GLP Impression 300 XL RZ RGB Instruction Manual
Instruction Manual
from Software Version 1.01/03/02
(Manual Version 1.2)
e-mail: service@glp.de
Internet: http://www.glp.de
3
3
3
0
0
0
0
0
0
X
X
X
L
L
L
R
R
R
Z
Z
Z
R
R
R
G
G
G
B
B
B
GLP German Light Products GmbH
(Manual Version 1.2) / from Software Version 1.01/03/02)
2
For your notes:
3
3
3
0
0
0
0
0
0
X
X
X
L
L
L
R
R
R
Z
Z
Z
R
R
R
G
G
G
B
B
B
GLP German Light Products GmbH
(Manual Version 1.2) / from Software Version 1.01/03/02)
3
Table of content
1 Description of Device ........................................................................................................ 4
1.1 Safety Instructions .......................................................................................................................5
2 Preparation and Installation.............................................................................................. 6
2.1 Mounting ......................................................................................................................................6
2.1.1
Mounting on the floor (upright) ....................................................................................7
2.1.2
Mounting in hanging position (Head down) .................................................................7
2.1.3
Mounting in sideway position .......................................................................................8
2.2 Securing the Device ....................................................................................................................9
2.3 Connections .................................................................................................................................9
2.3.1
Power Supply ...............................................................................................................9
2.3.2
DMX .............................................................................................................................9
3 The Menu Field .................................................................................................................. 9
4 DMX Channel Sheet ......................................................................................................... 12
5
5 Maintaining and Cleaning the IIMMPPRREESSSSIIOONN 330000 XXLL RRZZ RRGGBB ....................................... 17
5.1 Safety regulations ..................................................................................................................... 17
5.2 Maintenance Intervals (rule-of-thumb) ..................................................................................... 17
6 Technical Specifications ................................................................................................. 18
7 Index ................................................................................................................................. 19
3
3
3
0
0
0
0
0
0
X
X
X
L
L
L
R
R
R
Z
Z
Z
R
R
R
G
G
G
B
B
B
GLP German Light Products GmbH
(Manual Version 1.2) / from Software Version 1.01/03/02)
4
1 Description of Device
1. Moving head (actively and
passively cooled)
2. Arm with various cooling
vents
3. Tilt-lock to secure and lock
the tilt movement see also
1.1
4. LCD-Display/Menu (data
entry)
5. Base with various connectors
and Camlock mounting
system
Safety eyelets
1
2
4
5
3
base side 1
10
678910
base side 2
11
12
13
14
6. DMX- Output (5 Pin)
7. DMX- Output (3 Pin)
8. Micro-fuse 6.3x32mm, T15A
9. Power On/Off
10. 2x Safety eyelets
11. Powercon (Mains supply)
12. Blank panel
13. DMX- Input (3 Pin)
14. DMX- Input (5 in)
Note: Only connect one cable to the
DMX-Out/Input at a time!
3
3
3
0
0
0
0
0
0
X
X
X
L
L
L
R
R
R
Z
Z
Z
R
R
R
G
G
G
B
B
B
GLP German Light Products GmbH
(Manual Version 1.2) / from Software Version 1.01/03/02)
5
1.1 Safety Instructions
The
IIMMPPRREESSSSIIOONN 330000 XXLL RRZZ RRGGBB
is an advanced technology product.
To guarantee smooth operation, it is necessary to follow the following
instructions.
The manufacturer of this device will not take responsibility of damages
through any disregard of the information in this user manual. Warranty claims
will also be cancelled in the event of the system casing being opened.
1. Make sure that before powering up the fixture, the fans and air inlets are
clean and not blocked by anything.
2. Before powering up the fixture, ensure that the moving head part of the
fixture can rotate unhindered through its full range of movement.
3. A safety distance of at least 0.5 m to any easily flammable material (e.g.
decoration material) must be adhered to.
4. Attention! Don’t touch the device during operation. Parts of the fixture can
become hot and can cause injuries and / or damages.
5. The system doesn’t contain any user serviceable parts. Opening the fixture
will void the manufacturers warranty.
6. Danger of burning. Wait at least 15 minutes after disconnecting the AC
power before changing the optical carrier on the fixture. Pay attention to
possible hot parts of the system.
7.
Never look directly into the beam of light or one of the LEDs. Never use
optical apertures with a distance less than 0.5 m to observe the beam of
light. LED Class 2M. Not following these precautions can result in serious
injury to your eyes and in particular, your retina.
Attention: LED Class 2M can cause in
juries of your eyes even
without optical instruments in front of them or within a distance
of less than 0.5m and short exposure time.
Avoid direct radiation to your eyes!
8. To ensure proper operation, you must also follow the installation guide
described in chapter 2 of this manual. Operating the IIMMPPRREESSSSIIOONN 330000 XXLL
RRZZ RRGGBB
without suitable mounting devices can increase the risk of an
accident.
9. The IIMMPPRREESSSSIIOONN 330000 XXLL RRZZ RRGGBB features a unique small and lightweight
design with no specific carrying handles. Care needs to be shown when
handling the fixture to ensure that no unnecessary damage should occur.
Fragile areas include the LCD display and cover on one side arm and the
front bezel. Pressure in these areas could result in damages which will not
3
3
3
0
0
0
0
0
0
X
X
X
L
L
L
R
R
R
Z
Z
Z
R
R
R
G
G
G
B
B
B
GLP German Light Products GmbH
(Manual Version 1.2) / from Software Version 1.01/03/02)
6
be covered by the standard warranty.
10. Repair-, maintenance- and installation work should only be performed by
qualified or GLP certified staff. You need to pay attention to the common
rules of technology that are not explicit mentioned in this manual.
11. Use only original spare parts. Any structural modification on the system will
terminate all warranty claims.
12.
Please keep this instruction manual for future reference.
2 Preparation and Installation
2.1 Mounting
The IIMMPPRREESSSSIIOONN 330000 XXLL RRZZ RRGGBB is fully operational whether it hangs or is
mounted to a wall. It can also be operated while standing on the floor. Keep a
safety distance of 0.5 m from any easily inflammable materials (decoration etc.).
Pay attention to the regulations of: BGV C1 (former VBG 70)
and DIN VDE 0711-217.
The installation shall be done by qualified personal only.
For the various mounting positions of the IIMMPPRREESSSSIIOONN 330000 XXLL RRZZ RRGGBB
(standing on the floor, sideways or hanging) different accessories kits are
available. Using any required kits, along with the standard mounting connectors
on the base of the fixture, will ensure a safe and firm installation.
