Random all strobe slow > fast

160

199

62.7

78.0

Fade

Strobe sync all pixels 1Hz > 10Hz

200

250

78.4

98.0

Fade

Open

251

255

98.4

100

Snap

29

Pixel 01 Red

Pixel 01 red intensity 0-100%

0

255 0 100

255

Fade

30

Pixel 01 Green

Pixel 01 green intensity 0-100%

0

255 0 100

255

Fade

31

Pixel 01 Blue

Pixel 01 blue intensity 0-100%

0

255 0 100

255

Fade

32

Pixel 01 White

Pixel 01 white intensity 0-100%

0

255 0 100

0

Fade

33

Pixel 02 Red

Pixel 02 red intensity 0-100%

0

255 0 100

255

Fade

34

Pixel 02 Green

Pixel 02 green intensity 0-100%

0

255 0 100

255

Fade

35

Pixel 02 Blue

Pixel 02 blue intensity 0-100%

0

255 0 100

255

Fade

36

Pixel 02 White

Pixel 02 white intensity 0-100%

0

255 0 100

0

Fade

37

Pixel 03 Red

Pixel 03 red intensity 0-100%

0

255 0 100

255

Fade

38

Pixel 03 Green

Pixel 03 green intensity 0-100%

0

255 0 100

255

Fade

39

Pixel 03 Blue

Pixel 03 blue intensity 0-100%

0

255 0 100

255

Fade

40

Pixel 03 White

Pixel 03 white intensity 0-100%

0

255 0 100

0

Fade

41

Pixel 04 Red

Pixel 04 red intensity 0-100%

0

255 0 100

255

Fade

42

Pixel 04 Green

Pixel 04 green intensity 0-100%

0

255 0 100

255

Fade

43

Pixel 04 Blue

Pixel 04 blue intensity 0-100%

0

255 0 100

255

Fade

44

Pixel 04 White

Pixel 04 white intensity 0-100%

0

255 0 100

0

Fade

45

Pixel 05 Red

Pixel 05 red intensity 0-100%

0

255 0 100

255

Fade

46

Pixel 05 Green

Pixel 05 green intensity 0-100%

0

255 0 100

255

Fade

47

Pixel 05 Blue

Pixel 05 blue intensity 0-100%

0

255 0 100

255

Fade

48

Pixel 05 White

Pixel 05 white intensity 0-100%

0

255 0 100

0

Fade

49

Pixel 06 Red

Pixel 06 red intensity 0-100%

0

255 0 100

255

Fade

50

Pixel 06 Green

Pixel 06 green intensity 0-100%

0

255 0 100

255

Fade

51

Pixel 06 Blue

Pixel 06 blue intensity 0-100%

0

255 0 100

255

Fade

52

Pixel 06 White

Pixel 06 white intensity 0-100%

0

255 0 100

0

Fade

53

Pixel 07 Red

Pixel 07 red intensity 0-100%

0

255 0 100

255

Fade

54

Pixel 07 Green

Pixel 07 green intensity 0-100%

0

255 0 100

255

Fade

55

Pixel 07 Blue

Pixel 07 blue intensity 0-100%

0

255 0 100

255

Fade

56

Pixel 07 White

Pixel 07 white intensity 0-100%

0

255 0 100

0

Fade

57

Pixel 08 Red

Pixel 08 red intensity 0-100%

0

255 0 100

255

Fade

58

Pixel 08 Green

Pixel 08 green intensity 0-100%

0

255 0 100

255

Fade

59

Pixel 08 Blue

Pixel 08 blue intensity 0-100%

0

255 0 100

255

Fade

60

Pixel 08 White

Pixel 08 white intensity 0-100%

0

255 0 100

0

Fade

61

Pixel 09 Red

Pixel 09 red intensity 0-100%

0

255 0 100

255

Fade

62

Pixel 09 Green

Pixel 09 green intensity 0-100%

0

255 0 100

255

Fade

63

Pixel 09 Blue

Pixel 09 blue intensity 0-100%

0

255 0 100

255

Fade

64

Pixel 09 White

Pixel 09 white intensity 0-100%

0

255 0 100

0

Fade

65

Pixel 10 Red

Pixel 10 red intensity 0-100%

0

255 0 100

255

Fade

66

Pixel 10 Green

Pixel 10 green intensity 0-100%

0

255 0 100

255

Fade

67

Pixel 10 Blue

Pixel 10 blue intensity 0-100%

0

255 0 100

255

Fade

68

Pixel 10 White

Pixel 10 white intensity 0-100%

0

255 0 100

0

Fade

German Light Products® DMX MODE 4 impression FR10 Bar

impression FR10 Bar User Manual Rev. 20210901-2 67

Layer 3 (individual pixel zoom layer)

69

Pixel zoom
master

Layer 3 (pixel zoom) master 0-100%

0

255 0 100

128

Fade

70

Pixel 01 Zoom

Pixel 01 zoom wide > narrow

0

255 0 100

128

Fade

71

Pixel 02 Zoom

Pixel 02 zoom wide > narrow

0

255 0 100

128

Fade

72

Pixel 03 Zoom

Pixel 03 zoom wide > narrow

0

255 0 100

128

Fade

73

Pixel 04 Zoom

Pixel 04 zoom wide > narrow

0

255 0 100

128

Fade

74

Pixel 05 Zoom

Pixel 05 zoom wide > narrow

0

255 0 100

128

Fade

75

Pixel 06 Zoom

Pixel 06 zoom wide > narrow

0

255 0 100

128

Fade

76

Pixel 07 Zoom

Pixel 07 zoom wide > narrow

0

255 0 100

128

Fade

77

Pixel 08 Zoom

Pixel 08 zoom wide > narrow

0

255 0 100

128

Fade

78

Pixel 09 Zoom

Pixel 09 zoom wide > narrow

0

255 0 100

128

Fade

79

Pixel 10 Zoom

Pixel 10 zoom wide > narrow

0

255 0 100

128

Fade
